Spanish Quick Use Guide is included. Guía para rápida consulta en español está incluida. For USA assistance, please call: 1-800-211-PANA(7262) or send e-mail to : consumerproducts@panasonic.com For Canadian assistance, please call: 1-800-561-5505 or visit us at www.panasonic.ca Digital Video Camcorder...
Panasonic Responsible party: Matsushita Electric Corporation of America Address: One Panasonic Way, Secaucus, New Jersey 07094 Telephone number: 1-800-211-PANA (7262) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
Page 4
Precautions USE & LOCATION ≥TO AVOID SHOCK HAZARD ... Your Palmcorder and power supply should not be exposed to rain or moisture. Do not connect the power supply or operate your Palmcorder if it gets wet. Your Palmcorder has been designed for outdoor use, however, it is not designed to sustain direct exposure to water, rain, sleet, snow, sand, dust, or a direct splashing from a pool or even a cup of...
Contents Before Using Standard Accessories ... 6 Quick Guide... 7 To View the Playback Picture... 7 Controls and Components... 8 Remote Controller ... 10 Power Supply ... 12 Charging Time and Available Recording Time... 12 Attaching the Lens Cap ... 13 Adjusting the Grip Belt...
POWER CHARGE QUICK 100% MODE OFF ON CAMERA CARD P. B. POWER OPEN/EJECT MODE OFF ON CAMERA CARD P. B. POWER 6, 7 OFF ON MODE CAMERA CARD P. B. POWER BACKLIGHT CAMERA STILL Quick Guide Charge the Battery. (l 12) ≥Connect the AC Cable to the AC Adaptor and plug it into Wall Outlet.
START/ PHOTO DATE/ STOP SHOT TIME COUNTER RESET TITLE ZOOM MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV INDEX STOP INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU OFF/ON ITEM P.B.DIGITAL START/ DATE/ PHOTO STOP TIME SHOT COUNTER RESET...
Never put Button-Type battery in mouth. If swallowed, call your doctor. Replace battery with Panasonic PART NO. VSBW0004 (CR2025) only. Use of another battery may present a risk of fire or explosion. Caution: Battery may explode if mistreated.
POWER CHARGE QUICK 100% OFF ON CAMERA CARD P. B. 1 h 10 min. CGA-D07 1 h. (55 min.) CGR-D08A/1B 1 h. 1 h 15 min. (1 h 5 min.) 1 h 10 min. CGR-D16A/1B 2 h 30 min. (2 h 5 min.) CGR-D53A/1K 4 h 30 min.
OPEN/EJECT R E C SAVE Attaching the Lens Cap To protect the Lens surface, attach the Lens Cap. Pass the loop of the Lens Cap Cord through the Lens Cap Installation Hole on the Palmcorder. Pass the opposite side of the Lens Cap Cord through the cord’s hoop.
OFF ON CAMERA CARD P. B. 1, 2, 3 12:30:45PM 12:30:45PM 12:30:45PM 12:30:45PM OCT 10 2002 OCT 10 2002 OCT 10 2002 OCT 10 2002 MODE OFF ON 180x Turning on/off the Palmcorder and Selecting Modes Turn on the power first and then select Modes. ª...
2, 3, 4, 5 CAMERA W.B./SHUTTER/IRIS/ MF/VOL/JOG CARD P. B. PUSH START/ DATE/ PHOTO STOP TIME SHOT COUNTER RESET TITLE ZOOM MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV INDEX STOP INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU...
Ω º List of Menus The illustrations of the Menus are for explanation purposes only, and they are different from the actual Menus. Camera Mode Main-Menu [CAMERA FUNCTIONS] [CAMERA SETUP] Sub-Menu 1) Auto Exposure Mode [PROG.AE] (l 23) 2) Progressive PhotoShot Mode [PROGRESSIVE] (l 21) 3) Digital Electronic Image Stabilizer [EIS] (l 22) 4) Digital Zoom [D.ZOOM] (l 22)
1, 2 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH 1, 3 Setting Date and Time Press the [MENU] Button and rotate the [PUSH] Dial to select [OTHER FUNCTIONS] >> [CLOCK-SET] >> [YES]. Rotate and press the [PUSH] Dial to select [YEAR]/[MONTH]/[DAY]/[HOUR]/[MINUTE] and set it to a desired value.
STILL MPEG4 VOICE AUTO MANUAL RESET CARD MODE OFF ON MODE CAMERA CARD P. B. POWER ACCESS PAUSE PAUSE RECORD BACKLIGHT CAMERA STILL ° CAMERA Mode Recording Set the [OFF/ON/MODE] Switch to [ON]. ≥The [CAMERA] Lamp lights up. Slide the [TAPE/CARD] Selector towards [TAPE]. Press the Recording Start/Stop Button.
BACKLIGHT CAMERA STILL PHOTO SHOT TAPE CARD PHOTO PHOTO PHOTO PHOTO 1t W 5t W 10t W PhotoShot Recording on the DV Cassette With this function, you can record still pictures with sound for approximately 7 seconds each on the Cassette. Slide the [TAPE/CARD] Selector to [TAPE].
W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH 20t W D.ZOOM W.B./SHUTTER/IRIS/ Digital Zoom Function This function is useful when you want to record close-up shots of subjects located beyond a normal zoom range of 1k to 10k magnification. With the Digital Zoom Function, you can select a magnification of 25k or 200k. Set [CAMERA FUNCTIONS] >>...
CINEMA W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH ª BACKLIGHT W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH AUTO MANUAL FOCUS Cinema Function This function is for recording in a cinema-like wide screen. Set [CAMERA FUNCTIONS] >> [CAMERA SETUP] >> [CINEMA] >> [ON]. ≥Black bars appear at the top and bottom of the screen. To Cancel the Cinema Mode Set [CAMERA FUNCTIONS] >>...
2, 3 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH AUTO MANUAL FOCUS 1AWB 2, 3 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH AUTO MANUAL FOCUS 10 000K 9 000K 8 000K 7 000K 6 000K 5 000K 4 000K 3 000K 2 000K 1 000K Recording in Natural Colors (White Balance) Depending on the scene or light conditions, the Automatic White Balance Adjustment Mode may not be able to bring out natural colors.
ª Multi-Picture Mode Strobe Multi-Picture Mode W.B./SHUTTER/IRIS/ You can capture and record 9 consecutive small still pictures. MF/VOL/JOG Manual Multi-Picture Mode PUSH 1, 2 You can manually capture and record 9 small still pictures. After setting [CAMERA FUNCTIONS] >> [DIGITAL EFFECT] >> [EFFECT1] >>...
BACKLIGHT CAMERA STILL W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH OFF ON MODE CAMERA CARD P. B. POWER W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH BACKLIGHT CAMERA STILL Playing Back The recorded scene can be played back immediately after recording. Slide the [OFF/ON/MODE] Switch and set the Palmcorder in the VCR Mode.
START/ DATE/ PHOTO STOP TIME SHOT COUNTER RESET TITLE ZOOM MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV INDEX STOP INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU OFF/ON ITEM P.B.DIGITAL W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH BACKLIGHT CAMERA STILL START/ DATE/...
W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH START/ DATE/ PHOTO STOP TIME SHOT COUNTER RESET TITLE ZOOM MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV INDEX STOP INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU OFF/ON ITEM P.B.DIGITAL INDEX Index Search Functions To facilitate searching of desired scene, this Palmcorder automatically records index signals during recording, as explained in the following.
START/ DATE/ PHOTO STOP SHOT TIME COUNTER RESET TITLE ZOOM MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV STOP INDEX INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU OFF/ON ITEM P.B.DIGITAL ZOOM 2t START/ DATE/ PHOTO STOP TIME SHOT...
1, 2 BACKLIGHT CAMERA W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH START/ DATE/ PHOTO STOP TIME SHOT COUNTER RESET TITLE ZOOM MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV INDEX STOP INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU OFF/ON ITEM P.B.DIGITAL ª...
CAMERA RELEASE CAMERA RELEASE OPEN Special Features DV Camera Style and SD Camera Style This is a Digital Video Camera which can be used in two ways depending on the situation. One is the DV Camera Style Video Unit , and the other is the SD Camera Style Camera Unit and the supplied Battery Adaptor Unit DV Camera Style...
ACCESS CARD EJECT STILL MPEG4 VOICE CARD MODE TAPE CARD W.B./SHUTTER/IRIS/ 3, 4 MF/VOL/JOG PUSH BACKLIGHT CAMERA STILL PHOTO SHOT Using a Memory Card A Card can be used to record files or play back files. ≥Use genuine SD Memory Card or MultiMediaCard only. ª...
Page 36
STILL MPEG4 VOICE RESET OFF ON MODE CAMERA CARD P. B. POWER TAPE ACCESS CARD W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH BACKLIGHT CAMERA PHOTO SHOT ª Card PhotoShot (continued) Recording from a Cassette (VCR Mode) Slide the [TAPE/CARD] Selector to [CARD]. Slide the [STILL/MPEG4/VOICE] Selector to [STILL]. Set [VCR FUNCTIONS] >>...
W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH BACKLIGHT CAMERA STILL W.B./SHUTTER/IRIS/ MF/VOL/JOG PHOTO SHOT PUSH æ £ ß F 7 640 ª Automatically copying still pictures recorded on a cassette The Palmcorder copies images automatically, referring to Photo Index signals. After setting the Palmcorder to the VCR Mode (l 28)... Set the Palmcorder to Still Playback Mode just before the point where picture transfer is to commence.
Page 38
2, , 2 STILL MPEG4 VOICE 3, , 3 TAPE 1, , 1 CARD R: 0h20m STILL MPEG4 VOICE CARD MODE TAPE CARD R: 0h20m ª Recording Moving Pictures You can record moving pictures for e-mailing on a Memory Card. The recorded data can be also played back on Windows Media Player.
3, , 3 BACKLIGHT CAMERA STILL 2, , 2 STILL MPEG4 VOICE RESET CARD MODE OFF ON MODE CAMERA CARD P. B. POWER ACCESS 1, , 1 CARD CONTENTS PICTURE MPEG4 VOICE PICTURE 100-0012 MPEG4 MOL012.ASF VOICE Playing Back Files from the Memory Card It allows you to play back files recorded on a Card.
4, , W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH BACKLIGHT CAMERA STILL STILL MPEG4 VOICE RESET OFF ON MODE CAMERA CARD P. B. POWER ACCESS PICTURE 1200 1200 No.25 100-0012 No.3 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH TAPE CARD STILL MPEG4 VOICE RESET OFF ON MODE CAMERA CARD P.
1, 2, 3, 4, 5, 7 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH 1, 6, 7 BACKLIGHT 1200 1200 M.SLIDE SLIDE SLIDE Slide Show The recorded still pictures in the Card can be played back like a Slide Show. You can set up a Slide Show or change the content. To Select Pictures to Play Back in Your Slide Show After setting the [STILL/MPEG4/VOICE] Switch to [STILL], set [CARD FUNCTIONS] >>...
2, 4, 5, 6, 7, 8 W.B./SHUTTER/IRIS/ MF/VOL/JOG W.B./SHUTTER/IRIS/ 3, 4 MF/VOL/JOG PUSH 2, 4 TAPE CARD TITLE USR00002.TTL Creating a Title You can create a title and record on a Memory Card. Camera Mode: Slide the [STILL/MPEG4/VOICE] Selector to [STILL] and point the camera at the image you want to use for creating a title.
W.B./SHUTTER/IRIS/ 1, 2, 3 MF/VOL/JOG PUSH 1, 2, 4 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH PHOTO SHOT Protecting the Files on a Memory Card from Accidental Erasure (File Lock) Precious files recorded on a Memory Card can be locked to prevent accidental erasure. (Even if files are locked, the files will be deleted when the Memory Card is formatted.) After setting the Palmcorder to the Card Playback Mode (l 39)...
W.B./SHUTTER/IRIS/ 1, 2 MF/VOL/JOG PUSH W.B./SHUTTER/IRIS 2, 3, 4, 5 MF/VOL/JOG PUSH STILL MPEG4 VOICE Formatting a Memory Card If a Memory Card becomes unreadable by the Palmcorder, formatting it may make it reusable. Formatting will delete all the data recorded on a Memory Card.
START/ DATE/ PHOTO STOP SHOT TIME COUNTER RESET TITLE ZOOM MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV INDEX STOP INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU OFF/ON ITEM P.B.DIGITAL Using your Palmcorder with Digital Video Equipment (Dubbing) By connecting this Palmcorder with other digital video equipment (such as...
3 3 3 3 4, 5 4, 5 4, 5 4, 5 Using the Software with a Computer An image stored on the DV Cassette can be transferred to your Personal Computer. ª System Requirements for ArcSoft ≥CD-ROM drive (for installation) (for ArcSoft Software) ®...
ArcSoft Software There are 4 types of image editing software in the ArcSoft Software package. Before you begin... Open [Start] >> [Programs] >> [ArcSoft] >> [Panorama Maker 3.0] or [PhotoImpression 3.0] or [PhotoBase 3.0] or [PhotoPrinter 2000 Pro]. Panorama Maker 3.0 (Windows, Mac) ≥Easy-to-use photo-stitching program seamlessly combines multiple photos into a single panoramic picture.
VFA0366 LSFT0489 TO PC Using the Supplied USB Connection Kit ª Operating environment USB Driver can be installed in a PC/AT compatible personal computer ® which can run Microsoft Windows XP, Windows ® Windows 2000 Professional. ≥USB Driver ® For Windows ≥IBM PC/AT or compatible ≥Intel Pentium ll Processor: 300 MHz or higher CPU recommended ®...
Using the G726 Decoder G726 Decoder allows you to listen to MPEG4 sound with Windows Media Player. Install it from enclosed CD-ROM. In order for the G726 Decoder to be installed, the hard disk must have at least 16 MB of free space. Before proceeding with installation, check out the amount of free space on the hard disk.
Double click the icon in task tray. ≥Hardware disconnect dialog appears. Select [Panasonic DVC USB Driver] and click [Stop]. Verify [Panasonic DVC USB Driver] is selected and click [OK]. Click [OK]. ≥You can safely disconnect the cable. ≥Some OS, such as Windows® 98SE may not show the icon indicating that you may safely disconnect in task tray.
Select [Start] >> [Settings] >> [Control Panel], double click [System] select device driver tab, verify [Panasonic DVC USB Driver] and [Panasonic DVC Port Driver] are displayed in [Universal Serial Bus controllers] of [Device Manager]. ≥If [DVC] is displayed in [Other devices] of [Device Manager] tab, we recommend updating the driver by following the steps below: ª...
Page 53
(Palmcorder must be connected to computer) Select [Start] >> [Settings] >> [Control Panel], double click [System] Hardware tab, Device Manager. Verify [Panasonic DVC USB Driver] and [USB Root Hub] in [Universal Serial Bus controllers] of [Device Manager] of [Hardware]. ≥If [USB Mass Storage Device] is shown in [Universal Serial Bus controllers] of [Device Manager] tab, we recommend updating the driver as described below to Panasonic DVC USB Driver.
Page 54
ª Verifying driver (Palmcorder must be connected to computer) Select [Start] >> [Settings] >> [Control Panel], double click [System], Device Manager tab and verify [Panasonic DVC USB Driver] is displayed in [Universal Serial Bus controllers] of [Device Manager]. ≥If [USB Mass Storage Device] is displayed in [Universal Serial Bus controllers] of [Device Manager] tab, we recommend updating the driver by following the steps below.
ª Uninstalling ArcSoft Software 1 1 1 1 Select [ArcSoft Software]. ª Uninstalling USB driver Select [USB Driver for Panasonic DVC]. Uninstalling steps may vary depending on the OS. Please refer to the user manual of your OS. (uninstall) Windows XP)
Notes ≥Do not disconnect USB Connection Cable while the operation light of Palmcorder is on. It may freeze the software or destroy the data in transfer. Please refer to the user manual of Palmcorder. ≥We recommend using AC adapter as the power source for the Palmcorder when using USB Connection Kit.
0:00.00 R0:45 INDEX D.ZOOM P-IN-P NEGA Others Indications Various functions and Palmcorder conditions are displayed on the screen. 1) Remaining Battery Power [r] ≥When the battery power becomes low, the indication changes. When the battery is discharged completely, ) Indication flashes. ≥When you are using the AC Adaptor, the [s] Indication may appear, however, this has no meaning in this case.
Page 58
12) Recording Mode ≥AUTO: This appears when Mode Selector Switch is set to [AUTO]. (l 20) ≥MNL: This appears when Mode Selector Switch is set to [MANUAL]. (l 23, 24, 25) Electronic Image Stabilizer [EIS] (l 22) Audio Dubbing Input Display [MIC/AV IN] (l 33) Audio Recording Mode [12bit/16bit] (l 33) 13) Manual Focus [MF] (l 24) Backlight Mode [ª] (l 23)
ª Changing the Counter Display Mode By changing [C.DISPLAY] on the [DISPLAY SETUP] Sub-Menu, you can change the Counter Display Mode to Tape Counter Indication (0:00.00), Memory Counter Indication (M0:00.00), and Time Code Indication (0h00m00s00f). ≥You can also press the [COUNTER] Button of the Remote Controller repeatedly to change the Counter Indication.
Notes & Precautions ª Power-Related Items (l 12) ≥When the Palmcorder is used for a long time, the Camera body becomes warm, but this is not a malfunction. ≥If the [CHARGE] Lamp does not light up, although the Battery is attached, detach the Battery, and reattach it. ª...
Page 61
ª Cinema Function (l 23) ≥Cinema function does not operate during Card Mode. ≥Using the Cinema function does not widen the recording angle. ≥If you play back tape recorded in Cinema Mode on a wide-screen (16:9) format TV, playback size is automatically adjusted to fit the TV screen format.
Page 62
ª Index Search Functions (l 30) ≥Index Search may not be possible at the beginning of tape. ≥Because PhotoShot Index Signals are not recorded on still pictures recorded in Continuous PhotoShot Mode, the PhotoShot Index Function cannot be used for these still pictures.
Page 63
ª Card PhotoShot (l 36) ≥The sound cannot be recorded. ≥The Shutter Effect cannot be used. ≥The Progressive Function is set to [ON]. ≥The shutter speed ranges from 1/30-1/500 ≥Mega-pixel images cannot be recorded on a cassette as a Mega-pixel picture. ≥A Card formatted with other equipment (like a Personal Computer) might be unusable or it might take more time for recording.
ª Title Functions (l 42) ≥When the [STILL/MPEG4/VOICE] Selector is set to [MPEG4] or [VOICE], Title Creation Function is not possible. ≥If the [PICTURE SIZE] is set to [1200k900], title cannot be created. ≥Even if the contrast of the Title is adjusted, the portions where there is little difference between light and dark and where the boundary between light and dark is unclear may not appear.
Cautions for Use ª After Use Take out the Cassette. (l 13) Set the [OFF/ON/MODE] Switch to [OFF]. Detach the Power Source and retract the Viewfinder. (l 12) To protect the Lens, attach the supplied Lens Cap. (l 13) ª Tips for using your Palmcorder When you use your Palmcorder on a rainy or snowy day or on a beach, make sure that no water enters the Palmcorder.
≥If the dirty heads cannot be cleaned with the head cleaner, the Palmcorder needs to be cleaned at a service center. Please consult a distributor or Panasonic Service center. ≥Video head cleaners can be purchased from service centers.
ª Cautions for Storage Before storing the Palmcorder, take the Cassette out and detach the Battery. Store all the components in a dry place with a relatively stable temperature. ≥Recommended Temperature: 59oF Recommended Humidity: 40% to 60% Palmcorder ≥Wrap it with a soft cloth to prevent dust from getting into the Palmcorder.
Explanation of Terms ª Digital Video System In a digital video system, images and sounds are converted into digital signals and recorded on a tape. This complete digital recording is capable of recording and playback with minimal image and sound deterioration. In addition, it automatically records data, such as Time Code and date/time, as digital signals.
Specifications Digital Palmcorder Information for your safety Power Source: DC 7.9/7.2 V Power Consumption: Recording Recording Format: Mini DV (Consumer-use Digital Video SD Format) Tape Used: 6.35 mm digital video tape Recording/Playback Time: SP: 80 min.; LP: 120 min. (with DVM80) Video Recording System: Digital Component...
[6 AM-5 PM M-F, 6 AM-10:30 AM SAT, PACIFIC TIME] MAIL THIS ORDER TO: PANASONIC SERVICES COMPANY ACCESSORY ORDER OFFICE 20421 84th Avenue South Kent, WA. 98032 In CANADA, please contact your local Panasonic dealer for more information on Accessories. (For USA Customers) Price Each Quantity Your State &...
Before Requesting Service (Problems and Solutions) If you are experiencing one of the following problems with your Digital Palmcorder, it may be something you can correct yourself. Check the list below for Problems and Solutions. Problems The Palmcorder power cannot be turned on. The Palmcorder power turned off automatically.
Page 73
Cassette or personal computer. (l 40, 49) There is a possibility of damage to either the Palmcorder or the Card. Please contact Panasonic Call Center.
(Failure to due so will delay your repair.) • To further speed your repair, please provide an explanation of what wrong with the unit and any symptom it is exhibiting. Panasonic Services Company 1705 N. Randall Road Elgin, IL. 60123-7847 Attn: Camcorder Repair...
If your product does not work properly because of a defect in materials or workmanship, Panasonic Consumer Electronics Company or Panasonic Sales Company (collectively referred to as “the warrantor”) will, for the length of the period indicated on the chart below, which starts with the date of original purchase (“warranty period”), at its option either (a) repair your product with new or refurbished parts, or (b)
Customer’s in Puerto Rico, please ship or carry in to location below (“Service in Puerto Rico”). Matsushita Electric of Puerto Rico, Inc. Panasonic Sales Company/ Factory Servicenter: Ave. 65 de Infantería. Km. 9.5, San Gabriel Industrial Park, Carolina, Puerto Rico 00985 Phone (787) 750-4300 Fax (787) 768-2910 Service in Canada: As per Sevicenter listed in Canadian warranty information on page 77.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3 PANASONIC PRODUCT – LIMITED WARRANTY Panasonic Canada Inc. warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect for a period as stated below from the date of original purchase.
Index ª A AC Adaptor... 12 ArcSoft Software ... 48 Audio Dubbing... 33 Auto Focus ... 68 Auto White Balance Adjustment... 68 ª B Backlight Compensation... 23 Battery Adaptor Unit ... 34 Before Requesting Service... 72 Black & White Mode ... 26, 31 Blank Search ...
POWER CHARGE QUICK 100% MODE OFF ON CAMERA CARD P. B. POWER OPEN/EJECT RECORD STILL MPEG4 VOICE RESET CARD MODE OFF ON MODE CAMERA CARD P. B. POWER ACCESS BACKLIGHT CAMERA STILL OFF ON MODE CAMERA CARD P. B. POWER 1 , 2 Spanish Quick Use Guide/Guía española para el uso rápido...
Page 80
ACCESS CARD EJECT STILL MPEG4 VOICE RESET CARD MODE TAPE CARD W.B./SHUTTER/IRIS/ 3, 4 MF/VOL/JOG PUSH 3, 4 PHOTO SHOT STILL MPEG4 VOICE RESET CARD MODE MODE OFF ON CAMERA CARD P. B. POWER ACCESS 100-0012 ª Para introducir una tarjeta de memoria Antes de introducir una tarjeta de memoria, asegúrese de que esté...
Page 84
Executive Office: One Panasonic Way, Secaucus, NJ 07094 (201) 348-7000 Panasonic Company East: 6749 Baymeadow Drive, Glen Burnie, MD 21060 Panasonic Company Central: 1707 North Randall Road, Elgin, IL 60123 Panasonic Company West: 6550 Katella Avenue, Cypress, CA 90630 Division of Matsushita Electric Corporation of America Panasonic Sales Company (“PSC”)
Page 85
Caméscope numérique Manuel d’utilisation PV-VM202 Modèle Mini Il est recommandé de lire attentivement ce manuel avant d’utiliser I’appareil. Pour de I’aide, composez le 1-800-561-5505 ou visitez notre site Internet à www.panasonic.ca LSQT0511A...
Page 86
Renseignements Merci d’avoir choisi Panasonic! Vous avez acheté l’un des appareils les plus perfectionnés et les plus fiables actuellement sur le marché. Utilisé selon les directives, il vous apportera ainsi qu’à votre famille des années de plaisir. Veuillez prendre le temps de remplir la case ci- dessous.
Directives importantes 1) Lire les instructions. 2) Conserver les instructions. 3) Tenir compte des avertissements. 4) Suivre les instructions. 5) Ne pas utiliser cet appareil vidéo en présence d’eau. 6) Nettoyer l’appareil avec un chiffon sec. 7) Prendre soin à ne pas bloquer les ouvertures d’aération de l’appareil. Installer l’appareil conformément aux instructions du fabricant.
Page 88
Précautions Utilisation et emplacement ≥Pour éviter les chocs électriques ... Le caméscope et son bloc d’alimentation ne doivent pas être exposés à la pluie ou à une humidité excessive. Ne pas brancher le bloc d’alimentation ou faire fonctionner le caméscope s’ils sont mouillés.
Page 89
Table des matières Préface Accessoires standard ... 6 Guide sommaire ... 7 Visionnement de l’enregistrement ... 7 Nomenclature (Commandes et accessoires) ... 8 Télécommande... 10 Source d’alimentation... 12 Temps de recharge et autonomie d’enregistrement... 12 Mise en place du capuchon de l’objectif... 13 Ajustement de la courroie de la poignée ...
Il est à noter que le capuchon d’objectif ne peut alors être mis en place. 7) Fil A/V (l 33, 45) 8) Carte mémoire SD (l 56) 9) CD-ROM: Pilote USB pour caméscope numérique Panasonic (l 49) Décodeur G726 (l 47, 50) Logiciel ArcSoft (l 47, 48) Microsoft et Windows sont des marques déposées de Microsoft aux...
POWER CHARGE QUICK 100% OFF ON MODE CAMERA CARD P. B. POWER OPEN/EJECT OFF ON MODE CAMERA CARD P. B. POWER 6, 7 MODE OFF ON CAMERA CARD P. B. POWER BACKLIGHT CAMERA STILL Guide sommaire Recharge de la batterie. (l 12) ≥Insérer le câble c.a.
BACKLIGHT CAMERA STILL PHOTO SHOT A/V IN/OUT PHONES TAPE CARD Nomenclature (Commandes et accessoires) Caméscope (caméra DV) 1) Touche du menu [MENU] (l 15) 2) Touche de titre [TITLE] (l 42) 3) Touche d’écran multiple [MULTI] (l 27, 32, 40, 42) Touche d’image sur image [P-IN-P] (l 27) 4) Touche d’éclairage en contre-jour [BACKLIGHT] (l 23) Touche de lecture (Play) [1] (l 28, 39, 41)
Page 93
STILL MPEG4 VOICE AUTO MANUAL RESET CARD MODE FOCUS OFF ON MODE CAMERA CARD P. B. POWER ACCESS CAMERA RELEASE CARD EJECT TO PC S-VIDEO IN/OUT D.STILL PICTURE 26) Touche de réinitialisation [RESET] (l 71) 27) Voyants du mode de fonctionnement [CAMERA/VCR/CARD P.B.] (l 14, 20, 28, 39) 28) Voyant d’accès de la carte [ACCESS] (l 35) 29) Sélecteur de mode d’enregistrement sur carte...
START/ DATE/ PHOTO STOP TIME SHOT COUNTER RESET ZOOM TITLE MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV INDEX STOP INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU OFF/ON ITEM P.B.DIGITAL START/ DATE/ PHOTO STOP TIME SHOT COUNTER RESET...
Page 95
Tenir la pile de type bouton hors de la portée des enfants. Ne jamais mettre une pile de type bouton dans la bouche. Si elle était avalée, consulter immédiatement un médecin. N’utiliser qu’une pile de rechange Panasonic (pièce numéro VSBW0004 (CR2025)). L’utilisation d’une autre pile peut entraîner un risque d’incendie ou d’explosion.
POWER CHARGE QUICK 100% OFF ON CAMERA CARD P. B. CGA-D07 1 h 10 min (55 min) CGR-D08A/1B 1 h 15 min (1 h 5 min) 1 h 10 min CGR-D16A/1B 2 h 30 min (2 h 5 min) 4 h 30 min CGR-D53A/1K 8 h 15 min (6 h 45 min)
OPEN/EJECT R E C SAVE Mise en place du capuchon de l’objectif Pour assurer la protection de la surface de l’objectif, mettre le capuchon de l’objectif en place. Passer la boucle du cordon du capuchon dans l’orifice de fixation sur le caméscope. Passer l’autre extrémité...
OFF ON CAMERA CARD P. B. 1, 2, 3 12:30:45PM 12:30:45PM 12:30:45PM 12:30:45PM OCT 10 2002 OCT 10 2002 OCT 10 2002 OCT 10 2002 MODE OFF ON 180x Mise en marche/arrêt du caméscope et sélection des modes Mettre sous tension d’abord et sélectionner les modes ensuite. ª...
2, 3, 4, 5 CAMERA W.B./SHUTTER/IRIS/ MF/VOL/JOG CARD P. B. PUSH START/ DATE/ PHOTO STOP TIME SHOT COUNTER RESET TITLE ZOOM MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV INDEX STOP INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU...
Ω º Liste des menus Les illustrations des menus sont données à titre d’explication uniquement et sont différentes des menus actuels. Menu principal du mode caméra [CAMERA FUNCTIONS] Sous-menu [CAMERA SETUP] 1) Mode d’exposition automatique [PROG.AE] (l 23) 2) Mode PhotoShot progressif [PROGRESSIVE] (l 21) 3) Stabilisateur d’image électronique [EIS] (l 22) 4) Zoom numérique [D.ZOOM] (l 22) 5) Enregistrement au format cinématographique [CINEMA] (l 23)
Page 101
Menu principal du mode magnétoscope [VCR FUNCTIONS] Sous-menu [PLAYBACK FUNCTIONS] 1) Recherche des blancs [BLANK SEARCH] (l 29) 2) Enregistrement sur carte [RECORD TO CARD] (l 37) 3) Mode recherche index [INDEX] (l 30) 4) Sélecteur audio [AUDIO] (l 33) 5) Mode sortie audio [AUDIO OUT] (l 62) 6) Retour au menu principal [RETURN] Sous-menu [DIGITAL EFFECT]...
Page 102
FILE SEARCH DELETE FILE FILE LOCK DPOF SETTING EXIT Menu principal du mode lecture de carte [CARD FUNCTIONS] Sous-menu [DELETE CARD FILE] 1) Sélection et effacement d’un fichier [DELETE FILE BY SELECTION] (l 43) 2) Effacement de toutes les images [DELETE ALL FILES] (l 43) 3) Sélection et effacement d’un titre [DELETE TITLE BY SELECTION] (l 43) Sous-menu [CARD EDITING]...
1, 2 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH 1, 3 Réglage de la date et de l’heure Appuyer sur la touche [MENU] et tourner le cadran [PUSH] pour sélectionner [OTHER FUNCTIONS] >> [CLOCK-SET] >> [YES]. Tourner et appuyer sur le cadran [PUSH] pour sélectionner [YEAR]/[MONTH]/[DAY]/[HOUR]/[MINUTE] et insérer les valeurs désirées.
STILL MPEG4 VOICE AUTO MANUAL RESET CARD MODE OFF ON MODE CAMERA CARD P. B. POWER ACCESS PAUSE PAUSE RECORD BACKLIGHT CAMERA STILL ° Enregistrement Régler le commutateur [OFF/ON/MODE] sur [ON]. ≥Le voyant [CAMERA] s’allume. Glisser le sélecteur [TAPE/CARD] dans la direction [TAPE]. Appuyer sur la touche d’enregistrement.
BACKLIGHT CAMERA STILL PHOTO SHOT TAPE CARD PHOTO PHOTO PHOTO PHOTO 1t W 5t W 10t W Enregistrement PhotoShot sur la cassette DV Ce caméscope peut prendre environ 7 secondes chacune d’images fixes sonores. é gler le sélecteur [TAPE/CARD] sur [TAPE]. Appuyer sur la touche [PHOTO SHOT] en mode pause d’enregistrement.
W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH 20t W D.ZOOM W.B./SHUTTER/IRIS/ Fonction zoom numérique Cette fonction est utile lorsque vous souhaitez réaliser des gros-plans de sujets situés au-delà du champ de zoom normal avec grossissement allant de 1t à 10t. À l’aide de la fonction zoom numérique, vous pouvez choisir un grossissement de 25t ou même de 200t.
CINEMA W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH ª BACKLIGHT W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH AUTO MANUAL FOCUS Fonction cinéma Cette fonction permet d’enregistrer des images au format grand écran. Régler [CAMERA FUNCTIONS] >> [CAMERA SETUP] >> [CINEMA] >> [ON]. ≥Une bande noire apparaît dans le haut et le bas de l’écran. Désactivation du mode cinéma Régler [CAMERA FUNCTIONS] >>...
2, 3 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH AUTO MANUAL FOCUS 1/800 2, 3 W.B./SHUTTER/IRIS MF/VOL/JOG PUSH AUTO MANUAL FOCUS 1/60 F2.4 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH AUTO MANUAL FOCUS 1, 2 Réglage manuel de la vitesse d’obturation Utile pour enregistrer les scènes à action rapide. Régler le commutateur du sélecteur de mode sur [MANUAL].
2, 3 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH AUTO MANUAL FOCUS 1AWB 2, 3 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH AUTO MANUAL FOCUS 10 000K 9 000K 8 000K 7 000K 6 000K 5 000K 4 000K 3 000K 2 000K 1 000K Enregistrement avec des couleurs naturelles (Équilibre du blanc) En fonction de la scène ou des conditions d’éclairage, le réglage de I’équilibre du blanc automatique peut ne pas reproduire les couleurs...
1) MULTI 2) P-IN-P 3) WIPE 4) MIX 5) STROBE 6) MAGICPIX 7) TRAIL 8) MOSAIC 9) MIRROR 10) NEGA 11) SEPIA 12) MONO 13) SOLARI W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH 2, 3, 4 WIPE WIPE WIPE Effets et fonctions numériques Ce caméscope est muni de fonctions et d’effets numériques qui permettent la création d’effets spéciaux à...
Page 111
ª Mode d’écran multiple Mode stroboscopique d’écran multiple Il est possible de capturer et enregistrer une séquence de 9 petites images W.B./SHUTTER/IRIS/ MF/VOL/JOG fixes. PUSH Mode manuel d’écran multiple 1, 2 Il est possible de capturer et enregistrer manuellement une séquence de 9 petites images fixes.
BACKLIGHT CAMERA STILL W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH OFF ON MODE CAMERA CARD P. B. POWER W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH BACKLIGHT CAMERA STILL Mode magnétoscope Lecture La scène enregistrée peut être visionnée immédiatement après l’enregistrement. Glisser le commutateur [OFF/ON/MODE] et régler le caméscope en mode magnétoscope. ≥Le voyant [VCR] s’allume.
START/ DATE/ PHOTO STOP TIME SHOT COUNTER RESET TITLE ZOOM MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV INDEX STOP INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU OFF/ON ITEM P.B.DIGITAL W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH BACKLIGHT CAMERA STILL START/ DATE/...
W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH START/ PHOTO DATE/ STOP TIME SHOT COUNTER RESET TITLE ZOOM MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV INDEX STOP INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU OFF/ON ITEM P.B.DIGITAL INDEX Fonctions de recherche de l’index Afin de faciliter la recherche d’une scène, ce caméscope enregistre automatiquement les signaux de l’index lors de l’enregistrement, comme expliqué...
START/ DATE/ PHOTO STOP SHOT TIME COUNTER RESET TITLE ZOOM MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV STOP INDEX INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU OFF/ON ITEM P.B.DIGITAL ZOOM 2t START/ DATE/ PHOTO STOP TIME SHOT...
Page 116
1, 2 BACKLIGHT CAMERA W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH START/ DATE/ PHOTO STOP TIME SHOT COUNTER RESET TITLE ZOOM MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV INDEX STOP INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU OFF/ON ITEM P.B.DIGITAL ª...
CAMERA RELEASE CAMERA RELEASE OPEN Caractéristiques particulières Utilisation comme caméra vidéo (DV) ou comme appareil photo (SD) Le caméscope peut être utilisé de l’une de deux façons (configurations) selon la situation. La première configuration (DV) photo et de l’unité vidéo l’utilisation de l’unité...
ACCESS CARD EJECT STILL MPEG4 VOICE CARD MODE TAPE CARD W.B./SHUTTER/IRIS/ 3, 4 MF/VOL/JOG PUSH BACKLIGHT CAMERA STILL PHOTO SHOT Utilisation d’une carte mémoire Il est possible de recourir à une carte mémoire pour l’enregistrement et la lecture de fichiers. ≥N’utiliser qu’une carte mémoire SD ou une carte MultiMediaCard authentique, compatible avec l’appareil.
Page 120
STILL MPEG4 VOICE RESET MODE OFF ON CAMERA CARD P. B. POWER TAPE ACCESS CARD W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH CAMERA PHOTO SHOT ª Carte PhotoShot (suite) Enregistrement à partir d’une cassette (mode magnétoscope) Glisser le commutateur [TAPE/CARD] sur [CARD]. Glisser le commutateur [STILL/MPEG4/VOICE] sur [STILL]. Régler [VCR FUNCTIONS] >>...
W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH BACKLIGHT CAMERA STILL W.B./SHUTTER/IRIS/ MF/VOL/JOG PHOTO SHOT PUSH æ £ ß F 7 640 ª Copie automatique des images fixes qui ont déjà été enregistrées sur cassette Le caméscope copie les images automatiquement en se reportant aux signaux de l’index Photo.
Page 122
2, , 2 STILL MPEG4 VOICE 3, , 3 TAPE 1, , 1 CARD R: 0h20m STILL MPEG4 VOICE CARD MODE TAPE CARD R: 0h20m ª Enregistrement d’images animées Il est possible d’enregistrer des images pour ensuite, par exemple, les insérer à...
3, , 3 BACKLIGHT CAMERA STILL 2, , 2 STILL MPEG4 VOICE RESET CARD MODE OFF ON MODE CAMERA CARD P. B. POWER ACCESS 1, , 1 CARD CONTENTS PICTURE MPEG4 VOICE PICTURE 100-0012 MPEG4 MOL012.ASF VOICE Lecture des fichiers enregistrés sur carte mémoire Permet la lecture des fichiers enregistrés sur carte mémoire.
4, , W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH BACKLIGHT CAMERA STILL STILL MPEG4 VOICE RESET MODE OFF ON CAMERA CARD P. B. POWER ACCESS PICTURE 1200 1200 No.25 100-0012 No.3 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH TAPE CARD STILL MPEG4 VOICE RESET OFF ON MODE CAMERA CARD P.
1, 2, 3, 4, 5, 7 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH 1, 6, 7 BACKLIGHT 1200 1200 M.SLIDE SLIDE SLIDE Diaporama Les photos sauvegardées sur la carte mémoire peuvent être présentées en séquence à la manière d’un diaporama. Vous pouvez créer et éditer votre diaporama.
2, 4, 5, 6, 7, 8 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH W.B./SHUTTER/IRIS/ 3, 4 MF/VOL/JOG PUSH TAPE CARD TITLE USR00002.TTL Création d’un titre Il est possible de créer un titre et l’enregistrer sur une carte mémoire. Mode caméra: Glisser le sélecteur [STILL/MPEG4/VOICE] sur [STILL] puis orienter le caméscope vers l’image que vous souhaitez utiliser pour la création du titre.
W.B./SHUTTER/IRIS/ 1, 2, 3 MF/VOL/JOG PUSH 1, 2, 4 W.B./SHUTTER/IRIS/ MF/VOL/JOG PUSH PHOTO SHOT Protection des fichiers contre les effacements accidentels sur une carte mémoire (Verrouillage de fichier) Les fichiers qui vous sont précieux, enregistrés sur une carte mémoire, peuvent être verrouillés (pour les protéger contre tout effacement accidentel). (Même dans le cas où...
W.B./SHUTTER/IRIS/ 1, 2 MF/VOL/JOG PUSH NOW FORMATTING W.B./SHUTTER/IRIS 2, 3, 4, 5 MF/VOL/JOG PUSH STILL MPEG4 VOICE DPOF SETTING (PRINT QUANTITY) PUSH MENU TO EXIT Formatage d’une carte mémoire Si une carte mémoire devient illisible pour le caméscope, le formatage peut la rendre réutilisable.
START/ DATE/ PHOTO STOP TIME SHOT COUNTER RESET TITLE ZOOM MULTI/ A.DUB P-IN-P ¥ /REW PLAY STILL ADV PAUSE STILL ADV INDEX STOP INDEX ∫ SELECT VAR. P.B. SEARCH ZOOM STORE MENU OFF/ON ITEM P.B.DIGITAL Utilisation du caméscope avec un appareil vidéo numérique En branchant ce caméscope avec un autre appareil vidéo numérique (tel qu’un autre caméscope du même format/modèle) qui a une prise d’entrée/...
3 3 3 3 4, 5 4, 5 4, 5 4, 5 Utilisation du logiciel avec un ordinateur Une image mémorisée dans une cassette DV peut être transférée sur votre ª Configuration minimale requise par le système pour ArcSoft ≥Lecteur CD-ROM (pour l’installation) (pour Logiciel ArcSoft) Pour Windows ≥IBM PC/AT ou compatible...
Logiciel ArcSoft Le logigiel ArcSoft comprend 4 types de logiciel. Avant de commencer... Ouvrir [Start] >> [Programs] >> [ArcSoft] >> [Panorama Maker 3.0] ou [PhotoImpression 3.0] ou [PhotoBase 3.0] ou [PhotoPrinter 2000 Pro]. Panorama Maker 3.0 (Windows, Mac) ≥Programme de montage photographique facile à utiliser pour constituer une vue panoramique à...
VFA0366 LSFT0489 TO PC Utilisation de l’ensemble de connexion USB ª Configuration du système Le pilote USB peut être installé sur un ordinateur PC/AT compatible fonctionnant sous Microsoft Windows Windows 98 Deuxième Édition, Windows ≥Pilote USB Pour Windows ≥Ordinateur IBM PC/AT ou compatible ≥Processeur Intel Pentium II : 300 MHz ou supérieur recommandé...
Utilisation du décodeur G726 Le décodeur G726 permet l’écoute de données sonores MPEG4 avec Windows Media Player. Il est possible de l’installer à partir du CD-ROM. L’installation du décodeur nécessite un minimum de 16 Mo d’espace libre sur le disque dur. Avant de procéder à l’installation, vérifier l’espace libre disponible sur le disque.
Suivre les instructions ci-après pour déconnecter le câble. Double-cliquer sur l’icône ≥La boîte de dialogue de déconnexion s’affiche. Sélectionner [Panasonic DVC USB Driver], puis cliquer sur [Stop]. S’assurer que [Panasonic DVC USB Driver] est sélectionné, puis cliquer sur [OK].
[System], sélectionner l’onglet [Device Manager], puis vérifier que [Panasonic DVC USB Driver] et [Panasonic DVC Port Driver] se trouvent dans [Universal Serial Bus controllers] du [Device Manager]. ≥Dans le cas où [DVC] est affiché dans [Other devices] sous l’onglet [Device Manager], il est recommandé...
Page 137
Sélectionner [Start] >> [Settings] >> [Control Panel], double-cliquer sur [System], sélectionner [Device Manager] sous l’onglet [Hardware], puis vérifier que [Panasonic DVC USB Driver] et [USB Root Hub] se trouvent dans [Universal Serial Bus controllers] du [Device Manager] sous [Hardware]. ≥Dans le cas où [USB Mass Storage Device] est affiché dans [Universal Serial Bus controllers] sous l’onglet [Device Manager], il est...
Page 138
(Le caméscope doit être connecté à l’ordinateur.) Sélectionner [Start] >> [Settings] >> [Control Panel], double-cliquer sur [System], sélectionner l’onglet [Device Manager], puis vérifier que [Panasonic DVC USB Driver] se trouve dans [Universal Serial Bus controllers] du [Device Manager]. ≥Dans le cas où [USB Mass Storage Device] est affiché sous [Universal Serial Bus controllers] sous l’onglet [Device Manager], il est...
ª Désinstallation du logiciel Arcsoft 1 1 1 1 Sélectionner [Arcsoft Software]. ª Désinstallation du pilote USB Sélectionner [USB Driver for Panasonic DVC]. La procédure de désinstallation varie selon le système d’exploitation. Se reporter au manuel d’utilisation du système. Sous Windows XP)
Remarques ≥Ne pas déconnecter le câble USB pendant que le voyant de marche du caméscope est allumé. Cela pourrait “figer” le logiciel ou détruire les données en cours de transfert. Se reporter au manuel d’utilisation du caméscope. ≥Il est recommandé de faire fonctionner le caméscope sur le secteur (adaptateur fourni) lorsqu’un câble USB est connecté.
0:00.00 R0:45 INDEX D.ZOOM P-IN-P NEGA Autres Indications Les différentes fonctions et conditions du caméscope devraient s’afficher sur l’écran. 1) Autonomie de la batterie [r] ≥Lorsque la batterie est faible, l’indication change. Lorsque la batterie est complètement déchargée, l’indication ) clignote. ≥Lorsque vous utilisez l'adaptateur secteur, il se peut que l'indication [s] apparaisse, mais cela ne signifie rien dans ce cas.
Page 142
12) Mode d'enregistrement ≥AUTO: Ceci apparaît lorsque le commutateur du sélecteur de mode est placé sur [AUTO]. (l 20) ≥MNL: Ceci apparaît lorsque le commutateur du sélecteur de mode est placé sur [MANUAL]. (l 23, 24, 25) Stabilisateur d’image électronumérique [EIS] (l 22) Affichage entrée du doublage audio [MIC/AV IN] (l 33) Mode d’enregistrement audio [12bit/16bit] (l 33)
ª Modification du mode d’affichage du compteur En changeant [C.DISPLAY] à partir du sous-menu [DISPLAY SETUP], il est possible de changer le mode d’affichage du compteur par indication compteur de cassette (0:00.00), indication compteur de mémoire (M0:00.00), ou indication code temps (0h00m00s00f). ≥Vous pouvez également appuyer de manière répétée sur la touche [COUNTER] de la télécommande pour changer l’indication compteur.
Notes et précautions ª Indications se rapportant aux sources d’alimentation (l 12) ≥Lorsque le caméscope est utilisé pendant une longue durée, le boîtier du caméscope se réchauffe mais ceci n’est pas indice de mauvais fonctionnement. ≥Si le voyant [CHARGE] ne s’allume pas bien que la batterie soit fixée, la retirer et la remonter.
Page 145
ª Mode fondu à l’entrée/en sortie ≥Le mode fondu à l’entrée/en sortie ne peut pas être utilisé lors d’un enregistrement d’images fixes en modes PhotoShot, image fixe numérique et multi-image ni pour la petite image fixe du mode image sur image. ª...
Page 146
Mode écran multiple (mode caméra) (l 27) ≥Lorsque [PROGRESSIVE] du sous-menu [CAMERA SETUP] est sur [ON], le mode écran multiple ne peut pas être utilisé. ≥Si on appuie sur la touche [MULTI] lorsque l’auto-enregistrement est utilisé en mode miroir (l 20) l’image fixe est affichée à...
Page 147
ª À propos de l’adaptateur pour batterie (l 34) ≥Pour ne pas endommager les circuits électriques internes et protéger les données de la carte mémoire, ne pas mettre en place ni retirer l’adaptateur pour batterie lorsque le caméscope est en marche (le commutateur doit être sur la position [ON]).
Page 148
ª Lecture de la carte (l 39) ≥Si une carte vierge (sans enregistrement) est insérée, l’écran devient blanc et l’indication [NO PICTURE], [NO MPEG4 DATA] ou [NO VOICE DATA] apparaît selon le mode sélectionné. ≥Dans le cas où le fichier dont vous tentez de faire la lecture a été...
Précautions d’emploi ª Après utilisation Sortir la cassette. (l 13) Régler le commutateur [OFF/ON/MODE] sur [OFF]. (l 14) Retirer la source d’alimentation et rétracter le viseur. (l 12) Pour protéger l’objectif, fixer le capuchon d’objectif fourni. (l 13) ª Conseils d’utilisation de votre caméscope Lorsque vous utilisez votre caméscope sous la pluie ou sous la neige ou sur la plage, veiller à...
Page 150
≥Si les têtes sales ne peuvent pas être nettoyées au moyen d’une cassette auto-nettoyante, le caméscope doit être nettoyé par le centre de service. Consulter un détaillant ou un centre de service Panasonic. ≥Les cassettes auto-nettoyantes peuvent être achetées auprès des centres de service.
Page 151
ª Précautions de rangement Avant de ranger le caméscope, sortir la cassette et retirer la batterie. Placer tous les composants dans un endroit sec où température est relativement stable. ≥Température recommandée: de 15oC à 25oC (59oF à 77oF), Taux d’humidité recommandé: de 40% à 60% Caméscope ≥L’envelopper dans un linge doux à...
Explication des termes ª Système vidéo numérique Dans un système vidéo numérique, les images et les sons sont transformés en signaux numériques et enregistrés sur une bande. Cet enregistrement numérique complet est en mesure d’enregistrer et lire les images et les sons avec une distorsion minimale.
Spécifications Caméscope numérique Informations pour votre sécurité Source d’alimentation: 7,9/7,2 V c.c. Consommation d’énergie: Enregistrement Format d’enregistrement: Mini DV (Usage Consommateur- Format SD vidéonumérique) Bande utilisée: Bande vidéo numérique 6,35 mm Enregistrement/temps de lecture: Durée standard (SP) : 80 min; longue durée (LP): 120 min (avec DVM80) Vidéo Système d’enregistrement:...
Accessoires du caméscope N de pièce Illustration *CGR-D08A/1B *CGR-D16A/1B *CGP-D28A/1B *CGR-D53A/1K PV-DDC9-K PV-DRC9-K RP-SD064BPPA RP-SD032BPPA RP-SD016BPPA BN-SDCAPU/1B BN-SDABPU/1B PV-DRS2 *Concernant le temps de recharge de la batterie et le temps d'enregistrement disponible, se référer à la page 12. *Nota: Les accessoires et(ou) les numéros de modèle peuvent varier selon les pays. Consulter le détaillant de la région.
Guide de dépannage (Problèmes et Solutions) En cas de difficulté avec votre caméscope numérique, il peut s’agir d’un problème que vous pouvez résoudre vous-même. Voir la liste des problèmes et des solutions ci-dessous. Problèmes Le caméscope ne s’allume pas. L’alimentation du caméscope est automatiquement coupée.
Page 156
En cas de difficulté avec votre caméscope numérique, il peut s’agir d’un problème que vous pouvez résoudre vous-même. Voir la liste des problèmes et des solutions ci-dessous. Problèmes Les images ne peuvent pas être reproduites même lorsqu’on appuie sur la touche [1].
Garantie Panasonic Canada Inc. garantit cet appareil contre tout vice de fabrication et accepte, le cas échéant, de remédier à toute défectuosité pendant la période indiquée ci-dessous et commençant à partir de la date d’achat original. Caméscopes - Un (1) an, pièces et main-d’oeuvre LIMITATIONS ET EXCLUSIONS Cette garantie n’est valide que pour les appareils achetés au Canada et ne couvre pas les dommages résultant d’une installation...
Index ª A Accessoires du caméscope... 70 Adaptateur pour batterie... 34 Adaptateur secteur ... 12 Affichage date/heure ... 59 ArcSoft... 48 Atténuation bruit du vent ... 16 ª C Carte mémoire... 35 Carte mémoire SD... 56 Carte PhotoShot... 35, 36 Code temps ...
Page 160
Panasonic Canada Inc. 5770 Ambler Drive, Mississauga, Ontario L4W 2T3 (905) 624-5010 www.panasonic.ca Montréal: 3075 Louis A. Amos, Lachine, Québec H8T 1C4 (514) 633-8684 Toronto: 5770 Ambler Drive, Mississauga, Ontario L4W 2T3 (905) 238-2181 Calgary: 6835 8th Street N.E., Calgary, Alberta T2E7H7 (403) 295-3922 Vancouver: 12111 Riverside Way, Richmond, BC V6W 1K8 (604) 278-4211 Imprimé...
