Overview of the modes
The TRITON STUDIO has a large number of functions
that let you play and edit programs and combinations,
record and play sequence data, record and play back sam-
ples, and manage data on disk. The largest unit used to
organize these functions is called a mode.
The TRITON STUDIO has seven modes.
Program mode
• Select and play programs
You can choose programs from rewritable banks INT-
A–INT-F and EXB-A–EXB-G which contain a total of
1,664 programs, and non-rewritable bank INT-G (256
programs compatible with the GM2 standard, and nine
drum programs).
(The 128 programs of bank INT-F can be selected only
if the EXB-MOSS option has been installed.)
• Sample or resample.
For example you can sample an external audio source
while listening to the performance of the arpeggiator,
or resample a performance you play using a program.
• Edit a program
Make settings for the oscillator, filter, amp, EG, LFO,
effects, and arpeggiator.
SAMPLING MODE
AUDIO INPUT
1
S/P DIF IN
L
mLAN IN
1
Insert Effect
Resampling
IFX 1
IFX 2
IFX 3
Sample
Analog Audio
CDRW-1
Ripping
CD-ROM
Write Audio CD
Resampling
Basic concepts
AUDIO INPUT
2
S/P DIF IN
R
mLAN IN
2
Multisample
Multisample
Sample
Sample
IFX 4
IFX 5
Sample
Sample
Sample
Sample
GLOBAL MODE
DRUM KIT
Key
Drumsample / Sample - H
Assign
Drumsample / Sample - L
ARPEGGIATOR PATTERN
Preset Arpeggio
Pattern: P0 - 4
User Arpeggio
Pattern: U00 - 231
DISK MODE
Hard Disk
The following multisamples are available for the oscil-
lator.
• 429 internal multisamples (ROM, Piano)
• Expanded multisamples (when one or more EXB-
PCM series board are installed)
• Multisamples (RAM) that you sampled on the
TRITON STUDIO or loaded in from media
• Create drum programs using a drum kit (created in
Global mode)
Combination mode
• Select and play combinations
A combination is a set of two or more programs (a
maximum of eight), and allows you to produce com-
plex sounds that could not be created by an individual
program.
You can choose combinations from rewritable banks
INT-A–INT-E and EXB-A–EXB-G which contain a total
of 1,536 combinations.
• Sample or resample.
For example you can sample an external audio source
while listening to the performance of the arpeggiators,
or resample a performance you play using a combina-
tion.
• Edit a combination
Make settings for volume, pan, layer/split etc. for each
timbre (program), and make settings for effects and the
two arpeggiators.
PROGRAM
OSC 1
Multisample - H
Drum Kit
Multisample - L
PITCH1 FILTER1
AMP1
OSC 2
Multisample - H
Multisample - L
PITCH2 FILTER2
AMP2
COMBINATION
TIMBRE 1
PROGRAM
PROGRAM
TIMBRE 2
TIMBRE 3
PROGRAM
TIMBRE 4
PROGRAM
TIMBRE 5
PROGRAM
TIMBRE 6
PROGRAM
TIMBRE 7
PROGRAM
TIMBRE 8
PROGRAM
SEQUENCER / SONG PLAY
PROGRAM
TRACK 9
PROGRAM
TRACK 1
TRACK 2
PROGRAM
TRACK 10
PROGRAM
TRACK 3
PROGRAM
TRACK 11
PROGRAM
TRACK 4
PROGRAM
TRACK 12
PROGRAM
TRACK 13
TRACK 5
PROGRAM
PROGRAM
TRACK 14
TRACK 6
PROGRAM
PROGRAM
TRACK 15
PROGRAM
TRACK 7
PROGRAM
TRACK 16
TRACK 8
PROGRAM
PROGRAM
Insert / Master Effect
IFX 1
MFX 1
IFX 2
MFX 2
IFX 3
IFX 4
MEQ
IFX 5
Arpeggiator
Insert /Master Effect
IFX 1
MFX 1
IFX 2
MFX 2
IFX 3
IFX 4
MEQ
IFX 5
Arpeggiator - A
Arpeggiator - B
Insert /Master Effect
IFX 1
MFX 1
IFX 2
MFX 2
IFX 3
IFX 4
MEQ
Only SEQ
IFX 5
Arpeggiator - A
Arpeggiator - B
13
