Page 1: User Guide
User guide Conference phone Konftel 100 Dansk I Deutsch I English I Español I Français Italiano I Norsk I Suomi I Svenska Intelligent communications... -
Page 2: Table Of Contents
Connection, accessories, spare parts Programming the R key Volume control, mute, tuning, ring signal volume Troubleshooting and maintenance Konftel 100 • User Guide Contents Description Calling Incoming calls Outgoing calls Redial Three-party calls Conference key Technical data... -
Page 3: Description
Description Loudspeakers Bottom Telephone line input (POTS) Keyset OK key Conference R key Green/red mic indicators Microphone Redial key Konftel 100 • User Guide Keypad Power supply Up/Down key Mute/Pause key... -
Page 4: Connection, Accessories, Spare Parts
10 m 900103340 Extension cable, analogue network, 10 m 900103341 Extension cable, power and analogue network 7.5 m Konftel 100 • User Guide Description Analogue telephone line (POTS) Only a mains transformer type ML120P070G or FRIWO FW7237/12 may be connected. -
Page 5: Calling
R key to get a new dial tone. Enter the number of the second meeting participant and wait for answer. Press the R key followed by the 3 key, and all three can now participate in the call. Konftel 100 • User Guide... -
Page 6: Programming The R Key
Note: The availability and function of the three-party feature can vary from country to country but also depend on the PBX to which the Konftel 100 is connected. If you want to connect multiple participants we recommend you use a telephone meeting service. -
Page 7: Conference Key
Enter your phone conference number with the 0-9... keypad (max 20 digits). If Konftel 100 must wait for a second dial tone, you should insert a pause with the Mute/ Pause key. Press the OK to end and save the number. -
Page 8: Volume Control, Mute, Tuning, Ring Signal Volume
The mic indicators change back to green. Tuning The sound is adjusted automatically for the room and the telephone line when Konftel 100 is switched on. Konftel 100 senses the acoustics of the room and adapts continuously during the call. For manual tuning, press the Up/Down key at the same time. -
Page 9: Troubleshooting And Maintenance
Troubleshooting 1. Check that the microphone is on during the call. The green microphone indicators must be lit. 2. Check that the Konftel 100 is connected to an analogue telephone jack. 3. Bypass any extension cables and check whether the system is functioning correctly. If not, contact your dealer. -
Page 10: Technical Data
Konftel 100 Mains transformer (Europe): DC transformer 240 V AC/12 V DC; 700 mA. Mains transformer (UK): DC transformer 100 - 240 V AC/12 V DC; 700 mA. Network interface: Analogue PBX or PSTN, RJ-11. Power supply and network cable: 7.5 metre, RJ-11 (line), EIAJ Class IV (power). - Page 11 Characteristic of our products is that all conference telephones contain the same high quality audio technology – OmniSound – providing crystal clear sound. Learn more about Konftel Technology and our other products on www.konftel.com Developed by Konftel Technology AB Box 268, SE-901 06 Umeå, Sweden...
