Summary of Contents for Gigabyte G27F2

  • Page 2 GIGABYTE. Changes to the specifications and features in this manual may be made by GIGABYTE without prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by any means without GIGABYTE’s prior written permission.

  • Page 3: Safety Precautions

    Gaming Monitor User Guide Safety Precautions Read through the following Safety Precautions before using the monitor. • Only use the accessories that are provided with the monitor or that which are recommended by the manufacturer. • Keep the plastic packaging bag for the product in a place that cannot be reached by children.

  • Page 4: Stability Hazard Precautions

    Gaming Monitor User Guide Stability Hazard Precautions The product may fall, causing serious personal injury or death. To prevent injury, this product must be securely attached to the floor/wall in accordance with the installation instructions. Many injuries, particularly to children, can be avoided by taking simple precautions such as: •...

  • Page 5: Table Of Contents

    Appendices ..........................33 Specifications ........................33 Supported Timing List ....................34 Troubleshooting ......................36 Basic Care .......................... 37 Notes on USB Charging ....................37 GIGABYTE Service Information ................. 37 Safety Information ........................38 Regulatory Notices ......................38 - 5 -...

  • Page 6: Introduction

    Gaming Monitor User Guide INTRODUCTION Unpacking Open the upper cover of the packaging box. Then observe the unpacking label attached on the inner cover. Making sure the box is in the correct orientation, carefully lay the box on the stable surface. Open the inner cover.
  • Page 7 Gaming Monitor User Guide Remove the items from the upper EPS foam. Remove the upper EPS foam. Then you can remove the monitor from the lower EPS foam. - 7 -...

  • Page 8: Package Contents

    Gaming Monitor User Guide Package Contents The following items come with your packaging box. If any of them is missing, please contact your local dealer. Monitor Monitor Base Power Cable Power Adapter HDMI Cable USB Cable Multilingual Installation Guide G24F Quick Start Guide Warranty Card Note: Please keep the packaging box and packing materials for future...

  • Page 9: Product Overview

    Gaming Monitor User Guide Product Overview Front View Power LED - 9 -...
  • Page 10 Gaming Monitor User Guide Rear View HDMI-1 HDMI-2 USB 3.2 Control button Headphone jack USB upstream port Kensington lock DisplayPort USB 3.2 ports (x2) DC IN jack HDMI ports (x2) Note: HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

  • Page 11: Getting Started

    Gaming Monitor User Guide GETTING STARTED Installing the Monitor Base Place the monitor on the lower EPS foam, with the screen facing down. Align and slide the upper hooks on the stand into the mounting slots on the rear of the monitor. Push the locking latch forward and then release to secure the lower hooks on the stand into the mounting slots on the rear of the monitor.
  • Page 12 Gaming Monitor User Guide Lift the screw ring and turn it clockwise to secure the monitor base in place. Lift the monitor to an upright position and place it on a table. - 12 -...

  • Page 13: Adjusting The Viewing Angle

    Gaming Monitor User Guide Adjusting the Viewing Angle Note: Hold the monitor base so that the screen does not topple when you make the adjustment. Adjusting the Tilt Angle Tilt the screen forward or backward to the desired viewing angle (5˚...

  • Page 14: Installing A Wall-Mount Bracket (Optional)

    Gaming Monitor User Guide Installing a Wall-Mount Bracket (Optional) Use only the 100 x 100 mm wall mount kit recommended by the manufacturer. Place the monitor on the lower EPS foam, with the screen facing down. While pushing the locking latch forward, slide the stand backward to release the upper hooks from the mounting slots on the rear of the monitor.
  • Page 15 Gaming Monitor User Guide Attach the mounting bracket to the mounting holes at the rear of the monitor. Then use the screws to secure the bracket in place. 100 mm 100 mm Note: To mount the monitor on the wall, refer to the installation guide that is included in the wall-mount bracket kit.

  • Page 16: Making Connections

    Gaming Monitor User Guide Making Connections HDMI-1 HDMI-2 USB 3.2 DisplayPort cable HDMI cable Headphone cable USB (A-Male to B-Male) cable USB cable Power adapter and power cable - 16 -...

  • Page 17: Using The Device

    Gaming Monitor User Guide USING THE DEVICE Turning the Power On/Off Power On Connect one end of the power cable to the AC IN jack at the rear of the monitor. Connect other end of the the power cable to a power outlet. Control Press the button to turn on the monitor.

  • Page 18: User Comfort Recommendations

    Gaming Monitor User Guide User Comfort Recommendations The Monitor adopts Flicker-Free technology which clears the eye visible monitor flicker and prevents users from suffering eye strain and fatigue. The following are some tips for comfortable viewing of your monitor: • Optimal viewing distances for monitors range from approximately 510 mm to 760 mm (20 in to 30 in).

  • Page 19: Operations

    Gaming Monitor User Guide OPERATIONS Quick Menu Hot Key Control By default, the button has been assigned with the specific function. Note: To change the preset hot key function, refer to the “Quick Switch” section on page 30. To access the hot key function, do the following: Control ) to enter the Black Equalizer •...
  • Page 20 Gaming Monitor User Guide Control ) to enter the Picture Mode • Move the button down ( menu. Control Move the button up/down ( ) to select the Picture Mode desired option and press the Control button to confirm. Standard RTS/RPG Movie Reader...
  • Page 21 Gaming Monitor User Guide Function Key Guide Control button to display the Main menu. Press the Settings SETTING Dashboard Game Assist DASHBOARD EXIT GAME ASSIST Exit Power Off POWER OFF Control Then use the button to select the desired function and configure the related settings.
  • Page 22 Gaming Monitor User Guide system data to the SOC through the USB port and display the value of the selected function(s) on the screen. CPU Temperature CPU Frequency CPU Fan Speed CPU Usage Rate GPU Temperature GPU Frequency GPU Fan Speed GPU Usage Rate AORUS Mouse DPI Note: Make sure the USB cable is properly connected to the USB upstream port...
  • Page 23 Gaming Monitor User Guide • Game Info: Configure the FPS (First Person Shooting) game related settings. √ Select Gaming Timer to select countdown timer mode. To disable this function, set the setting to OFF. √ Select Gaming Counter or Refresh Rate to enable/disable the gaming counter or real-time refresh rate setting.

  • Page 24: Configure The Device Settings

    Balance 60 HZ Picture Mode Standard Gaming Monitor User Guide Configure the Device Settings When the Main menu appears on the screen, move the Control button ) to enter the Settings menu. up ( Note: Use the Control button to navigate through the menu and make adjustments.
  • Page 25 Gaming Monitor User Guide Item Description Super Sharpen the low resolution images. Resolution Display Mode Select the aspect ratio of the screen. • Full: Scale the input image to fill the screen. Ideal for 16:9 aspect images. • Aspect: Display the input image without geometric distortion filling as much of the screen as possible.
  • Page 26 Gaming Monitor User Guide Picture Configure the image related settings. Brightness Contrast Sharpness Gamma Color Temperature Gamma 3 Normal Picture Mode Standard Gaming Standard Brightness Contrast Picture Color Vibrance Display RTS/RPG Sharpness System Movie Gamma Language Reader Color Temperature Save Settings sRGB Reset All Custom 1...
  • Page 27 Gaming Monitor User Guide Item Description Color Select the color temperature. Temperature Note: Select User Define to customize the color temperature by adjusting the red (R), green (G), or blue (B) level according to your preference. Adjust the black level of the image to achieve the optimum contrast.
  • Page 28 Gaming Monitor User Guide Display Configure the display screen related settings. Brightness Contrast Sharpness Gamma Color Temperature Gamma 3 Normal Picture Mode Standard Gaming Input HDMI 1 Picture RGB Range HDMI 2 Display Overscan DisplayPort System Language Save Settings Reset All Exit Move/Adjust Enter/Confirm...
  • Page 29 Gaming Monitor User Guide System Configure the system related settings. Brightness Contrast Sharpness Gamma Color Temperature Gamma 3 Normal Picture Mode Standard Gaming Audio Volume Picture OSD Setting Mute Display Quick Switch System Other Settings Language Save Settings Reset All Exit Move/Adjust Enter/Confirm...
  • Page 30 Gaming Monitor User Guide Item Description Quick Switch Assign the function of the hot keys. Available options: Aim Stabilizer, Black Equalizer, Volume, Input, Contrast, Brightness, and Picture Mode. The default setting of the hot keys as below: D Up ( ): Black Equalizer D Down ( ): Picture Mode...
  • Page 31 Gaming Monitor User Guide Language Select an available language for the OSD menu. Brightness Contrast Sharpness Gamma Color Temperature Gamma 3 Normal Picture Mode Standard Gaming English Picture Display System Deutsch Language Français Save Settings Reset All 한국어 Exit Move/Adjust Enter/Confirm Save Settings Set the personalized OSD configurations for Setting1, Setting2, or...
  • Page 32 Gaming Monitor User Guide Reset All Restore the monitor to its factory default settings. Brightness Contrast Sharpness Gamma Color Temperature Gamma 3 Normal Picture Mode Standard Gaming Picture Display System Language Save Settings Reset All Exit Move/Adjust Enter/Confirm - 32 -...

  • Page 33: Appendices

    Gaming Monitor User Guide APPENDICES Specifications Item Specifications Panel Size 27-inch Aspect Ratio 16:9 Resolution 1920 x 1080 LED Life 30,000 hours Pixel Pitch 0.3108(H) x 0.3108(V) Brightness 400nits (typ.) Contrast Ratio 1000:1 (typ.) Color Depth 16.7M Active Display Area 597.888(H) x 336.312(V) Viewing Angle 178°(H) / 178°(V)

  • Page 34: Supported Timing List

    Gaming Monitor User Guide Supported Timing List Timing List HDMI DisplayPort 720X400 / 70Hz 720X400 / 88Hz 640X480 / 60Hz 640X480 / 67Hz 640X480 / 72Hz 640X480 / 75Hz 800X600 / 56Hz 800X600 / 60Hz 800X600 / 72Hz 800X600 / 75Hz 832X624 / 75Hz 1024X768 / 87Hz 1024X768 / 60Hz...
  • Page 35 Gaming Monitor User Guide Timing List HDMI DisplayPort 1440X480 / 60Hz 1920X1080 / 50Hz 1920X1080 / 60Hz 1920X1080 / 100Hz 1920X1080 / 120Hz 3840X2160 / 60Hz 1920x1080 / 144Hz 1920X1080 / 165Hz - 35 -...

  • Page 36: Troubleshooting

    Gaming Monitor User Guide Troubleshooting Problem Possible Solution(s) No power • Make sure the power cable is properly connected to the power source and the monitor. • Check the cable and plug to make sure they are not broken. • Make sure the monitor is turned on. No image appears •...

  • Page 37: Basic Care

    When the Hub is connected to a PC, these devices cannot be charged using the USB cable. Vendor Device PID/VID Apple iPad PID_129A/VID_05AC Samsung GALAXY Tab2 10.1 PID_6860/VID_04E8 Samsung GALAXY TabPro PID_6860/VID_04E8 GIGABYTE Service Information More service information, please visit GIGABYTE official website: https://www.gigabyte.com/ - 37 -...

  • Page 38: Safety Information

    Model Number: G27F 2 Responsible Party – U.S. Contact Information: G.B.T. Inc. Address: 17358 Railroad street, City Of Industry, CA91748 Tel.: 1-626-854-9338 Internet contact information: https://www.gigabyte.com FCC Compliance Statement: This device complies with Part 15 of the FCC Rules, Subpart B, Unintentional Radiators.
  • Page 39 European Union (EU) RoHS (recast) Directive 2011/65/EU & the European Commission Delegated Directive (EU) 2015/863 Statement GIGABYTE products have not intended to add and safe from hazardous substances (Cd, Pb, Hg, Cr , PBDE, PBB, DEHP, BBP, DBP and DIBP). The parts and components have been carefully selected to meet RoHS requirement.
  • Page 40 Gaming Monitor User Guide WEEE Symbol Statement The symbol shown below is on the product or on its packaging, which indicates that this product must not be disposed of with other waste. Instead, the device should be taken to the waste collection centers for activation of the treatment, collection, recycling and disposal procedure.
  • Page 41 Gaming Monitor User Guide CE declaração de conformidade Este produto com a marcação CE estão em conformidade com das seguintes Diretivas UE: Diretiva Baixa Tensão 2014/35/EU; Diretiva CEM 2014/30/EU; Diretiva Conceção Ecológica 2009/125/CE; Diretiva RSP 2011/65/UE e a declaração 2015/863. A conformidade com estas diretivas é...
  • Page 42 Gaming Monitor User Guide ES Prohlášení o shodě Toto zařízení splňuje požadavky Směrnice o Elektromagnetické kompatibilitě 2014/30/EU, Směrnice o Nízkém napětí 2014/35/EU, Směrnice ErP 2009/125/ES, Směrnice RoHS 2011/65/EU a 2015/863. Tento produkt byl testován a bylo shledáno, že splňuje všechny základní požadavky směrnic.
  • Page 43 Gaming Monitor User Guide Japan VCCI Class B Statement クラスB VCCI 基準について この装置は、クラスB情報技術装置です。この装置は、家庭環境で使 用することを目的としていますが、この装置がラジオやテレビジョン 受信機に近接して使用されると、受信障害を引き起こすことがありま す。 取扱説明書に従って正しい取り扱いをして下さい。 VCCI-B China RoHS Compliance Statement 中国《废弃电器电子产品回收处理管理条例》提示性说明 为了更好地关爱及保护地球，当用户不再需要此产品或产品寿命终止时， 请遵守国家废弃电器电子产品回收处理相关法律法规，将其交给当地具有 国家认可的回收处理资质的厂商进行回收处理。 环保使用期限 Environment-friendly Use Period 此标识指期限（十年），电子电气产品中含有的有害物质不会 发生外泄或突变、电子电气产品用户正常使用该电子电气产品 不会对环境造成严重 污染或对其人身、财产造成严重损害的 期限。 - 43 -...
  • Page 44 Gaming Monitor User Guide Declaration of the Presence Condition of the Restricted Substances Marking G27F 2 Equipment name Type designa on (Type) Restricted substances and its chemical symbols Unit Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium chromium biphenyls diphenyls ethers (Pb) (Hg) (Cd) (PBB)
