If the information in these instructions is not followed exactly, a fire or explosion may result
WARNING:
causing property damage, personal injury or loss of life.
-
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
-
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
This appliance may be installed in
an aftermarket permanently
located, manufactured home (USA
only) or mobile home, where not
prohibited by local codes.
This appliance is only for use
with the type(s) of gas indicated
on the rating plate. A conversion
kit is supplied with the appliance.
Owner's Manual
Installer:
After installation give this manual to
the home-owner and explain operation
of this heater.
© Copyright 2010, T.I.
$10.00
100-01246_000
4100716
864 HO GS Fireplace
Featuring the
• Direct Vent Fireplace
• Natural Gas or Propane
• Vent Horizontally or Vertically
• Standard Residential
• Mobile Home Approved
Tested and Listed by
Report # 100162735PRT-001 - ANSI Z21.88
www.travisproducts.com
4800 Harbour Pointe Blvd. SW
Mukilteo, WA 98275
Burner

Advertisement

Table of Contents
loading

Summary of Contents for Travis Industries 864 HO GS

  • Page 1 864 HO GS Fireplace Featuring the Burner • Direct Vent Fireplace • Natural Gas or Propane • Vent Horizontally or Vertically • Standard Residential • Mobile Home Approved Tested and Listed by Report # 100162735PRT-001 - ANSI Z21.88 If the information in these instructions is not followed exactly, a fire or explosion may result WARNING: causing property damage, personal injury or loss of life.
  • Page 2: Table Of Contents

    Yearly Service Procedure ................. 26   Glass Cleaning ..................26   Accent Light Bulb Replacement ............... 26   Replacement Parts List ................27   Wiring Diagram ..................28     LP Conversion Instructions ..............29 © Travis Industries 4100716 100-01254_000...
  • Page 3 All other work must be done by a trained technician. Don't modify or replace orifices. • The viewing glass should be opened only for conducting service. • Any safety screen or guard removed for servicing must be replaced prior to operating the heater. © Travis Industries 4100716 100-01254_000...
  • Page 4 The gas main shutoff valve is usually next to the gas meter or propane tank and requires a wrench to shut off. • Travis Industries, Inc. grants no warranty, implied or stated, for the installation or maintenance of your heater, and assumes no responsibility of any consequential damage(s). © Travis Industries...
  • Page 5: Btu Specifications

    Dimensions 1/2" 12mm 14" 356mm 48" 1219mm 44-1/2" 1130mm 36-3/4" 8" (203mm) 933mm 35-1/4" 895mm 40-3/4" 1035mm 1" 25mm 37" 940mm 29-1/4" 743mm 19-3/4" 41" 502mm 1041mm 225 Lbs. (102 Kg) (a) Includes ½” Clearance © Travis Industries 4100716 100-01254_000...
  • Page 6: Fireplace Placement Requirements

    Do not place insulation in this space. (c) Clearance to Angled Sides of Fireplace ½” (12mm) Raised Fireplaces • The fireplace (and hearth, if desired) may be placed on a platform designed to support the fireplace and vent. © Travis Industries 4100716 100-01254_000...
  • Page 7: Min. Framing Dimensions

    Installation (for qualified installers only) Min. Framing Dimensions 56-3/8" 1432mm 48" 1219mm 41-1/4" 1048mm 20-3/4" (527mm) © Travis Industries 4100716 100-01254_000...
  • Page 8: Nailing Brackets

    Installation (for qualified installers only) Nailing Brackets The fireplace has nailing brackets on both sides. Secure the fireplace to the framing. 54-7/8’’ (1394mm) 1/2''(13mm) 1/2" (13mm) 5/8''(16mm) 5/8" (16mm) © Travis Industries 4100716 100-01254_000...
  • Page 9: Gas Line Requirements

    Gas Line Location The gas line is located on the left side of the appliance in the location shown below. The gas inlet accepts a ½” FPT. 6-1/4" 159mm 10-3/4" 273mm 6-1/4" 159mm 10-3/4" 273mm © Travis Industries 4100716 100-01254_000...
  • Page 10: Electrical Connection

    Label all wires prior to disconnection when servicing controls. Wiring errors can cause Caution: improper and dangerous operation. Do not connect 110-120 VAC to the gas control valve or wiring system of this fireplace. © Travis Industries 4100716 100-01254_000...
  • Page 11: Vent Requirements

    • Horizontal sections require a 1/4" (6mm) rise every 12" (305mm) of travel. • Horizontal sections require non-combustible support every three feet (e.g.: plumbing strap). © Travis Industries 4100716 100-01254_000...
  • Page 12: Approved Vent Configurations

    Depending upon the vent configuration, you may be required to adjust the restrictor positions. The charts for acceptable vent configurations detail the correct vent restrictor positions. Exhaust Restrictor (closed) #8 (open - stock position) # 1 Position 3 Position 3 © Travis Industries 4100716 100-01254_000...
  • Page 13: Intake Restrictor

    Installation (for qualified installers only) Intake Restrictor 3/8" Wrench (closed) # 5 (open - stock position) # 1 Position 3 © Travis Industries 4100716 100-01254_000...
  • Page 14: Vent Configuration: Horizontal Termination (No Vertical Rise)

    Min. 4" (102mm) Horizontal Section Max.48" (1219mm) Horizontal Section(s) Vent with 1 45˚ Elbow Exhaust Restrictor # 1 (stock) 3 feet (0.915m) Intake Restrictor # 1 (stock) 0 feet Min. 4" (102mm) Horizontal Section Max. 24" (610mm) Horizontal Section(s) © Travis Industries 4100716 100-01254_000...
  • Page 15: Vent Configuration: Horizontal Termination (With Vertical Rise)

    15 feet (4.5 m) 15 feet (4.5 m) Exhaust Restrictor # 3 Intake Restrictor # 1 (stock) 10 feet (3 m) 10 feet (3 m) 5 feet (1.5 m) 5 feet (1.5 m) 0 feet 0 feet © Travis Industries 4100716 100-01254_000...
  • Page 16: Vent Configuration: Vertical Termination

    Intake Restrictor # 2 25 feet (7.5m) 25 feet (7.5m) 20 feet (6m) 20 feet (6m) 15 feet (4.5m) 15 feet (4.5m) 10 feet (3m) 10 feet (3m) 5 feet (1.5m) 5 feet (1.5m) 0 feet 0 feet © Travis Industries 4100716 100-01254_000...
  • Page 17: Termination Requirements

    Minimum 12” (305mm) above the roof line (for vertical terminations) Minimum 24” (610mm) horizontal clearance to any surface (such as an exterior wall) – for vertical terminations NOTE: Measure clearances to the nearest edge of the exhaust hood. © Travis Industries 4100716 100-01254_000...
  • Page 18: Hearth Requirements

    A non-combustible hearth is not required. However, if the heater is installed next to the floor, we recommend a hearth to protect the flooring surface from discoloration or other negative impact from the heater. Raised Fireplaces A hearth is not required when the fireplace is raised above the flooring surface. © Travis Industries 4100716 100-01254_000...
  • Page 19: Facing Requirements

    Tile or other non-combustible facing may be placed along the perimeter of the fireplace face, but must not extend over it (see “d”). This area must remain open to allow for glass frame removal and air flow. © Travis Industries 4100716 100-01254_000...
  • Page 20: Mantel Requirements

    A combustible or non-combustible mantel must meet the clearances listed below. Maximum Mantel Depth (b) 53-3/4" (1365mm) 52-3/4" (1340mm) 51-3/4" (1314mm) Mantel 50-3/4" (1289mm) Height 49-3/4" (1264mm) Above 48-3/4" (1238mm) 47-3/4" (1213mm) Base (a) 46-3/4" (1187mm) © Travis Industries 4100716 100-01254_000...
  • Page 21: Steps For Finalizing The Installation

    Give this manual to the home owner for future reference and fully explain operation of this heater. Glass Frame Removal and Installation The appliance must be completely cool before removing the glass frame. Warning: © Travis Industries 4100716 100-01254_000...
  • Page 22 Installation (for qualified installers only) Do not strike or slam the glass frame. Warning: © Travis Industries 4100716 100-01254_000...
  • Page 23: Log Installation

    Installation (for qualified installers only) Log Installation Install the logs as shown below. © Travis Industries 4100716 100-01254_000...
  • Page 24: Before You Begin

    This switch turns the rear burner on and off. (e) Comfort Control This holder contains 4 AA batteries that allow the fireplace to operate AA Battery Holder during power outages. This switch turns the fireplace burners on and off. (f) Main Burner © Travis Industries 4100716 100-01254_000...
  • Page 25: Continuous Pilot / Greensmartâ„¢ Pilot Switch

    Frequent On / Off Operation – if you are frequently turning the fireplace on and off, you may wish to leave it in continuous pilot. This allows the burner to turn on more quickly, without pilot ignition delay. © Travis Industries 4100716...
  • Page 26: Yearly Service Procedure

    WARNING: do not operate the fireplace without the glass frame in place. Accent Light Bulb Replacement WARNING: Use only 35 Watt 120 Volt T4 Halogen Bulbs (G6.35 Base) Several accent lights are included in your fireplace to provide additional lighting. Contact your dealer for replacement information. © Travis Industries 4100716 100-01254_000...
  • Page 27: Replacement Parts List

    LP Conversion Instructions Replacement Parts List Caution: Use only Travis Industries replacement parts. Do not use substitute materials. Warning: Do not operate appliance with the glass front removed, cracked, or broken. Replacement of the glass should be done by a licensed or qualified service person.
  • Page 28: Wiring Diagram

    GREENSMART CONTROL PILOT Accent Thermodisk Light (s) Optional Blower(s) Accent Light Rheostat Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. © Travis Industries 4100716 100-01254_000...
  • Page 29: Lp Conversion Instructions

    Remove the ember trays and burner (see below). Grasp the burner with both hands and lift it straight up and out of the firebox. Remove and discard the back air shield. Remove and discard the manifold cover (see below). © Travis Industries 4100716 100-01254_000...
  • Page 30 Look here for the orifice identification Screw each LP orifice in so the orifice protrudes 15/16" (24mm) Front 1.25mm (indicating full insertion). Rear .0625 15/16" 24mm Install the new manifold cover included in owner’s pack (see illustration below). © Travis Industries 4100716 100-01254_000...
  • Page 31 – tighten to 25 Lb-inches. Leak test this area after installation to verify proper installation. Re-attach the wiring. Make the gas line connection, bleed the gas line (if applicable), start the heater and thoroughly leak- test all gas connections and the gas control valve. © Travis Industries 4100716 100-01254_000...
  • Page 32 Vent Configuration: Horizontal Termination (with vertical rise) ..15 Vent Configuration: Vertical Termination ........... 16 Vent Firestop ..................11 Vent Installation ................. 11 Vent Requirements ................11 Wiring Diagram ................. 28 Yearly Service Procedure ..............26 © Travis Industries 4100716 100-01254_000...
