Desa GMC26F Assembly Instructions

GMC26F and GMC27U Hardwood
IMPORTANT: Read entire instruction sheet before assembling or installing mantel kit.
This mantel is only approved for use with RF(N/P)28T and RF(N/P)30T series Natural
and Propane models. Do not use mantel with any other product.
This mantel kit contains the following pieces:
Qty.
1 Left leg
1 Right leg
1 Header
1 Top
1 Base
1 Hardware package
2 Hardware bracket
2 Mounting blocks
The hardware package contains the following:
11 1 1/4" screws
2 1 3/4" screws
2 3" wood screws (not required)
Tools required:
#2 Phillips screw driver (regular length)
Only use 1 1/4" screws to assemble header and
top. Damage to the mantel will result if the longer
screws provided are used for this purpose.
GMC28F Oak
Prestige Mantel
Assembly Instructions
Part No.
GMC26F GMC27U
103755-01 103755-02
103755-03 103755-04
103755-05 103755-06
103755-07 103755-08
103755-09 103755-10
101223-02 101223-02
103680-01 103680-01
101527-01 101527-01
WARNING
WARNING ICON G 001
If any of these pieces are missing or dam-
aged, contact the dealer where you pur-
chased this kit or DESA International at 1-
800-972-7879 for referral information.
WARNING: Use care when
GMC28F
finishing an unfinished mantel.
103755-11
Finish pieces before assembly.
103755-12
Do not finish mantel pieces near
103755-13
running heater or open flame. Va-
103755-14
pors from most finishing prod-
103755-15
ucts are highly flammable. Fol-
101223-02
low manufacturer's guidelines
103680-01
when using finishing products.
101527-01
IMPORTANT:
ished mantel, apply an oil base undercoat to
the mantel before painting. This will seal the
wood. After undercoat dries completely,
lightly sand and apply an oil base top coat.
If you do not apply an oil base undercoat and
topcoat, the wood grain will bleed through
the paint.
Note: Place all mantel pieces together be-
fore actually assembling mantel.
If you are painting an unfin-
