CHAPTER 1 Getting Help • Thank you for purchasing our computer! • Using the eMachines Web site • Using Help and Support • Using Online help • Contact information • Microsoft Certificate of Authenticity...
Thanks again, from all of us at eMachines. eMachines's online support is available 24 hours per day, 7 days per week, and provides the most current drivers, product specifications, tutorials, and personalized information about your computer.
Use Help and Support to answer questions about Windows and to help you quickly discover and use the many features of your eMachines computer. To start Help and Support: Click Start, then click Help and Support. Help and Support opens.
Many programs provide information online so you can research a topic or learn how to perform a task while you are using the program. You can access most online help information by selecting a topic from a Help menu or by clicking a Help button. www.emachines.com...
Contact information The label on the front of your computer case contains information that identifies your computer model and serial number. eMachines Customer Care will need this information if you call for assistance.
The Microsoft Certificate of Authenticity label found on the back or side of your computer includes the product key code for your operating system. If you ever reinstall Windows from the installation CD or DVD, you will need to enter these numbers to activate Windows. www.emachines.com...
CHAPTER 2 Getting to Know Your Computer • Front • Back • Connecting the dial-up modem • Connecting to a cable or DSL modem or to a wired Ethernet network • Installing a printer, scanner, or other peripheral device • Configuring the audio jacks...
USB port (optional) Hard drive access indicator IEEE 1394 ports (optional) USB ports (optional) eMachines help resources and Customer Care information Component Icon Description Optical drive Use this drive to listen to audio CDs, install games and programs, watch DVDs, and store large files onto recordable discs (depending on drive type).
Page 16
Plug a microphone into this jack. This jack is color-coded red or pink. Headphone jack Plug powered, analog front speakers, an external amplifier, or headphones into this jack. This jack is color-coded orange. eMachines help Contains information about how to access eMachines Customer Care. resources and Customer Care information eMachines model Contains your model and serial number.
Parallel port Plug a parallel device (such as a printer) into this port. For more information, see “Installing a printer, scanner, or other peripheral device” on page www.emachines.com Case cover thumbscrew 1394 ports (optional)
Connecting the dial-up modem Warning To reduce the risk of fire, use only No. 26 AWG or larger telecommunications line cord. Component Icon Description Monitor port Plug a monitor into this port. USB ports Plug USB (Universal Serial Bus) devices (such as a USB Iomega™ Zip™ drive, (optional) printer, scanner, camera, keyboard, or mouse) into these ports.
To connect to a cable or DSL modem or to an Ethernet network: Insert one end of the network cable into the network jack of your computer. Insert the other end of the network cable into a network jack. www.emachines.com on the back...
Installing a printer, scanner, or other peripheral device Important Before you install a printer, scanner, or other peripheral device, see the device documentation and installation instructions. Help and Support For more information about installing peripheral devices, click Start, then click Help and Support.
Page 21
CHAPTER 2: Getting to Know Your Computer www.emachines.com...
CHAPTER 3 Using Your Computer • Working safely • Starting your computer • Turning off your computer • Restarting (rebooting) your computer • Using the keyboard • Using the mouse • Adjusting the volume...
Use an adjustable chair that is comfortable, distributes your weight evenly, ■ and keeps your body relaxed. www.emachines.com Top of screen is not higher than eye level Screen is perpendicular...
Setting up your computer and computer accessories Sitting at your computer Avoiding discomfort and injury from repetitive strain Position your chair so the keyboard is at or slightly below the level of your ■ elbow. This position lets your shoulders relax while you type.
To set the voltage selection switch: Use a tool such as an opened paper clip to slide the voltage selection ■ switch to the correct voltage position. Voltage selection switch www.emachines.com...
Starting your computer Important Your computer has a built-in variable speed fan. In addition, your computer uses a powerful processor which produces heat. Both the system fan and processor can run at different speeds at times to ensure proper system cooling.
As a part of the regular startup process, a program to check the disk status runs automatically. When the checks are finished, Windows starts. Audio playback Editing buttons buttons Function keys Windows keys www.emachines.com Navigation keys Internet buttons Indicators Directional keys Application key...
Standard keyboard Keyboard features Function keys Windows keys The keyboard has several different types of keys and buttons. Your keyboard also has status indicators that show which keyboard feature is active. Feature Icon Description Editing buttons Use these buttons to copy, cut, and paste.
You can use the left and right buttons on the mouse to select objects on the display. You can use the scroll wheel on the mouse to move through a document. This feature is not available in all programs. www.emachines.com Right button Scroll wheel...
Tips & Tricks For more information about how to adjust the double-click speed, pointer speed, right-hand or left-hand configuration, and other mouse settings, “Changing the mouse settings” on page 104. Adjusting the volume Tips & Tricks For instructions on how to adjust the volume in Windows, see “Adjusting the...
Page 31
CHAPTER 3: Using Your Computer www.emachines.com...
CHAPTER 4 Using Windows XP • Using the Windows desktop • Working with files and folders • Searching for files • Working with documents • Using shortcuts...
The Windows Security Center icon may appear on the taskbar near the clock. The icon changes appearance to notify you when the security settings on your computer are set below the recommended value or when updates are available. Double-click this icon to open the Windows Security Center. www.emachines.com...
Using the Start menu Help and Support For more information about the Windows desktop, click Start, then click Help and Support. Type the keyword Windows Start menu in the Search box, then click the arrow. You can start programs, open files, customize your system, get help, search for files and folders, and more using the Start menu.
The title bar is the horizontal bar at the top of a window that shows the window title. Clicking the minimize button reduces the active window to a button on the taskbar. Clicking the program button in the taskbar opens the window again. www.emachines.com Close Maximize Minimize...
Window item Help and Support For more information about the Windows desktop, click Start, then click Help and Support. Type the keyword window in the Search box, then click the arrow. Working with files and folders Viewing drives Description Clicking the maximize button expands the active window to fit the entire computer display.
Click File, New, then click Folder. The new folder is created. Type a name for the folder, then press E by the folder icon. For information about renaming folders, see www.emachines.com . The new folder name appears NTER “Using shortcuts” on page...
Copying and moving files and folders Important The clipboard stores whatever you cut or copy until you cut or copy again. Then the clipboard contains the new information only. Therefore, you can paste copies of a file or folder into more than one place,...
Page 39
Click File, then click Empty Recycle Bin. Windows asks you if you are sure that you want to empty the bin. Click Yes. Windows permanently deletes all files in the Recycle Bin. www.emachines.com “Searching for files” on “Using shortcuts” on page...
Searching for files Using the Windows Search utility If you are looking for a particular file or folder or a set of files or folders that have characteristics in common, but you do not remember where they are stored on...
(usually many more levels than a file cabinet, in fact). So you will usually have to search through levels of folders to find the file or folder that you need. This is called browsing. www.emachines.com...
Page 42
Help and Support For more information about the Windows desktop, click Start, then click Help and Support. Type the keyword files and folders in the Search box, then click the arrow. To browse for a file: Click Start, then click My Computer. The My Computer window opens.
To create a new document: Click Start, All Programs, Accessories, then click WordPad. Microsoft WordPad starts and a blank document opens. Begin composing your document. Use the menus and toolbar buttons at the top of the window to format the document. www.emachines.com...
Saving a document Help and Support For more information about the Windows desktop, click Start, then click Help and Support. Type the keyword saving in the Search box, then click the arrow. Opening a document After you create a document, you need to save it if you want to use it later.
Start the program and open the document. Click File, then click Print. The Print dialog box opens. Set the print options, then click OK. The document prints. www.emachines.com “Installing a printer, scanner, or 13. For information on installing a printer on...
Using shortcuts Help and Support For more information about the Windows desktop, click Start, then click Help and Support. Type the keyword Windows keyboard shortcuts in the Search box, then click the arrow. The following table shows a few shortcuts that you can use in Windows and almost all programs that run in Windows.
Page 47
CHAPTER 4: Using Windows XP www.emachines.com...
An e-mail program—a program that lets you create, send, and receive ■ e-mail messages over the Internet. Microsoft Outlook or Outlook Express was included with your computer. For more information, see e-mail” on page www.emachines.com “Using the World Wide Web” on page “Using...
Setting up an Internet account Accessing your Internet account Help and Support For general information about using Internet accounts, click Start, then click Help and Support. Type the keyword ISP in the Search box, then click the arrow. Using the World Wide Web Before you can view the information on the World Wide Web, you need to set up an Internet account with an Internet service provider (ISP).
To go to a different Web site, type the address (called a URL for “Universal Resource Locator”) in the browser address bar (for example www.emachines.com), then click GO on the browser address bar. - OR - On the current Web page, click a link to a Web site.
Tips & Tricks To protect your children from accessing objectionable Web sites, use the Parental Control feature in McAfee SecurityCenter. Downloading files Caution To protect your computer against viruses, make sure that you scan the files you download. For more information, see “Protecting your computer from viruses”...
Type the e-mail address of the recipient you want to send e-mail to in the To box. Type the subject of your e-mail in the Subject box. Type the e-mail message. When finished, click Send. Your e-mail is sent over the Internet to the e-mail address you specified. www.emachines.com Internet domain name...
Checking your e-mail Tips & Tricks To protect your computer from viruses, check any e-mail attachments using McAfee SecurityCenter. For more information, see “Protecting your computer from viruses” on page 111. Help and Support For general information about using Internet accounts, click Start, then click Help and Support.
Page 55
CHAPTER 5: Using the Internet www.emachines.com...
CHAPTER 6 Networking Your Computer • Introduction to Networking • Creating an Ethernet network • Sharing resources • Using the network • Adding a printer to your network...
Ethernet cables in your home or office. The most common way to set up an Ethernet network is Dynamic Host Control Protocol (DHCP) using a router. A DHCP network configuration uses a router to automatically assign IP addresses to each computer or network device. www.emachines.com...
Page 58
Tips & Tricks To add the ability to access a wireless Ethernet network to your wired Ethernet network, connect an access point to the router or use a router that has a built-in access point, such as the Linksys wireless access point router with 4-port switch.
Click Start, then click Control Panel. The Control Panel window opens. If your Control Panel is in Category View, click Performance and Maintenance. The Performance and Maintenance window opens. Click/Double-click System. The System Properties dialog box opens. Click Computer Name. www.emachines.com “Adding or replacing...
Configuring the TCP/IP protocol Click Change. The Computer Name Changes dialog box opens. Type a unique computer name in the Computer name box. This name identifies the computer to other users on the network. Use a computer name of up to 15 characters with no blank spaces. Each computer name must be unique on your network.
Page 61
If you do not see TCP/IP, drag the scroll bar to see more choices. Click Properties. The Internet Protocol (TCP/IP) Properties dialog box opens. Click the General tab. Click Obtain an IP address automatically. Click OK to close the Internet Protocol (TCP/IP) Properties dialog box. www.emachines.com...
Setting up an Ethernet network Important Category 5 cables are available in two different types; straight-through cables, used to connect computers to a router, and crossover cables, used to connect two computers. To determine which type of cable you...
Page 63
Repeat Step 3 for each computer on the network. For an Internet connection, plug a straight-through cable into the WAN port on the router and the other end into the Ethernet jack on the DSL or cable modem. www.emachines.com...
Configuring your router Important The following configuration information ® applies to the Linksys EtherFast Cable/DSL routers. For any other brand or model of router, see the manufacturer’s documentation, which may accompany the router or be available from the manufacturer’s Web site.
If you share a drive, the entire contents of that drive will be available to everyone on your network. If you share a folder, only the contents of that folder will be available to everyone on the network. Click the Sharing tab. www.emachines.com...
Page 66
If this is the first time you have shared a drive or folder, click Network Setup Wizard to enable remote access, then follow the on-screen instructions. - OR - If you have previously enabled remote file access and you want to share...
Click the arrow button to open the Drive list, then click the drive letter you want to map this drive or folder to. Click Reconnect at Logon if you want to reconnect to this drive or folder each time you log on to the network. Click Finish. www.emachines.com “Viewing shared...
Opening files across the network Copying files across the network Printing files across the network Important Before you can print a file across the network, you must install the driver for the printer on the computer you are sending the file from. You can obtain the...
Connect your printer to your access point if the access point includes a ■ USB or parallel port. For more information, see the instructions that came with your access point. Use a printer that has built-in wireless networking. ■ Use a wireless print server. ■ www.emachines.com “Sharing drives and printers”...
CHAPTER 7 Sending and Receiving Faxes • Installing and configuring Fax • Sending a simple fax • Setting up your cover page template • Faxing from programs • Faxing a scanned document • Receiving and viewing a fax • Canceling a fax •...
The Windows Components Wizard opens. Click Fax Services, then click Next. Click Finish to exit the Windows Components Wizard. Click Exit to close the Welcome to Microsoft Windows XP dialog box. -OR- Click Close to close the Add or Remove Programs dialog box. www.emachines.com...
Configuring Fax Important The first time you run the Fax Configuration Wizard, you may need to provide information in the Location Information and the Phone and Modem Options dialog boxes. Before you send your first fax, you need to set up your user information. Your fax cover sheets and fax headers contain this information, some of which is required by law.
Page 73
Next. The Configuration Summary screen opens. Click Finish. The fax console opens. If the Windows Security Alert dialog box opens, click Unblock. www.emachines.com Step...
Sending a simple fax You can use the Send Fax Wizard to send a simple one-page fax to one or more recipients. To send a simple fax: Click Start, All Programs, Accessories, Communications, Fax, then click Send a Fax. The Send Fax Wizard opens.
Click File, then click Print. The Print dialog box opens. Click the arrow button to open the Name list, then click the Fax printer. Click Print. The Send Fax Wizard opens. Complete the wizard by following the instructions in fax” on page www.emachines.com “Sending a simple...
Faxing a scanned document Receiving and viewing a fax Canceling a fax Automatically retry sending a fax To fax a document that you have scanned: Scan the document using the program for your scanner. With the scanned file open, click File, then click Print. The Print dialog box opens.
Right-click Fax, then click Properties. The Fax Properties dialog box opens. Click the Devices tab, then click Properties. The Modem dialog box opens. Click the Cleanup tab. Click to select the Automatically delete failed faxes after check box and specify the number of days. Click OK. www.emachines.com...
CHAPTER 8 Using Drives and Ports • Using the memory card reader • Using the CD or DVD drive • Using a second monitor • Viewing the display on a television • Using Windows Media Center • Using multimedia • Playing music and movies •...
® CompactFlash ™ IBM Microdrive Each slot is assigned a different drive letter (for example, the E: and F: drives) so data can be transferred from one memory card type to another. www.emachines.com Memory card reader slots Slot Insert left...
Using a memory card Caution To avoid memory card damage or errors while using a memory card, insert only one memory card in a slot at a time. Caution Do not remove the memory card or turn off the computer while the memory card reader access indicator is blinking.
Press the eject button on the CD or DVD drive. Place the disc in the tray with the label facing up. Press the eject button to close the tray. www.emachines.com Use your drive for... Installing programs, playing audio CDs, playing DVDs, accessing data, and recording video and data to DVD+R, DVD+RW, DVD-R, and DVD-RW discs.
Using a second monitor Important The dialog boxes shown in this section are examples only and may not represent the actual screens on your computer. Tips & Tricks For the location of the VGA port on your computer, see the setup poster or “Back”...
Start your computer. Click Start, then click Control Panel. The Control Panel window opens. If your Control Panel is in Category View, click Appearance and Themes. Click/Double-click the Display icon. The Display Properties dialog box opens. Click the Settings tab. www.emachines.com...
Page 84
Important If the Enable TV and TV buttons are grayed out, your computer has not detected the television. Make sure that the television is turned on and connected correctly. Click Advanced. The Multiple Monitors Properties dialog box opens. Click the Displays tab.
CHAPTER 8: Using Drives and Ports Modifying television settings To modify television settings: On the Multiple Monitors Properties dialog box Displays tab, click TV. The TV Properties dialog box opens. Modify the settings, then click OK. www.emachines.com...
Using Windows Media Center Audio/Video (A/V) control entry buttons If your computer came with Windows Media Center installed and with a Media Center remote control (optional), you can use the remote control to watch TV, videos, and DVDs, to listen to music, and to view photos. (The remote control included with your Media Center may look different.) For detailed setup...
Navigate to TV, then press OK. Navigate to Guide, then press OK. Navigate to Get guide data, then press OK. The Guide Data dialog box opens. Select Yes, then press OK. Media Center downloads the Program Guide updates. www.emachines.com button to make a...
Using multimedia Adjusting the volume Help and Support For more information about adjusting the volume, click Start, then click Help and Support. Type the keyword adjusting volume in the Search box , then click the arrow. You can use the Windows volume controls to adjust the overall volume and the volume of specific sound devices in your computer.
Page 89
OK. Drag the volume level and balance sliders for the device you want to adjust. For more information about the volume controls, click Help in the window. Click × in the top-right corner of the window to close it. www.emachines.com...
Playing music and movies Playing WAV audio files Playing audio and video files Sound Recorder is a simple Windows program that lets you record and play WAV files. WAV is the most common audio file format used for your Windows system sounds.
DVD drive-equipped computer. Playing a CD or DVD using Windows Media Player Use Windows Media Player to listen to CDs or watch DVDs. For more information about using Windows Media Player, click Help. www.emachines.com Video file information Video screen...
Page 92
Shortcut Insert a CD or DVD Windows Media Player opens and plays the disc To play a CD or DVD: Make sure that the speakers are turned on or headphones are plugged in and that the volume is turned up.
Sound recorder is a simple Windows program that lets you record and play WAV files. WAV is the most common audio file format used for your Windows system sounds. For information about playing WAV files, see on page www.emachines.com (play). The DVD plays. “Playing WAV audio files”...
Page 94
Help & Support For more information about making or playing an audio recording, click Start, then click Help and Support. Type the phrases recording audio or playing audio in the Search box, then click the arrow. To record a WAV audio file: Plug a microphone into one of the Microphone jacks on your computer.
Page 95
Click Tools, Options, then click the Rip Music tab. Click the arrow to open the Format list, then click either mp3 or Windows Media Audio. For more information on the differences between the two types of files, click Learn more about MP3 formats. www.emachines.com...
Building a music library Caution During the download process, WMA and MP3 files may become corrupt. If you are having trouble listening to, or working with, a downloaded file, try downloading the file again. Click File, CDs and Devices, Rip Audio CD, then click the drive that contains the audio CD.
(optional) on your computer. For more information about using Windows Movie Maker, see its online help. You may have received additional movie editing software with your computer. For more information about using this software, including additional features not available in Windows Movie Maker, see that program’s online help. www.emachines.com...
Transferring your video to your computer To transfer your video to your computer: Connect your video camera to your computer by following the camera manufacturer’s instructions. If a dialog box opens with a list of video editing programs, click Windows Movie Maker.
■ friends and family can watch your video on the Web. Click Send to DV Camera to play your video back to your video camera ■ so you can record it on tape and view it on your television. www.emachines.com...
Creating music CDs and video DVDs Important Some CDs have copy protection software. You cannot create MP3, WAV, or WMA files from these CDs and you may not be able to listen to these CDs on your computer. Tips & Tricks You can also use Windows Media Player to create music CDs.
To create a video DVD using Windows Media Center: Insert a blank, writable DVD-R or DVD-RW disc into your recordable DVD drive. Press the Start button on the remote control. Media Center starts. Click More Programs, then click Create CD/DVD. www.emachines.com...
Advanced multimedia software features Recording audio Click Video DVD, then click OK. Follow the on-screen prompts to finish burning the DVD. For more information, click the Media Center’s Help icon. Windows Media Player advanced features You can use Windows Media Player to transfer WMA and MP3 files to your portable music player, to listen to Internet radio, and to watch Internet TV.
Page 103
Open the Sound Recorder. Click File, then click Open. The Open dialog box opens. Click the file you want to play, then click Open. Play the file by clicking (play), then stop playing the file by clicking (stop). www.emachines.com Record Play Stop (stop).
CHAPTER 9 Customizing Your Computer • Adjusting the screen and desktop settings • Changing the mouse settings • Changing Power-Saving Settings • Installing an uninterruptible power supply...
Click Start, then click Control Panel. The Control Panel window opens. If your Control Panel is in Category View, click Appearance and Themes. Click/Double-click the Display icon. The Display Properties dialog box opens. Click the Settings tab. Single-monitor computer www.emachines.com Dual-monitor computer...
Help and Support For more information about changing the power scheme, click Start, then click Help and Support. Type the keyword changing display settings in the Search box, then click the arrow. Adjusting the screen resolution Help and Support...
Change the color or font settings for the item. Click OK, then click the Themes tab. Click Save As, type a name for the new theme, then click OK twice. The new colors appear on your desktop. www.emachines.com...
Changing the desktop background Help and Support For more information about changing the power scheme, click Start, then click Help and Support. Type the keyword changing desktop background in the Search box, then click the arrow. You can change the Windows desktop background picture. Windows provides several backgrounds, or you can use pictures that you have created or retrieved from other sources.
On resume, display Welcome screen check box. If you want to change the time before the screen saver is activated, ■ click the up or down arrows next to the Wait box. Click OK. www.emachines.com...
Using an extended desktop Help and Support For more information about changing the power scheme, click Start, then click Help and Support. Type the keyword multiple monitors in the Search box, then click the arrow. If your computer supports dual monitors (it must have multiple monitor ports), you can use a second monitor to roughly double the size of your Windows desktop.
Click Start, then click Control Panel. The Control Panel window opens. If your Control Panel is in Category View, click Printers and Other Hardware. Click/Double-click the Mouse icon. The Mouse Properties dialog box opens. Click one of the tabs to change your mouse settings. Click OK to save changes. www.emachines.com...
Changing Power-Saving Settings Changing the power scheme Help and Support For more information about changing the power scheme, click Start, then click Help and Support. Type the keyword power scheme in the Search box, then click the arrow. Power schemes (groups of power settings) let you change power saving options, such as when the monitor or hard drive is automatically turned off.
The next time you turn on your computer, it reads the memory information from the hard drive and opens the programs and documents that were open when you activated Hibernate mode. www.emachines.com...
Page 114
Help and Support For more information about changing the power scheme, click Start, then click Help and Support. Type the keyword hibernate in the Search box, then click the arrow. To activate Hibernate mode: Click Start, then click Control Panel. The Control Panel window opens. If your Control Panel is in Category View, click Performance and Maintenance.
Click the UPS tab. Click Select. The UPS Selection dialog box opens. Click the manufacturer and model of the UPS device, then click the serial port where the UPS device is attached. Click Finish, then click OK. www.emachines.com...
The password feature is very secure, and you cannot bypass it. If you forget your password, you will have to return your computer to eMachines so we can reset it. About Windows XP user accounts Although you may be able to replace your computer with a call to your insurance agent, you cannot replace the information stored on your computer.
Help & Support For more information about Windows XP user accounts, click Start, then click Help and Support. Type the phrase user accounts in the Search box, then click the arrow. Protecting your computer from viruses Help & Support...
CHAPTER 10: Protecting Your Computer Using McAfee SecurityCenter Your new eMachines computer has McAfee SecurityCenter installed. McAfee SecurityCenter includes the following components: McAfee VirusScan is an anti-virus subscription service. You can use ■ VirusScan to protect your computer from viruses, worms, Trojan horses, and hybrid attacks.
Page 120
Starting McAfee SecurityCenter To start McAfee SecurityCenter: Click Start, All Programs, McAfee, then click McAfee Security Center. ■ McAfee SecurityCenter opens. Scanning for and removing viruses To scan for viruses: Start McAfee SecurityCenter. Click virusscan. Data security...
Page 121
Start McAfee SecurityCenter. Click Update. The McAfee SecurityCenter Updates wizard opens. Click Check Now. If it is time to extend your subscription, an alert appears on your screen. Click Renew my subscription to extend your subscription and continue updating McAfee SecurityCenter. www.emachines.com...
Using Windows XP Security Center Windows Security Center helps protect your computer through: a firewall ■ automatic Windows updates ■ third party virus protection software ■ security options in Internet Explorer ■ Modifying security settings To modify security settings: Click Start, Control Panel, then double-click Security Center.
Microsoft creates a high-priority Windows update to fix the problem. You should update Windows regularly to keep your computer secure. Express—Click Express to download high-priority updates. These updates ■ include security updates. Custom—Click Custom to download high-priority, Windows software, ■ and hardware driver updates. These updates include security updates. www.emachines.com...
Page 124
Windows XP Security Center Use the Windows XP Security Center to schedule automatic updates. Windows can routinely check for the latest important updates for your computer and install them automatically. To schedule automatic updates: Click Start, Control Panel, then double-click Security Center.
It automatically gathers information about the latest bugs, security alerts, and updates from BigFix sites on the Internet. Whenever BigFix detects a problem, it alerts you by flashing the blue taskbar icon. To fix the problem, click on that icon to open BigFix. www.emachines.com...
CHAPTER 11 Protecting and Recovering Your Files and Software • System recovery options • Copying driver and application recovery files • Recovering your system...
Problem-solving may also involve re-installing some or all of the computer’s software (also called recovering or restoring your system). eMachines provides everything you need to recover your system under most conditions. A backup copy of your operating system is provided on a CD or DVD, and a backup copy of your factory-installed drivers and applications is saved on a hidden area of your hard drive.
Creating recovery discs Important If you are recording to CDs, make sure that they are CD-R and not CD-RW discs. If you are recording to a DVD, make sure that it is a DVD-R or DVD+R disc, not DVD-RW or DVD+RW discs.
CHAPTER 11: Protecting and Recovering Your Files and Software Important Use a permanent marker to label each disc “eMachines Driver and Application Recovery.” As you remove each disc from the drive, use the marker to label each disc 1 of x, 2 of x, 3 of x, and so on.
Store your recovery (ISO) images in a folder that indicates which computer the files are for. For example, store the files for an eMachines T2862 in a folder named eM T2862 Apps Recovery. Creating discs from recovery files on a network...
DVD-R disc. Important Use a permanent marker to label each disc “eMachines Driver and Application Recovery.” As you remove each disc from the drive, use the marker to label each disc 1 of x, 2 of x, 3 of x, and so on.
Recovering specific files and software You can perform a partial recovery by recovering specific files, such as device drivers and most pre-installed software. If you need to recover software that did not come pre-installed on your system, you need to follow the software’s own instructions for installation.
CHAPTER 11: Protecting and Recovering Your Files and Software Recovering your system using Microsoft System Restore Before using eMachines System Recovery, you should try Microsoft System Restore to determine whether you can restore your system to a previous condition. Every time you install new device drivers or software, and every 24 hours (while your computer is turned on), Microsoft System Restore takes a “snapshot”...
Click Next, then follow the on-screen instructions to finish the restoration. If completing Microsoft System Restore does not solve your problem, restart eMachines System Recovery. See hard drive” on page 127 for instructions. To recover your system from the hard drive: Remove all CDs and DVDs from the disc drives, disconnect all USB devices except the keyboard and mouse, then disconnect your Internet cable.
Page 135
Click Yes. Files are restored to your hard drive. When file recovery has finished, the System Restore dialog box opens. Click Restart. Your computer restarts, and Windows finishes its setup and installation. Reconnect your Internet cable and all USB peripheral devices. You are done. www.emachines.com...
CHAPTER 12 Maintaining Your Computer • Caring for your computer • Updating Windows • BigFix • Managing hard drive space • Moving from your old computer...
A soft, lint-free cloth ■ An aerosol can of air that has a narrow, straw-like extension ■ Cotton swabs ■ A CD or DVD drive cleaning kit ■ www.emachines.com Monthl When See... needed page 111 page 116 page 130 page 133...
Page 138
Warning When you shut down your computer, the power turns off, but some electrical current still flows through your computer. To avoid possible injury from electrical shock, unplug the power cord and modem cable from the wall outlets. Caution...
To fix the problem, click on that icon to open BigFix. * Program availability varies by country or region. To start BigFix: Click Start, All Programs, Accessories, System Tools, then click BigFix. ■ www.emachines.com 116. Windows Update , then click...
Managing hard drive space Checking hard drive space Using Disk Cleanup To learn more about using BigFix: From the BigFix program, click Help, then click Tutorial. ■ Windows provides several utilities you can use to manage your hard drive.
To check the hard drive for errors: Click Start, then click My Computer. The My Computer window opens. Right-click the hard drive that you want to check for errors, for example Local Disk (C:), then click Properties. The Properties dialog box opens. www.emachines.com...
Help and Support For more information about Windows Update, click Start, then click Help and Support. Type the keyword checking for disk errors in the Search box, then click the arrow. Defragmenting the hard drive Click the Tools tab.
(if you have a diskette drive). Use a backup device, such as a recordable drive or Zip drive, to do a complete hard drive backup. For more information, see page www.emachines.com “Advanced multimedia software features” on...
Using the Scheduled Task Wizard Important Your computer must be on during scheduled tasks. If your computer is off, scheduled tasks will not run. Help and Support For more information about Windows Update, click Start, then click Help and Support.
Help and Support For more information about Windows Update, click Start, then click Help and Support. Type the keyword searching for files in the Search box, then click the arrow. Transferring Internet settings Help and Support For more information about Windows Update, click Start, then click Help and Support.
Add Printer wizard opens. Install your printer by following the on-screen instructions. See your peripheral device’s user guide for installation information and tips. Because most installation software is periodically updated, you should also check the manufacturer’s Web site for software updates. www.emachines.com...
Installing your old programs Tips & Tricks If your new computer comes with a newer version of a program, it is usually better to use the newer version than to reinstall the old one. Help and Support For more information about Windows Update, click Start, then click Help and Support.
Page 149
CHAPTER 12: Maintaining Your Computer www.emachines.com...
CHAPTER 13 Adding and Replacing Components • Preventing static electricity discharge • Opening the case • Closing the case • Installing memory • Replacing the system battery • Adding or replacing a CD or DVD drive • Replacing the memory card reader •...
Follow the instructions in page 144. Shut down your computer, then disconnect the power cord and modem, network, and all peripheral device cables. Press the power button to drain any residual power from your computer. www.emachines.com “Preventing static electricity discharge” on...
Page 152
Opening the case Remove the two thumbscrews from the side panel cover, slide the side panel cover toward the back of the computer, then lift the panel away from the computer.
Position the computer where you can grasp the top front edge of the ■ bezel, then pull the bezel away from the case. Continue to loosen the bezel until you can remove it from the front of the case. www.emachines.com...
Closing the case Replacing the front bezel Replacing the side panel To replace the front bezel: If you disconnected the bezel cables when you removed the bezel, reconnect them to the system board. Align the latch pins on the bezel with the computer latch holes.
Align the notches on the new DIMM with the notches on the memory module bank and press the module firmly into the bank. The tabs on the sides of the memory module bank should snap in and secure the memory module automatically. www.emachines.com “Removing the side...
Replacing the system battery Warning There is a danger of explosion if the battery is incorrectly replaced. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries following the manufacturer’s instructions.
146. If you are replacing an existing drive, remove the two screws that secure the drive to the drive bay. If you are adding a new drive, go to www.emachines.com “Replacing the side “Removing the side “Removing the...
Page 158
Disconnect the power, data, and sound (if attached) cables from the back of the drive. Slide the drive out of the case toward the front. Slide the new drive into the drive bay from the front of the case.
There should be enough slack in the cables to allow you to lay the bezel on its side in front of the case. Remove the single screw holding the card reader in the drive bay. Disconnect the card reader’s USB cable from the system board. www.emachines.com “Removing the side “Removing the Screw...
Adding or replacing a hard drive Tips & Tricks You need a Phillips screwdriver to add or replace a hard drive. Slide the card reader out of the case. Slide the new card reader into the bay from the front of the case.
Page 161
Slide the old drive out of the bay. Slide the new drive into the drive bay. Use the four screws you removed previously to secure the hard drive to the hard drive bay. www.emachines.com Screw Step 9. If you are replacing an existing...
Replacing the rear fan Tips & Tricks You need a Phillips screwdriver to add or replace a rear fan. Slide the hard drive bay back into position, then secure it to the case using the screw you removed previously.
144. Disconnect all power supply cables from the system board and drives. Remove the four screws that secure the power supply to the case. Slide the power supply forward about one inch. www.emachines.com “Replacing the side “Removing the side Screws...
Tips & Tricks On some models, you may first need to remove the heat sink fan. Replacing the heat sink Tips & Tricks You need a Phillips screwdriver to add or replace the heat sink. Pull down on the side of the power supply nearest you, then remove the power supply from the bay.
147. To replace the front I/O panel: Remove the side panel by following the instructions in panel” on page 144. Disconnect the front bezel’s power and LED cables from the system board. www.emachines.com Screws “Replacing the side “Removing the side...
Page 166
Pry the front bezel away from the front of the case. Slide the front bezel’s power and LED cables through the hole in the front of the case, then remove the bezel completely. Replacing the front I/O panel...
Page 167
Rotate the I/O panel up until its screw hole aligns with the screw hole in the front of the case, then secure it to the case with the screw. Reconnect the I/O panel’s cables to the appropriate connectors on the system board. www.emachines.com Screw...
Adding or replacing an expansion card Insert the front bezel’s cables through the hole in the case behind the bezel, then snap the bezel back into place. Reconnect the front bezel’s power and LED cables to the appropriate connectors on the system board.
Remove each screw that secures an expansion card to the case, then remove each expansion card and place them in static-free bags for storage. Disconnect each drive data cable from the system board. Disconnect the card reader cable from the system board. www.emachines.com “Replacing the side “Removing the side...
Page 170
Caution The heat sink has Thermal Interface Material (TIM) on the bottom. Be careful not to damage this material when you remove the heat sink from the processor. If removing the heat sink also pulls the processor out of the processor socket, the processor could be damaged.
Page 171
Gradually and equally tighten each captive screw until each is firmly tightened. Do not over-tighten the screws. Connect the heat sink fan’s power connector to the system board. Reinstall each expansion card. Replace the side panel by following the instructions in panel” on page 147. www.emachines.com “Replacing the side...
Make sure that your hard drive is not full. ■ If an error message appears on the screen, write down the exact message. ■ The message may help eMachines Customer Care in diagnosing and fixing the problem. If you added or removed peripheral devices, review the installation ■...
Troubleshooting Add-in cards Audio Battery CD or DVD drives Troubleshooting topics are listed in alphabetical order. The computer does not recognize an add-in card Shut down and restart your computer. ■ Make sure that you have installed the required software. For more ■...
Make sure that the write-protection tab on the upper-right corner of the ■ diskette is down (unprotected). Delete unnecessary files on the diskette and try again. ■ Make sure that the diskette you are using is IBM-compatible. ■ www.emachines.com “Cleaning CDs or DVDs” on “Cleaning CDs or DVDs” on...
DVD drives File management Help and Support For more information about troubleshooting, click Start, then click Help and Support. Type the keyword System Restore in the Search box, then click the arrow. Try a different diskette. Occasionally diskettes are flawed and cannot be ■...
Contact your ISP technical support for help. Make sure that you do not have a problem with your modem. For more ■ information, “Modem (dial-up)” on page www.emachines.com “Using Disk Cleanup” on 134. NTER 174. or your setup poster to make...
Help and Support For more information about troubleshooting, click Start, then click Help and Support. Type the keyword troubleshooting connections in the Search box, then click the arrow. Keyboard You see an “Unable to locate host” message and are unable to browse the...
■ that were offered with the Media Center computer when you purchased it from eMachines. Other types of display devices, including retail TVs, may provide lower quality video. If you did not order a display device when you purchased your Media Center computer, a progressive scan display device with a VGA input is the best choice.
Page 180
Age of the TV—Newer TVs usually have more advanced features, ■ produce a better quality picture, and support higher screen resolutions. The Media Center video display will likely be better on a newer model TV. Type of TV (interlaced or progressive scan) ■...
Contact your telephone service to get the correct code to temporarily disable the service. Also make sure that the modem dialing properties are set correctly. www.emachines.com “Connecting the dial-up modem” on...
Page 182
Help and Support For more information about troubleshooting, click Start, then click Help and Support. Type the keyword dialing in the Search box, then click the arrow. To check the dialing properties: Click Start, then click Control Panel. The Control Panel window opens.
Page 183
If your Control Panel is in Category View, click Printers and Other Hardware. Click/Double-click the Phone and Modem Options icon, then click the Modems tab. Click the modem you want to adjust, then click Properties. www.emachines.com “Connecting the or your setup poster to make sure that the...
Monitor Tips & Tricks For more information, see “Adjusting the color depth” on page Help and Support For more information about troubleshooting, click Start, then click Help and Support. Type the keyword screen resolution in the Search box, then click the arrow.
Make sure that the router is plugged into a powered electrical outlet and ■ turned on. Most routers have lights that indicate they are working. For more information, see the documentation that came with your router. Make sure that all computers on your network have the same workgroup ■ name. www.emachines.com...
Passwords Power Printer Make sure that all computers are using the same Subnet Mask. ■ If you assigned IP addresses to the computers, make sure that all ■ computers have different IP addresses. For home networks, IP addresses should be 192.168.N.N where N is a number you assign between 0 and 254.
Page 187
You see a “Printer is out of paper” error message After adding paper, make sure that the printer is online. Most printers have an online/offline button that you need to press after adding paper. www.emachines.com Control Panel . The Control Panel window Printers and Faxes icon.
■ have installed it according to the instructions provided with it. If you did not purchase the hardware or software from eMachines, see the manufacturer’s documentation and technical support resources. If you have “how to” questions about using a program, see: ■...
(See “Before calling eMachines Customer Care” on page 181 before calling) If you have how-to questions about using your eMachines-supplied hardware or software, see the following resources: The printed or online documentation that came with your hardware or ■ software. In many cases, additional product information and online documentation for eMachines-supplied hardware can be found in our Web site's Documentation Library.
APPENDIX A Safety, Regulatory, and Legal Information • Important safety information • Regulatory compliance statements • Environmental information • Notices...
Your eMachines system is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that the safety instructions marked on the product and in the documentation are followed.
Regulatory compliance statements United States of America Caution Changes or modifications not expressly approved by eMachines could void the FCC compliance and negate your authority to operate the product. Warning This product contains chemicals, including lead, known to the State of California to cause cancer, birth defects or reproductive harm.
External television antenna grounding If an outside antenna or cable system is to be connected to your eMachines PC, make sure that the antenna or cable system is electrically grounded to provide some protection against voltage surges and static charges.
When your electrical or electronic equipment is no longer useful to you, “take it back” to your local or regional waste collection administration for recycling. ■ In some cases, your “end of life” product may be “traded in” for credit towards the purchase of new eMachines equipment. Call eMachines to see if this program is available in your area. ■...
Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited. www.emachines.com...
Index AC power connector accessing shared drives shared files shared folders accessories safety precautions accounts Internet activity indicators See indicators adding icons to desktop address e-mail application key arrow keys AU file audio audio in jack configuring jacks headphone jack...
Page 197
Internet Disk Cleanup Disk Defragmenter diskette troubleshooting diskette drive troubleshooting display changing resolution properties troubleshooting using screen saver documentation eMachines Web site help Help and Support online help documents creating opening printing saving domain name double-clicking downloading files dragging...
Page 198
Fast Ethernet faxes automatically canceling canceling configuring Fax installing Fax receiving and viewing retrying sending sending from program sending scanned image setting up cover page template troubleshooting files backing up copying cutting deleting downloading finding moving opening opening shared...
Page 199
PS/2 port right-clicking scroll wheel selecting screen objects troubleshooting USB port moving files files from old computer www.emachines.com folders Internet settings from old computer pointer screen objects settings from old computer MP3 file creating editing track information playing...
Page 200
Pad Lock indicator parallel port password pasting files and folders text and graphics memory cards peripheral devices playing audio CD audio file Media Player file multimedia files music CD Windows Media Player file Plug and Play devices...
Page 201
DVD/CD drive faxes files general guidelines hard drive Internet connection keyboard LCD panel memory memory card reader modem monitor www.emachines.com mouse network passwords power printer safety guidelines screen screen area screen resolution technical support telephone support Web site connection speed...
Page 202
WAN IP Address WAV file Web browser Web page Web site connecting to downloading files eMachines window close button closing maximize button menu bar minimize button title bar Windows clipboard Files and Settings Transfer...
Page 204
Utilisation du site Web eMachines ........
Page 205
Ajout d'une imprimante au réseau ........62 www.emachines.com...
Page 206
Chapitre 7 : Envoi et réception de télécopies ....... . . 63 Installation et configuration de Fax .
Page 207
Microsoft ........... . . 126 www.emachines.com...
Page 208
Mise à jour de Windows ..........132 BigFix .
Page 209
Support par téléphone ..........181 Avant d'appeler le service d'assistance clientèle eMachines ..181 Numéros de téléphone .
Page 210
CHAPITRE 1 Obtenir de l'aide • Nous vous remercions d'avoir acheté notre ordinateur ! • Utilisation du site Web eMachines • Obtenir de l'aide et un support technique • Utilisation de l'aide en ligne • Coordonnées • Certificat d'authenticité Microsoft.
à garder votre ordinateur en bon état de fonctionnement. eMachines est fidèle au principe suivant : les clients méritent la meilleure valeur possible. eMachines s'engage donc à offrir un service et un support technique de première classe, une qualité...
Servez-vous du Centre d'aide et de support pour toutes vos questions relatives à Windows et pour vous aider à découvrir et à utiliser rapidement plusieurs des fonctions de votre ordinateur eMachines. Pour accéder au Centre d'aide et de support, procédez comme suit : Cliquez sur Démarrer, puis sur Aide et support.
Pour accéder à l'aide de Media Center, procédez comme suit : Dans la fenêtre Media Center, déplacez la souris pour activer la barre d'outils de Media Center. La barre d'outils s'affiche en haut de la fenêtre. Cliquez sur l'icône Aide www.emachines.com dans la barre d'outils.
Utilisation de l'aide en ligne Utilisation de l'aide en ligne De nombreux programmes fournissent des informations en ligne pour vous permettre de faire des recherches par sujet ou d'apprendre à exécuter une tâche en utilisant le programme. Vous pouvez accéder à la plupart des rubriques d'aide en ligne en sélectionnant un sujet dans un menu d'Aide ou en cliquant...
L'étiquette se trouvant sur la face avant du boîtier de votre ordinateur comporte des informations qui permettent d'identifier votre modèle d'ordinateur et son numéro de série. Le service clientèle eMachines aura besoin de cette information lorsque vous appellerez pour obtenir de l'aide.
CHAPITRE 2 Faites connaissance avec votre ordinateur • Avant • Arrière • Branchement du modem commuté • Branchement à un modem câble ou DSL ou à un réseau Ethernet • Installation d'une imprimante, d'un scanneur, ou d'un autre périphérique • Configuration des prises audio...
Ports IEEE 1394 (en option) Ports USB (en option) Ressources d'aide et informations sur l'assistance clientèle eMachines Composant Icône Description Lecteur optique Utilisez ce lecteur pour écouter des CD audio, installer des jeux et des programmes, regarder des DVD et stocker de gros fichiers sur des disques enregistrables (selon le type de lecteur).
Ressources d'aide et Contient des informations permettant d'accéder à l'assistance clientèle informations sur eMachines. l'assistance clientèle eMachines Modèle et numéro Contient le modèle et le numéro de série. de série eMachines Avant ® ® ou i.Link « Installation d'une imprimante, d'un...
Branchez un clavier PS/2 dans ce port. Port série Branchez un périphérique série dans ce port. Pour de plus amples informations, consultez périphérique » à la page www.emachines.com Vis de serrage du couvercle du boîtier 1394 (en option) (réseau) Vis de serrage du couvercle du boîtier...
Branchement du modem commuté Avertissement Afin de réduire les risques d'incendie, nous vous recommandons d'utiliser uniquement un cordon d'alimentation pour télécommunications de calibre 26 AWG ou supérieur. Composant Icône Description Port parallèle Branchez un périphérique parallèle (tel qu'une imprimante) dans ce port. Pour de plus amples informations, consultez scanneur, ou d'un autre périphérique »...
à un modem câble ou DSL ou à un réseau Ethernet filaire 10/100. Branchement à un modem câble/DSL ou à un réseau Ethernet Insérez une extrémité du câble réseau dans la prise réseau l'arrière de l'ordinateur. Insérez l'autre extrémité du câble réseau dans une prise réseau. www.emachines.com située à...
Installation d'une imprimante, d'un scanneur, ou d'un autre périphérique Important Avant d'installer une imprimante, un scanneur ou un autre périphérique, consultez la documentation et les consignes d'installation du périphérique. Aide et support Pour de plus amples informations sur l'installation de périphériques, cliquez sur Démarrer, puis sur Aide et support.
Page 223
CHAPITRE 2: Faites connaissance avec votre ordinateur www.emachines.com...
Page 224
CHAPITRE 3 Utilisation de votre ordinateur • Travailler en toute sécurité • Démarrage de l'ordinateur • Mise hors tension de l'ordinateur • Redémarrage (réinitialisation) de l'ordinateur • Utilisation du clavier • Utilisation de la souris • Réglage du volume...
Utilisez une chaise confortable et ajustable, qui distribue uniformément ■ votre poids et détend votre corps. www.emachines.com Le haut de l'écran ne doit pas être plus haut que le niveau des yeux L'écran doit être perpendiculaire à votre...
Préparation de l'ordinateur et des accessoires Position devant l'ordinateur Éviter les douleurs et les blessures dues à la fatigue répétitive Positionnez votre chaise de sorte que le clavier soit au niveau de vos ■ coudes ou légèrement en dessous. Cette position vous permet de détendre vos épaules pendant que vous tapez.
115 V ou 230 V. Pour vérifier si le paramètre du système est approprié pour l'environnement, vérifiez le commutateur de tension. Pour régler le commutateur de tension : Utilisez un outil tel qu'un trombone ouvert pour basculer le commutateur ■ de tension dans la position appropriée. Commutateur de tension www.emachines.com...
Démarrage de l'ordinateur Important Votre ordinateur est équipé d'un ventilateur à vitesse variable. De plus, votre ordinateur utilise un processeur puissant qui produit de la chaleur. Le ventilateur système et le processeur peuvent, par moment, opérer à des vitesses différentes pour assurer un refroidissement adéquat du système.
à vérifier l'état du disque s'exécute automatiquement. Lorsque les vérifications sont terminées, Windows démarre. Boutons Boutons de lecture d'édition audio Touches de fonction Touches Windows www.emachines.com . La fenêtre Gestionnaire des tâches s'ouvre. Touches de navigation Boutons Internet Voyants Touches de direction Touche Clavier numérique...
Clavier standard Fonctionnalités du clavier Touches de fonction Touches Windows Le clavier comporte plusieurs types différents de touches et de boutons. Votre clavier comporte également des voyants d'état indiquant la fonctionnalité active. Fonctionnalité Icône Description Boutons d'édition Utilisez ces boutons pour copier, couper et coller.
Vous pouvez utiliser les boutons gauche et droit de la souris pour sélectionner des objets sur l'écran. Vous pouvez utiliser la roue de défilement de la souris pour faire défiler un document. Cette fonctionnalité n'est pas disponible dans tous les programmes. www.emachines.com ) est activé. Bouton droit Roue de défilement...
Conseils et astuces Pour plus d'informations sur le réglage de la vitesse du double clic, la vitesse du pointeur, la configuration main gauche ou main droite, ainsi que d'autres paramètres liés à la souris, consultez « Modification des paramètres de la souris »...
Page 233
CHAPITRE 3: Utilisation de votre ordinateur www.emachines.com...
Page 234
CHAPITRE 4 Utilisation de Windows XP • Utilisation du bureau Windows • Gestion des fichiers et des dossiers • Recherche de fichiers • Gestion des documents • Utilisation des raccourcis...
La Corbeille est l'endroit où sont stockés les fichiers, les dossiers et les programmes que vous supprimez. Vous devez vider la Corbeille pour les supprimer définitivement de votre ordinateur. Consultez « Suppression de fichiers et de dossiers » à la page 32 l'utilisation de la Corbeille. www.emachines.com pour obtenir des instructions sur...
Éléments du bureau Utilisation du menu Démarrer Aide et support Pour de plus amples informations sur le bureau Windows, cliquez sur Démarrer, puis sur Aide et support. Tapez les mots clés menu Démarrer de Windows dans le champ Rechercher et cliquez ensuite sur la flèche.
La plupart des fenêtres comportent les éléments suivants : Description La barre de titre est la barre horizontale qui affiche le titre de la fenêtre en haut de celle-ci. www.emachines.com Fermer Agrandir Réduire...
élément de fenêtre Aide et support Pour de plus amples informations sur le bureau Windows, cliquez sur Démarrer, puis sur Aide et support. Tapez le mot clé fenêtre dans le champ Rechercher et cliquez ensuite sur la flèche. Gestion des fichiers et des dossiers...
Les fichiers sont fort similaires à des documents imprimés—lettres, feuilles de calcul et photos—que vous stockez sur votre ordinateur. En fait, toutes les informations d'un ordinateur sont stockées dans des fichiers. Dossiers Fichiers www.emachines.com Lecteur de disques...
Aide et support Pour de plus amples informations sur le bureau Windows, cliquez sur Démarrer, puis sur Aide et support. Tapez les mots clés création de fichiers et de dossiers dans le champ Rechercher et cliquez ensuite sur la flèche.
Si vous ne trouvez pas le fichier que vous voulez supprimer, consultez « Recherche de fichiers » à la page Cliquez sur Fichier, puis sur Supprimer. Windows déplace les fichiers et les dossiers vers la Corbeille. www.emachines.com « Utilisation des...
Page 242
Mise en garde Vider la Corbeille supprime définitivement les fichiers ou les dossiers qui s'y trouvent. Ces fichiers ou dossiers sont alors irrécupérables. Aide et support Pour de plus amples informations sur le bureau Windows, cliquez sur Démarrer, puis sur Aide et support. Tapez les mots clés vider la corbeille dans le champ...
Si vous saisissez le nom entier, la recherche affichera tous les ■ fichiers/dossiers portant ce nom. Si vous saisissez une partie du nom, la recherche affichera tous les ■ fichiers/dossiers dont le nom contient les lettres que vous avez saisies. www.emachines.com...
Aide et support Pour de plus amples informations sur le bureau Windows, cliquez sur Démarrer, puis sur Aide et support. Tapez le mot clé recherche dans le champ Rechercher et cliquez ensuite sur la flèche. Parcourir les fichiers et les dossiers Cliquez sur Rechercher.
Page 245
Si vous ne pouvez voir le contenu d'un lecteur ou d'un dossier, cliquez sur Afficher le contenu de ce lecteur ou Afficher le contenu de ce dossier. Double-cliquez sur les dossiers et leurs sous-dossiers jusqu'à ce que vous trouviez le fichier ou le dossier désiré. www.emachines.com...
Gestion des documents Création d'un nouveau document Les documents informatiques comprennent des fichiers de traitement de texte, des fichiers de feuille de calcul ou d'autres fichiers similaires. Les méthodes de base pour créer, enregistrer, ouvrir et imprimer un document s'appliquent à la plupart de ces types de fichiers.
Pour afficher, modifier ou imprimer un document existant, vous devez tout d'abord l'ouvrir. Ouvrez le document dans le programme dans lequel il a été créé. Pour ouvrir un document : Démarrez le programme. Cliquez sur Fichier, puis cliquez sur Ouvrir. www.emachines.com...
Aide et support Pour de plus amples informations sur le bureau Windows, cliquez sur Démarrer, puis sur Aide et support. Tapez les mots clés ouverture de fichiers dans le champ Rechercher et cliquez ensuite sur la flèche. Impression d'un document...
E Fermer la fenêtre active ou le Appuyez sur A programme Basculer vers un fichier, un dossier ou un Appuyez sur A programme ouvert différent www.emachines.com + C. + X. + V. NTRÉE + F4. UPPR...
Page 250
CHAPITRE 5 Utilisation d'Internet • Découvrir Internet • Configuration d'un compte Internet • Utilisation du Web • Utilisation de la messagerie...
électroniques via Internet. Microsoft Outlook ou Outlook Express est déjà installé sur votre ordinateur. Pour obtenir de plus amples informations, consultez « Utilisation de la messagerie » à la page www.emachines.com « Utilisation du Web » à la...
Configuration d'un compte Internet Accès à votre compte Internet Aide et support Pour des informations générales sur l'utilisation des comptes Internet, cliquez sur Démarrer, puis sur Aide et support. Tapez les mots clés fournisseur de services Internet dans le champ Rechercher et cliquez ensuite sur la flèche.
Pour visiter un autre site Web, tapez l'adresse (appelée URL pour « Universal Resource Locator ») dans la barre d'adresse du navigateur (exemple : www.emachines.com) et cliquez ensuite sur OK. - OU - Dans la page Web affichée, cliquez sur un lien vers un site Web.
Aide et support Pour des informations générales sur l'utilisation des comptes Internet, cliquez sur Démarrer, puis sur Aide et support. Tapez les mots clés connexion à un site Web dans le champ Rechercher et cliquez ensuite sur la flèche.
À. Saisissez l'objet de votre message dans la zone Objet. Tapez le message électronique. Lorsque vous avez terminé, cliquez sur Envoyer. Votre message est envoyé à l'adresse électronique spécifiée via Internet. www.emachines.com Nom de domaine Internet...
Consultation du courrier électronique Conseils et astuces Pour protéger votre ordinateur contre les virus, vérifiez les pièces jointes aux messages électroniques en utilisant McAfee SecurityCenter. Pour obtenir de plus amples informations, consultez « Protection antivirus de votre ordinateur » à la page 111.
Page 258
CHAPITRE 6 Mise en réseau de votre ordinateur • Introduction à la mise en réseau • Création d'un réseau Ethernet • Partage des ressources • Utilisation du réseau • Ajout d'une imprimante au réseau...
Le moyen le plus courant de configurer un réseau Ethernet consiste à utiliser le protocole DHCP (Dynamic Host Control Protocol) avec un routeur. Une configuration de réseau DHCP utilise un routeur pour attribuer automatiquement une adresse IP à chaque ordinateur ou périphérique du réseau. www.emachines.com...
Page 260
Conseils et astuces Pour que votre réseau Ethernet filaire puisse accéder à un réseau Ethernet sans fil, connectez un point d'accès au routeur ou utilisez un routeur doté d'un point d'accès intégré, tel que le routeur point d'accès sans fil Linksys avec commutateur 4 ports.
Pour tester la connexion, connectez-vous à Internet à l'aide de votre configuration actuelle. Si la connexion ne fonctionne pas, contactez votre fournisseur de services Internet. www.emachines.com « Ajout ou remplacement d'une carte...
Attribution d'un nom aux ordinateurs et au groupe de travail Important Tous les ordinateurs du réseau doivent posséder un nom unique et le même groupe de travail. Configuration du protocole TCP/IP Pour identifier cet ordinateur sur le réseau, procédez comme suit : Cliquez sur Démarrer puis sur Panneau de configuration.
Page 263
Cochez la case Protocole Internet (TCP/IP) dans la liste Cette connexion utilise les éléments suivants. Si vous ne voyez pas TCP/IP, faites glisser la barre de défilement pour afficher d'autres choix. Cliquez sur Propriétés. La boîte de dialogue Propriétés du protocole Internet (TCP/IP) s'ouvre. www.emachines.com...
Configuration d'un réseau Ethernet Important Les câbles de catégorie 5 sont disponibles sous deux types différents : les câbles directs, utilisés pour connecter des ordinateurs à un routeur, et les câbles croisés, utilisés pour connecter deux ordinateurs. Pour déterminer de quel type de câble vous disposez, tenez les deux extrémités...
Page 265
Répétez l'étape 3 pour chaque ordinateur du réseau. Pour une connexion Internet, branchez une extrémité d'un câble direct dans le port WAN du routeur et l'autre extrémité dans la prise Ethernet du modem câble ou DSL. www.emachines.com...
Configuration de votre routeur Important Les informations de configuration suivantes s'appliquent aux routeurs ® Linksys EtherFast câble/DSL. Pour toute autre marque ou modèle de routeur, reportez-vous à la documentation du fabricant, qui peut accompagner le routeur ou être disponible sur le site Web du fabricant.
Partage et sécurité. La boîte de dialogue des propriétés du dossier s'ouvre. Si vous partagez un lecteur, tout le contenu de ce lecteur sera accessible à quiconque sur le réseau. Si vous partagez un dossier, seul le contenu de ce dossier sera accessible à quiconque sur le réseau. www.emachines.com...
Page 268
Cliquez sur l'onglet Partage. Si c'est la première fois que vous partagez un lecteur ou un dossier, cliquez sur Assistant Configuration du réseau pour activer l'accès à distance, puis suivez les instructions qui s'affichent à l'écran. - OU - Si vous avez précédemment activé...
Double-cliquez sur le nom de votre groupe de travail. Le nom de tous les ordinateurs de votre groupe de travail est répertorié. Double-cliquez sur le nom de l'ordinateur contenant le lecteur ou le dossier que vous souhaitez afficher. Tous les lecteurs et dossiers partagés de cet ordinateur sont répertoriés. www.emachines.com...
Mappage d'un lecteur réseau Ouverture de fichiers sur le réseau Copie de fichiers sur le réseau Une fois qu'un lecteur ou dossier d'un ordinateur est mappé en tant que lecteur sur un autre ordinateur, le contenu du lecteur ou dossier est accessible comme si le lecteur était connecté...
USB ou d'un port parallèle. Pour de plus amples informations, consultez les instructions fournies avec votre point d'accès. Utilisez une imprimante dotée de capacités réseau sans fil incorporées. ■ Utilisez un serveur d'impression sans fil. ■ www.emachines.com « Partage de lecteurs et d'imprimantes » à la...
Page 272
CHAPITRE 7 Envoi et réception de télécopies • Installation et configuration de Fax • Envoi d'une télécopie simple • Configuration du modèle de page de garde • Envoi de télécopies à partir de programmes • Télécopie d'un document numérisé • Réception et affichage d'une télécopie •...
Configuration de télécopie s'ouvre la première fois que vous tentez d'envoyer une télécopie. Pour configurer Microsoft Fax, procédez comme suit : Cliquez sur Démarrer, Tous les programmes, Accessoires, Communications, Fax, puis sur Console de télécopie. L'Assistant Configuration de télécopie s'ouvre. www.emachines.com...
Page 274
Important Certains télécopieurs ne peuvent pas utiliser des caractères spéciaux tels que des traits d'union. Nous vous suggérons d'utiliser des espaces au lieu de traits d'union dans les numéros de téléphone et de télécopie. Dans l'écran Bienvenue !, cliquez sur Suivant. L'écran Informations sur l'expéditeur s'ouvre.
Saisissez le nom et le numéro de télécopie du destinataire de la télécopie. Si vous devez utiliser un indicatif régional pour le destinataire, cliquez sur Utiliser les règles de numérotation pour saisir les dix chiffres du numéro de télécopie. www.emachines.com l'étape 7. L'écran Options...
Configuration du modèle de page de garde Si vous souhaitez envoyer votre télécopie à plusieurs destinataires, cliquez sur Ajouter et saisissez le nom et le numéro de télécopie du destinataire suivant. Lorsque vous avez ajouté tous les destinataires, cliquez sur Suivant.
Numérisez le document à l'aide du programme fourni avec le scanneur. Alors que le fichier numérisé est ouvert, cliquez sur Fichier, puis sur Imprimer. La boîte de dialogue Imprimer s'ouvre. Cliquez sur le bouton fléché pour ouvrir la liste Nom, puis cliquez sur l'imprimante Fax. www.emachines.com « Envoi d'une...
Réception et affichage d'une télécopie Annulation d'une télécopie Réessayer automatiquement d'envoyer une télécopie Important Fax est automatiquement configuré pour réessayer trois fois à dix minutes d'intervalle. Cliquez sur Imprimer. L'Assistant Envoi de télécopie s'ouvre. Exécutez l'Assistant en suivant les instructions de la section télécopie simple »...
Propriétés de télécopie s'ouvre. Cliquez sur l'onglet Périphériques, puis sur Propriétés. La boîte de dialogue Modem s'ouvre. Cliquez sur l'onglet Nettoyage. Cochez la case Supprimer automatiquement les télécopies en échec après et indiquez le nombre de jours. Cliquez sur OK. www.emachines.com...
Page 280
CHAPITRE 8 Utilisation de lecteurs et de ports • Utilisation du lecteur de carte mémoire • Utilisation du lecteur de CD ou de • Utilisation d'un deuxième moniteur • Visualisation de l'affichage sur un téléviseur • Utilisation de Windows Media Center •...
IBM Microdrive Chaque logement se voit attribuer une lettre de lecteur différente (par exemple, lecteurs E: et F:) de manière à pouvoir transférer les données d'un type de carte mémoire vers un autre. www.emachines.com Logements du lecteur de carte mémoire Logement...
Utilisation d'une carte mémoire Mise en garde Pour éviter d'endommager les cartes mémoire ou de causer des erreurs pendant leur utilisation, insérez une seule carte mémoire dans un logement à la fois. Mise en garde Ne retirez pas la carte mémoire ou n'éteignez pas l'ordinateur lorsque le...
Appuyez sur le bouton d'éjection du lecteur CD ou DVD. Placez le disque sur le plateau avec l'étiquette vers le haut. Appuyez sur le bouton d'éjection pour fermer le plateau. www.emachines.com Utilisez votre lecteur pour... Installation de programmes, lecture de CD audio, lecture de DVD, accès à...
Utilisation d'un deuxième moniteur Important Les boîtes de dialogue illustrées dans cette section sont des exemples uniquement et leur apparence peut être différente des boîtes de dialogue de votre ordinateur. Conseils et astuces Pour connaître l'emplacement du port VGA sur votre ordinateur, consultez l'affiche de configuration ou «...
Cliquez sur Démarrer puis sur Panneau de configuration. La fenêtre Panneau de configuration s'ouvre. Si votre Panneau de configuration est affiché par catégories, cliquez sur Apparence et thèmes. Cliquez/double-cliquez sur l'icône Affichage. La boîte de dialogue Propriétés de l'affichage s'ouvre. Cliquez sur l'onglet Paramètres. www.emachines.com...
Page 286
Important Si les boutons Activer TV et TV sont grisés, votre ordinateur n'a pas détecté le téléviseur. Assurez-vous que le téléviseur est correctement branché et allumé. Cliquez sur Avancé. La boîte de dialogue Propriétés des moniteurs multiples s'ouvre. Cliquez sur l'onglet Affichages.
Modification des paramètres du téléviseur Pour modifier les paramètres du téléviseur : Cliquez sur TV dans l'onglet Affichages de la boîte de dialogue Propriétés des moniteurs multiples. La boîte de dialogue Propriétés du téléviseur s'ouvre. Modifiez les paramètres et cliquez ensuite sur OK. www.emachines.com...
Utilisation de Windows Media Center Boutons de commande numérique/boutons de saisie de données Si votre ordinateur a été livré avec le logiciel Windows Media Center et une télécommande Media Center (optionnelle), vous pouvez utiliser cette télécommande pour regarder la télévision, des vidéos et des DVD, pour écouter de la musique et pour visualiser des photos.
La boîte de dialogue Données du guide s'ouvre. Sélectionnez Oui et appuyez ensuite sur OK. Media Center télécharge les mises à jour du guide des programmes. www.emachines.com pour effectuer une sélection. de la télécommande. Le logiciel de la télécommande. Media Center...
Utilisation du multimédia Réglage du volume Aide et support Pour plus d'informations sur le réglage du volume, cliquez sur Démarrer puis sur Aide et support. Tapez les mots clés réglage du volume dans le champ Rechercher et cliquez ensuite sur la flèche.
Page 291
Faites glisser les curseurs de volume et de balance du périphérique que vous voulez ajuster. Pour plus d'informations sur les commandes de volume, cliquez sur Aide dans la fenêtre. Cliquez sur x dans le coin supérieur droit de la fenêtre pour la fermer. www.emachines.com...
Écouter de la musique et regarder des films Lecture de fichier audio WAV Lecture de fichiers audio et vidéo Le Magnétophone est un petit programme Windows qui vous permet d'enregistrer et de lire des fichiers WAV. WAV est le format de fichier audio le plus couramment utilisé...
Utilisez le Lecteur Windows Media pour écouter des CD ou regarder des DVD. Pour plus d'informations sur l'utilisation du Lecteur Windows Media, cliquez sur Aide. www.emachines.com Informations sur les fichiers vidéo (lecture) et arrêtez la lecture du fichier en Écran...
Page 294
Raccourci Insérez un CD ou un DVD Le Lecteur Windows Media s'ouvre et lit le disque. Pour lire un CD ou un DVD : Assurez-vous que les haut-parleurs sont allumés ou les écouteurs branchés, et que le volume est en fonction.
WAV. WAV est le format de fichier audio le plus couramment utilisé pour les sons du système Windows. Pour obtenir des informations sur la lecture des fichiers WAV, consultez WAV » à la page www.emachines.com (lecture). Le DVD « Lecture de fichier audio...
Page 296
Aide et support Cliquez sur Démarrer puis sur Aide et support pour obtenir plus d'informations sur la création et la lecture d'un enregistrement audio. Tapez les mots clés enregistrement audio ou lecture audio dans le champ Rechercher et cliquez ensuite sur la flèche.
Page 297
Cliquez sur l'onglet Outils, Options puis sur l'onglet Extraire de la musique. Cliquez sur la flèche pour ouvrir la liste Format, puis cliquez sur mp3 ou sur Audio Windows Media. Pour plus d'informations sur les différences entre ces deux types de fichiers, cliquez sur Informations sur les formats MP3. www.emachines.com...
Création d'une bibliothèque musicale Mise en garde Les fichiers WMA et MP3 peuvent être endommagés pendant le processus de téléchargement. Si vous ne pouvez écouter ou utiliser un fichier téléchargé, essayez de le télécharger à nouveau. Modifier les informations des pistes Création de fichiers audio et de bibliothèques musicales...
Windows Movie Maker, consultez l'aide en ligne. Un logiciel de montage vidéo additionnel peut être installé sur votre ordinateur. Pour plus d'informations sur l'utilisation de ce logiciel, y compris les fonctionnalités supplémentaires non disponibles dans Windows Media Maker, consultez l'aide en ligne du logiciel. www.emachines.com...
Transfert d'une vidéo vers l'ordinateur Pour transférer une vidéo vers votre ordinateur : Branchez la caméra vidéo sur l'ordinateur en suivant les instructions du fabricant. Si une boîte de dialogue contenant une liste des programmes de montage vidéo s'affiche, cliquez sur Windows Movie Maker. Windows Movie Maker s'ouvre.
■ un site Web et la partager avec vos amis et votre famille. Cliquez sur Envoyer vers une caméra DV pour lire la vidéo sur votre ■ caméra vidéo, l'enregistrer sur une bande et la regarder sur votre téléviseur. www.emachines.com...
Création de CD musicaux et de DVD vidéo Important Certains CD comportent un logiciel de protection contre la copie. Vous ne pourrez pas créer de fichiers MP3, WAV ou WMA à partir de ces CD et vous ne pourrez peut-être pas écouter ces CD sur votre ordinateur.
Pour créer un DVD vidéo avec Windows Media Center : Insérez un disque DVD-R ou DVD-RW vierge accessible en écriture dans votre graveur de DVD. Appuyez sur le bouton Démarrer démarre. Cliquez sur Autres programmes, puis sur Créer un CD/DVD. www.emachines.com de la télécommande. Media Center...
Fonctionnalités avancées des logiciels multimédias Enregistrement audio Cliquez sur DVD vidéo puis sur OK. Suivez les invites à l'écran pour graver le DVD. Pour plus d'informations, cliquez sur l'icône Aide de Media Center. Fonctionnalités avancées du Lecteur Windows Media Vous pouvez utiliser le Lecteur Windows Media pour transférer des fichiers WMA...
Page 305
Cliquez sur Fichier, puis cliquez sur Ouvrir. La boîte de dialogue Ouvrir s'ouvre. Cliquez sur le fichier que vous voulez lire et cliquez ensuite sur Ouvrir. Lisez le fichier en cliquant sur en cliquant sur (arrêter). www.emachines.com Enregistrer Lecture Arrête (arrêter). (lecture) et arrêtez la lecture du fichier...
Page 306
CHAPITRE 9 Personnalisation de votre ordinateur • Réglage des paramètres de l'écran et du bureau • Modification des paramètres de la souris • Changement des paramètres d'économie d'énergie • Installation d'un onduleur...
Panneau de configuration s'ouvre. Si votre Panneau de configuration est affiché par catégories, cliquez sur Apparence et thèmes. Cliquez/double-cliquez sur l'icône Affichage. La boîte de dialogue Propriétés de l'affichage s'ouvre. Cliquez sur l'onglet Paramètres. Ordinateur à moniteur unique www.emachines.com Ordinateur à deux moniteurs...
Aide et support Pour de plus amples informations sur la modification du schéma d'alimentation, cliquez sur Démarrer, puis sur Aide et support. Tapez les mots clés modification des paramètres d'affichage dans le champ Rechercher, puis cliquez sur la flèche.
Modifiez les paramètres de couleur ou de police de l'élément. Cliquez sur OK, puis sur l'onglet Thèmes. Cliquez sur Enregistrer sous, saisissez le nom du nouveau thème, puis cliquez sur OK deux fois. Les nouvelles couleurs s'affichent sur le bureau. www.emachines.com...
Modification de l'arrière-plan du bureau Aide et support Pour de plus amples informations sur la modification du schéma d'alimentation, cliquez sur Démarrer, puis sur Aide et support. Tapez les mots clés modification de l'arrière-plan du bureau dans le champ Rechercher, puis cliquez sur la flèche.
À la reprise, afficher l'écran d'accueil. Si vous souhaitez modifier la durée devant s'écouler avant que ■ l'écran de veille soit activé, cliquez sur les flèches Haut ou Bas situées en regard du champ Attente. Cliquez sur OK. www.emachines.com...
Utilisation d'un bureau étendu Aide et support Pour de plus amples informations sur la modification du schéma d'alimentation, cliquez sur Démarrer, puis sur Aide et support. Tapez les mots clés plusieurs moniteurs dans le champ Rechercher, puis cliquez sur la flèche.
Imprimantes et autres périphériques. Cliquez/double-cliquez sur l'icône Souris. La boîte de dialogue Propriétés de la souris s'ouvre. Cliquez sur un des onglets pour modifier les paramètres de la souris. Cliquez sur OK pour enregistrer les modifications. www.emachines.com...
Changement des paramètres d'économie d'énergie Modification du schéma d'alimentation Aide et support Pour de plus amples informations sur la modification du schéma d'alimentation, cliquez sur Démarrer, puis sur Aide et support. Tapez les mots clés schéma d'alimentation dans le champ Rechercher, puis cliquez sur la flèche.
(RAM) sur le disque dur et éteint ensuite complètement l'ordinateur. La prochaine fois que vous allumerez votre ordinateur, il lira les informations en mémoire depuis le disque dur et ouvrira les programmes et documents qui étaient ouverts lors de l'activation du mode Veille prolongée. www.emachines.com...
Page 316
Aide et support Pour de plus amples informations sur la modification du schéma d'alimentation, cliquez sur Démarrer, puis sur Aide et support. Tapez les mots clés veille prolongée dans le champ Rechercher, puis cliquez sur la flèche. Changement des paramètres d'économie d'énergie Pour activer le mode Veille prolongée, procédez comme suit :...
Cliquez sur l'onglet Onduleur. Cliquez sur Sélectionner. La boîte de dialogue Sélection de l'onduleur s'ouvre. Cliquez sur le fabricant et sur le modèle de l'onduleur, puis sur le port série auquel l'onduleur est connecté. Cliquez sur Terminer, puis sur OK. www.emachines.com...
Page 318
CHAPITRE 10 Protection de votre ordinateur • Sécurité du matériel • Sécurité des données • Mises à jour de sécurité...
Si vous oubliez votre mot de passe, vous devrez retourner votre ordinateur à eMachines pour nous permettre de le réinitialiser. À propos des comptes d'utilisateur Windows XP Vous pouvez peut-être remplacer votre ordinateur en appelant votre assureur, mais les informations stockées sur votre ordinateur, elles, sont irremplaçables.
Aide et support Cliquez sur Démarrer, puis cliquez sur Aide et support pour plus d'informations sur les comptes d'utilisateur Windows XP. Tapez les mots clés comptes d'utilisateur dans le champ Rechercher, puis cliquez sur la flèche. Protection antivirus de votre ordinateur Aide et support Cliquez sur Démarrer, puis cliquez sur...
CHAPITRE 10: Protection de votre ordinateur Utilisation de McAfee SecurityCenter McAfee SecurityCenter est préinstallé sur votre nouvel ordinateur eMachines. McAfee SecurityCenter comprend les composants suivants : McAfee VirusScan, un service d'abonnement antivirus. Vous pouvez utiliser ■ VirusScan pour protéger votre ordinateur contre les virus, les vers, les chevaux de Troie et les attaques hybrides.
Page 322
Démarrage de McAfee SecurityCenter Pour démarrer McAfee SecurityCenter : Cliquez sur Démarrer, Tous les programmes, McAfee, puis cliquez sur ■ McAfee Security Center. McAfee SecurityCenter s'ouvre. Recherche et suppression des virus Pour vérifier s'il n'y pas de virus : Démarrez McAfee SecurityCenter.
Page 323
Cliquez sur Mettre à jour. L'Assistant Mise à jour de McAfee SecurityCenter s'ouvre. Cliquez sur Vérifier maintenant. Lorsqu'il est temps de prolonger votre abonnement, une alerte s'affiche à l'écran. Cliquez sur Renouveler mon abonnement pour prolonger votre abonnement et continuer à mettre à jour McAfee SecurityCenter. www.emachines.com...
Utilisation de Windows XP Security Center Windows Security Center protège votre ordinateur grâce à : un pare-feu, ■ des mises à jour automatiques de Windows, ■ un logiciel de protection antivirus tiers, ■ des options de sécurité dans Internet Explorer.
Ces mises à jour comprennent des mises à jour de sécurité. Custom—Cliquez sur Custom pour télécharger des mises à jour de haute ■ priorité, des mises à jour de logiciels Windows et des mises à jour de pilotes. Ces mises à jour comprennent des mises à jour de sécurité. www.emachines.com...
Page 326
Windows XP Security Center Utilisez Windows XP Security Center pour programmer des mises à jour automatiques. Windows peut rechercher régulièrement les toutes dernières mises à jour importantes pour votre ordinateur et les installer automatiquement. Pour programmer des mises à jour automatiques : Cliquez sur Démarrer, Panneau de configuration, puis double-cliquez...
à jour depuis les sites BigFix sur Internet. Dès que BigFix détecte un problème, il vous avertit en faisant clignoter l'icône bleue de la barre des tâches. Pour résoudre le problème, cliquez sur l'icône pour ouvrir BigFix. www.emachines.com...
Page 328
CHAPITRE 11 Protection et récupération de vos fichiers et logiciels • Options de récupération du système • Copie des fichiers de récupération des pilotes et des applications • Récupération du système...
également impliquer la réinstallation d'une partie ou de l'ensemble des logiciels de l'ordinateur (également appelée récupération ou restauration du système). eMachines fournit tout ce dont vous avez besoin pour récupérer votre système dans la plupart des situations.
Création de disques de récupération Important Si vous effectuez l'enregistrement sur CD, assurez-vous qu'il s'agit de disques CD-R et non de disques CD-RW. Si vous effectuez l'enregistrement sur un DVD, assurez-vous qu'il s'agit d'un disque DVD-R ou DVD+R et non d'un disque DVD-RW ou DVD+RW.
Important Utilisez un marqueur indélébile pour écrire la mention « Récupération des pilotes et des applications eMachines » sur chaque disque. Utilisez le marqueur indélébile pour étiqueter chaque disque 1 sur x, 2 sur x, 3 sur x, etc., au fur et à...
Page 332
Conseils et astuces Stockez votre image (ISO) de récupération dans un dossier qui indique l'ordinateur auquel les fichiers appartiennent. Par exemple, stockez les fichiers d'un ordinateur eMachines T2862 dans un dossier intitulé Récupération applications eM T2862. Création de disques à partir de fichiers de récupération stockés sur un réseau...
Si votre disque dur est en panne et qu'il est impossible de récupérer les logiciels à partir du disque dur, contactez le service clientèle de eMachines pour obtenir de l'aide. Moyennant paiement, le service clientèle peut vous fournir une série de disques de récupération pour restaurer votre ordinateur.
Récupération de fichiers et de logiciels spécifiques Vous pouvez effectuer une récupération partielle en restaurant des fichiers spécifiques, comme des pilotes de périphérique ou la plupart des logiciels préinstallés. Pour récupérer un logiciel qui n'était pas préinstallé sur votre système, vous devez suivre les instructions d'installation de ce logiciel.
Page 335
CHAPITRE 11: Protection et récupération de vos fichiers et logiciels Récupération du système à l'aide de l'option Restauration du système de Microsoft Avant d'utiliser l'option de récupération du système de eMachines, vous devriez essayer l'option Restauration du système de Microsoft afin de déterminer si la restauration du système vers un état précédent est possible.
Cliquez sur Suivant, puis suivez les instructions affichées à l'écran pour terminer la restauration. Si l'option Restauration du système de Microsoft ne résout pas le problème, redémarrez l'option de récupération du système de eMachines. Consultez disque dur » à la page 127 pour obtenir des instructions.
Page 337
Restauration du système s'ouvre. Cliquez sur Redémarrer. L'ordinateur redémarre et l'installation et la configuration de Windows se poursuivent. Reconnectez votre câble Internet et tous les périphériques USB. La procédure est terminée. www.emachines.com...
Page 338
CHAPITRE 12 Maintenance de votre ordinateur • Entretien de votre ordinateur • Mise à jour de Windows • BigFix • Gestion de l'espace disque • Déplacement depuis votre ancien ordinateur...
Un aérosol d'air comportant une rallonge étroite ressemblant à une paille ■ Des cotons-tiges ■ Un kit de nettoyage de lecteur de CD ou de DVD ■ www.emachines.com Mensuel En cas de besoin Voir... page 111 page 116 page 130...
Page 340
Avertissement Lorsque vous éteignez votre ordinateur, l'alimentation s'arrête, mais un faible courant électrique traverse toujours l'ordinateur. Pour éviter d'éventuelles blessures par décharge électrique, débranchez le cordon d'alimentation et le câble du modem des prises murales. Mise en garde Un écran ACL d'ordinateur est composé...
Pour résoudre le problème, cliquez sur l'icône pour ouvrir BigFix. * La disponibilité du programme varie en fonction du pays ou de la région. www.emachines.com 116. Tous les programmes , puis sur...
Gestion de l'espace disque Vérification de l'espace disque Pour démarrer BigFix, procédez comme suit : Cliquez sur Démarrer, Tous les programmes, Accessoires, Outils ■ système, puis sur BigFix. Pour en savoir davantage sur l'utilisation de BigFix, procédez comme suit : Depuis le programme BigFix, cliquez sur Aide, puis sur Didacticiel.
Le programme Vérification des erreurs examine le disque dur pour y déceler des défauts matériels et des problèmes de fichier et de dossier. Ce programme corrige les problèmes de fichier et de dossier et marque les zones défectueuses du disque dur pour que Windows ne les utilise pas. www.emachines.com...
Page 344
Aide et support Pour de plus amples informations sur Windows Update, cliquez sur Démarrer puis sur Aide et support. Tapez les mots clés clé recherche d'erreurs sur le disque dur dans le champ Rechercher, puis cliquez sur la flèche.
Cliquez sur Défragmenter maintenant. Si le défragmenteur de disque ne démarre pas automatiquement, cliquez sur Défragmenter. Le défragmenteur de disque indique la progression sur l'affichage de l'ordinateur. Une fois terminé, le défragmenteur de disque demande si vous voulez quitter le programme. www.emachines.com...
Aide et support Pour de plus amples informations sur Windows Update, cliquez sur Démarrer puis sur Aide et support. Tapez le mot clé défragmentation dans le champ Rechercher, puis cliquez sur la flèche. Sauvegarde de fichiers Aide et support Pour de plus amples informations sur Windows Update, cliquez sur Démarrer...
Pour rechercher des fichiers dans le dossier Mes documents, procédez comme suit : Sous Windows XP, cliquez sur Démarrer, puis sur Mes documents. La fenêtre Mes documents s'ouvre et affiche bon nombre de vos fichiers de données personnels. Passez à www.emachines.com l'étape...
Page 348
Aide et support Pour de plus amples informations sur Windows Update, cliquez sur Démarrer puis sur Aide et support. Tapez les mots clés recherche de fichiers dans le champ Rechercher et cliquez ensuite sur la flèche. - OU - Sous Windows 98, Windows Me ou Windows 2000, double-cliquez sur l'icône Poste de travail sur le bureau.
Il est possible que Windows dispose d'une prise en charge intégrée pour les imprimantes, scanneurs et autres périphériques anciens. Cela signifie que vous n'avez pas besoin de logiciels supplémentaires. Cependant, les périphériques plus récents nécessitent souvent les disques ou disquettes d'installation d'origine du logiciel. www.emachines.com...
Aide et support Pour de plus amples informations sur Windows Update, cliquez sur Démarrer puis sur Aide et support. Tapez les mots clés Restauration du système dans le champ Rechercher et cliquez ensuite sur la flèche. Aide et support Pour de plus amples informations sur Windows Update, cliquez sur Démarrer...
Page 351
Web de l'éditeur comporte des mises à jour importantes du programme. Si vous rencontrez des difficultés après avoir réinstallé vos anciens programmes, vous pouvez restaurer les anciens paramètres de l'ordinateur à l'aide de la fonctionnalité Restauration du système. www.emachines.com...
Page 352
CHAPITRE 13 Ajout et remplacement de composants • Prévention de décharge d'électricité statique • Ouverture du boîtier • Fermeture du boîtier • Installation de la mémoire • Remplacement de la batterie système • Ajout ou remplacement d'un lecteur de CD ou de DVD •...
Pour démonter le panneau latéral, procédez comme suit : Suivez les instructions de « Prévention de décharge d'électricité statique » à la page 144. Arrêtez l'ordinateur, puis débranchez le cordon d'alimentation et les câbles du modem, du réseau et de tous les périphériques. www.emachines.com...
Page 354
Appuyez sur l'interrupteur pour purger l'ordinateur de toute électricité restante. Enlevez les deux vis à oreilles du couvercle du panneau latéral, glissez le panneau latéral vers l'arrière de l'ordinateur, puis soulevez le panneau en l'écartant de l'ordinateur. Ouverture du boîtier...
Pour démonter le cadre avant, procédez comme suit : Placez l'ordinateur afin de pouvoir agripper le bord avant du cadre, puis ■ tirez le cadre en l'écartant du boîtier. Continuez à desserrer le cadre jusqu'à ce que vous puissiez l'enlever du boîtier. www.emachines.com...
Fermeture du boîtier Remontage du cadre avant Remontage du panneau latéral Pour remonter le cadre avant, procédez comme suit : Si vous avez débranché les câbles du cadre lors de son démontage, rebranchez-les à la carte système. Alignez les goupilles du cadre avec les trous correspondants de l'ordinateur.
- OU - Si vous ajoutez une barrette DIMM à un connecteur de module de mémoire vide, écartez soigneusement les onglets en plastique des côtés du connecteur de module de mémoire. www.emachines.com 144.
Remplacement de la batterie système Avertissement Un danger d'explosion existe si la batterie n'est pas remplacée correctement. Remplacez la batterie uniquement par une autre identique ou équivalente recommandée par le fabricant. Jetez les batteries épuisées en respectant les directives du fabricant.
Démontez le cadre avant en suivant les instructions de la section « Démontage du cadre avant » à la page Si vous remplacez un lecteur existant, enlevez les deux vis qui maintiennent le lecteur à sa baie. Si vous ajoutez un lecteur, passez à l'étape www.emachines.com 147. l'étape 144. 146.
Page 360
Ajout ou remplacement d'un lecteur de CD ou de DVD Débranchez les câbles d'alimentation, de données et audio (le cas échéant) de l'arrière du lecteur. Enlevez le lecteur du boîtier en le glissant vers l'avant. Insérez le nouveau lecteur dans la baie en le glissant par l'avant du boîtier.
Enlevez la vis qui maintient le lecteur de carte à la baie. Débranchez le câble USB du lecteur de carte de la carte système. www.emachines.com 144. 146, mais laissez les câbles...
Ajout ou remplacement d'un disque dur Conseils et astuces Munissez-vous d'un tournevis cruciforme pour ajouter ou remplacer un disque dur. Glissez le lecteur de carte hors du boîtier. Insérez le nouveau lecteur de carte dans la baie en le glissant par l'avant du boîtier.
Page 363
Faites glisser l'ancien disque dur hors de la baie. Glissez le nouveau disque dur dans la baie. Fixez le disque dur à la baie du disque dur à l'aide des quatre vis précédemment enlevées. www.emachines.com l'étape 9. Si vous remplacez un disque...
Remplacement du ventilateur arrière Conseils et astuces Munissez-vous d'un tournevis cruciforme pour ajouter ou remplacer un ventilateur arrière. Glissez à nouveau la baie du disque dur en position, puis fixez-la au boîtier à l'aide de la vis précédemment enlevée.
« Démontage du panneau latéral » à la page Débranchez tous les câbles d'alimentation de la carte système et des lecteurs. Enlevez les quatre vis qui maintiennent le bloc d'alimentation au boîtier. Glissez le bloc d'alimentation environ 2,5 cm vers l'avant. www.emachines.com 147. 144.
Conseils et astuces Sur certains modèles, le ventilateur du dissipateur thermique doit être enlevé d'abord. Remplacement du dissipateur thermique Conseils et astuces Munissez-vous d'un tournevis cruciforme pour ajouter ou remplacer le dissipateur thermique. Tirez vers le bas le côté du bloc d'alimentation le plus proche de vous, puis sortez le bloc d'alimentation de la baie.
« Remontage du panneau latéral » à la page Pour remplacer le panneau E/S avant, procédez comme suit : Démontez le panneau latéral en suivant les instructions de la section « Démontage du panneau latéral » à la page www.emachines.com 147. 144.
Page 368
Conseils et astuces Pour faciliter le rebranchement ultérieur des câbles à la carte système, notez l'emplacement de chaque connecteur alors que vous le débranchez. Débranchez les câbles d'alimentation et des DEL du cadre avant de la carte système. Dégagez le cadre avant de l'avant du boîtier.
Page 369
Faites pivoter le panneau E/S vers le haut jusqu'à ce que son trou de vis soit aligné au trou de vis de l'avant du boîtier, puis fixez-le au boîtier à l'aide de la vis. Rebranchez les câbles du panneau E/S dans les connecteurs appropriés de la carte système. www.emachines.com...
Ajout ou remplacement d'une carte d'extension Insérez les câbles du cadre avant dans le trou du boîtier derrière le cadre, puis enfoncez le cadre avant en position. Rebranchez les câbles du cadre avant et des DEL dans les connecteurs appropriés de la carte système.
Débranchez les câbles de données des lecteurs de la carte système. Débranchez le câble du lecteur de carte mémoire de la carte système. www.emachines.com 147. 144.
Page 372
Mise en garde Le fond du dissipateur thermique est doté d'un matériau d'interface thermique. Prenez soin de ne pas endommager ce matériau lorsque vous enlevez le dissipateur du processeur. Si le processeur est tiré hors de son support lorsque vous enlevez le dissipateur thermique, le processeur peut être endommagé.
Page 373
Ne serrez pas trop les vis. Branchez le câble d'alimentation du ventilateur du dissipateur thermique à la carte système. Réinstallez chaque carte d'extension. Remontez le panneau latéral en suivant les instructions de la section « Remontage du panneau latéral » à la page www.emachines.com 147.
Page 374
CHAPITRE 14 Dépannage • Directives de sécurité • Premières étapes • Dépannage • Support par téléphone...
Si un message d'erreur apparaît à l'écran, prenez note du message exact. ■ Le message peut aider le service d'assistance clientèle de eMachines à poser le diagnostic et à résoudre le problème. Si vous avez ajouté ou retiré des périphériques, examinez les procédures ■...
Dépannage Cartes d'extension Audio Batterie Lecteurs de CD ou de DVD Les rubriques de dépannage sont listées par ordre alphabétique. L'ordinateur ne reconnaît pas une carte d'extension Arrêtez et redémarrez votre ordinateur. ■ Assurez-vous que le logiciel requis est installé. Pour plus d'informations, ■...
« Le disque est plein ou est protégé en écriture » Assurez-vous que l'onglet de protection en écriture du coin supérieur droit ■ de la disquette est positionné vers le bas (non protégée). www.emachines.com « Réglage du volume » à « Réglage du volume » à la « Nettoyage des 132.
Lecteurs de DVD Gestion de fichiers Aide et support Pour plus d'informations sur le dépannage, cliquez sur Démarrer et ensuite sur Aide et support. Tapez les mots clés Restauration du système dans le champ Rechercher et cliquez ensuite sur la flèche.
(FSI) est bien configuré. Pour obtenir de l'aide, contactez le service d'assistance technique du FSI. Assurez-vous qu'il n'y a pas de problème de modem. Voir ■ (commuté) » à la page 174 www.emachines.com pour redémarrer l'ordinateur. NTRÉE 174. « Branchement à un modem câble ou DSL ou ou votre affiche de configuration pour «...
Aide et support Pour plus d'informations sur le dépannage, cliquez sur Démarrer puis sur Aide et support. Tapez les mots clés dépannage dans le champ Rechercher, puis cliquez sur la flèche. Clavier Vous voyez apparaître un message « Impossible de trouver l'hôte » et vous ne pouvez pas naviguer dans Internet.
Type d'affichage—L'affichage de Media Center est optimal sur des ■ périphériques offerts en conjonction avec l'ordinateur Media Center que vous avez acheté auprès de eMachines. La qualité vidéo des autres types de périphériques d'affichage, notamment les téléviseurs, peut être moins bonne. Si vous n'avez pas commandé...
Page 382
Âge du téléviseur—Les téléviseurs plus récents sont dotés d'un ■ plus grand nombre de fonctionnalités avancées, produisent une image de meilleure qualité et prennent en charge les hautes résolutions d'écran. L'affichage vidéo de Media Center sera meilleur sur les téléviseurs plus récents.
Contactez votre service téléphonique pour connaître le code exact afin de désactiver temporairement le service. Assurez-vous également que les propriétés de numérotation du modem sont bien déterminées. www.emachines.com 170. « Branchement du modem...
Page 384
Aide et support Pour plus d'informations sur le dépannage, cliquez sur Démarrer puis sur Aide et support. Tapez le mot clé numérotation dans le champ Rechercher, puis cliquez sur la flèche. Pour vérifier les propriétés de numérotation : Cliquez sur Démarrer puis sur Panneau de configuration. La fenêtre Panneau de configuration s'ouvre.
Page 385
Pour diminuer le volume du modem : Cliquez sur Démarrer puis sur Panneau de configuration. La fenêtre Panneau de configuration s'ouvre. Si votre Panneau de configuration est affiché par catégories, cliquez sur Imprimantes et autres périphériques. www.emachines.com ou votre affiche de...
Moniteur Conseils et astuces Pour obtenir de plus amples informations, consultez « Modification de l'intensité de couleur » à la page Aide et support Pour plus d'informations sur le dépannage, cliquez sur Démarrer puis sur Aide et support. Tapez les mots clés résolution d'écran dans le champ...
La plupart des routeurs comportent des témoins indiquant qu'ils fonctionnent. Pour plus d'informations, consultez la documentation fournie avec votre routeur. Assurez-vous que tous les ordinateurs de votre réseau ont le même nom ■ de groupe de travail. www.emachines.com « Mise en...
Mots de passe Alimentation Imprimante Assurez-vous que tous les ordinateurs utilisent le même masque de ■ sous-réseau. Si vous avez attribué des adresses IP aux ordinateurs, assurez-vous qu'ils ■ ont tous des adresses IP différentes. Pour les réseaux familiaux, les adresses IP devraient être 192.168 N.N où...
Page 389
Si vous imprimez de gros fichiers ou de nombreux fichiers en même temps, ■ il serait judicieux d'ajouter de la mémoire à l'imprimante. Consultez la documentation de l'imprimante pour obtenir des instructions sur l'ajout de mémoire. www.emachines.com Panneau de configuration puis sur Imprimantes et . La...
■ assurez-vous d'avoir effectué l'installation conformément aux instructions fournies. Si vous n'avez pas acheté les périphériques ou logiciels chez eMachines, consultez la documentation du fabricant et les ressources du support technique. Support par téléphone « Réglage du volume » à...
Dans bon nombre de cas, vous trouverez des informations complémentaires sur les produits et de la documentation en ligne pour le matériel fourni par eMachines dans la bibliothèque de documentation de notre site Web. Ce manuel de l'utilisateur.
Page 392
ANNEXE A Informations relatives à la sécurité, aux règlements et aux questions d'ordre juridique • Informations de sécurité importantes • Énoncés sur la conformité aux règlements • Informations d'ordre environnemental • Avis...
Votre système eMachines a été conçu et testé pour satisfaire aux plus récentes normes en matière de sécurité d'équipement technologique. Cependant, pour assurer une utilisation en toute sécurité de cet ordinateur, il est recommandé de suivre les instructions de sécurité figurant sur l'ordinateur et dans la documentation.
Page 394
Énoncés sur la conformité aux règlements États-Unis d'Amérique Mise en garde Les changements ou modifications non approuvés expressément par eMachines peuvent annuler la conformité de la FCC et annuler votre autorisation d'utiliser l'ordinateur. Avertissement Ce produit contient des éléments chimiques, incluant du plomb, reconnu par l'État de la Californie comme un...
Page 395
REN de tous les dispositifs ne doit pas dépasser 5. Tous les systèmes eMachines équipés de lecteurs CD et DVD sont conformes aux normes de sécurité appropriées, incluant la norme IEC 825.
Page 396
Pour empêcher l'émission de substances dangereuses dans l'environnement et pour maximiser l'utilisation de nos ressources naturelles, eMachines fournit les informations suivantes sur la façon responsable de recycler ou de réutiliser la plupart du matériel à la « fin de la vie »...
Page 397
L'utilisation de cette technologie doit être autorisée par Macrovision Corporation, et a pour fin prévue une utilisation pour le domicile ainsi que d'autres usages limités sauf en cas d'autorisation de Macrovision Corporation. La rétroconception ou le démontage sont interdits. www.emachines.com...
Index accès dossiers partagés fichiers partagés lecteurs partagés accessoires mesures de sécurité adresse messagerie adresse IP entrer réseau étendu réseau local adresse IP du réseau étendu adresse IP du réseau local affichage dépannage dossiers partagés lecteurs partagés modification de la résolution propriétés...
Page 399
CD musical documents dossiers DVD vidéo fichiers musicaux fichiers WMA icônes de bureau raccourcis du bureau CyberLink PowerDVD décharge électrostatique...
Page 400
Aide et support site Web eMachines documents création enregistrement impression ouverture dossiers coller copie couper création déplacement désactivation du partage...
Page 401
Internet lecteur Zip port lecteurs affichage des fichiers et des dossiers affichage du contenu www.emachines.com CD enregistrable défragmentation dépannage désactivation du partage DVD enregistrable identification de types de lecteur mappage du réseau partage...
Page 402
McAfee SecurityCenter mise à jour des définitions recherche des virus mémoire ajout dépannage installation remplacement menu Démarrer menus de raccourcis accès messagerie adresse consultation des messages envoi transfert de paramètres de...
Page 403
électricité statique entretien de votre ordinateur éviter la fatigue répétitive installation de l'ordinateur mises en garde générales...
Page 404
Fax dépannage envoi envoi à partir d'un programme installation de Fax réception et affichage réessai télécopie d'une image numérisée téléphone annulation automatique d'une télécopie annulation d'une télécopie configuration d'un modèle de page de garde de télécopie...
