D IG I T A L - MU LTI MED IA PR O J E CT OR
OWNER'S MANUAL
About owner's manual
Please read owner's manual thoroughly to ensure correct usage of the projector
and its features. After reading, store owner's manual in a safe place for future
reference.
Features
1. Design with 3LCD optical system.
2. Support Dynamic Contrast and 3D Comb Filter, great for home theater use.
3. Auto V keystone function, +/- 30 degrees.
4. Auto brightness control.
5. Auto ceiling function.
6. Support YPbPr signal.
The content of this manual is subject to change without period notice. All rights reserved.
1
Advertisement
Table of Contents
Related Manuals for Dukane Digital-Multimedia Projector None
Summary of Contents for Dukane Digital-Multimedia Projector None
-
Page 1: About Owner's Manual
D IG I T A L - MU LTI MED IA PR O J E CT OR OWNER’S MANUAL About owner’s manual Please read owner’s manual thoroughly to ensure correct usage of the projector and its features. After reading, store owner’s manual in a safe place for future reference. -
Page 2: Table Of Contents
Contents About owner’s manual ... Contents ... Safety Instructions ... Product Safety Labels ... Checking the Package Contents ... Part Names and Function ... 10 Main Unit ... Control Panel ... Rear View I/O Board ... Bottom View ... Remote Control ... Inserting the batteries ... -
Page 3: Safety Instructions
Safety Instructions WARNING C A U T I O N Typical Symbols This symbol indicates an additional warning (including cautions). A n i l l u s t r a t i o n i s p r o v i d e d t o c l a r i f y t h e c o n t e n t s ( f o r e x a m p l e : the illustration to the left indicates danger of electrical shock). - Page 4 Safety Instructions(continued) WARNING If a problem should occur If smoke or strange odors arise, continued use could result in fire or electrical shock. In such case, immediately turn off the power switch and then disconnect the power plug from the power outlet. After making sure that the smoke or odor has stopped, contact your dealer for repairs.
- Page 5 Safety Instructions(continued) WARNING Do not look through the lens when the lamp is on. Never look through the lens when the lamp is on. The powerful light could adversely affect vision. Use special caution in households where children are present. Avoid shock or impact on the projector.
- Page 6 Safety Instructions(continued) CAUTION Placing heavy objects on top of this projector could result in loss of balance or falling and cause personal injury or damage the projector. Do not block the ventilation openings. Do not block the ventilation openings of this projector. Blocking ventilation could lead to internal overheating which could result in fire.
- Page 7 Safety Instructions(continued) CAUTION Avoid installation in humid or dusty locations. Do not install this projector in a humid or dusty location. This could result in fire or electrical shock.Do not handle the power cord roughly. Keep the power cord away from heaters; The heat could melt the power cord and cause fire or electrical shock.
-
Page 8: Product Safety Labels
Location of product safety labels Safety labels are used on or within the projector to alert you to items or areas requiring your attention. EMI LABEL Model: Input: 100-240V, 50/60Hz, 4A(1.2A~2.8A) Serial no.: LAMP WARNING LABEL LENS WARRANTY LABEL Business card... -
Page 9: Checking The Package Contents
Checking the Package Contents Projector Power Cord Computer cable Filter Sponge Remote Control (option) Remote Control S-Video Cable Speaker Cable Quick Start Guide (included CD) Carrying Bag (option) Video Cable Audio Cable USB Cable Convergence Lens RS232 (Optional) -
Page 10: Part Names And Function
Part Names and Function: Main Unit Zoom ring Focus ring 1 Zoom Ring U s e t h e Z o o m R i n g t o a d j u s t t h e s i z e o f t h e p r o j e c t e d i m a g e . R o t a t e t h e Z o o m R i n g u n t i l t h e i m a g e i s t h e d e s i r e d s i z e . -
Page 11: Part Names And Function
Part Names and Function:(continued) Main Unit Lens cover 5 Front adjustable foot E x t e n d a n d r e t r a c t t o a d j u s t t h e p r o j e c t i o n a n g l e 6 Foot adjust button L o c k / u n l o c k t h e a d j u s t a b l e f o o t . -
Page 12: Control Panel
Part Names and Function:(continued) Control panel Power indicator Power Auto Input Blank Power button Power on / operation mode, Standby mode, Cooling-down mode Brightness function,when sensor detects the surrounding light lower than 150 lux,”power button”will turn into blue light. Input Selects between RGB input source-Computer i n 1→... - Page 13 Part Names and Function:(continued) Control panel Power indicator Power Auto Input Blank Menu Display or hides the OSD main menu page. Menu-up /down, Menu-right / left Selecting OSD menu item up or down. Selecting and adjusting the function of OSD menu item Keystone Adjusts the vertical keystone with menu-up, menu-down (See Page 32) Power indicator...
-
Page 14: Rear View I/O Board
Part Names and Function:(continued) Rear View / IO Board USB mouse connector RS-232C Monitor out Computer in 1 Computer in 2 Computer in 1 Input Analog RGB video signal from a computer Computer in 2 / YPbPr When input signal from computer in 2, it may encounter incorrect picture color. - Page 15 Part Names and Function:(continued) Rear View / IO Board USB mouse connector RS-232C Monitor out Computer in 1 Computer in 2 Audio out Connecting to an external speaker system. Audio in Stereo mini jack for PC input USB mouse connector Connects a USB cable to a computer for interactive smart function.
-
Page 16: Bottom View
Part Names and Function:(continued) Bottom View Suspension bracket fixing points (4 points) Install the optional ceiling mount here when suspending the projector from the ceiling. Air filter cover Prevents dust and other foreign particles from being drawn into the projector. Air filter cover Suspension bracket fixing points(4) -
Page 17: Remote Control
Part Names and Function:(continued) Remote Control Power Power on / operation mode, Standby mode, Cooling-down mode Press”ESC”button,it will close”Menu”picture Vol +/- Sound louder or lower Menu Display or hide the OSD main menu page Keystone +/- Adjusts the vertical keystone function Still Keep the current image on the Screen Blank... -
Page 18: Inserting The Batteries
Part Names and Function:(continued) Remote Control Batteries Installation 1. Remove the battery cover. 2. Loading the batteries. Make sure the plus and minus poles are correctly oriented. 3. Close the battery cover. C A U T I O N 1. Avoid excessive heat and humidity. 2. -
Page 19: Installation
Installation Setting Up the Projector The projector supports the following four different projection methods Front projection Rear A special method of installation is required in order to suspend the projector from the ceiling. Please ask your dealer for details. - Page 20 Installation(contiuned) Setting Up the Projector Rear ceiling projection Front ceiling projection A special method of installation is required in order to suspend the projector from the ceiling. Please ask your dealer for details.
- Page 21 Installation(contiuned) Size and Projection Distance The distance between the projector and screen determines the actual image size. Refer to the table below to determine the image size at a given distance. The values shown below are approximate and may vary from actual sizes. Screen (inch) Distance(m)
-
Page 22: Adjusting The Image Position
Installation(contiuned) Adjusting the Image Position Use the adjustable foot at the front of the projector to set the image height. Rotate the adjustable foot at the rear of the projector to fine- tune the image position. When the foot is adjusted, it may cause the shape of the projected image to become distorted. -
Page 23: Moving The Projector
Installation(contiuned) Moving the projector 1. Use the carry bag when moving the projector.(option) 2. Replace the lens cover and retract the front adjustable foot when moving the projector to prevent damage to the projector. carry bag ( O p t i o n a l , p l e a s e c o n t a c t y o u r d e a l e r f o r m o r e i n f o r m a t i o n ) C A U T I O N The optional carry bag is intended to protect the projector from dust and scratches on the surface of the cabinet. -
Page 24: How To Connect
How to Connect Desktop PC Before starting, make sure that the projector and computers are both turned off. 1. Connect the computer cable. Connect either end of the computer cable to the projector’s Computer in 1 or Computer in 2 Disconnect the monitor cable from the computer and connect the other end of the terminal where the monitor cable is disconnected from the computer. -
Page 25: Laptop Pc
How to Connect Laptop PC Before beginning, make sure that the projector and computers are both turned off. 1. Connect the computer cable. Connect either end of the computer cable to the projector’s Computer in 1. Connect the other end of the project cable to the monitor out connection on the laptop. -
Page 26: Usb-Mouse
How to Connect USB Mouse USB mouse compatible MS-Window98/2000/NT/XP/Me, Macintosh :OS8.6~10.1, and a Microsoft Mouse driver installed. 1. Insert the end of the USB Cable (B-Type) to the projector’s USB port. 2. Connect the end of the USB Cable (A-type) to the computer’s USB port. -
Page 27: Video
How to Connect Video 1. Connect to a video source The Projector can receive composite AV ,YPbPr and S-Video. Connect RCA plug at projector and video source ( like DVD player) for video signal. Please contact with your dealer for optional cable. - Page 28 How to Connect Video Connect YPbPr plug at projector computer in 2 port and video source ( like DVD player) for video signal. For S-Video, using S-Video cable connect to projector and video source for video signal.
-
Page 29: Basic Operation
Basic Operation Turning on the projector - Procedure Check the power is turned off for the projector and all components connected to the projector. Remove the lens cover. Connect the power cord to the projector. Turn on the power switch. Press the button on the control panel or [POWER] button on the remote control. - Page 30 Basic Operation Turning on the Projector - Procedure The power indicator will flash green. Press the Input button on the control panel or on the remote control to select the appropriate source. Rotate the zoom ring to adjust the screen size. Rotate the focus ring to adjust the focus.
- Page 31 Basic Operation Turning off the Projector - Procedure Press the power button on the projector or remote control. The power off confirmation message appears . Press the power button again and the projector will enter cool-down mode. The lamp shuts off, the lamp indicator flashes red, and the fans continue to run for approximately two minutes.
-
Page 32: Adjusting The Screen Image
Basic Operation Adjust the Screen Image 1. Adjusting the image size Rotate the Zoom Ring to adjust the image. 2. Adjusting the image height Extend or retract the front adjustable foot to adjust the height of the image. 3. Correcting Keystone Distortion ◆... -
Page 33: Functionofmenu(Osd)
Functions of Menu (OSD) Keypad Operating: Power Auto Input Blank Turn on and turn off the projector 2. Blank : Blanks the projected image. If the projector is left in Blank m o d e f o r m o r e t h a n 1 5 m i n u t e s , t h e p r o j e c t o r w i l l automatically shut off the lamp and enter cool-down mode. -
Page 34: Computer Mode
Functions of Menu (OSD) Computer Mode-Picture Menu Brightness 000/100 Contrast 000/100 Sharpness 000/002 Display mode Powerful Presentation Natural Green board User Red User Green User Blue 1. PICTURE Adjusts the overall image brightness Adjusts the difference between light and dark areas of the image Adjusts the image sharpness Select Enhance brightness... - Page 35 Functions of Menu (OSD) Computer Mode-Audio Menu Volume 000/040 Mute 2. AUDIO Adjusts the volume Off/on Mutes the volume on/off...
- Page 36 Functions of Menu (OSD) Computer Mode-SETTING Menu H position 000/100 V position 000/100 Phase 000/100 Frequency 000/100 Auto keystone off/on Keystone V -80/+80 Auto sync execute Auto search off/on 3.SETTING Move the image position horizontally Move the image position vertically Set the synchronization polarity Set the horizontal scanning frequency Automatically Corrects keystone...
- Page 37 Functions of Menu (OSD) Computer Mode-ADVANCED Menu...
- Page 38 Functions of Menu (OSD) Computer Mode-ADVANCED Menu Zoom/pan execute Still on/off Blank on/off Reset all execute Language English Resize Select source execute Blank on If the projector is left in Blank mode for more than 15 minutes, the projector will automatically shut off the lamp and enter cool-down mode.
- Page 39 Functions of Menu (OSD) Computer Mode-PRESENTATION Menu Auto ceiling off/on Front execute execute Ceiling execute Rear execute Ceiling and Rear Auto off/on Brightness normal Lamp mode economic Lamp Reset lamp execute timer (optional) 5.PRESENTATION Automatically inverts the image when the projector is turned upside down i.e. when the projector is mounted on the ceiling Normal projection mode...
- Page 40 Functions of Menu (OSD) Reset Lamp Timer 1. After you select ［ Reset Lamp Timer ］ on the OSD menu, the following confirmation message will appear on the screen. 2.You choose ［ Yes ］ ,the Lamp Mode show ［ 0 ］ . * The replacement warning message is set to appear after about 2000 hours of lamp use in order to maintain the brightness and quality of the projected images.
-
Page 41: Video Mode
Functions of Menu (OSD) Video Mode-Picture Menu Brightness Contrast Sharpness Display mode Presentation Green board User Red User Green User Blue 1. PICTURE 000/100 Adjusts the overall image brightness 000/100 Adjusts the difference between light and dark areas of the image 000/002 Adjusts the image sharpness Select... - Page 42 Functions of Menu (OSD) Video Mode-Audio Menu Volume 000/040 Mute Off/on 2. AUDIO Adjusts the volume Mutes the volume on/off...
- Page 43 Functions of Menu (OSD) Video Mode-Setting Menu Auto keystone off/on Keystone V -80/+80 Auto search off/on 3.SETTING Automatically Corrects keystone distortion in image i.e. press once to do once Corrects vertical keystone distortion in image Search signal source automatically.
- Page 44 Functions of Menu (OSD) Video Mode-Advanced Menu...
- Page 45 Functions of Menu (OSD) Video Mode-Advanced Menu Zoom/pan execute Still on/off Blank on/off Reset all execute Language English Resize Select source execute logo on/off scale mode Normal/True blank on If the projector is left in Blank mode for more than 15 minutes, the projector will automatically shut off the lamp and enter cool-down mode.
- Page 46 Functions of Menu (OSD) Video Mode-PRESENTATION Menu Auto ceiling off/on Front execute execute Ceiling execute Rear Ceiling and Rear execute Auto Brightness off/on normal Lamp mode economic Lamp Reset lamp execute timer (optional) 5.PRESENTATION Automatically inverts the image when the projector is turned upside down i.e. when the projector is mounted on the ceiling Normal projection mode...
-
Page 47: Appendix
Maintenance and Troubleshooting Ceiling Mounted Installation Guide Attach the optional ceiling mount at four-suspension bracket fixing points when suspending the from a ceiling. A special method of installation is required in order to suspend the projector from the ceiling. Please ask your dealer for more details. MAX M 4 x 8mm FOR MOUNT... -
Page 48: List Of Support Display Modes
Maintenance and Troubleshooting 1.Cleaning the projector Clean the projector cabinet by wiping it gently with a soft cloth.If necessary, the cabinet can be cleaned using a neutral detergent and a soft cloth ensure th case WARNING 2.Cleaning the lens Use a commercially available air blower, or use lens cleaning paper and lens cleaner approved for use on optical coatings. - Page 49 Maintenance and Troubleshooting Lamp Replacement 1. Remove the lamp screw from the lamp door. 2. Remove the Lamp Door. 3. Remove the two Phillips head screws that hold the lamp in place. 4. Grasp the handle on the top of the lamp and pull the lamp straight up out of the projector.
- Page 50 Maintenance and Troubleshooting Indicators The Power and Lamp indicators show the status of the projector. Before requesting repair, check the projector status using the chart below. If the problem cannot be resolved contact your dealer. Power Lamp Conditions (Green) (Red) Slow Stand by flashing...
- Page 51 Maintenance and Troubleshooting Symptom The main power switch is not The power is turned on. not turned on The power cord is disconnected. The input is not correctly connected. No video No signal input. No open lens cover. The projector is not correctly connected.
- Page 52 List of Support Displays Modes List of Supported Monitor Displays Signal VESA SVGA SXGA SXGA SXGA Signal SDTV(480i) SDTV(480p) HDTV(720p) HDTV(1080i) Signal TV(NTSC) TV(PAL,SECAM) Computer mode Refresh Rate(Hz) 60/72/75/85 56/60/72/75/85 60/70/75/85 70/75 60/75 Component(YPbPr) Refresh Rate(Hz) Composite/S-video Refresh Rate(Hz) Resolution(dots) 640X480 640X480 800X600...
