Digital Multimedia Projector
About User's manual
Features
The content of this manual is subject to change without period notice.
All rights reserved.
Multimedia LCD Projector
Thank you for purchasing the LCD projector.
Please read this user's manual thoroughly to ensure
correct usage of the projector and its features.
After reading, store this instruction manual in
a safe place for future reference.
1. Design with 3LCD optical system, provide you:
Bright image, natural color, smooth video playback
and gentle for your eyes.
2. V keystone function, +/- 30 degrees.
3. Support YPbPr signal.
-1-
Advertisement
Table of Contents
Related Manuals for Dukane ImagePro 8077A
Summary of Contents for Dukane ImagePro 8077A
- Page 1 Multimedia LCD Projector Thank you for purchasing the LCD projector. Please read this user’s manual thoroughly to ensure correct usage of the projector and its features. After reading, store this instruction manual in a safe place for future reference. 1. Design with 3LCD optical system, provide you: Bright image, natural color, smooth video playback and gentle for your eyes.
-
Page 2: Table Of Contents
Bottom View...………………………….…...17 Remote Control…...……………………….…….18 Inserting the batteries ..………………………19 Remote Control…...……………………….…….20 Inserting the batteries ..………………………21 Installation Setting up the projector………………………………………….……..22 Screen size and projection distance…………………………...……..24 Adjusting the image position. ………….………………………….… 25 Moving the projector………………………………………...…………26 How to connect Desktop PC...………...……………………...…27 Laptop PC...……………………………... - Page 3 Basic Operation Turning on the projector………………………………..…….………..31 Adjusting the screen image……………….……………………...…….33 Turning off the power…………….………………………………...….34 Function of Menu (OSD) Keypad operating…………………………………………..…………..35 Computer mode……………………………………………..……….…36 Video mode………………….……………………………..…………..43 Maintenance and Troubleshooting Ceiling Mounted Installation Guide……………………………………50 Cleaning the Projector/Lens……...………………….……..…………..51 Lamp replacement………….……………………….……………….…52 Indicators…………………………………….…………….….………..53 List of Support Displays Modes…………………………..…………..…55...
-
Page 4: Safety Instructions
This symbol indicates a compulsory action. The contents will be clearly indicated in an illustration or description near the symbol (for example: the symbol to the left shows that the power plug should be disconnected from the power outlet). Multimedia LCD Projector... - Page 5 Never attempt to make repairs yourself because this is dangerous. Do not use this projector if there is no image or sound, or if the sound is distorted. Continued use could result in fire or electrical shock.
- Page 6 Do not use any power cable except those supplied with the projector. The use of any other power cable could result in fire or electrical shock. Do not shine the laser beam onto yourself or other.
- Page 7 Do not place this projector on its side during use or push it into a small, poorly ventilated location. Do not place this projector on a carpet or bedding or cover it with a tablecloth, etc.
- Page 8 This could damage the power cord and cause fire or electrical shock. Always grip the plug when disconnecting. When the projector is not to be used for an extended period. If the projector is not to be used for an extended period because of travel, etc., disconnect the power plug from the power outlet and...
-
Page 9: Location Of Product Safety Labels
Multimedia LCD Projector Location of product safety labels Safety labels are used on or within the projector to alert you to items or areas requiring your attention. -
Page 10: Checking The Package Content
□ Projector □ ( included battery) □ Power Cord □ Computer cable □ USB Cable (optional) □ Quick Start Guide (included CD) Multimedia LCD Projector Remote Control □ included battery)(optional) □ S-Video(optional) □ □ Speaker Cable □ (optional) (optional) □... -
Page 11: Main Unit
Use the Zoom Ring to adjust the size of the projected image. Rotate the Zoom Ring until the image is the desired size. 2. Focus Ring Use the Focus Ring to focus the projector image. Rotate the Focus Ring until the image is clear. Multimedia LCD Projector... - Page 12 3. Front IR receiver When using the remote control, point the remote control at this sensor. 4. Filter cover Prevent dust and other foreign particles from being drawn into projector. Remove the Filter cover to clean the air filter. 5. Front adjustable foot Extend and retract to adjust the projection angle 6.
-
Page 13: Keypad Control
150 lux,”power button”will flash blue. 2. Input Computer source Selects between RGB input source-Computer 1 → Computer 2(RGB or YPbPr) →AV →S-Video → Computer1 ,System will auto detect YPbPr or RGB signal in computer 2 port. Multimedia LCD Projector -13-... - Page 14 3. Blank Blanks the projected image. If the projector is left in blank mode for more than 15 minutes, the projector will automatically shut down. 4. Auto Automatically adjusts the setting to match the current input. 5. Menu Display or hides the OSD main menu page.
-
Page 15: Rear View I/O Board
Please press "Auto" button again. The picture will be corrected. 3. Monitor out connector Connect an external monitor to this connection view the Computer1 input. 4. Control (RS-232C) Serial data port for controlling the projector with a computer or other RS-232 control device. Multimedia LCD Projector -15-... - Page 16 Connects a USB mouse cable to a computer to control computer mouse functions. 10. Power socket Connects the power core to this connection. 11. Power switch Turns the power on/off. 12. Rear IR receiver When using the remote control, point the remote control at this sensor. Multimedia LCD Projector -16-...
-
Page 17: Bottom View
Bottom View 1. Suspension bracket fixing points (4 points) Install the optional ceiling mount here when suspending the projector from the ceiling. 2. Air filter cover Prevents dust and other foreign particles from being drawn into the projector. Multimedia LCD Projector... -
Page 18: Remote Control
6.Still Keep the current image on the Screen. 7.Blank Hide the current image, become black color on the screen. Multimedia LCD Projector 8.Auto Sync Refresh the current image. 9. Menu down/ up, Menu left/right Selecting and adjusting the function of OSD 10. -
Page 19: Inserting The Batteries
Replace the batteries when remote control operation becomes sluggish or unresponsive. Do not place the remote control close to the cooling fan of the projector. Do not disassemble the remote control. If the remote control needs service. Please bring it to the service station. Multimedia LCD Projector -19-... -
Page 20: Remote Control
”Menu” picture . 12.Auto Sync Refresh the current image. 13.Blank Hide the current image, Become black color on the screen Multimedia LCD Projector 14.Still Keep the current image on the screen. -20- 2.Laser pointer Use laser pointer from remote control. -
Page 21: Inserting The Batteries
The laser pointer function emits a class directly into the laser beam outlet or point the laser beam at other people. Vision can be impaired by shining the beam in to the eyes. Multimedia LCD Projector Ⅱ laser beam. Do not look... -
Page 22: Installation
Setting Up the Projector The projector supports the following four different projection methods Front projection Rear A special method of installation is required in order to suspend the projector from the ceiling. Please ask your dealer for details. Multimedia LCD Projector -22-... - Page 23 Rear ceiling projection Front ceiling projection A special method of installation is required in order to suspend the projector from the ceiling. Please ask your dealer for details. Multimedia LCD Projector -23-...
-
Page 24: Screen Size And Projection Distance
Size and Projection Distance The distance between the projector and screen determines the actual image size. Refer to the table below to determine the image size at a given distance. Image Size (Inch) Multimedia LCD Projector Distance(m) Tele Wide 1.38 1.15... -
Page 25: Adjusting The Image Position
Adjusting the Image Position Use the adjustable foot at the front of the projector to set the image height. Rotate the adjustable foot at the rear of the projector to fine-tune the image position. When the foot is adjusted, it may cause the shape of the projected image to become distorted. -
Page 26: Moving The Projector
Caution The optional carry bag is intended to protect the projector from dust and scratches on the surface of the cabinet. It is not designed to protect the projector from external shock. -
Page 27: How To Connect
How to Connect Desktop PC Before starting, make sure that the projector and computers are both turned off. 1. Connect the computer cable. 1.1 Connect either end of the computer cable to the projector’s computer 1/ computer port. 1.2 Disconnect the monitor cable from the computer and connect the other end of the terminal where the monitor cable is disconnected from the computer. -
Page 28: Laptop Pc
Laptop PC Before beginning, make sure that the projector and computers are both turned off. 1. Connect the computer cable. 1.1 Connect either end of the computer cable to the projector’s computer 1 port. 1.2 Connect the other end of the project cable to the monitor out connection on the laptop. -
Page 29: Usb Mouse
USB mouse compatible MS-Window98/2000/NT/XP/Me, Macintosh :OS8.6~10.1, and a Microsoft Mouse driver installed. 1. Insert the end of the USB Cable (B-Type) to the projector’s USB port. 2. Connect the end of the USB Cable (A-type) to the computer’s USB port. -
Page 30: Video
Connect to a video source The Projector can receive composite AV ,YPbPr and S-Video. 1 Connect RCA plug at projector and video source ( like DVD player) for video signal. 2 . Connect RCA plug ( white and red) to audio source ( like DVD player) and connect the phone jack to projector for audio signal. -
Page 31: Basic Operation
Basic Operation Turning on the projector Procedure 1. Check the power is turned off for the projector and all components connected to the projector. 2. Remove the lens cover. 3. Connect the power cord to the projector. 4. Turn on the power switch. - Page 32 7. Press the [VIDEO]/[PC] button on the control panel or the Computer/Video buttons on the remote control to select the appropriate source. 8. Use the zoom ring to adjust the screen size. 9. Use the focus ring to adjust the focus. Multimedia LCD Projector -32-...
-
Page 33: Adjusting The Screen Image
Adjust the Screen Image 1. Adjusting the image size Turn the zoom ring on the projector to adjustor to adjust the image 2.Adjusting the image height. Extend or retract the front adjustable foot to adjust the height of the image. -
Page 34: Turning Off The Power
Turning off the projector 1. Press the power button on the projector or r emote control. The power off confirmation message appears .If you do not wan t to power off the projector, ignore the message and it will disappear. -
Page 35: Keypad Operating
Keypad Operating: : Turn on and turn off the projector 2. Blank: Blanks the projected image. If the projector is left in Blank mode for more than 15 minutes, the projector will automatically shut off the lamp and enter cool-down mode. -
Page 36: Computer Mode
Video Presentation Natural Cinema User User Red User Green User Blue Multimedia LCD Projector 1. PICTURE Adjusts the overall image brightness Adjusts the difference between light and dark areas of the image Adjusts the image sharpness Select Enhance brightness Keep the soft tender color... - Page 37 Volume 000/040 Mute off/on Multimedia LCD Projector 2. AUDIO Adjusts the volume Mutes the volume off/on -37-...
- Page 38 Set the synchronization polarity Frequency 000/100 Set the horizontal scanning frequency Keystone V -80/+80 Corrects vertical keystone distortion in image Auto sync execute Sets all of the above settings automatically Auto search off/on Search signal source automatically. Multimedia LCD Projector 3.SETTING -38-...
- Page 39 Multimedia LCD Projector -39-...
- Page 40 Computer 1 / Computer2 (RGB or YPbPr) / Video / S-Video Blank on If the projector is left in Blank mode for more than 15 minutes, the projector will automatically shut off the lamp and enter cool-down mode. Reset all 1.
- Page 41 Inverts the image horizontally, used when projecting onto a rear projection screen Inverts the image horizontally and vertically, used when the projector is mounted upside down and projecting onto a rear projection screen Show Lamp timer After changing a new lamp,execute this function for reset the Lamp timer.(see below)
- Page 42 Multimedia LCD Projector Reset Lamp Timer 1.After you select ［ Reset Lamp Timer］ on the OSD menu, the following confirmation message will appear on the screen. 2.You choose［Yes］,the Lamp Mode show［0］. *The replacement warning message is set to appear after about 2000 hours of lamp use in order to maintain the initial brightness and quality of the projected images.
-
Page 43: Video Mode
Presentation Natural Cinema User User Red User Green User Blue Multimedia LCD Projector 1. PICTURE Adjusts the overall image brightness Adjusts the difference between light and dark areas of the image Adjusts the image sharpness Adjusts the image color Adjusts the image tint... - Page 44 Volume 000/040 Mute off/on Multimedia LCD Projector 2. AUDIO Adjusts the volume Mutes the volume off/on -44-...
- Page 45 Keystone V -80/+80 Auto search off/on Multimedia LCD Projector 3.SETTING Corrects vertical keystone distortion in image Search signal source automatically. -45-...
- Page 46 Multimedia LCD Projector -46-...
- Page 47 Computer 1 / Computer2 (RGB or YPbPr) / Video / S-Video Blank on If the projector is left in Blank mode for more than 15 minutes, the projector will automatically shut off the lamp and enter cool-down mode. Reset all 1.
- Page 48 Inverts the image horizontally, used when projecting onto a rear projection screen Inverts the image horizontally and vertically, used when the projector is mounted upside down and projecting onto a rear projection screen Show Lamp timer After changing a new lamp,execute this function for reset the Lamp timer.(see below)
- Page 49 Multimedia LCD Projector Reset Lamp Timer 1.After you select ［ Reset Lamp Timer］ on the OSD menu, the following confirmation message will appear on the screen. 2.You choose［Yes］,the Lamp Mode show［0］. *The replacement warning message is set to appear after about 2000 hours of lamp use in order to maintain the initial brightness and quality of the projected images.
-
Page 50: Maintenance And Troubleshooting
Attach the optional ceiling mount at four-suspension bracket fixing points when suspending the from a ceiling. *A special method of installation is required in order to suspend the projector from the ceiling. Please ask your dealer for more details. -50-... -
Page 51: Cleaning The Projector/Lens
Do not clean the lens with harsh materials or subject the lens to shock, as it can easily become damaged. Close the lens cover when the projector not in use. 3.Change Air Filter When the air filter becomes clogged with dust, etc., the projector may... -
Page 52: Lamp Replacement
Lamp Replacement Caution: The lamp and inside of the projector become very hot while the projection lamp is lit. Allow the projector to cool for at least 15 minutes prior to opening the lamp door. 1. Release the Lamp Door Latch using a small screwdriver or similar tool to slide the latch towards the projector lens. -
Page 53: Indicators
Indicators The Power and Lamp indicators show the status of the projector. Before requesting repair, check the projector status using the chart below. If the problem cannot be resolved contact your dealer. Power Lamp Conditions Notes (Green) (Red) Slow Stand by... - Page 54 *The power cord is disconnected. No video *The input is not correctly connected. *No signal input *No open lens cover No audio *The projector is not correctly connected. *The volume is set to minimum. *Mute is turned on No remote *No battery function...
-
Page 55: List Of Support Displays Modes
SVGA 56/60/72/75/85 60/70/75/85 SXGA SXGA SXGA Component(YPbPr) Signal Refresh Rate(Hz) SDTV(480i) SDTV(480p) HDTV(720p) HDTV(1080i) Composite/S-video Signal Refresh Rate(Hz) TV(NTSC) TV(PAL,SECAM) Multimedia LCD Projector Resolution(dots) 640X480 640X480 800X600 1024X768 70/75 1152X864 60/75 1280X960 1280X1024 640x480 832x624 1024x768 1152x870 Resolution(dots) 720X480 720X480...
