For the customers in the USA This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Overview The ESBK-7052 Ethernet Option is an expansion board that installs in an ISA slot of the ES-7 EditStation™ to make it possible to connect the ES-7 to a network using Ethernet . You can use the network to exchange ES-7 data with other equipment.
Installing the Expansion Board For installation, refer to “Installing Expansion Boards in ISA Slots” in Chapter 3 “Connections and Settings” in the Operating Instructions supplied with the ES-7 EditStation. Note Be sure to power the ES-7 off before installing this board. Installing the Driver Software To use the expansion board, you will need to start the system and install the driver software.
Page 20
Installing the Driver Software Click the Start button on the taskbar, point to Settings, and click Control Panel. The Control Panel window appears. Double click the Network icon in the Control Panel. The following dialog box appears.
Page 21
Click the Yes button. After a few moments, the following dialog box appears. Click the Next button. The following dialog box appears. (Continued)
Page 22
Installing the Driver Software Click the Start Search button. The following dialog box appears. Check to be sure that “3Com Etherlink III ISA/PCMCIA Adapter (detected)” is displayed under Network Adapter, and then click the Next button. The following dialog box appears.
Page 23
In the Network Protocol list, check only the NetBEUI Protocol check box, and then click the Next button. The following dialog box appears. Click the Next button. The following dialog box appears. (Continued)
Page 24
Installing the Driver Software Click the Next button. The following dialog box appears. Enter “D:\I386” in the text box, and then click the Continue button. The following dialog box appears. Check to be sure that “0x300” is displayed in the I/O Port Address box and that “10”...
Page 25
Click the OK button. Installation starts. After a few moments, the following dialog box appears. Click the Next button. The following dialog box appears. (Continued)
Page 26
Installing the Driver Software Click the Next button. The following dialog box appears. Enter a Workgroup or Domain name, and then click the Next button. For more information about the Workgroup or Domain name, contact your Network Administrator. The following dialog box appears.
Page 27
Remove the CD-ROM disk from the ES-7 and click the Yes button. After the system shuts down and restarts, you will be able to use the ESBK-7052 board. If you are connecting only one ES-7 system to your network, this completes the installation. If you will connect two or more ES-7 systems, proceed to step 20.
Page 28
Installing the Driver Software Click the Change button. The following dialog box appears. Enter a new name in the Computer Name box and click the OK button. As the new computer name, choose a name that is not being used by any other computer connected to your network.
Specifications General Dimensions (w/h/d) 179 × 121 × 22 mm (7 × 4 × inches) Mass 110 g (3 oz) Input and output connectors RJ-45 connector For 10Base-T twisted pair cables AUI connector For 10Base-5 coaxial cables BNC connector For 10Base-2 coaxial cables Accessories supplied Operating Instructions (1) Design and specifications are subject to change without notice.
Page 31
Table des matières Aperçu ................32 Emplacement et fonction des organes ......32 Installation de la carte d’extension ......33 Installation du logiciel de pilotage ....... 33 Spécifications ..............43...
Aperçu La carte Ethernet Option ESBK-7052 est une carte d’extension qui s’installe dans un logement ISA de l’EditStation ES-7 pour permettre le raccordement de l’ES-7 à un réseau à l’aide de Ethernet . Le réseau peut être employé pour échanger des données ES-7 avec d’autres appareils.
Installation de la carte d’extension Voir “Installation de cartes d’extension dans les logements ISA” dans le Chapitre 3 “Raccordements et réglages” du mode d’emploi fourni avec l’EditStation ES-7 pour l’installation. Remarque Ne pas oublier de mettre l’ES-7 hors tension avant d’installer cette carte.
Page 34
Installation du logiciel de pilotage Cliquer sur le bouton Start de la Taskbar, pointer Settings et cliquer sur Control Panel. La fenêtre Control Panel apparaît. Cliquer deux fois sur l’icône Network sous Control Panel. La boîte de dialogue suivante apparaît.
Page 35
Cliquer sur le bouton Yes. Au bout d’un instant, la boîte de dialogue suivante apparaît. Cliquer sur le bouton Next. La boîte de dialogue suivante apparaît. (à suivre)
Page 36
Installation du logiciel de pilotage Cliquer sur le bouton Start Search. La boîte de dialogue suivante apparaît. Confirmer que “3Com Etherlink III ISA/PCMCIA Adapter (detected)” est affiché sous Network Adapter, puis cliquer sur le bouton Next. La boîte de dialogue suivante apparaît.
Page 37
Dans la liste Network Protocol, pointer seulement la case NetBEUI, puis cliquer sur le bouton Next. La boîte de dialogue suivante apparaît. Cliquer sur le bouton Next. La boîte de dialogue suivante apparaît. (à suivre)
Page 38
Installation du logiciel de pilotage Cliquer sur le bouton Next. La boîte de dialogue suivante apparaît. Entrer “D:\I386” dans la case texte, puis cliquer sur le bouton Continue. La boîte de dialogue suivante apparaît. Confirmer que “0x300” est affiché dans la boîte I/O Port Address et “10”...
Page 39
Cliquer sur le bouton OK. L’installation commence. Au bout d’un instant, la boîte de dialogue suivante apparaît. Cliquer sur le bouton Next. La boîte de dialogue suivante apparaît. (à suivre)
Page 40
Installation du logiciel de pilotage Cliquer sur le bouton Next. La boîte de dialogue suivante apparaît. Entrer un nom Workgroup ou Domain, puis cliquer sur le bouton Next. Contacter l’Administrateur du réseau pour plus d’informations sur les noms Workgroup et Domain. La boîte de dialogue suivante apparaît.
Page 41
La boîte de dialogue suivante apparaît. Retirer le CD-ROM de l’ES-7 et cliquer sur le bouton Yes. La carte ESBK-7052 sera utilisable après l’arrêt et le redémarrage du système. Si un seul système ES-7 est raccordé au réseau, l’installation est maintenant terminée. Passer à l’étape 20 pour raccorder deux ES-7 ou plus.
Page 42
Installation du logiciel de pilotage Cliquer sur le bouton Change. La boîte de dialogue suivante apparaît. Entrer un nouveau nom dans la boîte Computer Name, et cliquer sur le bouton OK. Choisir un nom différent de ceux des ordinateurs déjà raccordés au réseau pour le nouveau nom d’ordinateur.
Spécifications Généralités Dimensions (l/h/p) 179 × 121 × 22 mm (7 × 4 × pouces) Poids 110 g (2 onces) Connecteurs d’entrée/sortie Connecteur RJ-45 Pour câbles à paire torsadée 10Base-T Connecteur AUI Pour câbles coaxiaux 10Base-5 Connecteur BNC Pour câbles coaxiaux 10Base-2 Accessoires fournis Mode d’emploi (1) La conception et les spécifications sont sujettes à...
Page 45
Für Kunden in Deutschland Dieses Produkt kann im kommerziellen und in begrenztem Maße auch im industriellen Bereich eingesetzt werden. Dies ist eine Einrichtung, welche die Funk-Entstörung nach Klasse B besitzt. Inhaltsverzeichnis Kurzbeschreibung ............46 Lage und Funktion der Teile ........46 Installieren der Erweiterungskarte ......
Kurzbeschreibung Die Ethernet Option ESBK-7052 ist eine Erweiterungskarte für die Installierung in einen ISA-Steckschlitz in der EditStation™ ES-7 zwecks Einbindung in ein Ethernet -Netzwerk für den Datenaustausch mit anderen Geräten. Lage und Funktion der Teile 1 RJ-45 2 AUI 3 BNC Fragen Sie Ihren Netzwerk-Administrator, über welche der...
Installieren der Erweiterungskarte Zur Installierung lesen Sie bitte „Installieren in ISA- Steckschlitze“ in Kapitel 3 „Anschlüsse und Einstellungen“ in der Bedienungsanleitung der EditStation ES-7. Hinweis Denken Sie daran, die ES-7 vor dem Einbauen der Karte auszuschalten. Installieren der Treiber-Software Für das Arbeiten mit der Erweiterungskarte ist die Installierung der mitgelieferten Treiber-Software erforderlich.
Page 48
Installieren der Treiber-Software Klicken Sie in der Taskleiste auf Start, gehen Sie mit dem Cursor auf Einstellungen (Settings), und klicken Sie auf Systemsteuerung (Control Panel). Das Systemsteuerung-Fenster (Control Panel) wird geöffnet. Doppelklicken Sie im Systemsteuerung-Fenster (Control Panel) auf das Network-Symbol.
Page 49
Die folgende Dialogbox erscheint. Klicken Sie auf Yes (Ja). Kurz darauf erscheint die folgende Dialogbox. Klicken Sie auf Next (Weiter). Die folgende Dialogbox erscheint. (bitte wenden)
Page 50
Installieren der Treiber-Software Klicken Sie auf Start Search (Suche beginnen). Die folgende Dialogbox erscheint. Vergewissern Sie sich davon, daß „3Com Etherlink III ISA/PCMCIA Adapter (detected)“ unter Network Adapters erscheint, und klicken Sie auf Next (Weiter). Die folgende Dialogbox erscheint.
Page 51
Aktivieren Sie in der Network Protocols-Liste nur die Box „NetBEUI Protocol“, und klicken Sie auf Next (Weiter). Die folgende Dialogbox erscheint. Klicken Sie auf Next (Weiter). (bitte wenden)
Page 52
Installieren der Treiber-Software Klicken Sie auf Next (Weiter). Die folgende Dialogbox erscheint. Geben Sie „D:\I386“ in die Textbox ein, und klicken Sie auf Continue (Weiter). Die folgende Dialogbox erscheint. Vergewissern Sie sich davon, daß „0x300“ in der I/O Port Address-Box und daß „10“ in der Interrupt Number-Box angezeigt wird.
Page 53
Klicken Sie auf OK. Der Installationsvorgang beginnt. Kurz darauf erscheint die folgende Dialogbox. Klicken Sie auf Next (Weiter). Die folgende Dialogbox erscheint. (bitte wenden)
Page 54
Installieren der Treiber-Software Klicken Sie auf Next (Weiter). Die folgende Dialogbox erscheint. Geben Sie einen Workgroup- oder Domain-Namen ein, und klicken Sie auf Next (Weiter). Informationen zu Workgroup- oder Domain-Namen erfragen Sie bitte bei Ihrem Netzwerk-Administrator. Die folgende Dialogbox erscheint.
Page 55
Entnehmen Sie die Windows NT Workstation CD-ROM- Disc aus der ES-7, und klicken Sie auf Yes (Ja). Mit der ESBK-7052 läßt sich nun arbeiten, nachdem das System einmal heruntergefahren und wieder gestartet ist. Wenn nur eine ES-7 in das Netz eingebunden wird, ist die Installation hiermit abgeschlossen.
Page 56
Installieren der Treiber-Software Klicken Sie auf Change (Ändern). Die folgende Dialogbox erscheint. Geben Sie einen neuen Namen in die Computer Name- Box ein, und klicken Sie auf OK. Wählen Sie einen Computer-Namen der noch nicht innerhalb des Netzes verwendet wird. Einzelheiten erfragen Sie bitte bei Ihrem Netzwerk-Administrator.
Technische Daten Allgemeines Abmessungen (B/H/T) 179 × 121 × 22 mm Gewicht ca. 110 g Schnittstellen RJ-45 Für 10Base-T-Zweileiterkabel Für 10Base-5-Koaxialkabel Für 10Base-2-Koaxialkabel Im Lieferumfang Bedienungsanleitung (1) Änderungen, die dem technischen Fortschritt dienen, bleiben vorbehalten.
