INSTALLATION
MANUAL
R410A SPLIT SERIES
MODELS
FDMRN20AV1K
FDMRN25AV1K
FDMRN30AV1K
FDMRN36AV1K
FDMRN36AV1K
FDMRN50AV1K9 RR50AY1K9
FDMRN60AV1K
FDMRN20AV1KU RR20AV1KU
FDMRN25AV1KU RR25AV1KU
FDMRN30AV1KU RR30AV1KU
FDMRN36AV1KU RR36AV1KU
FDMRN50AV1KU RR50AY1KU
FDMRN60AV1KU RR60AY1KU
RR20AV1K
RR25AV1K
RR30AV1K
RR36AV1K
RR36AY1K
RR60AY1K
RR20AV1KRE
RR25AV1KRE
RR30AV1KRE
Installation Manual
R410A Split Series
IM-5CC(HA)-1115(9)-DAIKIN
Part No.: R08019044313J
English
Advertisement
Table of Contents
Related Manuals for Daikin FDMRN20AV1K
Summary of Contents for Daikin FDMRN20AV1K
- Page 1 INSTALLATION MANUAL R410A SPLIT SERIES MODELS Installation Manual English R410A Split Series FDMRN20AV1K RR20AV1K FDMRN25AV1K RR25AV1K FDMRN30AV1K RR30AV1K FDMRN36AV1K RR36AV1K FDMRN36AV1K RR36AY1K FDMRN50AV1K9 RR50AY1K9 FDMRN60AV1K RR60AY1K FDMRN20AV1KU RR20AV1KU RR20AV1KRE FDMRN25AV1KU RR25AV1KU RR25AV1KRE FDMRN30AV1KU RR30AV1KU RR30AV1KRE FDMRN36AV1KU RR36AV1KU FDMRN50AV1KU RR50AY1KU FDMRN60AV1KU RR60AY1KU IM-5CC(HA)-1115(9)-DAIKIN Part No.: R08019044313J...
-
Page 3: Outline And Dimensions
OUTLINE AND DIMENSIONS Indoor Unit [FDMRN] All dimensions are in mm Dimension Model 1176 1137 1097 1200 Indoor Unit [FDMRN] All dimensions are in mm Dimension Model 25/30A 359 1115 1076 1030 467 359 1369 1326 1287 594 359 1569 1526 1487 694... - Page 4 Indoor Unit [FDMRN] All dimensions are in mm Dimension Model 1372 1264 741 1148 665 Outdoor Unit [RR] All dimensions are in mm Dimension Model 20/25A 855 730 328 520 182 44 93 149 101 113 603 126 164 17 34 23 73 75 362...
-
Page 5: Top View
Outdoor Unit [RR] All dimensions are in mm Dimension Model 1030 852 428 410 412 827 72 196 91 488 448 142 141 83 Outdoor Unit [RR] All dimensions are in mm TOP VIEW SIDE VIEW FRONT VIEW SIDE VIEW Dimension Model 1030 826... - Page 6 Outdoor Unit [RR] All dimensions are in mm Dimension Model 1067 1006...
-
Page 7: Safety Precautions
INSTALLATION MANUAL This manual provides the procedures of installation to ensure a safe and good standard of operation for the air conditioner unit. Special adjustment may be necessary to suit local requirements. Before using your air conditioner, please read this instruction manual carefully and keep it for future reference. This appliance is intended to be used by expert or trained users in shops, in light industry and on farms, or for commercial use by lay persons. -
Page 8: Installation Diagram
INSTALLATION DIAGRAM Indoor Unit Hanger Return Duct Supply Duct Wrap the insulated pipe with the finishing tape from bottom to top Drain Piping Thermal Insulation Air Intake Air Intake Air Discharge Outdoor Unit INSTALLATION OF THE INDOOR UNIT The indoor unit must be installed such that there is no short circuit of the cool discharge. - Page 9 Center distance of axle (see drawing below) Provide clearance for servicing ease and optimal air flow as shown in the diagram. FOR 20A/25A/30A/36A/50A MODEL 300mm or more 300mm* or more Ceiling 2300mm or more Floor * Can be smaller than 300mm if ceiling is removable. Model A mm (inch) L mm (inch)
- Page 10 Ceiling Concealed Drain Piping Work Unit : mm • The drain pipe must be installed as shown in the diagram (see diagram above) to avoid damage caused by leaks and condensation. • For the best result, keep the piping as short as possible. Slant the piping at an angle to improve the flow. •...
-
Page 11: Installation Of The Outdoor Unit
INSTALLATION OF THE OUTDOOR UNIT As condensing temperature rises, evaporating temperature rises and cooling capacity drops. In order to achieve maximum cooling capacity, the location selected for outdoor unit should fulfill the following requirements: • Install the condensing (outdoor) unit in a way such that the hot air distributed by the outdoor condensing unit cannot be drawn in again (as in the case of short circuit of hot discharge air). - Page 12 Outdoor air throw direction changing method...
-
Page 13: Installation Clearance
INSTALLATION CLEARANCE • The outdoor unit must be installed in such a way, so as to prevent short circuit of the hot discharged air or obstruction to the smooth air flow. Please follow the installation clearances shown in the figure. Select the coolest possible place where intake air temperature is not greater than the outside air temperature (Refer to operating range). - Page 14 Piping Works And Flaring Technique Figure I • Do not use contaminated or damaged copper tubing. If Cutting Copper Tube any piping, evaporator or condenser had been exposed or 1/4t had been opened for 15 seconds or more, the system must be vacuumed.
-
Page 15: Electrical Connection
ELECTRICAL CONNECTION IMPORTANT: These values are for information only, they should be checked and selected to comply with the local and/or national codes and regulations. They are also subjected to the type of installation and size of conductors. ** The appropriate voltage range should be checked with data label on the unit. FDMRN20/25A - RR20/25A COMP COMP... - Page 16 FDMRN36/50/60A - RR36/50/60A (3PH) COMP COMP Outdoor unit Interconnection cable Terminal Block Indoor unit Terminal Block Power Fuse / Supply Main Circuit Cable Switch Breaker R / L1 S / L2 There must be an all pole T / L3 disconnection in the supply Power mains with a contact separation...
-
Page 17: Vacuuming And Charging
SPECIAL PRECAUTIONS WHEN DEALING WITH R410A UNIT R410A is a new HFC refrigerant which does not damage the • Use tools and materials exclusively for refrigerant R410A. ozone layer. The working pressure of this new refrigerant is Tools exclusively for R410A are manifold valve, charging 1.6 times higher than conventional refrigerant (R22), thus hose, pressure gauge, gas leak detector, flare tools, torque proper installation/servicing is essential. -
Page 18: Additional Charge
ADDITIONAL CHARGE The refrigerant is pre-charge in the outdoor unit. If the piping length is less than 7.5m, then additional charge after vacuuming is not necessary. When the piping length is more than 7.5m, use the table below. Cooling only Model Indoor (FDMRN) -
Page 19: Indicator Lights
! CAUTION • Manifold Gauge will show cylinder pressure rather than suction pressure if the cylinder valve and Manifold valve “A” are both open. There are many ways of charging liquid in a “controlled manner” into the suction side:- Use valve A on the manifold gauge set Use the valve on the refrigerant cylinder Charge through a Shredder valve Use a hose with a Shredder valve depressor... -
Page 20: Operating Range
OPERATING RANGE COOLING Outdoor Outdoor DB (°C) DB (°C) Indoor WB (°C) Indoor WB (°C) **Applicable only for RR20AV1KRE, RR25AV1KRE, RR30AV1KRE, RR50A and RR60A DB = Dry Bulb WB = Wet Bulb OVERALL CHECKING Ensure the following, in particular:- 2) Watch out for the following:- 1) The unit is mounted solidly and rigid in position. -
Page 21: Service And Maintenance
SERVICE AND MAINTENANCE Service Parts Maintenance Procedures Period Indoor Air Filter Remove any dust adhered on the filter by using a vacuum cleaner or At least once every wash in lukewarm water (below 40°C) with neutral cleaning detergent. 2 weeks. Rinse well and dry the filter before placing it back onto the unit. -
Page 22: Specifications
5620 POWER FACTOR (UAE Standard) 0.94 0.96 NET WEIGHT INDOOR UNIT OUTDOOR UNIT REFRIGERANT R410A Malaysia COUNTRY OF ORIGIN INDOOR UNIT Malaysia OUTDOOR UNIT NOTE: This product is not designed for repacking. In case of re-packing, contact to Daikin Dealer. - Page 24 P.O.Box 18674, Jebel Ali Free Zone, Dubai-UAE JR Shinagawa East Bldg., 2-18-1, Konan, Email: info@daikinmea.com Minato-ku, Tokyo, 108-0075 Japan Web: www.daikinmea.com http://www.daikin.com/global/ Importer for Turkey Lot 60334, Persiaran Bukit Rahman Putra 3, Taman Perindustrian Bukit Rahman Putra, Allianz Plaza-Kucukbakkalkoy Mah.Kayısdagi Cad.No:1 34750...
- Page 25 P.O.Box 18674, Jebel Ali Free Zone, Dubai-UAE JR Shinagawa East Bldg., 2-18-1, Konan, Email: info@daikinmea.com Minato-ku, Tokyo, 108-0075 Japan Web: www.daikinmea.com http://www.daikin.com/global/ Importer for Turkey Lot 60334, Persiaran Bukit Rahman Putra 3, Taman Perindustrian Bukit Rahman Putra, Allianz Plaza-Kucukbakkalkoy Mah.Kayısdagi Cad.No:1 34750...
- Page 27 ﺍﻟﻤﻮﺻﻔﺎﺕ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺪﺍﺧﻠﻴﺔ ﺍﻟﻤﻮﺩﻳﻞ FDMRN36AV1K FDMRN30AV1K FDMRN25AV1K FDMRN20AV1K FDMRN36AV1KU FDMRN30AV1KU FDMRN25AV1KU FDMRN20AV1KU ﺍﻟﻮﺣﺪﺓ ﺍﻟﺨﺎﺭﺟﻴﺔ RR36AV1K RR30AV1K RR25AV1K RR20AV1K RR36AV1KU RR30AV1KU RR25AV1KU RR20AV1KU RR30AV1KRE RR25AV1KRE RR20AV1KRE ﻓﻮﻟﺖ ﺍﻟﻔﻮﻟﻄﻴﺔ ﺍﻟﻤﻘﺪﺭﺓ 220-240 220-240 220-240 220-240 ﻫﺮﺗﺰ ﺍﻟﺘﺮﺩﺩ ﺍﻟﻤﻘﺪﺭ ﺃﻣﺒﻴﺮ ﺍﻟﺘﻴﺎﺭ ﺍﻟﻤﻘﺪﺭ 13.20 11.70 9.35...
- Page 28 ﺍﻟﺘﺼﻠﻴﺢ ﻭﺍﻟﺼﻴﺎﻧﺔ ﺍﻟﻤﺪﺓ ﺍﺟﺮﺍﺀﺍﺕ ﺍﻟﺼﻴﺎﻧﺔ ﺍﻗﺴﺎﻡ ﺍﻟﺼﻴﺎﻧﺔ ﻣﺮﺷﺢ ﺍﻟﻬﻮﺍﺀ ﺍﻟﺪﺍﺧﻠﻲ ﺍﺯﻝ ﺍﻱ ﻏﺒﺎﺭ ﻣﻠﺘﺼﻖ ﺑﺎﻟﻤﺮﺷﺢ ﺑﺎﺳﺘﻌﻤﺎﻝ ﻣﻜﻨﺴﺔ ﻛﻬﺮﺑﺎﺋﻴﺔ ﺍﻭ ﻧﻈﻔﹼ ﻪ ﺑﻤﺎﺀ ﺩﺍﻓﻲﺀ ﻣﺮﺓ ﻭﺍﺣﺪﺓ ﻛﻞ .ﻣﻊ ﻣﺤﻠﻮﻝ ﺗﻨﻈﻴﻒ ﻣﺘﻌﺎﺩﻝ ﻣﺌﻮﻳﺔ ﺍﻗﻞ ﻣﻦ ﻗﻠﻴ ﻼ ﹰ 40° .ﺍﺳﺒﻮﻋﲔ ﻋﻠﻰ ﺍﻻﻗﻞ .ﺍﺷﻄﻒ...
- Page 29 ﺣﺎﻻﺕ ﺍﻟﺘﺸﻐﻴﻞ ﺍﻟﻌﺎﺩﻱ ﺍﻟﺘﺒﺮﻳﺪ ﺍﻟﺨﺎﺭﺟﻴﺔ ﺍﻟﺨﺎﺭﺟﻴﺔ ﺑﺼﻴﻠﺔ ﺭﻃﺒﺔ ﺑﺼﻴﻠﺔ ﺭﻃﺒﺔ ﺩﺭﺟﺔ ﻣﺌﻮﻳﺔ ﺩﺭﺟﺔ ﻣﺌﻮﻳﺔ ﺩﺭﺟﺔ ﻣﺌﻮﻳﺔ ﺍﻟﺪﺍﺧﻠﻴﺔ ﺑﺼﻴﻠﺔ ﺟﺎﻓﺔ ﺩﺭﺟﺔ ﻣﺌﻮﻳﺔ ﺍﻟﺪﺍﺧﻠﻴﺔ ﺑﺼﻴﻠﺔ ﺟﺎﻓﺔ ، ﺗﻨﻄﺒﻖ ﻋﻠﻰ ﻧﻤﺎﺫﺝ ﻓﻘﻂ RR20AV1KRE ﻭ ، ، .RR60A RR50A RR30AV1KRE RR25AV1KRE ﺑﺼﻴﻠﺔ ﺭﻃﺒﺔ ﺑﺼﻴﻠﺔ ﺟﺎﻓﺔ = DB = WB ﺍﻟﻔﺤﺺ...
- Page 30 ﺗﻨﺒﻴﻪ ﺳﻮﻑ ﻳﺒ ﻴ ﹼﻦ ﺍﻟﻤﻘﻴﺎﺱ ﺍﻟﻤﺘﺸﻌﺐ ﺿﻐﻂ ﺍﻻﺳﻄﻮﺍﻧﺔ ﺑﺪﻻ ﻣﻦ ﺿﻐﻂ ﺍﻻﻣﺘﺼﺎﺹ ﺇﺫﺍ ﻛﺎﻥ ﺻﻤﺎﻡ ﺍﻻﺳﻄﻮﺍﻧﺔ ﻭﺻﻤﺎﻡ ﺍﻟﻤﻘﻴﺎﺱ ﺍﻟﻤﺘﺸﻌﺐ • "A" .ﻣﻔﺘﻮﺣﺔ ﻓﻲ ﺟﺎﻧﺐ ﻃﺮﻳﻘﺔ ﺍﻟﺘﺤﻜﻢ ﺗﻮﺟﺪ ﻋﺪﺓ ﻃﺮﻕ ﻟﺸﺤﻦ ﺍﻟﺴﺎﺋﻞ ﻓﻲ " " -:ﺍﻻﻧﺒﻮﺑﺔ ﻋﻠﻰ ﺟﻬﺎﺯ ﺍﻟﻤﻘﻴﺎﺱ ﺍﻟﻤﺘﺸﻌﺐ ﺍﺳﺘﻌﻤﻞ...
- Page 31 ﺍﻟﺸﺤﻦ ﺍﻻﺿﺎﻓﻲ ﻡ، ﺍﺫﻥ ﻻﺣﺎﺟﺔ ﻟﺸﺤﻦ ﺍﺿﺎﻓﻲ ﺑﻌﺪ ﺍﻟﺘﻔﺮﻳﻎ. ﺍﺫﺍ ﻛﺎﻥ ﻃﻮﻝ ﺍﻻﻧﺎﺑﻴﺐ ﺍﻥ ﻣﺎﺩﺓ ﺗﺒﺮﻳﺪ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺨﺎﺭﺟﻴﺔ ﻣﺸﺤﻮﻧﺔ ﻣﺴﺒﻘ ﺎ ﹰ. ﺍﺫﺍ ﻛﺎﻥ ﻃﻮﻝ ﺍﻻﻧﺎﺑﻴﺐ ﺍﻗﻞ ﻣﻦ .ﻡ، ﺁﻧﺬﺍﻙ ﺍﺳﺘﻌﻤﻞ ﺻﻤﺎﻡ ﺍﻟﺸﺤﻦ ﺍﻻﺿﺎﻓﻲ ﻛﻤﺎ ﻫﻮ ﻣﺒﲔ ﻓﻲ ﺍﻟﺠﺪﻭﻝ ﺍﺩﻧﺎﻩ ﺍﻛﺜﺮ...
- Page 32 ﺗﺤﺬﻳﺮﺍﺕ ﺧﺼﻮﺻﻴﺔ ﻋﻨﺪ ﺍﻟﺘﻌﺎﻣﻞ ﻣﻊ ﺍﻟﻮﺣﺪﺓ R410A . ﺍﻥ ﺍﻻﺩﻭﺍﺕ ﺍﻟﻤﺨﺼﺔ ﺍﺳﺘﻌﻤﻞ ﺍﺩﻭﺍﺕ ﻭﻣﻮﺍﺩ ﻣﻘﺘﺼﺮﺓ ﻟﻤﺎﺩﺓ R410A • ﺟﺪﻳﺪﺓ ﺍﻟﺘﻲ ﻻﺗﺴﺒﺐ ﺿﺮﺭ ﻟﻄﺒﻘﺔ ﻫﻲ ﻣﺎﺩﺓ ﺗﺒﺮﻳﺪ ﺍﻥ R410A ،ﻋﻠﻰ ﻭﺟﻪ ﺍﻟﺨﺼﻮﺹ ﻫﻲ ﺻﻤﺎﻡ ﻣﺘﺸﻌﺐ ﺍﻟﻤﺴﺎﻟﻚ ﻟﻤﺎﺩﺓ R410A ﺍﻋﻠﻰ ﻣﻦ ﻣﺎﺩﺓ ﺍﻻﻭﺯﻭﻥ.
- Page 33 FDMRN36/50/60A - RR36/50/60A (3PH) ﻣﺠﻤﻮﻋﺔ ﺍﻃﺮﺍﻑ COMP COMP ﻛﺎﺑﻞ ﺍﻟﺮﺑﻂ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺨﺎﺭﺟﻴﺔ ﻃﺮﻑ ﻣﻜﺒﺢ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺪﺍﺧﻠﻴﺔ ﻛﺎﺑﻞ ﺍﻟﻤﻔﺘﺎﺡ / ﺍﻟﺼﻤﺎﻣﺎﺕ ﺍﻟﺘﺰﻭﺩ ﺍﻟﺮﺋﻴﺴﻲ ﻗﻮﺍﻃﻊ ﺩﻭﺍﺋﺮ ﺑﺎﻟﺘﻴﺎﺭ R / L1 ﻳﺠﺐ ﺃﻥ ﻳﻜﻮﻥ ﻫﻨﺎﻙ ﻓﺼﻞ ﻗﻄﺐ ﻛﻠﻲ S / L2 ﻓﻲ ﻣﺼﺪﺭ ﺍﻟﻄﺎﻗﺔ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ ﺍﻟﺮﺋﻴﺲ T / L3 .ﻣﻢ...
- Page 34 ﺍﻟﺘﻮﺻﻴﻼﺕ ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ :ﻫﺎﻡ ﺍﻥ ﻫﺬﻩ ﺍﻟﻘﻴﻢ ﻟﻐﺮﺽ ﺍﻻﻃﻼﻉ ﻓﻘﻂ، ﻳﺠﺐ ﻓﺤﺼﻬﺎ ﻭﺍﺧﺘﻴﺎﺭﻫﺎ ﺑﺤﻴﺚ ﺗﺘﻮﺍﻓﻖ ﻣﻊ ﺍﻟﺸﻔﺮﺍﺕ ﺍﻟﻤﺤﻠﻴﺔ ﺍﻟﻤﺄﻟﻮﻓﺔ. ﻫﺬﺍ ﺍﻳﻀ ﺎ ﹰ ﻳﻌﺘﻤﺪ ﻋﻠﻰ ﻧﻮﻉ ﺍﻟﺘﺮﻛﻴﺐ ﻭﺣﺠﻢ .ﺍﻟﻤﻮﺻﻼﺕ ﺍﻟﻤﺴﺘﻌﻤﻠﺔ .ﻳﺠﺐ ﻓﺤﺺ ﻣﺪﻯ ﺍﻟﻔﻮﻟﻄﻴﺔ ﺍﻟﻤﻨﺎﺳﺐ ﻣﻊ ﻣﻌﻄﻴﺎﺕ ﺍﻟﻌﻼﻣﺔ ﺍﻟﻤﻮﺟﻮﺩﺓ ﻋﻠﻰ ﺍﻟﻮﺣﺪﺓ FDMRN20/25A - RR20/25A COMP COMP...
- Page 35 ﺍﻧﺠﺎﺯ ﺷﺒﻜﺔ ﺍﻻﻧﺎﺑﻴﺐ ﻭ ﺍﻟﺘﻮﺳﻴﻊ ﺍﻟﺘﻘﻨﻲ ﺍﻟﺸﻜﻞ ﻗﻄﻊ ﺍﻧﺒﻮﺏ ﺍﻟﻨﺤﺎﺱ ،ﻻ ﺗﺴﺘﻌﻤﻞ ﺃﻧﺎﺑﻴﺐ ﻧﺤﺎﺳﻴﺔ ﻣﻠﻮﺛﺔ ﺃﻭ ﻣﺘﻀﺮﺭﺓ. ﺇﺫﺍ ﺗﻢ ﻓﺘﺢ ﺃﻳﺔ ﺃﻧﺎﺑﻴﺐ • ﺕ ﺛﺎﻧﻴﺔ ﺃﻭ ﺃﻛﺜﺮ، ﻓﺎﻧﻪ ﻳﺠﺐ ﺗﻔﺮﻳﻎ ﺃﻭ ﺍﻟﻤﺒﺨﺮ ﺃﻭ ﺍﻟﻤﻜﺜﻒ ﻟﻤﺪﺓ ﺍﻟﻨﻈﺎﻡ. ﻋﺎﺩﺓ، ﻻ ﺗﻨﺰﻉ ﺍﻟﺒﻼﺳﺘﻚ، ﺍﻟﻘﻮﺍﺑﺲ ﺍﻟﻤﻄﺎﻃﻴﺔ ﻭﺍﻟﺼﻤﻮﻻﺕ ﺍﻟﻨﺤﺎﺳﻴﺔ...
- Page 36 ﺍﻟﻤﺴﺎﻓﺔ ﺍﻟﻔﺎﺭﻏﺔ ﻟﻠﺘﺮﻛﻴﺐ ﻳﺠﺐ ﺗﺮﻛﻴﺐ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺨﺎﺭﺟﻴﺔ ﺑﻤﺜﻞ ﻫﺬﻩ ﺍﻟﻄﺮﻳﻘﺔ، ﻟﻤﻨﻊ ﻗﺼﺮ ﺍﻟﺪﺍﺋﺮﺓ ﻟﻠﻬﻮﺍﺀ ﺍﻟﻤﻔﺮﻍ ﺍﻟﺤﺎﺭ ﺍﻭ ﺍﻋﺎﻗﺔ ﺍﻻﻧﺴﻴﺎﺏ ﺍﻟﺴﻬﻞ ﻟﻠﻬﻮﺍﺀ. ﻳﺮﺟﻰ ﺍﺗﺒﺎﻉ ﺍﻟﻤﺴﺎﻓﺔ ﺍﻟﻔﺎﺭﻏﺔ ﻟﻠﺘﺮﻛﻴﺐ ﻳﺮﺟﻰ ﺍﻟﺮﺟﻮﻉ ﺇﻟﻰ ﻣﺪﻯ ﺍﻟﺘﺸﻐﻴﻞ ﺍﻟﻤﻮﺿﺤﺔ ﻓﻲ ﺍﻟﺮﺳﻢ. ﺍﺧﺘﺮ ﺃﺑﺮﺩ ﻣﻜﺎﻥ ﻣﺤﺘﻤﻞ ﺑﺤﻴﺚ ﻻﺗﺰﻳﺪ ﺩﺭﺟﺔ ﺣﺮﺍﺭﺓ ﺍﻟﻬﻮﺍﺀ ﺍﻟﺪﺍﺧﻠﻲ ﻋﻦ ﺩﺭﺟﺔ ﺣﺮﺍﺭﺓ ﺍﻟﻬﻮﺍﺀ ﺍﻟﺨﺎﺭﺟﻲ ﺍﻟﻬﻮﺍﺀ...
- Page 37 ﻃﺮﯾﻘﺔ ﺗﻐﯿﯿﺮ ﺍﺗﺠﺎﻩ ﺭﻣﻲ ﺍﻟﻬﻮﺍﺀ ﺍﻟﻄﻠﻖ ١٠...
- Page 38 ﺗﺮﻛﻴﺐ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺨﺎﺭﺟﻴﺔ ﻋﻨﺪﻣﺎ ﺗﺮﺗﻔﻊ ﺩﺭﺟﺔ ﺣﺮﺍﺭﺓ ﺍﻟﺘﻜﺜﻴﻒ، ﺗﺮﺗﻔﻊ ﺩﺭﺟﺔ ﺣﺮﺍﺭﺓ ﺍﻟﺘﺒﺨﺮ ﻭﺗﻘﻞ ﻗﺪﺭﺓ ﺍﻟﺘﺒﺮﻳﺪ. ﻟﻠﺤﺼﻮﻝ ﻋﻠﻰ ﺃﻋﻠﻰ ﻗﺪﺭﺓ ﻟﻠﺘﺒﺮﻳﺪ، ﻳﺠﺐ ﺍﻥ ﻳﺘﻮﺍﻓﻖ ﺗﺮﻛﻴﺐ ﺍﻟﻮﺣﺪﺓ :ﺍﻟﺨﺎﺭﺟﻴﺔ ﻣﻊ ﺍﻟﻤﺘﻄﻠﺒﺎﺕ ﺍﻟﺘﺎﻟﻴﺔ ﻛﻤﺎ ﻓﻲ ﺑﻄﺮﻳﻘﺔ ﻻ ﺗﺴﻤﺢ ﻟﻠﻬﻮﺍﺀ ﺍﻟﺴﺎﺧﻦ ﺍﻟﺨﺎﺭﺝ ﻣﻦ ﻭﺣﺪﺓ ﺍﻟﺘﻜﺜﻴﻒ ﺍﻟﺨﺎﺭﺟﻴﺔ ﺑﺎﻟﺮﺟﻮﻉ ﻣﺮﺓ ﺛﺎﻧﻴﺔ ﻟﻠﺪﺍﺧﻞ ﻓﻲ...
- Page 39 ﻔﻴﺔ ﻓﻲ ﺍﻟﺴﻘﻒﺃﻋﻤﺎﻝ ﺃﻧﺎﺑﻴﺐ ﺍﻟﺘﺼﺮﻳﻒ ﺍ ﻭﺣﺪﺓ: ﻣﻢ .ﻳﺠﺐ ﺗﺮﻛﻴﺐ ﺃﻧﺒﻮﺏ ﺍﻟﺘﺼﺮﻳﻒ ﻛﻤﺎ ﻫﻮ ﻣﺒ ﻴ ﹼﻦ ﺍﻟﺮﺳﻢ )ﺍﻧﻈﺮ ﺍﻟﺮﺳﻢ ﻓﻲ ﺍﻷﻋﻠﻰ( ﻟﺘﺠ ﻨ ﹼﺐ ﺍﻟﻀﺮﺭ ﺍﻟﺬﻱ ﻳﻤﻜﻦ ﺃﻥ ﻳﻨﺘﺞ ﻋﻦ ﺍﻟﺘﺴﺮﺏ ﻭﺗﻜﺎﺛﻒ ﺍﻟﻤﺎﺀ • .ﻣﻦ ﺍﺟﻞ ﻧﺘﺎﺋﺞ ﺃﻓﻀﻞ، ﺍﺣﺘﻔﻆ ﺑﺎﻷﻧﺎﺑﻴﺐ ﺑﺄﻗﺼﺮ ﻣﺎ ﻳﻤﻜﻦ. ﻣ ﻴ ﹼﻞ ﺍﻷﻧﺎﺑﻴﺐ ﻋﻠﻰ ﺯﺍﻭﻳﺔ ﻟﺘﺤﺴﻴﻦ ﺍﻟﺘﺪﻓﻖ •...
- Page 40 ﺃﻧﻈﺮ ﺍﻟﺮﺳﻢ ﺍﺩﻧﺎﻩ ﺿﻊ ﺍﻟﻤﺤﻮﺭ ﻓﻲ ﺍﻟﻤﻨﺘﺼﻒ ﻭ ﻓ ﹼﺮ ﻓﺴﺤﺔ ﻓﺮﺍﻍ ﻟﺘﺴﻬﻴﻞ ﺍﻋﻤﺎﻝ ﺍﻟﺼﻴﺎﻧﺔ ﻭﺍﻧﺴﻴﺎﺏ ﺍﻓﻀﻞ ﻟﻠﻬﻮﺍﺀ ﻛﻤﺎ .ﻫﻮ ﻣﻮﺿﺢ ﻓﻲ ﺍﻟﺮﺳﻢ ﺍﻟﺘﺨﻄﻴﻄﻲ ﻟﻠﻄﺮﺍﺯ 20A/25A/30A/36A/50A ﻣﻢ ﺃﻭ ﺃﻛﺜﺮ ﻣﻢ* ﺃﻭ ﺃﻛﺜﺮ ﺍﻟﺴﻘﻒ ﻣﻢ ﺃﻭ ﺃﻛﺜﺮ 2300 ﺍﻻﺭﺽ .ﻣﻢ ﺇﺫﺍ ﻛﺎﻥ ﺍﻟﺴﻘﻒ ﻗﺎﺑﻞ ﻟﻠﻨﺰﻉ ﻳﻤﻜﻦ...
- Page 41 ﻣﺨﻄﻂ ﺍﻟﺘﺮﻛﻴﺐ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺪﺍﺧﻠﻴﺔ ﻋﻼﻗﺔ ﻗﻨﺎﺓ ﺍﻟﺮﺟﻮﻉ ﻗﻨﺎﺓ ﺍﻟﺘﺰﻭﻳﺪ ﻟﻒ ﺍﻷﻧﺎﺑﻴﺐ ﺍﻟﻤﻌﺰﻭﻟﺔ ﺑﺸﺮﻳﻂ ﻧﻬﺎﺋﻲ ﻣﻦ ﺍﻷﺳﻔﻞ ﺇﻟﻰ ﺍﻷﻋﻠﻰ ﺃﻧﺒﻮﺏ ﺍﻟﺘﺼﺮﻳﻒ ﺍﻟﻌﺰﻝ ﺍﻟﺤﺮﺍﺭﻱ ﻣﺪﺧﻞ ﺍﻟﻬﻮﺍﺀ ﻣﺪﺧﻞ ﺍﻟﻬﻮﺍﺀ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺨﺎﺭﺟﻴﺔ ﺗﺼﺮﻳﻒ ﺍﻟﻬﻮﺍﺀ ﺗﺮﻛﻴﺐ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺪﺍﺧﻠﻴﺔ ﻳﺠﺐ ﺗﺮﻛﻴﺐ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺪﺍﺧﻠﻴﺔ ﺑﺤﻴﺚ ﻻﻳﻤﻜﻦ ﻗﺼﺮ ﺩﺍﺋﺮﺓ ﺗﻔﺮﻳﻎ ﺍﻟﺘﺒﺮﻳﺪ. ﺗﻘﻴﺪ ﻣﺎﺩﺓ...
- Page 42 ﻛﺘﻴﺐ ﺍﻟﺘﺮﻛﻴﺐ ﻳﺰﻭﺩﻙ ﻫﺬﺍ ﺍﻟﻜﺘﻴﺐ ﺑﻄﺮﻕ ﺍﻟﺘﺮﻛﻴﺐ ﻟﻀﻤﺎﻥ ﺍﻟﺘﺸﻐﻴﻞ ﺍﻟﻌﺎﺩﻱ ﺍﻟﺠﻴﺪ ﻭﺍﻟﻤﺄﻣﻮﻥ ﻟﻮﺣﺪﺓ ﻣﻜﻴﻔﺔ ﺍﻟﻬﻮﺍﺀ. ﻗﺪ ﻳﻜﻮﻥ ﻣﻦ ﺍﻟﻀﺮﻭﺭﻱ ﺍﺟﺮﺍﺀ ﺿﺒﻂ .ﺧﺎﺹ ﻟﻜﻲ ﻳﻼﺋﻢ ﻣﺘﻄﻠﺒﺎﺗﻚ .ﻗﺒﻞ ﺍﺳﺘﻌﻤﺎﻝ ﻣﻜﻴﻔﺔ ﺍﻟﻬﻮﺍﺀ، ﻳﺮﺟﻰ ﻗﺮﺍﺀﺓ ﻛﺘﻴﺐ ﺍﻟﺘﻌﻠﻴﻤﺎﺕ ﻫﺬﺍ ﺑﻌﻨﺎﻳﺔ ﻭﺍﻻﺣﺘﻔﺎﻅ ﺑﻪ ﻟﻠﻤﺮﺍﺟﻌﺔ ﻓﻲ ﺍﻟﻤﺴﺘﻘﺒﻞ ﻫﺬﺍ...
- Page 43 ﺍﻟﻮﺣﺪﺓ ﺍﻟﺨﺎﺭﺟﻴﺔ [RR] ﺟﻤﻴﻊ ﺍﻷﺑﻌﺎﺩ ﻫﻲ ﺑﺎﻟﻤﻠﻴﻤﺘﺮ ﻣﻢ ﺍﻷﺑﻌﺎﺩ ﻃﺮﺍﺯ 1006 1067 ٤...
- Page 44 ﺍﻟﻮﺣﺪﺓ ﺍﻟﺨﺎﺭﺟﻴﺔ [RR] ﺟﻤﻴﻊ ﺍﻷﺑﻌﺎﺩ ﻫﻲ ﺑﺎﻟﻤﻠﻴﻤﺘﺮ ﻣﻢ ﺍﻷﺑﻌﺎﺩ ﻃﺮﺍﺯ 1030 ﺍﻟﻮﺣﺪﺓ ﺍﻟﺨﺎﺭﺟﻴﺔ [RR] ﺟﻤﻴﻊ ﺍﻷﺑﻌﺎﺩ ﻫﻲ ﺑﺎﻟﻤﻠﻴﻤﺘﺮ ﻣﻢ ﺍﻟﻤﻨﻈﺮ ﺍﻟﻌﻠﻮﻱ ﺍﻟﻤﻨﻈﺮ ﺍﻟﺠﺎﻧﺒﻲ ﺍﻟﻤﻨﻈﺮ ﺍﻷﻣﺎﻣﻲ ﺍﻟﻤﻨﻈﺮ ﺍﻟﺠﺎﻧﺒﻲ ﺍﻷﺑﻌﺎﺩ ﻃﺮﺍﺯ 1030 ٣...
- Page 45 ﺍﻟﻮﺣﺪﺓ ﺍﻟﺪﺍﺧﻠﻴﺔ [FDMRN] ﺟﻤﻴﻊ ﺍﻷﺑﻌﺎﺩ ﻫﻲ ﺑﺎﻟﻤﻠﻴﻤﺘﺮ ﻣﻢ ﺍﻷﺑﻌﺎﺩ ﻃﺮﺍﺯ 1148 1264 1372 ﺍﻟﻮﺣﺪﺓ ﺍﻟﺨﺎﺭﺟﻴﺔ [RR] ﺟﻤﻴﻊ ﺍﻷﺑﻌﺎﺩ ﻫﻲ ﺑﺎﻟﻤﻠﻴﻤﺘﺮ ﻣﻢ ﺍﻷﺑﻌﺎﺩ ﻃﺮﺍﺯ 20/25A ٢...
- Page 46 ﺍﻟﺮﺳﻢ ﺍﻟﺘﺨﻄﻴﻄﻲ ﻭﺍﻷﺑﻌﺎﺩ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺪﺍﺧﻠﻴﺔ [FDMRN] ﺟﻤﻴﻊ ﺍﻷﺑﻌﺎﺩ ﻫﻲ ﺑﺎﻟﻤﻠﻴﻤﺘﺮ ﻣﻢ ﺍﻷﺑﻌﺎﺩ ﻃﺮﺍﺯ 1200 1097 1137 1176 ﺍﻟﻮﺣﺪﺓ ﺍﻟﺪﺍﺧﻠﻴﺔ [FDMRN] ﺟﻤﻴﻊ ﺍﻷﺑﻌﺎﺩ ﻫﻲ ﺑﺎﻟﻤﻠﻴﻤﺘﺮ ﻣﻢ ﺍﻷﺑﻌﺎﺩ ﻃﺮﺍﺯ 1030 1076 1115 25/30A 1287 1326 1369 1487 1526 1569 ١...
- Page 48 ﻛﺘﻴﺐ ﺍﻟﺘﺮﻛﻴﺐ ﺍﻟﺴﻠﺴﻠﺔ ﺍﻟﻤﻨﻔﺼﻠﺔ R410A ﻃﺮﺍﺯ ﻋﺮﺑﻲ ﻛﺘﻴﺐ ﺍﻟﺘﺮﻛﻴﺐ RR20AV1K FDMRN20AV1K ﺍﻟﺴﻠﺴﻠﺔ ﺍﻟﻤﻨﻔﺼﻠﺔ R410A RR25AV1K FDMRN25AV1K RR30AV1K FDMRN30AV1K RR36AV1K FDMRN36AV1K RR36AY1K FDMRN36AV1K RR50AY1K9 FDMRN50AV1K9 RR60AY1K FDMRN60AV1K RR20AV1KU FDMRN20AV1KU RR20AV1KRE RR25AV1KU FDMRN25AV1KU RR25AV1KRE RR30AV1KU FDMRN30AV1KU RR30AV1KRE RR36AV1KU FDMRN36AV1KU RR50AY1KU FDMRN50AV1KU RR60AY1KU...
