  • Page 2: Important Safeguards

    Tornado F1 Upright Vacuum FLR00049 User Manual IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed. These instructions should be saved for future reference: • Read and familiarise yourself with all operating instructions before using this Vacuum Cleaner.
  • Page 3 Tornado F1 Upright Vacuum FLR00049 User Manual • If the power cable is damaged, it should only be replaced by the manufacturer or a suitable qualified after-sales-service in order to avoid a hazard • Do not allow the mains cable to hang over sharp edges or come in contact with hot surfaces.

  • Page 4: Description Of Parts

    Tornado F1 Upright Vacuum FLR00049 User Manual Description of parts Handle Cable clip Handle pole Hose Hose hook Cylinder release button Suction pressure release valve Cylinder lid Hose anti Cylinder Upper cable topple ring storage hook Filter assembly Crevice and...
  • Page 5 Tornado F1 Upright Vacuum FLR00049 User Manual Assembly Insert the screw (supplied) Align the handle pole with using a pozidrive screwdriver the top of the vacuum (not supplied) and tighten. body and insert until the screw hole in the body aligns with the screw hole in the pole.
  • Page 6 Tornado F1 Upright Vacuum FLR00049 User Manual Unravel the cable from the storage hooks. To do this simply rotate the upper storage hook through 180 degrees and pull the cable away, then unhook from the lower cable hook. Insert the plug into a suitable socket...
  • Page 7 Using the hose and pet brush For difficult to remove soiling on upholstery such as pet hairs, the pet brush can be used. This should be fitted onto the hose as shown above. The fixed combs and rotating pneumatic brush clean up even the most stubborn or matted hairs.
  • Page 8 Tornado F1 Upright Vacuum FLR00049 User Manual Using the hose and multi tool Remove the end of the hose from the hose connector by twisting anti clockwise and pulling upwards Attach the multi tool to the hose by simply sliding onto the end of...
  • Page 9 Tornado F1 Upright Vacuum FLR00049 User Manual To retract the uphostery brush, push the button on the side of the tool and push the brush back Note: To improve stability of the vacuum cleaner when using the hose, hook the hose anti topple...
  • Page 10 Tornado F1 Upright Vacuum FLR00049 User Manual Emptying the cylinder To release the cylinder from the main body of the vacuum cleaner, press the cylinder release button at the top of the cylinder and pull the cylinder away from the top.
  • Page 11 Tornado F1 Upright Vacuum FLR00049 User Manual Cleaning the filters Cylinder HEPA filter Remove the cylinder from the vacuum cleaner as described on the previous page. Rotate the cylinder lid anti clockwise while holding on to the cylinder body and pull the cylinder head and filter assembly away.
  • Page 12 Tornado F1 Upright Vacuum FLR00049 User Manual Once all parts are thoroughly dry, reassemble the cylinder. Place the HEPA filter back into the filter assembly and re-attach the filter assembly to the cylinder lid. Ensure all parts click back into place by...
  • Page 13 Tornado F1 Upright Vacuum FLR00049 User Manual Sponge filter To access the sponge filter, remove the cylinder and empty. The filter is located at the base of the filter assembly. With your thumb and forefinger, pinch the filter and pull out towards you.
  • Page 14 Tornado F1 Upright Vacuum FLR00049 User Manual Changing the belt NOTE: Before starting any maintenance on the belt, ensure the vacuum is switched off and disconnected from the mains supply. Lay the vacuum on the floor face down so the base can be accessed.
  • Page 15 Tornado F1 Upright Vacuum FLR00049 User Manual Remove the brushroll from the vacuum casing Hook the replacement belt over the motor spindle and over the brushroll. Ensure the belt sits in the middle section in between the two grooves on the brushroll.
  • Page 16 Tornado F1 Upright Vacuum FLR00049 User Manual Clearing blockages Ensure the upright vacuum is turned off and disconnected from the mains supply before checking for blockages. The upright vacuum would only become blocked if the cylinder is full (Beyond the MAX level), the filters are clogged or a large object has been sucked up.

  • Page 17: Troubleshooting

    Tornado F1 Upright Vacuum FLR00049 User Manual Troubleshooting Problem Possible cause Solution Unit fails to turn on. The unit may not be Ensure the plug is fully properly plugged in inserted into the sock- or the fuse may have et and the socket is tripped.

  • Page 18: Electrical Connections

    Tornado F1 Upright Vacuum FLR00049 User Manual Electrical Connections This appliance is fitted with a fused three-pin plug to BS 1363. If the plug has to be removed, it should be cut off and carefully disposed of immediately. To avoid a possible shock hazard, do not insert the discarded plug into a mains socket.
  • Page 19 Tornado F1 Upright Vacuum FLR00049 User Manual Technical data Voltage 220-240V AC 50Hz Rated power 750 W Sound level 77dB Model No. FLR00049 Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with...

  • Page 20: Warranty

    As part of our commitment to quality we are o ering you an extra 2 years warranty in addition to your 1 year guarantee. Your Daewoo vacuum product is guaranteed for 1 year from the date of original purchase, with proof of purchase or receipt. If any defects should arise due to faulty workmanship or material, your faulty vacuum should be returned to the place of purchase, replacement or refund is at the discretion of the retailer.
