Vespa would like to thank you
for choosing one of its products. We have prepared this manual to help you to get the very best from your vehicle. Please read it carefully before riding
the vehicle for the first time. It contains information, tips and precautions for using your vehicle. It also describes features, details and devices to assure
you that you have made the right choice. We believe that if you follow our suggestions, you will soon get to know your new scooter and it will serve you
well for a long time to come. This booklet forms an integral part of the vehicle; should the vehicle be sold, it must be transferred to the new owner.
VESPA PRIMAVERA 50 2T
Ed. 03_11/2013

Advertisement

Table of Contents
loading

Related Manuals for VESPA PRIMAVERA 50 2T 2013

Summary of Contents for VESPA PRIMAVERA 50 2T 2013

  • Page 1 Vespa would like to thank you for choosing one of its products. We have prepared this manual to help you to get the very best from your vehicle. Please read it carefully before riding the vehicle for the first time. It contains information, tips and precautions for using your vehicle. It also describes features, details and devices to assure you that you have made the right choice.
  • Page 2 The instructions given in this manual are intended to provide a clear, simple guide to using your vehicle; this booklet also details routine maintenance procedures and regular checks that should be carried out on the vehicle at an authorised Dealer or Service Centre. The booklet also contains instructions for simple repairs.
  • Page 3 Personal safety Failure to completely observe these instructions will result in serious risk of personal injury. Safeguarding the environment Sections marked with this symbol indicate the correct use of the vehicle to prevent dam- aging the environment. Vehicle intactness The incomplete or non-observance of these regulations leads to the risk of serious damage to the vehicle and sometimes even the invalidity of the guarantee.

  • Page 5: Table Of Contents

    INDEX VEHICLE..................MAINTENANCE................37 Dashboard................Hub oil level................38 Analogue instrument panel............Tyres..................39 Digital lcd display..............11 Spark plug dismantlement............40 Setting the hour/minutes function.......... 12 Removing the air filter............... 41 *MODE* button..............13 Secondary air system............... 42 Keyswitch.................. 13 Checking the brake oil level............

  • Page 7: Vehicle

    VESPA PRIMAVERA 50 2T Chap. 01 Vehicle...

  • Page 8: Dashboard

    Dashboard (01_01) 01_01...

  • Page 9: Analogue Instrument Panel

    A = Ignition switch B = Horn button C = Turn indicator switch D = Rear brake lever E = Light switches F = Instrument panel G = Front brake lever H = Throttle grip I = MODE button L = Start-up button Analogue instrument panel (01_02)
  • Page 10 01_02 A = Speedometer B = Turn indicator warning light...

  • Page 11: Digital Lcd Display

    C = Fuel reserve warning light D = Digital display E= Mixer low oil warning light F = High-beam warning light Digital lcd display (01_03) G = Fuel gauge with petrol symbol H = Total and partial odometer I = Clock 01_03 By turning the ignition key to the «ON»...

  • Page 12: Setting The Hour/Minutes Function

    - press the MODE button; - Holding in the MODE button, turn the key to the «ON» position; - after about 2 seconds release the MODE button. N.B. THE NAVIGATION OF THE DISPLAY DEFINES: - «SHORT PRESS»: PRESSING THE BUTTON INDICATED FOR LESS THAN TWO SECONDS;...

  • Page 13: Mode* Button

    WARNING DISCONNECTING THE BATTERY CABLES WILL RESULT IN A RESET OF THE CLOCK WHICH WILL INDICATE "12:00" UNTIL THE TIME IS SET AGAIN. *MODE* button (01_05) With the vehicle on or with the key in the «ON» position, short press the MODE button «I», to change the odometer display (TOTAL, TRIP A, TRIP B).

  • Page 14: Locking The Steering Wheel

    Locking the steering wheel (01_07) Turn the handlebar to the left (as far as it will go), turn the key to «LOCK» and remove the key. CAUTION NEVER TURN THE KEY TO «LOCK» OR «OFF» WHILE RIDING. 01_07 Releasing the steering wheel (01_08) Reinsert the key and turn it to «OFF».

  • Page 15: Switch Direction Indicators

    Switch direction indicators (01_09) The left turn indicators turn on by moving the turn indicator switch «C» to the left, to position «1». The right turn indicators turn on by moving the switch «C» to the right, to position «2». The turn indicator switch «C»...

  • Page 16: Light Switch

    Light switch (01_11) When the light switch «E» is set to «1», the low-beam light is on. When set to «2», the high-beam light is activated. CAUTION DO NOT PLACE, TRANSPORT OBJECTS AND/OR CLOTHES OVER THE FRONT HEADLIGHT ASSEMBLY, WHEN THE HEADLIGHT IS TURNED ON OR OFF. 01_11 FAILURE TO FOLLOW THIS PRECAUTION MAY CAUSE OVERHEATING AND THE SUBSEQUENT FUSION OF THE GLASS.

  • Page 17: Fuel Tank

    Fuel tank (01_13) The fuel tank cap «A» is under the saddle. To reach it, tip the saddle forwards. CAUTION DURING THE FUEL REFUELLING, AVOID THE USE OF ELECTRONIC DEVICES AND/OR CELLULAR PHONES, WHICH MAY CAUSE FIRE FROM FUEL VA- POURS WITH POSSIBLE DAMAGE TO OBJECTS AND/OR PERSONAL INJU- 01_13 RIES.

  • Page 18: Mixture Oil Reservoir

    THIS IS NOT A MALFUNCTION BUT IS RATHER THE NORMAL BEHAVIOUR OF VALVES WHICH ARE PRESENT ON THE VEHICLE. Mixture oil reservoir (01_14) The oil mix tank cap «B» is under the saddle. To reach it, insert the key into the saddle lock, turn it anticlockwise and tip the saddle forwards.

  • Page 19: Opening The Side Panels

    Opening the side panels (01_16, 01_17, 01_18) To remove the front cover, proceed as follows: - remove the clip-on badge, paying attention to the vehicle bodyworks. 01_16 - Undo the fixing screw. - Turn the handlebar until the end of one side. - Remove the front cover towards the base, releasing the housing tongues.

  • Page 20: Keys

    Keys (01_19) The vehicle is supplied with two keys (one spare) which serve to start the engine and unlock the saddle compartment. The keys are accompanied by a tag marked with the identification code to be quoted when ordering duplicates. WARNING WE RECOMMEND KEEPING THE DUPLICATE KEY TOGETHER WITH ITS CODE IN A SAFE PLACE AND NOT ON THE VEHICLE...

  • Page 21: Rear Top Box Opening

    Chassis number The chassis number «A» is stamped near the fuel tank. To read it, proceed as follows: - lift the saddle; - lift the helmet compartment by removing it. 01_20 Engine number The engine number «B» is stamped near the rear left shock absorber lower support. 01_21 Rear top box opening (01_22) With the key in position «OFF»...

  • Page 22: Bag Clip

    Bag clip (01_23) The bag hook is placed on the saddle end. To use the hook, slide it off from the front. Maximum applicable load: 1.5 kg 01_23 FOR THE USER SAFETY, THE DIMENSIONS OF THE LOAD SHOULD NOT BE EXCEEDED BY THE PERIMETER OF THE VEHICLE OR PREVENT AT ALL THE RIDING.

  • Page 23: Use

    VESPA PRIMAVERA 50 2T Chap. 02...

  • Page 24: Checks

    Checks (02_01) Before using the vehicle, check: 1.That the petrol tank and the oil reservoir are full. 2.Rear hub oil level. 3.That the tyres are properly inflated. 4.The correct functioning of headlights, rear light and turn indicators. 5.The correct functioning of front and rear brakes. 02_01 6.The fluid level in the brake pump reservoir.
  • Page 25 CAUTION DO NOT BRING NAKED FLAMES OR CIGARETTES NEAR THE MOUTH OF THE FUEL TANK: FIRE HAZARD. ALSO AVOID INHALING HARMFUL VAPOURS. IMPORTANT: NEVER EMPTY THE MIXER OIL RESERVOIR. 02_03 CAUTION THE USE OF OILS AND SPARK PLUGS OTHER THAN THOSE RECOMMENDED CAN SHORTEN THE LIFE OF THE ENGINE.
  • Page 26 CAUTION DURING THE REFUELLING, AVOID FUEL LEAKAGE WHICH MAY CAUSE DAM- AGE TO OBJECTS AND/OR PERSONAL INJURIES AND FIRE HAZARD. Recommended products eni i-Ride PG 2s Synthetic based lubricant for low smoke 2-stroke engines and additives. API TC - JASO FC - ISO-L-EGD Characteristic Fuel tank capacity 6.4 ±...

  • Page 27: Tyre Pressure

    Tyre pressure (02_04) Check tyre pressure as indicated in the scheduled maintenance table. CAUTION TYRE PRESSURE SHOULD BE CHECKED WHEN TYRES ARE COLD.INCOR- RECT TYRE PRESSURE CAUSES ABNORMAL TYRE WEAR AND MAKES RID- ING DANGEROUS. 02_04 TYRES MUST BE REPLACED WHEN THE TREAD REACHES THE WEAR LIMITS SET FORTH BY LAW.

  • Page 28: Running In

    Running in (02_05) WARNING DURING THE FIRST 1000 KM DO NOT RIDE THE VEHICLE OVER 80% OF ITS MAXIMUM SPEED. AVOID TWISTING THE THROTTLE GRIP FULLY OR KEEP- ING A CONSTANT SPEED ALONG LONG SECTIONS OF ROAD. AFTER THE FIRST 1000 KM, GRADUALLY INCREASE SPEED UNTIL REACHING THE MAX- IMUM PERFORMANCE.
  • Page 29 CAUTION DUE TO THE HIGH TEMPERATURES THE CATALYTIC CONVERTER CAN REACH, ALWAYS TAKE CARE, WHEN PARKING THE VEHICLE, THAT THE SI- LENCER DOES NOT COME INTO CONTACT WITH FLAMMABLE MATERIALS, TO AVOID SERIOUS BURNS. 02_07 02_08 02_09...

  • Page 30: Difficult Start Up

    Difficult start up (02_10) If there is a problem you can follow the instructions below: 1. Flooded engine Place the vehicle on its centre stand and check that the rear wheel is off the ground. Open the throttle fully and press the starter button for five seconds and then stop for five seconds.

  • Page 31: Stopping The Engine

    Stopping the engine (02_11) After having stopped the vehicle, with the accelerator throttle grip fully closed, turn the key to OFF (removable key). CAUTION DUE TO THE HIGH TEMPERATURES THAT CAN BE REACHED IN THE CATA- LYTIC CONVERTER, WHEN PARKING THE VEHICLE, PAY ATTENTION TO THE 02_11 MUFFLER: TO AVOID SERIOUS BURNS OR FIRE, THE MUFFLER SHOULD NEV- ER COME INTO CONTACT WITH FLAMMABLE MATERIALS.

  • Page 32: Stand

    CAUTION DUE TO THE HIGH TEMPERATURES THAT CAN BE REACHED IN THE CATA- LYTIC CONVERTER, WHEN PARKING THE VEHICLE, PAY ATTENTION TO THE MUFFLER: TO AVOID SERIOUS BURNS OR FIRE, THE MUFFLER SHOULD NEV- ER COME INTO CONTACT WITH FLAMMABLE MATERIALS. Stand (02_13) Centre stand Push with your foot on the centre stand's fork "A"...

  • Page 33: Automatic Transmission

    Automatic transmission (02_14) To ensure simple, pleasurable riding, the vehicle is equipped with automatic trans- mission with regulator and centrifugal clutch. The system is designed to give the best possible performance in terms of both acceleration and consumption, on level ground and uphill, thanks to the adjustments made to engine speed and transmitted torque.
  • Page 34 5. Avoid riding off by mounting the scooter when it is resting on its support. In any case, in order to avoid abrupt departures, the rear wheel should not be turning when in comes into contact with the ground. 6. If the vehicle is used on roads covered with sand, mud, snow mixed with salt, etc., clean the brake disc frequently with a mild detergent in order to prevent abrasive par- ticles from building up inside the holes, which can result in early brake pad wear.
  • Page 35 ACCESSORIES AND LUGGAGE CAN REDUCE YOUR SCOOTER STABILITY AND PERFORMANCE, AS WELL AS THE LEVEL OF SAFETY DURING USE. (SEE THE «SPARE PARTS AND ACCESSORIES» SECTION)

  • Page 37: Maintenance

    VESPA PRIMAVERA 50 2T Chap. 03 Maintenance...

  • Page 38: Hub Oil Level

    Hub oil level (03_01, 03_02, 03_03) To check the hub oil level, proceed as follows: 1. Place the vehicle on its stand on a level surface; 2. Unscrew the oil dipstick «A», dry it with a clean rag and then reinsert it, screwing it tightly into place;...

  • Page 39: Tyres

    Lubricant for gearboxes and transmissions. API GL-4 Characteristic Transmission oil 80 cm³ Tyres (03_04) Periodically check the inflation pressure of each tyre (when cold). Tyres are fitted with wear indicators; tyres should be replaced as soon as these indi- cators become visible on the tyre tread. Also check that the tyres do not show signs of splitting at the sides or irregular tread wear;...

  • Page 40: Spark Plug Dismantlement

    TYRE INFLATION PRESSURE Front tyre pressure 1.6 bar Rear tyre pressure 1.8 bar Spark plug dismantlement (03_05, 03_06) Removal In order to inspect the spark plug, follow the operation described when the engine is cold: - Slide off the spark plug inspection cover «A» by unscrewing the screw «B». - Slide off the spark plug tube «C».

  • Page 41: Removing The Air Filter

    CAUTION THE SPARK PLUG MUST BE REMOVED WHEN THE ENGINE IS COLD. USING IGNITION ELECTRONIC CENTRAL UNITS OR SPARK PLUGS OTHER THAN THE TYPES PRESCRIBED (SEE «TECHNICAL DATA» SECTION) CAN CAUSE SERIOUS DAMAGE TO THE ENGINE. CAUTION PROCEED WITH CAUTION. DO NOT DAMAGE THE TONGUES OR THEIR SEATS.

  • Page 42: Secondary Air System

    Secondary air system (03_07) Remove the two screws «A» from the aluminium SAS cover. Release the metal tube from the rubber housing on the cover without extracting the tube from the cover/sleeve. Remove the tab and plastic cover, extract the sponge and wash it in water and soap. Dry it with compressed air before refitting it, making sure to correctly fit the tab in the housing on the two plastic and aluminium covers.

  • Page 43: Braking System Fluid Top Up

    Braking system fluid top up (03_09, 03_10, 03_11, 03_12) To access the brake fluid tank, the upper handlebar cover must be removed, proceed as follows: - Remove the rear-view mirrors. - Remove on both sides of the vehicle the screw «A» fixing the surround of the head- light assembly.
  • Page 44 - Remove the tank cover «D» after sliding off the two fixing screws «E». - Refill with the prescribed brake fluid type only, paying attention not to exceed the maximum allowed level and indicated by the inspection sight glass. Under standard climatic conditions, replace fluid as indicated in the scheduled main- tenance table.

  • Page 45: Battery

    FITTING To fit the removed components to access the brake fluid tank, work in reverse order what is described in the instructions of this paragraph. Battery (03_13, 03_14) To access the battery, it is necessary to proceed as follows: - Undo the four screws «A» and remove the rubber cover at the centre of the footrest. - Remove the battery fixing bracket by unscrewing the two screws «B».

  • Page 46: Use Of A New Battery

    CAUTION IN ORDER TO AVOID DAMAGING THE ELECTRICAL SYSTEM, NEVER DISCON- NECT THE WIRING WHILE THE ENGINE IS RUNNING. DO NOT TIP THE VEHICLE TOO MUCH IN ORDER TO AVOID DANGEROUS LEAKAGE OF THE BATTERY ELECTROLYTE. Use of a new battery (03_15) To install a new battery: -Place the battery in its housing.

  • Page 47: Checking The Electrolyte Level

    Characteristic Battery 12 V / 4 Ah Checking the electrolyte level The electrolyte level, which should be checked regularly, must always be at the max- imum level. To reach this level, use only distilled water. Should it become necessary to top up the battery with water too frequently, check the vehicle's electrical system because the battery is being overloaded, causing it to lose power quickly.
  • Page 48 - Take your vehicle to a garage (as indicated in the «Vehicle not used for extended periods» section) to have the battery removed. Have the battery cleaned, charged fully and stored in a dry, ventilated place. Recharge at least once every two months.

  • Page 49: Fuses

    Fuses (03_17) The electrical system is protected by a fuse valve «A» located in the battery compart- ment. Before replacing a blown fuse, find and solve the problem that caused it to blow. Do not replace the fuse with any alternative form of conductor Electric characteristic Fuse 10 A...
  • Page 50 IFICATIONS OF THE SYSTEM CAN CAUSE MALFUNCTIONING AND RISK OF FIRE. CAUTION PROCEED WITH CAUTION. DO NOT DAMAGE THE TONGUES OR THEIR SEATS. HANDLE THE PAINTED AND PLASTIC COMPONENTS CAREFULLY. DO NOT SCRATCH OR DAMAGE THEM. BULBS High/low beam light bulb Type: Halogen (HS1) Power: 12V - 35/35W Quantity: 1...

  • Page 51: Front Light Group

    Power: 12V - 6W Quantity: 1 RHS + 1 LHS Rear turn indicator light bulb Type: Halogen, BAZ9s base, Amber Power: 12V - 6W Quantity: 1 RHS + 1 LHS Front light group (03_18, 03_19, 03_20, 03_21, 03_22) To access the bulb of the front headlight assembly, the upper handlebar cover must be removed, proceed as follows: - Remove the rear-view mirrors.
  • Page 52 - Remove the two screws «C». - Detach the upper handlebar cover, complete with instrument panel, from the lower one, supporting it on the leg shield back plate and paying attention to the instrument panel connector. 03_20 HIGH/LOW BEAM LIGHT BULB - Disconnect, by sliding the electric connector off.

  • Page 53: Head Light Adjustment

    A COMMON PHENOMENON AND IS ATTRIBUTABLE TO HUMIDITY AND/OR TO LOW TEMPERATURES; DOES NOT SHOW FAILURE. THE PRESENCE OF DROPS OF WATER, ON THE OTHER HAND, COULD INDI- CATE THAT WATER IS INFILTRATING. CONTACT AN AUTHORISED SERVICE CENTRE. CAUTION DO NOT PLACE, TRANSPORT OBJECTS AND/OR CLOTHES OVER THE FRONT HEADLIGHT ASSEMBLY, WHEN THE HEADLIGHT IS TURNED ON OR OFF.

  • Page 54: Front Direction Indicators

    03_24 Front direction indicators (03_25, 03_26) To replace the bulbs: - Open the front case and remove the rubber cap «A». 03_25 - Take out the bulb holder «B» from its fitting by turning it anticlockwise. - Press the bulb, turn it anticlockwise and then take it out. To refit, proceed in reverse order.

  • Page 55: Rear Optical Unit

    Rear optical unit (03_27, 03_28, 03_29) To replace the taillight bulb: - Remove the knob-type head «A» fixing the rear headlight assembly, can be reached from the wheel housing on the left side of the vehicle. - Slide off the headlight assembly by pulling it towards the base and releasing the two upper fixings.

  • Page 56: Rear Turn Indicators

    Rear turn indicators (03_30, 03_31) To replace the bulbs: - remove the turn indicator from its seat by undoing the screw «A». 03_30 - Take out the bulb holder «B» from its fitting by turning it anticlockwise. - Press the bulb, turn it anticlockwise and then take it out. To refit, proceed in reverse order.

  • Page 57: Rear-View Mirrors

    Rear-view mirrors (03_32, 03_33) The mirrors can be set to the desired position by adjusting the mirror frame. 03_32 To remove the rear view mirror, lift the rubber protection, unscrew the lock nut «A» slightly to unlock the stem. Unscrew the stem «B» until removing it. CAUTION DO NOT ADJUST THE MIRRORS WHILE RIDING.

  • Page 58: Front Disc Brake

    If the adjustment in these conditions is difficult, contact an Authorised Service Cen- tre. CAUTION WHEN ADJUSTING IDLE SPEED, BE CAREFUL NOT TO TOUCH HOT PARTS OF THE ENGINE TO AVOID BURNS. Characteristic Engine idle speed 1,800 ± 100 rpm Front disc brake (03_35) The brake disc and pad wear is automatically compensated, therefore it has no effect on the functioning of the front and rear brakes.

  • Page 59: Rear Drum Brake

    CAUTION HAVE THE BRAKE PADS CHECKED BY THE DEALER ACCORDING TO THE CHECKS SPECIFIED IN THE SCHEDULED MAINTENANCE TABLE. HOWEVER, IN THE EVENT OF NOISES COMING FROM THE FRONT AND/OR REAR BRAK- ING SYSTEM DURING OPERATION, IT IS ADVISABLE TO HAVE THE BRAKING SYSTEM CHECKED BY AN AUTHORISED SERVICE CENTRE OR DEALER.

  • Page 60: Puncture

    Puncture (03_37) The vehicle is equipped with Tubeless tyres (without inner tube). In the event of a puncture, Tubeless tyres - unlike tyres with inner tubes - go flat very slowly, resulting in a greater steering safety. In the event of a puncture, an emergency repair can be carried out using an "inflate and repair"...

  • Page 61: Cleaning The Vehicle

    Recommended products eni i-Ride PG 2s Synthetic based lubricant for low smoke 2-stroke engines and additives. API TC - JASO FC - ISO-L-EGD Cleaning the vehicle Use a low pressure jet of water to soften the caked dirt and mud deposited on the painted surfaces.
  • Page 62 • DO NOT USE HIGH-PRESSURE WATER JETS. • DO NOT STEAM WASH. • DO NOT AIM THE JET AT: THE ENGINE, THE WIRING, THE COOLING SLITS ON THE TRANSMISSION OR SCROLL COVERS. CAUTION NEVER WASH THE SCOOTER IN DIRECT SUNLIGHT, ESPECIALLY IN SUMMER WHEN THE BODYWORK IS STILL HOT AS THE SHAMPOO COULD DAMAGE THE PAINTWORK IF IT DRIES BEFORE BEING RINSED OFF.
  • Page 63 Filters, jets or carburettor body Contact an Authorised Service dirty or clogged. Centre. Insufficient battery charge Kick-start. Recharge the battery. GNITION PROBLEMS No spark from spark plug. Due to Make sure the electrodes are the presence of high voltage, this properly adjusted.
  • Page 64 INEFFICIENT BRAKING Oil on drum or disc. Worn Pads/ Contact an Authorised Service Shoes Centre incorrect rear brake adjustment Adjust INEFFICIENT SUSPENSION Oil leak; worn limit switch bumpers; Contact an Authorised Service worn shock absorber attachment Centre points AUTOMATIC TRANSMISSION PROBLEMS Deteriorated roller housing or belt.
  • Page 65 STAND DOES NOT RETURN TO POSITION Presence of dirt Clean and grease STARTER LEVER DOES NOT RETURN TO CORRECT POSITION Presence of dirt Clean and grease...

  • Page 67: Technical Data

    VESPA PRIMAVERA 50 2T Chap. 04 Technical data...

  • Page 68: Data

    Data (04_01) 04_01...
  • Page 69 VEHICLE SPECIFICATIONS Chassis Stamped plate body with welded structural reinforcements. Front suspension Single arm with helical spring and single double-acting hydraulic shock absorber. Rear suspension Single-chamber shock absorber. Front brake Ø 200-mm disc brake with hydraulic control activated by handlebar right-side lever. Rear drum Ø...
  • Page 70 ENGINE SPECIFICATIONS Type single-cylinder, two-stroke Engine capacity 49 cm³ Bore x stroke 40 X 39.3 mm Compression ratio 9.9 ± 0.5: 1 Engine idle speed 1,800 ± 100 rpm Max. power 3.2 kW at 7,500 rpm MAX. torque 4.4 Nm at 6,500 rpm Transmission Automatic expandable pulley variator with torque server, V-belt,...

  • Page 71: Tool Kit

    Emissions EURO 2 CAPACITIES Transmission oil 80 cm³ Fuel tank capacity 6.4 ± 0.1 l Oil mix tank capacity ~ 1.3 l Tool kit (04_02) The toolkit comprises: - one box-spanner; - one twin screwdriver; - one fuse puller; - one torx wrench. The tools are stored in the helmet compartment.

  • Page 73: Spare Parts And Accessories

    VESPA PRIMAVERA 50 2T Chap. 05 Spare parts and accessories...

  • Page 74: Warnings

    Warnings (05_01) WARNING IT IS RECOMMENDED THAT "ORIGINAL PIAGGIO SPARE PARTS" BE USED, AS THESE ARE THE ONLY ONES OFFERING YOU THE SAME QUALITY AS- SURANCE AS THOSE INITIALLY FITTED ON THE VEHICLE. IT SHOULD BE REMEMBERED THAT USING NON-ORIGINAL SPARE PARTS 05_01 CAUSES YOUR WARRANTY RIGHTS TO EXPIRE.

  • Page 75: Scheduled Maintenance

    VESPA PRIMAVERA 50 2T Chap. 06 Scheduled maintenance...

  • Page 76: Scheduled Servicing Table

    Scheduled servicing table (06_01) Adequate maintenance is fundamental to ensure long-lasting, optimum operation and performance of your vehicle. To this end, a series of checks and maintenance operations (at the owner's expense) have been suggested, which are included in the summary table on the following page. Any minor faults should be reported without delay to an Authorised Service Centre or Dealer without waiting until the next scheduled service to solve it.
  • Page 77 km x 1,000 Brake fluid ** Mixer Mixer oil* Hub oil Headlight direction adjustment Brake pads/shoes Sliding shoes / CVT rollers Tyre pressure and wear Vehicle road test Idle speed Suspension Steering Transmission Mixer oil pipes I: INSPECT AND CLEAN, ADJUST, LUBRICATE OR REPLACE IF NECESSARY C: CLEAN, R: REPLACE, A: ADJUST, L: LUBRICATE Clean the SAS air filter every 2 years * Check level every 500 km...
  • Page 78 RECOMMENDED PRODUCTS TABLE Product Description Specifications AGIP GEAR SAE 80W-90 Lubricant for gearboxes and transmissions. API GL-4 AGIP BRAKE 4 Brake fluid. Synthetic fluid SAE J 1703 -FMVSS 116 - DOT 3/4 - ISO 4925 - CUNA NC 956 DOT 4 eni i-Ride PG 2s Synthetic based lubricant for low smoke 2- API TC - JASO FC - ISO-L-EGD...
  • Page 79 1 Miles per hour (mi/h) 1.602 Kilometres per hour (km/h) 1 Pound per square inch (PSI) 0.069 (bar) 1 Fahrenheit (°F) 32+(9/5) Celsius (°C)
  • Page 81 TABLE OF CONTENTS Tyre pressure: 27 Tyres: 39 Air filter: 41 Horn: 15 Puncture: 60 Hub oil: 38 Vehicle: 7, 60, 61 Battery: 45, 46 Refuelling: 24 Brake: 42, 58, 59 Identification: 20 Instrument panel: 9 Saddle: 18 Checks: 24 Scheduled maintenance: 75 Keys: 20 Spark plug: 40...
  • Page 82 The descriptions and images in this publication are given for illustrative purposes only and are not binding. While the basic characteristics as described and illustrated in this booklet remain unchanged, Piaggio & C. S.p.A. reserves the right, at any time and without being required to update this publication beforehand, to make any changes to components, parts or accessories, which it considers necessary to improve the product or which are required for manufacturing or construction reasons.
