Optional Kit - GE CafA?A CSA1201RSS Owner's Manual

Charcoal
filter (JX81D -

optional kit)

To install
the charcoal
filter
36
If the model is not vented to the
outside, the air will be recirculated
through a disposable charcoal filter
that helps remove smoke and odors.
The charcoal filter cannot be cleaned.
It must be replaced. Order Part No.
WB2X9883 from your GE supplier.
To install a new filter:
1. Remove plastic and other outer
wrapping from the new filter.
2. Remove the top grill by removing
the two screws that hold it in place.
3. Insert the filter into the top opening
of the oven as shown.
4. It will rest at an angle on two back
support tabs and in front by two tabs.
5. Replace the grill and two screws.
To remove the filter, repeat step 2
above, remove the filter and repeat
step 5.
Care and Cleaning
Advantium Oven
The charcoal filter should be replaced
when it is noticeably dirty
or discolored (usually after 6 to
12 months, depending on usage).
