Brivis Models:
Contour Series
Promina Series
Advance Series
AD Series
Evaporative Air Coolers
Installation Manual
by

Advertisement

Table of Contents
loading

Summary of Contents for Rinnai brivis Contour Series

  • Page 1 Brivis Models: Contour Series Promina Series Advance Series AD Series Evaporative Air Coolers Installation Manual...
  • Page 2 This appliance must be installed in accordance with: • Manufacturer’s Installation Instructions • Current AS/NZS 3000 • Local Regulations and Municipal Building Codes including local OH&S requirements This appliance must be installed, maintained and removed only by an Authorised Person. For continued safety of this appliance it must be installed and maintained in accordance with the manufacturer’s instructions.
  • Page 3: Table Of Contents

    5. Installation - Promina & Contour 5�1 Dropper Duct Installation and Fitting the Cooler ������������������������������������������������������������������������������������������������������������11 5�2 Fitting Brivis Promina Optional Winter-Seal ������������������������������������������������������������������������������������������������������������������ 12 5�3 Fitting the Brivis Promina & Brivis Contour Series Cooler �������������������������������������������������������������������������������������������� 12 6. Installation - Brivis Advance 6.1  Brivis Advance Series Dropper Duct Specific  ��������������������������������������������������������������������������������������������������������������� 13 6�2 Fitting the Brivis Advance Unit ��������������������������������������������������������������������������������������������������������������������������������������...
  • Page 4 TABLE OF CONTENTS 10. Dismantling 10�1 Removing the Front and Rear Pads ��������������������������������������������������������������������������������������������������������������������������� 20 10�2 Removing the Side Pads ������������������������������������������������������������������������������������������������������������������������������������������� 20 10�3 Dismantling the Framework ���������������������������������������������������������������������������������������������������������������������������������������� 20 11. Installation - Brivis AD 11.1  Brivis AD Dropper Duct Specific  ���������������������������������������������������������������������������������������������������������������������������������� 21 11.2  Installing the Dropper Duct and fitting the Brivis AD Cooler  ���������������������������������������������������������������������������������������� 21 11�3 Brivis AD Winter Seal Installation ��������������������������������������������������������������������������������������������������������������������������������...
  • Page 5: Warnings And Important Information

    SHOULD: INDICATES A RECOMMENDED REQUIREMENT OF THIS MANUAL. Any deviations from these instructions may, at the discretion of Rinnai, void the warranty. As a result, the customer and/or installer may be charged a fee for product non-warranty related call outs. Also, note that failure to comply with these instructions may preclude Rinnai from being able to service the unit.
  • Page 6: Mandatory Inspection Prior To Installation

    No responsibility will be accepted for installation or operation of damaged or incorrect appliances. Installation of damaged or incorrect appliances may also contravene local regulations. MODELS COVERED IN THIS MANUAL Brivis Contour Series* IMPORTANT Brivis Promina Series Brivis Advance Series*...
  • Page 7: General Guidelines

    1. GENERAL GUIDELINES 1.1 UNPACKING THE COOLER The unit is supplied on a pallet and enclosed with protective packaging� To unpack: • Carefully remove the outer packaging and any retaining brackets/straps that secure the cooler to the pallet� • For AD units cut and remove the strap at the bottom centre of the unit, where the fan motor assembly is held to the pallet�...
  • Page 8: Cooler Service Requirements

    2. COOLER SERVICE REQUIREMENTS Switch A qualified electrician MUST install the 240 Volt wiring according to local regulations. Switch OFF the power and unplug the Cooler before touching any wiring. If any IMPORTANT electrical wiring is damaged, it MUST BE replaced by the manufacturer, its service Active Neutral agents or an electrically qualified technician, in order to avoid a hazard.
  • Page 9: Cooler Hardware

    Water diverter channel Dropper Duct Flashing This diagram is for Brivis Promina and Brivis Contour Series Models. NOTE 3.4 DROPPER DUCT INSTALLATION GUIDELINES • The dropper duct on which the Cooler is mounted MUST BE properly secured to the roof structure or timbers�...
  • Page 10: Clearances

    The roof access point is 6m above ground level • The structure is unsound All service works are governed by the Rinnai Australia Pty Ltd Safe Work Method Statements (SWMS) for Evaporative Coolers and Working at Heights� Brivis Evap AC IM...
  • Page 11: Installation - Promina & Contour

    5. INSTALLATION - PROMINA & CONTOUR 5.1 DROPPER DUCT INSTALLATION AND FITTING THE COOLER • The dropper duct size for all Brivis Promina & Brivis Contour Series models is 550mm X 550mm� • Brivis Promina & Brivis Contour Series Coolers MUST use a dropper duct with an out turned flange (15-20mm). ...
  • Page 12: 5�2 Fitting Brivis Promina Optional Winter-Seal

    • Then proceed with the mounting of the cooler into the dropper duct� 5.3 FITTING THE BRIVIS PROMINA & BRIVIS CONTOUR SERIES COOLER • The Cooler should now be mounted into position� Insert the Cooler’s air outlet fully into the dropper duct�...
  • Page 13: Installation - Brivis Advance

    6. INSTALLATION - BRIVIS ADVANCE 6.1 BRIVIS ADVANCE SERIES DROPPER DUCT SPECIFIC • High side of roof All Brivis Advance Series units sit on a 550mm x 550mm dropper box with a 15-20mm out turned flange. • Brivis Advance Series units can also be installed on an existing dropper box�...
  • Page 14: Network Connection

    7. NETWORK CONNECTION 7.1 WIRING CONNECTION BRIVIS NETWORKERS The Brivis Networker backing plate has 4 terminal points for the connection of Thermostat wires� When connecting, use the top 2 terminal points marked TW1 and TW2 or the bottom 2 terminal points also marked TW1 or TW2� Never use a combination of terminals when connecting to a single appliance�...
  • Page 15: 7�4 Master And Slave Addressing

    7. NETWORK CONNECTION 7.4 MASTER AND SLAVE ADDRESSING Unit Parameter • Type Value Press the clock Key 5, and across the top a scrolling message should say “Clock setting mode”, and after the message has finished the time  Master will begin flashing. Slave • Push and hold Keys 2 & 4, until the screen displays this message “Installer  parameter access” • After  the  message  has  finished,  push  the  Mode  key  until  the  screen  displays - n01 ID00:1 at the top (see diagram)�...
  • Page 16: 7�6 Setting Up Multiple Coolers On The Network

    7. NETWORK CONNECTION 7.6 SETTING UP MULTIPLE COOLERS ON THE NETWORK To ensure each Cooler is configured correctly to the Brivis Networker see the instructions below and refer to the  Brivis Networker Advanced Programming Manual No� 400 (Available on request from Brivis Customer Service)� As the Brivis Networker is polarity sensitive when more than one Cooler is installed on a Brivis Networker all the Coolers should be wired in parallel (see diagrams below)�...
  • Page 17: Changing An Identification Number

    7. NETWORK CONNECTION 7.7 CHANGING AN IDENTIFICATION NUMBER • To change the ID number a cooler MUST BE powered and configured individually. • So, turn OFF the power to all the other coolers and heaters on the Network System� Use the Installer Set-Up program as follows� •...
  • Page 18: Water Connection

    The  Brivis  Contour  Series  is  fitted  with  an  AquaSave  module  that  maintains water purity during the cooler’s operation and therefore does not flush as often. 8.3 WATER DRAIN CONNECTION Brivis Advance, Brivis Promina and Brivis Contour Series models have a drainage connection point at the underside of the base, on the low side of the roof�...
  • Page 19: Timing & Cooler Functions

    9.1 START UP Brivis Cooler with Dump Valve fitted will have a 15 second delay on start up. On start up, the Brivis Advance and Brivis Contour Series ServoSeal damper will also open before any other function� If  the  Cooler  has  been  OFF  for  longer  than  60  minutes  the  tank  will  require  refilling. Allow  approximately  3-5 ...
  • Page 20: Dismantling

    10. DISMANTLING 10.1 REMOVING THE FRONT AND REAR PADS For general servicing, remove the front and back pads to access all components� • Loosen the 4 plastic thumbscrew knobs on the c ooler’s roof until the large front pad can be lifted up enough to clear the bottom edge�...
  • Page 21: Installation - Brivis Ad

    11. INSTALLATION - BRIVIS AD 11.1 BRIVIS AD DROPPER DUCT SPECIFIC • For Brivis AD models 66 and 86 the dropper box size is 650 mm x 650 mm� • For Brivis AD 56 the dropper box size is 550 mm x 550 mm� •...
  • Page 22: 11�3 Brivis Ad Winter Seal Installation

    11. INSTALLATION - BRIVIS AD 11.3 BRIVIS AD WINTER SEAL INSTALLATION The Winter Seal can be fitted into the dropper duct before or after the dropper has been installed, but it is important  to ensure that: • Dropper duct is square • The dropper duct seam and the large 45º fold-up corner are to the high side of the roof as shown in the drawing below, otherwise the flaps will not open correctly.
  • Page 23: 11�4 Wiring The Brivis Ad To The Programmable And Manual Wall Control

    11. INSTALLATION - BRIVIS AD 11.4 WIRING THE BRIVIS AD TO THE PROGRAMMABLE AND MANUAL WALL CONTROL • The Brivis AD coolers are supplied with a 20 m wall control loom pre-wired to the Cooler’s electronic module� • Ensure the wall control is positioned so that it is within reach of the Cooler, using the 20 m wire loom assembly supplied�...
  • Page 24: Brivis Ad Water Connection

    12. BRIVIS AD WATER CONNECTION 12.1 INLET CONNECTION The water inlet connection point is in the Cooler base, which should be positioned on the low side of the roof� The connection is a 12 mm copper tube union (flare). 12.2 BRIVIS AD FLOAT VALVE SETTING DETAILS The Float Valve has been factory set so that the water fills  initially to a level between the minimum and maximum level ...
  • Page 25: 12�5 Brivis Ad Bleed Setting Instructions

    12. WATER CONNECTION 12.5 BRIVIS AD BLEED SETTING INSTRUCTIONS • Loosen the thumb screw, firmly grip the over flow pipe, and rotate it. • Move the bleed tray further under the pad to increase the bleed rate or further away from the pad to decrease it� • Measure to confirm the required bleed rate and then tighten the thumb screw. Ensure the arrow of the overflow pipe assembly sits between the leg of the locking bracket. NOTE 12.6 BRIVIS AD DUMP VALVE FUNCTIONS The Dump Valve empties the tank after the Cooler is turned OFF, leaving it dry�...
  • Page 26: Brivis Ad Timing & Cooler Functions

    13. BRIVIS AD TIMING & COOLER FUNCTIONS 13.1 START - UP - BRIVIS AD MODEL WITH DUMP VALVE The Cooler has been pre-programmed to automatically saturate the filter pads when the pump is turned ON (Pre- Wet). The cooler will delay this Pre-Wet operation for a period of 4 minutes to allow the tank to fill with water (Fill- Time)� This delay will only occur where the pump has been OFF for longer than 45 minutes� 13.2 PRE - WET Pre-wet is the process of running the pump and wetting the pads without the fan operating, ensuring full pad saturation and optimum cooling potential when the fan starts�...
  • Page 27: Commissioning Checklist

    14.1 ISOLATING SWITCH - BRIVIS ADVANCE, BRIVIS PROMINA & BRIVIS CONTOUR The Brivis Advance, Brivis Promina and Brivis Contour Series have an external power-isolating switch to facilitate servicing� The switch is located under the front left hand side of the cooler� To access the switch, reach under the front of the Cooler’s trough and locate the switch�...
  • Page 28: 14�5 What If The Pump Will Not Start

    12. COMMISSIONING CHECKLIST • The motor is not hot, causing the auto-reset thermal overload switch in the fan motor to open circuit� • The motor speed sensor has not been damaged or displaced (where fitted). • That all electrical connections are secure, and if the motor will not start, call Brivis for service� 14.5 WHAT IF THE PUMP WILL NOT START? Check: •...
  • Page 29: Exhaust And Ventilation

    15. EXHAUST AND VENTILATION Exhaust fans may be required if insufficient free exhaust area exists. If the exhaust fan is the only exhaust or ventilation outlet, then its capacity should be at least equal to the Cooler’s air output. IMPORTANT Door = 1�6m²...
  • Page 30: Technical Specifications

    16. TECHNICAL SPECIFICATIONS Model Weight kg Motor Loom Minimum Tank Angle of Dump Dropper Dropper Water Capacity Impellor Dropper Drain Note: the type of Box Size Connection (litres) Watts Amps Blades loom depends on the Connection Length wall control used Brivis Contour 50.0 68.5...
  • Page 31 16. TECHNICAL SPECIFICATIONS Model Weight kg Motor Loom Minimum Tank Angle of Dump Dropper Dropper Water Capacity Impellor Note: the type of loom Dropper Drain Box Size Connection (litres) Blades Connection Watts Amps depends on the wall Length control used Brivis Advance 49.0 67.0...
  • Page 32: Contacts

    Tel: 1300 555 545* Fax: 1300 555 655 Monday to Friday, 8.00 am to 5.00 pm EST. *Cost of a local call higher from mobile or public phones. For further information visit www.rinnai.com.au or email enquiry@rinnai.com.au innai has a Service and Spare Parts network with...
