Chapter 1
INTRODUCTION
The MSI NLX LX3 mainboard is a high-performance personal computer
®
mainboard based on the Pentium
II processor. The mainboard supports
®
®
Intel
82558 Network chip and Creative Lab
Vibra 16x sound chip. An AGP
®
slot is also available for an AGP VGA card. The Pentium
II processor
TM
supports MMX
(Multimedia Extension) technology.
®
The mainboard uses the highly integrated Intel
82440LX AGPset which
optimize the system bandwidth and concurrency with the implementation of
Quad Port Acceleration (QPA). QPA provides 4-port concurrent arbitration
of the processor bus, graphics, PCI bus and SDRAM.
®
The Intel
82371AB chipset integrates all system control functions such as
ACPI (Advanced Configuration and Power Interface). The ACPI provides
more Energy Saving Features for the OSPM(OS Direct Power Management)
®
function. The Intel
82371AB chipset also improves the IDE transfer rate by
supporting Ultra DMA/33 IDE that transfers data at the rate of 33MB/s.
The mainboard also supports the LM78/W83781D System Hardware
Monitor Controller as optional function. The System Hardware Monitor
function includes: CPU /power supply/chassis fan revolution detect, CPU/
system voltage monitor, system temperature monitor, and chassis intrusion
detect(optional).
1-1

Advertisement

Table of Contents
loading

Summary of Contents for MSI NLX LX3

  • Page 1 Chapter 1 INTRODUCTION The MSI NLX LX3 mainboard is a high-performance personal computer ® mainboard based on the Pentium II processor. The mainboard supports ® ® Intel 82558 Network chip and Creative Lab Vibra 16x sound chip. An AGP ®...
  • Page 2: Mainboard Features

    1.1 Mainboard Features ® Slot 1 for Pentium II processor. Supports 200MHz, 233MHz, 266MHz, 300MHz, and 333MHz. Core/Bus ratios are x2, x2.5, x3, x3.5, x4, x4.5, x5, x5.5, x6 and higher. Switching Voltage Regulator On-board switching mode DC-DC Step Down Regulator. ®...
  • Page 3 System Hardware Monitor ® This can be used with Intel LDCM to monitor system voltage, system temperature & fan rotation speed. This can also be used to monitor overall system status over the network. System temperature sensor: ® - detect Pentium II processor’s temperature.
  • Page 4 Rear Mainboard Connectors ® ® PS/2 keyboard interface and PS/2 mouse interface. Two COM port connectors. One printer port with SPP/EPP/ECP function. One USB connector. One MIDI/Joystick connector. One RJ-45 LAN connector. Audio conectors: Speaker/Line-In/Mic. Dimension NLX Form Factor: 21.7cm(L) x 34.6cm(W) x 4 layers PCB. Other Features Bulk Erase Flash ROM.
  • Page 5: Mainboard Layout

    1.2 Mainboard Layout T: LPT T: mouse Joystick/ SPKR L-IN B: COM A Port RJ-45 MIDI keyboard COM B JVCC JVSB WAVET1 Creative Intel ® VIBRA 16x 82558 10/100M Ethernet BATT JBAT1 FW82371AB LM78 (optional) FW82443LX JSOR1 JMODE1 CPUFA1 MS-6113...
  • Page 6: Hardware Installation

    Chapter 2 HARDWARE INSTALLATION ® ® The mainboard operates with Intel Pentium II processor with MMX technology. The mainboard uses a CPU Slot called Slot 1 for easy CPU installation and a DIP switch (SW1) to set the proper speed for the CPU. The CPU should always have a Heat Sink and a cooling fan attached to prevent overheating.
  • Page 7: Cpu Installation Procedures

    2.1-1 CPU Installation Procedures ® There are two kinds of Pentium II processor that is currently used: the ® ® OEM Pentium II processor and the Boxed Pentium II processor. OEM ® Pentium II processor has no Heat Sink, Fan and Heat Sink Support, while ®...
  • Page 8 HSSBASE through the fins on the ATX heatsink. ® **Heat Sink w/ fan - Heat Sink that can be attached to the Pentium processor with metal clip. Note: * Provided by MSI mainboard. ** Provided by Special request. HSSBASE HSSPIN RMAM...
  • Page 9 Step 1: Insert the Retention Mechanism Attach Mount at the bottom of the mainboard. Step 2: Install the Retention Mechanism. Look for the key on Slot 1, and match it with the Notch Key on the Retention Mechanism for proper direction. Then, attach the Retention Mechanism to the Retention Mechanism Attach Mount.
  • Page 10 Step 3: Install the Heat Sink Support Base. Look for the Two holes across Slot 1, and match it with the Two legs of the Heat Sink Support Base for the proper direction. Take note that one hole/leg is bigger than the other. The Four top pins of the Heat Sink Support Base should also be oriented towards Slot 1.
  • Page 11 Step 5: Install the Heat Sink with Fan to the Processor. Push down the metal clips, so that they are in line with the back of the Heat Sink. Be careful, so as not detach the metal clips from the Heat Sink.
  • Page 12 Step 6: Install the Processor. Unlock the Processor by pushing in the Processor Locks. Insert the Processor like inserting a PCI or an ISA card. Step 7: Lock the Processor Locks. Secure the CPU by pulling the Processor Locks out.
  • Page 13 Step 8: Install the Heat Sink Support Top Bar. Push the Heat Sink Support Top Bar to the Heat Sink Support Base, Until you hear a “click” sound. Check for a perfect fit. Heatsink Support Top The installation is now complete.
  • Page 14 ® B. Boxed Pentium II processor Installation Procedures ® The Boxed Pentium II processor has a built- in Fan and Heat Sink. It also has a Heat Sink Support. So if you’re going to use the Boxed processor, all you need is the Retention Mechanism. Step 1: Insert the Retention Mechanism Attach Mount at the bottom of the mainboard.
  • Page 15 Step 3: Install the Heat Sink Support Base. Look for the 2 holes across Slot 1, and match it with the 2 Heat Sink Support Base. Take note that one hole/base is bigger than the other. Retention Mechanism Notch Hole Heat Sink Support Base Push the Heat Sink Support Base onto the mainboard, until you hear...
  • Page 16 Step 4: Install the Heat Sink Support. Attach the 2 Heat Sink Supports to the sides of the Processor. These Heat Sink Supports will fit in any direction, so be sure that the Heat Sink Support Locks are oriented outwards for the proper direction. ®...
  • Page 17 Step 5: Unlock the Processor Locks and Heat Sink Support Locks. Push in the Processor Locks. Open the Heat Sink Support Locks. Processor Lock Heatsink Support Lock PC-3744 Step 6: Insert the Processor like inserting a PCI or an ISA card. 2-12...
  • Page 18 Step 7: Lock the Processor Locks and Heat Sink Support Locks Secure the CPU by pushing out the Processor Locks. Close the Heat Sink Support Locks. The installation is now complete. 2-13...
  • Page 19: Cpu Core Speed Derivation Procedure

    2.1-2 CPU Core Speed Derivation Procedure 1. The DIP Switch SW1 (5 & 6) is used to adjust the CPU clock frequency. Clock 66.8MHz 68.5MHz* 75MHz* Note: We don’t guarantee 68.5MHz and 75MHz bus frequency. It might not be stable. 2-14...
  • Page 20 2. The DIP Switch SW1 (1, 2, 3, and 4) is used to set the Core/Bus (Frac- tion) ratio of the CPU. The actual core speed of the CPU is the Host Clock Frequency multiplied by the Core/Bus ratio. For example: CPU Clock 66MHz Core/Bus ratio...
  • Page 21 2.1-3 CPU Speed Setting: SW1 To adjust the speed of the CPU, you must know the specifications of your CPU (always ask the vendor for CPU spec.). Then look at Table 2.1 (200 ~ ® ® 333MHz Intel Pentium II processor) for setting. Speed Setting Table 2.1 200 ~ 333MHz Intel ®...
  • Page 22: Fan Power Connector: Cpufa1

    2.1-4 Fan Power Connector: CPUFA1 This connector support system cooling fan with +12V. It supports three pin head connector. When connecting the wire to the connector, always take note that the red wire is the positive and should be connected to the +12V, the black wire is Ground and should be connected to GND.
  • Page 23 A battery must be used to retain the mainboard configuration in CMOS RAM. If you use the on-board battery, you must short 1-2 pins of JBAT1 to keep the CMOS data. JBAT1 Function JBAT1 Keep Data Clear Data Note: You can clear CMOS by shorting 2-3 pin, while the system is off. Then, return to 1-2 pin position.
  • Page 24 This jumper is for setting the voltage of the Flash ROM BIOS. JMODE1 Function JMODE1 +12V (default) ® ® Note: a. Short 1-2 pin, if you’re using Intel or MXIC flash memory and you want to flash the ROM data. ®...
  • Page 25 The mainboard supports two kinds of system boot up: the Boot-Up by switch and the Immediate Boot-Up. With the Boot-Up by Switch, the system will boot up only when the power on switch is pressed. For Immediate Boot- Up, the system will boot up instantly when the power connector is connected into the system.
  • Page 26 This is used to enable/disable the keyboard power on feature. This mainboard supports keyboard power-on feature. The keyboard needs to have a power supply which can provide sufficient 5V standby power for both the keyboard and the mainboard. JVCC JVSB Function JVCC/JVSB Enabled...
  • Page 27: Memory Bank Configuration

    2.6-1 Memory Bank Configuration The mainboard supports a maximum of 768MB of memory : It provides three 168-pin unbuffered DIMMs (Double In-Line Memory Module) sockets. It supports 8 MB to 256 Mbytes DIMM memory module. The memory module can be either FP(Fast Page), EDO (Extended Data Output), and SDRAM(Synchronous DRAM) MODE DRAM.
  • Page 28: Memory Installation Procedures

    2.6-2 Memory Installation Procedures: A. How to install a DIMM Module Single Sided DIMM Double Sided DIMM 1. The DIMM slot has a two Notch Key “VOLT and DRAM”, so the DIMM memory module can only fit in one direction. 2.
  • Page 29: Memory Population Rules

    2.6-3 Memory Population Rules 1. To operate properly, at least one 168-pin DIMM module must be installed. This mainboard supports Table Free memory, so memory can be installed on (DIMM1), (DIMM2), or (DIMM 3), in any order. 2. Use only a 3.3v unbuffered DIMM. 3.
  • Page 30 Table 2.5-1 EDO DRAM Memory Addressing DRAM MB/SIMM DRAM Address Size DRAM Density & Tech. Addressing Single Double Column Width pcs. Side(S) pcs. Side(D) 1Mx4 SYMM 4MBx8 8MBx16 1Mx16 SYMM 4MBx2 8MBx4 1Mx16 ASYM 4MBx2 8MBx4 2Mx8 ASYM 8MBx4 16MBx8 2Mx8 ASYM 8MBx4...
  • Page 31 The mainboard has two 9-pin male DIN connectors for serial ports COM A and COM B. These two ports are 16550A high speed communication ports that send/receive 16 bytes FIFOs. You can attach a mouse or a modem cable directly into these connectors. 1 2 3 4 5 6 7 8 9 COM B...
  • Page 32 The mainboard provides a 25 pin female centronic connector for LPT. A parallel port is a standard printer port that also supports Enhanced Parallel Port(EPP) and Extended capabilities Parallel Port(ECP). See connector and pin definition below: 13 12 11 10 9 8 7 6 5 4 3 2 1 25 24 23 22 21 20 19 18 17 16 15 14 PIN DEFINITION SIGNAL...
  • Page 33 ® The mainboard provides a standard PS/2 mouse mini DIN connector for ® ® attaching a PS/2 mouse. You can plug a PS/2 mouse directly into this connector. The connector location and pin definition are shown below: Pin5 Mouse Clock Pin6 Pin3 Pin4...
  • Page 34 You can connect MIDI keyboard, joystick or game pads to this connector. 8 7 6 5 4 3 2 1 15 14 13 12 11 10 9 Joystick/Midi(15-Pin Female) SIGNAL Joystick But0 Joystick X1 Joystick Y1 Joystick But1 Joystick But2 Joystick X2 Midi Out Joystick Y2...
  • Page 35 The mainboard provides a UHCI(Universal Host Controller Interface) Universal Serial Bus root for attaching USB devices like: keyboard, mouse and other USB devices. You can plug the USB device directly to this connector. 1 2 3 4 USB Port SIGNAL DESCRIPTION -Data 0 Negative Data Channel 0...
  • Page 36 The mainboard provides a RJ-45 connector for your network need. RJ-45 Connector 2-31...
  • Page 37 Speaker is a connector for Speakers or Headphones. Line In is used for external CD player, Tape layer, or other audio devices. Mic is a connector for the microphones. Speaker Line In Mic 1/8” Stereo Audio Connectors 2-32...
  • Page 38 This jumper is used to amplify the PC speaker. Feature Enable Disable Note: Short JP2, to enable the PC speaker amplify. Open JP2, to disable the PC speaker amplify. 2-33...
  • Page 39 EMUL EMUR 2-34...
  • Page 40 The mainboard provides a connector to support the PC-PCI technology of Sound Blaster AWE64D. This will enable users to play real-mode DOS game. SIGNAL DMA Grand Signal DMA Request Signal Serial Interrupt SIgnal 2-35...
  • Page 41 This is used to check the CPU temperature. The JSOR1 is a sensor that is placed near the processor heatsink. This will monitor the CPU temperature. JSOR1 2-36...
  • Page 42 The MS-5931 Riser card can be used with the MS-6113 mainboard. USB2 USB2 JSW1 JWOL JIR1 Optional Connector PSFAN1 SFAN1 MS-5931(Front View) MS-5931(Back View) 2-37...
  • Page 43 2.19-1 Power Saving LED: J1 This connector is used by Power Saving LED. Note: During Suspend Mode, this LED will light up. 2.19-2 Power LED: J2 This connector is used by Power LED. Note: During System-On Mode, this LED will light up. 2.19-3 Front Panel Connector: U1 Reset Turbo...
  • Page 44 a. Turbo LED The Turbo LED is always ON. You can connect the Turbo LED from the system case to this pin. b. Reset Switch Reset switch is used to reboot the system rather than turning the power ON/OFF. Avoid rebooting while the HDD LED is lit. You can connect the Reset switch from the system case to this pin.
  • Page 45 2.19-6 Infrared Module Connector: JIR1 The mainboard provides two 5-pin infrared (IR) connectors for IR modules. These connectors are for optional wireless transmitting and receiving infrared module. You must configure the setting through the BIOS setup to use the IR function. FIR and Consumer IR are reserved functions for future Super I/O chipset.
  • Page 46: Chassis Intrusion Switch Connector: J4

    2.19-8 Chassis Intrusion Switch Connector: J4 This connector can be used to connect the Chassis Intrusion switch. 2.19-9 Wake On LAN Connector: JWOL The JWOL connector is for use with LAN add-on cards that supports Wake Up on LAN function. JWOL SIGNAL 5VSB...
  • Page 47 2.19-10 Power/System Fan Connector: PSFAN1/SFAN1 This connector support system cooling fan with +12V. It supports three pin head connector. When connecting the wire to the connector, always take note that the red wire is the positive and should be connected to the +12V, the black wire is Ground and should be connected to GND.
  • Page 48 ® Chapter 3 ® BIOS USER GUIDE The system configuration information and chipset register information is stored in the CMOS RAM. This information is retained by a battery when the power is off. Enter the BIOS setup (if needed) to modify this information. The following pages will describe how to enter BIOS setup, and all about options.
  • Page 49: Enter Bios Setup

    ® 3.1 Enter BIOS Setup ® Enter the AMI setup Program’s Main Menu as follows: 1. Turn on or reboot the system. The following screen appears with a series of diagnostic check. AMIBIOS (C) 1996 American Megatrends Inc. AGIOMS VXXX XXXXXX Hit <DEL>...
  • Page 50 ® AMIBIOS HIFLEX SETUP UTILITIES - VERSION 1.07 (C) 1996 American Megatrends, Inc. All Rights Reserved Standard CMOS Setup Advanced CMOS Setup Advanced Chipset Setup Power Management Setup PCI/Plug and Play Setup Peripheral Setup Hardware Monitor Setup Auto-Detect Hard Disks Change User Password Change Supervisor Password Change Keyboard Wake-Up Password...
  • Page 51: Standard Cmos Setup

    ® 3.2 Standard CMOS Setup 1. Press <ENTER> on “Standard CMOS Setup” of the main menu screen . AMIBIOS SETUP - STANDARD CMOS SETUP (C)1996 American Megatrends,Inc.All Rights Reserved Date (mm/dd/yyyy): Mon Jan 26, 1998 Time (hh/mm/ss): 17:09:25 Floppy Drive A: 1.44 MB 3 1/2 Floppy Drive B: Not Installed...
  • Page 52: Advanced Cmos Setup

    ® 3.3 Advanced CMOS Setup 1. Press <ENTER> on “Advanced CMOS Setup” of the main menu AMIBIOS SETUP - ADVANCED CMOS SETUP (C) 1996 American Megatrends, Inc. All Rights Reserved Quick Boot Enabled Available Options: Ist Boot Device Floppy Enabled 2nd Boot Device IDE 0 Disabled...
  • Page 53 ® Description of the item on screen follows: Quick Boot ® Set this option to Enabled to permit AMI BIOS to boot within 5 seconds. This option replaces the old ABOVE 1 MB Memory Test option. The Optimal default setting is Enabled. The Fail-Safe default setting is Disabled.
  • Page 54 ® Boot up Num Lock ® When this option is set to Off, AMI BIOS turns off the Num Lock key when the system is powered on. The end user can then use the arrow keys on both the numeric keypad and the keyboard. The settings are On or Off.
  • Page 55: System Bios Cacheable

    ® Cache Bus ECC ® This option is for future Pentium II processor. During Enabled, this will affect the system performance. Disabled this option if you don’t want to affect the system performance. System BIOS Cacheable ® BIOS always copies the system BIOS from ROM to RAM for faster execution.
  • Page 56: Advanced Chipset Setup

    ® 3.4 Advanced Chipset Setup 1. Press <ENTER> on “Advanced Chipset Setup” of the main menu screen. AMIBIOS SETUP - ADVANCED CHIPSET SETUP (C) 1996 American Megatrends, Inc. All Rights Reserved Auto Configure EDO DRAM Timing Enabled Available Options: EDO DRAM Speed (ns) Enabled EDO Read Burst Timing x222...
  • Page 57 ® Description of the item on screen follows: Auto Configure EDO DRAM Timing Choose Enabled(default) will automatically configure the DRAM timing depending on the “DRAM Speed” selection. Choose disable to customize setup. EDO DRAM Speed (ns) This option specifies the RAS access time (in nanoseconds) for the DRAM used in the computer.
  • Page 58: Sdram Ras Precharge Time

    ® SDRAM CAS Latency This option determines the CAS latency time parameter of SDRAM. The settings are 2 clks or 3 clks. SDRAM RAS Precharge Time This option defines the RAS# precharge requirements for the SDRAM memory type in 66MHz clocks. DRAM Integrity Mode During ECC, this will enable the DRAM ECC mechanism that allows detection of single-bit and multiple-bit errors and recovery of single-bit...
  • Page 59: Agp Aperture Size

    ® PCI Frame Buffer USWC ® The Pentium II processor supports the Uncacheable Speculatable Write-Combining (USWC) memory type. The processor provides a write- combining with buffering strategy for write operation. This is useful for frame buffering. Writing to USWC memory can be buffered and combined in the processors write-combining buffer (WCB).
  • Page 60: Usb Function

    ® USB Passive Release ® During Enabled, this will allow the PIIX4 to use passive release (look ® at PIIX4 Passive Release) while transferring control information or data for ® USB transaction. During Disabled, PIIX4 will perform PCI accesses for USB without using passive release.
  • Page 61: Power Management Setup

    ® 3.5 Power Management Setup 1. Press <ENTER> on “Power Management Setup” of the main menu screen. AMIBIOS SETUP - POWER MANAGEMENT SETUP (C) 1996 American Megatrends, Inc. All Rights Reserved Power Management / APM Enabled Available Options: Green PC Monitor Power State Stand By Enabled Video Power Down Mode...
  • Page 62 ® Description of the item on screen follows: Power Management/APM ® Set this option to Enabled to enable the Intel 82440LX ISA power management features and APM(Advanced Power Management). The settings are Enabled or Disabled. The default setting is Enabled. The Fail- safe default setting is Disabled.
  • Page 63: Suspend Time Out

    ® Suspend Time Out This option specifies the length of a period of system inactivity while in Standby state. When this length of time expires, the computer enters Suspend power state. The settings are Disabled, 1 min, 2 min, 3 min, 4 min, 5 min, 6 min, 7 min, 8 min, 9 min, 10 min, 11 min, 12 min, 13 min, 14 min or 15 min.
  • Page 64: Power Button Function

    ® CPU Critical Temperature This option is for setting the CPU temperature that would be critical enough, so that it would use the Thermal Slow Clock Ratio to cool down the CPU. Power Button Function During Suspend, if you push the switch one time, the system goes into suspend mode and if you push it more than 4 seconds, the system will be turned off.
  • Page 65 ® LAN Resume from Soft-Off During Disabled, the system will ignore any incoming signal from the LAN network card. During Enabled, the system will boot up if there’s an incoming signal from the LAN network card. Note: If you have change the setting, you must let the system boot up until it goes to the operating system.
  • Page 66: Pci/Plug And Play Setup

    ® 3.6 PCI/Plug and Play Setup 1. Press <ENTER> on “PCI/Plug and Play Setup” of the main menu screen. AMIBIOS SETUP - PCI/PLUG AND PLAY SETUP (C) 1996 American Megatrends, Inc. All Rights Reserved Available Options: Plug and Play Aware O/S Enabled Clear NVRAM on Every Boot Disabled...
  • Page 67 ® Description of the item on screen follows: Plug and Play Aware O/S Set this option to Yes if the operating system in this computer is aware of and follows the Plug and Play specification. Currently, only ® Windows 95 is PnP-aware. The settings are Yes or No. The Optimal and Fail-Safe default settings No.
  • Page 68 ® Allocate IRQ to PCI VGA Choose the IRQ to be assigned to the PCI VGA display adapter card. The Optimal and Fail-Safe default setting is No. PCI IDE BusMaster Set this option to Enabled to specify that the IDE controller on the PCI local bus includes a bus mastering capability.
  • Page 69: Dma Channel

    ® DMA Channel 0/1/3/5/6/7 These options specify the bus that the specified DMA channel is used. These options allow you to reserve DMAs for legacy ISA adapter cards. ® These options determine if AMI BIOS should remove a DMA from the available DMAs passed to devices that are configurable by the system BIOS.
  • Page 70: Peripheral Setup

    ® 3.7 Peripheral Setup 1. Press <ENTER> on “Peripheral Setup” of the main menu screen. AMIBIOS SETUP - PERIPHERAL SETUP (C) 1996 American Megatrends, Inc. All Rights Reserved Available Options: Onboard FDC Auto Auto Onboard Serial Port A 3F8h/COM1 Enabled Onboard Serial Port B 2F8h/COM2 Disabled...
  • Page 71: Onboard Fdc

    ® Description of the item on screen follows: Onboard FDC Choose Auto, for the BIOS to automatically detect the device If the ISA add-on card has Onboard FDC to be set at Disabled FDC exist Enabled none FDC exist Choose Enabled, Enabling onboard FDC. Choose Disabled, Disabling onboard FDC.
  • Page 72: Onboard Parallel Port

    ® Onboard Parallel Port Choose Auto, the BIOS automatically assigned onboard parallel port to the available parallel port or disabled. If the ISA add-on card has Onboard parallel port to be set as LPT1 LPT2 LPT3 PORT I/O:378H I/O:278H I/O:3BCH ASSIGNED ASSIGNED Disabled...
  • Page 73 ® Parallel Port IRQ If the onboard parallel mode is not on auto mode, the user can select the interrupt line for onboard parallel port. We suggest that the user select the interrupt for the onboard parallel port as shown below: Onboard parallel port set at Parallel Port IRQ LPT1(378H)
  • Page 74: Hardware Monitor Setup

    ® 3.8 Hardware Monitor Setup The Hardware Monitor Setup is used to monitor the Current CPU temperature, CPU Fan speed, Chassis Fan Speed, Power fan speed, Vcore, and etc. AMIBIOS SETUP - HARDWARE MONITOR SETUP (C) 1996 American Megatrends, Inc. All Rights Reserved Available Options: -=System Hardware Monitor=-...
  • Page 75 Chapter 4 AUDIO INSTALLATION GUIDE INTRODUCTION The Sound Blaster 16, lets you enjoy CD-quality digital audio. This mainboard audio comes with an extensive suite of Windows applications and Creative ® Wavesynth to help enhance your productivity and enjoyment. Chip List: ®...
  • Page 76 4.1 Install MS-6113 Audio Drivers 1. Driver ® 1.1 Install Enhance Audio Drivers for Windows ® ® After installing Windows 95 on the mainboard, Windows 95 will auto-detect the changes in your hardware configuration, and will show you a message. To get a higher performance, you need to install the Driver.
  • Page 77 ® 1.2 Install Enhance Audio Drivers for DOS or Windows The Install.exe is a Windows ® 3.1 setup program that installs both DOS and Windows ® 3.1 drivers and utilities at the same time. To install MS-6113 Enhance Audio Drivers, follow the steps below: Step 1: Select Run..from the File menu.
  • Page 78 4.2 Install MS-6113 Audio Utility Drivers 1. Utility ® 1.1 Install Audio Utility Drivers for Windows The Sound Blaster 16 utility provides user-friendly and powerful Windows applications, that allows you to record, play, and edit 8-bit (tape quality) and 16-bit (CD-quality) wave data in your Windows environment.
  • Page 79 3. Sound Blaster 16 Utility Windows Application Creative Remote A multi-player “remote control” that enables you to control the Creative CD, Creative Wave, and Creative MIDI Players. Creative CD A player that allows you to play audio CDs from your CD-ROM drive, compile playlist, and gives names to the track on your CD.
  • Page 80 4.3 Install MS-6113 Creative ® WaveSynth ® 1. Creative Wavesynth ® ® 1.1 Install Creative Wavesynth for Windows ® The Creative Wavesynth is a revolutionary way to add music to your computer. It is a software-based wavetable synthesizer that allows you to play high quality music for Windows multimedia applications and computer games.
  • Page 81 4.4 Enable Creative ® 3D Stereo Enhancement To enable Creative ® 3D Stereo Enhancement, follow the steps below: Step 1: Go to the Control Panel, and double click on the System icon. Step 2: Choose Device Manager, and click on the Sound, video and game controllers.
  • Page 82 ® Chapter 5 ® INTEL 82558 FAST ETHERNET LAN DRIVER The 82558 is a sophisticated 32-bit PCI component, with enhanced scatter- gather bus mastering capabilities. Its true 32-bit architecture enables it to perform high speed data transfers on the PCI bus using four DMA channels. 1.1 Features IEEE 802.3/802.3u 10BASE-T and 100BASE-TX compatible Glueless 32-bit PCI bus master interface...
  • Page 83 ® 2.1 Windows ® To install the driver, just insert the provided CD-ROM into the CD- ROM drive. The CD-ROM will autorun. Press the button for installing the LAN driver. 2.2 Other OS driver To install the driver for other operating system, just insert the provided CD-ROM into the CD-ROM drive.
