NANLITE Forza 300B User Manual

Led bi-color spot light
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Forza 300B
USER MANUAL
Guangdong NanGuang Photo&Video Systems Co., Ltd

Advertisement

Table of Contents
loading

Related Manuals for NANLITE Forza 300B

Summary of Contents for NANLITE Forza 300B

  • Page 1 Forza 300B USER MANUAL Guangdong NanGuang Photo&Video Systems Co., Ltd...

  • Page 2: Table Of Contents

    Contents Product Diagram ..................Technical Data ....................Product Details ..................... Detailed Description ................... Instruction ............. 1. Connection between the light fixture and battery ............. 2. Connection between the light fixture and power adapter ..................3. Installation of the Reflector ................4.
  • Page 3 Operating Instructions ................1. Screen Interface Display Instructions ......................2. CCT Key ......................3. EFFECT Key ......................4. MENU Key ① ....................OUTPUT MODE ② ....................ROTATE SCREEN ③ ....................ADDRESS/DMX ④ ................... WIRELESS PROTOCOL ⑤ ......................... ⑥ ....................SCREEN LIGHT ⑦...

  • Page 4: Product Diagram

    Forza 300B LED Bi-color Spot Light Product Diagram Technical Data Rated Power: 355W Input voltage/current: DC48V/8.4A Max AC100-240V 50/60Hz Color Temperature: 2700K-6500K CRI: Average 96 TLCI: Average 98...

  • Page 5: Product Details

    Product Details 11. USB port 2. Control operation panel 12. Host output socket 3. Handle 4. Power indicator 13. Angle fixing knob 18. Lamp body handle 5. Power switch 1. Battery 14. Lock catch 17.Umbrella hole holder 6. DMX OUT 7.

  • Page 6: Detailed Description

    Detailed Description 1. Battery holder: For installing the battery with two 14.8V/12A Sony V-mount battery or power adapter. 2. Control operation panel: For diaplaying various function operations and data. 3. Handle: It is convenient for users to carry the host. 4.

  • Page 7: Connection Between The Light Fixture And Battery

    Usage 1. Connection between the light fixture and battery Battery Battery ▲Note: When use the V mount battery, please make sure to turn off the fixture and then plug in or pull out the battery or DC cable.

  • Page 8: Connection Between The Light Fixture And Power Adapter

    2. Connection between the light fixture and power adapter...

  • Page 9: Installation Of The Reflector

    ▲Note: (1) When connect the power supply, please make sure the power and voltage should be consistent with the provide power supply. (2) Make sure to use the provided power cable and power adapter, the plug or power supply and the cable to the socket of the fixture should be connected as following.

  • Page 10: Installation Of The Light Stand Clamp

    4. Installation of the Light Stand Clamp ② Push in the button to open Secure the clamp on the light Mount the power adapter into the clamp. stand and rotate the locking the slot on the clamp. knob to secure. 5.

  • Page 11: Remote Control

    Remote Control · Forza 300B supports remote control via DMX, 2.4G, RDM, and has built-in bluetooth. 1. ADDRESS/DMX, including ADDRESS and DMX MODE settings. ① ADDRESS Press the ''MENU'' Key to access options. MENU CH: 512 OUTPUT MODE ROTATE SCREEN...
  • Page 12 Note: 1. The ADDRESS needs to be set before operating the remote control by DMX,2.4G and RDM. 2. Forza 300B has 11 channels, for multiple llights controlled remotely, the address of the first light is set to 001, the second one is 012, the third one is 023 and so on.
  • Page 13 ② DMX MODE MENU MENU CH: 512 CH: 512 ADDRESS CCT 8bit DMX MODE ULTIMATE DMX 8bit PRESS “MENU” TO RETURN PRESS “MENU” TO RETURN Rotate the ''right knob'' to the DMX MODE and press in the ''right knob'' to enter the correspoding secondary menu. MENU MENU CH: 512...

  • Page 14: Dmx Remote Control

    2. DMX Remote Control ① Connect the light fixture to the DMX512 console with a connection cable in the following way: DMX IN DMX OUT GND 1 1 GND DATA-2 2 DATA- DATA+3 3 DATA+ ·The connection between the light fixture and DMX512, light fixture and light fixture should use five core shielded cable and make sure its diameter is not less than 0.3mm.XLR plug/socket and the wire should be connected as the picture aboved.

  • Page 15: Remote Control

    Refer to the attached DMX channel list and control the light via DMX512. (For specific operation methods, please refer to the DMX512 console operation manual.) Note: DMX Channel List《 Forza 300B DMX Channel List (NANLITE) 》please download it from www.nanlite.com 3. 2.4G Remote Control Set the address of the 2.4G remote controller to be consistent with the light fixture, then the light fixture can be...

  • Page 16: Rdm Remote Control

    4. RDM Romote Control ① Connect the light fixture to the console with RDM function with a connection cable, the connection method is the same as the DMX512 console. ② Set the address of the RDM consloe to be consistent with the light fixture. ③...
  • Page 17 CCT MODE CH: 512 CCT MODE CH: 512 5600K 100% 5600K 100% Note: In other modes, DIM range is the same as the CCT MODE. When the light function is unlocked, in any modes, press in the ''left knob'', the light will off and the brightness shown on the screen is 0%. Press in again to restore the previous states.

  • Page 18: Effect Key

    CCT: 2700K - 7500K SPEED: 8s left knob right knob ·Forza 300B has built-in effects: CCT LOOP, INT LOOP, FLASH, PULSE, STORM AUTO, STORM MANUAL, TV, PAPARAZZI, CANDLE/FIRE, BAD BULB, FIREWORK, EXPLOSION AUTO, EXPLOSION MANUAL and WELDING. CCT MODE CCT MODE...
  • Page 19 ① CCT LOOP CCT LOOP setting: rotate the "right knob" to select DIM, CCT and SPEED (Range 2s-30s), then rotate the "left knob" to set the parameters of the corresponding options. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: CCT LOOP EFFECT: CCT LOOP DIM: 100%...
  • Page 20 ②I NT LOOP INT LOOP setting: rotate the "right knob" to select DIM, CCT and SPEED (Range 2s .. 30s), then rotate the "left knob" to set the parameters of the corresponding options. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: INT LOOP EFFECT: INT LOOP DIM:...
  • Page 21 ③ FLASH FLASH setting: rotate the "right knob" to select DIM, CCT, INTERVALS (Range: 0.1s..10.0s) and FLASH RATIO (Range: 0% .. 100%), then rotate the "left knob" to set the parameters of the corresponding options. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: FLASH EFFECT: FLASH...
  • Page 22 ④ PULSE PULSE setting: rotate the "right knob" to select DIM, CCT and PULSES/MIN (Range: 1...240), then rotate the "left knob" to set the parameters of the corresponding options. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: PULSE EFFECT: PULSE DIM: 100% DIM: 100%...
  • Page 23 ⑤ STORM AUTO STORM AUTO setting: rotate the "right knob" to select DIM,CCT and INTVL RANGE (Range: 1s ... 60s) , then rotate the "left knob" to set the parameters of the corresponding options. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: STORM AUTO EFFECT: STORM AUTO...
  • Page 24 ⑥ STORM MANUAL STORM MANUAL setting: rotate the "right knob" to select DIM and CCT, then rotate the "left knob" to set the parameters of the corresponding options. Press "right knob" to trigger Storm. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: STORM MANUAL EFFECT: STORM MANUAL...
  • Page 25 ⑦ TV setting: rotate the "right knob" to select DIM,CCT, CCT SHITF (Range: 0K...3000K) and SPEED (Range: 1...100), then rotate the "left knob" to set the parameters of the corresponding options. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: TV EFFECT: TV DIM: 0% - 100%...
  • Page 26 ⑧ PAPARAZZI PAPARAZZI setting: rotate the "right knob" to select DIM, CCT and SPEED (Range:1...100), then rotate the "left knob" to set the parameters of the corresponding options. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: PAPARAZZI EFFECT: PAPARAZZI DIM: 100% DIM: 100%...
  • Page 27 ⑨ CANDLE/FIRE CANDLE/FIRE setting: rotate the "right knob" to select DIM, CCT and SPEED (Range: 1...100), then rotate the "left knob" to set the parameters of the corresponding options. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: CANDLE/FIRE EFFECT: CANDLE/FIRE DIM: 0% - 100% DIM: 0% - 100%...
  • Page 28 ⑩ BAD BULB BAD BULB setting: rotate the "right knob" to select DIM, CCT, INTENSITY (Range: 1...100) and SPEED (Range: 1...100), then rotate the "left knob" to set the parameters of the corresponding options. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: BAD BULB EFFECT: BAD BULB...
  • Page 29 ⑪ FIREWORK RIREWORK setting: rotate the "right knob" to select DIM ,CCT, SPEED (Range: 1...100) and DECAY(Range: 1...100), then rotate the "left knob" to set the parameters of the corresponding options. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: FIREWORK EFFECT: FIREWORK DIM: 100%...
  • Page 30 ⑫ EXPLOSION AUTO EXPLOSION AUTO setting: rotate the "right knob" to select DIM, CCT, SPEED (Range: 1...100) and DECAY (Range: 1...100), then rotate the "left knob" to set the parameters of the corresponding options. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: EXPLOSION AUTO EFFECT: FIREWORK...
  • Page 31 ⑬ EXPLOSION MANUAL EXPLOSION MANUAL setting: rotate the "right knob" to select DIM, CCT and DECAY (Range 1...100), then rotate the "left knob" to set the parameters of the corresponding options. EFFECT MODE EFFECT MODE CH: 512 CH: 512 EFFECT: EFFECT: EXPLOSION MANUAL EXPLOSION MANUAL...
  • Page 32 Rotate the "left knob" to set the parameters of the corresponding options. NOTE: When the PAUSE is on , WELDING will pause. ·Lighting effects and additional functionality maybe added with future firmware releases, for details of these please see www.nanlite.com.

  • Page 33: Menu Key

    4. MENU Key: Press the MENU key to enter the interface of menu, the menu includes DIM OUTPUT, ROTATE SCREEN, ADDRESS/DMX, WIRELESS CONTROL, FAN,SCREEN LIGHT, BUTTON BACKLIGHT, LANGUAGE and VERSION. The operation of the menu: MENU CH: 512 OUTPUT MODE ROTATE SCREEN ADDRESS/DMX WIREELESS PROTOCOL...

  • Page 34: ① Output Mode

    ① OUTPUT MODE MENU MENU CH: 512 CH: 512 OUTPUT MODE MAX OUTPUT ROTATE SCREEN CONSTANT OUTPUT ADDRESS/DMX WIREELESS PROTOCOL SCREEN LIGHT PRESS “MENU” TO RETURN Rotate the ''right knob'' to the DIM OUTPUT and press in the ''right knob'' to enter the correspoding secondary menu. MENU MENU CH: 512...

  • Page 35: ② Rotate Screen

    ② ROTATE SCREEN MENU MENU CH: 512 CH: 512 OUTPUT MODE ROTATE SCREEN Do you want to rotate screen ADDRESS/DMX WIREELESS PROTOCOL SCREEN LIGHT PRESS “MENU” TO RETURN Rotate the ''right knob'' to the ROTATE SCREEN and press in the right knob to enter the correspoding secondary menu MENU CH: 512...

  • Page 36: ④ Wireless Protocol

    Rotate the ''right knob'' to select the V1.0 or V2.0 and press in the ''right knob'' to set. Note: Forza 300B supports V1.0 and V2.0 wireless protocol, when using the WS-RC-C2 for remote control, the wireless protocol should be set to V2.0 and set to V1.0 while using other remote controllers.

  • Page 37: ⑤ Fan

    ⑤ MENU MENU CH: 512 CH: 512 OUTPUT MODE ROTATE SCREEN FAN STATUS ADDRESS/DMX WIREELESS PROTOCOL SCREEN LIGHT PRESS “MENU” TO RETURN Rotate the ''right knob'' to the FAN and press in the ''right knob'' to enter the correspoding secondary menu. MENU MENU CH: 512...

  • Page 38: ⑥ Screen Light

    ⑥ SCREEN LIGHT MENU MENU CH: 512 CH: 512 OUTPUT MODE ROTATE SCREEN SCREEN BRIGHTNESS ADDRESS/DMX WIREELESS PROTOCOL SCREEN LIGHT PRESS “MENU” TO RETURN Rotate the ''right knob'' to the SCREEN LIGHT and press in the ''right knob'' to enter the correspoding secondary menu. MENU MENU CH: 512...

  • Page 39: ⑦ Button Backlight

    ⑦ BUTTON BACKLIGHT MENU MENU CH: 512 CH: 512 ROTATE SCREEN ADDRESS/DMX BUTTON BACKLIGHT WIREELESS PROTOCOL SCREEN LIGHT BUTTON BACKLIGHT PRESS “MENU” TO RETURN Rotate the ''right knob'' to the BUTTON BACKLIGHT and press in the ''right knob'' to enter the correspoding secondary menu. MENU MENU CH: 512...

  • Page 40: ⑧ Language

    ⑧ LANGUAGE MENU MENU CH: 512 CH: 512 ADDRESS/DMX ENGLISH WIREELESS PROTOCOL 简体中文 SCREEN LIGHT BUTTON BACKLIGHT LANGUAGE PRESS “MENU” TO RETURN Rotate the ''right knob'' to the LANGUAGE and press in the ''right knob'' to enter the correspoding secondary menu. MENU MENU CH: 512...

  • Page 41: ⑨ Version

    USB drive that has BUTTON BACKLIGHT new firmware, and restart the LANGUAGE light, www.nanlite.com VERSION PRESS “MENU” TO RETURN Rotate the "right knob" to the VERSION, and press in the "right knob" to check the current version.

  • Page 42: Safety Precautions

    4. When cleaning the light, please wipe off debris or dirty by using a cloth with clean water or neutral cleanser. 5. The Forza 300B should be safely operated where it won’t be at risk of getting wet or under extreme temperatures.

  • Page 43: Product Includes

    What's in the box? Please kindly check Forza 300B x 1 Light Stand Clamp x 1 Reflector × 1 DC Connecting Power Cable 3M × 1 Power adapter × 1 Cable 2.5M x 1 Carrying bag x 1 User Manual × 1...

  • Page 44: General Fault Detection And Diagnosis

    If the failure is not resolved after troubleshooting, please contact place of purchase. This manual and all stats within it were produced under controlled conditions, and are accurate at time of print. Any future changes to design/technical data can be found at www.nanlite.com.
  • Page 45 Version: V3 2021-04-29 +86-754-85751187 +86-754-85300887 service@nanlite.com Zhanglin,324,Dongli Chenghai Shantou Guangdong China www.nanlite.com...
