Exmark QUEST BAGGER Setup Instructions

Hide thumbs Also See for QUEST BAGGER:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Literature Pack
Part #
—
Assembly Diagram
Key
Qty
Description
1
1
Weight, Suitcase
2
1
Weight, Flat
3
1
Rod, Weight Lock
4
1
Bracket, Holding
5
4
Nut, Nyloc 3/8-16 Flg
6
1
Bracket, Weight Mount RH
7
1
Hopper
8
4
Screw, Hex Flange 3/8-16 x 1 1/4
9
2
Screw Hex Flange 3/8-16 x 1
10
1
Bracket, Weight Mount LH
11
2
Washer, 3/8 SAE
12
1
Asm, Lower Tube (421 Series Decks)
Asm, Lower Tube (501 Series Decks)
13
1
Tube, Upper
14
4
Nut-Nyloc 5/16-18 Flg
15
1
Bracket-Upper Support
16
1
Spacer
© 2012—Exmark Mfg. Co., Inc.
P.O. Box 808
Beatrice, NE 68310
Description
Manual, Operator's
QUEST™ BAGGER
For Quest™Bagger Serial Nos. 312,000,000 & Higher
(To fit All Quest™ Units Serial Nos. 920,000 & Higher)
Qty.
1
Read before operating the machine.
Key
Qty
Description
17
2
Screw-HWH 5/16-18 x 3/4 TF
18
1
Pin-Clevis
19
3
Pin-Hair
20
2
Screw-HH FLG 5/16-18 x 1
21
1
Vent-Air
22
2
Washer-1/2 SAE
23
2
Rod-Support
24
1
Frame-Bagger
25
2
Bag
26
1
Bracket-Lower Support
27
2
Bolt-Carriage 5/16-18 x 3/4
28
1
Knob (502 Series Deck)
Bolt-Carr 5/16 x 1 3/8 inch (502 Series
29
1
Deck)
30
1
Nut-Flange 5/16 (502 Series Deck)
31
1
Asm-Lower Tube (502 Series Deck)
32
1
Washer (502 Series Deck)
Setup Instructions
Use
Part No. 4501-215 Rev. A
Printed in the USA.
All Rights Reserved

Advertisement

loading

Related Manuals for Exmark QUEST BAGGER

Summary of Contents for Exmark QUEST BAGGER

  • Page 1 Nut-Flange 5/16 (502 Series Deck) Nut-Nyloc 5/16-18 Flg Asm-Lower Tube (502 Series Deck) Bracket-Upper Support Washer (502 Series Deck) Spacer © 2012—Exmark Mfg. Co., Inc. Part No. 4501-215 Rev. A P.O. Box 808 Printed in the USA. Beatrice, NE 68310 All Rights Reserved...
  • Page 2 Figure 1...

  • Page 3: Safety Alert Symbol

    Safety Safety Alert Symbol This Safety Alert Symbol (Figure 2) is used both in this setup instructions and on the machine to identify important safety messages which must be followed to avoid accidents. This symbol means: ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Figure 3 Figure 2 1.
  • Page 4 3. With the hopper open, install the bags by sliding the bag frame hook onto the retaining bracket. Figure 5 1. Clevis pin 4. Washer 2. Haripin 5. Support rod 3. Bagger frame 6. Slot 5. On the RH side of the mower, insert the flared end of the support rod into the slot on mower frame (see Figure 5).
  • Page 5 5. Install the RH weight mount bracket using two 3/8-16 x 1 1/4 inch hex screws and the nuts retained in step 4. 6. Install the weight holding bracket by aligning the outboard holes in the bracket with the LH and RH weight mounting brackets.
  • Page 6 WARNING Operating the mower with the bagger installed and the front weights removed may cause loss of traction and steering control or an unstable condition which could result in injury or death. • Install the bagger only when the front weights are installed.
  • Page 7 B. Install the existing baffle with the existing bolts E. Secure the lower tube assembly to the deck by and nuts after removing the plate assembly (see fastening the flexible latch to the deck clasp (see Figure 15). Figure 17). Figure 15 1.
  • Page 8 Fill Out Warranty Registration Form Fill out the online warranty registration form.
