Setting the Telephone Line Type

Before using your machine, you need to make sure it is set for your telephone line type. If you are unsure of
your telephone line type, check with your local telephone company. The factory default setting of your
machine varies depending on the current country selection. You can print the USER'S DATA LIST to check
the current setting. (
If you need to change the setting, follow this procedure.
1
Press Menu.
2
Use or to select FAX SETTINGS.
3
Press OK twice.
4
Use or to select TEL LINE TYPE.
5
Press OK.
6
Use or to select the telephone line type setting you
want to set.
• You can select from the following:
- ROTARY PULSE (For pulse dialling)
- TOUCH TONE (For tone dialling)
7
Press OK.
8
Press Stop/Reset to return to standby mode.

Dialling Through a Switchboard

A PBX (Private Branch Exchange) is an on-site telephone switchboard. If your machine is connected through
a PBX or other telephone switching system, you have to dial the outside line access number first, and then the
number of the party you are calling.
To facilitate this procedure, you can register the PBX access type and the outside line access number under the
R button so that you only need to press this button before dialling the fax/telephone number you want to reach.
See below for details.
The settings available and the factory default setting vary depending on the current country selection. You can
print the USER'S DATA LIST to check the current setting. (
1
Press Menu.
2
Use or to select FAX SETTINGS.
2-6
p. 2-5)
MENU
5.FAX SETTINGS
Ex:
FAX SETTINGS
1.USER SETTINGS
USER SETTINGS
1.DATE & TIME
USER SETTINGS
9.TEL LINE TYPE
TEL LINE TYPE
Ex:
TEL LINE TYPE
Ex:
USER SETTINGS
10.R-KEY SETTING
p. 2-5)
MENU
5.FAX SETTINGS
Ex:
TOUCH TONE
ROTARY PULSE
