[MAIN UNIT]
REF
PARTS
DESCRIPTION
NO.
NO.
C290
4030009770 S.CER C1005 CH 1H 220J-T
C300
4030019970 S.CER C1005 JB 0J 105K-T
C301
4030019970 S.CER C1005 JB 0J 105K-T
C302
4030019740 S.CER C1005 JB 1H 102K-T
C303
4030019740 S.CER C1005 JB 1H 102K-T
C304
4030019810 S.CER C1005 JB 1E 103K-T
C306
4030019740 S.CER C1005 JB 1H 102K-T
C307
4030019560 S.CER GRM21BB31C106KE15L
C308
4030009740 S.CER C1005 CH 1H 100C-T
C309
4550006250 S.TAN
TEESVA 1A 106M8R
C310
4030019970 S.CER C1005 JB 0J 105K-T
C311
4030019740 S.CER C1005 JB 1H 102K-T
C314
4030019930 S.CER C1005 JB 1A 104K-T
C315
4030019740 S.CER C1005 JB 1H 102K-T
C316
4030011320 S.CER C1005 CH 1H 470J-T
C317
4030019970 S.CER C1005 JB 0J 105K-T
C318
4030009800 S.CER C1005 JB 1H 471K-T
C319
4030019930 S.CER C1005 JB 1A 104K-T
C320
4030019740 S.CER C1005 JB 1H 102K-T
C321
4030009800 S.CER C1005 JB 1H 471K-T
C325
4030019740 S.CER C1005 JB 1H 102K-T
C328
4550000530 S.TAN
TEESVA 1V 104M8R
C329
4030019740 S.CER C1005 JB 1H 102K-T
C330
4030019740 S.CER C1005 JB 1H 102K-T
C331
4030019930 S.CER C1005 JB 1A 104K-T
C332
4030019740 S.CER C1005 JB 1H 102K-T
C333
4030009740 S.CER C1005 CH 1H 100C-T
C334
4550002980 S.TAN
TEESVA 1C 225M8R
C335
4030011320 S.CER C1005 CH 1H 470J-T
C336
4030019810 S.CER C1005 JB 1E 103K-T
C337
4030010090 S.CER C1005 CH 1H 560J-T
C338
4030011700 S.CER C1005 CH 1H 040B-T
C339
4030019740 S.CER C1005 JB 1H 102K-T
C340
4550000550 S.TAN
TEESVA 1V 224M8R
C341
4030019930 S.CER C1005 JB 1A 104K-T
C342
4030009710 S.CER C1005 CH 1H 070C-T
C343
4030011320 S.CER C1005 CH 1H 470J-T
C345
4030019740 S.CER C1005 JB 1H 102K-T
C346
4030009800 S.CER C1005 JB 1H 471K-T
C347
4030011680 S.CER C1005 CH 1H 030B-T
C348
4030019810 S.CER C1005 JB 1E 103K-T
C349
4030019740 S.CER C1005 JB 1H 102K-T
C350
4030019740 S.CER C1005 JB 1H 102K-T
C351
4030009800 S.CER C1005 JB 1H 471K-T
C352
4030019930 S.CER C1005 JB 1A 104K-T
C353
4030019810 S.CER C1005 JB 1E 103K-T
C354
4030019930 S.CER C1005 JB 1A 104K-T
C355
4030019740 S.CER C1005 JB 1H 102K-T
C356
4030019640 S.CER C1005 CH 1H 0R3B-T
C357
4030019930 S.CER C1005 JB 1A 104K-T
C358
4030019640 S.CER C1005 CH 1H 0R3B-T
C359
4030019970 S.CER C1005 JB 0J 105K-T
C360
4030019740 S.CER C1005 JB 1H 102K-T
C361
4030019740 S.CER C1005 JB 1H 102K-T
C362
4030019640 S.CER C1005 CH 1H 0R3B-T
C363
4030019810 S.CER C1005 JB 1E 103K-T
C364
4030011680 S.CER C1005 CH 1H 030B-T
C365
4030011680 S.CER C1005 CH 1H 030B-T
C366
4030019930 S.CER C1005 JB 1A 104K-T
C367
4030011320 S.CER C1005 CH 1H 470J-T
C368
4030007030 S.CER C1608 CH 1H 150J-T
C369
4030011700 S.CER C1005 CH 1H 040B-T
C370
4030019740 S.CER C1005 JB 1H 102K-T
C371
4030011770 S.CER C1608 CH 1H 060B-T
C372
4030011320 S.CER C1005 CH 1H 470J-T
C373
4030019740 S.CER C1005 JB 1H 102K-T
C374
4030019740 S.CER C1005 JB 1H 102K-T
C375
4030007050 S.CER C1608 CH 1H 220J-T
C376
4030007040 S.CER C1608 CH 1H 180J-T
C377
4550006250 S.TAN
TEESVA 1A 106M8R
C378
4030019740 S.CER C1005 JB 1H 102K-T
C379
4030019740 S.CER C1005 JB 1H 102K-T
C380
4030007020 S.CER C1608 CH 1H 120J-T
C381
4030007020 S.CER C1608 CH 1H 120J-T
C382
4030019740 S.CER C1005 JB 1H 102K-T
C383
4030010250 S.CER C1005 CH 1H 101J-T
C385
4030019810 S.CER C1005 JB 1E 103K-T
C386
4030011640 S.CER C1005 CH 1H 010B-T
C387
4030019740 S.CER C1005 JB 1H 102K-T
C388
4030019740 S.CER C1005 JB 1H 102K-T
C389
4030019740 S.CER C1005 JB 1H 102K-T
C390
4030011630 S.CER C1005 CH 1H 0R5B-T
C391
4030019740 S.CER C1005 JB 1H 102K-T
C392
4030019880 S.CER C1005 JB 1A 333K-T
C393
4030019740 S.CER C1005 JB 1H 102K-T
C394
4030019740 S.CER C1005 JB 1H 102K-T
C395
4030019740 S.CER C1005 JB 1H 102K-T
C396
4030010280 S.CER C1005 CH 1H 390J-T
C397
4030019740 S.CER C1005 JB 1H 102K-T
C398
4030011680 S.CER C1005 CH 1H 030B-T
C399
4030011640 S.CER C1005 CH 1H 010B-T
C400
4030011320 S.CER C1005 CH 1H 470J-T
C401
4030019930 S.CER C1005 JB 1A 104K-T
C402
4030009770 S.CER C1005 CH 1H 220J-T
C403
4030009770 S.CER C1005 CH 1H 220J-T
C404
4030019930 S.CER C1005 JB 1A 104K-T
C405
4030019810 S.CER C1005 JB 1E 103K-T
C406
4030019810 S.CER C1005 JB 1E 103K-T
C407
4030019810 S.CER C1005 JB 1E 103K-T
C408
4030019740 S.CER C1005 JB 1H 102K-T
C409
4030009780 S.CER C1005 CH 1H 270J-T
C412
4030019810 S.CER C1005 JB 1E 103K-T
C413
4030019740 S.CER C1005 JB 1H 102K-T
C414
4030019740 S.CER C1005 JB 1H 102K-T
C415
4030019740 S.CER C1005 JB 1H 102K-T
All manuals and user guides at all-guides.com
[MAIN UNIT]
H/V
REF
M.
LOCATION
B
69/13
C417
T
54.5/30.2
C418
T
54.5/31.1
C419
T
55.5/28.1
C420
T
45/4.4
T
55.1/23.9
T
55/20.3
T
56.4/20.3
T
51.6/19.7
T
58.3/20
T
49/14.8
T
47.5/15.4
T
57.2/11.8
T
44.8/14.7
C421
T
56/11.4
C422
T
49/13.9
C423
T
57.2/10.9
C424
T
45.5/8.8
C425
T
49/15.7
C426
T
45.5/9.7
C427
T
47/5.5
C428
T
49.4/3.3
C429
T
45.5/10.6
C430
T
55.2/1.8
C431
T
53.1/5
C432
T
55.5/3
C433
T
55.5/22.7
C434
T
56.4/4.5
C435
T
46.6/19.6
C500
T
56.9/26.9
C501
T
57.9/29.4
C502
T
56.7/29.9
C504
T
58.4/2
C505
B
56.7/11.5
C506
B
52.6/8.1
C507
T
57.9/30.4
C508
T
48/20.9
C509
B
49.9/10.2
C512
B
46.4/39.9
C513
T
56.6/32.8
C515
B
54.2/8.5
C516
B
54.1/15.9
C517
T
58.4/15.8
C518
B
46.4/39
C519
B
51.1/38.9
C520
B
56.7/8.4
C522
B
48.1/38.8
C523
B
43.6/38.2
C524
B
51.5/10.9
C526
B
47.7/41.4
C527
B
55.5/6.2
C528
B
55.1/42.8
C529
B
45.6/41.2
C530
B
56.4/14.5
C532
B
55.5/7.8
C535
B
56/42.8
C536
B
43/8.1
C537
B
44.2/8.6
C538
B
52.3/14.5
C539
B
41.7/6.9
C540
B
50.4/15.4
C541
B
43/9.1
C542
B
49.8/8
C543
B
52.7/6.1
C544
B
48.9/8
C545
T
49.3/41.8
C546
B
52.3/16.2
C547
B
53.2/18.8
C548
B
56.1/19.5
C549
B
57.5/43.3
C551
B
46.8/42.4
C552
B
41.2/5.7
C553
B
50.9/5.2
C554
B
52.1/4.1
C555
B
48/9.8
C556
B
41.2/11.5
C557
B
41.2/9
C558
B
50.1/19.4
C559
B
42.9/42.2
C560
B
48.1/42.6
C561
B
56.6/17.6
C562
B
49.4/3.9
C564
B
45.8/5.6
C565
B
52.7/48.7
C566
B
46.8/13.1
C568
B
47.2/16.5
C570
B
52.7/47.8
C572
B
50.3/48.5
C573
B
47.1/8.9
C574
B
45.9/7.7
C575
B
48.2/15.4
C576
B
46.7/5.6
C577
B
52.2/49.9
C578
B
48.6/13.1
C579
B
45.3/8.9
C580
B
57.1/49.5
C582
B
55.2/46.7
B
57.4/39.9
B
59.4/45.4
B
55.5/38.9
B
59.4/42.4
B
57.8/37.7
B
43.7/12.8
B
40.7/23.8
B
37.7/24.5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 5
PARTS
DESCRIPTION
NO.
NO.
4030019740 S.CER C1005 JB 1H 102K-T
4030009740 S.CER C1005 CH 1H 100C-T
4030009760 S.CER C1005 CH 1H 150J-T
4030009710 S.CER C1005 CH 1H 070C-T
4030009710 S.CER C1005 CH 1H 070C-T
4030009710 S.CER C1005 CH 1H 070C-T
4030011700 S.CER C1005 CH 1H 040B-T
4030009710 S.CER C1005 CH 1H 070C-T
4030009710 S.CER C1005 CH 1H 070C-T
4030009710 S.CER C1005 CH 1H 070C-T
4030009710 S.CER C1005 CH 1H 070C-T
4030009710 S.CER C1005 CH 1H 070C-T
4030009710 S.CER C1005 CH 1H 070C-T
4030019740 S.CER C1005 JB 1H 102K-T
4030009830 S.CER C1005 CH 1H 180J-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019810 S.CER C1005 JB 1E 103K-T
4030009780 S.CER C1005 CH 1H 270J-T
4030009710 S.CER C1005 CH 1H 070C-T
4030010280 S.CER C1005 CH 1H 390J-T
4030009740 S.CER C1005 CH 1H 100C-T
4030019740 S.CER C1005 JB 1H 102K-T
4030011640 S.CER C1005 CH 1H 010B-T
4030009760 S.CER C1005 CH 1H 150J-T
4030019810 S.CER C1005 JB 1E 103K-T
4030011640 S.CER C1005 CH 1H 010B-T
4030019740 S.CER C1005 JB 1H 102K-T
4030011680 S.CER C1005 CH 1H 030B-T [USA] only T
4030019740 S.CER C1005 JB 1H 102K-T
4030009710 S.CER C1005 CH 1H 070C-T
4030011320 S.CER C1005 CH 1H 470J-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019810 S.CER C1005 JB 1E 103K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030009740 S.CER C1005 CH 1H 100C-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030009710 S.CER C1005 CH 1H 070C-T
4030009770 S.CER C1005 CH 1H 220J-T
4030019900 S.CER C1005 JB 1A 473K-T
4030019930 S.CER C1005 JB 1A 104K-T
4030019810 S.CER C1005 JB 1E 103K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019930 S.CER C1005 JB 1A 104K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030011320 S.CER C1005 CH 1H 470J-T
4030019810 S.CER C1005 JB 1E 103K-T
4030019810 S.CER C1005 JB 1E 103K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030011630 S.CER C1005 CH 1H 0R5B-T
4030009720 S.CER C1005 CH 1H 080C-T
4030019740 S.CER C1005 JB 1H 102K-T
4030011320 S.CER C1005 CH 1H 470J-T
4030019810 S.CER C1005 JB 1E 103K-T
4030011660 S.CER C1005 CH 1H 020B-T
4030009720 S.CER C1005 CH 1H 080C-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030011640 S.CER C1005 CH 1H 010B-T
4030019930 S.CER C1005 JB 1A 104K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019560 S.CER GRM21BB31C106KE15L
4030011320 S.CER C1005 CH 1H 470J-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019930 S.CER C1005 JB 1A 104K-T
4030009750 S.CER C1005 CH 1H 120J-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019930 S.CER C1005 JB 1A 104K-T
4030019930 S.CER C1005 JB 1A 104K-T
4030019810 S.CER C1005 JB 1E 103K-T
4030009720 S.CER C1005 CH 1H 080C-T
4030019810 S.CER C1005 JB 1E 103K-T
4030011640 S.CER C1005 CH 1H 010B-T
4030019930 S.CER C1005 JB 1A 104K-T
4030019810 S.CER C1005 JB 1E 103K-T
4030009790 S.CER C1005 CH 1H 330J-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030011320 S.CER C1005 CH 1H 470J-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019740 S.CER C1005 JB 1H 102K-T
4550007650 S.TAN
F931V105MAABMA
4030019740 S.CER C1005 JB 1H 102K-T
4030010250 S.CER C1005 CH 1H 101J-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030009830 S.CER C1005 CH 1H 180J-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030011670 S.CER C1005 CH 1H 2R5B-T
4030019740 S.CER C1005 JB 1H 102K-T
4030019740 S.CER C1005 JB 1H 102K-T
4030007070 S.CER C1608 CH 1H 330J-T
H/V
M.
LOCATION
B
36.5/25.7
B
58.1/33.9
B
43/22.6
[EUR] B
38.2/27.5
[UK]
[TPE]
[USA]
[KOR]
[AUS]
[CHN]
[EXP]
[EXP-01]
[RSP]
B
55.7/24.2
B
54.8/27.5
B
40.8/14.2
B
54.8/25
B
43.9/22.6
B
38/28.8
B
40.8/15.8
B
53.9/23.3
T
42.4/15.8
B
44.6/18.7
B
44.9/22.6
B
56.3/22.9
B
58.4/24.4
B
38.6/22.5
42.6/20.5
T
41.3/18.8
B
49.1/27.7
B
49.2/23.4
B
49.2/22.5
T
45.2/1.7
B
45.9/25.6
B
40.7/25.2
B
47.2/27.8
T
41.3/17.9
T
42.2/6.6
B
47/23
B
44.9/24.2
T
44.3/1.7
T
42.3/12.3
T
42.2/5.7
T
20.4/17.2
B
34.3/18
T
42.3/11.4
T
40.5/14.5
B
35.9/22
B
30.2/20.1
B
34.3/15
B
35.9/21.1
B
32.8/25.5
B
33.1/21.9
B
32.6/20.1
B
31.5/21.9
B
36.5/4.3
B
31.1/23.1
B
30.3/24.6
T
36.9/12.7
T
40.4/9.4
B
30.3/25.5
T
37.2/14.1
T
40/8.2
T
36.9/4.3
B
28/21.9
B
27.2/20.3
T
36/12.7
T
38.6/9.4
T
38.4/6.4
T
37.2/15
T
38.6/3.8
B
37.9/9.5
B
28.5/25.5
B
36.8/14.1
B
26.4/25.1
B
33.8/12
B
34.3/14.1
T
33/12.9
T
34.4/4.5
T
32.5/11.7
B
22/22
B
25/21.7
B
23.2/21.7
T
23.8/15
B
10.1/19.7
T
32.1/16.3
B
11.7/19.7
B
36.9/18.9
T
31.2/16.3
B
20.5/24
T
23.1/16.8
T
32.1/6.1
B
21.3/20.3
T
24/16.8
B
20.2/16.6
T
24/8.5
S.=Surface mount
Advertisement
Table of Contents
