Furman AR-2330D Owner's Manual

AR-2330D front view
AR-Series Features
● Output capacity 30 amps
● Output voltage can be changed to 220V or 240V with
internal jumper
● Usable range for most equipment is an ad di tion al 10% above
and below the capture ranges shown in Specifi cations (pg. 4)
● One twist lock inlet and one regulated, con di tioned
twistlock outlet on rear panel
● Eight-tap toroidal autoformer
● 10-LED bargraph Input Voltage meter
● 10-LED bargraph true RMS reading Output Current meter
● Extreme overvoltage/undervoltage causes in stant
shutdown, protecting equip ment
● Extreme Voltage Shutdown indicator LED
● Output In Regulation in di ca tor
● Fast-acting user-accessible circuit breaker pro tects against
overload or shorts. Also acts as ON/OFF switch.
● Low stray magnetic fi eld
● Low noise, variable speed fan provides cooling for heavy-
duty, continuous op er a tion
● Rugged, two-space rack unit weighs only 49 lbs. (22 kg.)
Determine the Correct Voltage
Is 240V the correct voltage for your application?
The AR-2330D is factory set for 240V output. All equipment
should be checked fi rst, to be sure that 240V is a suit able volt-
age (normally listed near the power cord). If a lower volt age is
desired, the AR-2330D should have its internal jumper changed
to 220 or 230 volts. If in doubt, consult your dealer.
AC Line Voltage Reg u la tor
MODEL AR-2330D
Owner's Manual
AR-2330D rear view, shown with optional RRM-2 rear rack ears
General Information
Thank you for choosing a Furman AR-2330D AC Line Volt age
Reg u la tor. An AR-Series regulator is the perfect ac ces so ry to any
au dio, video, or computer rackmount system re quir ing clean,
fi l tered, and regulated AC power for optimum op er a tion.
Furman Voltage Regulators are intended to protect sensitive
electronic equipment from problems caused by AC line voltage
irregularities—brownouts or overvoltages that can cause audio
ton al changes, digital equipment malfunction (such as loss of
MIDI pro grams or other data), or, in extreme cases, permanent
dam age. The AR-2330D accepts input voltages over a wide AC
volt age range (see table above) converts them to, and stabilizes
them at ±10V for 240V output. (The output voltage can be changed
to 220V or 230V with an internal jumper.) Voltages approximately
±10% beyond the AR-2330D's range may be converted to usable
levels, depending on the requirements of the equipment. See
Figure 1.
The AR-2330D has one twistlock inlet and one twistlock out let
on the rear panel. The outlet is regulated, spike-suppressed, and
EMI/RFI fi ltered. There are no controls except an on-off break er
switch.
Limitations: The AR-2330D is for use with AC voltage only.
DC voltages should never be applied to it. Also, it does not change
or regulate line frequency. The output frequency will always be
the same as the incoming line fre quen cy.
