1115653821 Underceiling air conditioner Model name: 42TGV____CP Owner's Manual Notice: is committed to continuously improving its products to ensure the highest quality and reliability standards, and to meet local regulations and market requirements. All features and specifications are subject to change without prior notice. English Português English...
– 1 – Contents Original instruction ADOPTION OF R32 REFRIGERANT 1 Precautions for safety ..........3 This Air Conditioner has adopted a refrigerant HFC (R32) which 2 Part names .
Page 3
Thank you for purchasing this air conditioner. These safety cautions describe important matters concerning safety to prevent injury to users or other people and Please read carefully through these instructions that contain important information which complies with the damages to property. Please read through this manual after understanding the contents below (meanings of Machinery Directive (Directive 2006/42/EC), and ensure that you understand them.
– 3 – Precautions for safety Warning indications on the air conditioner unit The manufacturer shall not assume any liability for the damage caused by not observing the description of this manual. WARNING WARNING WARNING ELECTRICAL SHOCK HAZARD ELECTRICAL SHOCK HAZARD Disconnect all remote Disconnect all remote electric power supplies before servicing. electric power supplies General before servicing.
Page 5
Installation parts is required, contact a qualified installer (*1) or a qualified • Only a qualified installer (*1) or qualified service person (*1) is sevice person (*1). allowed to carry out the electrical work of the air conditioner. Under • Do not move or repair any unit by yourself. Since there is high no circumstances must this work be done by an unqualified indi voltage inside the unit, you may get electric shock when removing vidual since failure to carry out the work properly may result in elec the cover and main unit. tric shocks and/or electrical leaks. • Use of a stand more than 50 cm high to clean the filter of the indoor • After the installation work has been completed, have the installer unit or to carry out other such jobs constitutes working at heights. explain about the circuit breaker positions. In the event that trouble Due to the danger of falling off the stand and injuring yourself while has occurred in the air conditioner, set the circuit breaker to the OFF working at heights, this kind of work should not be done by unqualified position, and contact a qualified service person (*1). individuals. When this kind of work must be carried out, do not do • If the unit is installed in a small room, take appropriate measures to it yourself but ask a qualified installer (*1) or a qualified service prevent the refrigerant from exceeding the limit concentration even person (*1) to do it for you.
Page 6
– 5 – CAUTION • Stop running the air conditioner and turn off the breaker before cleaning.Otherwise, injury may result as the fan is rotating at high To disconnect the appliance from the mains supply. speed inside the unit. • This appliance must be connected to the mains by means of a Repairs switch with a contact separation of at least 3 mm. • If there is any kind of trouble (such as when an error display has appeared, there is a smell of burning, abnormal sounds are heard, The installation fuse (all types can be used) must be used for the...
Page 7
• Do not leave flammable sprays or other flammable materials near Information on the transportation, handling and storage of the the air conditioner, and do not spray flammable aerosol directly to carton the air conditioner. They may catch fire. • Stop running the air conditioner and turn off the breaker before Examples of indication on the carton cleaning.Otherwise, injury may result as the fan is rotating at high Symbol Description Symbol Description speed inside the unit. • Ask for cleaning of the air conditioner to be performed by the dealer. Cleaning the air conditioner in an improper manner may cause Keep dry Do not drop...
– 7 – Part names Wired remote controller This remote controller can control the operation of up to 8 indoor units. Indoor unit Display section Horizontal louver / Vertical grille / Air discharge In the display illustration below all the icons are shown. When the The air discharge direction can be changed.
Page 9
Operation section Push each button to select a desired operation. The control saves commands in memory and after the initial setting, there is no need for any additional settings unless changes are desired. The air conditioner can be operated by pushing the button.
– 9 – Timer operation Correct usage Three timer modes are available: (Setting of up to 168 hours is enabled.) When the air conditioner is used for the first time or when the setting is changed, follow the steps below. Settings are saved in memory and are displayed anytime the unit is turned on by pushing the button.
Adjustment of wind direction How to start swinging Unit select button When multiple indoor units are controlled with one Push , set the louver (adjustment plate For best cooling performance, adjust the louvers remote controller, wind direction can be set for each of up / down wind direction) direction to the (adjustment plates of up / down wind direction) indoor unit by selecting individually.
– 11 – Power saving mode Push buttons, to adjust the power saving mode setting. Each push of the button changes the power level by 1 % within the range from 100 % to 50 %. The factory default is 75 %. The power saving mode saves energy by limiting the maximum current which will effect cooling capacity that the unit can generate.
Self clean mode Maintenance This function is provided to dry the inside of the indoor unit by the FAN operation after running the cooling WARNING / dry / AUTO (cooling) mode to keep the indoor unit clean. The self clean time varies with the cooling / dry / Auto (cooling) operation time as follows. Cleaning the air filter and other parts of the air filter involves dangerous work in high places.
– 13 – Troubleshooting Check periodically If the unit is used for a long time, parts may deteriorate and cause malfunction or bad drainage of dehumidified Check the points described below before requesting repair. water depending on the heat, humidity, or dust. In addition to the usual maintenance, it is recommended that you have the unit checked and maintained by the dealer where you purchased it.
Operations and performance Confirmation and check Confirmation of error log When an error occurred in the air conditioner, an error When an error occurred on the air conditioner, the error Check before running Protective device code and indoor UNIT No. appear on the display part log can be confirmed with the following procedure.
– 15 – Installation Do not install the air conditioner in the following places Do not install the air conditioner in any place within 1 m from a TV, stereo, or radio set. If the unit is installed in such place, noise transmitted from the air conditioner affects the operation of these appliances. Do not install the air conditioner near a high frequency appliance (sewing machine or massager for business use, etc.), otherwise the air conditioner may malfunction.
