Specifications

CPU
Chipset
Memory
Expansion Slot
Multi-GPU
Onboard Graphics
16
Specifications
∙ Supports 10th Gen Intel® Core™ Processors, 11th Gen
Intel® Core™ Processors, Pentium® Gold and Celeron®
Processors*
∙ Processor socket LGA1200
* Please go to intel.com for compatibility information.
Intel® Z590 Chipset
∙ 4x DDR4 memory slots, support up to 128GB*
∙ Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel®
CPU (by JEDEC & POR)*
∙ Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen
Intel® CPU (by JEDEC & POR)*
∙ Max overclocking frequency:
▪ 1DPC 1R Max speed up to 5600 MHz
▪ 1DPC 2R Max speed up to 4800+ MHz
▪ 2DPC 1R Max speed up to 4400+ MHz
▪ 2DPC 2R Max speed up to 4000+ MHz
∙ Supports Dual-Channel mode
∙ Supports non-ECC, un-buffered memory
∙ Supports Intel® Extreme Memory Profile (XMP)
*Please refer to www.msi.com for more information on compatible memory
∙ 3x PCIe x16 slots
▪ Support x16/x0/x4, x8/x8/x4, x8/x4+x4/x4
▪ PCI_E1 & PCI_E3 slots (From CPU)
▫ Support up to PCIe 4.0 for 11th Gen Intel® CPU
▫ Support up to PCIe 3.0 for 10th Gen Intel® CPU
▪ PCI_E5 slot (From Z590 chipset)
▫ Supports up to PCIe 3.0
∙ 2x PCIe 3.0 x1 slots (From Z590 chipset)
∙ Supports 2-Way NVIDIA® SLI™ Technology
∙ Supports 3-Way AMD® CrossFire™ Technology
1x HDMI 2.0b with HDR port, supports a maximum
resolution of 4K 60Hz*
*Available only on processors featuring integrated graphics.
* Graphics specifications may vary depending on the CPU installed.
Continued on next column
