Parts Locator

7
6
5
1. USB Connector
2. Power Supply Connector
3. Power Switch
4. External LED Attachments
USB-7855R OEM Device Components
The following table lists the interfacing components on the NI USB-7855R OEM device and
the component manufacturers.
Components
LEDs
USB connector
Power connector
Power switch
The following table lists and describes the I/O connectors on the NI USB-7855R OEM device.
Refer to the connector manufacturer for information about using and matching these
connectors.
Table 1. USB-7855R OEM Device Components
Reference Designator
DS2, DS5, DS7, DS8, DS10
DS4
J5
J1, J2, & J9
SW2
8
4
5. Connector 0 (Analog)
6. Connector 1 (Digital)
7. Connector 2 (Digital)
8. Connector 3 (Digital)
SunLED (XZBB54W-1TN)
Everlight Electronic (QTLP630C-2 T/R)
Phoenix Contact (1727566)
C&K (E101J1AQE2)
NI USB-7855R OEM User Manual | © National Instruments | 3
1
2
Manufacturer
Tyco (292304-1)
3
