- Page 1 National Instruments PCIe-7846 Manual Get Pricing & Availability at ApexWaves.com Call Today: 1-800-915-6216 Email: sales@apexwaves.com https://www.apexwaves.com/modular-systems/national-instruments/r-series/PCIe-7846...
-
Page 2: Hardware Overview
R Series Digital I/O Module for PCI Express, 8 AI, 8 AO, 48 DIO, 500 kS/s AI, Kintex-7 160T FPGA This document provides compliance, pinout, connectivity, mounting, and power information for the PCIe-7846. Hardware Overview The following high-level block diagram represents the PCIe-7846. Figure 1. PCIe-7846 Block Diagram 100 MHz Flash DDR3 RAM... - Page 3 Positive analog input signal connection Negative analog input signal connection AISENSE Reference connection for NRSE measurements AIGND Ground reference for the analog input signal Analog output signal connection AOGND Ground reference for the analog output signal 2 | ni.com | NI PCIe-7846 User Manual...
-
Page 4: Analog Input
Analog Input The PCIe-7846 provides connections for eight AI channels. Each channel has an AI+ pin, AI- pin, and AIGND pin to which you can connect both single-ended or differential voltage signals. Use the AISENSE pin to connect non-referenced single-ended signals. - Page 5 AI+ and the negative voltage signal to AI-. To connect grounded differential signals to the PCIe-7846, you must also connect the signal reference to AI GND. Figure 4. Connecting Grounded Differential Signals to the PCIe-7846...
-
Page 6: Analog Output
AIGND Connection Accessory NI PCIe-7846 Analog Output The PCIe-7846 provides connections for eight analog output channels. Each channel has an AO pin and AOGND pin to which you can connect a load. Figure 6. Connecting a Load LOAD AOGND Connection... -
Page 7: Field Wiring Considerations
When the system powers on, the DIO channels are set as input low with pull-down resistors. To set another power-on state, you can configure the NI PCIe-7846 to load a VI when the system powers on. The VI can then set the DIO lines to any power-on state. -
Page 8: Power Source
Separate NI PCIe-7846 signal lines from high-current or high-voltage lines. These lines can induce currents in or voltages on the NI PCIe-7846 signal lines if they run in parallel paths at a close distance. To reduce the magnetic coupling between lines, separate them by a reasonable distance if they run in parallel or run the lines at right angles to each other. -
Page 9: Worldwide Support And Services
Device Temperature. The return value is in increments of 0.25 °C. For more details, refer to the NI PCIe-7846 Reference topic in LabVIEW Help. Worldwide Support and Services The NI website is your complete resource for technical support. At ni.com/support, you have access to everything from troubleshooting and application development self-help resources to email and phone assistance from NI Application Engineers.
