JFE - 680
JFE
Echo Sounder
Echo Sounder
INSTRUCTION
INSTRUCTION
MANUAL
MANUAL
680

Advertisement

Table of Contents
loading

Related Manuals for JRC JFE-680

Summary of Contents for JRC JFE-680

  • Page 1 JFE - 680 Echo Sounder Echo Sounder INSTRUCTION INSTRUCTION MANUAL MANUAL...
  • Page 3 General Information Thank you for purchasing the JFE-680 Echo-Sounder manufactured by Japan Radio Co., Ltd. The JFE-680 conforms to the IMO (International Maritime Organization) performance standards, enabling seabed displays and digital depth displays. Before attempting to operate this equipment, please read this instruction manual thoroughly to ensure correct and safe operation in accordance with the warning instructions and operation procedures.
  • Page 4 Before You Begin Symbols Used In This Manual To ensure that the equipment is used safely and correctly, and that the operator and third parties are not exposed to danger or damage, pictograms are used in this manual and on the equipment itself.
  • Page 5 Usage Hints Do not remove the cover of this set. Otherwise, you may touch a high-voltage part and suffer from an electrical shock. Do not dismantle or modify this equipment. Failure to observe this warning may result in fire, electric shock, or damage.
  • Page 6 There are no customer-serviceable parts inside. Unauthorized inspections and repairs could cause fires and electrical shock hazards. Please call our field representative or your nearest JRC office for inspection and repair services. Use only the specified fuses.
  • Page 7 Please contact JRC or its agent for the electrical installation of this equipment. Electrical installations carried out by other than the qualified staff may result in faulty operation. Do not store or operate the equipment where subject to temperatures more than 55℃ or less than -15℃. High temperature may cause failures.
  • Page 8 When removing the power cord, be sure to remove the power cord terminal correctly. If the power cord is pulled, the cord may be damaged resulting in a fire or an electrical shock. Do not install the units on the place being poor ventilation.
  • Page 9 External View NO ALERT External View vii...
  • Page 10 Explanation of Terms Beam angle: The angle that sound waves spread out from the transducer. Sound waves spread out in a conical manner taking the center of the bottom surface of the transducer at the apex of the cone. Bubbling: The phenomenon where the image of the seabed is interrupted due to air bubbles caused by the ship's hull or the propeller during a voyage.
  • Page 11 Contents General Information ....................Before You Begin ......................Usage Hints ........................External View ....................... Explanation of Terms ....................viii 1. Introduction ......................1.1 Function ......................…. 1.2 Feature ......................…. 1.3 Components ....................... 1.4 Construction ...................... 1.5 System Configuration ..................2. Control Panel ......................3.
  • Page 12 Setting Adjustment of Date and Time…………………………………………… 4.6 Printer Control Setting……………………………………………………………… Setting Print Output………………………………………………………………… Setting Print Mode………………………………………………………………….. Setting Log Book Print ……………………………………………………………. Setting Log Output Length………………………………………………………... Setting Transfer Speed…………………………………………………………….. Setting Printer Model Selection…………………………………………………… 4.7 Communication Setting…………………………………………………………….. Setting Depth Output………………………………………………………………. Setting Alert Output………………………………………………………………. Setting System Output……………………………………………………………..
  • Page 13 This information is gained by using ultrasonic waves sent from the transducer that are then reflected off the sea bottom and picked up again by the transducer. The JFE-680 also has the following functions: (1) depth alert, (2) power fail alert, (3) output of depth data, (4) output of depth and power fail alerts.
  • Page 14 1.3 Components This section lists the components. Standard Equipment Name Type No. Qty. Remarks JRC Echo Sounder JFE-680 Matching box (primary) AW-154F 200kHz Transducer (primary) NKF-341 200kHz (with cable 20,30,40m) Spare parts 7ZXNA2002 Fuse×3, Printer paper Instruction manual 7ZPNA2012H Option Name Type No.
  • Page 15 1.4 Construction Equipment Outline The following shows the external dimensions of the JFE-680. 1. External Dimension of JFE-680 Unit : mm Mass : 7kg 2. Dimensions of AW-154F/AW-154F-50 Matching box Unit : mm Mass : 4kg 1. Introduction 3...
  • Page 16 External Dimensions of Transducer mounting The external dimensions illustrated below are for the standard equipment. Please refer to the separately supplied drawings if your specifications are not standard. 1. NKF-341/NKF-345 (Installed on ship’s bottom) Unit : mm Mass : 22kg 2.
  • Page 17 3. NKF-393 (Installed on ship’s bottom) 4. NKF-394 (Installed on ship’s bottom) 5. NKF-396 (Installed on ship’s bottom) 1. Introduction 5...
  • Page 18 1.5 System Configuration 1. Introduction 6...
  • Page 19 2. Control Panel This section describes the names and functions of the control panel and its controls. Figure 2-1 Control Panel Name Function Cancels the buzzer. MENU Displays the menu. Move a cursor. Selects an item. MODE Switches the display modes. Clears an item.
  • Page 20 3. Display 3.1 Standard mode (dual frequency) Standard mode displays real time sounding echoes. Alert Alert Depth cursor By primary and secondary transducer setting, dual display data will change position. FWD sounding data is displayed on the right side. Please see page 27 200kHz 50kHz Alert...
  • Page 21 3.2 History mode History mode displays past 12hour or 24 hour depth graph and real time sounding. Alert Alert 12hr 200kHz Keel height value Note : LAT/LON display needs to connect position data. 3. Display 9...
  • Page 22 3.3 Docking mode Docking mode displays depth data. Alert Alert By primary and secondary transducer setting, dual display data will change position. FWD sounding data is displayed on the right side. Please see page 27 A F T : 2 0 0 k H z F W D : 5 0 k H z Note : LAT/LON display needs to connect position data.
  • Page 23 4. Operation 4.1 Basic Operation Turning Power ON/OFF [PWR/PANEL] ・ To turn on power, press the [PWR/PANEL] key for about three seconds. ・ To turn off power, press the [PWR/PANEL] key and the [BRILL] key for about three seconds. Adjusting Control Panel Illumination [PWR/PANEL] ・...
  • Page 24 Gain control [GAIN+] [GAIN-] ・ Gain can be set to 31 stages of 0～30. ・ Whenever [GAIN+] key is pressed, the sensitivity is raised. ・ Whenever [GAIN-] key is pressed, the sensitivity is lowered. ・ Keep pressing [GAIN+] key and [GAIN -] key to the setting of auto range at the same time for about three seconds.
  • Page 25 Selecting Display Mode [MODE] ・ Each time you press the MODE key, the display mode changes. Single frequency: Each time you press the MODE key, the display mode changes as follows. Standard mode History mode Docking mode Dual frequency: Each time you press the MODE key, the display mode changes as follows. Single frequency standard mode (primary), Single frequency standard mode (secondary), Dual frequency standard mode,...
  • Page 26 Cancelling Menu [CLR] ・ This key uses with menu functions. ・ When it keeps pressing the key while printing, the printer is canceled printing. Printing [PRINT] ・ This key uses for print or the data output. ・ The printer setting is set on “PRINT MODE" menu. (Refer to 4.6 Printer Control Setting.) Stopping Buzzer [ACK] ・...
  • Page 27 Right and Left Key of Cursor [CURSOR ] When it is a history mode  ・ When the key is pressed, a position cursor is moved left, and it moves accelerating when keeping pressing it. ・ When the key is pressed, a position cursor is moved right, and it moves accelerating when keeping pressing it.
  • Page 28 OFF ON │ ├ RX ALERT OFF ON │ ├ BUBBLE ALERT OFF ON │ └ PRINTER ALERT OFF ON *JFE-680 │ DPU-414 does not have │ this alert ├ INITIAL │ ├ MEMORY LENGTH 12hr 24hr │ ├ COLOR │...
  • Page 29 4800bps 9600bps 19200bps 38400bps │ └ PRINTER MODEL SELECTION NKG-91 DPU-414 NKG-901 *JFE-380 │ └ BUILD-IN NKG-91 DPU-414 NKG-901 *JFE-680 ├ COMMUNICATION *JFE-680 standard printer │ ├ DEPTH VER1.5 VER2.3 ALL VER5.0 setting is NKG-901. │ ├ ALERT OFF ON │...
  • Page 30 4.3 Display Setting The following sub menu is displayed with [MENU] / DISPLAY ・ A present selection item is displayed by a yellow character. DISPLAY ・ Move a yellow character with key. SCROLL SPEED ・ When or the [ENT] key is pressed after a necessary CLUTTER INTERFERENCE item is selected, the item setting content is displayed.
  • Page 31 Setting Auto Gain ◎The setting method of sensitivity is selected. ・ Make GAIN a yellow display, press or the [ENT] key, and select it from the following, set content. Set content ： AUTO/MANUAL AUTO ：This equipment automatically sets sensitivity. At this time, STC becomes “LONG" regardless of the setting of “INITIAL>STC"...
  • Page 32 Setting Cursor Display ◎The cursor display method in a standard mode and a history mode is selected. ・Make CURSOR a yellow display, press or the [ENT] key, and select it from the following, set content. Set content ： OFF/ON/AUTO ： When the cursor key is operated, it makes an error of the cursor without displaying it. ：...
  • Page 33 4.4 Alert Setting The following menu is displayed with [MENU]・ALERT ALERT ※A left, set content is an initial value. KEY ＡＣＫ ＲＥＬＡＹ MODE CONTINUOUS DEPTH ALARM > SYSTEM ALERT > ・A present selection item is displayed by a yellow character. ・Selecting items move a yellow display with key.
  • Page 34 Setting Depth Alarm ・ Make DEPTH ALARM a yellow display, press or the [ENT] key, and the following menu is displayed. DEPTH ALARM ALERT CONT ・Selecting items move a yellow display with key. DEPTH SETTING 「ALERT CONT」 ◎ The operation of the depth alert is selected. ・Make ALERT CONT a yellow display, press or the [ENT] key, and select it from the following, set content.
  • Page 35 Setting System Alert ・ Make SYSTEM ALERT a yellow display, press or the [ENT] key, and the following menu is displayed. SYSTEM ALERT DEPTH LOST ・Selecting items move a yellow display with key. TX ALERT RX ALERT BUBBLE ALERT PRINTER ALERT 「DEPTH LOST」...
  • Page 36 「RX ALERT」 ◎When the receiving signal becomes abnormal, the alert operation is selected. ・Make RX ALERT a yellow display, press or the [ENT] key, and select it from the following, set content. Set content ：OFF/ON ：The receiving signal alert doesn't operate. ：When abnormality occurs in the receiving signal, the receiving signal alert is started.
  • Page 37 ◎Each Alert and Alert Display (Screen Display) list Alert Display Alert Primary Description (Screen Display) Depth becomes below DEPTH1 Primary depth alert Alarm the set value Depth becomes below DEPTH2 Secondary depth alert Alarm the set value Sea bottom tracking is DEPTH1 Primary sea bottom lost Warning...
  • Page 38 ・The Warning sound is two short buzzer and about five minutes intervals. Alert corol ・The Alarm color is red. ・The Warning color is orange. When JFE-680 “ACK” key push on active state, state is jump to Acknowledged state. 4. Operation 26...
  • Page 39 4.5 Initial Setting This Initial Settings use for service engineer only. Do not change the settings. If you change the Initial settings, malfunction might occur. The following menu is displayed with [MENU]・INITIAL INITIAL MEMORY LENGTH 24hr ※A left, set content is an initial value. COLOR ＞...
  • Page 40 ｢DAY1｣/｢DAY2｣/｢NIGHT1｣/｢NIGHT2｣ ・ Make SCREEN or CHARACTER a yellow display, press or the [ENT] key, and the number of 1～6 is displayed. ・Select a color tone of the favor number with key and press the [ENT] key because each content of characters is shown in the following. SCREEN (image color) CHARACTER (character color) 1 : Background color: Black・Sea bottom color: B/W 8 steps...
  • Page 41 Setting Primary (Secondary) Transducer This Transducer Settings use for service engineer only. Do not change the settings. If you change the settings, malfunction might occur. ◎Various settings concerning the installation of the transducer are selected. ・Make PRIMARY or SECONDARY a yellow display, press or the [ENT] key, and the following menu is displayed.
  • Page 42 Note : On Primary and Secondary transducer settings, when select the transducer position as primary 200kHz position to AFT and secondary 50kHz or 50kHz-A position to FWD, standard dual display mode and docking mode display is changed to right side FWD data . NO ALERT NO ALERT ALERT...
  • Page 43 Setting Adjustment of Date and Time ◎Date/Time/Time difference/GPS synchronization is set. ・ Make DATE/TIME a yellow display, press or the [ENT] key, and the following menu is displayed. DATE/TIME DATE ＞ ・A left, set content is an initial value. TIME ＞...
  • Page 44 4.6 Printer Control Setting Note: JFE-680 electrically stores last 12or 24hours depth data. Printer runs after only your [PRINT] pressing. The following menu is displayed with [MENU]・PRINTER CONT ・ A present selection item is displayed with a yellow PRINTER CONT character.
  • Page 45 ◎ When PRINTER PORT OUT is “PRINTER" COPY ：A present screen display is printed. The direction of paper feed is length against the screen. HISTORY ：All the memorized depth data is graphically printed. The direction of paper feed is time. Secondary data is printed following primary in display screen for dual frequency.
  • Page 46 2. HISTORY print mode 3. LOG print mode 24hours history 30minutes log 1hour time mark 4. Operation 34...
  • Page 47 ：4800bps/9600bps/19200bps/38400bps ・Select the baud rate by and press the [ENT] key. Setting Printer Model Selection This item selects printer model from BUILD-IN/ NKG-91/ DPU-414/ NKG-901. On JFE-680 when select NKG-91 or DPU-414 printer disconnect build-in printer cable. 4. Operation 35...
  • Page 48 4.7 Communication Setting The following menu is displayed with [MENU]・COMMUNICATION COMMUNICATION DEPTH ※A left, set content is an initial value. ALERT SYSTEM PRINTER PORT OUT PRINTER ・A present selection item is displayed by a yellow character. ・Selecting items move a yellow display with key.
  • Page 49 ◎Depth output $SDDBS, xxx.x, f, xxx.x, M, xxx.x, F(CR)(LF) $SDDBT, xxx.x, f, xxx.x, M, xxx.x, F(CR)(LF) $SDDBK, xxx.x, f, xxx.x, M, xxx.x, F(CR)(LF) (1) Depth value after compensation (in feet) (2) Depth value after compensation (in meters) (3) Depth value after compensation (in fathoms) (4) No check sum $SDDPT, xxx.x, x.x, x.x *hh (CR)(LF) (1) (2) (3) (4)
  • Page 50 ◎Alert output, input On DEPTH output setting: ver1.5 or ver2.3 or ALL $SDALR,hhmmss.ss,xxx,A,A,c--c*hh<CR><LF> (2) (3)(4)(5) (6) (1) Time of alert condition change,UTC (2) ID number of the alert source 351 primary depth alert 352 secondary depth alert 353 primary depth lost 354 secondary depth lost 356 printer paper is not good 357 printer connection is not good...
  • Page 51 (10) Alert instance, 1 to 999999 (11) Revision counter, 1 to 99 (12) Escalation counter, 0 to 9 (13) Alert text (14) Checksum $SD ALC,xx,xx,xx,x.x,aaa,x.x,x.x,x.x,……,aaa,x.x,x.x,x.x*hh <CR><LF> (1) (2) (3) (4) (5) (6) (7) (8) (5) (6) (7) (8) (9) (1) Total number of sentences for this message, 01 to 99 (2) Sentence number, 01 to 99 (3) Sequential message identifier, 00 to 99 (4) Number of alert entries...
  • Page 52 Setting System Output ・Make SYSTEM a yellow display, press or the [ENT] key, and select it from the following, set content. Set content ：OFF/ON ：Maintenance system information is not output with the constant period. ：Maintenance system information is added to the depth output port and it outputs. ・Select the content by and press the [ENT] key.
  • Page 53 5. Installation When installing the equipment, securely connect the earth lead to the earth terminal. Failure to connect the earth may result in electric shock in the event of a fault or power leak developing. Do not install or operate the equipment where subject to temperatures 55°C or higher or –15°C or lower.
  • Page 54 5.1 Installing the Recorder Unit Flush-Mount Equipment Figure 3-1 5. Installation 42...
  • Page 55 Wall-Mount Equipment Figure 3-2 5. Installation 43...
  • Page 56 5.2 Installing the Transducer The external dimensions illustrated below are for the standard equipment. Please refer to the separately supplied drawings if your specifications are not standard. NKF-341 5. Installation 44...
  • Page 57 NKF-345 5. Installation 45...
  • Page 58 NKF-392C 5. Installation 46...
  • Page 59 NKF-393 5. Installation 47...
  • Page 60 NKF-394 5. Installation 48...
  • Page 61 NKF-396 5. Installation 49...
  • Page 62 5.3 Connecting Components alert alert alert alert alert alert alert Notes: 1. The shield of each cable must be securely attached to the connectors and must not contact any other connectors, etc. 2. Casings must be grounded securely to the ship’s hull using copper plates. 3.
  • Page 63 6. Maintenance & Check Do not open the equipment to inspect or repair internal circuits. Inspection or repairs by anyone other than a specialized technician may result in fire, electrical shock, or malfunction. If internal inspection or repair is necessary, contact our service center or agents. 6.1 Daily Maintenance The life of the equipment depends on the execution situation of the daily maintenance and check.
  • Page 64 6.2 Maintenance Function Make [MENU]・MAINTENANCE a yellow display by , press , and the following menu is displayed. ・A present selection item is displayed by a yellow character. MAINTENANCE SELF TEST ・Selecting items move a yellow display with key. ＞ ALERT LOG ＞...
  • Page 65 「KEY UNIT」 ・Make KEY UNIT a yellow display, press or the [ENT] key, and the operation unit self test starts. ･When the key on the operation panel is pressed, the name of the pressed key is displayed. However, it returns to the self test menu when the [CLR] key is pressed, and the [CLR] key is judged. 「PRINTER TEST」...
  • Page 66 Displaying Alert Log ・Make ALERT LOG a yellow display, press or the [ENT] key, and ALERT last 20 memorized alert histories are displayed. ・Each alert log displays alert occurred position (position data need), date/month/year, time, alert No. and alert status. Alert No.
  • Page 67 Executing Line Monitor ・Make LINE MONITOR a yellow display, press or the [ENT] key, and the following menu is displayed. LINE MONITOR NAV/DEPTH ： Navigation data/Depth output NAV/DEPTH ＞ ：ALR Input/Output ＞ PRINTER ：Printer port PRINTER ＞ ・Make the monitor item a yellow display, press or the [ENT] key, and the input/output data of the serial port is displayed, and input data is displayed in the upper part of the screen, and output data is displayed under the screen.
  • Page 68 6.3 Replacing Printer Paper Do not cut your hand in the blade tip of the paper cutter. Name Model type Remarks H-7ZPJD0384 TF50KS-E2D for build-in printer Printer paper H-6ZCAF00252A for optional DPU-414 printer ◎After turning off the power supply of this equipment, exchange papers. When the printer cover is opened while turning on, the alert of “NO PAPER"...
  • Page 69 If the backup battery is low, “Please do connection setting of transducers.” Message will pop up with turning on. See page 37, 4.8 Master Reset. If your JFE-680 becomes like this, please contact our agent to order replacing the battery. Backup lithium coin cell battery CR2032 Note : For the safety, turn off the main power switch of echo sounder.
  • Page 70 3 Replace the battery. Stick the small width (narrower than 5mm) slotted screwdriver between the battery and the battery socket. Lift the screwdriver to take off the battery. Set the new battery in the battery socket. The positive (+) terminal is upside. Push the battery until stayed in horizontally.
  • Page 71 6.5 Troubleshooting The table below shows the principal symptom, the cause, and measurements. As a result, request the repair to our company or our agency when it is not possible to recover to normal operational condition. Symptom Cause Measurements The screen doesn't appear The breaker of AC100-230V of the Make the breaker of AC100-230V of the even...
  • Page 72 6.6 Replacing Fuses Exchange the fuse for the one of our specification. Exchange it after confirming the cause to which the fuse is blown. Moreover, turn off the main switch of the power supply CQD-2083 when you exchange fuses (Press ○ sign side). Model type Rating Remarks...
  • Page 73 I/F Unit CQD-2083 Operation Unit CCK-963 LCD Panel ASSY CCN-464 Printer H-7HPJD0003 Screen plate BRBX05341 Closing board when there is no printer for JFE-680 printer Screw Cap BRBX05352 Decoration cap of front four corners screw 6. Maintenance & Check 61...
  • Page 74 7. Consider Installation • Do not install the JFE-680 where subject to the following conditions as such conditions may cause failures and reduce the life of the equipment. 1. Where liable to be splashed with water. 2. Where ventilation is poor.
  • Page 75 Note that such inspection and maintenance is subject to charge. Please consult JRC or its agent for further details of any part of the afterservice conditions. Contact: See list at end of manual.
  • Page 76 If any failure occurs in the product during its normal operation in accordance with the instruction manual, the dealer or JRC will repair free of charge. In case that any failure is caused due to misuse, faulty operation, negligence or force major such as natural disaster and fire, the product will be repaired with charges.
  • Page 77 9. Disposal 9.1 Disposal of this equipment If this equipment is to be disposed, please follow the guidelines of the local body governing the location at which the equipment is disposed of. 9. Disposal 65...
  • Page 78 10. Specifications Display 10.4 inch TFT LCD (640 x 480 pixels) Frequency 200kHz / 50kHz or 50kHz-A Echo color 8 colors or 8 level monochrome Digital depth 3 digit (0.0m to 99.9m : 0.1m steps, 100m over : 1m steps) Range 100m 200m...
  • Page 79 Appendix Noise Bubble Noise Bubble Interruption Interference Noise from other ship Plankton layer Appendix 67...
  • Page 80 Actual Pictures Zero line DISP TRANS figure A Seabed DISP SURF DISP KEEL Seabed Zero line Third reflection of bottom Second reflection of bottom Seabed In case of a shallow seabed or when increasing the amplifier sensitivity, two seabed lines may be recorded.
  • Page 81 Seabed Quality Change Rock In case of a hard seabed composed of rocks etc., its return trails long, as shown in right chart. In case of a soft seabed made of mud, seaweed, etc., they poorly reflect an ultrasonic wave to result in thin recording of the seabed with short trail.
  • Page 82 Abrupt-Sloped Seabed Sidelobe False echo A dim echo may sometimes appear along an abrupt slope of seabed, as if it were floating above the slope, when recording. In case of flat seabed, thin second return of seabed may sometimes appear, which is slightly below the actual seabed.
  • Page 83 The echo of a seabed with abrupt slope is recorded as a lone difficult to see and less discriminative, since it tends to accompany with a false echo due to the side lobe and the inherent property of directivity. In particular, a seabed with abrupt slope and heavily rugged surface provided an echo very difficult to display on the recording.
  • Page 86 Not use the asbestos For further information,contact: URL Head office : http://www.jrc.co.jp/eng/ Marine Service Department 1-7-32 Tatsumi, Koto-ku, Tokyo 135-0053, Japan 　　　　　　　　　　　: tmsc@jrc.co.jp e - mail One - call 　　　　　　　　　　　: +81-50-3786-9201 ISO 9001, ISO 14001 Certified CODE No.7ZPNA2012H JAN. 2019 Edition 8...
