Preface
B85M-E45
Motherboard
G52-78171X2

Advertisement

Table of Contents
loading

Related Manuals for MSI B85M-E45

Summary of Contents for MSI B85M-E45

  • Page 1 Preface B85M-E45 Motherboard G52-78171X2...

  • Page 2: Preface

    Copyright Notice The material in this document is the intellectual property of MICRO-STAR INTERNATIONAL. We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents. Our products are under continual improvement and we reserve the right to make changes without notice.

  • Page 3: Smartphone Application

    If a problem arises with your system and no solution can be obtained from the user’s manual, please contact your place of purchase or local distributor. Alternatively, please try the following help resources for further guidance. Visit the MSI website for technical guide, BIOS updates, driver updates, and other information: http://www.msi.com/service/download/ Contact our technical staff at: http://support.msi.com...

  • Page 4: Safety Instructions

    Safety Instructions ￭ Always read the safety instructions carefully. ￭ Keep this User’s Manual for future reference. ￭ Keep this equipment away from humidity. ￭ Lay this equipment on a reliable flat surface before setting it up. ￭ The openings on the enclosure are for air convection hence protects the equipment from overheating.

  • Page 5: Fcc-B Radio Frequency Interference Statement

    FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 6: Radiation Exposure Statement

    Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment and its antenna should be installed and operated with minimum distance 20 cm between the radiator and your body. This equipment and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.

  • Page 7: Battery Information

    Replace only with the same or equivalent type recommended by the manufacturer. Chemical Substances Information In compliance with chemical substances regulations, such as the EU REACH Regulation (Regulation EC No. 1907/2006 of the European Parliament and the Council), MSI provides the information of chemical substances in products at: http://www.msi.com/html/popup/csr/evmtprtt_pcm.html Preface...

  • Page 8: Weee (Waste Electrical And Electronic Equipment) Statement

    MSI will comply with the product take back requirements at the end of life of MSI-branded products that are sold into the EU. You can return these products to local collection points.
  • Page 9 MSI će poštovati zahtev o preuzimanju ovakvih proizvoda kojima je istekao vek trajanja, koji imaju MSI oznaku i koji su prodati u EU. Ove proizvode možete vratiti na lokalnim mestima za prikupljanje.
  • Page 10 MSI si adeguerà a tale Direttiva ritirando tutti i prodotti marchiati MSI che sono stati venduti all’interno dell’Unione Europea alla fine del loro ciclo di vita.

  • Page 11: Table Of Contents

    CONTENTS ▍ Preface ......................i Copyright Notice ......................ii Trademarks ......................ii Revision History ......................ii Smartphone Application ..................iii Technical Support ....................iii Safety Instructions ....................iv FCC-B Radio Frequency Interference Statement ........... v CE Conformity ......................v Radiation Exposure Statement ................vi European Community Compliance Statement ............vi Taiwan Wireless Statements ...................vi Japan VCCI Class B Statement ................vi Korea Warning Statements ..................vi...
  • Page 12 Internal Connectors .................... 1-19 SATA1~6: SATA Connectors ..............1-19 CPUFAN,SYSFAN1~2: Fan Power Connectors .......... 1-20 JFP1, JFP2: System Panel Connectors ............1-21 JUSB1~2: USB 2.0 Expansion Connector ........... 1-22 JUSB3: USB 3.0 Expansion Connector ............1-22 JCI1: Chassis Intrusion Connector .............. 1-23 JAUD1: Front Panel Audio Connector ............
  • Page 13 Security ......................3-14 Save & Exit ....................3-15 OC ........................3-16 M-FLASH ......................3-22 OC PROFILE ..................... 3-23 HARDWARE MONITOR ..................3-24 Appendix A Intel SBA ................. A-1 Prerequisites ......................A-2 Installing Intel SBA ....................A-3 Software Configuration ..................A-3 Software panel overview ................A-3 Password settings ..................A-4 Help Button ......................A-4 xiii...

  • Page 15: Chapter 1 Getting Started

    Chapter 1 Getting Started Thank you for choosing the B85M-E45 Series (MS-7817 v2.X) Micro-ATX motherboard. The B85M-E45 Series motherboards are based on Intel ® chipset for optimal system efficiency. Designed to fit the advanced Intel ® LGA1150 processor, the B85M-E45 Series motherboards deliver a high...

  • Page 16: Packing Contents

    * These pictures are for reference only and may vary without notice. * The packing contents may vary according to the model you purchased. * If you need to purchase the optional accessories or request part numbers, please visit the MSI website at http://www.msi.com/index.php or consult the dealer. Getting Started...

  • Page 17: Assembly Precautions

    Assembly Precautions ■ The components included in this package are prone to damage from electrostatic discharge (ESD). Please adhere to the following instructions to ensure successful computer assembly. ■ Always turn off the power supply and unplug the power cord from the power outlet before installing or removing any computer component.

  • Page 18: Motherboard Specifications

    Motherboard Specifications ■ 4th Generation Intel Core™ i7 / Core™ i5 / Core™ i3 / Pentium ® ® Celeron processors for LGA 1150 socket Support ® Chipset ■ Intel B85 Express Chipset ® Memory ■ 4x DDR3 memory slots supporting up to 32GB ■...
  • Page 19 Internal ■ 1x 24-pin ATX main power connector ■ 1x 4-pin ATX 12V power connector Connectors ■ 4x SATA 6Gb/s connectors ■ 2x SATA 3Gb/s connectors ■ 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) ■ 1x USB 3.0 connector (supports additional 2 USB 3.0 ports) ■...

  • Page 20: Connectors Quick Guide

    Connectors Quick Guide DIMM4 CPUFAN SYSFAN2 DIMM3 DIMM2 JPWR1 DIMM1 CPU Socket JCOM1 Back Panel SYSFAN1 JPWR2 PCI_E1 JCI1 JBAT1 PCI_E2 SATA2 SATA5_6 PCI_E3 JTPM1 JUSB3 PCI1 SATA1 JAUD1 SATA3 JUSB1 SATA4 JLPT1 JUSB2 JFP1 JFP2 Getting Started...
  • Page 21 PCIe x1 Expansion Slots 1-17 PCI1 PCI Expansion Slot 1-17 SATA1~4 SATA 6Gb/s Connectors 1-19 SATA5~6 SATA 3Gb/s Connectors 1-19 For the latest information about CPU, please visit http://www.msi.com/service/cpu-support/ For more information on compatible components, please visit http://www.msi.com/service/test-report/ Getting Started...

  • Page 22: Back Panel Quick Guide

    Back Panel Quick Guide LAN Port VGA Port Line-In PS/2 Mouse Port USB 2.0 Port Line-Out HDMI USB 3.0 Port DVI-D Port USB 2.0 Port PS/2 Keyboard Port ▶ PS/2 Keyboard/Mouse Port The PS/2 mouse/keyboard DIN connectors for a PS/2 mouse/keyboard.
  • Page 23 Important This platform supports dual-display and triple-display function. HDMI+VGA VGA+DVI-D DVI-D+HDMI HDMI+VGA+DVI-D Extend mode ◯ ◯ ◯ ◯ (Extend the desktop to the second and third monitor) Clone mode ◯ ◯ ◯ ◯ (Monitors have the same screen) ▶ LAN Port The standard RJ-45 LAN jack is for connecting to a Local Area Network (LAN).

  • Page 24: Cpu (Central Processing Unit)

    This motherboard is designed to support overclocking. Before attempting to overclock, please make sure that all other system components can tolerate overclocking. Any attempt to operate beyond product specifications is not recommend. MSI does not guarantee the damages or risks caused by inadequate operation beyond product specifications.

  • Page 25: Cpu & Heatsink Installation

    CPU & Heatsink Installation When installing a CPU, always remember to install a CPU heatsink. A CPU heatsink is necessary to prevent overheating and maintain system stability. Follow the steps below to ensure correct CPU and heatsink installation. Wrong installation can damage both the CPU and the motherboard.
  • Page 26 3. Align the notches with the socket alignment keys. Lower the CPU straight down, without tilting or sliding the CPU in the socket. Inspect the CPU to check if it is properly seated in the socket. 4. Close and slide the load plate under the retention knob. Close and engage the load lever.
  • Page 27 7. Locate the CPU fan connector on the motherboard. 8. Place the heatsink on the motherboard with the fan’s cable facing towards the fan connector and the fasteners matching the holes on the motherboard. CPU fan connector 9. Push down the heatsink until the four fasteners get wedged into the holes on the motherboard.

  • Page 28: Memory

    Memory These DIMM slots are used for installing memory modules. For more information on compatible components, please visit http://www.msi.com/service/test-report/ DIMM1 DIMM2 DIMM3 DIMM4 Video Demonstration Watch the video to learn how to install memories at the address below. http://youtu.be/76yLtJaKlCQ Dual-Channel mode Population Rule In Dual-Channel mode, the memory modules can transmit and receive data with two data bus channels simultaneously.

  • Page 29: Mounting Screw Holes

    Mounting Screw Holes When installing the motherboard, first install the necessary mounting stands required for an motherboard on the mounting plate in your computer case. If there is an I/O back plate that came with the computer case, please replace it with the I/O backplate that came with the motherboard package.

  • Page 30: Power Supply

    Power Supply Video Demonstration Watch the video to learn how to install power supply connectors. http://youtu.be/gkDYyR_83I4 JPWR1~2: ATX Power Connectors These connectors allow you to connect an ATX power supply. To connect the ATX power supply, align the power supply cable with the connector and firmly press the cable into the connector.

  • Page 31: Expansion Slots

    Expansion Slots This motherboard contains numerous slots for expansion cards, such as discrete graphics or audio cards. PCI_E1~E3: PCIe Expansion Slots The PCIe slot supports the PCIe interface expansion card. PCIe 3.0 x16 Slot PCIe 2.0 x1 Slot PCI1: PCI Expansion Slot The PCI slot supports additional LAN, SCSI, USB, and other add-on cards that comply with PCI specifications.

  • Page 32: Video/ Graphics Cards

    Adding on one or more discrete video cards will significantly boost the system’s graphics performance. For best compatibility, MSI graphics cards are recommended. Video Demonstration Watch the video to learn how to install a graphics card on PCIe x16 slot with butterfly lock.

  • Page 33: Internal Connectors

    Internal Connectors SATA1~6: SATA Connectors This connector is a high-speed SATA interface port. Each connector can connect to one SATA device. SATA devices include disk drives (HDD), solid state drives (SSD), and optical drives (CD/ DVD/ Blu-Ray). Video Demonstration Watch the video to learn how to Install SATA HDD. http://youtu.be/RZsMpqxythc SATA6 SATA4...

  • Page 34: Cpufan,Sysfan1~2: Fan Power Connectors

    CPUFAN,SYSFAN1~2: Fan Power Connectors The fan power connectors support system cooling fans with +12V. If the motherboard has a System Hardware Monitor chipset on-board, you must use a specially designed fan with a speed sensor to take advantage of the CPU fan control. Remember to connect all system fans.

  • Page 35: Jfp1, Jfp2: System Panel Connectors

    JFP1, JFP2: System Panel Connectors These connectors connect to the front panel switches and LEDs. The JFP1 connector is compliant with the Intel Front Panel I/O Connectivity Design Guide. When ® installing the front panel connectors, please use the optional M-Connector to simplify installation.

  • Page 36: Jusb1~2: Usb 2.0 Expansion Connector

    JUSB1~2: USB 2.0 Expansion Connector This connector is designed for connecting high-speed USB peripherals such as USB HDDs, digital cameras, MP3 players, printers, modems, and many others. Important Note that the VCC and GND pins must be connected correctly to avoid possible damage.

  • Page 37: Jci1: Chassis Intrusion Connector

    JCI1: Chassis Intrusion Connector This connector connects to the chassis intrusion switch cable. If the computer case is opened, the chassis intrusion mechanism will be activated. The system will record this intrusion and a warning message will flash on screen. To clear the warning, you must enter the BIOS utility and clear the record.

  • Page 38: Jtpm1: Tpm Module Connector

    JTPM1: TPM Module Connector This connector connects to a optional TPM (Trusted Platform Module) Module. Please refer to the TPM security platform manual for more details and usages. JLPT1: Parallel Port Connector This connector is used to connect an optional parallel port bracket. The parallel port is a standard printer port that supports Enhanced Parallel Port (EPP) and Extended Capabilities Parallel Port (ECP) mode.

  • Page 39: Jcom1: Serial Port Connector

    JCOM1: Serial Port Connector This connector is a 16550A high speed communication port that sends/receives 16 bytes FIFOs. You can attach a serial device. Jumper JBAT1: Clear CMOS Jumper There is CMOS RAM onboard that is external powered from a battery located on the motherboard to save system configuration data.

  • Page 40: Drivers And Utilities

    After you install the operating system you will need to install drivers to maximize the performance of the new computer you just built. MSI motherboard comes with a Driver Disc. Drivers allow the computer to utilize your motherboard more efficiently and take advantage of any special features we provide.
  • Page 41 Chapter 2 Quick Installation This chapter provides demonstration diagrams about how to install your computer. Some of the installations also provide video demonstrations. Please link to the URL to watch it with the web browser on your phone or tablet. You may have even link to the URL by scanning the QR code. Important The diagrams in this chapter are for reference only and may vary from the product you purchased.
  • Page 42 CPU Installation http://youtu.be/bf5La099urI Quick Installation...

  • Page 43: Chapter 2 Quick Installation

    Quick Installation...

  • Page 44: Memory Installation

    Memory Installation http://youtu.be/76yLtJaKlCQ Quick Installation...

  • Page 45: Motherboard Installation

    Motherboard Installation Quick Installation...
  • Page 46 Quick Installation...

  • Page 47: Power Connectors Installation

    Power Connectors Installation http://youtu.be/gkDYyR_83I4 Quick Installation...
  • Page 48 Quick Installation...

  • Page 49: Sata Hdd Installation

    SATA HDD Installation http://youtu.be/RZsMpqxythc Quick Installation...

  • Page 50: Msata Ssd Installation

    mSATA SSD Installation Quick Installation 2-10...

  • Page 51: Front Panel Connector Installation

    Front Panel Connector Installation JFP1 Connecotr Installation http://youtu.be/DPELIdVNZUI Front Panel Audio Connector Installation 2-11 Quick Installation...

  • Page 52: Peripheral Connector Installation

    Peripheral Connector Installation USB2.0 Connector Installation USB3.0 Connector Installation Quick Installation 2-12...

  • Page 53: Graphics Card Installation

    Graphics Card Installation http://youtu.be/mG0GZpr9w_A 2-13 Quick Installation...
  • Page 54 Quick Installation 2-14...

  • Page 55: Chapter 3 Bios Setup

    Chapter 3 BIOS Setup CLICK BIOS is a revolutionary UEFI interface that allows you to setup and configure your system for optimum use. Using your mouse and keyboard, users can change BIOS settings, monitor CPU temperature, select the boot device priority and view system information such as the CPU name, DRAM capacity, the OS version and the BIOS version.

  • Page 56: Entering Setup

    (optional) on the motherboard to enable the system going to BIOS setup directly at next boot. Click "GO2BIOS" tab on "MSI Fast Boot" utility screen. Important Please be sure to install the “MSI Fast Boot” utility before using it to enter the BIOS setup. BIOS Setup BIOS Setup...

  • Page 57: Overview

    Overview After entering BIOS, the following screen is displayed. Temperature monitor Language System information Model name Virtual OC Genie Button Boot device priority bar BIOS menu selection BIOS menu selection Menu display ▶ Temperature monitor Show the temperatures of the processor and the motherboard. ▶...
  • Page 58 Enables or disables the OC Genie function by clicking on this button. When enabled, this button will be light. Enabling OC Genie function can automatically overclock with MSI optimized overclocking profile. Important We recommend that you do not to make any modification in OC menu and do not to load defaults after enabling the OC Genie function.

  • Page 59: Operation

    Operation You can control BIOS settings with the mouse and the keyboard. The following table lists and describes the hot keys and the mouse operations. Hot key Mouse Description <↑↓→← > Select Item Move the cursor <Enter> Select Icon/ Field Click/ Double-click the left button <Esc>...

  • Page 60: Settings

    SETTINGS System Status ▶ System Date Sets the system date. Use tab key to switch between date elements. The format is <day> <month> <date> <year>. <day> Day of the week, from Sun to Sat, determined by BIOS. Read-only. <month> The month from Jan. through Dec. <date>...

  • Page 61: Advanced

    Advanced ▶ PCI Subsystem Settings Sets PCI, PCI express interface protocol and latency timer. Press <Enter> to enter the sub-menu. ▶ PEG0 - Gen X [Auto] Sets PCI Express protocol for matching different installed devices. [Auto] Enables all PCIe Gen1, Gen2 and Gen3. supports. [Gen1] Enables PCIe Gen1 support only.
  • Page 62 ▶ Ipv6 PXE Support [Enabled] When “Enabled”, the system UEFI network stack will support Ipv6 protocol. This item will appear when “Network Stack” is enabled. [Enabled] Enables the Ipv6 PXE boot support. [Disabled] Disables the Ipv6 PXE boot support. ▶ SATA Mode [AHCI Mode] Sets the operation mode of the onboard SATA controller.
  • Page 63 ▶ Intel(R) Rapid Start Technology Sets Intel Rapid Start Technology for optimizing the system resume operation. Press ® <Enter> to enter the sub-menu. ▶ Intel(R) Rapid Start Technology [Disabled] Intel Rapid Start Technology lets the system resume from sleep mode quickly. ®...
  • Page 64 ▶ LakeTiny Feature [Disabled] Enables or disables Intel Lake Tiny feature with iRST for SSD. This item appears when a installed CPU supports this function and "Intel C-State" is enabled. [Enabled] Enhance the dynamic IO load adjusted performance for accelerating the SSD speed.
  • Page 65 ▶ Device Mode [Printer Mode] Selects an operating mode for parallel port. [Printer Mode] Printer port mode [SPP] Standard Parallel Port mode [EPP-1.9/ 1.7 + SPP] Enhanced Parallel Port-1.9/ 1.7 mode + Standard Parallel Port mode. [ECP] Extended Capability Port mode [ECP + EPP-1.9/ 1.7] Extended Capability Port mode + Enhanced Parallel Port-1.9/ 1.7 mode.
  • Page 66 ▶ MSI Fast Boot [Disabled] MSI Fast Boot is the fastest way to boot the system. It will disable more devices to speed up system boot time which is faster than the boot time of “Fast Boot”. [Enabled] Enables the MSI Fast Boot function to speed up booting time. And the following "Fast Boot"...
  • Page 67 ▶ Wake Up Event Setup Sets system wake up behaviors for different sleep modes. Press <Enter> to enter the sub-menu. ▶ Wake Up Event By [BIOS] Selects the wake up event by BIOS or operating system. [BIOS] Activates the following items, and use these items to set the wake up events.

  • Page 68: Boot

    Boot Sets the sequence of system boot devices. ▶ Full Screen Logo Display [Enabled] Enables or disables to show the full screen logo while system POST. [Enabled] The OS boots straight to the GUI without showing the POST screen. [Disabled] Shows the POST messages at booting.

  • Page 69: Save & Exit

    ▶ Make U-Key at Makes a key at the USB flash drive to prevent other people from accessing the system. Only the user who has the key with the flash drive can access the system. ▶ Chassis Intrusion Configuration Press <Enter> to enter the sub-menu. ▶...
  • Page 70 Important Overclocking your PC manually is only recommended for advanced users. • • Overclocking is not guaranteed, and if done improperly, can void your warranty or severely damage your hardware. • If you are unfamiliar with overclocking, we advise you to use OC Genie for easy overclocking.
  • Page 71 ▶ Intel Turbo Boost [Enabled] Enables or disables the Intel Turbo Boost. This item appears when the installed CPU ® supports this function. [Enabled] Enables this function to boost CPU performance automatically above rated specifications when system request the highest performance state.
  • Page 72 ▶ DRAM Training Configuration Press <Enter> to enter the sub-menu. Enables or disables the various training ways of DRAM. The system may become unstable or unbootable after changing these items in this sub-menu. If it occurs, please clear the CMOS data and restore the default settings.
  • Page 73 ▶ CPU Specifications Press <Enter> to enter the sub-menu. This sub-menu displays the information of installed CPU. You can also access this information menu at any time by pressing [F4]. Read only. ▶ CPU Technology Support Press <Enter> to enter the sub-menu. The sub-menu shows what the key features does the installed CPU support.
  • Page 74 ▶ Hardware Prefetcher [Enabled] Enables or disables the hardware prefetcher (MLC Streamer prefetcher). [Enabled] Allows the hardware prefetcher to automatically pre-fetch data and instructions into L2 cache from memory for tuning the CPU performance. [Disabled] Disables the hardware prefetcher. ▶ Adjacent Cache Line Prefetch [Enabled] Enables or disables the CPU hardware prefetcher (MLC Spatial prefetcher).
  • Page 75 ▶ LakeTiny Feature [Disabled] Enables or disables Intel Lake Tiny feature with iRST for SSD. This item appears when a installed CPU supports this function and "Intel C-State" is enabled. [Enabled] Enhance the dynamic IO load adjusted performance for accelerating the SSD speed.

  • Page 76: M-Flash

    Enables the system to boot from the BIOS within USB flash disk. [Disabled] Enables the system to boot from the BIOS within ROM on motherboard. *This may cause system unstable, MSI recommend it only for power users. ▶ Select one file to boot Selects a BIOS file in the USB flash disk (NTFS/ FAT 32 format) to boot the system.

  • Page 77: Oc Profile

    OC PROFILE ▶ Overclocking Profile 1/ 2/ 3/ 4/ 5/ 6 Overclocking Profile 1/ 2/ 3/ 4/ 5/ 6 management. Press <Enter> to enter the sub- menu. ▶ Set Name for Overclocking Profile 1/ 2/ 3/ 4/ 5/ 6 Names the current overclocking profile. ▶...

  • Page 78: Hardware Monitor

    HARDWARE MONITOR Current Temperature & Temperature & Speed Speed information graphic display control field Voltage display ▶ Current Temperature & Speed information Shows the current CPU temperature, system temperature and fans' speeds. ▶ Temperature & Speed graphic display The red graph shows the minimum and maximum temperatures that be set on the “Fan control field”.
  • Page 79 Please follow the description below to set the temperatures and fan speeds. ■ a - Selects a fan you want to specify the speed. ■ b - Checks this item to activate the following items for changing default values. ■ c - Slides the Min and Max tabs to set the minimum and maximum temperatures.

  • Page 81: Appendix A Intel Sba

    Appendix A Intel SBA Intel Small Business Advantage (Intel SBA) provides an out-of-the-box ® ® hardware-based security and productivity suite designed for the small business user. Intel SBA includes a customizable user interface and several ® bundled Intel applications.

  • Page 82: Prerequisites

    Prerequisites ■ Supported Operating Systems Intel SBA supports following OS: ■ Windows 7 Professional 64-bit and 32-bit ■ Windows 7 Enterprise 64-bit ■ Windows 8 PRO 64-bit and 32-bit ■ Required User Permissions You must run the installer and the customization wizard with a user that has local administrator permissions on the computer.

  • Page 83: Installing Intel Sba

    Installing Intel SBA This procedure describes how to install Intel SBA. ■ To install Intel SBA: Logon to the computer with a user that has administrator privileges. Insert the application DVD into the DVD-ROM drive. The setup screen will automatically appear. Click OTHERS tab.

  • Page 84: Password Settings

    Password settings By default, the system is in an unconfigured state. Before the hardware capabilities can be used by Intel SBA software, the system must be configured. This is done in the Settings > Password Settings tab in the main menu of the GUI. Fill out the form to create the new password and click “Save”.
