BM 2610012115 03-11:BM 2610012115 02-11 2/23/11 11:10 AM Page 1
IMPORTANT:
Read Before Using
PS11
Call Toll Free for
Consumer Information
& Service Locations
1-877-BOSCH99 (1-877-267-2499) www.boschtools.com
For English Version
See page 2
IMPORTANT :
Lire avant usage
Operating/Safety Instructions
Consignes de fonctionnement/sécurité
Instrucciones de funcionamiento y seguridad
Pour obtenir des informations
et les adresses de nos centres
de service après-vente,
appelez ce numéro gratuit
Version française
Voir page 15
IMPORTANTE:
Leer antes de usar
Llame gratis para
obtener información
para el consumidor y
ubicaciones de servicio
Versión en español
Ver la página 28

Advertisement

Table of Contents
loading

Related Manuals for Bosch PS11

Summary of Contents for Bosch PS11

  • Page 1 Read Before Using Lire avant usage Leer antes de usar Operating/Safety Instructions Consignes de fonctionnement/sécurité Instrucciones de funcionamiento y seguridad PS11 Call Toll Free for Pour obtenir des informations Llame gratis para Consumer Information et les adresses de nos centres obtener información...

  • Page 2: General Power Tool Safety Warnings

    BM 2610012115 03-11:BM 2610012115 02-11 2/23/11 11:10 AM Page 2 General Power Tool Safety Warnings Read all safety warnings and all instructions. Failure to follow the warnings WARNING and instructions may result in electric shock, fire and/or serious injury. SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE The term “power tool”...

  • Page 3: Safety Rules For Cordless Drill/Drivers

    BM 2610012115 03-11:BM 2610012115 02-11 2/23/11 11:10 AM Page 3 Disconnect the plug from the power source Battery tool use and care and/or the battery pack from the power tool Recharge only with the charger specified before making any adjustments, changing by the manufacturer.

  • Page 4: Additional Safety Warnings

    Do not WARNING charger, read substitute any other charger. Use only Bosch instructions and cautionary markings on approved chargers with your product. See (1) battery charger, (2) battery pack, and (3) Functional Description and Specifications.

  • Page 5: Battery Care

    120 degrees F Use of an attachment not recom- (49 degrees C). This is important to prevent mended or sold by Bosch may result in a serious damage to the battery cells. risk of fire, electric shock or injury to Battery leakage may occur under extreme persons.
  • Page 6 BM 2610012115 03-11:BM 2610012115 02-11 2/23/11 11:10 AM Page 6 Symbols IMPORTANT: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer.
  • Page 7 BM 2610012115 03-11:BM 2610012115 02-11 2/23/11 11:10 AM Page 7 Symbols (continued) IMPORTANT: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer.

  • Page 8: Functional Description And Specifications

    RUBBERIZED GRIP BATTERY CHARGE CONDITION INDICATOR LIGHTS BATTERY RELEASE TABS BATTERY PACK Model number Charge time BC330 (1 Hour) PS11 BC430 (30 minutes) Voltage rating 10.8V/12V No load speed 0-3000/min Battery pack BAT411, BAT412 & BAT413 Maximum Capacities Chuck size 3/8"...
  • Page 9 BM 2610012115 03-11:BM 2610012115 02-11 2/23/11 11:10 AM Page 9 Assembly Disconnect battery pack injury is possible if attempting to grasp the WARNING from tool before making spinning chuck. any assembly, adjustments or changing accessories. Such preventive safety FIG. 2 measures reduce the risk of starting the tool CHUCK SLEEVE accidentally.
  • Page 10 BM 2610012115 03-11:BM 2610012115 02-11 2/23/11 11:10 AM Page 10 ARTICULATION BUTTON one position when the trigger switch is released. This will allow you to tighten or loosen Your tool also features a 5 position articulating head. To adjust, depress articulation button a nut or screw by rotating the tool by hand with and move head to desired position (Fig.
  • Page 11 “off” when take or send tool, battery pack and charger lights are turned off. to your local Bosch Service Center. See “Tools, Electric” in the Yellow Pages for c. Check battery pack terminals for dirt.
  • Page 12 BM 2610012115 03-11:BM 2610012115 02-11 2/23/11 11:10 AM Page 12 BATTERY PACK FIG. 6 CHARGER RED LIGHT GREEN LIGHT CHARGER INDICATORS, SYMBOLS AND MEANING (Model BC330) If the indicator lights are “OFF”, the charger If the green indicator light is is not receiving power from power supply "ON", charger...

  • Page 13: Operating Tips

    BM 2610012115 03-11:BM 2610012115 02-11 2/23/11 11:10 AM Page 13 The purpose of the green light is to indicate When the battery pack is fully charged, that the battery pack is fast-charging. It does unplug the charger (unless you're charging not indicate the exact point of full charge.
  • Page 14 BM 2610012115 03-11:BM 2610012115 02-11 2/23/11 11:10 AM Page 14 First, clamp the pieces together and drill the the hole to make the screw flush with the first hole 2/3 the diameter of the screw. If the surface. Then, simply apply even pressure material is soft, drill only 2/3 the proper when driving the screw.

  • Page 15: Maintenance

    Certain cleaning agents and TOOL LUBRICATION CAUTION solvents damage plastic Your Bosch tool has been properly lubricated parts. Some of these are: gasoline, carbon and is ready for use. tetrachloride, chlorinated cleaning solvents, ammonia and household detergents that contain ammonia.
