- Page 1 HD-ILA TV HD-Z56RX7 INSTRUCTIONS LCT2211-001A...
-
Page 2: Table Of Contents
Useful functions · View and search in multi-picture mode · Sleep timer / Channel Guard · Register your favourite channels Operate JVC recorders and other devices Just the way you like it Customizing your TV Advanced picture adjustment · Reduce noise / Watch a more natural picture ·... -
Page 3: Warning
Warning Please follow all the guidelines below Never insert objects Never place anything on Never expose to rain Do not allow the TV into the cabinet the TV! or moisture! to fall! openings! Placing liquids, open To prevent fi re or Do not rest your elbows on, or allow children fl... -
Page 4: Precautions
Precautions Please follow all the guidelines below This TV uses a lamp to project the picture on the screen. Misoperations may shorten the lamp life or cause malfunction of the lamp. When the power is turned Before operating the TV, read all the instructions below. When the power is turned off, the cooling down is on, the warming up... -
Page 5: Replacing The Lamp
Wait for at least 1 hour until the lamp has fully cooled Use only the specifi ed Replacement Lamp Kit! Remove the lamp unit This lamp is for use with JVC Replacement Lamp Kit: model televisions. Using the TS-CL110C lamp with a different television... - Page 6 Install the NEW lamp unit Reset the lamp timer Display the menu bar Unpack Select “Set Up” select Do not drop the lamp! Never touch the glass Set Up next surface of the lamp! Do not shock the glass surface of the lamp! Oils deposited from the fi...
-
Page 7: Names Of All The Parts
TV cannot be turned on. If the LAMP indicator blinks rapidly To index page AAA/LR03 Batteries “Lamp” (P. 21) For confi rming When watching TV (P. 16) the TV works When operating a JVC VCR or (P. 17) -
Page 8: Basic Connections
Basic connections Please read the user manuals of each device carefully before setup. It is necessary to connect an aerial to watch TV. Connect with other devices “Connecting external devices” (P. 10) Connect the aerial Connect a VCR / DVD recorder AERIAL AERIAL VIDEO-1... -
Page 9: Initial Settings
> Edit Edit channels CH/CC in “Editing channels” (P. 9) To the previous screen Exit Confi rm If the “JVC” logo does not appear or if you wish to make changes later “Language”, “Teletext Language” and “Auto Program” (P. 18) -
Page 10: Editing Channels
Editing channels Edit the channels registered with “Auto Program” in “Initial settings” (P. 8). Begin Select a destination Finish Move a When coming from “Initial settings” (P. 8), skip to >Edit > Edit select channel’s CH/CC CH/CC position Display the menu bar MOVE move out move in... -
Page 11: Connecting External Devices
Connect DVI devices to Simply insert a pre-recorded media into your JVC brand VCR or DVD player and the device will automatically turn on and begin playback. At the same time, using the AV CompuLink, the VCR or DVD player sends a signal to the television telling it to “HDMI-1”... -
Page 12: Enjoying Your New Tv
Enjoying your new TV! TV mode TV and Text mode Text mode Viewing teletext PAGE Watching TV Enlarge the text To the index page PAGE View channel information Hold the current page Change the aspect ratio Switch briefl y between teletext and TV Enjoy “Cinema Surround”... -
Page 13: Watching Tv
Watching TV After turning on the TV, it takes about 1 minute to project the picture to its normal brightness. After turning off the TV, it takes about 5 seconds to make the screen dark. After that, cooling down is performed for about 1 minute. “About the LAMP indicator”... -
Page 14: Viewing Teletext
Viewing teletext This TV can display TV broadcasts and teletext on the same channel in two windows. Hold the current page When watching TV Hold the current page HOLD Release Press again TEXT Enter a teletext page Display hidden information (answers to quizzes, etc) Reveal hidden pages... -
Page 15: Watching Videos / Dvds
HDMI2 Select “Set Up” Operate the connected device and play a video select Operate JVC recorders and other devices (P. 17) Set Up next Select the video source using the side buttons Select “Video-1 Setting” or “Video-3 Setting” Set Up... -
Page 16: Useful Functions
Useful functions select “Features” Still picture Features next Take Set a time for snapshots of Features select “Sleep Timer” the TV to turn Current programme Sleep Timer the screen Channel Guard itself off Appearance Type A Cancel Blue Back FREEZE Child Lock Auto Shutoff SLEEP TIMER... - Page 17 Useful functions (continued) “MENU” “ ” “Features” “Blue Back” select While the channel is displayed : Function is : Displays a Displays a turned off blue screen blue screen Hold down for 1 - 4? 3 seconds and mute the sound when the signal is Press the number to...
-
Page 18: Operate Jvc Recorders And Other Devices
Confi rm the code for your recorder by checking the manual it came with. Some models of JVC devices cannot be operated with this remote control. Mute JVC DVD recorders and HDD recorders are set to code “C” or “3” by default. Volume Note Select a surround mode If the battery is removed, the remote control code reverts back to code A or 1. -
Page 19: Customizing Your Tv
Menu Item Adjustments / Confi gurations Customizing your TV Picture Mode Picture mode (Bright / Standard / Soft) Contrast Contrast (Lower Higher) Bright Brightness (Darker Brighter) Display the menu bar Sharp Sharpness (Softer Sharper) Colour Colour (Lighter Deeper) Tint Tint for NTSC (Reddish Greenish) White Balance Colour temperature (Warm / Mid / Cool) -
Page 20: Advanced Picture Adjustment
Advanced picture adjustment By default, the TV automatically adjusts itself for the best picture. Auto Super For smooth : Function is : When the : When : Automatically Auto Display the menu bar DigiPure looking picture turned off picture loses much noise adjusts sharpness... -
Page 21: Troubleshooting
Troubleshooting Problem Actions page Severe noise or snow Unplug the TV, and wait about 1 hour until the lamp Remote control stops completely cooled. Then plug the TV in again. (Turning on the working TV soon may shorten the lamp life.) Front control buttons do Switch “Child Lock”... - Page 22 Problem Actions page Problem Actions page Keep the TV off for a while and then turn the power on Adjust the “Bass” and “Treble.” again. If the TV goes into warning mode, unplug the TV Poor sound If receiving a poor signal in “Stereo / · ”, switch to “Mono.” The LAMP indicator after the cooling has completed and consult your retailer.
-
Page 23: Technical Information
Technical information CH/CC List Language group for teletext To use the INSERT function (P. 9), fi nd the “CH/CC” number corresponding to the TV’s Channel number from this table. Group Languages The US channel numbers are the channel numbers used in the United States, Philippines, etc. Group-1 Turkish, Hungarian, English, German, French, Italian, Spanish, Portuguese, Greek, Swedish, Finnish CCIR:... -
