Important Note:
In the spaces below, enter the model and serial number of your television (located
at the rear of the television cabinet). Staple your sales receipt or invoice to the
inside cover of this guide. Keep this user's guide in a convenient place for future
reference. Keep the carton and original packaging for future use.
Model Number:
Serial Number:
Projection Television Users Guide
Illustration of HD-P70R2U and RM-C14G
For Models:
HD-P61R2U
HD-P70R2U
LCT2178-001A-A
1106TNH-II-IM
Advertisement
Table of Contents
Related Manuals for JVC HD-P61R2U
Summary of Contents for JVC HD-P61R2U
- Page 1 Keep this user’s guide in a convenient place for future reference. Keep the carton and original packaging for future use. Model Number: Serial Number: Illustration of HD-P70R2U and RM-C14G For Models: HD-P61R2U HD-P70R2U LCT2178-001A-A 1106TNH-II-IM...
-
Page 2: Important Safety Precautions
5. In the event of trouble, unplug the unit and call a service technician. Do not attempt to repair it yourself or remove the rear cover. Changes or modifications not approved by JVC could void the warranty. * When you don’t use this TV set for a long period of time, be sure to disconnect both the power plug from the AC outlet and antenna for your safety. - Page 3 This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
- Page 4 13) Unplug this apparatus during lightning storms or when unused for long periods of time. 14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
-
Page 5: Warnings
Caring for the Cabinet Normally, light dusting with a soft, non-scratching duster will keep your TV clean. If you wish to wipe down the television, first unplug it. Then wipe gently with a soft cloth, slightly moistened with water. You can add a few drops of mild liquid detergent to the water to help remove spots of oily dirt. - Page 6 Warnings Thank you for purchasing a JVC HDTV-ready projection television which uses the high-quality HD-ILA projection system. This is one of the highest quality and most technologically advanced televisions available today. It is recommended that you read this instruction manual before using your television in order to learn about it’s many features.
- Page 7 4. The television requires a lot of electrical power It is recommended that the television is connected directly to the wall socket, and not to another device. When connecting the television to a wall socket that is being used by another device, or when using an extension cord, be careful not to exceed the electrical capacity of the socket.
-
Page 8: Table Of Contents
Table of Contents Important Safety Precautions . . 2 Warnings ....5 Quick Setup ....9 Unpacking your TV . -
Page 9: Quick Setup
Unpacking your TV Thank you for your purchase of a JVC Color Television. Before you begin setting up your new television, please check to make sure you have all of the following items. In addition to this guide, your television box should include:... -
Page 10: Tv Models
Quick Setup TV Models Before you connect your television to another device, please refer to the proper diagrams for your specific TV and remote. These will help assist you in understanding how to connect your television to another device, as well as use the remote to set up your television. Rear Panel Diagram S-VIDEO VIDEO... -
Page 11: Front Panel Diagram
Front Panel Diagram POWER LAMP/PROGRAM • For information on the LED, see page 89. Side Panel Diagram INPUT MENU OPERATE INPUT 4 CHANNEL – VIDEO L/MONO VOLUME – AUDIO POWER LAMP/PROGRAM LAMP/PROGRAM LED POWER BUTTON POWER LED Quick Setup... -
Page 12: Tv Remote Control
Quick Setup Remote Control • For information on remote control buttons, see pages 66 - 82. • i.LINK MENU, TIMER, SUB CHANNEL and GUIDE buttons are for digital channels. If your TV is connected to an ATSC antenna or Digital Cable, you can use these buttons. POWER TV CATV VCR DVD ASPECT... -
Page 13: Getting Started
To move rapidly through the channels using JVC’s Hyperscan feature, press and hold CH+ or CH –. The channels will zip by at a rate of five channels per second. The right and left buttons will turn the volume up or down. -
Page 14: Connecting Your Devices
Quick Setup Step 2 – Connecting Your Devices To make these connections, you will use plugs like the ones illustrated below. Coaxial Cables Used to connect an external antenna or cable TV system to your TV. S-Video Cable Used to make video connections with S-Video VCRs, Camcorders and DVD players. -
Page 15: Vcr Connection
VCR Connection Notes: • Green, blue and red are the most common colors for DVD cables. Some models may vary colors. Please consult the user’s manual for your DVD player for more information. • Be careful not to confuse the red DVD cable with the red audio cable. It is best to complete one set of connections (DVD or audio output) before starting the other to avoid accidentally switching the cables. -
Page 16: Audio Out
Quick Setup Diagram #2 Two-Way Splitter Two-Way Splitter (Attachment) ATSC /DIGITAL CABLE IN TV Rear Panel AUDIO OUT DVD Player (OPTIONAL) Cable or Antenna Output OUT OUT OUT OUT Coaxial Cable (Attachment) 75Ω (VHF/UHF) Green Blue S-VIDEO VIDEO R - AUDIO - L OVER VIDEO R - AUDIO - L... - Page 17 Connecting to Monitor/Recording Output Terminal Notes: • When you make this connection, set the Video-1 Monitor Out menu to ON. See page 54. • If you are receiving ATSC/Digital Cable signal, it can be outputted to the S-Video output terminal or Video (composite video) terminal. •...
-
Page 18: Connecting To A Camcorder
Quick Setup Connecting to a Camcorder You may connect a camcorder, game console or other equipment to your television by using the side input jacks (Input 4) located on the side of the television. You can also connect these using the television’s rear input jacks, using the same instructions. INPUT MENU OPERATE... -
Page 19: Connecting To The Surround Amplifier
Connecting to the Surround Amplifier In multi-channel sound such as 5.1 channel, the speech characters are played back from the center speaker. A center speaker in a movie theater is set in back of the screen so it can recreate a conversation scene in the movie more naturally. By using your TV's speaker as the center speaker, you can obtain the same sound effect as in a movie theater in you home theater sound system. - Page 20 Quick Setup Connecting to an amplifier using your optical output You can connect an amplifier that has an optical digital input terminal by using an optical digital cable from the optical output. The signal that is output can be PCM or Dolby Digital. TV Rear Panel OPTICAL OUT Digital Audio...
-
Page 21: Connecting To A Digital Tv Receiver
Connecting to a Digital TV Receiver By connecting a Digital TV Receiver, high definition pictures can be displayed on your TV in their digital form. AUDIO OUT DTV Decoder 1) Connect the HDMI to DVI Cable from the DIGITAL OUT on the back of your DTV decoder, to the HDMI1 DIGITAL-IN on the back of your television. - Page 22 Quick Setup Connecting to an HDMI Compatible Device By connecting an HDMI compatible device, high definition pictures can be displayed on your TV in their digital form. Some HDMI devices can include DVD players, D-VHS or any HDMI compatible devices. HDMI (High Definition Multimedia Interface) is the first industry supported, uncompressed, all digital audio/video interface.
-
Page 23: V1 Smart Input
Connecting to an AV Receiver using your television's V1 Smart Input By connecting your AV Receiver to your television's V1 Smart Input, you can watch picture sources from many different devices, without having to change or use the other input connections on your TV. -
Page 24: Tv Rear Panel
Setup, the video signal you are recording or playing back may stop or you may not be able to perform the Digital Auto Tuner Setup. • Your television can connect with i.LINK D-VHS decks and HD-Camcorders (JVC brand only). If you connect other brand devices, with i.LINK cable, they will not work. -
Page 25: Connecting To The Computer
Connecting to the computer This TV can be used as a computer screen. Use a commercially available D-SUB cable to connect the TV's PC INPUT terminal to the computer's analog RGB output terminal. If you want to listen to the sound from the computer, use a commercially available RCA cable to connect the INPUT-3 audio input terminal to the computer's audio output terminal. -
Page 26: Table Of Signals For Each Type Of Computer
Quick Setup Table of signals for each type of computer • Only the above formats are supported. • Even with the above formats at 60 Hz, some problems may be experienced depending on the quality of the synchronous signal. (Depending on the quality, some pictures may not be displayed correctly). -
Page 27: Interactive Plug In Menu
• If you press the Menu button while setting up the interactive plug-in menu, it will skip over it. Language After the “JVC INTERACTIVE PLUG IN MENU” has been displayed, the TV automatically switches to the LANGUAGE settings. You can choose to view your onscreen menus in three languages: ENGLISH, FRANÇAIS (French) or ESPAÑOL (Spanish). -
Page 28: Auto Clock Set
Quick Setup Auto Clock Set Before you use any of your TV’s timer functions, you must first set the clock. You may precisely set your clock using the XDS time signal broadcast by most public analog broadcasting stations. If you do not have this in your area, you will have to set the clock manually. - Page 29 You can now begin watching your television, or you can continue on in this guide for more information on programming your remote control, or using the JVC onscreen menu system to customize your television viewing experience. Notes: •...
-
Page 30: Programming Your Remote
Quick Setup Remote Programming You can program your remote to operate your cable box, satellite receiver, VCR or DVD player by using the instructions and codes listed below. If the equipment does not respond to any of the codes listed below or to the code search function, use the remote control supplied by the manufacturer. -
Page 31: Vcr Codes
VCR Codes The remote control is programmed with VCR codes for power on/off, play, stop, fast-forward, rewind, pause, record, channel up/down operation. 1) Find the VCR brand from the list of codes shown below. 2) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “VCR”. 3) Press and hold down the D key pad. -
Page 32: Dvd Codes
Quick Setup DVD Codes The remote control is programmed with DVD codes for power on/off, play, stop, fast-forward, rewind, previous/next chapter, tray open/close, and still/pause operation. 1) Find the DVD player brand from the list of codes shown below. 2) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “DVD”. 3) Press and hold down the D key pad. -
Page 33: Search Codes
Search Codes Cable/Satellite Search Codes Function 1) Slide the first 2-Way Mode Selector switch to CATV. 2) Press the P and R OWER ETURN 3) Press the P button on the remote, and see if the cable or satellite box responds. OWER 4) If there was a response, press R response, repeat Step 3. -
Page 34: Onscreen Menus
Onscreen Menus Using the Guide Certain symbols are used throughout this guide to help you learn about the features of your new television. The ones you will see most frequently are: π † Up and Down arrows mean press the C buttons let you: •... -
Page 35: Onscreen Menu System
The Onscreen Menu System Your television comes with JVC’s onscreen menu system. The onscreen menus let you make adjustments to your television’s operation simply and quickly. Examples of the onscreen menus are shown on the next page. Detailed explanations on using each menu follow later in this guide. -
Page 36: Initial Setup 04
Onscreen Menus Press the M button To INITIAL SETUP 03 INITIAL SETUP PREVIOUS AUTO TUNER SETUP CHANNEL SUMMARY V-CHIP SET LOCK CODE NEXT PAGE (4/5) SELECT OPERATE EXIT MENU INITIAL SETUP 04 INITIAL SETUP PREVIOUS DIGITAL SETUP NEXT PAGE (5/5) SELECT OPERATE EXIT... -
Page 37: Auto Tuner Setup
Auto Tuner Setup The auto tuner setup function is described on page 29 as the interactive plug-in menu. If you need to run the auto tuner setup again, follow the steps below. Press the M button To AUTO TUNER SETUP π... -
Page 38: Channel Summary
Onscreen Menus Channel Summary Channel summary allows you to customize the line-up of channels received by your TV. Regarding analog channels, you can add or delete channels from the line-up or prevent any unauthorized viewers from watching any or all 191 channels. Regarding digital channels, the only channels that will appear are the ones that are broadcasting. -
Page 39: Channel Label
How to set the channel label. (This is only for analog broadcasting.) Press the M button To CHANNEL SUMMARY π † √® To operate To the ID column π † Press the O button to enter √® To select the character you want To move to the next space π... -
Page 40: V-Chip
Onscreen Menus Channel Guard Message When a viewer attempts to watch a guarded channel, the following message appears: To watch a channel that you have locked, enter the Lock Code using the 10 key pad. If the wrong code is entered, the message “INVALID LOCK CODE!”... -
Page 41: Unrated Programs
Unrated Programs Unrated programming refers to any programming which does not contain a rating signal. Programming on television stations which do not broadcast rating signals will be placed in the “Unrated Programming” category. Examples of Unrated programs: • Emergency Bulletins •... - Page 42 Onscreen Menus US V-Chip Ratings U.S. PARENTAL RATING SYSTEMS Programs with the following ratings are appropriate for children. ❒ TV Y is Appropriate for All Children Programs are created for very young viewers and should be suitable for all ages, including children ages 2 - 6.
-
Page 43: Setting Us V-Chip Ratings
Setting US V-Chip Ratings Press the M button To V-CHIP π † √® To operate (lock icon Press Z to access the V-Chip menu √® To turn V-Chip ON or OFF To move to SET US TV RATINGS π † √®... -
Page 44: Directions To Set Movie (Mpaa) Ratings
Onscreen Menus Movies Ratings ❒ NR – Not Rated This is a film which has no rating. In many cases these films were imported from countries which do not use the MPAA ratings system. Other NR films may be from amateur producers who didn’t intend to have their film widely released. -
Page 45: Directions To Set Canadian V-Chip Ratings
Canadian V-Chip Ratings ❒ E – Exempt Exempt programming includes: news, sports, documentaries and other information programming, talk shows, music videos, and variety programming. ❒ C – Programming Intended for Children Violence Guidelines: There will be no realistic scenes of violence. Depictions of aggressive behavior will be infrequent and limited to portrayals that are clearly imaginary, comedic or unrealistic in nature. -
Page 46: Set Lock Code
Onscreen Menus Set Lock Code Channel guard and V-Chip settings are protected by a four-digit lock code. Your TV comes preset with a lock code of “0000”. You may change the code to any four-digit number you wish. To change the lock code, follow the steps below. Press the M button To SET LOCK CODE... -
Page 47: Language
Language The language function is described on page 27 as the interactive plug-in menu. If you need to choose the language again, follow the steps below. Press the Menu button To LANGUAGE π † √® To choose a language: ENG. (English), FRAN. - Page 48 Onscreen Menus Digital Auto Setting Press the M button To CLOSED CAPTION π † √® To enter To Type π † √® To select Auto, Advanced or Basic Auto: Shows closed caption a priority for digital channels over analog channels. It is set automatically.
- Page 49 Digital Manual Setting Press the M button To CLOSED CAPTION π † √® To enter To Type π † √® To select Auto, Advanced or Basic To Service π † √® To select 1, 2, 3, 4, 5 or 6 To Appearance π...
-
Page 50: Auto Shut Off
Onscreen Menus Auto Shut Off This function automatically shuts off your TV when there is no signal from the channel the TV is on. Press the M button To AUTO SHUT OFF π † √® To turn ON or OFF Press the M button when finished •... -
Page 51: Front Panel Lock
Front Panel Lock This allows you to lock the keys on the side of the TV, so that a child may not accidentally change your viewing preferences. Press the M button To FRONT PANEL LOCK π † √® To turn ON or OFF Press the M button when finished You can turn off this feature in the following ways:... -
Page 52: Video Input Label
Onscreen Menus Video Input Label This function is used to label video input connections for the onscreen displays. Press the M button To VIDEO INPUT LABEL π † √® To enter To select the desired video input π † √® To select the desired preset input label (see chart below) Press the OK button to save... -
Page 53: Position Adjustment
Position Adjustment Position adjustment allows you to adjust the position of the picture on the screen vertically when the aspect is set to panorama or cinema. Press the M button To POSITION ADJUSTMENT π † √® To enter √® To adjust the position π... -
Page 54: Video-1 Monitor Out
Onscreen Menus Video-1 Monitor Out This function allows you to set whether the signal, which comes from VIDEO-1 input terminal, should be output from MONITOR OUT terminal. If you select it from MONITOR OUT, set it to "ON". Press the M button To VIDEO-1 MONITOR OUT π... -
Page 55: Digital-In
Digital-In The DIGITAL-IN option can only be displayed in the INITIAL SETUP menu when an HDMI480p picture signal is being input to the DIGITAL-IN terminal. This option adjusts the position when an HDMI or DVI 480p picture signal is being displayed on the screen. There are two types of HDMI480p picture signals: 640x480 and 720x480. -
Page 56: Center Ch Input
Onscreen Menus Center CH Input When you are using a surround system, you can substitute the speaker of this television for the center speaker of your surround system. Set CENTER CH INPUT to ON when you use the speaker as the center speaker of your surround system. The volume differs when the TV is being utilized as the Center Channel Input versus when it is not. -
Page 57: Antenna Level
Antenna Level Confirms the present antenna level. Press the M button To DIGITAL SETUP π † √® To enter To Antenna Level π † √® To enter Note: • If you are watching an analog channel or a signal from your i.LINK device, antenna level will not appear. -
Page 58: Cable Card Application
Onscreen Menus Cable Card Application Press the M button To DIGITAL SETUP π † √® To enter To Cable Card Application π † √® To enter Press the O button The application will perform i.LINK Auto Play When playing a D-VHS tape, you can set it to the i.LINK input automatically, or manually. Press the M button To DIGITAL SETUP... -
Page 59: Picture Adjust
Picture Settings These settings allow you to change and adjust the way the picture appears on your television. TINT Tint allows you to adjust the levels of red and green in your TV picture. COLOR The color function lets you make all the colors in the TV picture appear either more vivid or subtle. -
Page 60: Color Management
Dynamic Gamma JVC's Dynamic Gamma Circuitry (DGC) makes it easier to see dark areas when a picture has many dark areas, and makes it easier to see the bright areas when a picture has many bright areas. DGC is turned on, DGC analyzes and adjusts the total level of picture brightness... -
Page 61: Digital Vnr
Digital VNR This function can be selected to change the effect of Digital VNR (Video Noise Reduction). Press the M button To DIGITAL VNR π † √® To enter To select the effect you like. π † AUTO: adjusts the effect of VNR automatically. MIN: adjusts the effect of VNR to minimum. -
Page 62: Sound Adjust
Onscreen Menus Sound Settings These settings allow you to change and adjust the sound on your television. BASS – You can increase or decrease the level of low-frequency sound in the TV’s audio with the bass adjustment. TREBLE – Use treble to adjust the level of high-frequency sound in your TV’s audio. BALANCE –... -
Page 63: Clock/Timers
Set Clock The set clock function is described on page 28 as the interactive plug-in menu. You can choose to set the clock automatically or manually. If you need to set the clock again, follow the steps below. Press the M button To SET CLOCK π... -
Page 64: On/Off Timer
Onscreen Menus On/Off Timer The on/off timer lets you program your television to turn itself on or off. You can use it as an alarm to wake up, to help you remember important programs, or as a decoy when you’re not home. -
Page 65: Lamp Timer Reset
Lamp Timer Reset The lamp replacement message will appear when you need to change the lamp. After you replace the lamp, you need to reset the timer which is built into your television. Press the M button To LAMP TIMER RESET π... -
Page 66: Button Functions
Button Functions Multi Screen Function Your television has two kinds of screen: TWIN (2 channels) and INDEX (12 channels). Note: After you press any multiscreen buttons, if you press the menu button, only the picture adjust screen will appear. Twin Activate the split-screen option by pressing T the remote control. -
Page 67: Index
Index This allows you to quickly look at up to 12 channels at a time so that you can decide which one to watch. Notes: • Only Analog channel input signal will be displayed. • You can watch the channel added in channel summary. See page 38. Freeze Pressing the F button causes the screen to change to the split-screen display with the still... -
Page 68: Power
Button Functions Power Turns the TV on or off. Press the P OWER Note: • After turning the power on, you can not turn the power off for about one minute. Number Buttons - 10Key Pad Use the number buttons on the remote control to move directly to a specific channel. For example, to move to channel 12: 0 (Zero) 1 (One) -
Page 69: Channel
Channel +/– Use these buttons to move up or down all the available channels your TV is able to receive. Volume +/– Use these buttons to raise or lower the TV’s volume level. The maximum is the level you set in Volume Limit. -
Page 70: Sound
Button Functions Sound By pressing the S button, you can change the A.H.S.+ (Advanced Hyper Surround plus) OUND mode, VOICE ENHANCEMENT, SMART SOUND or MaxxBass on or off. A.H.S.+ - Adds a more spacious surround sound. Music gives basic effect and movie for more effect. -
Page 71: Natural Cinema
Natural Cinema Natural cinema corrects the problem of blurred edges which may occur when viewing a program originally shot on film (such as motion pictures) or animation. If you notice blurring at the edges of these programs, press N ATURAL conversion errors that occur when film, which is shot at 24 frames-per-second, is broadcast at the television rate of 30 frames-per-second. -
Page 72: Sleep Timer
Button Functions Sleep Timer The Sleep Timer can turn the TV off for you after you fall asleep. Program it to work for a total time of up to 180 minutes. Press the S button LEEP 60 seconds before the automatic shutoff, this message will appear: You then have 60 seconds to press the S delay the shut off for another 15 minutes. -
Page 73: Display
Display The display screen shows the current status of timers, inputs and XDS ID. Press the D ISPLAY The screen to the right shows the following information: • The current channel or AV input (Channel 05) • The current time (12:20 pm) •... -
Page 74: Favorite
Button Functions Favorite The Favorite button allows you to select your favorite channels easily. First, you must register the channels that you like. See how to register below. Press the F AVORITE The favorite channel list will appear. To select the channel you want to watch π... -
Page 75: Aspect
Aspect This feature will help you adjust the picture you are watching to give you the best possible picture quality. Aspect Ratios PANORAMA - With this ratio a normal 4:3 aspect picture is stretched to fit the dimensions of the 16:9 aspect screen. CINEMA - This ratio “zooms in”... -
Page 76: Menu
• When you are receiving a 1080p signal, you can not change the aspect ratios. Menu The M button allows you to access JVC’s onscreen menu system. Press M the onscreen menu system. • See individual topics like “Sound Adjust” for specific information on using menus. -
Page 77: Tv/Catv Slide Switch
VCR, please see the code chart and instructions on page 31. • The remote is preset with the code 000 to control JVC-brand DVD players. For any other manufacturer’s brand DVD player, please see the code chart and instructions on page 32. -
Page 78: D/A (Digital/Analog)
Button Functions D/A (Digital/Analog) The D/A button changes the analog and digital channel. Each time you press the D/A button, you can switch back and forth the analog and digital channels. Digital channels have a "D" in front of the channel number. Note: •... -
Page 79: I.link Menu
i.LINK Menu i.LINK has two menus - Controller and Device. By connecting a D-VHS VCR with an i.LINK cable, you can set the timer easily. Notes: • The i.LINK/Timer function will only work when you are receiving digital programming only. •... - Page 80 Button Functions Device To operate, select a device. i.LINK Controller Device D-VHS1 HM-DH30000U D-VHS2 HM-DH40000U HD-MOVIE 1 GR-HD1 To select your device connecting with i.LINK π † Press the OK button Notes: • If you do not select the device, you cannot use the i.LINK timer functions. •...
-
Page 81: Timer
Timer You can set the two timers: Record and view. The timer starts the recording or turns to the channel you set for it automatically. Reservation Press the T button IMER To New Reservation π † Press the O button New Reservation Timer New Reservation... -
Page 82: Timer Edit
Button Functions Timer Edit When you want to confirm the timer you set or edited, or delete the timer setting, use this function. Timer Edition Press the T button IMER To select the timer list you want to edit π † Press the O button √®... -
Page 83: Osd Information
Weak Signal This OSD warning appears when the digital channel that you have selected is too weak to receive or no signal is being detected for that channel. No Program If the external input terminal you selected, or were watching is not receiving a signal, "NO PROGRAM"... -
Page 84: Cable Card Information
Cable Card Information Cable card offers information when a cable card is inserted into the CABLE CARD slot on the back of the TV. Notes: • Please contact your local cable company regarding detailed information. • When the cable card is inserted into the cable card slot, if you turned the power off, the fan will continue to rotate because the program information is being renewed. -
Page 85: Lamp Replacement
Changing the Lamp It is very important that you NEVER TOUCH THE GLASS SURFACE OF THE NEW LAMP. Touching the glass surface will deposit oils from your hand onto the lamp surface. When the lamp heats up to its operating temperature, the oil will cause a difference in temperature on the lamp surface that will likely cause the lamp to break. - Page 86 Replacement Lamp Kit Before replacing the lamp, you will need to purchase a replacement kit, part number TS-CL110U. To purchase this kit, consult your dealer or call 1-800-252-5722, or go to www.jvc. com. The replacement kit will include the following:...
- Page 87 How to Replace the Lamp Please read these instructions fully before attempting to replace the lamp. If you feel unsure about replacing the lamp yourself, call a service technician. Please observe all safety warnings. 1) Turn off the television. Press the POWER button on the remote control or TV front panel. Wait until the picture has closed and the LAMP LED on the front panel has stopped blinking indicating the lamp cool down is complete.
- Page 88 Lamp Replacement 4) Remove the lamp unit. Using a Philips head type screwdriver (cross-head type), loosen the two screws fastening the lamp unit. When the screws have been loosened, remove the lamp by raising the handle and gently sliding the unit straight towards you. Place it carefully in the recycling packaging. 5) Install the new lamp unit.
- Page 89 Warning LED Messages While the power is on, and there is a problem with the TV, the TV changes to warning mode and informs you of the problem using the LED as follows. Then, the power turns off automatically and performs the cooling for approximately 1 minute. The LAMP/PROGRAM LED blinks Condition: It may be a malfunction of the internal electrical circuits.
-
Page 90: Troubleshooting
Troubleshooting PROBLEMS There is no power • See if the power cord became unplugged. • Check for a blown fuse or circuit breaker or a power outage. • It is possible the fan is stuck or the inside temperature is rising abnormally. Consult your dealer. - Page 91 PROBLEMS There is no sound • The Center CH Input may be turned on. See page 56. from the TV's • The TV Speaker option may be turned off. See page 54. speaker Static electricity • It is normal to feel static electricity if you brush or touch the screen. You hear occasional •...
-
Page 92: Specifications
Accessories Specifications subject to change without notice. • The open source software is embedded in this product. For more information, please go to: http://software.jvc.com/opensource/lnx/DP/04_AtscCC/download.html HD-P61R2U HD-ILA Device Projection NTSC, BTSC System (Multi-Channel Sound) ATSC Terrestrial, Digital Cable VHF 2 to 13, UHF 14 to 69 at ATSC,... -
Page 94: Notes
Notes... - Page 95 Notes...
