OPERATING CONTROLS
5
SPEAKER
The speaker allows you to hear calls on
your channel. Note that the speaker can
be muted using the squelch control.
6
MICROPHONE
The microphone allows your voice to be
heard in other radios. Hold the radio
about two inches away while talking into
the front grille. Shouting does not
improve listener reception.
7
SQUELCH CONTROL
The squelch control knob can mute noise
in the absence of an incoming radio
signal. To silence noise, rotate the
squelch control knob clockwise until noise
first occurs. Then rotate the knob counter-
clockwise to the point that noise stops.
QUIET CALL (QC)
If the JBX unit is equipped with an
RTS-5PA module, you can turn on QC
squelch by rotating the squelch control
fully counterclockwise until the switch
clicks. The radio will then stay quiet until
it receives a call from a unit that transmits
your QC code.
Wait until the channel is free before
transmitting, to avoid interfering with
other users. Listen for others talking on
the channel by rotating the squelch
control clockwise out of the Quiet Call
click position.
When the PTT button is pressed, the QC
code is automatically transmitted with
your broadcast, independent of the
squelch control setting.
8
AUDIO JACK
The audio jack can be used to connect
optional accessories, such as a remote
speaker/microphone or an earphone.
NOTE: The remote speaker/ microphone
(RSM-3X) has a two-plug
connector. Insert the smaller
plug into the charge jack.
All manuals and user guides at all-guides.com
5
NOISE
5
9
BATTERY DOOR
This door covers the battery compart-
ment, holding the battery pack in place.
Refer to FIG-2 (page 6) as you continue
reading.
To remove the battery door, unlock the
door latch at the bottom of the radio using
your thumbnail or a coin. When the latch
is unlocked, the color "red" shows. Slide
the door away.
To install the door, align it with the battery
compartment (the door’s top edge faces
the antenna). Place the door against the
compartment and slide the door up, into
the slots shown in FIG-2. Then lock the
door latch.
10 DROP-IN CHARGER
CONTACTS
See FIG-1, left. Three charger contacts,
visible through the bottom of the radio
case, allow the battery pack to be
charged with an optional RITRON drop-in
charger. You may charge the battery
pack inside or out of the radio case.
Plug the drop-in charger into an 110 VAC
outlet. Set the portable or battery into the
charger, three contacts facing down, with
each battery contact resting on a charger
contact pin.
An optional "fast rate" drop-in charger unit
charges the standard battery in less than
two hours. For a list of optional battery
chargers, refer to the "Accessories"
section (page 9).
5
