IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased: ____________________
INSTALLATION & OPERATION
MANUAL
Gas Modular Skillets
GMTS-30 GMTS-40 GMTS-60
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read
the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
CROWN FOOD SERVICE EQUIPMENT
y
A Middleby Compan
70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9
Telephone: 919-762-1000
www.crownsteamgroup.com
Printed in Canada
MANUAL 10094R2
Advertisement
Table of Contents
Related Manuals for Crown GMTS-30
Summary of Contents for Crown GMTS-30
- Page 1 Date Purchased: ____________________ INSTALLATION & OPERATION MANUAL Gas Modular Skillets GMTS-30 GMTS-40 GMTS-60 WARNING Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
-
Page 2: Important Notes For Installation And Operation
INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) 1.0 IMPORTANT NOTES FOR INSTALLATION AND OPERATION It is recommended that this manual be read thoroughly and that all instructions be followed carefully. This manual should be retained for future reference. This is the safety alert symbol. -
Page 3: Table Of Contents
INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) TABLE OF CONTENTS DESCRIPTION PAGE 1.0 Important Notes for Installation and Operation ........2 2.0 Service Connections . -
Page 4: Service Connections
INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) 2. SERVICE CONNECTIONS Part No. 10094R2 2019-01-16... - Page 5 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) Part No. 10094R2 2019-01-16...
-
Page 6: Installation Instructions
Before installing, verify that the electrical service agrees with the specifications on the rating plate located on the left side panel as you face the front of the braising pan. If the supply and equipment requirements do not agree, contact your dealer or Crown Food Service Equipment Ltd. - Page 7 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) 3.0 INSTALLATION INSTRUCTIONS (Continued) LEVELLING AND ANCHORING TILTING BRAISING PAN Place tilting braising pan in the installation position. Place a carpenter’s level on top of the braising pan and turn the adjustable feet to level braising pan side-to-side and front-to-back.
- Page 8 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) GAS CONNECTIONS (Continued) After piping has been checked for leaks, all piping receiving gas should be fully purged to remove air. WARNING: Never use an open flame to check for gas leaks. Check all connections for leaks using soapy water before use.
- Page 9 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) INSTALLATION INSTRUCTIONS (Continued) ELECTRICAL CONNECTIONS WARNING: Do not connect the appliance to the electrical supply until after the gas connection has been made. WARNING: ELECTRICAL GROUNDING INSTRUCTIONS This appliance is equipped with a three-prong (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-prong receptacle.
-
Page 10: Operating Instructions
INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) 4.0 OPERATING INSTRUCTIONS WARNING: The tilting braising pan and its parts are hot. Use care when operating, cleaning and servicing the tilting braising pan. BEFORE FIRST USE Using a non-corrosive, grease-dissolving commercial cleaner, clean the protective metal oils from all surface parts and the interior of the tilting braising pan. - Page 11 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) 4.0 OPERATING INSTRUCTIONS (Continued) START UP PROCEDURE Open the manual gas shut-off valve located inside cabinet on left side when facing the front of the unit. Ensure that the skillet pan is in the down or horizontal position. Turn the “POWER”...
- Page 12 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) 4.0 OPERATING INSTRUCTIONS (Continued) TILTING THE BRAISING PAN 1. DO NOT try to tilt braising pan with lid down. Turn MOTOR switch on. 2. Make sure the receiving pan is in place. 3.
-
Page 13: Cleaning Instructions
INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) 5.0 CLEANING INSTRUCTIONS WARNING: Disconnect the power supply to the appliance before cleaning or servicing. After each use, allow the tilting braising pan to cool before cleaning. Keep exposed cleanable areas of the tilting braising pan clean at all times. -
Page 14: Cooking Temperatures
INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) 6.0 COOKING TEMPERATURES Temperature ( F) Thermostat Setting Simmering 200 Maximum 1 - 4 Sautéing 225 - 275 5 - 6 Searing 300 - 350 7 - 8 Frying 325 - 375 8 - 9 Grilling 350 - 450... -
Page 15: Maintenance
INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) 7.0 MAINTENANCE NOTICE: Contact the factory, factory representative or local service company to perform maintenance and repairs. WARNING: The tilting braising pan and its parts are hot. Use care when operating, cleaning and servicing the tilting braising pan. WARNING: Disconnect the power supply to the appliance before cleaning or servicing. - Page 16 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) HYDRAULIC SYSTEM (Continued) 6. Check the cleanliness of the oil strainer inside the reservoir once per year. This item can be washed in clean Varsol. 7. Change the breather filter once per year. 8.
- Page 17 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) ADJUSTMENTS AND CONTROLS (Continued) FLOW CONTROL: There are two flow control valves mounted on the power unit and located on the solenoid valve subplate. The flow control valves will restrict the capacity of oil passing through them when the knurled knob is screwed in - in a clockwise direction.
-
Page 18: Troubleshooting
INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) 8.0 TROUBLESHOOTING 1. BURNERS DO NOT COME ON: 1. Gas supply to unit is “OFF”. 2. Manual shut off valve is “OFF”. 3. Thermostat is not turned “ON”. 4. Pan not in lowest position. 5. - Page 19 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) TROUBLESHOOTING - HYDRAULICS (Continued) 2. FOAMING OIL: 1. Return of tank line not below fluid level. 2. Fluid contamination. 3. Suction leak to pump. 3. MOISTURE IN OIL: 1. Fill pipes left open. 2.
- Page 20 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) TROUBLESHOOTING - HYDRAULICS (Continued) 5. Aeration of fluids in reservoir (return line above fluid level.) 6. Worn cam ring, damaged gear, faulty bearing. 7. Reversed rotation. 8. Plugged lines. 9. Oil viscosity too high or temperature too low. 10.
-
Page 21: Material Safety Data Sheets
INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) Part No. 10094R2 2019-01-16... - Page 22 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) Part No. 10094R2 2019-01-16...
- Page 23 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) Part No. 10094R2 2019-01-16...
- Page 24 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) Part No. 10094R2 2019-01-16...
- Page 25 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) Part No. 10094R2 2019-01-16...
- Page 26 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) Part No. 10094R2 2019-01-16...
- Page 27 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) Part No. 10094R2 2019-01-16...
- Page 28 INSTALLATION AND OPERATION MANUAL, GAS SKILLETS, MODELS GMTS-(30, 40, 60) Part No. 10094R2 2019-01-16...
