P/N 127017-01 Rev. H 10/2019
Ce manuel est disponible en francais, simplement
en faire la demande. Numéro de la pièce 127017-02.
P127017-01
This book is valuable. In addition to instructing you on how to install and maintain your appliance, it also
contains information that will enable you to obtain replacement parts or accessory items when needed. Keep
it with your other important papers.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This wood burning fireplace complies with UL127
CAN/ULC-S610-M87 standard as a FACTORY
BUILT FIREPLACE.
This fireplace is approved for use as a wood burning fireplace or for use with a vented gas log approved to
ANSI Z21.60 or Z21.84 standards or for use with a vent-free gas log heater approved to ANSI Z21.11.2 standard .
FOR CANADA: The authority having jurisdiction
(such as the municipal building department, fire
department, etc.) should be contacted before
installation to determine the need to obtain a permit.
This installation manual will enable you to obtain a safe, efficient and dependable installation of your fireplace
system. Please read and understand these instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any circumstances. Any modification or alteration of
the fireplace system, including but not limited to the fireplace, chimney components and accessories, may void the
warranty, listings and approvals of this system and could result in an unsafe and potentially dangerous installation.
IMPORTANT! TO ASSURE PROPER ALIGNMENT OF GLASS DOORS: INSTALL THIS FIREPLACE IN A SQUARE
AND PLUMB CONDITION, USING SHIMS AS NECESSARY AT SIDES AND/OR BOTTOM.
PFS
C
REPORT NO. F09-095
SAVE THIS BOOK
NOTE: DIAGRAMS AND ILLUSTRATIONS THROUGHOUT THE MANUAL ARE NOT TO SCALE.
Installation and Operation Instructions
Superior
Outdoor Wood Burning Fireplace
®
®
US
WRE4536WS
WRE4536WH
Installateur : Laissez cette notice avec l'appareil.
Consommateur : Conservez cette notice pour consultation ultérieure.
Ce foyer au bois est conforme aux UL 127 CAN/ULC-
S610-M87 norme comme une USINE CONSTRUITE
CHEMINÉE.
POUR LE CANADA: L'autorité compétente (comme le
service municipal du bâtiment, les pompiers, etc.) doit
être contacté avant l'installation afin de déterminer la
nécessité d'obtenir un permis.
Models
WRE4550WS
WRE4542WS
WRE4550WH
WRE4542WH
Advertisement
Table of Contents
Related Manuals for Superior Fireplaces WRE4536WS
Summary of Contents for Superior Fireplaces WRE4536WS
- Page 1 Outdoor Wood Burning Fireplace ® P/N 127017-01 Rev. H 10/2019 Models Ce manuel est disponible en francais, simplement en faire la demande. Numéro de la pièce 127017-02. ® WRE4550WS WRE4536WS WRE4542WS WRE4550WH WRE4536WH WRE4542WH REPORT NO. F09-095 P127017-01 SAVE THIS BOOK This book is valuable.
-
Page 2: Table Of Contents
Thank you for your purchase. We appreciate your TABLE OF CONTENTS business! Safety .....................2 Please carefully read and follow all instructions in this manual. Pay Specifications .................4 special attention to all warnings and safety information. Fireplace Installation ..............7 Following these safety, care, and operation instructions will help Venting Installation ................9 ensure many years of dependable and enjoyable service from your Refractory Panels Installation ............16... - Page 3 SAFETY Continued WARNING: CONTINUED OVERFIRING CAN PER- WARNING: BURNING IMPROPER FUEL (I.E. CHAR- MANENTLY DAMAGE YOUR FIREPLACE SYSTEM. COAL) CAN RESULT IN CARBON MONOXIDE POISON- SOME EXAMPLES OF CONDITIONS THAT COULD ING, WHICH MAY LEAD TO DEATH! CAUSE OVERFIRING ARE: Carbon Monoxide Poisoning –...
-
Page 4: Specifications
SPECIFICATIONS 36" MODEL 1" (26 mm) CHIMNEY AIRSPACE CLEARANCE TO COMBUSTIBLE MATERIAL NO COMBUSTIBLE MATERIAL ON FACE COMBUSTIBLE WALL BOARD " (39 mm) AIR SPACE BACK AND SIDES OUTSIDE AIR MINIMUM 12" (305 mm) TOPERPENDICULAR GAS LINE SIDEWALL KNOCKOUTS HEARTH EXTENSION 60" X 20" 0"... - Page 5 SPECIFICATIONS Continued 42" MODEL 2" (51 mm) CHIMNEY AIRSPACE CLEARANCE TO COMBUSTIBLE MATERIAL NO COMBUSTIBLE MATERIAL ON FACE COMBUSTIBLE WALL BOARD " (39 mm) AIR SPACE BACK AND SIDES OUTSIDE AIR MINIMUM 18" (458 mm) TOPERPENDICULAR GAS LINE SIDEWALL KNOCKOUTS HEARTH EXTENSION 66"...
- Page 6 SPECIFICATIONS Continued 50" MODEL 2" (51 mm) CHIMNEY AIRSPACE CLEARANCE TO COMBUSTIBLE MATERIAL NO COMBUSTIBLE MATERIAL ON FACE COMBUSTIBLE WALL BOARD " (39 mm) AIR SPACE BACK AND SIDES OUTSIDE AIR MINIMUM 18" (458 mm) TO PERPENDICULAR GAS LINE SIDEWALL KNOCKOUTS HEARTH EXTENSION 74"...
-
Page 7: Fireplace Installation
FIREPLACE INSTALLATION SELECTING LOCATION fabricated to fit your required platform height. Ember protector should extend under fireplace a minimum of 1 ". Ember protector To determine the safest and most efficient location for the fireplace, should be made of galvanized sheet metal (28 gauge minimum to you must take into consideration the following guidelines: prevent corrosion. - Page 8 FIREPLACE INSTALLATION Continued HEARTH EXTENSION MANTELS A hearth extension projecting a minimum of 20" in front of and a A mantel may be installed if desired (see Figure 7). Woodwork such as minimum of 12" beyond each side of fireplace opening is required wood trims, mantels or any other combustible material projecting from to protect combustible floor construction in front of fireplace.
-
Page 9: Venting Installation
VENTING INSTALLATION LINEAL GAIN OPTIONAL OUTSIDE AIR KIT (MODEL AK4/AK4F) PART NO. DESCRIPTION GAIN The installation of an outside air kit should be performed during Signature Fireplace " the rough framing of the fireplace due to the nature of it's location. 12-12DM Pipe Section "... - Page 10 VENTING INSTALLATION Continued USING ELBOW OFFSETS (30E-12DM) OFFSET RISE CHIMNEY LENGTH 12" 18" 24" 36" 48" 1. To achieve desired offset, you may install combinations of 12", " " ELBOW SET ONLY 18", 24", 36" and 48" length of double wall pipe (see offset chart "...
- Page 11 VENTING INSTALLATION Continued Return Return Elbow Elbow Return Offset Offset Elbow Elbow Elbow 6' (1.83 m) 6' (1.83 m) Max. Max. Return Ceiling Support Return 6' (1.83 m) Elbow Pipe 12S-12DM Elbow Max. 6' (1.83 m) Offset Max. Offset Elbow 6' (1.83 m) Elbow 6' (1.83 m)
- Page 12 VENTING INSTALLATION Continued FLASHING INSTALLATION (V6F-10DM OR V12F-10DM) 17" Determine the flashing to be used with the roof opening chart. Slide (432 mm) flashing over pipe until base is flat against roof. Replace as many 30" (762 mm) Min. 1" (26 mm) Min.
- Page 13 VENTING INSTALLATION Continued Terminations/Spark Arrestor 10 FOOT RULE The fireplace system must be terminated with the listed round top All flue gas outlet chimney terminations must extend a minimum of or chase terminations. 3 feet in height above the highest point where it passes through the roof and must be at least 2 feet above the highest point of the roof CAUTION: Do not seal openings on the rooftop that is within a horizontal distance of 10 feet (see Figure 20).
- Page 14 VENTING INSTALLATION Continued Fabricate a flashing having a 16-1/2" diameter hole centered Termination over chimney end with a 2" collar around hole (see Figure 22). Attach noncombustible spacers at each corner and place flash- Sheet Metal Screw ing over chase. 1"...
- Page 15 VENTING INSTALLATION Continued Attach noncombustible spacers at each corner and place flashing Note: Do Not Seal Termination Cap over chase (see Figure 27). Secure flashing through sides with Ventilation Openings 8-penny nails or sheet rock screws. Caulk Place termination cap over opening. Slip stainless steel inner pipe of termination into inner stainless steel chimney section Storm Collar 6"...
-
Page 16: Refractory Panels Installation
REFRACTORY PANEL INSTALLATION WARNING LIFTING HAZARD SINGLE -PERSON LIFT COULD CAUSE INJURY. USE ASSISTANCE WHEN MOVING OR LIFTING. IMPORTANT: Installation of Refractory panels should be done after the fireplace is placed in a permanent location. 1. Remove grate, screen assemblies and all hardware components Figure 31 - Installing Grate Retainers out of the firebox. -
Page 17: Optional Gas Line Installation
OPTIONAL GAS LINE INSTALLATION Gas line hook up should be done by your supplier or a qualified service person. Outside of Fireplace Note: Before you proceed, make sure your gas supply is turned off. Side Firebrick Incoming Use only a 1/2" black iron pipe and appropriate fittings. Finished Side 1/2"... -
Page 18: Glass Door Installation
GLASS DOOR INSTALLATION IMPORTANT: Install glass door frame before installing glass Fold Door and Slide Spring Clip Top Pins Into Track door. Insert Pin into INSTALLING DOOR FRAMES Spring Clip 1. Remove screws from smoke shelf (see Figure 36). 2. Mount top door frame and secure with screws removed in step 1. 3. -
Page 19: Operation And Maintenance Guidelines
OPERATION AND MAINTENANCE GUIDELINES IMPORTANT NOTICES - CANADA IMPORTANT NOTICE WARNING: Do not slam or strike doors. Damage A manufactured shroud which has been approved by a can result in a hazardous condition. national testing agency for use with this fireplace may be used if installed in accordance with the instructions WARNING: Discontinue use of the appliance imme- by its manufacturer. -
Page 20: Parts
PARTS MODEL CATALOG NO. WRE4536WS F0438 WRE4536WH F0440 WRE4542WS F0442 WRE4542WH F0444 WRE4550WS F0446 WRE4550WH F0448 16/17 SuperiorFireplaces.us.com 127017-01_H... - Page 21 PARTS This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on page 24 of this manual. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP.
- Page 22 LIFTING HAZARD SINGLE -PERSON LIFT COULD CAUSE INJURY. USE ASSISTANCE WHEN MOVING MODEL CATALOG NO. WRE4536WS F0438 OR LIFTING. WRE4536WH F0440 WRE4542WS F0442 WRE4542WH F0444 WRE4550WS F0446 WRE4550WH F0448 Stacked Refractory Shown SuperiorFireplaces.us.com...
- Page 23 Refractory, Lt 50" Her White • Refractory, Rear 50 Her White • Refractory, Ash 50" Stk White • Retainer Assy., Ref. Corner • WRE4536WS WRE4542WS WRE4550WS CAT. NO. DESCRIPTION (F0438) (F0442) (F0446) QTY. 45 series White Stacked Refractory Set, 36"...
-
Page 24: Technical Service
TECHNICAL SERVICE REPLACEMENT PARTS You may have further questions about installation, operation, or See Pages 20 to 23 for a complete replacement parts list. Use only troubleshooting. Please contact your IHP dealer for any questions parts supplied from the manufacturer. or concerns a. -
Page 25: Accessories
ACCESSORIES CAT NO. MODEL DESCRIPTION BI-FOLD GLASS DOORS F1002 BDG36 GLASS DOOR, 36" BLACK F1005 BDG42 GLASS DOOR, 42" BLACK F1008 BD50 GLASS DOOR, 50" BLACK DOUBLE WALL PIPE F0932 12-12DM 12" Section Double Wall Pipe Snap Lock F0933 18-12DM 18"... - Page 26 ACCESSORIES Continued FIRESTOP SPACER F0940 FS-10 2" Clearance Firestop Spacer ROOF FLASHING F0942 V6F-10DM Roof Flashing 0 to 6/12 Pitch F0943 V12F-10DM Roof Flashing 6/12 to 12/12 Pitch SQUARE CHASE-TOP TERMINATION F0948 STL-12D Square Top Termination with Slip Section Square Top Termination with Slip Section (Pre-Painted F0949 STL-12DMP Black)
-
Page 27: Draft Smoke Guidelines
APPENDIX A Draft Requirements take into account all variables within the installation and install the appliance in such a manner that satisfies the draft requirements of Your wood-burning appliance is dependent upon a properly func- the appliance. See Chimney Guidelines to assist you in selecting the tioning chimney for optimum performance. - Page 28 APPENDIX A Continued Smoking – Causes And Troubleshooting Location Recommended To reduce the likelihood of smoking when opening the door, open Marginal Location the combustion air control or damper before opening the door. Wind Direction Your appliance has been designed and tested to provide smoke free Tree operation.
- Page 29 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 127017-01_H SuperiorFireplaces.us.com...
- Page 30 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ SuperiorFireplaces.us.com 127017-01_H...
-
Page 31: Warranty
Innovative Hearth Products Superior Brand Wood-Burning Fireplace ® 20 Year Limited Warranty THE WARRANTY Innovative Hearth Products ("IHP") 20 Year Limited Warranty warrants your Superior Brand wood burning fireplace ("Product") to be free from defects in materials and ® workmanship at the time of manufacture. The Product body, firebox and ceramic glass carry the 20 Year Limited Warranty. Ceramic glass carries the 20 Year Limited Warranty against thermal breakage only. - Page 32 SuperiorFireplaces.us.com Record the following important information about your fireplace: Fireplace model number Fireplace serial number Date fireplace was Installed Dealer name P127017-01 Innovative Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information.
