INSTALLATION INSTRUCTIONS
PACKAGED HEAT PUMP
Q24H2-A
Q30H2-A
Q24H2-B
Q30H2-B
Q24H2-C
Q30H2-C
Q-TEC SERIES
Models:
Q36H2-A
Q36H2-B
Q36H2-C
Bard Manufacturing Company, Inc.
Bryan, Ohio 43506
www.bardhvac.com
Q42H2-A
Q48H2-A
Q42H2-B
Q48H2-B
Q42H2-C
Q48H2-C
Manual No.:
Supersedes:
Date:
Q60H2-A
Q60H2-B
Q60H2-C
2100-601B
2100-601A
10-30-14
Page
1 of 42
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Bard Q24H2-A
Summary of Contents for Bard Q24H2-A
- Page 1 PACKAGED HEAT PUMP Models: Q24H2-A Q30H2-A Q36H2-A Q42H2-A Q48H2-A Q60H2-A Q24H2-B Q30H2-B Q36H2-B Q42H2-B Q48H2-B Q60H2-B Q24H2-C Q30H2-C Q36H2-C Q42H2-C Q48H2-C Q60H2-C Bard Manufacturing Company, Inc. Manual No.: 2100-601B Bryan, Ohio 43506 Supersedes: 2100-601A Date: 10-30-14 www.bardhvac.com Page 1 of 42...
-
