USER'S MANUAL AND OPERATING INSTRUCTIONS
For Manual
READ INSTRUCTIONS CAREFULLY:
Read and follow all instructions. Place
instructions in a safe place for future ref-
erence. Do not allow anyone who has
not read these instructions to assemble,
light, adjust or operate the heater.
PORTABLE PROPANE HEATER FOR
RECREATIONAL,
COMMERCIAL AND
EMERGENCY INDOOR USE
FOR US SALE EXCEPT
MASSACHUSETTS
Patent Pending
WARNING:
– Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
– An LP cylinder not connected for use shall not be stored in the vicinity of this or any other
appliance.
– WHAT TO DO IF YOU SMELL GAS
•
Do not try to light appliance.
•
Extinguish any open flame.
•
Shut off gas to appliance.
– Service must be performed by a qualified service agency.
This is an unvented gas-fired portable heater. It uses air (oxygen) from the area in which
it is used.
Adequate combustion and ventilation air must be provided. Refer to page 3.
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 877-447-4768 8:30 a.m. – 4:30 pm CST, Monday – Friday
XX-XX-XXX
Model #
HA1360RH
HA1360R
HA1360B
HA2360R
For Product
Registration
HA2360B
If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or
loss of life.
CONSUMER: Retain this manual for future reference.
or email us at customerservice@ghpgroupinc.com
www.ghpgroupinc.com
HEAT AROUND 360
RADIANT HEATER
CSA 4.98 US, GAS-FIRED PORTABLE HEATERS
FOR RECREATIONAL AND COMMERCIAL USE
1
US
Rev 03-06-2017
Advertisement
Related Manuals for Dyna-Glo HeatAround HA1360RH
Summary of Contents for Dyna-Glo HeatAround HA1360RH
- Page 1 HEAT AROUND 360 RADIANT HEATER USER'S MANUAL AND OPERATING INSTRUCTIONS Model # HA1360RH HA1360R HA1360B HA2360R For Product For Manual Registration HA2360B READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe place for future ref- erence. Do not allow anyone who has not read these instructions to assemble, light, adjust or operate the heater.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Service / Parts Ordering Information ..................1 General Safety Instructions ....................2 General Information ......................3 Operating with Disposable Propane Cylinders ..............3 Operating With Hose Connected to Remote Cylinder............4 Tank Installation Instructions ....................5 Lighting Operation Instructions....................6 Troubleshooting ........................6 Parts List ..........................6 Maintenance ........................8 Warranty..........................13 WARNING:... - Page 3 • NOTE: This HEATER MAY BE OPERATED WITH (1) OR (2) DISPOSABLE 1 LB. PROPANE CYLINDERS OR WITH (1) REMOTE REFILLABLE PROPANE CYLINDER MAX. 20 LBS USING BOTH (1) Dyna-Glo Model # EH12DG 12’ Extension Hose and (1) Dyna-Glo Model # HAFFDG Fuel Filter (Sold Separately) COLD WEATHER OPERATION: •...
-
Page 4: General Safety Instructions
CAUTION: SPECIFICATIONS •Some linoleum surfaces may discolor if heater is MODEL NO..HA1360RH / HA1360R / HA1360B / HA2360R / HA2360B placed directly on these floor coverings. GAS TYPE ..............PROPANE •When operating the heater at altitudes over 7,000 FT above sea INPUT BTU/HR. -
Page 5: Tank Installation Instructions
TANK INSTALLATION INSTRUCTIONS Tank Installation for DOT Certified 1 lb. Propane Cylinder(s) (Fig. 1) • Open easy access tank compartment door(s). • Locate regulator and swivel it upward by hand to provide better access for cylinder • Attach cylinder(s) to swivel mount by gently turning clockwise until it is hand tight. Do not overtighten. Do not use tools to tighten. •... -
Page 6: Lighting Operation Instructions
• Inspect the hose before each use of the heater. If there is excessive abrasion or wear, or the hose is cut, replace prior to using the heater with Dyna-Glo EH12DG. PILOT POSITION • The propane cylinder must include a listed overfilling protection device as well as a collar to protect the cylinder valve. - Page 7 North America. In 2016, GHP introduced the HeatAround360 and HeatAround360 Elite portable heaters into the market. These heaters, which are sold under the Dyna-Glo brand feature an Oxygen Depletion Sensor (“ODS”), which shuts off the heater if the oxygen in the room gets below a certain point and a tip-over safety switch that turns it off in the event of it being knocked on its side.
- Page 8 MAINTENANCE: Wire Guard Always keep the heater area clear and free from combustible materials, gasoline and other flammable vapors and liquids. Keep the vent areas (slots in the bottom and the top at the front Burner Assembly of heater) clear at all times so combustion is ventilation air is not Burner Orifice obstructed.
-
Page 9: Troubleshooting
TROUBLESHOOTING WARNING: If you smell gas: • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. •... - Page 10 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Burner backfiring 1. Burner orifice is clogged or 1. Clean burner orifice (see Care and during combustion. damaged. Maintenance, page 8 or contact customer service. 2. Burner is damaged. 2. Contact dealer or customer service. 3.
-
Page 11: Parts List
PARTS LIST ITEM HA1360RH HA1360R HA1360B DESCRIPTION HA10360-04 HA10360-04 HA10360-04 Wire Guard HA10360-GTA HA10360-GTA HA10360-GTA Gas Train Assembly TT15C-07 TT15C-07 TT15C-07 Tip Switch HA360-23 HA360-23 HA360-23 Control Knob HA10360-PBA-RD HA10360-PBA-RD HA10360-PBA-B Plastic Base Assembly HA10360-15-RD HA10360-15-RD HA10360-15-B Access Door HA10360-01 HA10360-01 HA10360-10 Burner Assembly... - Page 12 PARTS LIST ITEM HA2360R HA2360B DESCRIPTION HA18360-01 HA18360-01 Burner Assembly HA18360-GTA HA18360-GTA Gas Train Assembly HA360-HK HA360-HK Hardware Kit HA18360-04 HA18360-04 Wire Guard HA360-23 HA360-23 Control Knob HA18360-PBA-RD HA18360-PBA-B Plastic Base Assembly HA18360-15-RD HA18360-15-B Door TT15C-07 TT15C-07 Tip Switch HA18360-21 HA18360-21 Door Hinge, Upper HA18360-22...
-
Page 13: Maintenance
WARRANTY LIMITED WARRANTY: This limited warranty is extended to the original retail purchaser of this Forced Air/Convection/Radiant Heater and warrants against any defect in materials and workmanship for a period of one (1) year from the date of retail sale (lifetime warranty for the brass nozzle burner only). GHP Group, Inc., at it’s option, will either provide replacement parts or replace or repair the unit, when properly returned to the retailer where purchased or one of our service centers as directed by GHP Group, Inc., within one (1) year of retail purchase. - Page 14 WARRANTY REGISTRATION IMPORTANT: We urge you to fill out your warranty registration card within fourteen (14) days of date of purchase. You can also register your warranty on the internet at www.ghpgroupinc.com. Complete the entire serial number. Retain this portion of the card for your records.
