PROPANE CONSTRUCTION HEATER
USER'S MANUAL AND OPERATING INSTRUCTIONS
RA18LPDGP, RA18LPA, RA18LPB, and RA18LPC
&
CSA 2.14b-2009, ANS Z83.7b-2009
IMPORTANT: READ AND UNDERSTAND
THIS MANUAL BEFORE ASSEMBLING,
STARTING OR SERVICING HEATER.
IMPROPER USE OF HEATER CAN
CAUSE SERIOUS INJURY. KEEP THIS
MANUAL FOR FUTURE REFERENCE.
CALIFORNIA PROPOSITION 65 WARNING:
)XHOV XVHG LQ JDV RU RLO ¿UHG DSSOLDQFHV
DQG WKH SURGXFWV RI FRPEXVWLRQ RI VXFK
IXHOV FRQWDLQ FKHPLFDOV NQRZQ WR WKH
6WDWH RI &DOLIRUQLD WR FDXVH FDQFHU ELUWK
GHIHFWV RU RWKHU UHSURGXFWLYH KDUP 7KLV
SURGXFW FRQWDLQV FKHPLFDOV LQFOXGLQJ
OHDG DQG OHDG FRPSRXQGV NQRZQ WR WKH
VWDWH RI &DOLIRUQLD WR FDXVH FDQFHU ELUWK
GHIHFWV RU RWKHU UHSURGXFWLYH KDUP
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 877-447-4768 8:30 a.m. – 4:30 pm CST, Monday – Friday
20-10-090
MODEL # RA18LPDG, RA18LPDGD,
86
CONSUMER: Retain this manual for future reference.
or email us at customerservice@ghpgroupinc.com
Printed in China
1-877-475-5660
Dyna-Glo, Dyna-Glo Pro
Dyna-Glo Delux
GENERAL HAZARD WARNING:
FAILURE TO COMPLY WITH THE
PRECAUTIONS AND INSTRUCTIONS PROVIDED
WITH THIS HEATER, CAN RESULT IN DEATH,
SERIOUS BODILY INJURY AND PROPERTY
LOSS, OR DAMAGE FROM THE HAZARDS OF
FIRE, EXPLOSION, BURN. ASPHYXIATION,
CARBON MONOXIDE POISONING, AND/OR
ELECTRICAL SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND
FOLLOW THE INSTRUCTIONS SHOULD USE OR
SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER
INFORMATION SUCH AS AN INSTRUCTION
MANUAL, LABELS, ETCETERA, CONTACT THE
MANUFACTURER.
1-877-475-5660
Rev. 2011-01-10
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Dyna-Glo RA18LPDG
Summary of Contents for Dyna-Glo RA18LPDG
- Page 1 1-877-475-5660 Dyna-Glo, Dyna-Glo Pro Dyna-Glo Delux PROPANE CONSTRUCTION HEATER USER’S MANUAL AND OPERATING INSTRUCTIONS MODEL # RA18LPDG, RA18LPDGD, RA18LPDGP, RA18LPA, RA18LPB, and RA18LPC & CSA 2.14b-2009, ANS Z83.7b-2009 IMPORTANT: READ AND UNDERSTAND GENERAL HAZARD WARNING: THIS MANUAL BEFORE ASSEMBLING, FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED STARTING OR SERVICING HEATER.
-
