Deluxe vent-free universal fireboxe

Advertisement

Quick Links

DELUxE VENT-FREE
UNIVERSAL FIREbOxES
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING
FIRE OR ExPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Leave the building immediately.
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
GAS-FIRED
ANSI Z21.91
Ventless Fireplace
Enclosures
for Gas Fired
Decorative Type
Unvented Room
Heaters
UNIVERSAL FIREbOx
FOR ALL VENT-FREE
LOG SETS MODELS:
VFD32Fb0F- 4
VFD36Fb0F- 4
VFD32Fb0L- 4
VFD36Fb0L- 4
VFD32Fb2AF- 4
VFD36Fb2AF- 4
VFD32Fb2AL- 4
VFD36Fb2AL- 4
VFD32Fb2MF- 6
VFD36Fb2MF- 6
VFD32Fb2ML- 6
VFD36Fb2ML- 6
VFD00Fb3MF-4
VFD36Fb3MF- 6
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Refer to this manual. For
assistance or additional information, con-
sult a qualified installer, service agency or
the gas supplier.
FOR USE ONLY WITH A LISTED GAS-FIRED UNVENTED
DECORATIVE ROOM HEATER NOT TO ExCEED 40,000 bTU/H.
Do not build a wood fire.
Carefully review the instructions supplied with the decorative type
unvented room heater for the minimum fireplace size requirement.
Do not install A VENT-FREE LOG SET in this firebox, unless this
firebox meets the minimum dimensions required for the installation.
This appliance may be installed in an aftermarket, permanently located,
manufactured home (USA only) or mobile home, where not prohibited
by local codes. This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
Do not attempt to modify or alter the construction of the firebox or its
components. Any modification or alteration of construction may void
the warranty of this firebox. Children and adults should be alerted
to the hazards of high surface temperature and should stay away to
avoid burns or clothing ignition. Young children should be carefully
supervised when they are in the same room as the firebox.
VFD42Fb0F- 4
VFD42Fb0L- 4
VFD42Fb2AF- 4
VFD42Fb2AL- 4
VFD42Fb2MF- 6
VFD42Fb2ML- 6
VFD42Fb2ML-4
Page 1

Advertisement

Table of Contents
loading

Summary of Contents for Empire Comfort Systems VFD32FB0F-4

  • Page 1 INSTALLATION INSTRUCTIONS AND OWNER’S MANUAL DELUxE VENT-FREE UNIVERSAL FIREbOx UNIVERSAL FIREbOxES FOR ALL VENT-FREE LOG SETS MODELS: GAS-FIRED VFD32Fb0F- 4 VFD36Fb0F- 4 VFD42Fb0F- 4 VFD32Fb0L- 4 VFD36Fb0L- 4 VFD42Fb0L- 4 VFD32Fb2AF- 4 VFD36Fb2AF- 4 VFD42Fb2AF- 4 VFD32Fb2AL- 4 VFD36Fb2AL- 4 VFD42Fb2AL- 4 ANSI Z21.91 VFD32Fb2MF- 6...
  • Page 2: Table Of Contents

    TAbLE OF CONTENTS SECTION PAGE Important Safety Information ................... 3 Introduction ........................3 Clearances ......................... 4 - 5 Firebox Installation Instructions .................. 6 - 8 Installing Hood ......................8 - 9 Gas Line Connection ....................... 9 Optional FBB5 Single Speed Blower Installation Instructions ........ 10 - 12 Junction Box Wiring Installation Instructions ..............
  • Page 3: Important Safety Information

    It is imperative that control compartment, burners and circulating air passageways of the appliance be kept clean. This Empire Comfort Systems, Inc. firebox and its - Installation and/or use of any component part components have been tested and will operate safely...
  • Page 4: Clearances

    CLEARANCES COMBUSTIBLE Sidewall Clearances: The clearance from the inside of the firebox FINISHED WALL to perpendicular combustible side wall should not be less than 6 OR MANTEL inches. See Figure 1. 2 X 4 HEADER FINISHED WITH Firebox Side and back Clearances: The firebox outer casing side TRIM KIT OR and back flanges are zero clearance to combustibles. NON-COMBUSTIBLE MATERIAL Top Framing and Finishing: Combustible finishing materials requires 3/4 inch to top of unit.
  • Page 5 CLEARANCES Ceiling Clearances: The ceiling height should not be less than 42 inches from the top of the hood. See Figure 3. Mantel Clearances: Vent free firebox models must use the hood supplied with the firebox, or one of the optional hood kits available for each model. If a combustible mantel is installed, it must meet the clearance requirements detailed below. Grate Clearance: The minimum clearance between the front legs of the grate and front edge of the firebox is 2 inches.
  • Page 6: Firebox Installation Instructions

    FIREbOx INSTALLATION INSTRUCTIONS Any vent-free Gas Log Heater must be “For use with approved ANSI At this point, you should have decided what components to include Z21.11.2 unvented room heater.” in your installation, and where the firebox is to be located. If this has not been done, stop and consult your dealer for assistance Follow and complete the installation instructions of the gas log set with this planning.
  • Page 7 FIREbOx INSTALLATION INSTRUCTIONS OUTER FIREBOX DIMENSIONS DELUXE DELUXE LOUVERED FLUSH .5 inches INNER FIREBOX DIMENSIONS SIDE VIEW TOP VIEW OUTER FIREbOx DIMENSIONS (in inches) INNER FIREbOx DIMENSIONS (in inches) LOUVERED FLUSH INDEx INDEx VFD32 VFD36 VFD42 LETTER LETTER VFD32 VFD36 VFD42 VFD32 VFD36...
  • Page 8: Installing Hood

    FIREbOx INSTALLATION INSTRUCTIONS Locating Firebox Place firebox in framing opening. Use the tabs on the side of the firebox to attach firebox to framing. Different tab locations can be used for finishing materials with thicknesses of 1/2 inch and 5/8 inch. See Figure 8. Framing tabs should fit directly against framing material. Use at least one nail per bracket to secure in place. Check squareness of the firebox prior to securing to framed opening. See Figure 9. Figure 9 Figure 8 INSTALLING HOOD Flush Face Models A black hood that is furnished with each firebox (or optional hood) MUST be installed before the firebox is used. Failure to do so...
  • Page 9: Gas Line Connection

    INSTALLING HOOD Extended Hoods If your non-combustible facing material is over 1" in thickness that will be used to finish this firebox, an extended hood is available that will extend out 2" farther out into the room. Contact your local dealer for details. VB4H32BL Standard Black VB4H36BL Standard Black VB4H42BL Standard Black Finishing All joints (top, bottom and sides), where the wall or decorative facing material meets the firebox surround should be sealed with a non- combustible material. Hearth extensions are recommended, but not required for these fireboxes. GAS LINE CONNECTION The firebox is designed to accept a 3/8-inch gas line for an approved vent-free gas logset. Have the line installed by a qualified service person in accordance with all building codes. Consult local building codes to properly size the gas supply line leading to the 3/8-inch hook-up at the unit.
  • Page 10: Optional Fbb5 Single Speed Blower Installation Instructions

    OPTIONAL Fbb5 SINGLE SPEED bLOWER INSTALLATION INSTRUCTIONS A factory installed junction box is located on the lower right Attention: Install blower assembly before connecting gas inlet side of the firebox. Wiring must be fed to the junction box and supply line. attached to the receptacle that is provided. From right side of the firebox, remove the screw securing the junction box as- Wiring sembly.
  • Page 11 OPTIONAL Fbb5 SINGLE SPEED bLOWER INSTALLATION INSTRUCTIONS 4. Insert blower assembly into interior, bottom of firebox. Posi- 7. The fan control wires will slide down between the firebox and tion blower assembly so that you align the notch on back of outer wrap near the blower assembly. See Figure 16. blower assembly with the center screw on firebox back, then One fan control wire will have a 1/4 inch female terminal that push the blower assembly against firebox back. The blower must be attached to the open terminal on the blower motor.
  • Page 12 OPTIONAL Fbb5 SINGLE SPEED bLOWER INSTALLATION INSTRUCTIONS blower Motor 110 VOLT AC The blower motor does not have oiling holes. Do not attempt to oil JUNCTION BOX the blower motor. FAN/MOTOR blower Wheels ASSEMBLY The blower wheels will collect lint and could require periodic clean- ing.
  • Page 13: Junction Box Wiring Installation Instructions

    JUNCTION bOx WIRING INSTALLATION INSTRUCTIONS CAUTION All wiring should be done by a qualified electrician and shall be in compliance with all local, city and state building codes. before making the electrical connection, make sure that main power supply is disconnected. The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the national electrical code ansi/nfpa 70 (latest edition)
  • Page 14: Parts List

    PARTS LIST PART NUMbER INDEx DESCRIPTION VFD32 VFD36 VFD42 17169 18807 17187 UPPER LOUVER 17170 18808 17188 LOWER LOUVER 39520 39520 39520 JUNCTION BOX ASSEMBLY R3492 R3492 R3492 RECEPTACLE R3491 R3491 R3491 COVER, JUNCTION BOX 27338 27338 27338 BRACKET, TOP BRICK RETAINER (QUANTITY 2) 19401 19401 19401 BRACKET, BOTTOM BRICK RETAINER (QUANTITY 2) R10388 R10392 R10392 BRICK PANEL RIGHT - REFRACTORY BRICK 31675 31678...
  • Page 15: Parts View

    PARTS VIEW 39000-1-0219 Page 15...
  • Page 16: Accessories

    ACCESSORIES Accessory Description Model Numbers Fan Kit Designed to provide forced air flow. FBB5 Variable Speed Control Kit Wall mounted variable speed control for use SCV-1 with FBB5 blower brick Liners Contact dealer for all available Deluxe Firebox optional liner kits Fresh Air Kit Deluxe and Premium Fireboxes VFA2 Frame Kits 3-Piece Frame Kits...
  • Page 17 ACCESSORIES (CONT'D) Accessory Description Model Numbers Extended 4" Hoods Extended hoods that extend out 2" farther than the standard hoods, to accommodate thicker surround Contact dealer for all avail- materials. able optional hood acces- sories Available as optional kits in Brass, Hammered Pew- ter, and Stainless Steel finishes.
  • Page 18: Master Parts Distributor List

    This list changes from time to time. For the current list, please click on the Master Parts button at www.empirecomfort.com. Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Dey Distributing F.
  • Page 19: Warranty

    WARRANTY Empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the periods speci- fied below. Hearth products must be installed by a qualified technician and must be maintained and operated safely, in accordance with the instructions in the owner’s manual. This warranty applies to the original purchaser only and is not transferable. All warranty repairs must be accomplished by a qualified gas appliance technician.
  • Page 20 Empire Comfort Systems Inc. belleville, IL If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. www.empirecomfort.com Page 20 39000-1-0219...
