Page 1: Broadband Router
BR-XXXXXX Wired / Wireless Broadband Router Quick Installation Guide Version: 1.0(October, 2007) - Page 2 Č Č ý : Českého průvodce rychlou instalací naleznete na přiloženém CD s ý ovladači : Finden Sie bitte das deutsche S.A.L. beiliegend in der Treiber CD ñ l : Incluido en el CD el G.R.I. en Español. ñ ç : Veuillez trouver l’français G.I.R ci-joint dans le CD ç...
-
Page 3: Table Of Contents
3-1 Change management password ... 13 3-2 Firmware Upgrade... 14 3-3 System Reset... 15 3-4 Wireless Security (For Wireless Router Only) ... 16 3.5 Print Server(BR-6315SRg only) ... 17 3.6 Web / FTP Server(BR-6315SRg only) ... 18 3.7 iTunes Server(BR-6315SRg only)... 20 n ... - Page 4 Copyright© by Edimax Technology Co, LTD. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this Company .
-
Page 5: Product Introduction
Product Introduction You can configure the router by the Setup Wizard in the CD-ROM within the package . The wizard is an easy and quick configuration for internet connection, SSID, wireless security , firmware upgrade and router password change. When you start the Setup Wizard, you will get the following welcome screen. -
Page 6: Introduction
1 Introduction： 1-1 Package Contents Before you starting to use this router, please check if there’s anything missing in the package, and contact your dealer of purchase to claim for missing items： □ Broadband router (main body, 1 pcs) □ Quick installation guide (1 pcs) □... -
Page 7: Back Panel
LED of WLAN is flashing (around 10~26 seconds ) and the router will reset itself to the factory default settings (warning: your original configurations will be replaced with the factory... -
Page 8: E T W O R K S E T U P
Instructions for using the router to share the Internet with multiple PCs. (Power on the Modem and the Router.) Connect the Ethernet cable from the router’s WAN port to the LAN port of the modem. Connect another Ethernet cable from the any LAN ports (1~4) on router to the Ethernet socket on the PC. -
Page 9: Step 2 : P C L A N I P C O N F I G U R A T I O N
Configure the PC LAN setting to automatically obtain an IP address from the router by following below steps. Click “Start” in the task bar then select the “Control Panel” to open it. Click “Switch to Classic View” on the left top to see more setting icon…... - Page 10 Find an icon “Network Connection” then Double-Click to open the network connection setting. You will see an icon “Local Area Connection”, click the icon then Right-Click the mouse to open the sub-menu and select the “Properties” for setting the IP.
- Page 11 Select the “Internet Protocol (TCP/IP)” then click the “Properties” Ensure the parameter marked in blue are checked in “Obtain an IP address automatically” and “Obtain DNS server address automatically” then press “OK” to close.
-
Page 12: R O U T E R C O N F I G U R A T I O N - P P P O E
1. Enter the router’s default IP address: “192.168.2.1” into your PC’s web browser and press “enter”. 2. The login screen below will appear. Enter the “User Name” and “Password” and click “OK” to login. The default User name is “admin” and the Password is “1234”, Note: It’s highly recommended to change and save Router's log-in settings in... - Page 13 3. The main page will appear, click “Quick Setup” Following example is for “PPPoE” WAN setting. 4. Select ‘(GMT) Greenwich Mean Time: (your country or city) then Click “Next” button.
- Page 14 6. Enter the “User Name” and “Password” that ISP provided and leave the others. (The “Service Name” can be blank) and click “OK” to save the setting then reboot the router 7. After reboot, your router is now ready for Internet connection.
-
Page 15: R O U T E R C O N F I G U R A T I O N - C A B L E M O D E M
1. The following example is for U.K. Click on “Quick Setup”. 2. Select ‘(GMT) Greenwich Mean Time : “London”. Click “Next” button. - Page 16 The MAC Address is provided by ISP (e.g. NTL) or click “Clone Mac Address” button if you’re using the computer’s MAC Address. Confirm with your ISP about MAC Address used, Click “OK” button to save the settings then reboot the router. 5. After reboot, your router is now ready for Internet connection.
-
Page 17: Advanced Setup
3 Advanced Setup 3-1 Change management password Default password of this router is 1234, and it’s displayed on the login prompt when accessed from web browser. There’s a security risk if you don’t change the default password, since everyone can see it. -
Page 18: Firmware Upgrade
You can also use this firmware upgrade function to add new functions to your router, even fix the bugs of this router. To upgrade firmware, please follow the following instructions: Please click ‘Tool’... -
Page 19: System Reset
3-3 System Reset If you think the network performance is bad, or you found the behavior of the router is strange, you can perform a router reset, sometime it will solve the problem. To do so, please click ‘Tool’ located at the upper-right corner of web management interface, then click ‘Reset’... -
Page 20: Wireless Security (For Wireless Router Only)
Please select an encryption method from ‘Encryption’ dropdown menu, there are four options. And we will inform you about WPA function. When you select this mode, the wireless router will use WPA encryption, and the following setup menu will be shown on your web browser: Here are descriptions of every setup items：... -
Page 21: Print Server(Br-6315Srg Only)
Please click ‘Continue’ to back to previous setup menu; to continue on other setup procedures, or click ‘Apply’ to reboot the router so the settings will take effect (Please wait for about 50 seconds while router is rebooting). NOTE: Some wireless clients (especially those manufactured before year 2003) only support WEP or WPA (TKIA) cipher. -
Page 22: Web / Ftp Server(Br-6315Srg Only)
Click <Apply> at the bottom of the screen to save the configurations. You can now configure other advance sections or start using the router. About the detail setting , please read the user manual in the CD ROM . - Page 23 Parameters Users setup You can add/edit users of File/FTP server. You can add/edit the name of file server, shared folders and File Server setup sharing policies of files that will be shared via Network Neighborhood. You can add/edit FTP folders and configure some advanced FTP Server setup settings for FTP server.
-
Page 24: Itunes Server(Br-6315Srg Only)
If the USB mass storage device you attached to this broadband router is loaded with media files supported by iTunes, you can use the iTunes server function of this... - Page 25 Click this button to get latest information of iTunes server and Refresh users listed above. You can now click “Advanced Setting” to configure other advance sections or start using the router. After you click “Advanced Setting”, you’ll be prompted to specify the advanced settings of this iTunes server:...
- Page 26 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
