- Page 1 Mobile HDD 5400 RPM - SATA Product Manual Standard models SED (FIPS 140-2) models ST2000LM007 ST2000LM010 ST1500LM012 ST1000LM038 ST1000LM035 ST500LM033 ST500LM030 Self-Encrypting Drive models ST500LM032 100850135, Rev. A February 2019...
- Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. SeaTools and 3D Defense System are either a trademark or registered trademark of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 S.M.A.R.T. commands ............... . 40 Seagate Mobile HDD Product Manual, Rev. A...
- Page 5 Example of FIPS tamper evidence labels..............29 Seagate Mobile HDD Product Manual, Rev. A...
-
Page 6: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate Mobile HDD Product Manual, Rev. A... -
Page 7: Introduction
Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate® Mobile HDD model drives: Standard Standard SED Standard SED models models (FIPS 140-2) models ST2000LM007 ST2000LM010 ST1500LM012 ST1000LM035 ST1000LM038 ST500LM030 ST500LM032 ST500LM033 Previous generations of Seagate Self-Encrypting Drive models were called Full Disk Encryption (FDE) models Note before a differentiation between drive-based encryption and other forms of encryption was necessary. -
Page 8: About The Serial Ata Interface
Register Block. All Serial ATA devices behave like Device 0 devices. For additional information about how Serial ATA emulates parallel ATA, refer to the Serial ATA International Organization: Serial ATA (Revision 2.6). The specification can be downloaded from www.serialata.org. Seagate Mobile HDD Product Manual, Rev. A... -
Page 9: Drive Specifications
Wet bulb temperature 40.0°C max (non-operating) Altitude, operating –304.8 m to 3048 m (–1000 ft to 10,000+ ft) Altitude, non-operating –304.8 m to 12,192 m (–1000 ft to 40,000+ ft) (below mean sea level, max) Seagate Mobile HDD Product Manual, Rev. A... - Page 10 Accessible capacity may vary depending on operating environment and formatting. If the drive is powered-off before issuing flush cache command, in some instances, Note the end user data in the DRAM cache might not be committed to the disk. Seagate Mobile HDD Product Manual, Rev. A...
- Page 11 –304.8 m to 12,192 m (–1000 ft to 40,000+ ft) (below mean sea level, max) Operational Shock 400 Gs at 2 ms max Non-Operational Shock 1000 Gs at 1 ms max 5–200 Hz: 2.0 Gs Vibration, operating 201–500 Hz: 1.0 Gs Seagate Mobile HDD Product Manual, Rev. A...
-
Page 12: Formatted Capacity
When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the number of guaranteed sectors as defined above. Refer to Configuring and Mounting the Drive on page 24 (words 60-61 and 100-103) for additional information about 48-bit addressing support of drives with capacities over 137 GB. Seagate Mobile HDD Product Manual, Rev. A... -
Page 13: Physical Organization
(such as track-to-track and average), are expected to meet the noted values. However, due Note to the manner in which these drives are formatted, benchmark tests that include command overhead or measure logical seeks may produce results that vary from these specifications. Seagate Mobile HDD Product Manual, Rev. A... -
Page 14: Start/Stop Times
+5V input average (25° C) Spinup (max) 1.00A Write average 1.70W 1.80W Read average 1.60W 1.70W Idle, low power mode 0.45W 0.50W Standby 0.13W Sleep 0.13W Standby power is measured at steady state (after 200ms from transition) Seagate Mobile HDD Product Manual, Rev. A... -
Page 15: Figure 1 Typical 1D - 5V Startup And Operation Current Profile
Drive Specifications 2.7.1.1 Typical current profiles The typical 5V startup and operation current profile is shown in Figure 1 Figure Figure 1 Typical 1D - 5V Startup and Operation Current Profile Seagate Mobile HDD Product Manual, Rev. A... -
Page 16: Figure 2 Typical 2D - 5V Startup And Operation Current Profile
Drive Specifications Figure 2 Typical 2D - 5V Startup and Operation Current Profile Seagate Mobile HDD Product Manual, Rev. A... -
Page 17: Conducted Noise
If the standby timer reaches zero before any drive activity is required, the drive makes a transition to standby mode. In both Idle and standby mode, the drive accepts all commands and returns to active mode when disk access is necessary. Seagate Mobile HDD Product Manual, Rev. A... -
Page 18: Environmental Specifications
-304.8m to 12,192m Altitude (-1000ft to 10,000ft) (-1000ft to 40,000ft) Seagate does not recommend operating at sustained case temperatures above 60°C. Note Operating at higher temperatures will reduce useful life of the product. The recommended storage period: • 1 year under controlled conditions of 34°C 90%RH or less Note •... -
Page 19: Vibration
Test for prominent discrete tones (PDTs) Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses the lower limit for the threshold curve* to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 20: Electromagnetic Immunity
Testing to be done with magnet .375” dia. x 0.100” Ni-plated NdFeB; B,~11.5 kG, magnetized along its length; the magnet is oriented with the length perpendicular to the drive cover/PCBA. Drive to be properly secured during test. Seagate Mobile HDD Product Manual, Rev. A... -
Page 21: Reliability
Seagate drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with all relevant regulatory requirements and standards for the drives, Seagate cannot guarantee that all system-level products into which the drives are installed comply with all regulatory requirements and standards applicable to the system-level products. The drive is designed for operation inside a properly designed system (e.g., enclosure designed for the drive), with properly shielded I/O cable (if... -
Page 22: Canada Ices-003
2.12.6 Morocco Commodity Mark To satisfy our OEM customers, Seagate has added the Moroccan Commodity Mark to the drives provided to the OEM for the sale of Customer Kits produced by our OEM customers that are intended to be incorporated into the OEM's finished system-level product by an end user. -
Page 23: Environmental Protection
2.13.1.1 Restriction of Hazardous Substances in Electrical and Electronic Equipment Seagate drives are designed to be compliant with the European Union RoHS "Recast" Directive 2011/65/EU (RoHS 2) as amended by Directive (EU) 2015/863. The RoHS2 restricts the use of certain hazardous substances such as Lead, Cadmium, Mercury, Hexavalent Chromium, Polybrominated Biphenyls (PBB) and Polybrominated Diphenyl Ether (PBDE), BisBis(2-Ethylhexyl) phthalate (DEHP), Benzyl butyl phthalate (BBP), Dibutyl phthalate (DBP), and Diisobutyl phthalate (DIBP) in electrical and electronic equipment (EEE). -
Page 24: Taiwan Requirements - Taiwan Rohs
Users should use caution exposing any electronic components to uncontrolled chemical pollutants and corrosive chemicals as electronic drive component reliability can be affected by the installation environment. The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. -
Page 25: Configuring And Mounting The Drive
For installations which require cables, users can connect the drive as shown in Figure Figure 3 Attaching SATA Cabling Signal connector Power connector Signal cable Power cable Each cable is keyed to ensure correct orientation. Seagate Mobile HDD Product Manual, Rev. A... -
Page 26: Drive Grounding
1, 2, 3, and 4. • Do NOT use sides A1, A2 or A3 for grounding purposes. • If less than four screws are used, at least one mounting screw is required for proper grounding. Seagate Mobile HDD Product Manual, Rev. A... -
Page 27: Drive Mounting
4MM MIN. SCREW DEPTH FROM BOTH SIDES M3 PADS. NO THRU. 3.5+.075-.3X90 RECOMMENDED TEMPERATURE MEASUREMENT LOCATION (13.430) 4 X M3 X 0.5-6H (3.500) 2.5MM MIN FULL THREAD. NO THRU 3.5 +.075 -.3 X90 Seagate Mobile HDD Product Manual, Rev. A... -
Page 28: Figure 7 Mounting Dimensions (For 1-Disk Models) (Alternate Basedeck)
4MM MIN. SCREW DEPTH FROM BOTH SIDES M3 PADS. NO THRU. 3.5+.075-.3X90 RECOMMENDED TEMPERATURE MEASUREMENT LOCATION (13.430) 4 X M3 X 0.5-6H (3.500) 2.5MM MIN FULL THREAD. NO THRU 3.5 +.075 -.3 X90 Seagate Mobile HDD Product Manual, Rev. A... - Page 29 2X (3.000) BOTH SIDES 7.000 0.200 FROM M3 PADS. NO THRU 3.5 +.075 -.3 X90 RECOMMENDED TEMPERATURE MEASUREMENT LOCATION 4 X M3 X 0.5-6H 2.5MM MIN FULL THREAD. NO THRU 3.5 +.075 -.3 X90 Seagate Mobile HDD Product Manual, Rev. A...
-
Page 30: About Fips
Figure 9 Example of FIPS tamper evidence labels. For reference only. May not represent actual drive. Note Seagate Mobile HDD Product Manual, Rev. A... -
Page 31: About (Sed) Self-Encrypting Drives
The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the computer, storage and digital communications industry. Seagate's SED models comply with the standards published by the TCG. To use the security features in the drive, the host must be capable of constructing and issuing the following two SATA commands: •... -
Page 32: Random Number Generator (Rng)
In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: 1. -
Page 33: Serial Ata (Sata) Interface
There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate backplane configuration. All used voltage pins (V ) must be terminated. Seagate Mobile HDD Product Manual, Rev. A... -
Page 34: Supported Ata Commands
Set Max Features Password: register as defined to the right. Lock: Unlock: Freeze Lock: Set Max Address Ext Set Multiple Mode S.M.A.R.T. Disable Operations B0h/D9h S.M.A.R.T. Enable/Disable Autosave B0h/D2h S.M.A.R.T. Enable Operations B0h/D8h Seagate Mobile HDD Product Manual, Rev. A... - Page 35 ATA-standard power-management commands Check Power Mode Idle Idle Immediate Sleep Standby Standby Immediate ATA-standard security commands Security Set Password Security Unlock Security Erase Prepare Security Erase Unit Security Freeze Lock Security Disable Password Seagate Mobile HDD Product Manual, Rev. A...
-
Page 36: Identify Device Command
Number of current logical heads xxxx Number of current logical sectors per logical track xxxx 57–58 Current capacity in sectors xxxx Number of sectors transferred during a Read Multiple or Write Multiple command xxxx Seagate Mobile HDD Product Manual, Rev. A... - Page 37 Hardware reset value (see description following this table) xxxx Auto acoustic management setting xxxx Stream Min. Request Size 0000 Streaming Transfer Time - DMA 0000 Streaming Access Latency - DMA and PIO 0000 Seagate Mobile HDD Product Manual, Rev. A...
- Page 38 ATA-reserved 0000 Transport major version number 101F 223–254 ATA-reserved 0000 Integrity word xxA5 See the bit descriptions below for words 63, 88 and 93 of the Identify Drive data. (on next page) Note Seagate Mobile HDD Product Manual, Rev. A...
- Page 39 Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Word 93 1 = 80-conductor cable detected, CBLID above VIH 0 = 40-conductor cable detected, CBLID below VIL Seagate Mobile HDD Product Manual, Rev. A...
-
Page 40: Set Features Command
Disable the Free Fall Protection feature (41 above enables the Free Fall Protection feature) Report full capacity available At power-on, or after a hardware or software reset, the default values of the features are as indicated above Note Seagate Mobile HDD Product Manual, Rev. A... -
Page 41: Commands
S.M.A.R.T. Enable Operations S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x 04 (abort) is written to the Error register. Seagate Mobile HDD Product Manual, Rev. A... - Page 42 AMERICAS Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 90 Woodlands Avenue 7, Singapore 737911, 65-6412-3666 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology (Netherlands) B.V. Koolhovenlaan 1, 1119 NB Schiphol-Rijk, Netherlands, 31-20-316-7300 Publication Number: 100850135, Rev. A...
