Sony PCG-GR150K Marketing Specifications

FEATURES
• Mobile Intel ® Pentium ® III processor 866MHz-M
featuring Enhanced SpeedStep
• Hot-swappable 12 multi-bay for internal
removable CD-RW/DVD combo drive or optional
additional battery
• Integrated 10Base-T/100Base-TX Ethernet
™ ®
• MagicGate Memory Stick
• 14.1" XGA TFT screen with dual display
• 128 MB SDRAM (expandable to 512 MB max.)
4
• Removable 20 GB hard drive
• AGP-enabled ATI RAGE ™ Mobility RADEON
graphics chip with 3D acceleration support
2
• 133 MHz front side bus
• 8 MB video DDRAM
™
• center Jog Dial control with back button!
• High-capacity lithium-ion battery, dual battery capability
• i.LINK ® (IEEE 1394) S400 interface
high-speed digital video, audio, and data transfer
capabilities among equipped Sony products
• Optional port replicator available for increased
connectivity!
• Integrated V.90 modem
• Extended life battery!
®
• Choice of Microsoft Windows
or Microsoft ® Windows ® 2000 Professional
7
• About 6 lbs. light, 1.4" thin
• 512K byte level two cache (on die)
• One or two type II or one type III PC card, with
CardBus support
• Built-in stereo speakers
1 Optional.
2 MHz denotes microprocessor internal clock speed; other factors may affect application performance.
3 The processor may be reduced to a lower operating speed when operating on battery power.
4 GB means one billion bytes when referring to hard drive capacity. Accessible capacity may vary.
5 With one battery and weight saver in multi-bay.
6 i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394
connector. All products with an i.LINK connector may not communicate with each other.
7 Estimated battery life. Actual battery life may vary on usage.
8 Certain restrictions apply to Express Repair Service.
9 From date of purchase upon registration.
10 Requires payment of additional fees or subscription for use.
11 Available with Microsoft® Windows® Millennium Edition only.
12 Available on GR150K only.
Web address: http://www.sony.com/vaio
Computer Interface: The computer industry lacks standards, and therefore, there are a multitude
of varying software packages and add-on hardware options. This personal computer is not
manufactured to any specific software, and Sony does not and cannot make any warranty or
representation with respect to the performance of this product with any particular software
packages and/or non-Sony add-on hardware option except those mentioned in this document.
Sony hereby disclaims any representations or warranty that this product is compatible with any
combination of products you may choose to connect. While Sony representatives or Sony
authorized dealers may be able to assist you and may make recommendations, they are NOT
authorized to vary or waive this disclaimer. Purchasers must determine for themselves the
suitability and compatibility of the hardware and software in each and every particular instance.
Some pre-installed software titles may not include full documentation. Software titles pre-
installed on the Sony Notebook Computer are subject to change without notice. Simulated
graphic shown on display.
©2001 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written
permission is prohibited. Sony, i.LINK, VAIO and Memory Stick are registered trademarks of Sony.
DVgate, Jog Dial, PictureGear, MagicGate, MovieShaker, OpenMG and VisualFlow are trademarks of
Sony. Intel and Pentium are registered trademarks and SpeedStep is a trademark of Intel
Corporation. Microsoft and Windows are registered trademarks of Microsoft Corporation.
RealNetworks, RealPlayer, and RealJukebox are registered trademarks of RealNetworks, Inc. All
other trademarks are trademarks of their respective owners. This product meets the standards of
the International Energy Star Program for energy efficiency. Features and specifications are subject
to change without notice. Non-metric weights and measurements are approximate.
Printed in U.S.A. 06/01

SPECIFICATIONS

Models
PCG-GR150 and PCG-GR150K
Processor
2
Mobile Intel
™ 3
technology
featuring Enhanced SpeedStep
Cache Memory
512 KB integrated on-die level 2
Bus Speed
133 MHz
Bus Architecture
media slot
AGP / PCI
11
LCD
14.1" XGA (1024x768) TFT
Dual display
Graphics
™ -M
ATI RAGE
8 MB video DDRAM
3D acceleration support
Audio
Windows
MPEG
MPEG1 and MPEG2 digital video
6 supports
Supports full screen playback
Standard RAM
128 MB SDRAM (128x1), expandable to 512 MB
Open RAM Slot
1:SO DIMM
Hard Drive
Removable 20 GB
CD-RW/DVD Combo Drive
®
Millennium Edition
Internal removable CD-RW/DVD combo drive
Floppy Drive
External 1.44 MB, 3.5" USB floppy disk drive
Memory Stick
Supports MagicGate
Hot-Swappable
• CD-RW/DVD combo drive
• Second battery
Modem
Integrated V.90 modem
Ethernet
10Base-T/100Base-TX Ethernet with RJ-45 interface
Keyboard
83 key QWERTY layout
19mm key pitch
3mm stroke
Pointing Device
center Jog Dial
Electro-Static touch pad
Microphone
Monoral mini-jack
Battery
Lithium-ion battery
Supports dual battery operation
Battery Life
2.0 - 3.0 hours with one battery
4.0 - 6.0 hours with optional second battery
PC Card Slots
Supports two type II cards or one type III card
CardBus support
Other Interfaces
i.LINK
jack, RJ-45 Ethernet, Memory Stick
output monitor, parallel, headphone (stereo), mic-in,
port replicator
• Hot-swappable
combo drive or optional second battery!
• Mobile Intel Pentium
featuring Enhanced SpeedStep
• 128 MB SDRAM and 20 GB
• Integrated 10/100 Base-T Ethernet
• MagicGate
™
® Pentium ® III processor 866MHz-M
™ 3
technology
11
™ ™
Mobility RADEON -M graphics chip
®
sound system compatible with 3D surround
4
1
® Media Slot
™ ® 1
Memory Stick media
12 Multi-Bay supports:
1
™
control with back button
7
7
® 6
(IEEE 1394) interface , USB (3), RJ-11 modem
®
media slot, VGA
PCG-GR150
PCG-GR150K
multi-bay supports CD-RW/DVD
12
III processor 866MHz-M
®
technology
™
hard drive
4
Memory Stick media slot
®
1
Port Replicator
DC in, PS/2 ® keyboard and mouse, USB(2), serial,
parallel, VGA output monitor, S-video, RJ-45, NTSC
VIDEO out, line-in, docking CN
2
Power Requirements
80 watts maximum (16V / AC100-240V)
Power Management
Energy Star compliant
Advanced power management - APM-ACPI compatible
Size (H x W x D)
1.4" X 12.3" X 10.3"
Weight
5.6 lbs. 5
Supplied Accessories
Lithium-ion battery, power cord, AC adapter,
and weight saver
Optional Accessories
Port Replicator (PCGA-PRGR1)
Additional battery (PCGA-BP2E)
USB mouse (PCGA-UMS1/A)
Carrying case (PCGA-CCF)
Additional AC adapter (PCGA-AC16V)
Wireless LAN Access Point & PC Card (PCWA-A100)
Wireless LAN PC Card (PCWA-C100)
External USB Floppy Disk Drive (PCGA-UFD5)
Service
One year limited Express Service
Limited Warranty
One year parts and labor (90 days without registration)
Telephone Support
Hardware: One year 9
Software and operating system: 90 days
INCLUDED SOFTWARE
Operating System
GR150: Microsoft ® Windows
GR150K: Microsoft ® Windows
Software Applications
®
Adobe Photoshop Elements
® 11
Adobe Premiere LE
Adaptec Easy CD ™ Creator
Microsoft ® Word 2002
Norton AntiVirus ™
Quicken ® 2001
QuickTime ™
RealNetworks ® RealJukebox
RealNetworks ® RealPlayer ®
™
Sony DVgate
™ 11
Sony OpenMG Jukebox
™
Sony MovieShaker
Sony PictureGear ™
Sony Smart Capture
Sony VisualFlow ™ 11
VAIO ® Support Agent
WinDVD ® 2000
Online Center
America Online ® 10
Compuserve ® 2000 10
EarthLink Network TotalAccess
Microsoft ® Internet Explorer
Netscape Communicator ®
Prodigy Internet ® 10
VAIO Support Agent
2
3
8
9
9
® Millennium Edition
® 2000 Professional
11
® 2 Basic
8 Basic
® 10
