Welcome Congratulations on your purchase of this Sony VAIO This user guide provides detailed information on all aspects of using your new VAIO computer, from keyboard functions to preinstalled software programs. In the left navigation window, click the topics you want to learn more about, and that information will be displayed in this main window.
Powering Your Computer Your VAIO computer comes with a battery and an AC adapter. This chapter explains how to install and use these supplied ® accessories to power your computer. It also describes ways you can efficiently utilize the battery as a power source. ...
Using AC Power The supplied battery is not charged when you receive your computer. To use your computer immediately, use the supplied AC adapter as the power source. While the computer uses AC power, it automatically charges the battery if it is inserted. Using the Battery for more information on installing and using your battery.
Page 4
Connecting the AC adapter To connect the AC adapter Plug the cable attached to the AC adapter into the DC IN port on your computer or docking station. Connecting the AC Adapter to the Com puter Plug one end of the power cord into the AC adapter, and plug the other end into an AC outlet. Use only the AC adapter supplied with your computer.
Page 5
Turning on the computer To turn on the computer Slide the release lever to the right, and lift the cover while holding the bottom of the computer firmly. Opening the Com puter Press the power button until the power indicator turns on. Turning on the Com puter If you hold the power button down, the computer turns off.
Using the Battery A battery is an auxiliary power source you can use when your computer is not plugged into an AC outlet. Your computer may come equipped with one or two battery bays, depending on the model you purchased. If your computer comes with two battery bays, you can purchase a second rechargeable battery to extend your computing time.
Page 7
Inserting a battery The battery that comes with your computer is not fully charged at the time of purchase. To insert a battery Push the battery bay cover down to open it. The battery bay cover swings out but does not detach from the computer.
Page 8
Removing a battery If you are not using the computer for an extended period of time, remove the battery from the computer to avoid damaging the battery. You can remove the battery when the computer is on or off. If the computer is on, connect the AC adapter and exit a power saving mode before you remove the battery. To remove a battery Push the battery bay cover down to open it.
Page 9
Using a second battery To insert a second battery If another device is in the multipurpose bay, remove that device. Insert the battery into the multipurpose bay. When the computer uses the second battery, the Battery 2 indicator turns on. Inserting the Second Battery Slide the weight saver in the direction of the arrow until it clicks into place.
Page 10
Pull the weight saver and battery gently from the multipurpose bay. Insert the weight saver into the multipurpose bay to protect the bay. See "Using the Weight Saver" for more information. Page 10...
Page 11
Displaying battery information You can display the remaining battery charge on the Battery Information toolbar and/or the Battery Information window. To display the Battery Information toolbar Right-click the center of the Windows Select Toolbars from the shortcut menu, and click Battery Information. The Battery Information toolbar appears on the taskbar.
Page 12
change your computer's alarm settings from this window. Click Help in the lower right corner of the window for more information. The battery icons that appear on the Battery Information toolbar and the Battery Information window indicate the current status of the installed battery. Battery icon Battery status Charging...
Page 13
Charging a battery You will need to charge the battery if battery power drops below 10 percent or you have not used the battery for a considerable amount of time. The lithium-ion battery supplied with your computer may be recharged at any time, whether you wait until the battery is completely or partially discharged.
Page 14
Notes on batteries Never leave the battery in temperatures above 140°F (60°C), such as under direct sunlight or in a car parked in the sun. While the battery is in use or being discharged, the battery heats up. This is normal and is not cause for concern. ...
Page 15
Frequently asked questions How do I know when the battery is charged? To determine the remaining battery charge, see When is the computer using AC power? When the computer is directly connected to the AC adapter, it uses AC power, even if a battery is installed. When should I recharge the battery? ...
Conserving Battery Power You may use the power saving modes and PowerPanel or power schemes to conserve battery power. Conserving battery power may significantly extend your computing time, depending on how you use your computer. Using power saving modes ...
Page 17
Using power saving modes In addition to the normal operating mode, which allows you to turn off specific devices, your computer has two distinct power saving modes: Standby and Hibernate. You can use the Standby and Hibernate power saving modes to override a profile setting or initiate an immediate action.
Page 18
Using PowerPanel The PowerPanel utility enables you to select and customize a predefined power management profile to conserve battery life. The following table describes all the predefined power management profiles in PowerPanel. Your computer is set to Automatic Profile Selection by default. You can customize the settings for all the following profiles, except the Disable Power Management profile.
Page 19
When you use the battery to power your computer, your system automatically selects the Maximum Battery Life power management profile by default. If you select a different power management profile while using battery power, that profile is selected automatically the next time you use the battery to power your computer. See PowerPanel Help for information on customizing the power management profiles.
Page 20
Frequently asked questions Can my computer enter Hibernate mode while using battery power? Your computer can enter Hibernate mode while using battery power, but some software programs and peripheral devices prevent the system from entering Hibernate mode at all. If you are using a program that prevents the system from entering Hibernate mode, save your data frequently.
Connection Wizard guides you through the process of connecting to the Internet and choosing an Internet service provider (ISP) or setting up an existing account. When you connect to the Internet, you can register your VAIO services, and gain access to Sony Computing Support. ...
Page 23
Setting up a dial-up Internet connection Before you can connect to the Internet, you need to connect your computer to a telephone line via a telephone cable (not supplied). Once you have set up your telephone cable, you're ready to connect to the Internet. To connect a telephone cable Locate the Modem jack on your computer.
Page 24
Setting up an Ethernet Internet connection Your computer accommodates both 10BASE-T and 100BASE-TX Ethernet connections, with data transfer speeds of between 10 and 100 Mbps, depending on the line conditions and Ethernet cable. To connect an Ethernet cable Locate the Ethernet port on your computer. For location information, see Locating Controls and Ports in the Setting Up chapter of your printed VAIO Connecting an Ethernet Cable Plug one end of the Ethernet cable into your computer's Ethernet port...
Page 25
Customizing your Internet connection The Internet Properties dialog box enables you to change the way you view the Internet. You can change your home page, fonts, language, and colors. You can also regulate content and set your browsing preferences. To open the Internet Properties dialog box Click Start on the Windows ®...
Page 26
Make sure the telephone number the program is dialing is correct. Make sure the software you are using is compatible with the computer's modem. (All preinstalled Sony programs are compatible.) If you are still experiencing problems, use the supplied Application Recovery CD(s) to reinstall the modem driver software.
Network Connections With a Sony computer, you can easily set up or connect to a variety of networks. The New Connection Wizard and Network Setup Wizard make it easy to gain access to remote and local area networks (LANs) using wireless, Ethernet, or dial-up connections.
Page 28
Using Ethernet and dial-up connections Local area networks (LANs) comprise a group of computers and associated devices within a small geographic area, such as a home or office building. For setting up LANs, Ethernet is a widely installed technology. Your computer accommodates both 10BASE-T and 100BASE-TX Ethernet connections, with data transfer speeds of between 10 and 100 Mbps, depending on the Ethernet cable.
Page 29
You can connect to your company network from a remote location and use data, programs, and network resources. See Microsoft Windows Help by clicking Help and Support from the Start menu, and then clicking Networking and the Web in ® ®...
Page 30
A wireless local area network (LAN) is a network in which you can connect to a LAN through a wireless (radio) connection. You can opt to purchase a Sony Wireless LAN Access Point to set up a LAN. The wireless LAN access point is designed for building a wireless LAN environment. Because a wireless LAN configuration requires no wiring, you can operate multiple computers more freely than ever before.
Page 31
information. Click Connect. To set up a wireless network Insert a Wireless LAN PC Card into the PC Card slot. See The Wireless LAN indicator lights up. From the Start menu, click Control Panel, Network and Internet Connections, and then click Network Connections.
Page 32
Type up to 32 ASCII characters in the Network name (SSID) box. Click to select the Data encryption (WEP enabled) check box. Click to select the Network Authentication (Shared mode) check box. Click to cancel the The key is provided for me automatically check box. Type between 5 to 13 ASCII characters or 10 to 26 hexadecimal characters in the Network key box.
Page 33
Checking your network connection status Whether you have a wireless, Ethernet, or dial-up connection, you can check the status of that connection by double-clicking the Wireless Network Connection icon on your taskbar. The Wireless Network Connection Status window appears. Wireless Network Connection Status Window Page 33...
Page 34
Frequently asked questions Why can't my computer connect to a wireless LAN access point? Connection availability is affected by distance and obstructions. You may need to move your computer away from obstructions or closer to any access point you may be using. ...
Page 35
Wireless LAN communication occurs on divided frequency bands known as channels. Third-party wireless LAN access point channels may be preset to different channels from Sony devices. If you are using a wireless LAN access point, refer to connectivity information contained in your access point instructions.
N K is a trademark of Sony us ed to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 37
Connecting VAIO computers When you connect two VAIO computers, you can use one computer to edit, copy, or delete files on the other computer. You can also print from a printer attached to either computer. To connect VAIO computers Plug one end of the i.LINK cable into the i.LINK port Click Start on the Windows ®...
Page 38
* T he c omputers s hown in this graphic are for illus tration purpos es and may not res emble your c omputer. Page 38...
Page 39
Disconnecting VAIO computers You can disconnect two VAIO computers when the computers are on or off. To disconnect VAIO computers when the computers are on Close all open files that are shared with the connected computers. Unplug the i.LINK cable from the i.LINK port on each computer. To disconnect VAIO computer when the computers are off ...
Inserting and Ejecting CDs or DVDs Avoid using adhesive labels to identify your CDs or DVDs. Adhesive labels may damage the optical drive if they come off while the disc is in the drive. To insert a CD or DVD Turn on the computer or exit a power saving mode (Standby or Hibernate) if one is active.
Page 43
into the manual eject hole next to the Eject button. Lift the disc from the drive. Push the drive tray gently to close it. Page 43...
Copying and Playing CDs Your optical drive can read CDs and DVDs. The type of optical drive installed in or connected to your computer may vary, depending on the model you purchased. If you are using a CD-RW/DVD Combo Drive, you can write data to CD-Rs and CD-RWs.
Page 45
Playing CDs Before you play an audio CD, you may need to enable your computer's audio feature. To enable the audio feature Click Start on the Windows ® System Properties window appears. Select the Hardware tab, and click Device Manager in the Device Manager box. A window with a listing of the computer's hardware devices appears.
Page 46
Connect and use the AC adapter to power your computer. Use CD-Rs that are compatible with 16x speed. Insert the disc into the optical drive, and open the preinstalled Sony SonicStage Programs, and then SonicStage. For instructions on how to use SonicStage software, follow these steps: Click Start, and then Help and Support.
Playing DVDs You can play DVDs in your computer's optical drive and view the video on a TV. The type of optical drive installed in or connected to your computer may vary, depending on the model you purchased. Connecting your computer to a TV ...
Page 48
Connecting your computer to a TV In order to connect your computer to a TV, your computer must have an A/V OUT jack. Not all VAIO with an A/V OUT jack. To see if your computer has an A/V OUT jack, check "Locating Controls and Ports" in the Setting Up chapter of your printed online VAIO To connect a TV to your computer Turn off the computer.
Page 49
Watching DVDs on a TV Do not remove the optical drive when the computer is in a power saving mode (Standby or Hibernate). Doing so may cause the computer to malfunction. To play a DVD Disable the screen saver and the virus checker. Select a display.
Page 50
Disconnecting the TV from the computer Unplug the audio-video (AV) cable connector from the A/V OUT jack on the computer. Disconnecting the cable when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. Page 50...
Page 51
Watching DVDs on your computer Your computer is equipped with a CD-RW/DVD drive, which enables you to watch most DVDs on your computer. To play a DVD while connected to the AC adapter Close all open programs. Insert the DVD into the CD-RW/DVD Combo Drive. Select a preinstalled DVD program in which to play the DVD.
Page 52
Frequently asked questions How do I maintain CDs and DVDs? Avoid touching the surface of the disc with your fingers. Fingerprints and dust on the surface of the disc may cause reading errors. To clean the disc, hold the edge of the disc, and use a soft cloth to wipe the surface from the center out. If the disc is badly soiled, moisten a soft cloth with water, wring it out well, and use it to wipe the surface of the disc from the center out.
Page 53
Click Start on the Windows and System. The System Properties window appears. Select the Hardware tab, and then click Device Manager. The Device Manager window appears. Double-click the listed DVD/CD-ROM drive. The Properties window appears. Click the Properties tab, and click to select the Enable digital CD audio for this CD-ROM device check box, if it is not selected.
Page 54
The Fn+F8 key combination will not work once a DVD is inserted into the optical drive. Switching the display while a DVD is playing may cause the computer to malfunction, and you may need to restart the DVD software. Page 54...
Printing With Your Computer You can connect a universal serial bus (USB) printer or a parallel port printer to your computer. To print properly, the printer you connect must be compatible with the Microsoft Connecting a printer Disconnecting a printer ...
Page 57
Connecting a printer Your computer is compatible with many popular printers. The New Hardware Wizard guides you through the software installation process. Some printers require separate driver software installation. See the instructions that accompanied your printer for more information. If you cannot print once you have connected your computer to your printer, see asked questions in this section for more information.
Page 59
Disconnecting a printer You can disconnect a USB or parallel printer when the computer is on or off. Disconnecting a printer when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To disconnect a printer ...
Page 60
You may need to enable the computer's printer settings. Click Start, and point to All Programs, Sony Notebook Setup, and click Sony Notebook Setup again. Click the Device tab. In the left panel, make sure the Printer Port check box is selected, and click Setting.
Using the Keyboard Your keyboard is very similar to a typewriter's, but your computer keyboard has additional keys that perform specific computer-related tasks. Key locations and descriptions Combinations and functions with the Windows key Indicators Combinations and functions with the Fn key Page 62...
Page 63
Key locations and descriptions Keyboard Description Numeric keypad Contains the keys found on a typical calculator. Use the numeric keypad area to type numbers or to perform mathematical calculations such as addition and subtraction. Numbers appear on the front beveled edge of the numeric keys.
Page 64
Combinations and functions with the Windows key Combination Function + F1 Displays the VAIO Help and Support Center window. + Tab Switches the selected button on the taskbar. Displays the desktop. Displays the My Computer window. Displays the Search Results window, where you can find a file or folder. This is the equivalent of selecting Search from the Start menu.
Page 65
Indicators Indicator Function Power Turns on when the power to the computer is on, blinks in Standby mode, and turns off when the computer is in Hibernate mode or off. Battery Turns on when the computer is using battery power, blinks when the battery is running out of power, double-blinks when the battery is charging.
Page 66
Combinations and functions with the Fn key If you switch user identities during a computing session, the Fn+F7 key functionality (if available on your computer) will be interrupted. To switch to an external display or monitor, see Combinations/ Feature Function Fn + (F3) Mute On/Off...
Page 67
Bass Boost Toggles the bass-boost function off and on. This feature is available only while using headphones. You can also carry out these functions using the Jog Dial Control. Some functions are not available until the Microsoft Windows operating system launches. ®...
Using the Touch Pad The keyboard contains a pointing device called a touch pad. You can point to, select, drag, and scroll objects on the screen using the built-in touch pad. Describing the touch pad Customizing the touch pad ...
Page 69
Describing the touch pad Locating and Describing the Touch Pad Action Description Point Slide one finger on the touch pad to place the pointer on an item or object. Click Press the left button once. Double-click Press the left button twice. Right-click Press the right button once.
Page 70
Customizing the touch pad Sony Notebook Setup lets you customize your touch pad, such as enable or disable the touch pad. You can also open the Mouse Properties dialog box, which enables you to set your touch pad and mouse preferences, such as changing pointers, enabling or disabling the tapping feature, clicking both buttons simultaneously, and adjusting the touch pad speed.
Page 71
Frequently asked questions Why doesn't the touch pad work? You may have disabled the touch pad without connecting a mouse to the computer. See Restart the computer to activate the touch pad again. If your touch pad is interpreting a single tap as a double-click, adjust the button assignments. Follow these steps: Press the Windows Click the Tools menu, and select Folder Options.
Click << or >> to view the designs. Click Apply to select a design that appears in the center window. The UI Design Selector window design changes. The window design for your Sony software will match the UI Design Selector window. Click OK.
Using External Mice and Keyboards You can connect a universal serial bus (USB) mouse or keyboard to your computer. To function properly, the device you connect must be compatible with the Microsoft about your computer's built-in keyboard and key functions, see ...
Page 75
Connecting a mouse or keyboard Your computer is compatible with many popular mice and keyboards. The New Hardware Wizard guides you through the software installation process. Some devices require separate driver software installation. See the instructions that accompanied your mouse or keyboard for more information. If the mouse or keyboard does not work once you have connected it to your computer, see Your computer can be on or off when connecting a mouse or keyboard.
Page 76
Disconnecting a mouse or keyboard You can disconnect a USB mouse or keyboard when the computer is on or off. Disconnecting the USB mouse or keyboard when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To disconnect the USB mouse or keyboard ...
Page 77
Frequently asked questions Why doesn't the computer recognize the USB mouse? Make sure the mouse is securely plugged into the USB port. See information. You may need to install or reinstall the mouse driver software. Use the supplied Application Recovery CD to install the drivers.
Using Floppy Disk Drives You can connect a floppy disk drive to your computer. The floppy disk drive enables you to read data stored on a floppy disk. Connecting a floppy disk drive Inserting and removing floppy disks ...
Page 80
Connecting a floppy disk drive You can connect a floppy disk drive when your computer is on or off. Connecting the drive when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To connect a floppy disk drive Close any active programs to prevent data loss.
Page 81
Inserting and removing floppy disks Floppy disks are portable devices that store data. To protect your floppy disks, keep them away from magnets and direct sunlight or other heat sources. To insert a floppy disk Hold the floppy disk with the label facing up. Push the floppy disk into the drive until it clicks into place.
Page 82
Notes on handling floppy disks Do not open the shutter manually and touch the surface of the floppy disk. Keep floppy disks away from magnets. Keep floppy disk away from direct sunlight and other heat sources. Page 82...
Page 83
Disconnecting a floppy disk drive You can disconnect a floppy disk drive when the computer is on or off. Disconnecting the drive when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To disconnect a floppy disk drive Close any active programs to prevent data loss.
Page 84
Carrying the floppy disk drive Fold the floppy disk drive cable and connector into the side compartment on the floppy disk drive. Carrying a Floppy Disk Driv e Page 84...
Page 85
Frequently asked questions Why doesn't the Safety Remove Hardware icon The computer does not recognize the floppy disk drive. First, make sure the USB cable is properly connected to the USB port. If you need to secure the connection, wait a few moments for the computer to recognize the drive. If the icon still does not appear, follow these steps: Close all programs that were opened from the disk and wait for the LED indicator to turn off.
Using PC Cards Your computer includes one or more PC Card slots. A PC Card enables you to connect portable external devices such as another hard disk drive or a PC Network Interface Card (NIC) to connect to a network. See your VAIO Computer Specifications for the type of PC Card that is compatible with your computer.
Page 87
Your computer may contain PC Card slot protectors. Remove these protectors before you insert a PC Card into the slot. To remove slot protectors. Some PC Cards may require you to disable idle devices when using the PC Card. You can use Sony Notebook Setup to disable devices.
Page 88
Removing PC Cards You can remove PC Cards while the computer is on or off. PC Cards draw power from the computer when they are inserted into the PC Card slot, whether or not you use the card. If you are not using your PC Card and you are using a battery as a power source, remove the PC Card from the PC Card slot to conserve battery power.
Page 89
The PC Card drive enables you to read data stored on a DVD or CD. Your computer may come with an external PC Card drive, depending on the model you purchased. If you wish to purchase an optional PC Card drive, shop Sony online at http://www.sonystyle.com/vaio...
Page 90
Click Stop. The Stop a Hardware device window appears. Make sure the PC Card drive is selected, and click OK. A message appears stating it is now safe to remove the hardware device. Eject the PC Card from the PC Card slot. Page 90...
Page 91
Make sure the PC Card is inserted properly. See Make sure the PC Card is compatible with the Microsoft Use the Sony Notebook Setup utility to disable devices you are not currently using. See Setup for more information. ...
Audio and Video Connections Using i.LINK Digital-Video Recorders Using Computer Monitors and Projectors Using Speakers Using Microphones Page 92...
N K is a trademark of Sony us ed to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tor. T he i.LI...
Page 94
Connecting an i.LINK digital video recorder You can connect an i.LINK digital video (DV) recorder when the computer is powered on or off. Connecting the DV recorder when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To connect an i.LINK digital video recorder Turn on the DV device and the computer.
Page 95
Disconnecting the i.LINK digital video recorder You can disconnect the i.LINK digital video recorder when the computer is on or off. Disconnecting the DV device when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To disconnect the i.LINK DV recorder when the computer is off Turn off the computer and the i.LINK DV device.
Page 96
Using a digital video camera recorder Your computer comes with preinstalled driver software that is compatible with most Sony digital video camera recorders. If you purchased a camera that comes with its own driver software, install these drivers before you use the camera.
Page 97
Notes on connecting an i.LINK device Do not connect more than one digital video camera recorder at a time. The programs supplied with your computer will not recognize multiple cameras. Do not connect an external device that requires power from the i.LINK port. The i.LINK port cannot supply power to the external device.
Page 98
N K is a trademark of Sony us ed only to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Using Computer Monitors and Projectors You can connect an external display (such as a computer monitor or a projector) to your computer. Connecting a computer monitor Connecting a multimedia computer monitor Connecting a projector Selecting a display mode ...
Page 100
Connecting a computer monitor You can display the images on the computer screen (LCD) onto an external computer monitor. The external monitor displays the operations you perform on your computer. To connect a computer monitor Make sure the computer monitor is plugged into an AC outlet. Turn off the computer.
Page 101
Connecting a multimedia computer monitor A multimedia computer monitor has built-in speakers and/or a microphone device. Before you can connect your computer to a multimedia computer monitor, it must have an A/V OUT jack. For more information, see "Locating Controls and Ports" in the "Setting Up"...
Page 102
Connecting a projector You can use a projector to display the actions and images on the computer screen (LCD). To connect a projector Plug the projector into an AC outlet. Turn off the computer. Plug the display cable into the Monitor (VGA) port Plug the other end of the display cable into the projector.
Page 103
Selecting a display mode When you connect your computer to an external display (projector, computer monitor, or TV), you can switch the display mode between the computer screen (LCD) and the external display, using shortcut keys or the Display Properties settings. Shortcut keys Result (F7) Toggles between the computer screen (LCD), a connected external display (projector or computer monitor), and both the LCD and external display.
Page 104
Turn on the computer after you connect the external display. Page 104...
Page 105
Disconnecting a computer monitor or projector You can disconnect the external computer monitor or projector by unplugging the display or Monitor (VGA) cable from your computer's port. Disconnecting the external display when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction.
Your computer comes with built-in stereo speakers. If you wish to enhance the sound quality of your computer, you can purchase and connect external speakers. If you want to purchase speakers, make sure the speakers are designed for computer use. You can shop Sony online at ...
Page 107
Connecting speakers You can connect speakers to your computer to enhance the sound quality of your computer. Do not place floppy disks on the speakers. The speakers' magnetic field may damage the data stored on the floppy disks. To connect speakers to your computer Turn down the volume of the speakers.
Page 108
Disconnecting external speakers You can disconnect external speakers when the computer is on or off. Simply unplug the speaker cable from the Headphone jack on the computer. Page 108...
Page 109
Adjusting the volume To adjust the volume for playing CDs and DVDs, use the Volume icon playing CDs or DVDs does not adjust the volume for recording CDs or DVDs. You can only adjust the recording volume in the Recording Control window. See record for instructions on how to open this window.
Page 110
Enabling the audio feature If you do not hear sound when playing a CD or DVD, you may need to enable the audio feature. To enable the audio feature Click Start on the Windows ® Click Performance and Maintenance, and click System. The System Properties window appears. Select the Hardware tab, and click Device Manager.
Page 111
Frequently asked questions Why won't my speakers work? Make sure the speakers are properly connected and the volume is turned up loud enough to hear sound. Your speakers may not be designed for computer use. If the speakers have a mute button, set the button to off. ...
Using Microphones You can connect an external microphone to your computer to enhance the sound input to your computer. Make sure your microphone is designed for computer use. If you wish to purchase a microphone, shop Sony online at http://www.sonystyle.com/vaio or contact your local retailer.
Page 113
Connecting a microphone Plug the microphone cable into the Microphone jack on the computer. Connecting a Microphone Jack See the guide that came with your microphone for more information on its installation and use. A protruding dot loc ated next to the M ic rophone jac k dis tinguis hes this jac k from the H eadphone jac k. Page 113...
Page 114
Disconnecting a microphone You can disconnect an external microphone when the computer is on or off. Simply unplug the microphone cable from the Microphone jack on the computer. Page 114...
Page 115
Using a microphone or other device to record You can record messages, memos, or other recordings in analog by connecting a microphone or other audio device to the Microphone jack on your computer and switching the jack functionality. The Microphone jack (monaural).
Page 116
Frequently asked questions Why doesn't my microphone work? If you are using an external microphone, make sure the microphone is properly plugged into the Microphone jack on the computer. See Connecting a microphone for more information. Page 116...
Software Programs On Your Computer Your computer may not be supplied with all of the programs listed in purchased. Preinstalled software may not be identical to retail versions or include supporting documentation. Program overview Frequently asked questions Program overview, depending on the configuration you Page 118...
Page 119
Sony Electronics Inc. Network Smart Capture captures images and video from any Sony Digital Camcorder that supports a standard i.LINK connection. Send your video or still images through e-mail or upload them to the ImageStationSM service. You can use the Web camera function to automatically upload your captured images.
Page 120
(on computer models that include a CD recording device), and a parametric equalizer for fine-tuning audio playback. Sony on Yahoo! Yahoo! Inc. Personalize your own Web portal with Sony on Yahoo! Get a free Web mail account, customized news and local weather reports, comics, instant messaging, and more. VAIO Support Agent Sony Electronics Inc.
Page 121
WinDVD software is a simple-to-use DVD player that offers all the features you would expect to find in a standard consumer DVD player, including advanced display and navigation features such as zoom, pan, bookmark, and time search. Page 121...
Page 122
Which program do I use for CD-R/CD-RW functions? Use the preinstalled Sony SonicStage program and Windows model you purchased is preconfigured with all of the necessary components for CD-R and CD-RW capability.
DVgate Program Notes Recording images to a digital video device Adjusting image resolution Saving to your hard disk drive Page 123...
Page 124
Recording images to a digital video device If your system displays the message, "Failed to record to DV deck, please check deck's power status, cable connection...," while you are recording images to a digital video device using the DVgate program, close all open programs, and restart your computer.
Page 125
Adjusting image resolution If the images on the computer screen (LCD) do not display smoothly, the resolution may not be set correctly. To check the resolution From the DVgate Motion-Monitor window, click Setup. From the shortcut menu, point to Settings, and then select Low Resolution. The settings you change in this menu affect the images in the monitor window only.
Page 126
Saving to your hard disk drive In order to improve the performance of your computer's DVgate been formatted with two partitions, C and D. The C partition holds 40 percent and the D partition holds 60 percent of the entire drive capacity. The DVgate program saves files to the D partition. This prevents large video captures from consuming the available space on your C partition.
Program Support Information Sony Service Center Adobe Acrobat Reader , Photoshop ® ® ® Web site http://www.adobe.com/ e-mail techdocs@adobe.com telephone 206-675-6126 (fee-based support) 206-628-5737 hours M-F, 6 A.M.-5 P.M. (Pacific time) America Online (America Online, Inc.) ® Web site http://www.aol.com/...
Page 128
® Web site http://www.apple.com telephone 800-275-2273 hours M-F, 6 A.M.-6 P.M. (Pacific time) Sony Applications (Sony Electronics Inc.) Web site http://www.sony.com/pcsupport telephone 888-4-SONY-PC (888-476-6972) hours 7 days a week, 24 hours a day Support from 1 -8 8 8 -4 -SO N Y -P C is free of c harge for 9 0 days after the original date of purc has e.
Page 129
Sony Service Center For the Sony Service Center nearest you, call 1-888-4-SONY-PC (1-888-476-6972) or find Sony Customer Service on the Web at http://www.ita.sel.sony.com/support. Page 129...
Changing Your Computer's Memory Before you begin upgrading your computer's memory, make sure you read page to view the VAIO Computer Specifications for the type of module and amount of memory installed on your computer. ® See also Typical expansion memory configuration. upgrades and information about which memory modules to use, refer to your VAIO ...
Page 132
The procedures described below assume familiarity with the general terminology associated with personal computers and with the safety practices and regulatory compliance required for using and modifying electronic equipment. Sony recommends that memory upgrades be performed by an authorized Sony Service Center. To find the nearest center or agent, go to: http://www.sony.com/pcsupport.
Page 133
Typical expansion memory configuration Total System Memory (MB) On board (MB) Slot (MB) Page 133...
Page 134
Removing and installing memory modules Make sure you read Precautions and procedures module, do not open the module package until you are ready to install it. The package protects the module from Electrostatic discharge (ESD). To remove a memory module Turn off the computer and all peripheral devices.
Page 135
Snap the connectors into place when the board is correctly seated, and close the computer cover. Replace the fastening screws on the bottom of the computer. Make sure the system memory matches the amount of installed memory. See more information. Confirming amount of memory Page 135...
Page 136
Click Start on the Windows ® Select Sony Notebook Setup from the submenu. The Sony Notebook Setup dialog box appears. On the About This Computer tab, make sure the System Memory displayed in the System Information box matches the amount of memory installed.
CDs. If your computer does not come with an optical drive, use an external optical drive. Application Recovery CD(s) Sony Electronics Inc. This CD enables you to reinstall individual software programs and device drivers if they become corrupted or are erased.
Using Your Recovery CDs The following sections describe how to use the Application Recovery and System Recovery utilities. Using the Application Recovery CD(s) Using the System Recovery CD(s) Page 139...
Page 140
Logon to the Microsoft Windows ® Insert Sony Application Recovery CD No. 1 into your computer's optical drive. The Application Recovery utility loads automatically. Click OK in the VAIO welcome window. The Sony Application Recovery Program window appears. Double-click the Software folder icon.
Page 141
You are prompted to insert the next CD(s), depending on the application or driver you want to restore.. If you have any questions about using the Application Recovery CD(s), visit http://www.ita.sel.sony.com/support, or contact Sony Customer Support at 1-888-4-SONY-PC.
Page 142
Your system may take a few minutes to load necessary files. A blue screen may appear during the downloading process. Insert the Sony System Recovery CD in the optical drive. The first CD must be in the drive before you restart your computer.
Page 143
Your system may include one or more System Recovery CDs. If you have more than one System Recovery CDs, insert the first CD to run the System Recovery program. You are prompted to insert the second CD once the information from the first CD has been installed.
Troubleshooting and Support This section describes how to solve common problems you may encounter when using your computer. Many problems have simple solutions, so try these suggestions before you contact Sony Computing Support (http://www.sony.com/pcsupport). Troubleshooting Your Computer Troubleshooting Batteries ...
Select Exit (Save Changes), and press Enter. The Setup Confirmation window appears again. Select Yes, and press Enter. The computer restarts. If this occurs on a regular basis, contact Sony Computing Support (http://www.sony.com/pcsupport). Why does the message, "Operating system not found" appear when my computer starts, and why won't Windows start? ...
Page 146
Turn off the computer. Remove any peripheral devices connected to the computer. Restart the computer. Press F2 when the Sony logo appears. The BIOS Setup window appears. Press the Right Arrow key Press the Down Arrow key SETUP items appears.
Page 147
To reduce fan noise Right-click the CPU icon on the taskbar, and select Edit/Create Profiles. The AC Power Profile Editor window appears. Double-click System to open the file if it isn't already opened. Double-click Thermal Control Strategy - Performance, and select Quiet. Restart your computer.
Troubleshooting Batteries How do I know when the battery is charged? To determine the remaining battery charge, see When is the computer using AC power? When the computer is directly connected to the AC adapter, it uses AC power, even if a battery is installed. When should I recharge the battery? ...
You may need to set or reset your computer's printer settings. Click Start, and point to All Programs, Sony Notebook Setup, and click Sony Notebook Setup again. Click the Device tab. In the left panel, make sure the Printer Port check box is selected, and click Setting.
Troubleshooting the Mouse and Touch Pad Why doesn't the computer recognize the USB mouse? Make sure the mouse is securely plugged into the USB port. See information. You may need to install or reinstall the mouse driver software. Use the supplied Application Recovery CD to install the drivers.
Page 151
Press Alt to highlight the menu bar, and press the Right Arrow key Press Enter. Press R to restart the computer. If you still cannot restart your computer, press and hold the power to turn off the computer. If the pointer does not move while playing a disc, press Ctrl+Alt+Delete simultaneously to stop playback and restart the computer.
Make sure the telephone number the program is dialing is correct. Make sure the program you are using is compatible with the computer's modem. (All preinstalled Sony programs are compatible.) If you are still experiencing problems, use the supplied Application Recovery CD(s) to reinstall the modem driver software.
Troubleshooting DVDs and CDs How do I maintain DVDs? Avoid touching the surface of the disc with your fingers. Fingerprints and dust on the surface of the disc may cause reading errors. To clean the disc, hold the edge of the disc, and use a soft cloth to wipe the surface from the center out. If the disc is badly soiled, moisten a soft cloth with water, wring it out well, and use it to wipe the surface of the disc from the center out.
Page 155
Condensation may cause the computer to malfunction. If this occurs, do not use it for at least one hour. Make sure the digital CD audio is enabled for your optical drive. Follow these steps: Click Start on the Windows .
Troubleshooting Floppy Disk Drives Why doesn't the Safely Remove Hardware icon The computer does not recognize that the floppy disk drive is connected to the computer. First, make sure the USB connector is properly inserted into the USB port. If you need to secure the connection, wait a few moments for the computer to recognize the drive.
Make sure the PC Card is inserted properly. See Make sure the PC Card is compatible with the Microsoft Use the Sony Notebook Setup utility to disable devices you are not currently using. See Setup for more information. ...
Troubleshooting Audio-Video Connections Why can't I use the DV recorder? You may not be able to use the DV recorder and the message, DV equipment seems to be disconnected or turned off may appear because the i.LINK cable is not securely plugged into the i.LINK ports on the computer or camera. Unplug the connectors, and plug them in again.
Page 159
N K is a trademark of Sony us ed only to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Troubleshooting the Computer Screen (LCD) Why did the computer screen (LCD) go blank? Your computer screen may go blank if the computer has lost power or is in a power saving mode (Standby or Hibernate). Make sure the computer is plugged into a power source and is on. The power indicator on the computer will be on if the computer is on.
Which program do I use for CD-R/CD-RW functions? Use the preinstalled Sony SonicStage software and Windows specific model you purchased is preconfigured with all of the necessary components for CD-R and CD-RW capability.
Sony Computing Support This service provides instant access to information on commonly encountered problems. Type a description of the problem and the Knowledge Database searches for the corresponding solutions online. You can visit Sony Computing Support at: http://www.sony.com/pcsupport. Computer Quick Start provide information on how to maximize ®...
