RS8210
Operation Manual

Advertisement

loading

Related Manuals for Robertshaw RS8210

Summary of Contents for Robertshaw RS8210

  • Page 1 RS8210 Operation Manual...

  • Page 3: Table Of Contents

    RS8210 Table of Contents Page Table of Contents Caution Thermostat Operation DO NOT SWITCH SYSTEM TO Thermostat Quick Reference 4-6 COOL IF THE TEMPERATURE Programming IS BELOW 50°F (10°C). THIS Installer Setup Menu 8-10 CAN DAMAGE THE AIR CONDITIONING SYSTEM AND Terminal Designations CAUSE PERSONAL INJURY.

  • Page 4: Thermostat Operation

    THERMOSTAT OPERATION Room Set At Menu SLEEP HEAT AUTO COOL Temperature Set-Point Buttons LCD Screen Fan Switch User Buttons System Switch...
  • Page 5 THERMOSTAT OPERATION LCD Screen Selecting EMH (for heat pumps See page 4 for details about this with auxiliary heat) will lockout display read out. the compressor and control emergency/auxiliary heat. Fan Switch Select ON or AUTO. ON will Temperature Set-Point run the fan continuously.

  • Page 6: Thermostat Quick Reference

    THERMOSTAT QUICK REFERENCE Displays the user Days of the week selectable set-point Hold: Is displayed and time. temperature. when thermostat program is Sun Mon Tue Wed Thu Fri Sat Tech Set overridden. Next Step Min Com On Com Delay H e a t Low Battery Cool Swing Indicator:...
  • Page 7 THERMOSTAT QUICK REFERENCE Caution: When the battery icon appears, replace the alkaline AAA batteries immediately to avoid damage to your HVAC system. Freezing or overheating could occur Battery Door Information Install two AAA Alkaline batteries into battery compartment. Be sure to match positive (+) ends of batteries with positive (+) battery terminals in the battery compartment.
  • Page 8 THERMOSTAT QUICK REFERENCE Filter Change Reminder The thermostat can be configured to remind you when the air filter needs to be changed. The filter change reminder can be adjusted to up to 2000 hours in 50 hour increments. If the installer configured the thermostat to issue this reminder, FILTER will be displayed when it is time to change the air filter.

  • Page 9: Programming

    PROGRAMMING Set Time 1. Press the MENU button. 2. Press SET TIME. 3. Day of the week will be flashing. Use to select the current day of the week. 4. Press NEXT STEP. 5. The current hour will be flashing. Use to select the current hour.

  • Page 10: Installer Setup Menu

    INSTALLER SETUP MENU 1. Press MENU. 2. Press and hold TECH SET for 3 seconds. 3. Configure the installer options as desired using the table below. 4. Use to change settings and the NEW STEP or PREV STEP to move from one option to another. Note: Only press DONE when you want to exit the Installer Setup Options.
  • Page 11 INSTALLER SETUP MENU Room Minimum Compressor Filter Change Cooling Heating Feature Temperature Compressor Short Cycle Differential Differential Reminder Calibration On-Time Delay Factory default 0°F 0.5°F 0.4°F settings The cooling differential is The heating factory preset at differential is 0.5°. This means factory preset at This setting The compressor...
  • Page 12 INSTALLER SETUP MENU FILTER Setting: Display SE Fl, flashing 1000 (the default value 1000 hours), select from 50-2000 hours. Temperature Calibration: Display CAL and flashing 0°F (the default value 0), select from -3-3°F. Minimum compressor on time: Display AN ON and flashing OFF (default setting), select from OFF, 3, 4 or 5 minutes.

  • Page 13: Terminal Designations

    TERMINAL DESIGNATIONS W2 ..Auxiliary heat relay Y ..... Compressor relay G ..... Fan relay O ..... Heat pump reversing valve energized in cooling RH ..24VAC Power C ..... Common wire (if applicable) B ..... Heat pump reversing valve energized in heating E .....
  • Page 16 Customer Service +1.800.304.6563 Technical Service +1.800.445.8299 Use Phone Year HVACCustomerService@robertshaw.com to Scan for Limited 352-00310-001 Rev. B www.robertshaw.com • 352-00301-001 Warranty Info Warranty © 2021 Robertshaw Controls Company. Robertshaw is a trademark of Robertshaw Controls Company. ®...
