Owner's Installation and Operation Manual
Report No: 0215WH080S
This unit is certified UL 391(R2014)
U.S. ENVIRONMENTAL PROTECTION AGENCY
Certified to comply with the 2017 particulate
emission standards. Not approved for sale after
May 15, 2020
Installation is to be preformed by a
qualified installer.
SAVE THESE INSTRUCTIONS
NOT FOR USE IN A MOBILE HOME
Model 1660E
United States Stove Company
227 Industrial Park Rd.
South Pittsburg, TN 37380
852856B-3002G

Advertisement

Table of Contents
loading

Related Manuals for Ashley 1660E

Summary of Contents for Ashley 1660E

  • Page 1 Owner’s Installation and Operation Manual Model 1660E Report No: 0215WH080S This unit is certified UL 391(R2014) U.S. ENVIRONMENTAL PROTECTION AGENCY Certified to comply with the 2017 particulate emission standards. Not approved for sale after May 15, 2020 Installation is to be preformed by a qualified installer.
  • Page 2 CAUTION: • Power source not controlled by furnace main disconnect. • Respect all local and national codes when installing this unit. • This unit is not to be connected to a chimney flue serving another appliance. • This unit is designed to burn solid hardwood only. 48”...

  • Page 3: Specifications

    12.625” X 12.5” Weight (lbs): 509lbs This manual describes the installation and operation of the Ashley, 1660E wood heater. This heater meets the 2016 U.S. Environmental Protection Agency’s emission limits for wood heaters sold after May 15, 2016. Under specific EPA test conditions this heater has been shown to deliver heat at a rate of 33,438 to 77,456 BTU/hr.
  • Page 4 Safety • Do not operate with fuel loading or ash removal doors open. • Do not connect this unit to a chimney flue serving another appliance. • Danger: Risk of fire or explosion. Do not burn garbage, gasoline, naphtha, motor oil, or other inappropriate materials.

  • Page 5: Tools And Materials Needed For Installation

    Unpacking And Preassemble UNPACKING 1. Remove all packaging from the furnace. 2. Remove the supplied tools and parts from the furnace. BRICK ALIGNMENT Inspect for any damage. Ensure that the bricks are positioned correctly and not broken (see illustration for proper brick arrangement).

  • Page 6: Furnace Installation

    Furnace Installation INSTALLATION OPTIONS The installation of this furnace includes supplying electrical power, return (fresh air) ductwork, and supply air ductwork. This furnace may be installed as a stand alone wood furnace. See kit installation section in this manual to ensure proper assembly, installation and operation of your new furnace.

  • Page 7: Floor Protector Requirements

    MAINTENANCE CLEARANCES Your furnace has recommended minimum maintenance clearance requirements. These clearances insure that there is adequate room to preform maintenance and service your furnace. DO NOT store fuel within the specified clearances. clearances will change depending on what kits are installed with your furnace.

  • Page 8: Duct Work Installation

    Duct Work Installation We strongly recommend that the hot air ductwork be installed by a home heating specialist. If doing the installation yourself, before you decide which installation will best suit your needs, consult a qualified heating technician and follow his recommendations as to the safest and most efficient method of installation. This furnace can be installed in two ways, as a stand alone unit, or in series with an existing furnace.
  • Page 9 INSTALLATION ADD-ON INSTALLATION...

  • Page 10: Accessory Installation

    Accessory Installation ASSEMBLY OF FURNACE THERMODISC Your furnace requires the following items to be assembled or installed by the service person: Blowers and Blower Controls THERMODISC Electrical Connections COVER 1. Remove all parts from inside the furnace and inspect for damage, including the firebrick as some breakage could occur during shipment.

  • Page 11: Electrical Installation

    Electrical Installation All electrical connections should be done by a qualified electrician It is recommended to connect the furnace to its own 15 amp 120 Volt circuit from the house power supply 105°C NOTE: Wire leads from the distribution blower are usually BOTH BLACK.

  • Page 12: Chimney Installation

    Chimney Installation CHIMNEY Your wood furnace may be hooked up with a factory built or masonry chimney, matching the diameter of the exhaust. If you are using a factory built chimney, it must comply with UL 103 or CSA-B365 standard; therefore it must be a Type HT (2100°F).

  • Page 13: Masonry Chimney

    MASONRY CHIMNEY Ensure that a masonry chimney meets the minimum standards of the National Fire Protection Association (NFPA) by having it inspected by a professional. Make sure there are no cracks, loose mortar or other signs of deterioration and blockage. Have the chimney cleaned before the furnace is installed and operated. When connecting the furnace through a combustible wall to a masonry chimney, special methods are needed as explained in the “Combustible Wall Chimney Connector Pass-Throughs”...

  • Page 14: Combustible Wall Chimney Connector Pass-Throughs

    COMBUSTIBLE WALL CHIMNEY CONNECTOR PASS-THROUGHS Method A. 12” (304.8 mm) Clearance to Combustible Wall Member: Using a minimum thickness 3.5” (89 mm) brick and a 5/8” (15.9 mm) minimum wall thickness clay liner, construct a wall pass-through. The clay liner must conform to ASTM C315 (Standard Specification for Clay Fire Linings) or its equivalent.

  • Page 15: Chimney Connector

    CHIMNEY CONNECTOR Your chimney connector and chimney must have a 6” diameter. If this is not the case, we recommend you contact your dealer in order to insure there will be no problem with the draft. The furnace pipe must be made of aluminized or cold roll steel with a minimum thickness of 0.021” or 0.53 mm. It is strictly forbidden to use galvanized steel.

  • Page 16: Factory Built Chimney

    FACTORY BUILT CHIMNEY When a metal prefabricated chimney is used, the manufacturer’s installation instructions must be followed. You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass-through and “T” section package, firestops (where needed), insulation shield, roof flashing, chimney cap, etc. Maintain proper clearance to the structure as recommended by the manufacturer.

  • Page 17: Do Not Burn

    Wood Heat Utilization The top down method of fire building is recommended for this appliance. After making sure that the stove air intake controls are fully open (open all three air controls to there maximum setting). Place the largest pieces of wood on the bottom, laid in parallel and close together.

  • Page 18: Air Controls

    It is EXTREMELY IMPORTANT that you use DRY WOOD only. The wood should have dried for 9 to 15 months, such that the humidity content (in weight) is reduced below 20% of the weight of the log. It is very important to keep in mind that even if the wood has been cut for one, two or even more years, it is not necessarily dry, if it has been stored in poor conditions.

  • Page 19: Operation

    Operation NOTICE: To minimize the risk of smoke spillage when opening the door with a fire in your furnace, crack the door open no more than 1” and wait for at least 10 seconds before opening it more to allow pressure stabilization inside the furnace.

  • Page 20: Ash Disposal

    OPERATION Controlled combustion is the most efficient technique for wood heating because it enables you to select the type of combustion you want for each given situation. The wood will burn slowly if the wood furnace air intake control’s are adjusted to reduce the oxygen supply in the combustion chamber to a minimum. On the other hand, wood will burn quickly if the air control’s are adjusted to admit a larger quantity of oxygen in the combustion chamber.

  • Page 21: Over Firing

    • Be aware that the hotter the fire, the less creosote is deposited, and that weekly cleaning can be necessary in mild weather, even though monthly cleaning can be enough in the coldest months. • Have a clearly understood plan to handle a chimney fire. CAUTIONS: •...

  • Page 22: Maintenance

    Maintenance Your wood furnace is a high efficiency furnace and therefore requires little maintenance. It is important to perform a visual inspection of the furnace every time it is emptied, in order to insure that no parts have been damaged, in which case repairs must be performed immediately. Inspect and clean the chimney and connector pipe periodically for creosote buildup or obstructions.

  • Page 23: Replacement Parts

    Replacement Parts Gasket, Flue Collar Back Panel Wooden Knob Assembly Moisture Meter 88032 28067 892767 80697 Left Shoulder Weldment, Air Inlet Ring, Flue Collar Door Latch (C000022) 28053 610582 22761 23786 Right Shoulder Damper Slide Flue Collar, 6” C.I. Wooden Handle 28054 610583 40246...
  • Page 24 Replacement Parts Half Firebrick Left Brick Retainer F140 Thermodisc Control Mounting Bracket 891414A 28060 80714 22140 Cast Grate Side Panel Control Mounting Bracket Blower Gasket 40605 28065 22140 88127 Right Brick Retainer Weldment, Cabinet Top 4 X 4 Junction Box Cover, Junction Box 28061 610581...
  • Page 25 Replacement Parts Feed Door Handle 3/8” Rope Gasket Door Curtain, Smoke Secondary Air Tube 89636 88033 4.25ft 23800 86877 Handle Assembly Ashpan Weldment Feed Door Fiber Board 891098 610498 40499 892760 5/8” Rope Gasket Assembly, Ash Door Front Filler Firebrick (4-1/2 X 9) Pumice 88066 610496 28064...

  • Page 26: Service Record

    Service Record It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider: Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.

  • Page 27: Limited Warranty

    3) Parts and/or service replacements made under the terms of this warranty are warranted only for the remaining period of the original heater warranty. 4) Without specific written exclusionary waivers, no one has authority to add to or vary this limited warranty, or to create for Ashley hearth Products Company any further obligation of liability in connection with this heater or any other applicable accessory.

  • Page 28: How To Order Replacement Parts

    How to order Replacement Parts This manual will help you obtain efficient, dependable service from your stove, and enable you to order repair parts correctly. Keep this manual in a safe place for future reference. When writing, always give the full model number which is on the nameplate attached to the stove. When ordering repair parts, always give the following information as shown in this list: 1.
