Panasonic TH-65EF1U Operating Instructions (Functional Manual)

65" full hd lcd display for business use
Hide thumbs Also See for TH-65EF1U:
Table of Contents

Advertisement

Quick Links

Download this manual
This manual is common to all the models regardless of suffixes of the
*
model number.
U : for US, Canada and Mexico
E : for EU and CIS
W : for South East Asia and Middle East Asia
Please read these instructions before operating your set
English
and retain them for future reference.
EU
Operating Instructions
FULL HD LCD Display For business use
Model No.
Functional Manual
TH-65EF1U
TH-65EF1E
TH-65EF1W
65-inch model
65-inch model
65-inch model
DPQX1168ZA

Advertisement

Table of Contents
loading

Related Manuals for Panasonic TH-65EF1U

Summary of Contents for Panasonic TH-65EF1U

  • Page 1 Operating Instructions Functional Manual FULL HD LCD Display For business use TH-65EF1U 65-inch model Model No. TH-65EF1E 65-inch model TH-65EF1W 65-inch model This manual is common to all the models regardless of suffixes of the model number. U : for US, Canada and Mexico...

  • Page 2: Table Of Contents

    Table of Contents Dear Panasonic Customer Welcome to the Panasonic family of customers. We hope that you will have many years of enjoyment from your new LCD Display. Before use To obtain maximum benefit from your set, please read these ●...
  • Page 3 Digital ZOOM ........... 32 Connecting with LAN ........70 On-Screen Menu Displays ......33 Computer operation ·········································· 70 Using Web Browser Control ......70 Adjusting Position .......... 35 Before Using Web Browser Control ····················· 70 Auto setup ······················································ 35 Access from Web Browser ································· 71 Sound Adjustment ..........

  • Page 4: Important Safety Instructions

    Important Safety Instructions WARNING: To reduce the risk of electric shock, 1) Read these instructions. do not remove cover or back. 2) Keep these instructions. No user-serviceable parts inside. Refer servicing 3) Heed all warnings. to qualified service personnel. 4) Follow all instructions. The lightning flash with arrow-head within a 5) Do not use this apparatus near water.

  • Page 5: Fcc Statement

    To assure continued compliance, follow the attached installation instructions and use only the provided power supply cord. Any changes or modifications not expressly approved by Panasonic Corp. of North America could void the user’s authority to operate this device. Declaration of Verification Model No.

  • Page 6: Important Safety Notice

    Important Safety CANADIAN NOTICE: This Class A digital apparatus complies with Notice Canadian ICES-003. WARNING: Not for use in a computer room as defined in the • WARNING Standard for the Protection of Electronic Computer/ 1) To prevent damage which may result in fire or Data Processing Equipment, ANSI/NFPA 75.
  • Page 7 Not standing the displays on cloth or other A replacement fuse cover can be purchased from • materials placed between the display and your local Panasonic dealer. supporting furniture. Do not cut off the mains plug. Educating children about the dangers of climbing Do not use any other type of mains lead except the •...

  • Page 8: Safety Precautions

    If any foreign objects get inside the metal objects inside the wall. An electric shock may Display, please consult your local Panasonic dealer. occur if they contact metal objects inside the wall. Transport only in upright position!
  • Page 9 Have the Display checked, adjusted, or repaired at • Be sure to disconnect all cables before moving the your local Panasonic dealer. Display. Keep the AAA/R03/UM4 batteries (supplied) out of If the Display is moved while some of the cables are •...
  • Page 10 Do not step on, or hang from the display. They might tip over, or might be broken and it may • result in injury. Pay special attention to the children. Do not reverse the polarity (+ and -) of the battery when inserting.

  • Page 11: Precautions For Use

    • When using the unit at high altitudes (1 400 m (4 593 • Panasonic Corporation or its affiliate companies will • ft) and higher and below 2 800 m (9 186 ft) above sea never ask for your password directly. Do not divulge level): 0 °C to 35 °C (32 °F to 95 °F)
  • Page 12 Cleaning and maintenance The front of the liquid crystal panel has been specially treated. Wipe the surface of the liquid crystal panel gently using only a cleaning cloth or a soft, lint-free cloth. If the surface is particularly dirty, wipe with a soft, •...

  • Page 13: Accessories

    Accessories Power supply cord (Approx. 2 m) TH-65EF1U Accessories Supply ● 1JP155AF1U Check that you have the accessories and items shown TH-65EF1U, TH-65EF1E Operating Instructions (CD-ROM × 1) TH-65EF1E ● 2JP155AF1W Remote Control Transmitter × 1 ● N2QAYA000099 ● 3JP155AF1W Batteries for the Remote Control Transmitter ×...

  • Page 14: Remote Control Batteries

    Kensington security Remote Control Batteries 1. Pull and hold the hook, then open the battery cover. The security slot of this unit is compatible with the Kensington security slot. 2. Insert batteries - note correct polarity (+ and -). AAA/R03/UM4 type 3.

  • Page 15: Connections

    Connections Cable fixing Note ● 3 clampers are supplied with this unit. Fix the cables AC cord connection and fixing at 3 locations using the holes for clampers as shown Back of the unit below. If you need more clampers, purchase them from your dealer.

  • Page 16: Video Equipment Connection

    Video equipment connection AV IN (VIDEO): Composite Video / Audio Input USB: USB Terminal Terminal Connect the USB memory to use Connect to video equipment with [USB media player]. Also, this Composite signal output. can be used to supply power of up to 5V/1A to an external device (see page 20) when the picture is displayed.

  • Page 17: Before Connecting

    HDMI 1 and HDMI 2 terminals Before connecting connection ● Before connecting cables, carefully read the operating instructions for the external device to be connected. Note ● Turn off the power of all devices before connecting ● Video equipment and HDMI cable shown are not cables.

  • Page 18: Dvi-D In Terminal Connection

    DVI-D IN terminal connection Pin assignments and signal names for HDMI Terminal Note ● Video equipment and cables shown are not supplied with this unit. ● Use the DVI-D cable complying with the DVI standard. Image deterioration may occur depending on the length or the quality of the cable.

  • Page 19: Pc In Terminal Connection

    PC IN terminal connection Pin assignments and signal names for DVI-D Input Shared with DVI-D IN. (Female) Pin No. Signal Name (Male) T.M.D.S. data 2- T.M.D.S. data 2+ Connect a cable T.M.D.S. data 2 shield which matches the audio output terminal on the computer.

  • Page 20: Video Terminal Connection

    ● The computer shown in the illustration is for example VIDEO terminal connection purposes only. ● Additional computer, cables and conversion adapter Note shown are not supplied with this set. ● Video equipment, connection cables and conversion ● Do not set the horizontal and vertical scanning plugs are not supplied with this unit.

  • Page 21: Serial Terminal Connection

    SERIAL terminal connection Pin assignments and signal names for SERIAL Terminal The SERIAL terminal conforms to the RS-232C interface specification, so that the Display can be controlled by a computer which is connected to this terminal. Note ● Additional computer and cables shown are not supplied with this set.

  • Page 22: Ir In/Ir Out Terminal Connection

    “ER401” command back to the computer. ● In Standby condition (power OFF with remote control), the unit responds to PON command only. ● Consult your local Panasonic dealer for detail instructions on command usage. For more details, visit the following web site. http://panasonic.net/prodisplays/ English...

  • Page 23: Audio Out Terminal Connection

    AUDIO OUT terminal connection USB terminal connection Note Connect the USB memory (commercially available) to use [USB media player]. (see page 78) ● Audio equipment and the cable shown are not supplied with this set. Also, power is supplied when a separately sold stick PC, etc.
  • Page 24 Pin assignments and signal names for USB Terminal Pin No. Signal name +5 V DC DATA - DATA + GND (Ground) Power of up to 5V/1A can be supplied to an external device when the picture is displayed. ● If the electric current exceeding the power supplying capability is applied, the output is blocked, and the following message is displayed.

  • Page 25: Identifying Controls

    Identifying Controls Main unit INPUT MENU ENTER 1 External Input Terminal ● Slide the lever on the rear panel to eject the power Connects to video equipment, PC, etc. (see page 16) indicator and remote control sensor. 2 <Main Power On / Off button> To store them, slide the same lever, or directly Turns the power On / Off.

  • Page 26: Remote Control Transmitter

    14 RECALL Remote Control Transmitter ● Displays the current setting status of Input mode, Aspect mode, etc. (see page 29) 15 RETURN ● Used to return to the previous menu. (see page 33) 16 FUNCTION ● Displays [Function button guide]. (see page 55) 17 OFF TIMER ●...

  • Page 27: Basic Controls

    Basic Controls Connect the AC cord plug to the Display. (see page 15) AC socket outlet Connect the plug to the socket outlet. AC cord (supplied) Note ● Main plug types vary between countries. The power plug shown at left may, therefore, not be the type fitted to your set.

  • Page 28: Selecting The Input Signal

    ■ When the Unit is turned on for the first time Selecting the input signal Following screen will be displayed. Select the signals input to the unit. Select the language with Press <INPUT> or <INPUT (Unit)>. press <ENTER>. OSD language English (UK) Deutsch Français...

  • Page 29: Recall

    ● To display the clock, set [Date and time] and then set Note [Clock display] to [On]. (see page 52, 62) ● Displays the signal name as set in [Input label]. (see page 47) Volume Adjustment ● Input will not be switched unless [Input lock] is set to [Off].

  • Page 30: Sound Mute On / Off

    Sound mute On / Off It is useful when you want to mute the sound temporarily, for example, when answering the phone or door. Press <MUTE>. ● appears on the screen and the sound is muted. Press again to reactivate the sound. ●...

  • Page 31: Aspect Controls

    ASPECT Controls Aspect mode Description Press <ASPECT> or <ENTER (Unit)> repeatedly to move through the aspect options: Zoom1 Letterbox pictures with a 16:9 aspect ratio are enlarged vertically to fill the screen. The top and bottom edges of the pictures are cut off. Letterbox pictures with a 16:9 aspect Zoom2 ratio are enlarged vertically and...

  • Page 32: Digital Zoom

    Digital ZOOM Switch the zoom ratio for the screen areas. Switches every time <ENTER> is pressed. Select the screen areas (25 areas) to zoom in, and zoom in the selected image areas ×2, ×3 or ×4. (Use the remote control. The main unit’s buttons cannot be used for operation.) Exit Exit...

  • Page 33: On-Screen Menu Displays

    On-Screen Menu Set. Press to set. Displays Display the menu screen. Remote Control Press to set. INPUT MENU ENTER Press to select. Unit Exit from the menu. Press for several times. INPUT MENU ENTER Press. Each time the button is pressed, the menu screen will switch.
  • Page 34 Menu display list [Setup] menu ● Menu that cannot be adjusted is greyed out. (see page 43 ‒ 56) Adjustable menu changes depending on signal, input Setup and menu setting. Signal Screensaver [Position] menu Input label (see page 35 ‒ 36) Power management settings Image settings Position Wobbling...

  • Page 35: Adjusting Position

    Adjusting Position Auto setup When inputting a PC signal, [H-position] / [V-position], [H-size] / [V-size], [Clock phase] and [Dot clock] are Press <POSITION> to display the automatically corrected. [Position] menu. This setting is enabled under the following condition: Position ● When inputting an analogue signal (PC).
  • Page 36 [H-position] Adjust the horizontal position with Note ● In some cases, noise appears outside the area picture is displayed, but it is not a malfunction. [H-size] Adjust the horizontal size with [V-position] Adjust the vertical position with [V-size] Adjust the vertical size with [Clock (For PC IN input) phase]...

  • Page 37: Sound Adjustment

    Sound Adjustment [Output select] Select the audio output. [SPEAKERS]: Internal speakers Press <SOUND> to display the [AUDIO OUT]: [Sound] menu. AUDIO OUT terminal output ● When [AUDIO OUT] is selected, Sound the other menus are greyed out Default Default and cannot be selected. Output select SPEAKERS ●...

  • Page 38: Picture Adjustments

    Picture Adjustments [Picture mode] This menu switches to easy-to- see pictures suitable to the picture source or environment where this unit is used. Press <PICTURE> to display the [Normal] [Picture] menu. For viewing in standard (evening lighting) environments. Picture [Dynamic] Default Default Picture mode...
  • Page 39 User setting of [Colour [R gain] temperature] Adjusts the white balance for light 2 kinds of detailed [Colour red areas. temperature] settings ([USER1] 0 ‒ 255 and [USER2]) can be stored. [G gain] 1 Press <ENTER> while setting Adjusts the white balance for light [Colour temperature].

  • Page 40: Picture Profiles

    Picture Profiles Overview of Picture Profiles Original picture Adjust picture. Up to 6 combinations of picture adjustment values (in (see page 38 ‒ 39) the [Picture] menu) can be stored in the display memory as profiles and applied as needed, for a convenient way to enjoy your preferred picture settings.

  • Page 41: Saving Profiles

    When you finished entering the profile Saving profiles name, select [Ok] with Follow these steps to save picture adjustment values as press <ENTER>. profiles. Specify the picture quality in the MY MEMORY1 █ [Picture] menu. (see page 38 ‒ 39) In the [Picture] menu, select [Memory save] with and press <ENTER>.

  • Page 42: Editing Profiles

    ■ Renaming profiles When profile is being loaded, profile name is In the [Picture] menu, select [Memory displayed. edit] with and press <ENTER>. Memory save 16:9 Memory load Memory name: MEMORY2 Memory edit Select [Memory name change] with and press <ENTER>. Note Memory edit ●...

  • Page 43: Setup Menu

    Setup menu Signal Examples of [Signal] submenu screen When HDMI / DVI is selected Press <SETUP> to display the [Setup] Signal menu. YUV/RGB-in select Setup Cinema reality Noise reduction Auto Signal MPEG noise reduction Screensaver Signal range Full(0-255) Input label H-freq.
  • Page 44 ■ ■ [Component/RGB-in select] [Cinema reality] This menu is displayed at PC signal input. Faithfully reproduces videos shot with cinema films. Set this to [Off] normally. Select to match the signals from the source connected to PC IN terminal. Note ●...
  • Page 45 ■ ■ [Signal range] Input signal display This menu is displayed at HDMI1, HDMI2 and DVI-D Displays the frequency and the type of the current IN inputs. Switches the dynamic range to match the input signal. signals from the source connected to each terminal. H-freq.

  • Page 46: Screensaver (For Preventing Image Retention)

    Screensaver Screensaver (For preventing image retention) 2017/01/01 SUNDAY 10:00 Start Do not display a still picture, especially in 4:3 mode, for Mode Interval any length of time. Periodic time 0:00 If the display must remain on, a Screensaver should be Operating time 0:00 used.

  • Page 47: Input Label

    Input label Power management settings Set each item to reduce power consumption. This function can change the label of the Input signal to be displayed. This function works only for the input terminal that is currently selected. [Input label] - submenu screen [Power management settings] - submenu screen Input label Power management settings...
  • Page 48 Note [Power save] ● This function may not operate depending on the This function adjusts the brightness of the backlight to video output devices. reduce power consumption. [HDMI2 power management] [Off]: This function does not operate. When this function is set to [On], it operates under the following conditions to turn the power on or off automatically.

  • Page 49: Image Settings

    [Image select] conditions as below. Select the image to display. ‒ I f a file or folder is placed directly under the root [Default image]: Panasonic logo (blue background) directory of the USB device. [User image]: Image registered by the user ● Up to 246 characters of file name (including the extension) are properly displayed.

  • Page 50: Wobbling

    Wobbling Note ● Set the input to something other than USB, and Automatically shifts the display image (therefore read the image. unnoticeable to the eye) to prevent image retention of sharper contour of image. ● One user image can be registered for [Startup image settings] and [No signal image settings] Setting this to [On] moves the screen position at certain respectively.

  • Page 51: Multi Display Settings

    ■ Multi display settings [Bezel H adjustment] / [Bezel V adjustment] Adjust the area of image hidden in the joint 1 to 5 displays can be aligned in horizontal direction and horizontally and vertically respectively. vertical direction respectively, and those displays are 0 ‒...

  • Page 52: Set Up Timer

    Set up timer Date and time Set date and time. ([- -] shows no programme is set.) Sets the program to turn the power on with the specified time and video input, or to turn the power off at the [Date and time] - submenu screen specified time.

  • Page 53: Network Settings

    Network settings [DHCP], [IP address], [Subnet mask], [Gateway] Press to set [On] / [Off] of [DHCP] and press Set when networking with a computer. <ENTER>. [Network settings] submenu will be displayed. When [Off] is selected, IP address and other settings can be set manually.

  • Page 54: Usb Media Player Settings

    [Crestron Connected™] is a function to connect to Select [Save] and press <ENTER>. a system developed by Crestron Electronics, Inc. Save the current network Setup. which manages and controls multiple system devices connected to the network. Note ● For details of “Crestron Connected™”, refer to the ●...

  • Page 55: Function Button Settings

    ■ [Resume play] [Memory load] Set resume play off/on. Memory can be loaded with single-touch operation. ■ Memory load (see page 41) [Scenario file check] [MEMORY1] to [MEMORY6] Execute the contents check of the USB memory ● [MEMORY1] to [MEMORY6] load functions are which is connected to the USB terminal.

  • Page 56: Display Orientation

    ■ Note To use shortcut (numeric buttons) ● In the portrait setting, the power indicator shall come Press <FUNCTION> or <1> ‒ <6>. to the downside. [Function button guide] will be displayed. [Function button guide]: When [Off] is set, pressing OSD position the numeric button starts operation.

  • Page 57: Options Adjustments

    Power on message(Power management) POWER button lock Note ● [POWER button lock] function is only for TH-65EF1U. Select the item to set with For [Input search] and [Information timing], the submenu screen will be displayed when you press <ENTER>. (see page 58, 61)
  • Page 58 Input search [1st search input], [2nd search input] Set the input to search when [Custom] is selected. When a signal is not detected, another input with a signal is automatically selected. [HDMI1] / [HDMI2] / [DVI-D] / [PC] / [VIDEO] / [USB] / (None) Select the item with [Detect digital input]...
  • Page 59 Maximum VOL level ● [Changing delay] is the function to prevent the accidental input switch during a short period, Adjusts the maximum volume. such as when the signal is interrupted due to the frequency change for the input signal while [Input [Off]: detection] is operating.
  • Page 60 PC auto setting ■ To set [Button lock] Sets the operational mode of the automatic position Set with the buttons on the unit. adjustment in the [Position] menu. [Off]: [Off]: Press <+ (Unit)> for 4 times. Automatic position adjustment starts when <AUTO Press <INPUT (Unit)>...
  • Page 61 Select the LAN control protocol. functions: [Protocol 1]: [No signal power off], [HDMI1 power management], [HDMI2 power management], [DVI-D power Control with the Panasonic Display sequence. management], [PC power management] (see page [Protocol 2]: Control with the sequence that is compatible with Setting Example: Panasonic Projector.
  • Page 62 Power on screen delay Power on message(No activity power off) You can set the power-on delay time of the displays to reduce the power load, when you press <Main Power Sets to show/hide [No activity power off] precautions On / Off button> to turn on the multiple displays that are when the power is turned on.
  • Page 63 <Main Power On / Off button> operation is enabled. Note ● This function is only for TH-65EF1U. Initialization When both main unit buttons and remote control buttons are disabled due to the [Button lock], [Controller user level] and [Controller ID function] settings, set all the values [Off] so that all the buttons are enabled again.

  • Page 64: Using Network Function

    Using Network Example of network connection Function Note ● To use the network function, set each item in [Network settings] and make sure to set [Network control] to [On]. This unit has a network function and you can control the (see page 53) Display connected to the network using your computer.

  • Page 65: Control Command Via Lan

    8-byte random number obtained in step 2 “PDPCONTROL : Mismatching of ERRA” password yyyyy : Password of the WEB control administrator 4 bytes or 15 bytes 1 byte privileges user ● Default user name and password are as follows: User name: admin1 Password: panasonic English...
  • Page 66 2. When [LAN control protocol] is set to [Protocol 2]. Last Data part Space Mode terminal Communicates with the same protocol as that of a symbol Panasonic projector [PDPCONTROL] ■ (CR) When the WEB control administrator (ASCII character 0x20 0x30...
  • Page 67 : Busy status or follows: reception invalid period (CR) User name: admin1 0x0d “ERR4” : Timeout or reception Password: panasonic invalid period zzzzzzzz : “ERR5” : Wrong data length 8-byte random number obtained in step 2 “ERRA” : Mismatching of...

  • Page 68: Pjlink Protocol

    31: Shutter mode On the received data. (picture and audio on mute) ● Consult your local Panasonic dealer for detail AVMT? Shutter control query instructions on command usage. 11: Picture Off (picture on mute) For more details, visit the following web site.

  • Page 69: Early Warning Software

    INF1? Manufacturer name query For more details, visit the following web site. Returns “Panasonic”. http://panasonic.net/prodisplays/download/software/index.html INF2? Model name query Returns “65EF1U” / “65EF1E” / Note “65EF1W”.

  • Page 70: Connecting With Lan

    Connecting with Using Web Browser Control You can use a Web browser to control the unit and set Note up a network and password. ● To use the network function, set each item in [Network settings] and be sure to set [Network control] to [On].

  • Page 71: Access From Web Browser

    ● When using “Crestron Connected™” (see page 76), log in with the administrator rights. ● Under no circumstances, Panasonic Corporation or its associated companies will ask customers their password directly. Even if you are asked directly, please do not reveal your password.

  • Page 72: Operating With Web Browser

    Network status page Operating with Web Browser Click [Status], then [Network Status] to display the ■ Description of each section Status information page. Displays the current configuration information of the network. Page tab Displays the configuration details of wired LAN. Click these to switch pages.
  • Page 73 ■ User mode Change Password page Click [Change password]. A user can change password only. Administrator Current password input field User New password input field ■ Administrator mode New password input field (re-enter for confirmation) Button for executing password change Note ●...
  • Page 74 ■ LAN settings Adjust clock page Click [Detailed set up] in the menu. Click [Detailed set up], then [Adjust clock] to display the Adjust clock page. Click [Next]. New date field The settings window appears, showing the current settings. New time field To change the LAN settings, click [Change].
  • Page 75 [Browser Remote Control] Display which appears when the connection failed. It is possible to operate the display with the operation buttons displayed on the WEB browser. Click [Browser Remote Control]. The [Browser Remote Control] screen is displayed. Command port set up page Set the port number to be used with command control.

  • Page 76: Using Web Browser Control

    Using Web Browser Control Note ● To use this function, set [Network control] to [On]. Crestron Connected™ (see page 53) (Crestron Connected™ operation screen) ● The Browser Remote Control can also be displayed You can monitor or control the Display using “Crestron by entering “http://xxx.xxx.xxx.xxx/remote/”...
  • Page 77 ● ● [Tools] page [Info] page Click [Tools] on the operation page. Click [Info] on the operation page. [Control System] [Display Name] Sets the information required for the communication Displays the name of the Display. with the controller that is connected to the Display. [Mac Address] [User Password] Sets the password for the user rights in the...

  • Page 78: Usb Media Player

    USB media player Multi Media Player Connecting more than one unit using LAN cables plays back files in the USB memory simultaneously. Function description One of the multiple units becomes the parent, and the others are children. The two-unit configuration example The USB media player displays still pictures and is shown below.

  • Page 79: Preparation

    Preparation Motion pictures Extension Codec ■ Supported device Video Audio MPEG4 AVC/ MPEG-1/2 Audio Layer- ● Commercially available USB memory devices are 3(MP3) H.264 supported. (Those with security functions are not Linear PCM supported. Operation is not guaranteed.) MPEG-4 Visual ●...
  • Page 80 ■ Scenario VC-1 Maximum resolution: 1920 × 1080 Simple Maximum frame rate: 30fps The play order and time can be specified for a play file. Profile and (progressive) Save under the name (one-byte alphabetical characters) Main Profile Maximum bit rate: 20Mbps “scenario.dat”...

  • Page 81: Playing Back The Files

    Setting example Group ID (for Multi Media Player) USB memory contents It is an ID used for grouping on a network during Multi scenario.dat Media Player conditions. Introduction.jpg GroupID:Gxx : Group xx Contents_Video1.wmv ● The “xx” portion can be set from 01 to 10. Contents_Video2.wmv ●...
  • Page 82 Play contents Child side For the above setting example, the following contents USB memory contents will be played on repeat (loop). filelist.dat 1. Introduction.jpg (10 seconds) R_Introduction.jpg 2. Contents_Video1.wmv (10 seconds) R_Contents_Video1.wmv 3. Contents_Video2.wmv (20 seconds) 4. Contents_Video3.wmv (Played for the R_Contents_Video2.wmv duration of the play R_Contents_Video3.wmv...

  • Page 83: Network Environment (Multi Media Player Only)

    ■ USB memory contents check Network environment (Multi Media You can run a USB memory contents check in [USB Player only) media player settings] - [Scenario file check]. (see page ■ Example of setting up LAN connection and IP address / Subnet mask If an error is present, the information is given with the following details.

  • Page 84: Starting / Ending Media Player

    Starting / ending Media Player Resume Play function ■ After Media Player ends, the file to be played back next For Single Media Player time varies depending on the setting of [USB media Start player settings] - [Resume play]. 1. Insert USB memory for Media Player. When set to [On]: Note The file played prior to the end of Media Player starts...

  • Page 85: Data Cloning

    Data Cloning Copying the display data to the USB memory Insert the USB memory device to the Menu settings and adjusted values set on a single USB terminal of the display of data display can be copied to multiple displays using a USB copy source.

  • Page 86: Copying The Usb Memory Data To The Display

    <SETUP>. power plug again to turn the power on. ● [POWER button lock] function is only for TH-65EF1U. Select [OSD language] with press <ENTER> for over 3 seconds. The following display appears.

  • Page 87: Id Remote Control Function

    ID Remote Control Press one of <0> ‒ <9>. Sets the units digit. Function ● The steps from 3 to 5 need to be done within 5 seconds. ● Adjustable ID number range is 0 ‒ 100. You can set the remote control ID when you want to use Example: this remote control on one of several different displays.

  • Page 88: Entering Characters

    Entering characters Select Space key with , and press <ENTER>. MY █ Some settings require to enter characters. To enter text, select characters in the on-screen keyboard. Example: Entering profile names ([Memory save]) MEMORY1 █ – Delete All delete Cancel a/A/@ Space key As shown in step 3, select the characters to enter...

  • Page 89: Preset Signals

    Preset Signals This unit can display the video signals shown in the table below. ■ Video signal Scanning frequency Dot clock Corresponding signal Resolution (Dot) frequency Format* Horizontal (kHz) Vertical (Hz) (MHz) NTSC/NTSC4.43/ 720 × 480i 15.73 59.94 PAL-M/PAL60 PAL/PAL-N/SECAM 720 ×...
  • Page 90 Scanning frequency Dot clock Corresponding signal Resolution (Dot) frequency Format* Horizontal (kHz) Vertical (Hz) (MHz) 1 280 × 960 60.00 60.00 108.00 R/Y/D/H 1 280 × 960 1 280 × 960 85.94 85.00 148.50 1 280 × 1 024 63.98 60.02 108.00 R/Y/D/H...

  • Page 91: Shipping Condition

    ■ Shipping condition Unit Press <MENU (Unit)> for several times and display the [Setup] menu. It is possible to reset the following data to the factory Select [Menu display duration] with settings. , and then press and hold <ENTER Settings and set values of [Picture], [Sound], [Setup], (Unit)>...

  • Page 92: Troubleshooting

    Troubleshooting Before you call for service, determine the symptoms and make a few simple checks as shown below. Symptoms Check Picture Sound Electrical Appliances Cars / Motorcycles Interference Noisy Sound Fluorescent light Volume Normal No Sound (Check whether the mute function has been activated on the Picture remote control.) Not plugged into AC outlet...
  • Page 93 Symptoms Check Check whether [Controller ID function] is set to [On], or <ID [Controller ID function] function cannot be used. MODE> switch is set to <ON>. (see page 61) (When using ID remote controller) (When [Controller ID function] is set to [On], you need to set <ID MODE>...
  • Page 94 LCD Display panel Symptoms Check The screen will darken slightly when photos, still images of a computer or other pictures with minimal movements are The screen darkens slightly when bright pictures shown for an extended period. This is done to reduce image with minimal movements are shown.

  • Page 95: Specifications

    Specifications Connection terminals HDMI 1 HDMI 2 TYPE A Connector* × 2 Model No. Audio signal: TH-65EF1U Linear PCM (sampling frequencies - 48 kHz, TH-65EF1E 44.1 kHz, 32 kHz) TH-65EF1W DVI-D IN Power Consumption DVI-D 24 Pin × 1: 175 W Compliance with DVI Revision 1.0...
  • Page 96 IR IN Stereo mini jack (M3) × 1 IR OUT Stereo mini jack (M3) × 1 TYPE A USB connector × 1 DC 5V / 1A (USB 3.0 is not supported.) Sound Speakers 80 mm × 30 mm × 2 Audio Output 20 W [10 W + 10 W] (10 % THD) Remote Control Transmitter...

  • Page 97: Software License

    [Settings] menu of this product. At least three (3) years from delivery of this product, Panasonic will give to any third party who contacts us at the contact information provided below, for a charge no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under GPL V2.0, LGPL...
  • Page 98 Panasonic Canada Inc. 5770 Ambler Drive Mississauga, Ontario L4W 2T3 For TH-65EF1E Panasonic Testing Centre Panasonic Service Europe, a division of Panasonic Marketing Europe GmbH Winsbergring 15, 22525 Hamburg, F.R. Germany English Web Site: http://panasonic.com TP0217TS0 -PB © Panasonic Corporation 2017...
