Page 2: Table Of Contents
Pontiac Trans Sport Introduction Part Part Part Part Part Part Part Part p a r t 9 Printed in USA to Use this Manual I Seats & Restraint Systems 2 Features & Controls Comfort Controls & Audio Systems 4 Your Driving and the Road Problems on the Road 6 Service &...
Page 3 Important Notes About this Manual Please keep this manual in your Pontiac, so it will be there if you ever need it when you’re on the road. If you sell the vehicle, please leave this manual in it so the new owner can use it.
Page 4 Part 8: Customer Assistance Information This part tells you how to contact Pontiac for assistance and how to get service publications. It also gives you information on “Reporting Safety Defects’’ on page 277.
Page 5 CAUTION and NOTICE warnings in different colors or in different words. In this manual, we’ve used the familiar words that Pontiac has used for years. You’ll also see warning labels on your vehicle. They use yellow for cautions, blue for notices, and the words...
Page 6 For example, These symbols these symbols are important are used on an for you and original battery: your passengers whenever your vehicle is driven: DOOR LOCK UNLOCK PROTECT EYES BY SHIELDING FASTEN SEAT CAUSTIC BELTS BURNS ,\I/, SPARK OR FLAME COULD EXPLODE BATTERY...
Page 7 Notes...
Page 8: I Seats & Restraint Systems
H e r e you’ll find information about the seats in p u r Pontiac and how to use your safety belts properly You can also tearn about some things you should do with safety belts Seats Seats and Seat Controls...
Page 9: Seats And Seat Controls
& Seats Restraint Systems Seats and Seat Controls This section tells you about the seats-how to adjust them, take them out, put them back in, and fold them up and down. - . . 8 Manual Front Seats %dl up the lever on the front of the seat to ~nlock Slide the seat to where you vant it.
Page 10 Six- Way Power Seat (OPTION) To adjust the driver’s six-way power seat: Front Control (A): Raise the front of the seat by holding the switch up. Hold the switch down to lower the front of the seat. Center Control (B): Move the seat forward or back by holding the control to the front or back.
Page 11 Seats & Restraint Systems Reclining Front Seatbacks (CONK) Head Restraints Slide the head restraint up or down so that the top of the restraint is closest to the top of your ears. This position reduces the chance of a neck injury in a crash. On some models, the head restraints tilt forward and rearward also.
Page 12 Folding the Seatback To fold down the seatback, lift the seatback latch release while folding the seatback forward. To raise the seatback, lift the seatback latch release while raising the seatback until it locks upright. Push and pull on the seatback to check that it is locked.
Page 13 & Seats Restraint Systems Replacing the Bench Seat (CONT.) ’ 2. Push the rear hooks into’the rear floor pins, then push down onuhe two levers to lock the rear of the bench in place. Try to raise the bench seat to check that it is locked down.
Page 14 “RIGHT ONLY” seats that don’t have the built-in child restraint fit only in the right locations. “LEFT ONLY” seats that don’t have the built-in child restraint fit only in the left locations. The “CENTER OR LEFT” seat fits in the center location and in either left location.
Page 15 & Seats Restraint Systems Removing Rear Bucket Seats Removing the RIGHT ONLY Seats: 1. Lift the upper lever to fold the seatback forward. 2. Push the lower lever back so the entire seat and seatback tilt forward. Then, from behind the seat, support the top portion of the seat with one hand as you squeeze the front release bar toward the crossbar.
Page 16 2. Push down on the rear release bar. The entire seat will tilt forward. Then, from behind the seat, support the top portion of the seat with one hand as you squeeze the front release bar toward the crossbar. The seat will release from the floor pins.
Page 17 & Seats Restraint Systems Replacing Rear Bucket Seats Follow the diagram on the back of the seats to replace the seats in their proper location. The “LEFT ONLY” seats fit only in the left positions. The “RIGHT ONLY” seats fit only in the right positions. The “CENTER OR LEFT”...
Page 18: Safetybelts
Second and third row seats have been modified to allow them to fold fully upward and forward when the seats are anchored in the rear-most position. This modification improves both luggage/cargo capacity and rear seat entry/exit. Safety Belts: They’re For Everyone This part of the manual tells you how to use safety belts properly.
Page 19 & Seats Restraint Systems Safety Belts: They’re For Everyone (CONI) A few crashes are mild, and some crashes can be so serious that even buckled up a person wouldn’t survive. But most crashes are in between. In many of them, people who buckle up can survive and sometimes walk away.
Page 20 4. Put someone on it. up to speed. Then stop the vehicle. The rider doesn't stop. 6. The person keeps going until stopped by something. In a real vehicle, it could be the windshield or the instrument panel "Y. 8. or the safety belts! With safety belts, you slow down as the vehicle does.
Page 21 & Restraint Systems Seats Here Are Questions Many People Ask About Safety Belts and the Answers Won’t I be trapped in the vehicle after an accident if I’m wearing a safety belt? ,$;@& *:y.:& You could b m e --.whet er you re- wearing a safety belt or not.
Page 22: Driverposition
And there are different rules for smaller children and babies. If a child will be riding in your Pontiac, see “Children,” located later in this section. Follow those rules for everyone’s protection. First, you’ll want to know which restraint systems your vehicle has.
Page 23 & Seats Restraint Systems Lapshoulder Belt The driver has a lap-shoulder belt. Here’s how to wear properly. 1. Close and lock the door. Adjust the seat (to see how, see “Seats” in the Index) so you can sit up straight. Pick up the latch plate and pull the belt across you.
Page 24 5. To make the lap part tight, pull down on the buckle end of the belt as you pull up on the shoulder belt. ’he lap part of the belt should be worn and snug on the hips, just touching le thighs.
Page 25 & Seats Restraint Systems Lap-Shoulder Belt (CONT.) Q: What’s wrong with this? The belt is buckled in the wrong place. Q: What’s wrong with this? The belt is over an armrest. What’s wrong with this? The shoulder belt is worn under the arm.
Page 26: Supplemental Inflatable Restraint System
I ’ What’s wrong with this? The belt is twisted across the body. To unlatch the belt, just push the button on the buckle. The belt should go back out of the way. 3efore you close the door, be sure the belt out of the way.
Page 27 & Seats Restraint Systems Supplemental Inflatable Restraint System (Air Bag) (CONT.) AIR BAG Air Bag Readiness Light There is an air bag readiness light on the instrument panel, which shows “AIR BAG’ on it. The system checks for electrical malfunctions, and the light tells you if there is a problem.
Page 28 You will see this light flash for a few seconds when you turn your ignition to “Run” or “Start.” Then the light should go out, which means the system is ready. Remember, the air bag readiness light doesn’t come on when you start your vehicle, or stays on, or comes on when you are driving, your air bag system may not work properly.
Page 29 & Seats Restraint Systems How The Air Bag System Works (CONT.) What makes an air bag inflate? In a frontal impact of sufficient severity, the air bag sensing system detects that the vehicle is suddenly stopping as a result of a crash.
Page 30 Servicing Your Air Bag-Equipped Pontiac The air bag affects how your Pontiac should be serviced. There are parts of the air bag system in several places around your vehicle. You don’t want the system to inflate while someone is working on your vehicle.
Page 31: Safety Belt Use During Pregnancy
& Seats Restraint Systems Safety Belt Use During Pregnancy Safety belts work for everyone, including pregnant women. Like all occupants, they are more likely to be seriously injured if they don’t wear safety belts. A pregnant woman should wear a lap- shoulder belt, and the lap portion should be worn as low as possible throughout the pregnancy.
Page 32 Rear Seat Outside Passenger Positions Lap-Shoulder Belt The positions next to the windows have lap-shoulder belts. Here’s how to wear one properly. 1. Pick up the latch plate and pull the belt across you. Don’t let it get twisted. 2. Push the latch plate into the buckle until it clicks.
Page 33 & Seats Restraint Systems Rear Seat Outside Passenger Positions (CONI) To make the lap part tight, pull down on the buckle end of the belt as you pull up on the shoulder part. The lap part of the belt should be worn low and snug on the hips, just touching the thighs.
Page 34 To unlatch the belt, just push the button on the buckle. Center Passenger Position (Bench Seat) If your vehicle has a rear bench seat, someone can sit in the center position. Lap Belt When you sit in the center position of the bench seat, you have a lap safety belt, which has no retractor.
Page 35 & Seats Restraint Systems Lap Belt (CONK) To make the belt shorter, pull its free end as shown until the belt is snug. Buckle, position and release the same way as the lap part of a lap-shoulder belt. If the belt isn’t long enough, see “Safety Belt Extender”...
Page 36: Children
4. Position and release it the same way as the lap part of a lap-shoulder belt. If the belt isn’t long enough, see “Safety Belt Extender” at the end of this section. Make sure the release button on the buckle is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.
Page 37: Smaller Children And Babies
Seats & Restraint Systems Smaller Children and Babies...
Page 38: Built-In Child Restraint
Built-Zn Child Restrain, (OPTION) If you have a rear seat with the optional built-in child restraint, refer to this pictun to become familiar with the parts of each child seat and 5-point harness listed below: A. Child Head Restraint B. Head Restraint Release Strap C.
Page 39 & Seats Restraint Systems Built-In Child Restraini (COPIT.) make sure that the child is tall enough! ompare the child’s standing height to the op surface of the bucket seat, which is .bout 29 inches (74 cm) from the floor. - 3 8 The booster seat can be used by children wer 40 pounds (1 8 kg) or whose .boulders are above the shoulder belt...
Page 40 To Use the Built-in Child Restraint Pull the child head restraint release strap and raise the head restraint until hear the latch click. Lower the child restraint cushion. Before placing. the child in the child restraint, add slack to the shoulder hamess.
Page 41 If an object is in the opening, see your Pontiac dealer for service before using the child restraint. 6 Fasten the two halves of the shoulder harness clip together and put it two to three inches (5-8 cm) below the child’s chin.
Page 42 Pull the shoulder harness adjustment strap (grey) firmly until the shoulder harness straps are snug against the child’s shoulders. To release the child from the harness, separate the halves of the shoulder harness clip. Then push the red releast button in the buckle. Move the shoulder harness straps to the side an( remove the child.
Page 43 & Seats Restraint Systems T o Store the Built-ln Child Sestraint (CQNT.);, !. Unlatch the child head restraint by pulling the release.strap. Lower the head restraint and press firmly into the seatback until you hear the latch click. To Use as a Booster Seat 1.
Page 44: Child Restraints
Store the 5-point child restraint harness behind the removable pad. The pad is held in place by fastener strips. Place the child on the cushion and fasten the vehicle lap-shoulder belt around the child. To release the child from the vehicle lap-shoulder belt, push the red button on the buckle.
Page 45 Pontiac dealer to put it in for you. If you want to install an anchor bracket yourself, your dealer can tell you how to do it.
Page 46 Securing a Chi-ld Restrain4 an Outside Position bu’ll be using the lap-shoulder belt. See le earlier section about the top strap if le child restraint has one. Put the restraint on the seat. Follow the instructions for the child restraint. Secure the child in the child restraint as the instructions say.
Page 47 & Seats Restraint Systems Securing a Child Restraint Outside Position (CON7J 5. To tighten the belt, pull up on the shoulder belt while you push down on the child restraint. 6. Push and pull the child restraint in different directions to be sure it is secure.
Page 48 1. Make the belt as long as possible by tilting the latch plate and pulling it along the belt. 2. Put the restraint on the seat. Follow the instructions for the chi1.d restraint. Secure the child in the child restraint as the instructions say.
Page 49 & Seats Restraint Systems Securing a Child Restraint in the Center Seat Positior: (Bucket Seat) You’ll be using the lap belt. See the earlier section about the top strap if the child restraint has one. 1. Put the restraint on the seat. Follow the instructions for the child restraint.
Page 50: Largerchildren
6. To tighten the belt, feed back into the retractor while you push down on the child restraint. 7. Push and pull the child restraint in different directions to be sure it is secure. To remove the child restraint, just unbuckle the vehicle’s safety belt and let go back all the way.
Page 51 & Seats Restraint Systems Larger Children (CONT.) Children who aren’t buckled up can strike other people who are. What if a child is wearing a lap-shoulder belt, but the child is so small that the shoulder belt is very close to the child’s face or neck? Move the child toward the center of the vehicle, but be sure that the shoulder belt still is on the child’s...
Page 53: Replacing Seat And Restraint System Parts After A Crash
& Seats Restraint Systems Replacing Seat and Restraint System Parts After a Crash (CONT.) What’s wrong with this? The belt is torn. Torn or frayed belts may not protect you in a crash. They can rip apart under impact forces. If a belt is tom or frayed, get a new one right away.
Page 54: Features & Controls
H e r e you can learn about the many standard and optional features on your Pontiac. and information on starting. shifting and braking Atso explained are the instrument panel and the warning systems that tell you if everything is working properly and what to do if you have a problem .
Page 55 If you lose your keys, you’ll be Ae to have new ones made easily using lese plugs. NOTICE: Your Pontiac has a number of new features that can help prevent theft. But you can have a lot of trouble getting into your vehicle if you ever lock your keys inside.
Page 56 Front Doors Door Locks There are several ways to lock and unlock your vehicle. From the Outside: ' ? < Use your key or remote keyl& door entry transmitter, if your vehicle his this option.
Page 57 & Features Controls Door Locks (CONT.) From the Inside: To lock the door, slide the locking lever rearward. To unlock the door, slide the locking lever forward. Power Door Locks (OPTION) From the outside of either front door, the door key unlocks all doors and the liftgate.
Page 58 To lock the liftgate, use the power door lock switch, the optional remote keyless entry transmitter, or lock manually by turning the lock counterclockwise. Automatic Door Locks (OPTION) With this feature you can unlock all of the doors from the outside by holding the key in the unlock position for one second.
Page 59 Then get out and close the door. Remote Keyless Entry (OPTION) If your Pontiac has this option, you can lock and unlock your doors and liftgate from up to 30 feet (9 m) away using the key chain transmitter supplied with your vehicle.
Page 60 Operation The driver’s door will unlock and the interior lights will go on when pressed (see “Illuminated Entry System” later in this section). If pressed again within five seconds, all doors and the liftgate will unlock. All doors and the liftgate will lock when is pressed.
Page 61 & Features Controls Matching Transmitterfs) To Your Vehicle Each key chain transmitter is coded to prevent another transmitter from unlocking your vehicle. If a transmitter is lost or stolen, a replacement can be purchased through your dealer. Remember to bring the remaining transmitter with you when you go to your dealer.
Page 62 When you park your Pontiac and open the driver’s door, you’ll hear a chime reminding you to remove your key from the ignition and take it with you. Always do this.
Page 63 & Features Controls Parking at Night Park in a lighted spot, close all windows and lock your vehicle. Remember to keep your valuables out of sight. Put them in a storage area, or take them with you. Parking Lots If you park in a lot where someone will be watching your vehicle, it’s best to lock it up and take your keys.
Page 64 Sliding Door Lock From inside the vehicle, lock the sliding door by moving the manual locking lever down. Unlock by moving the lever up. If you have the optional power door locks, the sliding door lock has a delay feature. See “Power Door Locks” in the Index.
Page 65 & Features Controls Power Sliding Door (CONE) The sliding door must be unlocked for the power sliding door to operate. The key does not have to be in the ignition. To help avoid accidental operation of the sliding door, disable the power sliding door by placing the power sliding door enable switch in the “OFF”...
Page 66 Objects caught in the path of the sliding door may be damaged. Make sure the door path is clear before closing the door. To manually .open the power sliding door when the sliding door enable switch is in the “ON” position, pull the inside or outside latch release and let go;...
Page 67 Controls Door Siding Child Security Lock Your Pontiac may be equipped with a sliding door child security lock that helps prevent young children or other passengers from opening the sliding door from the inside. If you have the optional power sliding door, you can override the security lock by pressing either “PWR DOOR’...
Page 68 2. Then open the door from the outside. With Optional Power Sliding Door 1. Slide the power sliding door enable switch to the “ON” position. 2. Press either “PWR DOOR” (Power Door) switch. You should let adults and older children know how the security lock works, and how to cancel the lock.
Page 69 & Features Controls Raising the Lij’tgate Open the liftgate using the handle recessed above the license plate. Then, step back and the liftgate will rise by itself. Lights in the liftgate will come on, illuminating the rear cargo area (see “Interior Lights”...
Page 70 New Vehicle “Break-In” NOTICE: Your modern Pontiac doesn’t need an elaborate “break-in.’’ But it will perform better in the long run if you follow these guidelines: Don’t drive at any one speed fast or slow for the first 500 miles (804 km). Don’t make full-throttle starts.
Page 71 To restart when you’re already moving, use “N” (Neutral) only. NOTICE: Don’t try to shift to “P” (Park) if your Pontiac is moving. If you do, you could damage the transaxle. Shift to “P” (Park) only when your vehicle is stopped.
Page 72 If you ever have to have your vehicle towed, see the part of this manual that tells how to do it without damaging your vehicle. See “Towing Your Pontiac” in the Index. To start your 3.8 Liter engine: 1. Without pushing the accelerator pedal, turn your ignition key to “Start.”...
Page 73 If you ever have to have your vehicle towed, see the part of this manual that tells how to do it without damaging your vehicle. See “Towing Your Pontiac” in the Index. Driving Through Deep Standing Water NOTICE:...
Page 74 Instead of trying to list everything here, we ask that you contact a Pontiac dealer in the area where you’ll be parking your vehicle. The dealer can give you the best advice for that particular area.
Page 75 & Features Controls Park (Park): This locks your front wheels. It’s the best position to use when you start your engine because your vehicle can’t move easily. Index. if) you’re pulling a trailer, see “Towing Trailer’’ in the Index. Reverse R (Reverse): Use this gear to back up.
Page 76 Neutral d (Neutral): In this position, your engine loesn’t connect with the wheels. To estart when you’re already moving, use ‘N” (Neutral) only. Also, use “N” when ’our vehicle is being towed. NOTICE: Damage to your transaxle caused by shifting out of (Park) or “N”...
Page 77 & Features Controls Forward Gears (CONT.) NOTICE: This Notice applies only if you have the 3.8L V6 engine and the automatic Overdrive transaxle. If your vehicle is so equipped, and if it se’erns to start up rather slowly, or if it seems not to shift gears as you go faster, something may be wrong with a transaxle system sensor.
Page 78 1 (First Gear): This position gives you even more power (but lower fuel economy) than “2”. You can use very steep hills, or in deep snow or mud. If the selector lever is put in “I”, the transaxle won’t shift into first gear until the vehicle is going slowly enough.
Page 79 & Features Controls Shifting Into P (Park) 1. Hold the brake pedal down with your right foot and set the parking brake. e o . 7 8 2. Move the shift lever into “P” (Park) position like this: Pull the lever toward you. Move the lever up as far as it will go.
Page 80 Leaving Your Vehicle With the Engine Running If you have to leave your vehicle with the engine running, be sure your vehicle is in “P” (Park) and your parking brake is firmly set before you leave it. After you’ve moved the shift lever into the “P’ (Park) position, hold the regular brake pedal down.
Page 81 & Features Controls Engine Exhaust Running Your Engine Parking Over Things While You’re Parked That Burn It’s better not to park with the engine running. But if you ever have to, here are some things to know.
Page 82 Follow the proper steps to be sure your vehicle won’t move. See “Shifting Into ‘P’ (Park)” in the Index. If you are pulling a trailer, see “Towing a Trailer” in the Index. Horn You can sound the horn by pressing the horn symbols on your steering wheel.
Page 83 & Features Controls Side Window Latches The rear of the side windows swings open. To Open: Pull the latch forward to release then swing the window outward and press the center of the latch to secure the window in the open position. To Close: Pull the center of the latch forward and then close the latch.
Page 84 Turn Signal and Lane Change Indicator The turn signal has two upward (for Right) and two downward (for Left) positions. These positions allow you to signal a turn or a lane change. To signal a turn, move the lever all the way up or down.
Page 85 & Features Controls Cruise Control (OPTION) With Cruise Control, you can maintain a speed of about 25 mph (40 km/h) or more without keeping your foot on the accelerator. This can really help on long trips. Cruise Control does not work at speeds below about 25 mph (40 kmh).
Page 86 Push in the set button at the end of the lever and release 4. Take your fo-ot off the accelerator pedal. To Resume a Set Speed Suppose you set your Cruise Control at a desired speed and then you apply the brake.
Page 87 & Features Controls To Increase Speed While Using Cruise Control (CONT.) Here’s the second way to go to a higher speed: Move the Cruise switch from “ON” to “RESUME/ACCEL”. Hold there until you get up to the speed you want, and then release the switch.
Page 88 Headlights 'ush the switch to turn on: Parking Lights Side Marker Lights Taillights Instrument Panel Lights lull the switch to turn off the lights. Operation of Lights Although your vehicle's lighting system (headlights, parking lights, fog lamps, side marker lights and taillights) meet all applicable federal lighting requirements, certain states and provinces may apply their own lighting regulations that may...
Page 89 & Controls Features Lights On Reminder If you turn the ignition key to the off or Lock position while leaving the lights on, you will hear a warning chime. Daytime Running Lights (Canada Only) The Canadian Federal Government has decided that Daytime Running Lights (DRL) are a useful feature, in that DRL can make your vehicle more visible to pedestrians and other drivers during...
Page 90 interior Lights Control Slide the lower control up to turn on the interior lights, down to turn them off. Your standard front overhead console control can be overridden by the interior lights override switch located in the console. See “Interior Lights Override Switch”...
Page 91 & Features Controls Windshield Wipers The windshield wiper and washer controls are located to the right of the instrument cluster. For a Single Wiper Cycle: Press the switch marked “MIST” and release. For more cycles, press and hold the switch. For Pulse Delay Wiper Cycles: The pulse delay cycle system allows you to set the wiper speed as slow as 20 seconds...
Page 92 To Turn the Wipers Off: Slide the upper control to the “OFF” position. Heavy snow or ice can overload your wiper motor. A circuit breaker will stop the motor until it cools. Clear away snow or ice to prevent an overload. Windshield Washer To wash your windshield, press and hold the windshield washer switch.
Page 93 & Features Controls Rear Window Wiper and Washer To Use Your Rear Wiper: Slide the lower control to for steady wiping cycles. For a Delayed Wiper Cycle: Slide the lower control to “DEL”. To Wash the Rear Window: Slide the lower control to and hold it.
Page 94 Interior Lights Your vehicle has two overhead dome lights-one in the center of the passenger compartment and one in the rear. If you have the optional rear climate control, you will not have a center dome light. The rear dome light has an on-off switch; the center dome light has no switch.
Page 95 & Features Controls Rear Reading Lights The rear dome light also has two reading lights. To turn on either reading light, press the switch next to it. Accessory Power Outlet The power outlet is located in the rear compartment on the driver’s side. To open, slide the latch down and remove the cover.
Page 96 Air Inflator System (OPTION) Your vehicle may be equipped with an air inflator. With you can inflate things like air mattresses and basketballs, and you can also use it to bring your tires up to the proper pressure. The air inflator is located in the rear compartment on the driver’s side.
Page 97 & Features Controls Air Inflator System (CONK) Your air inflator will automatically shut off after about 10 minutes. To reset, press the “ON” switch again. Don’t run your air inflator for longer than 30 minutes at one time. If you do, you may damage the system.
Page 98 Manual Remote Control Mirrors Both the driver and passenger side outside mirrors can be adjusted with the control lever on each door so that you can just see the side of your vehicle when you are sitting in a comfortable driving position. Both outside mirrors can be folded forward or rearward.
Page 99 & Features Controls Sun Visors To block out glare, you can swing down the visors. You can also remove them from the center mount and swing them to the side. If the visors swing too easily, tighten the screw on the rear of the visors. Glove BoxlStorage Compartment Your vehicle has a storage compartment...
Page 100 To open the glove box, pinch the latch release. The fuse panel is located inside the glove box door. See “Fuses & Circuit Breakers’ in the Index. Cup Holders1 AshtraylLighter Two cup holders, an ashtray and a lighter are located in the center instrument panel console.
Page 101 & Features Controls Locking Storage Bin At the base of the center instrument panel console is a storage bin. Use the door key to lock and unlock it. To open the bin, pinch the latch release. You may have a coinholder inside the storage bin.
Page 102 Convenience Net (OPTION) 'he optional convenience net is designed help keep small loads, like grocery lags, from falling over during sharp turns r quick stops and starts. nstall the convenience net at the rear of our vehicle, just inside the liftgate. ittach the upper loops to the posts on ither side of the liftgate opening (the lbel on the net should be in the upper...
Page 103 & Features Controls Luggage Carrier (OPTION) If you have the optional luggage carrier, you can load things on top of your vehicle. The luggage carrier has slats and side rails attached to the roof, sliding crossrails and places to use for tying things down.
Page 104 Don’t exceed the maximum vehicle capacity when loading your Pontiac. For more information on vehicle capacity and loading, see “Loading Your Vehicle’’ in the Index. To prevent damage or loss of cargo as you’re driving, check now and then to make sure the luggage carrier and cargo are still securely fastened.
Page 105 & Features Controls Electronic Level Control (OPTION) With this option, the rear of the vehicle automatically adjust to changes in load weight. (See “Loading Your Vehicle” in the Index.) You may hear the compressor operating when you load or unload your vehicle, and periodically as the system self-adjusts.
Page 106 I’ The Instrument Panel-Your Information System 3ur instrument panel is designed to let know at a glance how your vehicle is nning. You’ll know how fast you’re jing, how much fuel you’re using, and any other things you’ll need to drive fely and economically.
Page 107 & Features Controls Vents Parking Brake Pedal Glove Compartment And Fuse Center...
Page 108 1. HVAC Controls 2. Rear Window Defog (Opt.) Radio 4. Traction Control Switch (Opt.) Courtesy Lamp Override 6. Cigar Lighter 7. Rear HVAC Controls (Opt.) 8. Open Storage Area 9. Ashtray 10. Locking Storage Bin 11. Bucket, Removes For Cleaning 12.
Page 109 & Controls Features Engine Instrument Panel Cluster four cluster includes indicator warning ights and gages that are explained on the ollowing pages. 1. Traction Control “ON” 2. Service Air Bag 3. Service Engine Soon 4. Sliding Door Ajar Symbol Liftgate Ajar 6.
Page 110 (used in the U.S.) or kilometers (used in Canada). Tamper Resistant Odometer Your Pontiac has a tamper resistant odometer. If you see silver lines between the numbers, you’ll know that someone has probably tried to turn it back, so the numbers may not be true.
Page 111 & Features Controls Trip Odometer The trip odometer can tell you how far your vehicle has been driven since you last set to zero. To set to zero, push the reset button located above the fuel gage. Warning Lights, Gages and Indicators This section describes the warning lights and gages that may be on your vehicle.
Page 112 Fuel Gage Your fuel gage tells you about how much fuel you have left, when the ignition is on. When the gage first indicates “E” (Empty), you still have a little fuel left, but you should get more soon. Here are four things that some owners ask about.
Page 113 & Features Controls Oil Pressure Indicator ( 3 . I L V6 Engine) Your vehicle is equipped with an oil pressure indicator rather than an oil pressure gage. Your oil pressure indicator lets you know when you may have a problem with your engine oil pressure.
Page 114 Readings in either red zone indicate a possible problem with your charging system. Have your Pontiac serviced immediately. When the engine is not running but the ignition is on (in the...
Page 115 Features Controls Brake System Warning Light Your Pontiac’s hydraulic brake system is divided into two parts. If one part isn’t working, the other part can still work and stop you. For good braking, though, you need both parts working well.
Page 116 Then start the engine again to reset the system. If the light still stays on, or conles again while you’re driving, your Pontiac needs service. If the light not flashing and the regular brake system warning light isn’t on. you still have brakes, but you don’t have anti-lock...
Page 117 & Features Controls Traction Control System Warning Light (OPTION: 3800 V6 ENGINE) The “TCS” (Traction Control System) warning light means that the system is not working. The “TCS” warning light may come on if your brakes overheat. This means that your traction control system has temporarily shut down to allow the brakes to cool.
Page 118 NOTICE: If you keep driving your vehicle with this light on, after a while^ the emission controls won’t work as well, your fuel economy won’t be as good and your engine may not run as smoothly. This could lead to costly repairs not covered by your warranty.
Page 119 & Features Controls Sliding Door Ajar Warning Light With the optional power sliding door, the sliding door ajar symbol on your instrument panel will come on if your sliding door is not completely closed. If you shift the transaxle out of “P” (Park while the sliding door is open or i n the process of closing, and the power sliding door enable switch is in the “ON”...
Page 120 I n this part you’ll find out how to operate the comfort control systems and audio systems offered with your Pontiac Be sure to read about the particular system supplied with your vehicle Comfort Controls Climate Control System Quick Reference Guide .
Page 121: Part 3 Comfort Controls & Audio Systems
Comfort Controls & Audio Systems Climate Control System Quick Reference Guide Your Climate Control System has been designed to provide an expanded range of comfort options. Use ,this diagram as a quick reference guide for operating the controls. For a complete explanation of this system, see “Climate Control System”...
Page 122 Heater and Ventilation System Your vehicle’s heater will work best if you keep your windows closed. Your vehicle also has flow-through ventilation, described later in this section, to bring outside air into your vehicle. If you have the optional engine coolant heater and use during cold weather, 0°F 18 “C) or lower, your heating system...
Page 123 Comfort Controls & Audio Systems Heater and Ventilation System (CONK) If your vehicle is equipped with seats in the third row, you will have a rear air outlet and a rear fan. To maximize air flow to the rear of your vehicle, place the left second row bucket seat in the forward position (see “Adjusting Rear Seats”...
Page 124 (OPTION) Your vehicle’s heater and air conditioner work best if you keep your windows closed. Your vehicle also has flow-through ventilation, described later in this section, to bring outside air into your vehicle. If you have the optional engine coolant heater and use it during cold weather, 0°F C>...
Page 125 Comfort Controls Directional Controls RECIRC (Recirculate): Press to get maximum cooling or quick cool-down on very hot days. This setting recirculates much of the air inside your vehicle. It should not be used for long periods of time because the air may become too cold and dry.
Page 127 Comfort Controls & Audio Systems Rear Climate Control System (OPTION) (CONT.) will be directed to the rear of the vehicle :hrough the overhead and third-row air -0nditioning outlets. If you select “A/C” in the “LOWER” mode, cooled air will be Sirected through the rear floor vent unless the temperature control lever is set approximately 30% from the full cold...
Page 128 Rear Fan-Rear Control This feature allows passengers riding in the rear seats to control the flow of air to the rear area of the vehicle. The rear control switch is located on the armrest next to the second row seat, left position.
Page 129 Comfort Controls & Audio Systems Rear Window Defogger (OPTION) Press “R. DEF” (Rear Defog) to warm the defogger grid on the rear window. The indicator light will glow while the rear window defogger is operating. The rear window defogger will turn off automatically after about 10 minutes of use.
Page 130 Ventilation Tips: Keep the hood and front air inlet free of ice, snow, or any other obstruction (such as leaves). The heater and work ddffoster will far better, reducing chance of fogging the inside of your windows. Hearing damage from loud noise is almost undetectable until it is too late.
Page 131 Comfort Controls & Audio Systems Audio Systems (CONT) NOTICE: Before you add any sound equipment to your vehicle like a tape player, CB radio, mobile telephone or two-way radio sure’you can add what you want. If you can, it’s very important to do it properly.
Page 132 Stereo AM/FM Radio The digital display indicates information on time or radio station frequency, the AM or FM radio band, whether the station is in stereo, and other radio functions. Upper Knob (PWRoVOL): This knob does four things: Turn it to turn the system on and off (your ignition must be on).
Page 133 Comfort Controls AM/FM Stereo Radio (C0;NT.) SEEK A Press to seek and stop on the next station higher or lower on the radio band. You can also use the “SEEK” buttons to scan radio stations up or down the AM or FM bands.
Page 134 AMIFM Stereo with Cassette Player The digital display indicates information on time or radio station frequency, the AM or FM radio band, whether the station is in stereo, and other radio functions. Upper Knob (VOL): This knob does four things: Turn it to turn the system on and off (your ignition must be on).
Page 135 Comfort Controls & Audio Systems AM/FM Stereo with Cassette Player (CONK) TREBLE: Slide this lever up to increase treble, or down to decrease it. If a station is weak or noisy, reduce the treble. BASS: Slide this lever up to increase bass, or down to decrease it.
Page 136 To Play a Cassette Tape: With the power switch on, insert.a tape into the cassette door. Do not use tapes that are longer than 45 minutes on each side. When the right indicator arrow is lit, selections listed on the bottom side of the cassette are playing.
Page 137 Comfort Controls AIWIFM Stereo with Cassette Player and Graphic Equalizer The digital display indicates information on time or radio station frequency, the AM or FM radio band, whether the station is in stereo, and other radio functions. PWR (Power): Press to turn the unit on and off when the ignition is on.
Page 138 stop on the next station lower on the band. RCL (Recall): Press to alternate the display between the time and the selected station and radio band. EQUALIZER: Boost the bass, emphasize a voice in a song, brighten the treble -your equalizer gives you freedom to adjust five separate frequencies of sound to your individual taste.
Page 139 Comfort Controls AMIFM Stereo with Cassette Player and Graphic Equalizer (CONT.) To Play a Cassette Tape: Press “PWR” to turn the radio on. The radio will play until a cassette is pushed into the cassette entry door (the tape side goes in first).
Page 140 AM/FM Stereo with Compact Disc Player and Graphic Equalizer The digital display indicates information on time or radio station frequency, the, AM or FM radio band, whether the station is in stereo, and other radio functions. PWR (Power): Turns the unit on and off when the ignition is on.
Page 141 Comfort Controls AM/FM Stereo with Compact Disc Player and Graphic Equalizer (CONT.) FADE: The control ring behind the lower knob adjusts the front/rear speaker balance. 4 SEEK b: Press to seek and stop on the next station higher or lower on the radio band.
Page 142 If the disc comes back out and/or “Err” appears on the display: The disc may be upside down. The disc may be dirty, scratched or wet. There may be too much moisture in the air (wait about one hour and try again).
Page 143 Comfort Controls & Audio Systems CD Player Anti-Theft Feature (CONI) To Set the Anti-Theft System: 1. Write down any six-digit number and keep it in a safe place. 2. Turn the ignition to the Accessory or Run position. Press the “PWR” button to turn the radio off.
Page 144 Disabling the Anti-Theft System: 1. Press the “1” and “4” buttons together for five seconds with ignition on and radio power off. The display will show “SEC”, indicating the unit is in the secure mode. (If appears on -” “- the display, the anti-theft system has already been disabled.) 2.
Page 145 Comfort Controls Steering Wheel Touch COntrOlS (OPTION) (CONI) SEEK: Each time you press an up or down arrow on “SEEK”, you will tune in the next station up or down the AM or FM radio band. When listening to a cassette tape or compact disc, you can change to the previous or next selection by pressing the “SEEK”...
Page 146 Care of Your Cassette Tape Player A tape player that is not cleaned regularly can cause reduced sound quality, ruined cassettes, or a damaged mechanism. Cassette tapes should be stored in their cases away from contaminants, direct sunlight, and extreme heat. if they aren’t, they may not operate properly or cause failure of the tape player.
Page 147 Comfort Controls Integrated Roof Antenna Your state-of-the-art integrated roof antenna is not visible. It is located between the roof and headliner of your vehicle, covering the entire roof area frorr the rear edge of the front doors to the liftgate. &...
Page 148 H e r e YOU’II find information about driving on different kinds of roads and in varying weather conditions We’ve also included many other useful tips on driving Your Driving ..........Defensive Driving .
Page 149 The best advice anyone can give about driving is: Drive defensively. Please start with a very important safety device in your Pontiac: Buckle up. (See “Safety Belts” in the Index.) Defensive driving really means “be ready for anything.” On city streets, rural roads, or freeways, it means “always expect the...
Page 150 According to the American Medical Association, a 180-pound (82 kg) person (355 who drinks three 12-ounce bottles of beer in an hour will end up with a BAC of about 0.06 percent. The person would reach the same BAC by drinking three 4-ounce (120 ml) glasses of wine or three mixed drinks if each had 1 ounces (45 ml) of a liquor like whiskey,...
Page 151 Your Driving and the Road Drunken Driving (CONT.) approaching 0.05 percent, and that the effects are worse at night. All drivers are impaired at BAC levels above 0.05 percent. Statistics show that the chance of being in an accident increases sharply for drivers who have a BAC of 0.05 percent or above.
Page 152 Once the power assist is used up, it may take longer to stop and the brake pedal will be harder to push. Anti-Lock Brakes (ABS) Your Pontiac has an advanced electmnic braking system that will help prevent skidding.
Page 153 Driving and the Road Your Anti-Lock Brakes (ABS) (CONT) When you start your vehicle, or when you begin to drive away, you may hear a momentary motor or clicking noise. And you may even notice that your brake pedal moves a little while this is going on.
Page 155 Your Driving and the Road Traction Control System (Option: 3800 V6 Engine) (CONI) The traction control system automatically comes on whenever you start your vehicle. To limit wheel spin, especially in slippery road conditions, you should always leave the system on. But you can turn the traction control system off if you ever need to.
Page 156 Suppose you’re steering through a sharp curve. Then you suddenly accelerate. Both control systems steering and acceleration have to do their work where the tires meet the road. Unless you have traction control and the system is on, adding the sudden acceleration can demand too much of those places.
Page 157 Your Driving and the Road Steering in Emergencies (CONT.) Your Pontiac can perform very well in emergencies like these, First apply your brakes. It is better to remove as much speed as you can from a possible collision. Then steer around the problem, to the left or right depending on the space available.
Page 158 Watch for traffic signs, pavement markings, and lines. If you can see a sign up ahead that might indicate a turn or an intersection, delay your pass. broken center line usually indicates it’s all right to pass (providing the road ahead is clear). Never cross a solid line on your side of the lane or a double solid line, even if the road seems empty of...
Page 159 “overdriving” those conditions. But skids are always possible. The three types of skids correspond .to your Pontiac’s three control systems. In the braking skid your wheels aren’t rolling. In the steering or cornering slud, too much speed or steering in a curve causes tires to slip and lose cornering force.
Page 160 ’ Since you can’t see as well, you may need to slow down and keep more space between you and other vehicles. Slow down, especially on higher speed roads. Your headlights can light up only so much road ahead. In remote areas, watch for animals. a If you’re tired, pull off the road in a safe place and rest.
Page 161 Your Driving and the Road Driving in the Rain (CONE) The heavier the rain, the harder it is to see. Even if your windshield wiper blades are in good shape, a heavy rain can make it harder to see road signs and traffic signals, pavement markings, the edge of the road, and even people walking.
Page 162 Hydroplaning usually happens at higher speeds. There just isn’t a hard and fast rule about hydroplaning. The best advice is to slow down when it is raining. Some Other Rahy Weather Tips Turn on your low-beam headlights not just your parking lights to help make you more visible to others.
Page 163 Your Driving and the Road Freeway Driving Mile for mile, freeways (also called thruways, parkways, expressways, turnpikes, or superhighways) are the safest of all roads. But they have their own special rules. The most important advice on freeway driving is: Keep up with traffic and keep to the right.
Page 164 Pontiac deaierships all across North America. They’ll be ready and willing to help if you need it. Here are some things you can check before a trip: Windshield Washer Fluid: Is the reservoir full? Are all windows clean...
Page 165 Your Driving and the Hill and Mountain Roads Driving on steep hills or mountains is different from driving in flat or rolling terrain. If you drive regularly in steep country, or if you’re planning to visit there, here are some tips that can make your trips safer and more enjoyable.
Page 167 Your Driving and the Road Driving on Snow or Ice Most of the time, those places where your tires meet the road probably have good traction. However, if there is snow or ice between your tires and the road, you can have a very slippery situation.
Page 168 If You’re Caught in a Blizzard If you are stopped by heavy snow, you could be in a serious situation. You should probably stay with your vehicle unless you know for sure that you are near help and you can hike through the snow. Here are some things to do to summon help and keep yourself and your passengers safe: Turn on your hazard flashers.
Page 169 Pontiac dealer for important information about towing a trailer with your vehicle. Your vehicle can tow a trailer. To identify...
Page 170 That’s the reason for this section. In it are many time-tested, important trailering tips and safety rules. Many these are important for your safety and that of your passengers. please read this section carefully before you pull a trailer. Load-pulling components such as the engine, transaxle, wheel assemblies, and tires are forced to work harder against the drag...
Page 171 You can ask your dealer for our trailering information or advice, or you can write u Customer Assistance Center Pontiac Division One Pontiac Plaza Pontiac, MI 48340-2952 In Canada, write to: General Motors of Canada Limited, Customer Assistance Center, 1908 Colonel Sam Drive, Oshawa, Ontario L1H 8P7.
Page 172 Total Weight on Your Vehicle’s Tires Be sure your vehicle’s tires are inflated to the limit for cold tires. You’ll find these numbers on the Certification label at the rear edge of the driver’s door Certificationnire label at the edge of the driver’s door or see “Tire Loading”...
Page 173 Your Driving and the Road Trailer Brakes [f your trailer weighs more than 1,000 pounds (450 kg) loaded, then it needs its own brakes and they must be adequate. Be sure to read and follow the instructions for the trailer brakes so you’ll be able to install, adjust and maintain them properly.
Page 174 Passing You’ll need more passing distance up ahead when you’re towing a trailer. And, because you’re a good deal longer, you’ll need to go much farther beyond the passed vehicle before you can return to your lane. Backing Up Hold the bottom of the steering wheel with one hand.
Page 175 Driving and the Road Your Parking on Hills You really should not park your vehicle, with a trailer attached, on a hill. If something goes wrong, your rig could start to move. People can be injured, and both your vehicle and the trailer can be damaged.
Page 176: Part 5 Problems On The Road
H e r e you’ll find what to do about some problems that occur on the road Hazard Warning Flashers ........... . . Jumpstarting TowingYourPontiac Engine Overheating...
Page 177 Problems on the Road Hazard Warning Flashers Your hazard warning flashers let you warn others. They also let police know you have a problem. Your front and rear turn signal lights will flash on and off. But they won’t flash if you‘re braking. Your hazard warning flashers switch is the steering column, below the ignition switch.
Page 178 Jump Starting If your battery has run down, you may want to use another vehicle and some jumper cables to start your Pontiac. But please follow the steps below to do it safely. On vehicles equipped with the optional power sliding door, a low voltage battery may cause the system to become inoperative.
Page 179 If they are, it could cause a ground connection you don’t want. You wouldn’t be able to start your Pontiac, and the bad grounding could damage the electrical systems. You could be injured if the vehicles roll. Set the parking brake firmly on each vehicle.
Page 180 Your Pontiac has a remote positive jump starting terminal. The terminal is in the red box on the same side of the engine compartment as your battery. You should always use the remote positive terminal instead of the positive terminal on your battery.
Page 181 Problems on the Road To Jump Start Your Pontiac: (CONT.) Connect the red positive cable to terminal of the vehicle the positive with the dead battery. Use a remote positive terminal if the vehicle has one. Don’t let the other end touch metal.
Page 182 Towing Your Pontiac 'ry to have a GM dealer or a professional )wing service tow your Pontiac. The sua1 towing equipment is: A) Sling-type tow truck B) Wheel-lift tow truck C) Car carrier.
Page 183 Problems on the Road Towing Your Pontiac (CONK) When you call, tell the towing service: That your vehicle cannot be towed from the front with sling-type equipment. That your vehicle has front-wheel drive. The make, model, and year of your vehicle.
Page 184 Towing from the Front-Vehicle Hook-up Before hooking up to a tow truck, be sure to read all the information on “Towing Your Pontiac” earlier in this section. NOTICE: Do not tow with sling-type equipment or fascia/fog light damage will occur. Use wheel-lift or car carrier equipment.
Page 185 9ear-Vehicle Hook-up 5efore hooking up to a tow truck, be sure read all the information on "Towing lour Pontiac" earlier in this section. 1 Attach T-hook chains on both sides in the slotted holes in the frame rails just ahead of the rear wheels.
Page 186 Position the lower sling crossbar directly under the rear bumper. No 4x4 wood beam is needed. Attach a separate safety chain around the end of each .axle inboard of the spring. 4. Be certain your vehicle is towed no fasteT than 35 mph (55 km/h) and no farther than...
Page 187 Road Problems on Engine Overheating will find a coolant temperature gage an your Pontiac’s instrument panel. See “Coolant Temperature Gage” in the [ndex. /s Coming From If Sfeam Your Engine NOTICE: If your engine catches fire because you keep driving with no coolant, your vehicle can be badly damaged.
Page 188 If No Steam Is Coming From Your Engine If you get the overheat warning but see or hear no steam, the problem may not be too serious. Sometimes the engine can get a little too hot when you: Climb a long hill on a hot day. Stop after high speed driving.
Page 189 Problems on the Road The coolant level should be at or above :he “FULL HOT” mark. If isn’t, you nay have a leak in the radiator hoses, leater hoses, radiator, water pump or somewhere else in the cooling system. Cooling System (CONT.)
Page 190 NOTICE: Engine damage from running your engine without coolant isn’t covered by your warranty. If there seems to be no leak, check to see if the electric engine fan is running. If the engine is overheating, the fan should be running.
Page 191 Problems on the Road to Add Coolant to the Radiator I. You can remove the radiator pressure cap when the cooling system, including the radiator pressure cap and upper radiator hose, is no longer hot. Turn the pressure cap slowly to the left until it first stops.
Page 192 If you hear a hiss, wait for that to stop. A hiss means there is still some pressure left. Then keep turning the pressure cap, but now push down as you turn it. Remove the pressure cap. Fill the radiator with the proper mix, up to the base of the filler neck.
Page 193 Problems on the Road 5. Put the cap back on the coolant recovery tank, but leave the radiator pressure cap off. 6. Start the engine and let run until you can feel the upper radiator hose gettinl hot. Watch out for the engine fan(s). 7.
Page 194 8. Then replace the pressure cap. Be sure the arrows on the pressure cap line up like this. a Tire Goes Flat It’s unusual for a tire to “blow out” while you’re driving, especially if you maintain your tires properly. If air goes out of a tire, it’s much more likely to leak out slowly.
Page 195 Problems on the Road Changing a Flat Tire (CONK) The following steps will tell you how to use the jack and change a tire. The equipment you'll need is in the storage compartment at the rear of the vehicle. 1. Open the jack storage compartment by sliding the latch down and removing the compartment cover.
Page 196 2. Remove the jack and jacking tools by loosening the wing nut and retainer bar. Separate the plastic pouch from the jack and remove the jacking tools (folding wrench and shaft) from the pouch. The compact spare tire is located under the vehicle, behind the rear bumper.
Page 197 Problems on the Road Changing a Flat Tire (CONT.) 7. If your vehicle has aluminum wheels, each wheel nut is covered with a nylon cap. Use the folding wrench to remove the nylon caps from the whee nuts before you loosen the nuts. If your vehicle has the plastic “bolt-on’’...
Page 198 1O.Attach the folding wrench to the jack, and rotate the wrench clockwise to rais'e the jack head a few inches. 1. Near each wheel, there is a notch in the vehicle's frame. Position the jack and raise the jack head until it fits firmly into the notch in the vehicle's frame nearest the flat tire.
Page 199 Problems on the Road Changing a Flat Tire (CONI) NOTICE: Raising your vehicle with the jack improperly positioned will damage the vehicle or may allow the vehicle to fall off the jack. Be sure to fit the jack lift head into the proper location before raising your vehicle.
Page 200 14.Remove any corrosion or dirt from the wheel bolts, mounting surfaces or spare wheel. Place the spare on the wheel mounting surface. 15.Replace the wheel nuts with the rounded end of the nuts toward the wheel. Tighten each .nut by hand until the wheel is held against the hub.
Page 201 Problems on the Road Changing a Flat Tire (CONI) 17.Tighten the wheel nuts firmly in a criss-cross sequence, as shown. Don’t try to put a wheel cover on the compact spare tire. It won’t fit. Store the wheel cover securely in the rear of the vehicle until you have the flat tire repaired or replaced.
Page 202 18.Lay the flat tire near the rear of the vehicle with the valve stem down. Slide the cable retainer through the center of the wheel and raise the flat tire until you hear the hoist mechanism click twice. This means the wheel is firmly stored against the underside of the vehicle.
Page 203 Problems on the Road Compact Spare Tire Although the compact spare was fully inflated when your vehicle was new, it can lose air after a time. Check the inflation pressure regularly. It should be 60 psi (420 kPa). After installing the compact spare on your vehicle, you should stop as soon as possible and make sure your spare tire is correctly inflated.
Page 204 If that doesn’t get you out after a few tries, you may need to be towed out. If you do need to be towed out, see “Towing Your Pontiac” in the Index.
Page 205 Notes...
Page 206 H e r e you will find information about the care of your Pontiac This part begins with service and fuel information. and then it shows how to check important fluid and lubricant levels There is also technical information about your vehicle. and a...
Page 207 ,roper Pontiac Service Manual. It tells you much more about how to service your Pontiac than this manual can, To order the proper service manual, see “Service Publications” in the Index. Your vehicle has an air bag system.
Page 208 Fuel Use regular unleaded gasoline rated at 87 octane or higher. It should meet specifications ASTM D4814 in the U.S. and CGSB 3.5-92 in Canada. These fuels should have the proper additives, so you should not have to add anything to the fuel.
Page 209 3e careful not to spill gasoline. Clean 5asoline from painted surfaces as soon as Iossible. See “Cleaning the Outside of four Pontiac” in the Index.
Page 210 Be careful not to spill gasoline. Clean gasoline from painted surfaces as soon as possible. See “Cleaning the Outside of Your Pontiac” in the Index. When you put the cap back on, turn it the right until you hear a clicking noise.
Page 211: Part 6 Service & Appearance Care
& Service Appearance Care Checking Things Under the Hood (CONK) The hood prop may be hot due to increased engine temperatures under the good, so be careful when handling your good prop sleeve when handling the good prop. Pull forward on the hood prop to release it from its storage clip.
Page 212 Underhood Light (oPTIcTN) Your underhood light will go on when you open the hood. Engine Oil It’s a good idea to check your engine oil every time you get fuel. In order to get an accurate reading, the oil must be warm and the vehicle must be on level ground.
Page 213 & Service Appearance Care W e n to Add Oil the oil is at or below the ADD mark, len you’ll need to add some oil. But you lust use the right kind. This section tplains what kind of oil to use. For rankcase capacity, see “Capacities and pecifications”...
Page 214 Recommended SAE Viscosity Grade Engine Oils For best fuel economy and cold starting, select the lowest SAE viscosity grade oil for the expected temperature range. HWTHER COLD WEATHER IF NEITHER SAE 5W-30 NOR SAE 1 OW-30 GRADE OILS ARE AVAILABLE, SAE 30 GRADE MAY BE USED AT TEMPERATURES PBOVE 40 DEGREES F (4 DEGREES C).
Page 215 GM Goodwrench@ oil (in Canada, GM Engine Oil) meets all the requirements for your vehicle. Engine Oil Additives Don’t add anything to your oil. Your Pontiac dealer is ready to advise if you think something should be added.
Page 216 When to Change Engine See if any one of these is true for you: Most trips are less than 4 miles km). It’s below freezing outside and most trips are less than 10 miles (16 km). The engine is at low speed most of the time (as in door-to-door delivery, or in stop-and-go traffic).
Page 217 & Service Appearance Care 3.1L Checking Air Cleaner Filter Air Cleaner (CONK) To Check or Replace: 1. Remove the large wing nut and lift the cover. .216 3.1L Replacing Air Cleaner Filter Remove the air cleaner filter. Be sure to install the air cleaner filter, replace the cover and tighten the wing nut securely.
Page 218 Services” in the Index. How to Check Because this operation can be a little difficult, you may choose to have this done at a Pontiac dealership Service Department. If you do it yourself, be sure to follow all the instructions here, or you could get a false reading on the dipstick.
Page 219 & Service Appearance Care How to Check (CONT.) To get the right reading, the fluid should be at normal operating temperature, which is 180°F to 200°F (82°C to 93°C). Get the vehicle warmed up by driving about 15 miles (24 km) when outside temperatures are above 50°F (10°C).
Page 220 If you have a problem with engine -111 overheating, see “Engine Overheating” in the Index. The proper coolant for your Pontiac will: Give freezing protection down to -34°F (-37°C). Give boiling protection up to 262°F (128°C).
Page 221 & Appearance Care Service Engine Coolant (CONE) What to Use Use a mixture of one-half clean water (preferably distilled) and one-half antifreeze that meets “GM Specification 1825-M,” which won’t damage aluminum parts. You can also use a recycled coolant conforming to GM Specification 1825-M with a complete coolant flush and refill.
Page 222 To Add Coolant If you need more coolant, add the proper mix at the coolant recovery tank. Add coolant mix at the recovery tank, but 5e careful not to spill it. Radiator Pressure Cap NOTICE: Your radiator cap is a kPa) pressure-type cap and must bc;...
Page 223 & Service Appearance Care 3.1L V6: Checking Power Steering Fluid 3800 V6: Checking Power Steering Fluid How To Check Power Steering Fluid (CONK) What to Add iefer to the Maintenance Schedule to letermine what kind of fluid to use. See ‘Recommended Fluids and Lubricants”...
Page 224 p F - - When using concentrated washer fluid, follow the manufacturer’s instructions for adding water. Don’t mix water with ready-to-use washer fluid. Water can cause the solution to freeze and damage your washer fluid tank and other parts of the washer system. Also, water doesn’t clean as well as washer fluid.
Page 225 If you do, wash it off immediately. See “Appearance Care” in the Index. Brake Wear Your Pontiac has front disc brakes and rear drum brakes. Disc brake pads have built-in wear indicators that make a high-pitched warning sound when the brake pads are worn and new pads are needed.
Page 226 Vehicles we design and test have top-quality GM brake parts in them, as your Pontiac does when it is new. When you replace parts of your braking system for example, when your brake linings...
Page 227 & Service Appearance Care Vehicle Storage [f you’re not going to drive your vehicle For 25 days or more, take off the black, negative cable from the battery. This will help keep your battery from running down. Contact your dealer to learn how to prepare your vehicle for longer storage periods.
Page 228 Twist the L-shaped bulb assembly counterclockwise 116 turn until the flanges align with the slots in the retainer ring. 4. Pull out the bulb assembly. Disconnect the bulb wiring harness from the bulb assembly by lifting the plastic locking tab. 6.
Page 229 & Service Appearance Care Taillight Bulb Replacement (CONT.) Replace the entire taillight housing and screws. Attach the spring clips to the taillight housing and secure them. I 0.Close the rear side windows and liftgate. 11. Test the bulbs by using your turn signals and taillights.
Page 230 with this. Be sure to spread out your load equally on both sides of the centerline. Never exceed the GVWR for your vehicle, or the Gross Axle Weight Rating (GAWR) for either the front or rear axle. And, if you do have a heavy load, you should spread it out.
Page 231 These tires are warranted by the tire manufacturers and their warranties are delivered with every new Pontiac. If your spare tire is a different brand than your road tires, you will have a tire warranty folder from each of these manufacturers.
Page 232 NOTICE:(Continued) If your tires have too much air (overinflation), you can get: Unusual wear Bad handling Rough ride Needless damage from road hazards. When to Check Check your tires once a month or more. Don’t forget your compact spare tire. It should be at 60 psi (420 kPa).
Page 233 & Service Appearance Care TREAD WEAR INDICATORS Tire Inspection and Potation (CONT.) When It’s Time for New Tires )ne way to tell when it’s time for new ires is to check the treadwear indicators, vhich will appear when your tires have mly 2/32 inch (1.6 mm) or less of tread emaining.
Page 234 Uniform Tire Qua/ity Grading The following information relates to the system developed by the United States National Highway Traffic Safety Administration which grades tires by treadwear, traction and temperature performance. (This applies only to vehicles sold in the United States.) Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire...
Page 235 If the wheel leaks air, replace (except some aluminum ,wheels, which can sometimes be repaired). See your Pontiac dealer if any of these conditions exist. Your dealer will know the kind of wheel you need. Each new wheel should have the same...
Page 236 Some are dangerous if you breathe their fumes in a closed space. When you use anything from a container to clean your Pontiac, be sure to follow the manufacturer’s warnings and instructidns. And always open your doors or windows when you’re cleaning the inside. See “Appearance Care Chart”...
Page 237 Use a vacuum cleaner often to get rid of dust and loose dirt. Wipe vinyl or leather with a clean, damp cloth. Your Pontiac dealer has two GM cleaners, a solvent-type spot lifter and a foam-type powdered cleaner. They will clean normal spots and stains very well.
Page 238 or scraper. Use very little cleaner, lighl pressure and clean cloths (preferably cheesecloth). Cleaning should start at the outside of the stain, “feathering” toward the center. Keep changing to a clean section of the cloth. When you clean a stain from fabric, immediately dry the area with an air hose, hair dryer, or heat lamp to help prevent a cleaning ring.
Page 239 & Service Appearance Care Cleaning the Top of the lnstrurnent Panel Use only mild soap and water to clean the top surfaces of the instrument panel. Sprays containing silicones or waxes may cause annoying reflections in the windshield and even make it difficult to see through the windshield under certain conditions.
Page 240 High pressure truck washes may cause water to enter your vehicle. Finish Care Occasional waxing or mild polishing of your Pontiac may be necessary to remove residue from the paint finish. You can get GM approved cleaning products from your dealer. (See “Appearance Care and Materials”...
Page 241 These brushes can take off the protective coating. .240 Tires Your Pontiac dealer has a GM White Sidewall Tire Cleaner. You can use a stiff m s h with the cleaner. When applying a tire dressing, always rake care to wipe off any over spray or splash from painted surfaces.
Page 242 Although no defect in the paint job causes this, Pontiac will repair, at no charge to the owner, the surfaces of new vehicles damaged by this fallout condition within 12 months or 12,000 miles (20 000 km)
Page 243 1052870 (0.473L) Not recommended for pigskin suede leather. See Your General Motors Dealers for These Products. See Your Maintenance Schedule for Other Products. You can get these from your Pontiac dealer. Lubriplate (White Grease) Preservatone Spot Lifter Washer Solvent Wash-Wax (conc.)
Page 244 Add-on Electrical Equipment NOTICE: Don’t add anything electrical to your Pontiac unless you check with your dealer first. Some electrical equipment can damage your vehicle and the damage wouldn’t be covered by your warranty. Some add-on electrical equipment can keep other components from working as they should.
Page 245 & Service Appearance Care Fuses & Circuit Breakers The wiring circuits in your vehicle are mtected from short circuits by a :ombination of fuses, circuit breakers, lnd fusible thermal links in the wiring tself. This greatly reduces the chance of 'ires caused by electrical problems.
Page 246 & R-WIPER HORN F-WIPER €33 STOP-HA2 F-PUMP R-BLWR Fuse Panel I L V6) ( 3 . Position Rating Circuitry (AMP.) CTSY Dome Lamm, Courtesv Lamps, Power Door Lock Switches, Glove Box Lamp, Powkr'Mirrors,Power Sliding Delay Lock Module Auto Level Control, Underhood Lamp HORN Horns, Horn Relay, Safety Belt Buzzer STOP...
Page 247 & Service Appearance Care RDO 2 r & p?a"r R-WIPER €33 F-WIPER TURN BIU prpl GAGE p-"1 INJ 3365 R-BLWR Fuse Panel (3800 V6) .246 Circuitry Position Rating (AMP.) Dome Lamps, Courtesy Lamps, Power Door Lock Switches, Glove CTSY Box Lamp, Power Mirrors, Power Sliding Delay Lock Module Auto Level Control, Underhood Lamp Horns, Horn Relay, Safety Belt Buzzer HORN...
Page 248 h" Circuit BreakevRelay Panel Zircuit breakers and relays are located in the circuit breaker/relay panel. This is ocated behind the panel under the glove box, near the passenger's door. Position Rating Circuitry (AMP.) Hazard Flasher With 3800 V6 engine only: Canister Purge Solenoid, A/C Clutch Control Relay, Cruise Control Daytime Running Lights (DRL) Power Windows Circuit Breaker...
Page 249 & Service Appearance Care njector 3365 Fuse '3800 V6 ENGINE ONLY) 'his 20-amp fuse is located underhood, I n a bracket just behind the passenger ide headlight. It is mounted on the face I f the bracket in the position closest to lassenger side of the vehicle.
Page 250 Capacities and Specifications ........Engine Crankcase (All Models) When changing filter, up to quart Automatic Transaxle When draining or replacing torque converter, more fluid may be needed.
Page 251 & Service Appearance Care Capacities and Specifications Power Steering 3.1L V6 Engine: PumpOnly Complete System 3800 V6 Engine: PumpOnly Complete System Tire Pressures, Sizes Wheel Nut Torque NOTE: All capacities are approximate. When adding, be sure to fill to the appropriate level, as recommended in this manual. .250 (CONT.) See Certification/Tiri= label on driver’s door.
Page 252 Engine Specifications VINEngineCode Type Displacement Compression Ratio Firing Order Thermostat Temperature Specification Normal Maintenance Replacemenf Parts ....Air Cleaner Element Engine Oil Filter. PCVValve Spark Plugs .
Page 253 Service & Appearance Care Replacement Bulbs OUTSIDE LIGHTS Back-up Lights Front Parkingnurn Signal Lights ..........License Plate Light Halogen Headlights Outer...
Page 254 Replacement Bulbs (COMT.) INSIDE LIGHTS Courtesy Lights ..........CargoArea .
Page 255 Notes...
Page 256: Part 7 Maintenance Schedule
KEEP ENGINE AT THE PROPER LEVEL AND CHANGE AS RECOMMENDED T h i s part covers the maintenance required for your Pontiac Your vehicle needs these services to retain its safety. dependability and emission control performance Have you purchased the...
Page 257 So please read this part and note how you drive. If you have any questions on how to keep your vehicle in good condition, see your Pontiac dealer, the place many GM owners choose to have their maintenance work done. Your dealer can be relied upon to use proper parts and practices.
Page 258 Using Your Maintenance Schedule This section tells you the maintenance services you should have done and when you should schedule them. Your Pontiac dealer knows your vehicle best and wants you to be happy with it. If you go to your dealer for your service needs, you’ll know...
Page 259 Maintenance Schedule Scheduled Maintenance Services Schedule I Follow Schedule I if your car is MAINLY driven under one or more of the following conditions: When most trips are less than 4 miles (6 kilometers). When most trips are less than 10 miles When most trips include extended idling and/or frequent low-speed operation as in stop-and-go traffic.
Page 260 WHAT TO SERVICE The services shown in this schedule to 48,000 miles (80 000 km) should be Derformed after 48,000 miles at the same intervals. An Emission Control Service. The US. Environmental Protection Agency or the California Air Resources Board has determined emission warranty or limit recall liobilily prior to the compleiion o f vehicle useful life.
Page 261 Maintenance Schedule Scheduled Maintenance Services Schedule I1 Follow Schedule I1 ONLY if none of the driving conditions specified in Schedule I apply. WHAT TO SERVICE (See ‘,‘Explanation of Scheduled Maintenance Services’’ following Schedules I and 11) Item No. 1. Engine Oil & Filter Change* Oil Filter Change* 2.
Page 262 WHAT TO SERVICE (See Explanation of Scheduled Maintenance Services Following Schedules I and 11) Item No. 7. Spark Plug Replacement* 8. Spark Plug Wire Inspection* 9. EGR System Inspection (3.1L Code D engine only)*? 10. Air Cleaner Filter Replacement” Air Cleaner Inspection (3.1L Code D engine only)*f‘...
Page 263 Maintenance Schedule Explanation of Scheduled Maintenance Services Following are explanations of the services listed in Schedule I and Schedule 11. The proper fluids and lubricants to use are listed in Section D. Make sure whoever services your vehicle uses these. All parts should be replaced and all necessary repairs done before you or anyone else drives the vehicle.
Page 264 Transaxle Service Change both the fluid and filter every 15,000 miles (25 000 km) if the vehicle is mainly driven under one or more of these conditions: In heavy city traffic where the outside temperature 90°F (32°C) regularly reaches In hilly or mountainous terrain. When doing frequent trailer towing.
Page 265 Maintenance Schedule Section B: Owner Checks and Services Listed below are owner checks and services which should be performed at the intervals specified to help ensure the safety, dependability and emission control performance of your vehicle. Be sure any necessary repairs are completed at once. Whenever any fluids or lubricants are added to your vehicle, make sure they are the proper ones, as shown in Section D.
Page 266 At Least Once a Month CHECK OR WHAT TO DO SERVICE Tire Inflation ‘Check tire inflation. Make sure they are inflated to the pressures specified on the Certificationnire label located on the rear edge of the driver’s door. See “Tires”’ in the Index for further details. Cassette Deck Clean cassette deck.
Page 267 Maintenance Schedule WHAT TO DO CHECKOR SERVICE While parked, and with the parking Steering Column Lock brake set, try to turn the key to “LOCK” in each shift lever position. The key should turn to “LOCK” only when the shift lever is in “P” (Park).
Page 268 CHECK OR WHAT TO DO SERVICE Underbody At least every spring, use plain water to Flushing flush any corrosive materials from the underbody. Take thoroughly any areas where mud and other debris can collect. Section C: Periodic Maintenance Inspections Listed below are inspections and services which should be performed at least twice a year (for instance, each spring and fall).
Page 269 Maintenance Schedule CHECK OR WHAT TO DO SERVICE Brake System inspect the complete system. Inspect [nspection brake lines and hoses for proper hookup, binding, chafing, etc. Inspect disc brake pads for wear and rotors for surface condition. Also inspect drum brake linings for wear and cracks.
Page 270 USAGE FLUID/LUBRICANT Parking Brake Chassis lubricant (GM Part No. Guides 1052497 or equivalent) or lubricant meeting requirements of NLGI Grade 2, Category LB or GC-LB. Power Steering GM Hydraulic Power Steering Fluid (GM Part No. 1052884 or equivalent). System Automatic DEXRON@-111 or DEXRON@-IIE Transaxle Automatic Transmission Fluid.
Page 271 Schedule Maintenance Section E: Maintenance Record After the scheduled services are performed, record the date, odometer reading and who performed the service in the columns indicated. When completing the Maintenance ODOMETER DATE MAINTENANCE PERFORMED READING Performed column, insert the numbers from the Schedule I or Schedule I1 maintenance charts which correspond to the maintenance performed.
Page 272 Maintenance Record ODOMETER DATE SERVICED BY MAINTENANCE PERFORMED READING...
Page 273 Maintenance Schedule Maintenance Record ODOMETER DATE MAINTENANCE PERFORMED SERVICED READING - . . .272...
Page 274: Part 8 Customer Assistance Information
H e r e you will find out how to contact Pontiac if you need assistance. This part also tells you how to obtain service publications and how to repori any safety defects. Customer Assistance Information Part 8 includes ........
Page 275 Customer Assistance Information Customer Satisfaction Procedure Your satisfaction and goodwill are important to your dealer and Pontiac. Normally, any concern with the sales transaction or the operation of your vehicle will be resolved by your dealer's Sales or Service Departments.
Page 276 We encourage you to call the toll free number listed previously in order to give your inquiry prompt attention. However, if you wish to write Pontiac, write to: United States Pontiac Division Customer Assistance Center One Pontiac Plaza Pontiac, MI 48340-2952...
Page 277 AUTO LINE, but you may contact the BBB at any time. The BBB will attempt to resolve the complaint serving as an intermediary between you and Pontiac. If this mediation is unsuccessful, an informal hearing will be scheduled where zligible customers may present their case to an impartial third-party arbitrator.
Page 278 REPURTZNG SAFETY DEFECTS TO THE UNZTED STATES GOVERNMENT If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA), in addition to notifying General Motors.
Page 279 Pontiac Roadside Assistance Program Security While You Travel 1-800-ROADSIDE 1-800-762-3743 As the proud owner of a new Pontiac vehicle, you are automatically enrolled in the Pontiac Roadside Assistance Program This value-added service is intended to provide you with peace of mind as you drive in the city or travel the open road.
Page 280 Vehicle model, year, and color Mileage of vehicle Vehicle identification number Vehicle license plate number Pontiac reserves the right to limit services or reimbursement to an owner or driver when in Pontiac’s judgement the claims become obsessive in frequency or type of occurrence.
Page 281: Index
Individual PSP’s If you don’t want to buy all the PSP’s issued by Pontiac for all models in the model year, you can buy individual PSP’s, such as those which may pertain to a particular model.
Page 282 Pontr'ac Service Publications You can get these by using the order form: Pontiac Division Service Manuals are intended for use by professional, qualified technicians. Attempting repairs or service without the appropriate training, tools, and equipment could cause injury to you or others and damage to your vehicle that may cause it not to operate properly.
Page 283 0...
Page 284 Model the model year. 1994 Pontiac Trans Sport ... . S-9410-U NOTE: Please specify special body or engine types on order form. Write information in the Form Number column. For example: Turbo, Convertible.
Page 286 PONTIAC SERVICE PUBLICATIONS NOTE: Please complete form below (Print or Type) and MAIL TO: Post Office Box (CUSTOMER NAME) (ATTENTION) (STREET ADDRESS-NO P.O. BOX NUMBERS) *Prices are subject to change without notice and without incurring obligation. cell to ba ann, , , , n ccd...
Page 287 0...
Page 288 8:OO A.M.-6:00 VEHICLE MODEL ITEM DESCRIPTION NAME Pontiac Trans Sport Pontiac Trans S ~ o r t be sent. should (STATE) NOTE TO CANADIAN CUSTOMERS All listed prices are quoted in U.S. funds. Canadian residents are to make checks further information.
Page 290 PONTIAC SERVICE PUBLICATIONS ORDER FORM NOTE: Please complete form below (Print or Type) and MAIL TO: NAME) (CUSTOMER (STREET ADDRESS-NO P.O. BOX NUMBERS) *Prices are subject to change without notice and without incurring obligation. *Price C e l l 1-800-782-4356 for announced at a later date.
Page 292 PONTIAC SERVICE PUBLICATIONS ORDER FORM NOTE: Please complete form below (Print or Type) Post Office Box 07130, Detroit, Michigan PUBLICATION FORM NUMBER Service Manual S-9410-U Owner’s Manual In-Portfolio 10260058 Owner’s Manual Without-Portfolio 10260060 Dealers and Companies please provide dealer NOTE also the name the person to whose attention the shipment should be sent.
Page 294 PONTIAC SERVICE PUBLICATIONS ORDER FORM NOTE: Please complete form below (Print or wpe) and _MAIL TO: Dealers and Companies please provide dealer NOTE: also the name the person to whose attention the shipment should purchases outside U.S.A. please write NAME) (CUSTOMER P.O.
Page 295 0...
Page 296 PONTIAC SERVICE PUBLICATIONS ORDER FORM NOTE: Please complete form below (Print or Type) and MAIL TO: Post Office Box 07130, Detroit, Michigan 48207 (Monday-Friday 8:OO A.M.-6:00 P.M. EST) PUBLICATION FORM NUMBER ITEM DESCRIPTION *Prices are subject to change without notice and without incurring obligation.
Page 298 Readiness Light Servicing Your Air Bag-Equipped ....Pontiac ... Air Cleaner Filter 215.
Page 299 ... . . Foreign Material Glass ..Inside of Your Pontiac ... . . Leather or Vinyl ..
Page 300 Electrical Equipment... Adding 7 1.72. 130. 243 ..Electric Outside Mirror Control ..Electronic Level Control 104. 229 ..Emergencies.
Page 301 ....Hood Release 209. 304 ....Safety Warning . . . Warning. Overheated Engine Horn Hot Engine.
Page 302 ....Mountain Driving ’ ....N e t . Convenience New Vehicle “Break-In” .
Page 303 Service Publications Service Publications Order Form Service Station Information Servicing Your Air Bag-Equipped Pontiac ....Setting the Clock Setting the Trip Odometer ... . .
Page 304 ....Towing a Trailer ... . Towing Your Pontiac ... . Traction Control 115.
Page 305: Service Station Information
Service Station Information Battery The Delco Freedom@ battery needs no water. See Page 225 Windshield Washer Fluid See Page 222 Transaxle Fluid See Page 217 Cold Tire Pressure See Certificationnire Label on inside edge of driver’s door. See Page 228 Fuel Capacity 20 U.S.
