1993

PONTIAC

Firebird

OWNER'S MANUAL

Table of Contents

Summary of Contents for Pontiac 1993 Firebird

Page 1 1993 PONTIAC Firebird OWNER'S MANUAL...
Page 2: Table Of Contents
Firebird Introduction HOW to Use This Manual Seats & Safety Belts. Part 1 Features & Controls Part 2 3 Comfort Controls Part Your Driving and the Road. Part 4 Problems on the Road Part 5 Service & Appearance Care Part 6 Maintenance Schedule Part 7 Customer Assistance Information...
Page 3 Please keep this manual in your Pontiac, so it will be there if you ever need it when you’re on the road. vehicle, please leave this manual in it so the new owner can use it. sell This manual includes the latest information at the time it was printed. We reserve the right to make changes in the product after that time without further notice.
Page 4 This part tells you how to use your seats and safety belts properly. Part 2: Features Controls & This part explains how to start and operate your Pontiac 3: Comfort Controls Part & Audio Systems This part tells you how to adjust the ventilation and comfort controls and how to operate your sound system.
Page 5 Part 6: Service & Appearance Care Here the manual tells you how to keep your Pontiac running properly and looking good. Part 7: Maintenance Schedule This part tells you when to perform maintenance and what fluids and lubricants to use.
Page 6 In this manual, we’ve used the familiar words and colors that Pontiac has used for years. You’ll also see warning labels on your vehicle. They use the same colors, the words CAUTION or NOTICE.
Page 7 How to Use This Manual Vehicle Symbols These are some of the symbols you will find on your vehicle. For example, these lights: driven: symbols are used on an original battery: Caution Possible Injury Protect Eyes by Shielding Caustic Battery Acid Could Cause Burns Avoid Sparks or Flames...
Page 8 These symbols are on some of your controls: Windshield Wiper Windshield Washer Windshield Defroster Rear Window Defogger Ventilating Fan These symbols are used on warning and indicator lights: Engine Coolant Temperature Battery Charging System Engine Oil Pressure Brake Anti-Lock Brake System (Canada) Here are some other symbols you may see:...
Page 9 Notes...
Page 10: Part 1 Seats & Safety Belts
Seat H e r e YOU’II find information about the seats in your Pontiac and how to use your safety belts properly . You can also learn about some do with things you should belts safety ..........
Page 11 Seats & Safety Belts and Seat Con&& Seuts This section tells you about seats adjust them, and also about reclining h n t seatbacks, satback latches and the folding rear seatback. Manual Front Seat CAUTION: You can lose control of the vehicle if you try to adjust a manual driver’s seat while the vehicle is moving.
Page 12 Fully Articulating Sport Seat (OPTION) [f your Pontiac has these seats, the driver’s seat has the four-way manual seat adjuster, See “Four-Way Manual Seat” earlier in this part. The passenger seat has the two-way manual seat adjuster.
Page 13 Se’ats & Safety Belts The two buttons that have “dots” inflate and deflate the outer parts of the seatback. To inflate, push the raised button. To deflate, push the indented button. The two buttons without “dots” inflate and deflate the lumbar (lower part of the seatback) support.
Page 14 sitting in a reclined position when your vehicle is in motion can be dangerous. Even if you buckle up, your safety belts can’t do their job when you’re reclined like this. The shoulder belt can’t do its job because it will be in front of you. In a crash you could go into it, receiving neck or other injuries.
Page 15 Seats & Safety Belts 1 1 1 FroN Seatback Latches frwm seatbacks foid forward to let people get into- the back s a t . To fold a seatback forward, push the seatback toward the rear as you lift this latch. Then the seatback will fold forward.
Page 16 Folding Rear Seatback The rear seatback in your Pontiac folds h w n to provide more storage space. To fold the seatback down: 1. Pull forward on both levers. 2. Fold the seatback down. T o raise the seatback: 1. Pull up to the locked, upright position.
Page 17 Seats & Safety Belts This figure lights up when you turn the key to Run or Start when your safety belt isn’t buckled, and you’ll hear a chime, too. It’s the reminder to buckle up. In many states and Canadian provinces, the law says to wear safety belts.
Page 18 Nhen the bike hits the block, it stops. But he child keeps going! rake the simplest “car.” Suppose it’s just seat on wheels. Put someone on...
Page 19 Seats & Safety Belts Get it up to speed. Then stop the “car.” The rider doesn’t stop. The person keeps going until stopped by something. In a real vehicle, could be the windshield or the instrument panel...
Page 20 the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. stop over more distance, and your strongest bones take the forces. That’s why safety belts make such good sense. Here Are Questions Many People Ask about Safety Belts and the...
Page 21 Seats & Safety Belts Q: If I’m a good driver, and I never drive far from home, why should I wear safety belts? A: You may be an excellent driver, but if you’re in an accident even one that isn’t your fault you and your passengers can be hurt.
Page 22 First, you’ll want to know which restraint systems your vehicle has. We’ll start with the driver position. Driver Position This section describes the driver’s restraint system. Lap-Shoulder Belt The driver has a lap-shoulder belt. Here’s how to wear it properly. 1.
Page 23 Seats & Safety Belts 5. To make the lap part tight, pull down the buckle end of the belt as you pull up on the shoulder belt. The lap part of the belt should be worn low and snug the hips, just touching the thighs.
Page 24 Q: What’s with this? wrong A,: The belt is buckled in the wrong place. You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen.
Page 25 System (Air Bags) This section explains the Supplemental (SIR), Inflatable Restraint or “air bag,” system. Your Pontiac has an air bag for both the driver and the right-front passenger. € lere’s the most important thing know: Even with an air bag, if you’re not wearing a safety belt and you’re in a crash, your injuries may...
Page 26 CAUTION: Air bags inflate with great force, faster than the blink of an eye. If you’re too close inflating air bag, could seriously injure you. Safety belts help keep you in position for an air bag inflation in a crash. Always wear your safety belt, even with an air bag, and the driver should sit as far back as possible while still...
Page 27 Seats & Safety Belts If the air bag readiness light doesn’t come on when you start your vehicle, or stays on, on when you are driving, ‘comes your air bag system may not work properly. Have your vehicle - 9 . 2 6 How the Air Bag System Works Where is the air bag?
Page 28 When is an air bag expected to inflate? The air bag is designed to inflate in moderate to severe frontal or near-frontal crashes. The air bag will only inflate if the velocity of the impact is above the designed threshold level. When impacting straight into a wall that does not move or deform, the threshold level for most GM vehicles is between 9 and 14 mph...
Page 29 Seats & Safety Belts How does an air bag restrain? In moderate to severe frontal or near-frontal collisions, even belted occupants can contact the steering wheel or the instrument panel. The air bag supplements the protection provided by safety belts. Air bags distribute the force of the impact more evenly over the occupant’s upper body, stopping the occupant more gradually.
Page 30 You don’t want the system to inflate while someone is working on your vehicle. The air bag system does not need regular maintenance. Your Pontiac dealer and the 1993 Firebird Service Manual have information about the air bag system, including repair or disposal. to 2...
Page 31 Seats & Safety Belts Your vehicle has a driver’s air bag and a right-front passenger’s air bag. Both bags must be disconnected if the ignition has to be on for electrical work or if the steering column is to be disassembled. First, disconnect the driver’s air bag like this: 1.
Page 32 Passenger Positions Right Front Passenger Position The right front passenger’s safety belt works the same way as the driver’s safety belt. See “Driver Position,” earlier this part. Rear Seat Passengers It’s very important for rear seat passengers to buckle up! Accident statistics show that unbelted people in the rear seat are hurt more often in crashes than those who are wearing safety .belts.
Page 33 Seats 81 Safety Belts If the belt stops before it reaches the buckle, tilt the latch plate and keep pulling until you can buckle it. If the belt is not long enough, see “Safety Belt Extender’’ at the end of this section.
Page 34 le safety belt locks if there’s a sudden stop or a crash. You can be seriously hurt if your shoulder belt is too loose. In a crash you would move forward too much, which could increase injury, The shoulder belt shouid fit against your body.
Page 35 Seats & Safety Belts Never hold a blaby in your arms while riding in a weigh much until a crash. During a crash a baby will become so heavy For example, in a crash at only 25 mph (40 km/h), a 12-pound you can't hold (5.5 kg) baby will suddenly become a 240-pound (1 10 kg) force on your arms.
Page 36 Child Restraints Be sure to follow the insiructions for the restraint. You may find these instructions on the restraint itself or in a booklet, or both. These restraints use the belt system in your vehicle, but the child also has to be secured within the restraint to help reduce the chance of personal injury.
Page 37 This should be used only with a child restraint, and only to secure a :hild restraint at a rear seating position. An additional anchor bracket for a child restraint at the other rear seating position is available at Pontiac dealerships in Canada.
Page 38 Child Restraint in the Rear Securing Seat You’ll be using the lap-shoulder belt. See the earlier sectian about the top strap if the child restraint has ane. 1. Put the restraint the seat. Follow the instructions for the child restraint. 2.
Page 39 You can get a locking clip where child restraints are sold, or from your Pontiac dealer (GM Part No. 94844571). The locking clip must be the same as the one shown here.
Page 40 Once you have the clip, follow these instructions: 1. Move the seat as far back as it will go before securing a front-facing child restraint. 2. Put the restraint on the seat. Follow the instructions for the child restraint. Secure the child in the child restraint as the instructions say.
Page 41 Se,ats & Safety Belts If a locking clip is not used or is not installed properly, the child restraint may move or tip over when your vehicle turns or stops quickly. The child or others could be injured. When you secure a child restraint with a lap-shoulder belt, always thread both the lap and shoulder belt portions through a...
Page 42 Larger Children Children who have outgrown child restraints should wear the vehicle’s safety belts. Accident statistics show that children are safer if they are restrained in the rear seat. But they need to use the safety belts properly. Children who aren’t buckled up can be thrown out in a crash.
Page 43 Seats & Safety Belts What if a child is wearing lap-shoulder belt, but the child is so small that. the shoulder bel8 is very .clwe to the child’s face or neck? A: Move the child t-oward center of the vehicle, but be sure that the shoulder belt still is an the child’s that in a crash the child’s shoulder,...
Page 44 Safety Belt Extender If the vehicle’s safety belt will fasten around you, you should use it. But if a safety belt isn’t long enough to fasten, your dealer will order you an extender. It’s free. When you go in to order it, take the heaviest coat you will wear, so the extender will be long enough for you.
Page 45 Seats & Safety Belts Q: What’s wrong with this? A: The belt is torn. a belt is torn or frayed, get a new one right away. The model number on the replacement belt must be listed on the safety belt you want to replace.
Page 46: Part 2 Features & Controls
F‘ H e r e you can learn about the many standard and optional Features on your Pontiac. and information on starting. shifting and braking Also explained are the instrument panel and the warning systems that tell you if everything is working properly -...
Page 47 Features & Controls CAUTION: Leaving young children in a vehicle with the ignition key is dangerous for many reasons. A child or others could be badly injured or even killed. They could operate power windows or other controls or even make the vehicle move.
Page 48 If you lose your keys, you’ll be able to have new ones made easily using these plugs. If your ignition keys don’t have plugs, go to your Pontiac dealer for the correct key code if you need a new ignition key.
Page 49 Features & Controls Door Locks Unlocked doors can be dangerous. Passengers especially children can easily open the doors and f a l l out. When a door is locked, the inside handle won't open it. Outsiders can easily enter through an unlocked door when you slow down or stop your vehicle.
Page 50 Then get out and close the door. Remote Lock Control (Option) If your Pontiac has this option, you can doors or unlock lock and unlock your your hatch from about 22-33 feet...
Page 51 Features & Controls Changes or modifications to this system by other than an authorized service facility could void authorization to use this equipment. Operation The driver’s door will unlock automatically when UNLOCK is pressed. If UNLOCK is pressed twice quickly, all doors will unlock. All doors will lock when DOOR is pressed.
Page 52 7. Check that all the buttons on both transmitters work correctly. the transmitters don’t work, or if you’d rather not match the transmitters yourself, see your Pontiac dealer. Battery Replacement Under normal use, the batteries in your key chain transmitter should last about two years.
Page 53 Features & Controls Remove and replace the batteries. Use two Duracella batteries, type DL2016, or a similar type. Put the new batteries in printed side down. 4. Replace the front cover. Make sure the cover is on tightly so water won’t get in.
Page 54 Theft Vehicle theft is big business, especially in some cities. Although your Pontiac has a number of theft-deterrent features, we know that nothing we put on it can make it impossible to steal. However, there are ways you can help.
Page 55 Features & Controls Parking Night: Park in a lighted spot, c1,ose all windows and lock your vehicle. Remember keep your valuables out of sight. Put them in a storage area, or take them with you. Parking-Lots: If you park in a lot where someone will be watching your vehicle, it’s best to lock it up and take your keys.
Page 56 Your vehicle is not protected by the PASS-Key II@ system. If you lose or damage a PASS-Key 1 1 ’ ignition key, see your Pontiac dealer or a locksmith who can service PASS-Key II@ to have a new key made.
Page 57 Features & Controls New Vehicle “‘Break-In” NOTICE: Ignition Switch With the ignition key in the ignition switch, you can turn the switch to five positions: Acc (A): Position in which you can operate your electrical power accessories. Press in the ignition switch as you turn the top of it toward you.
Page 58 Start (E): Starts the engine. When the engine starts, release the key. The ignition switch will return to Run for normal driving. Note that even if the engine is not running, Acc and Run allow you to operate your electrical accessories, such as the radio and ventilation fan.
Page 59 Features & Controls NOTICE: Retained Accessory Power (RAP) If you have power door locks, your vehicle has a feature called Retained Accessory Power (RAP). With RAP your power door locks, electric mirrors, power windows, audio system and remote hatch release will continue to work up to 10 minutes after the ignition key is turned to Off and neither door is opened.
Page 60 Manual Transmission: Shift your gear selector to neutral and hold the clutch pedal to the floor while starting the engine. Your vehicle won’t start if the clutch pedal is not all the way down that’s a safety feature. To start your V6 engine: 1.
Page 61 Features & Controls Your engine is designed to work with the electronics in your vehicle. you add electrical parts or accessories, you could change way the fuel injection system operates. Before adding electrical equipment, check with your deale,. If you don’t, your engine might 1.
Page 62 When starting your engine in very cold weather (below 0°F or -18"C), do this: 1. With your foot off the accelerator Start pedal, turn the ignition key to and hold it there. When the engine starts, let go of the key. Use the accelerator pedal to maintain engine speed, if you have to, until your engine has run for a while.
Page 63 Features & Controls Driving through Deep Stunding Water (CAAIAOA) In very cold weather, 0°F 18°C) 0r colder, the engine block hleater can help. You'lP get easier starting and better fuel economy during engine warm-up. To use the block heater: Turn engine.
Page 64 Instead of trying to list everything here, we ask that you contact a Pontiac dealer in the area where you’ll be parking your vehicle. The dealer can give you the best advice for that particular area.
Page 65 Ensure the shift lever is fully in (Park) range before starting the engine. Your Pontiac has a brake-transmission shift interlock. You have to fully apply your regular brakes before you can shift from P (Park) when the ignition key is in the Run position.
Page 66 Shifting out of P (Park) or N (Neutral) while your engine is “racing” (running at high speed) is dangerous. Unless your foot is firmly on the brake pedal, your vehicle could move very rapidly. You could lose control and hit people or objects.
Page 67 Features & Controls 2 (Second Gear) This position gives you more power but lower fuel economy. You can use hills. It can help control your speed as you go down steep mountain roads, but then you would also want to use your brakes off and on.
Page 68 NOTICE:...
Page 69 Features & Controls Neutral Use this position when start or idle your engine. (Reverse) back up, press down the clutch pedal and shift into L e t up on the clutch pedal slowly while pressing the accelerator pedal. Shift to (Reverse) only after v o w vehicle...
Page 70 e this position when you start or idle yaur engine. (Reverse) To back up, press down the clutch pedal and shift into Let up on the clutch pedal slowly while pressing the accelerator pedal. If you shift from into the shift lever Neutral must be first placed in the position centered between 2 and 3...
Page 71 Features 81 Controls Shift Speeds (MANUAL TRANSMISSION) This chart shows when to shift to the next higher gear for best fuel economy. MANUAL TRANSMISSION RECOMMEINDED SHIFT SPEEDS, IN MIPH (kmlh) Engine 1 t o 2 3.4L L32 1 3-1 6 (Code S) (21-25) 5.7L LTI...
Page 72 Limited-Slip Rear Axle [f you have this feature, your rear axle can give you additional traction on snow, mud, ice, sand or gravel. It works like a standard axle most of the time, but when one of the rear wheels has no traction and the other does, the limited-slip feature will allow the wheel with traction to move the vehicle.
Page 73 Features Controls are on a hill: See “Parking on J ~ Q U Hills” in the Index. That section shows how to turn your front wheels. towing a trailer parking hill: See ‘Towing a Trailer” in the Index. That section shows what to do first to keep the trailer from moving.
Page 74 If you can, it means that the shift lever wasn’t fully locked into P (Park). Shifting out of P (Park) (AUTOMATIC TRANSMISSION) Your Pontiac has a brake-transmission shift interlock. have to fully apply before your regular brake...
Page 75 Features & Controls If you cannot shift out of (Park), ease pressure on the shift lever push the shift lever all the way into (Park) and also release the shift lever button on floor shift console models as you maintain brake application.
Page 76 Parking over Things That Burn Things that can burn could touch hot exhaust parts under your vehicle and ignite. Don’t park over papers, leaves, dry grass or other things that can burn. Engine Exhaust I ’ Engine qhaust can kill. It CQntains see or smell.
Page 78 Power Windows (Option) With power windows, switches on the door control each window when the ignition is on or when RAP is present. (See “Retained Accessory Power” in the Index.) The switch for the driver’s window has an Express Down feature. Quickly press and release the switch for the driver’s window and the window will lower completely.
Page 79 Features & Controls SignallHeadlight Beam Lever The lever on the left side of the steering column includes your: Turn Signal and Lane Change Indicator Headlight Highbow Beam and Passing Signal Windshield Wipers Windshield Washer Cruise Control (Option} Turn Signal and Lane Change indicator The turn signal has two upward (for Right) and two downward (for Left)
Page 80 To change the headlights from low beam high or high to low, pull the turn signal lever all the way toward you. Then release it. When the high beams are on, this blue light on the instrument panel also will be on. Windshield W@em You control the windshield wipers by turning the band with the wiper symbol...
Page 81 Features & Controls CAUTION: Damaged wiper b.,,es prevent you from seeing well enough to drive safely. To avoid damage, be sure to clear ice and snow from the wiper blades before using them. If they’re frozen to the windshield, carefully loosen or thaw them.
Page 82 coI1ccllLliiLcu IlCI1 us111g washer fluid, follow the manufacturer’s instructions fo adding water. Don’t mix water with ready-to-use washer freeze and damage your your windshield washer. It ca damage your washer system and paint. ;wise Control (omoN) With Cruise Control, you can maintain a speed of about 25 mph (40 km/h) or more without keeping your foot on the accelerator.
Page 83 Fe’atures 81 Controls To Set Cruise Control 1. Move the Cruise Control switch to Control switch on when you.re using Cruise, you might hit a button and go into Cruise when you don’t want You could be startled and even lose control. Keep the Cruise Control sw** h OFF until want to use 2.
Page 84 If you hold the switch at RIA longer than half a second, the vehicle will keep going faster unti’ you release the switch or apply brake. You could be startled and even lose control. So unless yell want to go faster, don’t hold t ~ - switch at R/A.
Page 85 Features & Controls To Reduce Speed While Using Cruise Control There are two ways to reduce your speed while using cruise control: 1. Push in the button at the end of the lever until you reach the lower speed you want, then release 2.
Page 86 2. Move the Cruise switch to OFF. To Erase Speed Memory When you turn off the Cruise Control or the ignition, your Cruise Control set speed memory is erased. Operation of Lights Although your vehicle’s lighting system (headlights, parking lights, fog lamps, side marker lights.
Page 87 To manually close the headlight doors, turn the lights off and turn the knob clockwise. If the headlight doors aren't working properly, see your Pontiac dealer for help.
Page 88 Daytime Running Lights (Canada) The Canadian Federal Government has decided that “Daytime Running Lights” (DRL) are a useful feature, in that DRL can make your vehicle more visible to pedestrians and other drivers during daylight hours. DRL are required on new vehicles sold in Canada.
Page 89 Features & Controls Interior Lights Courtesy Lights When any door is opened, several interior lights go on. These lights are courtesy light,s. They make it easier for you to enter and leave your vehicle. Courtesy lights include the dome light and other lights throughout the interior of your vehicle.
Page 90 Convex Outside Mirror Your right side mirror convex. convex mirror’s surface is curved so you can see more from the driver’s seat. CAUTION: If you aren’t used to a convex mirror, you can hit another vehicle. A convex mirror can make things (like other vehicles) look farther away than they really are.
Page 91 Features & Controls Twin Lift-OffRoof Punels (OPTION) If you have this option, you can remove one or both lift-off roof panels. Don't try to remove the T-top panels while the vehicle is moving. Trying to remove a T-top panel while the vehicle is moving could cause an accident.
Page 92 Open the close-out panel completely. Place the panel in the correct slot (DRIVER or PASSENGER) in the rear area of your vehicle. Make sure the handle is open and facing you when you put it in the storage slot. Push the handle closed to secure the panel in the slot.
Page 93 Features & Co,ntrols T - m T o p ;Sunshades DRIVER 1 1 . S m w i t h the panel marked FRONT. Unlatch the driver-side T-top, raise it halfway close the latch handle. 2. With the top rais'ed and resting on the center roof rail, slide the flat edge of the sunshade panel (with the vinyl ;side to the glass) between the glass...
Page 94 You can store the sunshades in their storage area in the rear of your vehicle. You can also leave them attached to the T-tops. The T-tops can still be removed and placed in their storage slots when the sunshades are attached. Storage and Compartments Glove Box...
Page 95 Features & Controls Fromt Co'nsole TQI use the storage area, push the tab and pull up on the front end of the console. Therle is a cupholder and light and may a coinholder in the console. The console will also have a storage area for &her cassette tapes or compact discs.
Page 96 Sun Visors To block out glare, you can swing down the visors. You can also swing them to the side. Covered Visor Vanity Mirror Pull down the sun visor and lift the cover to expose the vanity mirror. Ashtray and Lighter Front Ashtray Lift up the cover to open the ashtray.
Page 97 Features & Controls...
Page 98 lnstrument Panel 1. Fog Lamp Switch (if equipped) Main Light Control Side Upper Air Vent Instrument Cluster Horn Center Upper Air Vent Audio System Glave Box Comfort Controls Cigarette Lighter Parking Brake Lever Cupholder Storage Console and Cassette Tape/Compact Disc Storage (as equipped) Ashtray (Manual Transmission) Shift Lever...
Page 99 Canada similar U.S. shown, You may wonder what happens if your Pontiac needs a new odometer installed. If possible, the new one has to be set to the same reading the old one had. If it can’t be, then it’s set at zero, but a label on the driver’s door must show the old...
Page 100 Trip Odometer The trip odometer can tell you how far your vehicle has been driven since you last set the trip odometer to zero. Tachometer The tachometer displays the engine speed in thousands of revolutions per minute (rpm). Warning Lights, Gages and Indicators I‘his section describes the warning lights md gages that are on your vehicle.
Page 101 Features & Controls working. If you are familiar with this sectio.n, you should not be alarmed when this happens. Gages can indicate when there may be or is a problem with one of your vehicle’s functions. Often gages and warning lights work together to let you know when there’s a problem with your vehicle.
Page 102 Brake System Warning Light Your Pontiac’s hydraulic brake system is divided into two parts. one part isn’t working, the other part can still work and stop you. For good braking, though, you need both parts working well. If the warning light goes on, there could be a brake problem.
Page 103 Then start the engine to reset the system. If the light still stays on, or comes on again while you’re driving, your Pontiac needs service. Unless the regular brake system warning light is also ‘on, you will still have brakes, but not anti-lock brakes.
Page 104 Engine Coolant Temperature Gage This gage shows the engine coolant temperature. If the gage pointer moves into the red area, your engine is too hot! [t means that your engine coolant has overheated. you have been operating your vehicle under normal driving zonditions, you should pull off the road, stop your vehicle and turn off the engine as soon as possible.
Page 105 Features 8t Controls Malfunction Indicator Lamp (Service Engine Soon Light} A computer monitor,s operation of your fuel, ignition and emission control systems.. This light should come on when the ignition is on, but the engine is not running, as a check to show you it is does not come on at all, working.
Page 106 Don’t keep driving if the oil pressure is low. If you do, your engine can become so hot that it catches fire. You or others could be burned. Check your oil as soon as possible and have your vehicle serviced. Eglected oil problems can be cost Check Gages Light .
Page 107 You may need to add coolant. See “Engine Coolant” in the Index. Driving with t light on couId cause vour Pontiac in the Index. Your Pontiac could be damaged, and it wouldn’t be...
Page 108: Audio Systems
> < . < I n this part you’ll find out how to operate the comfort control systems and audio systems offered with your Pontiac Be sure to read about the particular system supplied with your vehicle Comfort Controls ...........
Page 109 Comfort Controls & Audio Systems Comfort Controls With this system, you can control the heating and ventilation in your Pontiac. If you have the air conditioning option, you can also control cooling. Your vehicle also has the flow-through ventilation system described later in this section.
Page 110 Heating The heater works best if you keep your windows closed while using it. *A . 1. Turn the air control knob to 2. Turn the fan control knob to the right. Turn the temperature control knob to a comfortable setting. During initial start-up only, if your vehicle is equipped with...
Page 111 Comfort Controls & Audio Systems Defogging and Defrosting Wjndows Turn the air control knob to T u r n the temperature control knob all the way to the right. Turn the fan control knob to the right. Air Conditioner Controls (omotv) The air conditioning system uses the same controls as the heating system, except that the air control knob has two extra...
Page 112 Cooling The air conditioner works best if you keep your windows closed. On very hot days, open the windows just long enough for the hot air to escape. 1. Turn the air control knob to A/C for normal cooling. For faster cooling move the knob to MAX.
Page 113 Comfort Controls & Audio Systems Flow-Through Ventilation System Your Pontiac’s flow-through ventilation system supplies outside air into the vehicle when is moving. Outside air will also enter the vehicle when the heater or the air conditioning fan is running. Ventilation Tips...
Page 114 GAU I IVN: Hearing damage from loud noise is almost undetectable until it is too late. Your hearing can adapt to higher volumes of sound. Sound that seems normal can be loud and harmful to your hearing. Take precautions by adjusting the volume control on your radio to a safe sound level before your hearing adapts to it.
Page 115 AMJFM Stereo with Cassette Tape or Disc Player and Graphic CIompact Equalizer SET. 1. Press 2., Within five seconds, press and hold SEEK 4 until the correct hour appears. Bess and hold SEEK until the correct minute appears. Stereo AM/FM wifh Cassette Tape Player...
Page 116 Scan The scan function uses the same two buttons as the seek function. To go to the next higher station and stay there for a few seconds, press and hold SEEK and then press SEEK’ for an instant. To go to the next lower station and stay there for a few seconds, press and hold SEEK and then press SEEK...
Page 117 Comfort Controls & Audio Systems Setting the Tone Bass: Slide the BASS lever up to hear more bass. Treble: Slide the TREB lever up to hear more treble. If a station is weak and noisy, move TREE down to reduce the noise. Aldju,sting Speakers B'alance: Turn the balance control behind...
Page 118 AM/FM Stereo with Cassette Tape Player and Graphic Equalizer To Play the Radio Press to turn the system on or off. Volume Turn the upper knob to adjust the volume. AM-FM Press the lower knob to get AM, FM1 or FM2.
Page 119 C,omfort Controls & Audio Systems Pushbuttons The five pushbuttons let you return to your favorite stations. To set the pushbuttons for up to 15 stations ( 5 AM, 5 FM 1 and 5 FM2), just: 1, Press the lower knob to choose AM, FMl or FM2.
Page 120 each side. Tapes longer than that are so thin they may not work well in this player. The longer side with the tape visible goes in first. If you hear nothing or hear just a garbled sound, it may not be in squarely. EJECT Press to remove the tape and start...
Page 121 AM!FM Stereo with Compact Disc layer and Graphic Equalizer Flay the Radio F%ess to turn the system on or off. Volume Turn the upper knob to adjust the volume. AM-FA4 Press the lower knob to get AM, FML or FM2. Tune Turn the lower knob to choose radio stations.
Page 122 Pushbuttons The five pushbuttons let you return to your favorite stations. To set the pushbuttons for up to 15 stations ( 5 AM, 5 FM1 and 5 FM2), just: 1. Press the lower knob to choose AM, FM1 or FM2. 2.
Page 123 Comfort Controls & Audio Systems Compact Disc To Play Before you begin, please note: don’t use the mini-discs that are called “singles.” They won’t eject. Use full-size compact discs. With the audio system on, insert a disc “CD” int0 the slot with the label side up. will appear on the display and track 1 will begin to play.
Page 124 Random Press to hear a random selection of tracks. To Stop the Disc Player Turn the power off or turn the ignition key off. The disc stays in the player and will resume playing at the point where it stopped. Press ST-PL to stop playing the disc and switch to radio.
Page 125 Comfort Controls & Audio Systems 8. Press the lower knob and “000” will appear. Now you are ready to enter the last three digits of your code. Press SEEK 4 or b and hold until the fourth digit of your code appears. Release the button.
Page 126 Unlocking the Audio System after Power Failure [f power is disrupted to the audio system while in the “SEC” mode, the unit will not work and “LOC” will show on the display whenever the ignition is on. To unlock the unit: 1.
Page 127 Comfort Controls & Audio Systems Understanding Radio Reception FM Stereo stereo will give you the best sound. But FM signals will reach only about 10 to miles (16 to 65 km). And, tall buildings or hills can interfere with FM signals, causing the sound to come and go.
Page 128 Clean your tape player with a wiping-action, non-abrasive cleaning cassette, and follow the directions provided with it. Cassettes are subject to wear and the sound quality may degrade over time. Always make sure that the cassette tape is in good condition before you have your tape player serviced.
Page 129 Notes...
Page 130: Your Driving And The Road
H e r e you’ll find information about driving on different kinds of roads and in varying weather conditions We’ve also included many other useful tips on driving Your Driving and the Road ............RoadSigns .
Page 131 Your Driving and the Road Road Signs The road signs you see everywhere are coded by color, shape and symbols. It’s a idea to know these codes so that you can quickly grasp the basic meaning or intent of the sign even before you have a chance to read I 3 0 Color of Road Signs...
Page 132 BLUE signs with white letters show motorists’ services..CANOEING SWIMMING BROWN signs point out recreation areas or points of historic or cultural interest. ISTOI Shape of Road Signs The shape of the sign will tell you something, too.
Page 133 Your Driving and the RIGHT TURN KEEP LEFT OR THROUGH ONLY RIGHT RECTANGULAR (square or oblong) sigm show speed limits, parking regulations, give directions, and such information as distances to cities. Road FOOD NO RIGHT TURN Symbols on Road Signs There are many international road signs in use today.
Page 134 REVERSIBLE LANE ON MULTI-LANE ROADWAY Many city roads and expressways, and even bridges, use reversible-lane traffic control during rush hours. A red X light above a lane means no driving in that lane at that time. A green arrow means you may drive in that lane.
Page 135 The best advice anyone can give about driving is: Drive defensively. Please start with a very important safety device in your Pontiac: Buckle up. (See “Safety Belts” in the Index.) Defensive driving really means “be ready for anything.” On city streets, rural roads, or freeways, it means “always expect the...
Page 136 and designated parking areas, expect some drivers to ignore all these markings and dash straight toward one part of the lot. Pedestrians can be careless. Watch for them. In general, you must give way to pedestrians even if you know you have the right of way.
Page 137 Your Driving and the Road In most cases, these deaths are the result of someone who was drinking and driving. Over 25,000 motor vehicle-related deaths occur each year because of alcohol, and thousands of people are injured. Just how much alcohol is too much if a person plans to drive? Ideally, no one should drink alcohol and then drive.
Page 138 P"'""'NG THAT WILL RES, , . . . J A BAC .05*h IN THE TIMk SHOWN HOURS HOURS HOUR l& BODY WEIGHT IN POUNDS The law in most U.S. states sets the legal of 0.10 percent. In Canada limit at a the limit is 0.08 percent, and in some other countries it's lower than that.
Page 139 YQUF Driving and the Road Th’ere’s s0methin.g else about drinking and ‘drivmng that many people don’t know. Meducal research shows that alcohol in a system can make crash injuries person’s worse. That’s es,peciallly true for brain, spinal cord and heart injuries. That means if anyone who has been drinking that driver or passenger...
Page 140 Braking Braking action involves perception time and reaction time. First, you have to decide to push on the brake pedal. That’s perception time. Then you have to bring up your foot and do it. That’s reaction time. Average reaction time is about 3/4 of a second.
Page 141 Your Driving and the Road “Riding” your brakes can cause them to overheat to the point that they won’t work well. You might not be able to stop your vehicle in time to avoid an accident. If you “ride” your brakes, they will hot they will require a lot of pedal force to slow you down.
Page 142 Anti-Lock Brakes (ABS) Your Pontiac has an advanced electronic braking system that will help prevent skidding. This light on the instrument panel will go on when you start your vehicle. When you start your vehicle, you may hear a momentary motor or clicking noise.
Page 143 Your Driving and the Road Here’s how anti-lock works. Let’s say the road is wet. You’re driving safely. Suddenly an animal jumps out in front Y O U slam on the brakes. Here’s what happens with ABS. A computer senses that wheels are slowing down.
Page 144 Disc Brake Wear Indicators Unless you have the four-wheel disc brake option, your Pontiac has front disc brakes and rear drum brakes. Disc brake pads have built-in wear indicators that make a high-pitched warning sound when the brake pads are worn and new pads are needed.
Page 145 Your Driving and the Road Brake Pedal Travel See your dealer if the brake pedal does not return to normal height, or if there is a rapid increase in pedal travel. This could be a sign of brake trouble. Brake Adjustment Every time you make a moderate brake stop, your disc brakes adjust for wear.
Page 146 Experienced driver or beginner, each of us is subject to the same laws of physics when driving on curves. The traction of the tires against the road surface makes it possible for the vehicle to change its path when you turn the front wheels. If there’s no traction, inertia will keep the vehicle going in the same direction.
Page 147 But sometimes you can’t; there isn’t room. ‘That’s the time for evasive action steering around the problem. Your Pontiac can perform very well in emergencies like these. First apply your brakes. It is better to remove as much speed as you can from a possible collision.
Page 148 Off-Road Recovery You may find sometime that your right wheels have dropped off the edge of a road onto the shoulder (A) while you’re driving. If the level of the shoulder is only slightly below the pavement, recovery should be fairly easy.
Page 149 Your Driving and the Road here are some tips for passing: “Drive ahead.” Look down the road, to the sides, and to crossroads for situations that might affect your passing patterns. If you have any doubt whatsoever about making a successful pass, wait for a better time.
Page 150 If other cars are lined up to pass a slow vehicle, wait your turn. But take care that someone isn’t trying to pass you as you pull out to pass the slow vehicle. Remember to glance over your shoulder and check the blind spot.
Page 151 Your Driving and the Road The three types of skids correspond to your Pontiac’s three control systems. In the braking skid your wheels aren’t rolling. In the steering or cornering skid, too much speed or steering in a curve causes tires to slip and lose cornering force.
Page 152 Driving at Night Night driving is more dangerous than day driving. One reason is that some drivers we likely to be impaired by alcohol or drugs, with night vision problems, or by fatigue. Here are some tips on night driving. Drive defensively.
Page 153 Your Driving and the Road Night Vision No one can see as well at night as in the daytime. But as we get older these differences increase. 50-year-old driver may require at least twice as much light to see the same thing at night as a 20-year-old.
Page 154 High Beams If the vehicle approaching you has its high beams on, signal by flicking yours to high and then back to low beam. This is the usual signal to lower the headlight beams. If the other driver still doesn’t lower the beams, resist the temptation to put your high beams on.
Page 155 Your Driving and the Road Driving in the Rain Rain and wet roads can mean driving trouble. On a wet road you can’t stop, accelerate or turn as well because your tire-to-road traction isn’t as good as on dry roads. And, your tires don’t have much tread left, you’ll get even less traction.
Page 156 bHU 1 1 v 1 v ; Wet brakes can cause accidents. They won’t work a quick stop and may cause well in p.ulling to one side. You could lose control of the vehicle. After through a large puddle driving of water or a car wash, apply your brake pedal lightly until your brakes work normally.
Page 157 Your Driving and the Road Sionze Other Rainy Weather Tips e Turn your hadIights nut just your parking lights to help make yrru more visible to others. Laok for hard-to-see vehicles coming i h m behind. may want to your headlights even in daytime if it’s raining hard.
Page 158 When you drive into a fog patch, your visibility will be reduced quickly. The biggest dangers are striking the vehicle ahead or being struck by the one behind. Try to “read” the fog density down the road. If the vehicle ahead starts to become less clear or, at night, if the taillights are harder to see, the fog is probably thickening.
Page 159 Your Driving and the Road Treat dense fog as an emergency. Try to find a place to pull off .the road. Of course you want to respect another’s property, but you might need to put something between you and moving vehicles space, trees, telephone poles, a private driveway, anything that removes you from other traffic.
Page 160 Try to use the freeways that rim and crisscross most large cities. You’ll save time and energy. (See the next section, “Freeway Driving.”) Treat a green light as a warning signal. A traffic light is there because the corner is busy enough to need if. When a light turns green, and just before you start to move, check both ways for vehicles that have not...
Page 161 Your Driving and the Road Entering the Freeway At the entrance there is usually a ramp that leads to the freeway. If you have a clear view of the freeway as you drive along the entrance ramp, you should begin to check traffic. Try to determine where you expect to blend with the flow.
Page 162 Leaving the Freeway When you want to leave the freeway, move to the proper lane well in advance. Dashing across lanes at the last minute is dangerous. If you miss your exit do not, under any circumstances, stop and back up.
Page 163 If needs service, have done before starting out. Of course, you’ll find experienced and able service experts in Pontiac dealerships all across North Ameri’ca. They’ll be ready and willing to help if you need 1 1 8 2 Here are some things you can check...
Page 164 On two-lane highways or undivided multilane highways that do not have controlled access, you’ll want to watch for some situations not usually found on freeways. Examples are: stop signs and signals, shopping centers with direct access to the highway, no passing zones and school zones, vehicles turning left and right off the road, pedestrians, cyclists, parked vehicles, and even...
Page 165 Your Driving and Wear good sunglasses in bright light. Clare can cause drowsiness. But don’t wear sunglasses at night. They will drastically reduce your overall vision the very time you need ail the seeing power you have. a If you get sleepy, pull off the road into a rest, service, or parking area and take a nap, get some exercise, or both.
Page 166 Coasting downhill in N (Neutral) or with the I ~ I I I L I V I I off is dangerous. Your brakes will have to do all the work of slowing down. They could get so hot that they wouldn’t work well. You could crash.
Page 167 Your Driving and the Road Parking on Hills Hills and mountains mean spectacular scenery. But please be careful where you stop if you decide to look at the view or take pictures. Look for pull-offs or parking areas provided for scenic viewing.
Page 168 If you’re going uphill on a one-way street and you’re parking on the left side, your wheels should point to the right. If there is no curb when you’re parking uphill, turn the wheels to the right. If there is no curb when you’re parking uphill on the left side of a one-way street, your wheels should be turned to the left.
Page 169 Your Driving and the Road Winter Driving Here are some tips for winter driving: Have your Pontiac in good shape for winter. Be sure your engine coolant mix is correct. Snow tires can help in loose snow, but they may give you less traction on ice than regular tires.
Page 170 What’s the worst time for this? “Wet ice.” Very cold snow or ice can be slick and hard to drive on. But wet ice can be even more trouble because it may offer the least traction of all. You can get “wet ice” when it’s about freezing (32°F;...
Page 171 Your Driving and the Road If You’re Caught in a Blizzard If you are stopped by heavy snow, you could be in a serious situation. You should probably stay with your vehicle unless you know for sure that you are near help and you can hike through the snow.
Page 172 Run your engine only as long as you must. This saves fuel. When you run the engine, make go a little faster than just idle. That is, push the accelerator slightly. This uses less fuel for the heat that you get and it keeps the battery charged.
Page 173 Your Driving and the Road NOTICE; Your vehicle can tow a trailer if it is equipped with the proper trailer towing equipment. To identify what the vehicle trailering capacity is for your vehicle, you should read the information in "Weight of the Trailer"...
Page 174 You can ask your dealer for our trailering information or advice, or you can write us at: Pontiac Division Customer Assistance Center One Pontiac Plaza Pontiac, MI 48340-2952 In Canada, write to: General Motors of Canada Limited Customer Assistance Center...
Page 175 Your Driving and the Road Weight of the Trailer Tongue The tongue load of any trailer is an important weight to measure because it affects the total capacity weight of your vehicle. The capacity weight includes the curb weight of the vehicle, any cargo you may carry in it, and the people who will be riding in the vehicle.
Page 176 Here are some rules to follow: Will you have to make any holes in the body of your vehicle when you install a trailer hitch? If you do, then be sure to seal the holes later when you remove the hitch. If you don’t seal them, deadly carbon monoxide (CO) from your exhaust can get into your vehicle (see “Carbon Monoxide”...
Page 177 Your Driving and the Road Driving with a Trailer Towing a trailer requires a certain amount of experience. Before setting out for the open road, you’ll want to get to know your rig. Acquaint yourself with the feel of handling and braking with the added weight of the trailer.
Page 178 Making Turns When you’re turning with a trailer, make wider turns than normal. Do this so your trailer won’t strike soft shoulders, curbs, road signs, trees, or other objects. Avoid jerky or sudden maneuvers. Signal well in advance. Turn Signals When Towing a Trailer When you tow a trailer, your vehicle has to have a different turn signal flasher and extra wiring.
Page 179 Your Driving and the Road Parking on Hills You really should not park your vehicle, with a trailer attached, on a hill. If something goes wrong, your rig could start to move. People can be injured, and both your vehicle and the trailer can be damaged.
Page 180 Maintenance When Trailer Towing Your vehicle will need service more often when you’re pulling a trailer. See the Maintenance Schedule for more on this. Things that are especially important in trailer operation are automatic transmission fluid (don’t overfill), engine oil, axle lubricant, belts, cooling system, and brake adjustment.
Page 181 Notes...
Page 182: Problems On The Road
- - - . H e r e you’ll find what to do about some problems that can occur on the road Hazard Warning Flashers lump Starting rowing Your Vehicle Engine Overheating [f a Tire Goes Flat [f You’re Stuck: In Sand. Mud. Ice or Snow Part Problems on the Road...
Page 183 Problems on the Road Flashers Your hazard warning flashers let you warn others. They also let police know you have a problem. Your front and rear turn signal lights will flash and off..Press the button in to make your front and rear turn signal lights flash on and off.
Page 184 Jump Starting If your battery has run down, you may want to use another vehicle and some jumper cables to start your Pontiac. But please follow the steps below to do safely. CAUTION: Batteries can hurt you. TI can be dangerous because:- They contain acid that can you.
Page 185 If they are, it could cause a ground connection you don’t want. You wouldn’t be able start your Pontiac, and the bad grounding could damage the electrical systems. You could be injured if the vehicles roll. Set the parking brake firmly on each vehicle.
Page 186 4. Open the hoods and locate the batteries. LAW I IUN: ~~~~ An electric fan can start up even when the engine is not running and can injure you, Keep hands, clothing and tools away from any underhood electric fan. Find the positive and negative terminals on each battery.
Page 187 Don’t let the other end touch metal. Connect it to the positive terminal of the good battery. Use a remote positive terminal if the vehicle has one. But don’t use the junction block on your Pontiac.
Page 188 Now connect the black negative cable to the good battery’s negative terminal. Don’t let the other end touch anything until the next step. The other end of doesn’t go the negative cable to the dead battery. It goes to a heavy unpainted metal part on the engine the vehicle with the dead battery.
Page 189 Road Towing Your Vehicle Try to have a dealer or a professional towing service tow your Pontiac. The usual towing equipment is a sling-type (A) or a wheel-lift (B) or car carrier (C) tow truck. If your vehicle has been changed or...
Page 190 When your vehicle is being towed, have the ignition key off. The steering wheel should be clamped in a straight-ahead position, with a clamping device designed for towing service. not use the vehicle’s steering column lock for this. Neutral The transmission should be in and the parking brake released.
Page 191 Use wheel lift or car carrier equipment. Additional ramping may be required for car carrier equipment. Attach a separate safety chain around outboard end of each lower control arm. pipes and hoses or the ABS sensor and wiring. 'lowing a vehicle over rough surtaces could damage a vehicle.
Page 192 To help avoid damage, install a towing dolly and raise vehicle until proper clearance is obtained between on your Pontiac's instrument panel. You may also find a low coolant warning light on your Pontiac instrument panel.
Page 193 Problems on the Road If Steam Is Coming from Engine: Your NOTICE: engine calLIIL., ,,,cause your I 11 y o u keep driving wilh no coolant. your vehicle be badly damaged. The costly repairs wouldnot be- covered by your warranty. Steam Is Coming from Your Engine: If you get the overheat warning but see or...
Page 194 If you get the overheat warning with no sign of steam, try this for a minute or so: 1. If you have an air conditioner, turn off. 2. Turn on your heater to full hot at the highest fan speed and open the window as necessary.
Page 195 Problems on the Road On the V8 engine you’ll see this: 1. Coldant recovery tank 2. Radiator pressure cap Electric engine fans CAUTION: An electric fan under the hood can start engine is not running and can injure you. Keep hands, clothing and tools away from any underhood electric f a n :...
Page 196 If there seems to be no leak, check to see if the electric engine fan is running. If the engine is overheating, the fan should be running. If it isn’t, your vehicle needs service. to Add Coolant to the Coolant Recovery Tank If you haven’t found a problem yet, but the coolant level isn’t...
Page 197 Problems on the Road In cold weather, water can freeze and crack the engine, radiator, heater core and other parts. Use th ecommended coolant You can be burned if you spill coolant on hot engine parts. Coolant contains ethylene glycol and it will burn if the engine parts are hot enough.
Page 198 How to Add Coolant to the Radiator [3.41, L32 (Code S ) Engine) 1. You can remove the radiator pressure cap when the cooling system, including the radiator pressure cap and upper radiator hose, is no longer hot. Turn the pressure cap slowly to the left until first stops.
Page 199 Problems on the Road 4. Then fill the coolant recovery tank to FULL COLD. 5. Put the cap back on the coolant recovery tank, but leave the radiator pressure cap off. Start the engine and let run until you can feel the upper radiator hose getting hot.
Page 200 7. Then replace the pressure cap. Be sure the arrows on the pressure cap line up like this. How to Add Coolant to the Radiator (5.7L LTl (Code P) Engine) 1. You can remove the radiator pressure cap when the cooling system, including the radiator pressure cap and upper radiator hose, is no longer hot.
Page 201 Problems on the Road 2. Then keep turning the pressure cap, but now push down as you turn it. Remove the pressure cap. you spm coolant on hot engine parts. contains ethylene glycol Coolant and it will burn if the engine parts are hot enough.
Page 202 Continue to fill the radiator up to the base of the filler neck. 7. Rinse or wipe the spilled coolant from the engine and compartment. 8. Start the engine and allow to run in idle for approximately four minutes. By this time, the coolant level inside the radiator will be lower.
Page 203 Then fill the coolant recovery tank to the proper level. , : o r a complete drain, flush and refill, see your Pontiac dealer or a Pontiac Firebird Service Manual. To purchase a service manual, see “Service Publications” in the Index.
Page 204 A rear blowout, particularly on a curve, acts much like a skid and may require the same correction you’d use in a skid. In any rear blowout, remove your foot from the accelerator pedal. Get the vehicle under control by steering the way you want the vehicle to go.
Page 205 Problems on the Road The following steps will tell you how to use the jack and change a tire. The equipment you'll need is in the rear area. Find the plastic screw heads in the trim panel over the spare tire. Use a coin or a key to turn the screw heads until the slots point front and back.
Page 206 Remove the wing nut and adapter and pull out the spare. Start with the jack (A) and wheel wrench (B). The jack has a bolt at the end. Attach the wheel wrench to the jack bolt. Turn the wheel wrench to the right to raise the lift head a little.
Page 207 Problems on the Road If your vehicle has a bolt-on center cap, loosen the plastic caps using the wheel wrench. Then pry off the center cap with the wheel wrench. If your vehicle has optional alloy wheels, each wheel may have one locknut in place of the standard wheel nut.
Page 208 Position the jack under the vehicle. There is a notch in the vehicle’s rocker flange. Raise the jack head until it fits firmly into the notch nearest the flat tire. away from the moldings or fender langes to avoid damaging them. Getting under a vehicle when it is jacked up is dangerous.
Page 209 Problems on the Road Raising your vehicle the jack with improperly positioned will dama the vehicle or may allow the veh to fall the jack. Be sure to the jack lift head into the proper location before raising your vehi Raise the vehicle by rotating wheel Remove all the wrench clockwise.
Page 210 Rust or dirt- on wheel, or an parts to which it is fastened, can make the wheel nuts become loose after time. wheel could off and cause an accident. come When you change a wheel, remove rust or dirt the-places from attaches where the...
Page 211 "roblems on the Road Lower the vehicle by rotating the wheel wrench counterclockwise. Lower the jack completely. Tighten the wheel nuts firmly in a criss-cross sequence as shown. Incorrect wheel nuts or improperly tightened wheel nuts can cause the wheel to become loose and even come off.
Page 212 Replace the jack, wheel wrench and flat tire using the storage instructions. When you replace the trim panel, be sure to tuck it under the weatherstrip. Trim Panel 2. Bolt Cover 4. Jack 5. Wing Nut 6. Adapter 7. Compact Spare Tire 8.
Page 213 Problems on the Road CAUTION: Storing a jack, a tire or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store all these in the proper place. Spare Compact Although the compact spare was fully...
Page 214 NOTICE: Don’t use your compact spare on some other vehicle. And don’t mix your compact spare or wheel with other wheels or tires. They won’t fit. Keep your spare and its wheel together. ‘ ’ You’re Stuck: In Sand, Mud, Ice or must use caution.
Page 215 Problems on the Road 21 4 Rocking your vehicle to get it out: First, turn your steering wheel left and right. That will clear the area around your front wheels. Then shift back and forth between (Reverse) and a forward gear (or with a manual transmission, between First or Second gear and Reverse), spinning the wheels as little as possible.
Page 216: Service & Appearance Care
..H e r e you will find information about the care of your Pontiac This part begins with service and fuel information. and then it shows how to check important fluid and...
Page 217 Pontiac Service Manual, It tells you much more about how to service ya Pontiac than this manual can. To order tne proper service manual, see “Service Publications” in the Index. You should keep a record with all parts receipts and list the mileage and the date of any service work you perform.
Page 218 Fuel The 8th digit of your Vehicle Identification Number (VIN) shows the code letter for your engine. You will find the VIN at the top left of your instrument panel. (See “Vehicle Identification Number” in the Index.) 3.4L L32 (Code S) Use regular unleaded gasoline rated at 87 octane or higher.
Page 219 Service & Appearance Care LT1 (Code 5.7L Use premium unleaded gasoline rated at 91 octane or higher. You may use middle grade or regular unleaded gasolines, but your vehicle may not accelerate as well. The gasoline you use should meet specifications ASTM D4814 in the U.S.
Page 220 Methanol is methyl or wood alcohol. NOTICE: Gasolines for Cleaner Air Your use of gasoline with detergent additives will help prevent deposits from forming in your engine and fuel system. That helps keep your engine in tune and your emission control system working properly.
Page 221 Service & Appearance Care Fuels in Foreign Countries If you plan on driving in another country outside the U.S. or Canada, unleaded fuel may be hard to find. Do not use leaded gasoline. If you use even one tankful, your emission controls won’t work well or at all.
Page 222 To take off the cap, turn it slowly to the left (counterclockwise). CAUTION: If you get gasoline on you and then something ignites it, you could be badly burned. Gasoline can spray out on you if you open the fuel filler cap too quickly. This spray can happen if your tank is nearly full, and is more likely in hot weather.
Page 223 Service & Appearance Care Then go to the front of the vehicle and pull up on the hood release. Lift the hood. CAUTION: An electric fan under the hood can start up and injure you even when the engine is not running.
Page 224 When you open the hood you’ll see: 1. Battery 2. Engine Coolant Reservoir Engine Oil Dipstick 4. Automatic Transmission Dipstick (if equipped) Air Cleaner 5 . 7 ~ L Z ~ (Code 6. Oil Fill Cap 7. Brake Fluid Reservoir 8.
Page 225 Service & Appearance Care 3.4L L32 (Code S) Engine Oil It’s a good idea to check your engine oil every time you get fuel. In order to get an accurate reading, the oil must be warm and the vehicle must be on level ground. 5 .
Page 226 Check Engine Oil 5.7L LT1 (Code P) Engine) ’ull out the dipstick slightly. Pinch the :nd of the dipstick tube as you remove he dipstick to wipe the oil from it. Push t all the way back in. Now remove it vithout pinching the tube, keeping the ip lower.
Page 227 Service & Appearance Care What Kind of Oil to Use: Look for three things: SG must be on the oil container, either by itself or combined with other quality designations, such as SG/CC, SG/CD, SF, SG, CC, etc. These letters show American Petroleum Institute (API) levels of quality.
Page 228 Engine Oil Additives: Don’t add anything to your oil. Your Pontiac dealer is ready to advise if you think something should be added. When to Change Engine Oil: See if any one of these is true for you:...
Page 229 Service & Appearance Care What to Do with Used Oil: I I U I V ; Used engine oil contains things that have caused skin cancer in raooratory animals. Don’t let used oil stay on your skin for very long. Clean your skin and nails with soap and water, or a good hand cleaner.
Page 230 5.7L (Code CAUTION: Operating the engine with the air cleaner off can cause you or others to be burned. The air cleaner not only cleans the air, it stops flame if the engine backfires. If it isn’t there, and the engine backfires, you could be burned.
Page 231 Service & Appearance Care Disconnect the plastic clamp on the duct. Pull apart the connection. Pull the air cleaner straight up. Unclamp the metal clips. Open the air cleaner and remove the filter.
Page 232 How to Check: Because this operation can be a little difficult, you may choose to have this done at a Pontiac dealership Service Department. If you do it yourself, be sure to follow all the instructions here, or you could get a false reading on the dipstick.
Page 233 Service & Appearance Care T o check transmission fluid cold: A cold check is made after the vehicle has been sitting for eight hours or more with the engine off and is used only as a reference. Let the engine run at idle for five minutes "...
Page 234 5 . 7 L LTl (Code 2. Push it back in all the way, wait three seconds and then pull it back out again. Check both sides of the dipstick, and read the lower level. The fluid COLD level must be in the area for a cold check or in the HOT area or cross-hatched area for a hot check.
Page 235 How to Check: Because this operation can be a little difficult, you may choose to have this done at a Pontiac dealership Service Department. If you do yourself, be sure to follow all the instructions here, or you could get a false reading.
Page 236 How to Add Fluid: 4ere’s how to add fluid. Refer to the aaintenance Schedule to determine what ;ind of fluid to use. See “Recommended ?luids and Lubricants” in the Index. I. Remove the filler plug. Add fluid at the filler plug hole. Add only enough fluid to bring the fluid level up to the bottom of the filler plug hole.
Page 237 Service & Appearance Care Rear Axle When to Check and Change Lubricant: Refer to the Maintenance Schedule to determine how often to check the lubricant and when to change it. See “Periodic Maintenance Inspections” in the Index. How to Check Lubricant: If the level is below the bottom of the filler plug hole, you’ll need to add some lubricant.
Page 238 If you have a problem with engine overheating, see “Engine Overheating’’ in the Index. The proper coolant for your Pontiac will: Give freezing protection down to -34°F (-37°C). Give boiling protection up to 262°F (128°C).
Page 239 Service & Appearance Care NOTICE: if you use an improper coolant mix, your engine could overheat an badly damaged. The repair co wouldn’t be covered by your warranty. Too much water in mix can freeze and crack the radiator, heater core and other parts. Adding Coolant To Check Coolant: When your engine is cold, check the dipstick on the cap...
Page 240 To Add Coolant to the Recovery Tank: need more coalant, add the proper at the coolant recovery tank, only when your engine is cool. If the tank is very low or empty, also add coolant to the radiator. See the following procedure and refer to “Engine Overheating”...
Page 241 Service & Appearance Care Radiator Pressure Cap (All Engines) When you replace your radiator pressure cap, an A P cap is recommended. I'hermostat Engine coolant temperature is controlled by a thermostat in the engine coolant system. The thermostat stops the flow of zoolant through the radiator until the :oolant reaches a preset temperature.
Page 242 3 . 4 L L32 (Code S) Power Steering Fluid How to Check Power Steering Fluid: Unscrew the cap and wipe the dipstick with a clean rag. Replace the cap and completely tighten it. Then remove the cap again and look at the fluid level on the dipstick.
Page 243 Service & Appearance Care Whdshield Washer Fluid To Add: WASHER FLUID Open the cap labeled ONLY. Add washer fluid until the bottle is full. NOTICE: washer fluid, follow the manufacturer's instructions Don't mix water Water can cause the sol freeze and damage your washer fluid tank and ot parts of the washer system.
Page 244 So, it isn’t a good idea to “top off’ your brake fluid. Adding brake fluid won’t correct a leak. If you add fluid when your linings are worn, then you’ll have too much fluid when you get new brake linings. should add (or remove) brake fluid, as necessary, only when work is done on the brake hydraulic system.
Page 245 Vehicles we design and test have top-quality GM brake parts in them, as your Pontiac does when it is new. When you replace parts of your braking system for example, when your brake linings...
Page 246 Battery Every new Pontiac has a Delco Freedom@ battery. You never have to add water to one of these. When it’s time for a new battery, we recommend a Delco Freedom@ battery. Get one that has the catalog number shown on the original hurt.
Page 247 Service & Appearance Care Headlights T o replace a headlight: 1. Open the headlight door by hand. See “Headlight Doors” in the Index. Unscrew the bezel with a screwdriver and m o v e it. Remove the screws and pull aut the bulb housing.
Page 248 Center High-Mounted Stoplight To replace the bulb: 1. Remove the two screws in the stoplight lens. 2. Gently pull the assembly out and remove the bulb from the back of the assembly. Reverse the steps with a new bulb. Front f i r n Signal 1.
Page 249 Service & Appearance Care Turn and pull out the socket and the bulb. Pull out the bulb. 4. Reverse the steps with a new bulb Rear Lights To change any rear bulb, you have remove the entire housing. 1. Remove the trim panel from the side that you are replacing the bulb.
Page 250 Rear Sidemarker TO replace rear sidemarker bulk fiam Remove the screw sidemarker assembly. pull out bulb hauBiing, tilt the remove the t&bd end. housing T u r n counterclockwise pull out the socket and the bulb. 4. Pull out the bulb. 5.
Page 251 Service & Appearance Care TIRE-LOADING INFORMATION OCCUPANTS VEHlCLE CAP. CRT. FRT. TOTAL 1199 MAX. LOADING GVWR SAME AS VEHICLE CAPACITY WEIGHT BBW COLD TIRE SIZE SPEED Loading Your Vehicle Two labels on your vehicle show how much weight it may properly carry. The Tire-Loading Information label found on the driver’s door tells you the proper size, speed rating and recommended inflation...
Page 252 These tires are warranted 'by the tire manufacturers and their warranties are delivered with every new Pontiac. If your spare tire is a different brand than your road tires, you will have a tire warranty folder from each...
Page 253 Service & Appearance Care CAUTION: Poorly maintained and improperly used tires are dangerous. Overloading your tires can cause overheating as a result of too much friction. You could have an air-out and a serious accident. See “Loading Your Vehicle” in the Index.
Page 254 When C k k : Check your tires once a month ar more. Don’t forget your compact spare tire. It should be at (420 kPa). How to Check: Use a quality good pocket-type gage to check tire pressure. Simply looking at the tires will not tell yau the pressure, especially if have radial tires...
Page 255 Service & Appearance Care Rust or dirt on a wneel, or on the parts to which it is fastenec can make wheel nuts become loose after a time. The wheel could come off and cause an accident. When change a wheel, remove any rust or dirt from places where the wheel attaches to the vehicle.
Page 256 give proper endurance, handling, speed rating, traction, ride and other things during normal service on your vehicle. If your tires have an all-season tread design, number will be followed by a *‘MS” (for mud and snow). If you ever replace your tires with those not having a TPC Spec number, make sure they are the same size, load range, speed rating and construction type (bias,...
Page 257 Service & Appearance Care I‘readwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and a half (1 1/2) times as well on the government course as a tire graded 100.
Page 258 Warning: The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. Those grades are molded on the sidewalls of passenger car tires.
Page 259 If the wheel leaks air out, replace it (except some aluminum wheels, which can sometimes be repaired). See your Pontiac dealer if any of these conditions exist. Your dealer will know the kind of wheel you need.
Page 260 It could fail suddenly and cause an accident. If you have to replace a wheel use a new GM original equipment wheel. If your Pontiac has P235/55RI6 or P245/5OZR16 size tires, don’t use tire chains; they can damage your vehicle.
Page 261 When you use anything in a container clean your Pontiac, be sure to follow the instructions. And always open your doors or windows when you're cleaning the inside. Never use...
Page 262 Use a vacuum cleaner often to get rid of dust and loose dirt. Wipe vinyl with a clean, damp cloth. Your Pontiac dealer has two GM cleaners a solvent-type spot lifter and a foam-type powdered cleaner. They will clean normal spots and stains very well.
Page 263 Service & Appearance Care As soon as you’ve cleaned the section, use a sponge to remove the suds. Rinse the section with a clean, wet sponge. Wipe off what’s left with a slightly damp paper towel or cloth. Then dry immediately with an air hose, a hair dryer or a heat lamp.
Page 264 Special Cleaning Problems Greasy or oily stains: Like grease, oil, butter, margarine, shoe polish, coffee with :ream, chewing gum, cosmetic creams, vegetable oils, wax crayon, asphalt. Carefully scrape off excess stain. Then follow the solvent-type instructions above. Shoe polish, wax crayon, tar and asphalt will stain if left on a vehicle seat fabric.
Page 265 Service & Appearance Care Cleaning Vinyl or Leather Just use warm water and a clean cloth. Rub with a clean, damp cloth to remove dirt. You may have to do more than once. Things like tar, asphalt and shoe polish will stain if you don’t get them off quickly.
Page 266 Glass Glass should be cleaned often. GM Glass Cleaner (GM Part No. 1050427) or a liquid household glass cleaner will remove normal tobacco smoke and dust films. Don’t use abrasive cleaners on glass, because they may cause scratches. Avoid placing decals on the inside rear window, since they may have to be scraped off later.
Page 267 High pressure car washes may cause water to enter your vehicle. Finish Care Occasional waxing or mild polishing of your Pontiac may be necessary to remove residue from the paint finish. You can get GM approved cleaning products from your dealer. (See “Appearance Care and Maintenance Materials”...
Page 268 Aluminum Wheels Your aluminum vkheels have a protective coating similar to the painted surface of vehicle. Don’t use strong soaps, your chemicals, chrome polish, or other abrasive cleaners on them because you could damage this coating. After rinsing thoroughly, a wax may be applied. f you have aluminum wheels, don’t se an automatic car wash that has ard silicon carbide cleanin...
Page 269 Although no defect in the paint job causes this, Pontiac will repair, at no charge to the owner, the surfaces of new vehicles damaged by this fallout condition within 12 months or 12,000 miles (20 000...
Page 270 Appearance Care and Maintenance Materials i : R ; " iiL: 1050174 (0.473 L) >.<;,.t*,*:v<> *Not recommended for pigskin suede leather. your General Motors Dealers for these products. White Sidewall Tire Cleaner your Maintenance Schedule for other products. Cleans white black tires...
Page 271 Vehicle Identification Number (VIN) This is the legal identifier for your Pontiac. It appears on a plate in the front corner of the instrument panel, on the driver's side. You can see it if you look through the windshield from outside your vehicle.
Page 272 Fuses and Circuit Breakers The wiring circuits in your vehicle are from protected short circuits by a combination of fuses, circuit breakers, and fusible thermal links in the wiring itself. This greatly reduces the chance of fires caused electrical problems. There are two fuse centers on your vehicle.
Page 273 Service & Appearance Care Power Windows and Other Power Options Circuit breakers protect the power windows and other power accessories. When the current load is too heavy, the circuit breaker opens and closes, protecting the circuit until the problem is fixed or goes away.
Page 274 Underhood Electrical Center Fuses Electronic Brake Control Module Amp.) Fog Lamps (20 Amp.) Headlight Doors Module (1 5 Amp.) Headlight Doors Module (1 5 Amp.) Anti-Lock Brake System ( 5 Amp.) Coolant Fan Relays; EVAP Canister Purge Solenoid; Exhaust Gas Recirculation; Reverse Lockout Solenoid (10 Amp.) *z3??3>j$<>r+gq.
Page 275 Service & Appearance Care Replacement Bulbs Ashtray" Automatic Transmission Indicator Backup Center High-Mounted Stoplight Cluster Console Dome DoorCourtesy ............. Front Parking and Turn Signal GloveBox Headlight...
Page 276 Capacities and Specifications Engine Type VIN Engine Code S VINEngineCodeP ..........V 8 Fuel Delivery Valve Arrangement Piston Displacement...
Page 277 Wheel Nut Torque tNot all air conditioning refrigerants are the same. If the air conditioning system in your vehicle needs refrigerant, be sure the proper refrigerant is used. If you're not sure, ask your Pontiac dealer. CV789C CV895C oR43TSK (0.045'' Gap) oR45LTSP (0.050"...
Page 278 Capacities (Approximate) The following approximate capacities are given in U.S. and metric conversions..Air Conditioningt See the refrigerant information label under the hood. Automatic Transmission Drain and Refill Overhaul VIN Engine Code S VIN Engine Code P Cooling System VIN Engine Code S With Manual Transmission...
Page 279 Service & Appearance Care Vehicle Dimensions Wheelbase Tread ..........Front .
Page 280: Maintenance Schedule
KEEP ENGINE OIL AT THE PROPER LEVEL AND CHANGE. AS RECO MENDED T h i s part covers the maintenance required for your Pontiac Your vehicle needs these services to retain its safety. dependability and emission control performance Section Introduction: A Word about Maintenance...
Page 281 So please read this part and note how you drive. If you have any questions on how to keep your vehicle in good condition, see your Pontiac dealer, the place many GM owners choose to have their maintenance work done.
Page 282 ‘‘Section C: Periodic Maintenance Inspections” explains a vehicle can be important inspections that your Pontiac dealer’s service jobs, you can be department or another qualified service center should perform.
Page 283 Maintenance Schedule Introduction: A Word about Maintenance “Section D: Recommended Fluids and Lubricants” lists some products GM recommends to help keep your vehicle properly maintained. These products, or their equivalents, should be used whether you do the work yourself or have it done.
Page 284 This section tells you the maintenance services you should have done and when you should schedule them. Your Pontiac dealer knows your vehicle best and wants you to be happy with it. If you go to your dealer for your service needs, you’ll know that GM-trained and supported...
Page 285 Maintenance Schedule Section A: Scheduled Maintenance Services Schedule I Follow Schedule I if your vehicle is MAINLY driven under one or more of the following conditions: When most trips are less than miles km). When most trips are less than 10 miles (1 6 and outside temperatures remain below freezing.
Page 286 The services shown in this schedule up to 48,000 miles (80 OOO should be performed after 48,000 miles at the same intervals. MILES (000)
Page 287 Maintenance Schedule Section A: Scheduled Maintenance Services Schedule /I Follow Schedule I1 ONLY if none of the driving conditions specified in Schedule I apply. *An Emission Control Service. Environmental Protection Agency has determined that the failure to per$orm this maintenance item will not nullify the emission warranty or limit recall liability prior to the completion of vehicle useful life.
Page 288 The services shown in this schedule up 45,000 miles (75 OOO should be performed after 45,000 miles at the same intervals. MILES (000) 22.5 37.5 KILOMETERS 1000)
Page 289 Maintenance Schedule Section A: Scheduled Maintenance Services Explanation of Scheduled Maintenance SeMces Below are explanations of the services listed in Schedule I and Schedule 11. The proper fluids and lubricants to use are listed in Section D. Make sure whoever services your vehicle uses these. All ITEM NO.
Page 290 ITEM NO. SERVICE Cooling System Service* the system with new or approved recycled coolant conforming to Specification 1825M. Keep coolant at the proper mixture as specified. See “Coolant” in the Index. This provides proper freeze protection, corrosion inhibitor level and engine operating temperature.
Page 291 Maintenance Schedule, Section A: Scheduled Maintenance Services ITEM NO. SERVICE Transmission Service For manual transmissions, fluid doesn’t require changing. For automatic transmissions, change both the fluid and filter every 15,000 miles (25 000 vehicle is mainly driven under one or more of these conditions: In heavy city traffic where the outside temperature regularly reaches 90°F (32°C) or...
Page 292 ITEM SERVtCE Spark Plug Wire Inspection** burns, cracks or other damage. Check the boot fit at the distributor and at the spark plugs. Replace wires as needed. Air Cleaner Filter and Crankcase Ventilation Filter Replacement* Replace every 30,000 miles (50 000 or more often under dusty conditions.
Page 293 Maintenance Schedule Section B: Owner Checks and Services Listed below are owner checks and services which should be performed at the intervals specified to help ensure the safety, dependability and emission control performance of your vehicle. Each Fuel Fill (It is important for you or a service station attendant to perform these underhood checks at each fuel CHECK OR SERVICE Engine Oil Level...
Page 294 At Least Once a Month CHECK OR SERVICE Tire Inflation Check tire inflation. Make sure they are inflated to the pressures specified on the Tire-Loading Information label located on the rear edge of the driver’s door. See “Tires” in the Index for further details.
Page 295 Maintenance Schedule Section B: Owner Checks and Services Once a Year At leasf CHECK OR SERVICE Key Lock Cylinders Lubricate the key lock cylinders with the lubricant specified in Section Body Lubrication Lubricate all body door hinges, including the hatchback lid. Also lubricate all hinges and latches, including those for the hood, headlight door assemblies (including spring links), rear Starter Switch Before you start, be sure you have enough room around the vehicle.
Page 296 At Least Once a Year (cant.) CHECK OR SERVICE CAUTION: Brake Transmission Brake Transmission When you are doing this check, the vehicle could move suddenly. If Shift Interlock-BTSI Shift Interlock-BTSI Before you start, be sure you have enough room arouna me venicle. It should be parked on level surface.
Page 297 Maintenance Schedule Section Owner Checks and Services At Least Once a Year (cant.) Parking Brake and When you Automatic Transmission could be injured and property could be damaged. Make sure there is room (Park) Mechanism of your vehicle in case it begins to roll. Check Park on a fairly steep hill, with the vehicle facing downhill.
Page 298 Maintenance Schedule Section C: Periodic Maintenance Inspections Listed below are inspections and services which should be performed at least twice a year (for instance, each spring and fall). You should let your GM dealer’s service INSPECTION OR SERVICE Steering and Suspension Inspect the front and rear suspension and steering system for damaged, loose or missing parts, Inspection signs of wear, or lack of lubrication.
Page 299 Maintenance Schedule Section C: Periodic Maintenance Inspections INSPECTION OR SERVICE Rear Axle Service Check the gear lubricant level in the rear axle and add if needed. See “Rear Axle” in the Index. A fluid loss in this system may indicate a problem. Check the system and repair it if needed. your vehicle is used to pull a trailer, change the gear lubricant every 7,500 miles Brake System Inspect the complete system.
Page 300 Maintenance Schedule Section D: Recommended Fluids & Lubricants NOTE: Fluids and lubricants identified below by name, part number or specification may be obtained from your GM dealer. GM Goodwrench Motor Oil or equivalent for API service SG Energy Conserving I1 oils of the proper viscosity.
Page 301 Maintenance Schedule Section D: Recommended Fluids & Lubricants USAGE Lubricate with Multi-Purpose Lubricant (GM Part Lock Cylinders oil or silicone lubricant (GM Part No. 1052276 or 1052277). Automatic Transmission Engine Oil. Shift Linkage Clutch Linkage Pivot Engine Oil. Points Engine Oil. Floor Shift Linkage Chassis lubricant meeting requirements of NLGI Grade 2, Category LB or GC-LB Chassis Lubrication...
Page 302 USAGE Axle Lubricant (GM Part No. 1052271) or SAE 8OW-90 GL-5 Gear Lubricant. Rear Axle (Standard and Limited-Slip Differential) Hood Latch Assembly a. Pivots and Spring a. Engine oil. Anchor b. Release Pawl b. Chassis lubricant meeting requirements of NLGI Grade 2, Category LB or GC-LB (GM Part No.
Page 303 Maintenance Schedule Section E: Maintenance Record After the scheduled services are performed, record the date, odometer reading and who performed the service in the columns indicated. When completing the Maintenance Performed column, insert the numbers from the Schedule I DATE ODOMETER READING or Schedule I1 maintenance charts which correspond to the...
Page 304 ODOMETER DATE SERVICED BY MAINTENANCE PERFORMED READING...
Page 305 Maintenance Schedule Section E: Maintenance Record (Cont.) ODOMETER SERVICED BY MAINTENANCE PERFORMED DATE READING...
Page 306 ODOMETER DATE SERVICED BY MAINTENANCE PERFORMED READING...
Page 307 Maintenance Schedule Section E: Maintenance Record (Cont.) ODOMETER MAINTENANCE PERFORMED DATE SERVICED BY READING...
Page 308: Customer Assistance Information
Part Customer Assistance Information defects.
Page 309 Customer Assistance Information Customer Satisfaction Procedure Your satisfaction and goodwill are important to your dealer and Pontiac. Normally, any concerns with the sales transaction or the operation of your vehicle will be resolved by your dealer’s Sales or Service Departments.
Page 310 Nature of concern We encourage you to call the toll-free number listed previously in order to give your inquiry prompt attention. However, if you wish to write Pontiac, write to: United States Pontiac Division Customer Assistance Center One Pontiac Plaza...
Page 311 Customer Satisfaction Procedure described earlier in this part has been very successful in achieving customer satisfaction. However, if you have not been substantially satisfied, Pontiac wants you to be aware of GM’s voluntary participation in a no-charge mediatiodarbitration program called BBB AUTO LINE.
Page 312 40 days from the time you file your complaint to the time a decision is rendered (or 47 days if you did not first contact your dealer or Pontiac). We encourage you to use this program before or instead of resorting to the courts.
Page 313 Eligibility is limited by vehicle age/mileage and other factors. For further information concerning the program, call the BBB at 1-800-955-5100. You may also call the Pontiac Customer Assistance Center. *This program may not be available in all states, depending on state law.
Page 314 Transport Canada) in a situation like this, we certainly hope you’ll notify us. Please call us at 1-80O-PM-CARES, or write: Pontiac Division Customer Assistance Center One Pontiac Plaza Pontiac, MI 48340-2952 [n Canada, please call us at 1-800-263-3777 (English) or 1-800-263-7854 (French). Or, write:...
Page 315 Pontiac Roadside Assistance Program Security While You Travel 1-800-ROADSIDE (1-800-762-3743) As the proud owner of a new Pontiac vehicle, you are automatically enrolled in the Pontiac Roadside Assistance Program*. This value-added service is intended to provide you with peace of mind as you drive in the city or travel the open road.
Page 316 Pontiac reserves the right to limit services or reimbursement to an owner or driver when in Pontiac’s judgment the claims become obsessive in frequency or type of occurrence. For prompt and efficient assistance when calling, please provide the following information to the advisor:...
Page 317 Individual PSP’s If you don’t want to buy all the PSP’s issued by Pontiac for all models in the model year, you can buy individual PSP’s such as those which may pertain to a particular model.
Page 318 How You Can Get an Index: Indexes are published periodically. Most of the PSP’s which could potentially apply to the most recent Pontiac models will be listed in the most recent publication for that model year. This means you may want to wait until the end...
Page 319 A cumulative index is published quarterly during the current model Price Number year. The indexes list all PSP’s published by Pontiac in the model year. PSP Index and Summaries Year 1992 PSPI-92-P ......
Page 320 For purchases outside U.S.A. write to the above address please MODEL VEHICLE NAME Firebird $43.00 Pontiac Firebird $15.00 In-Portfolio Without-Portfolio Pontiac Firebird Check or Money Order payable for quotation. Helm. Inc. fUSA 1993 _____ 1993 1993 TOTAL MATERIAL...
Page 324 AirBags ..How the System Works Servicing Your Pontiac with ....the System ....
Page 325 Cleaner on Glass ... . Problems. Special The Inside of Your Pontiac The Outside of the Windshield ... . .
Page 326 Comfort Controls and Audio ....Systems Compact Disc Player. AM/FM Stereo and Graphic ... . Equalizer with .
Page 327 Index Disc Brake Wear Indicators Doing Your Own Service Work Door Locks Door Locks. Power ....Doors. Headlight ... . . Downhill.
Page 328 Following Distance (with a Trailer) ..Foreign Countries. Fuels in . . . Foreign Material Paint Damage Freeway ....Driving on the .
Page 329 Index If You’re Stuck in Deep Snow If You’re Stuck: In Sand... . . Mud. Ice or Snow ....Ignition Switch Inflatable Restraint.
Page 330 ....Inspections Pontiac Roadside ..Assistance Program Pontiac Service Publications ..(Ordering Information) . . .
Page 331 Index Power ....Door Locks ....Seat. Six-Way .
Page 332 ..Roads. Hill and Mountain ..Roadside Assistance. Pontiac 3 14 Rocking Your Vehicle to ....
Page 333 ....Publications Publications Ordering ..Information. Pontiac ..Work. Doing Your Own ....
Page 334 Theft Deterrent Feature/ ....Delco-Loc I1 How to Change Your Security Code Setting Your Security Code ....Shutting off the Unlocking the Audio System .
Page 335 Index Turn Signals When ....Towing a ....Weight of the When You Are Ready to Leave .
Page 336 Tires ... . . Wheel Nut Torque Wheels . . . Alignment and Tire Balance Aluminum Replacement Tilt ... Used Replacement Where to Put the Restraint (Children and Safety Belts) .
Page 337: Service Station Information
Service Station Information Hood Release See Page 221. €@ne Oil Dipstick and FM (3.4L L32 (Code S) Engine) See Page 224. €ngine Oil Dipstick and Fill Cap (5.7L LTl (Code See Page 224. Cold Tire Pressure :e Tire-Loading Information label on the inside of the rear edge of the driver's door.
