Page 2: Table Of Contents
Corvette Introduction This Manual Part Seats & Restraint Part 2 Features & Controls Part 3 Comfort Controls Part 4 Your Driving Part 5 Road Problems Part 6 Service & Appearance Part 7 Maintenance Part 8 Customer Including "Reporting Safety Defects" on page 254. Part 9 Index Service Station Information...
Page 3 For vehicles first sold in Canada, substitute the name “General Motors of Canada Limited” for Chevrolet Motor Division wherever it appears in this manual. For Canadian Owners Who Prefer a French Language Manual Aux proprietaires canadiens: Vous pouve;...
Page 4 Corvette one of the most celebrated sports cars in the world. In 1953, Chevrolet produced 300 new lightweight fiberglass roadsters. A handful went to project engineers, General Motors managers, and a select group of movie stars and celebrities.
Page 5 In 1963, Corvette hit the road with an eye-catching new look the Sting Ray coupe. An instant success, the now- classic Sting Ray featured concealed headlamps and a unique split rear window. The split window would only be offered in 1963, making this model among the most prized Corvettes ever built.
Page 6 For its 25th anniversary, the 1978 Corvette received a new fastback roofline with a wide expanse of glass that wrapped around the sides. Emblems front and rear identified the ’78 ’Vette as a Silver Anniversary model. In 1984, the sixth generation of America’s favorite sports car anticipated the future with a sleek look and advanced technology that provided superior handling and performance.
Page 7 Bowling Green, Kentucky, is one of the most sophisticated and computerized automobile assembly facilities in the world. To build your 1994 Corvette, over 1,200 employes teamed up with the 70 high-tech robots that assist in a variety of processes, from welding to painting.
Page 8: Part 1 Seats & Restraint Systems
5 . - How to This Manual Many people read their owner’s manual from beginning to end when they first receive their new vehicle. This will help you learn about the features and controls this for your vehicle. In manual, you’ll find that pictures and words work together to explain things quickly.
Page 9 How to Use This Manual Safety Warnings Symbols You will find a number of safety cautions in this book. We use a box with a gray background and the word CAUTION to tell you about things that could hurt you if you were to ignore the warning.
Page 10 Vehicle Symbols These are some of the symbols you will find on your vehicle. For example, these symbols are used on an original battery: Caution Possible Injury Protect Eyes by Shielding Caustic Battery Acid Could Cause Burns Avoid Sparks or Flames Sparks or Flame Could Explode Battery These symbols are important for you and...
Page 11 How to Use This Manual Normal Air Conditioning Bi-Level Vent Heater These symbols are used on warning and indicator lights: Engine Coolant Temperature I - 1 Battery Charging System Fuel Engine Oil Pressure Engine Oil Temperature Brake Anti-Lock Brake System Engine Here are some other symbols you may see: Hatch Release...
Page 12 H e r e you’ll find information about the seats in your Corvette and how to use your safety belts properly You can also learn about some things you should do with safety belts . Seats 81 Restraint Systems seats Seat Controls safety Belts: They’re for Everyone Nhy Safety Belts Work...
Page 13 Seats and Restraint Systems Seats and Seat Controls This section tells you about the seats how to adjust them, and also about reclining front seatbacks, seatback latches and the folding rear seatback. anual Front Seat & RIDE CONTF SEAT SPORT Dwer Seat (OPTION)
Page 14 :ONTROL ‘ORT Sport Seat (opnoN) These switches let you change the shape of your seat. The pictures show you which lumbar support the switch controls. First move the selector switch to “DR” (driver) or “PS” (passenger). Then move the shaping switches until your seat is comfortable.
Page 15 Seats and Restraint Systems Safety Belts: They’re for Everyone This part of the manual tells you how to use safety belts properly. It also tells you some things you should not do with safety belts. And it explains the Supplemental Inflatable Restraint, or “air bag”...
Page 16 This figure lights up as a reminder to buckle up. (See “Safety Belt Reininder Light” in the Index.) In many states and Canadian provinces, the law says to wear safety belts. Here’s why: They work. You never know if you’ll be in a crash. If you do have crash, you don’t know if it will be a bad one.
Page 17 Seats and Restraint Systems When the bike hits the block, it stops. But Take the simplest vehicle. Suppose it's Put someone on it. the child keeps going! just a seat on wheels. . I 6...
Page 18 up to speed. Then stop the vehicle. The rider doesn’t stop. The person keeps going until stopped by iomething. :n a real vehicle, could be the windshield or the instrument panel...
Page 19 Seats and Restraint Systems or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That’s why safety belts make such good sense. .
Page 20 Safety Belt Reminder Light Vhen the key is turned to “Run” or Start,” a chime will come on for about ight seconds to remind people to fasten heir safety belts, unless the driver’s ,afety belt is already buckled. The safety jelt light will also come on and stay on mtil the driver’s belt is buckled.
Page 21 Seats and Restraint Systems Lap-Shoulder Belt The driver has a lap-shoulder belt. Here’s how to wear it properly. 1. Close and lock the door. Adjust the seat (to see how, see “Seats” in the Index) so you can sit up straight.
Page 22 Lap Belt Cinch Feature If you do not want the lap belt to move freely, push the “cinch” button. To loosen the belt, unbuckle it, let it retract, and buckle up again. What’s wrong with this? A: The shoulder belt is too loose. It won’t give nearly as much protection this way.
Page 23 Seats and Restraint Systems t": Q: What's wrong with this? A: The shoulder belt is worn under the arm. It should be worn over the shoulder at all times. Q: What's wrong with this? A: The belt is twisted across the body. To unlatch the belt, just push the button on the buckle.
Page 24 AIR BAGS This vehicle has for front occupants. CAUTION: YOU NEED YOUR SAFETY BELT, EVEN W I T H A N AIR BAG. AND HERE'S WHY: Air bags are not designed inflate in rollovers or in rear, side or low-speed frontal crashes. Air bags inflate with great force, faster than the blink of an injure you.
Page 25 Seats and Restraint Systems Air Bag Readiness Light There is an air bag readiness light on the instrument panel, which shows “AIR BAG.” The system checks for electrical malfunctions, and the light tell! you if there is a problem. You will see this light flash for a few seconds when you turn your ignition to “Run”...
Page 26 The right-front passenger’s air bag is located in the instrument panel on the passenger’s side. When is an air bag expected to inflate? The air bag is designed to inflate in moderate to severe frontal or near-frontal crashes. The air bag will only inflate if the velocity of the impact is above the designed threshold level.
Page 27 You don’t want the system to inflate while someone is working on your vehicle. Your Chevrolet dealer and the 1994 Corvette Service Manual have information about servicing your vehicle and the air bag system. The air bag system does not need regular maintenance.
Page 28 Safety Belt Use during Pregnancy Safety belts work for everyone, including pregnant women. Like all occupants, they are more likely to be seriously injured if they don’t wear safety belts. A pregnant woman should wear a lap-shoulder belt, and the lap portion should be worn as low as possible throughout the pregnancy.
Page 29 Seats and Restraint Systems Smaller Children and Babies Children Everyone in a vehicle needs protection! That includes infants and all children smaller than adult size. In fact, the law in every state in the United States and in every Canadian province says children up to some age must be restrained while in a vehicle.
Page 30 If your vehicle is not a convertible and you need to have an anchor installed, can ask your Chevrolet dealer to put one in for you. If you want to install an anchc yourself, your dealer can tell you how to do it.
Page 31 Seats and Restraint Systems Securing a Child Restraint in the Passenger Seat Your vehicle has a right-front passenger’s air bag. NEVER put a rear-facing child restraint in this vehicle. Here’s why: You’ll be using the lap-shoulder belt. See the earlier section about the top strap if the child restraint has one.
Page 32 6. Push the “cinch” button. See “Lap-Shoulder Belt” in the Index, where we describe the cinch feature. 7. To tighten the belt, feed the lap belt back into the retractor while you push down on the child restraint. 8. Push and pull the child restraint in different directions to be sure it is secure.
Page 33 Seats and Restraint Systems Q. What if a child is wearing a lap-shoulder belt, but the child is so small that the shoulder belt is very close to the child’s face or neck? A: Move the child toward the center of the vehicle, but be sure that the shoulder belt still is on the child’s shoulder, so that in a crash the child’s...
Page 34 Safety Belt Extender If the vehicle’s safety belt will fasten around you, you should use it. But if a safety belt isn’t long enough to fasten, your dealer will order you an extender. It’s free. When you go in to order it, take the heaviest coat you will wear, so the extender will be long enough for you.
Page 35 Seats and Restraint Systems Q: What’s wrong with this? A: The belt is torn. Torn or frayed belts may not protect you in a crash. They can rip apart under impact forces. If a belt is torn or frayed, get a new one right away.
Page 36 Here You can learn d3out the many standard and optional features your Corvette. information on starting. shifting and braking Also explained are and the systems warning tell you if SignaVHeadlight Beam everything is working properly and what to do if you have a problem .
Page 37 ‘afe place. If you lose your keys, you’ll ,e able to have new ones made easily lsing these plugs. If your ignition keys lon’t have plugs, go to your Chevrolet lealer for the correct key code if you leed a new ignition key.
Page 38 NOTICE: Your Corvette has a number of new features that can help prevent theft. But you can have a lot of trouble getting into your vehicle if you ever lock your keys inside. You may even have to damage your vehicle to get in.
Page 39 This product has a maximum range. Check the location. Other vehicles or objects may be blocking the signal. See your Chevrolet dealer or a qualified technician for service. Changes or modifications to this system by other than an authorized service facility could void authorization to use this equipment.
Page 40 transmitter, and the system will automatically disarm your theft deterrent system and unlock the doors. If it’s dark enough outside, your interior lights will come on. If you move out of range, the PKE system will: 1. Lock the doors after five seconds. the theft deterrent system.
Page 41 Features and Controls Transmitter Range The transmitter range depends on your vehicle and where you are standing. The coupe (A) has an antenna in the driver’s door and one in the rear area. The convertible (B) has one antenna in each door.
Page 42 6. Bring one transmitter into range. The light will stop flashing and stay on to show that the code is stored. 7. Move the transmitter out of range. The light should start flashing again. 8. Repeat steps 6 and 7 with each additional transmitter.
Page 43 Features and Controls If you have a coupe, this switch is on the rear of the driver’s door. It works with the door open and the transmission in any gear. Push it down to release the hatch. The PKE transmitter will also release the hatch.
Page 44 NOTICE: If you put things in the hatchback area, be sure they won’t break the glass when you close it. Never slam the hatch down. You could break the glass or damage the defogger grid. When you close the hatch, make sure you pull down from the center, not the sides.
Page 45 Features and Controls Universal Theft Deterrent ‘our Corvette has a theft deterrent larm system. With this system, the SECURITY” light will flash as you pen the door (if your ignition is off). ‘his light reminds you to arm the theft eterrent system.
Page 46 Index). If the starter won’t work with the other key, your vehicle needs service. [f your vehicle does start, the first ignition key may be faulty. See your Chevrolet Jealer or a locksmith who can service the PASS-Key@ However, if you accidentally use a key...
Page 47 Features and Controls NOTICE: Your modern Corvette doesn’t need an elaborate “break-in.” But it will perform better in the long run if you follow these guidelines: Keep your speed at 55 mph km/h) or less for the first 500 miles (804 km). Don’t drive at any one speed fast or slow for the...
Page 48 !y Release Button: If you have a lnual transmission, your ignition lock a key release button. You must press button before you can take your key t of the ignition lock. NOTICE: If your key seems stuck in “Lock” and you can’t turn it, be sure it is all the way in.
Page 49 Features and Controls 2. If it doesn’t start within 10 seconds, push the accelerator pedal all the way to the floor, while you hold the ignition key in “Start.” When the engine starts, let go of the key and let up on the accelerator pedal. Wait about 15 seconds between each try to help avoid draining your battery.
Page 50 NOTICE: Your engine is designed to work with the electronics in your vehicle. If you add electrical parts or accessories, you could change the way the fuel injection system operates. Before adding electrical equipment, check with your dealer. If you don’t, your engine might not perform properly.
Page 51 Features and Controls Driving through Deep Standing Water NOTICE: If you drive too quickly through deep puddles or standing water, water can come in through your engine’s air intake and badly damage your engine. If you can’t avoid deep puddles or standing water, drive through them very slowly.
Page 52 Instead of trying to list everything here, we ask that you contact your Chevrolet dealer in the area where you’ll be parking your vehicle. The dealer can give you the best advice for that particular area.
Page 53 Features and Controls way into “P” (Park) and release the shift lever button as you maintain brake application. Then press the shift lever button and move the shift lever into the gear you wish. See “Shifting out of ‘P’ (Park)” in the Index. R (Reverse) Use this gear to back up.
Page 54 NOTICE: Don’t drive in “2” (Second Gear) for more than 5 miles (8 km), or at speeds over 55 mph (88 km/h), you can damage your transmission. or “D” as much as possible. Don’t shift into “2” unless you are going slower than 65 mph (1 05 km/h), or you can damage your engine.
Page 55 Features and Controls (Second Gear) Press the clutch pedal as you let up on the accelerator pedal and shift into “2.” Then, slowly let up on the clutch pedal as you press the accelerator pedal. 3,4,5 and 6 (Third, Fourth, Fifth and Sixth Gears) Shift into “3,”...
Page 56 One to Four Light (MANUAL TRANSMISSION) When this light comes on, you can only shift from “1” to “4” instead of “1” to “2.” This helps you get the best possible fuel economy. This light will come on when: The engine coolant temperature is higher than 170°F (77”C), You are going 15- 19 mph (24-29 kmh), and...
Page 57 Features and Controls RIDE CONTROL SPORT To@F Selective Ride Control (OPTION) This knob is on the center console. Turn i to select the ride control of your choice: TOUR: Use for city and highway driving Provides a smooth, soft ride. SPORT: Use where road conditions or personal preference demand more control Provides more “feel,”...
Page 58 To release the parking brake: Hold the brake pedal down. Pull the parking brake lever up until you can push in the release button. Hold the release button in as you move the lever all the way down. NOTICE: Driving with the parking brake on can cause your rear brakes to over- heat.
Page 59 Features and Controls Leaving Your Vehicle with the Engine Running (AUTOMATIC TRANSMISSION) Torque Lock (AUTOMATIC TRANSMISSION) If you are parking on a hill and you don’t shift your transmission into “P” (Park) properly, the weight of the vehicle may put too much force on the parking pawl in the transmission.
Page 60 Parking over Things That Burn Engine Exhaust Running Your Engine While You’re Parked (AuToMmc TRANSMI S SI O N) It’s better not to park with the engine running. But if you ever have to, here are some things to know.
Page 61 Features and Controls Follow the proper steps to be sure your vehicle won’t move. See “Shifting into ‘P’ (Park)” in the Index. Windows Power Windows With power windows, switches on the door control each window when the ignition is on or when DAB is present. (See “Delayed Accessory Bus”...
Page 62 Tilt Wheel A tilt steering wheel allows you to adjust the steering wheel before you drive. You can also raise it to the highest level to give your legs more room when you exit and enter the vehicle. To tilt the wheel, hold the steering wheel and pull the lever.
Page 63 Features and Controls A green arrow on the instrument panel will flash in the direction of the turn or lane change. To signal a lane change, just raise or lower the lever until the green arrow start to flash. Hold it there until you complete your lane change.
Page 64 For steady wiping at low speed, turn the band away from you to the “LO’ position. For high speed wiping, turn the band “HI.” To stop the wipers, move further, the band to “OW.” Damaged wiper blades may prevent you from seeing well enough drive safely.
Page 65 Features and Controls NOTICE: When using concentrated washer fluid, follow the manufacturer’s instructions for adding water. Don’t mix water with ready-to-use washer fluid. Water can cause the solution to freeze and damage your washer fluid tank and other parts of the washer system.
Page 66 2. Get up to the speed you want. Push in the set button at the end of the lever and release it. 4. Take your foot off the accelerator pedal. I - \ To Resume a Set Speed Suppose you set your Cruise Control at a desired speed and then you apply the brake or clutch pedal.
Page 67 Features and Controls Passing Another Vehicle While Using Cruise Control Use the accelerator pedal to increase your speed. When you take your foot off the pedal, your vehicle will slow down to the Cruise Control speed you set earlier. Using Cruise Control on Hills How well your Cruise Control will work on hills depends upon your speed, load, and the steepness of the hills.
Page 68 Ieadlights ?he headlight knob controls these lights: Headlights Taillights Parking lights Sidemarker lights h m the knob to to turn on your leadlights and other operating lights. rurn the knob t o : O O : t o turn on your mking and other operating lights without ‘our headlights.
Page 69 Features and Controls Daytime Running Lights (Canada) The Canadian Federal Government has decided that “Daytime Running Lights” ( D E ) are a useful feature, in that DIU can make your vehicle more visible to pedestrians and other drivers during daylight hours.
Page 70 Mirrors Inside Daymight Rearview Mirror An inside rearview mirror is attached above your windshield. The mirror has pivots that you can adjust it. You can adjust the mirror for day or nigh1 driving. Pull the tab for night driving to reduce glare.
Page 71 Features and Controls Roof Panel (COUPE) Until you are sure you can remove the panel alone, have someone help you. Removing the Roof Panel 1. Park on a level surface, set the parking brake firmly and shift an automatic transmission into “P”...
Page 72 4. The two rear bolts are on the roof, one above each seat. You’ll see three bolts on each side. Loosen the middle one. (The ratchet won’t work for the other two.) The bolts will stay in the roof panel. 5.
Page 73 Features and Controls 6. Gently lift up on the roof panel to be sure is locked in place. Installing the Roof Panel Park on a level surface, set the parking brake firmly and shift an automatic transmission into “P” (Park). Shift a manual transmission into “...
Page 74 Your roof panel or hardtop wrench is stored here. Rear Storage Compartment This compartment is in the floor behind the passenger seat. To use it, push the button and lift the lid. Use the door key to lock it. The top tray can be removed. The jack, wheel lock key and wheel nut socket are stored below the tray.
Page 75 Features and Controls Security Shade (Coupe) The security shade can provide hidden storage in the rear area of your vehicle. To use the security shade: 1. Pull the security shade by the center handle. 2. Put the ends of the shade into the slots behind the seats.
Page 76 Covered Visor Vanity Mirror Pull down the sun visor and lift the cover to expose the vanity mirror. When the ignition is on, slide the switch next to the mirror up to turn the lights on. Be sure to turn the lights off before closing the cover.
Page 77 Features and Controls Cigarette Lighter To use the lighter, push it in all the way and let go. When it’s ready, it will pop back by itself. NOTICE: Don’t hold a cigarette lighter in with your hand while it is heating. If you do, it won’t be able to back away from the heating element when it’s ready.
Page 78 NOTICE: When using the accessory plug: Don't splice wires directly into the accessory plug wire. If done incorrectly, splicing might cause damage to your electrical system. The maximum load of any electrical equipment should not exceed 10 amps. Be sure to turn electrical equipment when not in use.
Page 79 Features and Controls...
Page 80 Instrument Panel Acceleration Slip Regulation Switch Side Window Defogger Vent Side Air Vent Turn Signaweadlight Beam Lever 5. Tilt Lever Instrument Cluster Ignition Switch Trip Monitor Controls Solar Sensor I O . Center Air Vent Driver Information Center 1 2 . Comfort Controls 1 3 .
Page 81 Features and Controls Instrument Cluster Your instrument cluster and Driver Information Center are designed to let you know at a glance how your vehicle is running. You’ll know how fast you’re going, about how much fuel you have left and many other things you’ll need to know to drive safely and economically.
Page 82 If a new odometer is installed, it will automatically reset to the correct reading. If an electrical or other problem makes setting the odometer correctly impossible, then it’s set at zero, but label on the driver’s door must show the old reading and when the new one was installed.
Page 83 Features and Controls Warning Lights, Gauges and Indicators This section describes the warning lights and gauges that may be on your vehicle. The pictures will help you locate them. Warning lights and gauges can signal that something is wrong before it becomes serious enough to cause an expensive repair or replacement.
Page 84 For your convenience, the following table gives the reading for each mark. For numeric gauge measurements, refer to the digital readings by pressing “GAUGES” on the Trip Monitor. NUMERIC GAUGE READINGS ( O F ) Gauge 21 5 LT1 Oil Temperature LT5 Oil 1 00...
Page 85 Features and Controls It takes more (or less) fuel to fill up than the gauge reads. For example, the gauge reads half full, but it took more (or less) than half of the tank’s capacity to fill it. The gauge moves a little when you turn, stop or speed up.
Page 86 ’arking Brake Indicator Light rhis light will come on when you set your mking brake, and it will stay on if your )arking brake doesn’t release fully. rhis light should also come on as you tart the.vehicle. If it doesn’t come on hen, have it fixed so it will be ready to cmind you if the parking brake hasn’t &eleased fully.
Page 87 Features and Controls ACTIVE Anti-Lock Brake System Active Light When your anti-lock system is adjusting brake pressure to help avoid a braking skid, the “ABS ACTIVE’ light will come on. Slippery road conditions may exist if this light comes on, so adjust your drivinl accordingly.
Page 88 ACTIVE ASR Active Light When your ASR system is limiting wheel spin, the “ASR ACTIVE’ light will come on. Slippery road conditions may exist if this light comes on, so adjust your driving accordingly. The light will stay on for a few seconds after the ASR system stops limiting wheel spin.
Page 89 Take care when servicing or having your tires serviced. The sensors may not work properly if damaged. To prevent damage to the sensors, see the 1994 Corvette Service Manual for correct tire mounting and dismounting procedures. The “LOWRLAT TIRE” light may come...
Page 90 SERVICE LTPWS ‘ervice LTPWS Light (Option) ‘he “SERVICE LTPWS” light comes on rhenever a LTPWS part is not working roperly. It may also come on when ou’re going less than 25 mph k m k ) r in stop-and-go traffic. The light will go ut when the electronic receiver gets a ignal from each sensor.
Page 91: Part 3 Comfort Controls & Audio Systems
Features and Controls For numeric gauge measurements, press the “GAUGES” button on the Trip Monitor until “COOL,” appears. The number that appears next to the fuel gauge is the coolant temperature. If “LO’ appears, the temperature is below 32°F (0°C). VOLTS Voltmeter You can read the charging system’s rate of...
Page 92 SERVICE SOON Malfunction Indicator Lamp (Service Engine Soon Light) A computer monitors operation of your fuel, ignition and emission control systems. This light should come on when the ignition is on, but the engine is not running, as a check to show you it is working.
Page 93 Features and Controls NOTICE: Damage to your engine from neglected oil problems can be costly and is not covered by your warranty. TEMP TEMP ‘F Enginl T1 Engine Zngine Oil Temperature Gauge rhis gauge shows your engine oil emperature. Oil temperature may vary vith the type of driving you do and weather conditions, but readings above the shaded area show the normal...
Page 94 Check Gauges Light This light will come on briefly when you are starting the engine. If the light comes on and stays on while you are driving, check your gauges to see if they are in the warning areas. This light can come on for: high oil temperature or low oil pressure high coolant temperature...
Page 95 Features and Controls Zharging System Light rhis light will come on when you turn on he ignition, but the engine is not running a check to show you it is working. It ihould go out when the engine starts. If t stays on or comes on while you are Iriving, you may have a problem with he electrical charging system.
Page 96 1. Turn the key to “Run,” but don’t start the engine. 2. Press “ENG MET” on the Trip Monitor. Then, within five seconds, press it again. Within five seconds, press and hold “GAUGES” on the Trip Monitor. The “CHANGE OIL” light should flash. 4.
Page 97 Features and Controls Security Light This light comes on to remind you to your theft deterrent system. If it comes on and stays on when your ignition is on, there may be a problem with your theft deterrent system. See “Universal Theft Deterrent”...
Page 98 I r i w l I 2. Unlock the front of the convertible top by turning the latch handles outward. Then lift the top off the windshield slightly. Unfasten the strips at the rear of each window opening. 4. Tilt the driver's seatback forward. The convertible top release handle is behind the driver's seat beneath the storage compartment lid.
Page 99 Features and Controls If your Corvette has lost power (dead battery, for example), you can still open the storage compartment using the manual release handles. The handles are near the sidewall behind the safety belt anchors on each side of your vehicle. Move the handles toward the rear of the vehicle and upward.
Page 100 To Raise Your Convertible Top 1. Park on a level surface, set the parking brake firmly and shift an automatic “P” transmission into (Park). Shift a manual transmission into “R’ (Reverse). Lower both windows and sunshades and turn the ignition key to “LOCK.”...
Page 101 Fe’atures and Controls p m ; . 7. Fasten the strips for the, headliner at the rear of each window opening. 8. Then fasten the lower front corner of the top. NOTICE: Certain automatic vehicle washes may cause damage to your vehicle. The top fabric can be damaged by top cleaning brushes.
Page 102 Loosen the front bolts with the wrench. Move both seatbacks forward and remove the rear trim panel. 1. Loosen the rear corner brack& bolts with the ratchet. ..;'...
Page 103 Features and Controls 5. Using the wrench, remove the two lower bolts (A) from the lock pillar bracket on each side. 6. Remove the bolt (B) from the bottom flange of each lock pillar bracket. 7. Then remove the two upper bolts (C) from the receiver bracket on each side .I02 Slide both lock pillar brackets down...
Page 104 T O Install Your Convertible Hardtop 1. Park on a level surface, set the parkinl brake firmly and shift an automatic transmission into “F’” (Park). Shift a manual transmission into “R’ (Reverse). Lower both windows and sunshades. T u r n off the radio to lower the power antenna and turn the ignition key to “LOCK.”...
Page 105 Features and Controls Secure but don’t tighten the rear corner bracket bolts using the ratchet. . l o 4 10. Tighten the front bolts using the wrench. Insert the lower bolt into the bottom flange of the lock pillar brackets and tighten.
Page 106 I n this part you’ll find out how to operate the comfort control systems and audio systems offered with your Corvette sure to read about the particular system supplied with your vehicle Comfort Controls & Audio ..........Comfort Controls .
Page 107 Comfort Controls and Audio Systems 0 00 Comfort Controls With these systems, you can control the heating, cooling and ventilation in your Corvette. Your vehicle also has the flow-through ventilation system described later in this section. Air Conditioner Controls Control Buttons Press the arrows on the fan switch to select the force of air you want.
Page 108 Heating The heater works best if you keep your windows closed while using it. 1. Press 2. Press Slide the temperature control lever to a comfortable setting. If your vehicle has an engine coolant heater and you use it in cold weather, 0°F (-18°C) or lower, your heating system can provide heat more quickly because the engine coolant is already...
Page 109 Comfort Controls and Audio Systems Automatic Electronic Climate Control ( O P ~ O N ) With this system you set a temperature and then either let the system adjust air flow and force to maintain the temperature, or you can manually adjust flow and force.
Page 110 This delay helps prevent a false reading. If vehicle speed remains above 25 mph (40 kmh) or the temperature goes down, the display is updated immediately. If your vehicle has been for more than three hours, the current outside temperature will be stored in the system when you start the vehicle.
Page 111 Comfort Controls and Audio Systems ‘j except and-; and at all temperatures above freezing. Press the arrows on the fan speed switch if you don’t like the automatic setting. In “AUTO on hot days, ” the fan speed will be low at fist to help get rid of the hot inside air..
Page 112 1 - 0 Rear Window Defogger The rear window defogger uses a warming grid to remove fog from the rear window. The power mirrors are also warmed when the rear window defogger is on. Press to turn on the defogger. An indicator light will come on to fiemind you that the defogger is on.
Page 113 Comfort Controls and Audio Systems Ventilation Tips Keep the hood and front air inlet free of ice, snow, or any other obstruction (such as leaves). The heater and defroster will work far better, reducini the chance of fogging the inside of your windows.
Page 114 Setting the Clock 1. Press “SET.” 2. Within five seconds, press and hold “TUNE until the correct hour ” appears. Press and hold “TUNE until the ” correct minute appears. Noise Reduction Your audio system has automatic Dolby@ B Noise Reduction. Dolby and the @are trademarks of Dolby Laboratories Licensing...
Page 115 Comfort Controls and Audio Systems Adjusting the Speakers Balance: Turn the “BAL” control behind the “FADE” knob to move the sound between the right and left speakers if you do not have the DelcoBose system. With the DelcoBose system, your speakers are zlectronically balanced.
Page 116 PROG Delco/Bose AWFM Stereo with Cassette Tape and Compacf Disc Player To Play the Radio Turn the upper knob to turn the system on or off. Volume: Turn the upper knob to adjust the volume. Your system also has a ’...
Page 117 Comfort Controls and Audio Systems Fade: Turn the “FADE” knob to move the sound between the front and rear speakers. Note that if you turn the knob all the way to “F” or “R,” you may still get some sound from the opposite speakers.
Page 118 Repeat: Press “REPT” to go to the beginning of the current track after eight seconds or more of play. After eight seconds or less of play, the player will return to the beginning of the previous track. Search: Press “SRCH’ to go to the beginning of the next track.
Page 119 Comfort Controls and Audio Systems Clean your tape player with a wiping-action, non-abrasive cleaning P a r t cassette (GM 12344600), and follow the directions provided with it. Cassettes are subject to wear and the sound quality may degrade over time. Always make sure that the cassette tape is in good condition before you have your tape player serviced.
Page 120 Don't lubricate the power antenna. NOTICE: Before entering an automatic car wash, turn off your radio make the power antenna go down. This will prevent the mast from possibly getting damaged. If the antenna does not go down when you turn the radio off, it may be damaged or need to be cleaned.
Page 121 Notes .I20...
Page 122 H e r e find information YOU’II about driving on different kinds of roads and in varying weather conditions . We’ve also included many other useful tips on driving Your Driving and the Road ......... . . Defensive Driving .
Page 123 Your Driving and the Road Defensive Driving The best advice anyone can give about driving is: Drive defensively. Please start with a very important safety device in your Corvette: Buckle up. (See “Safety Belts” in the Index.) Defensive driving really means “be ready for anything.”...
Page 124 According to the American Medical Association, a 180-pound (82 kg) person who drinks three 12-ounce (355 ml) bottles of beer in an hour will end up with a BAC of about 0.06 percent. The person would reach the same BAC by drinking three 4-ounce (1 20 ml) glasses of wine or three mixed drinks if each had 1 ounces (45 ml) of a liquor like whiskey,...
Page 125 Your Driving and the Road There’s something else about drinking and driving that many people don’t know. Medical research shows that alcohol in a person’s system can make crash injuries worse. That’s especially true for brain, spinal cord and heart injuries. That means that if anyone who has been drinking driver or passenger is in a crash, the...
Page 126 This is a mistake. Your brakes may not have time to cool between hard stops. Your brakes will wear out much faster if you do a lot of heavy braking. If you keep pace with the traffic and allow realistic following distances, you will eliminate a lot of unnecessary braking.
Page 127 Your Driving and the Road You can steer around the obstacle while braking hard. As you brake, your computer keeps receiving updates on wheel speed and controls braking pressure accordingly. Remember: Anti-lock doesn’t change the time you need to get your foot up to the brake pedal.
Page 128 SERVICE “SERVICE ASR“ warning light will comc on to let you know if there’s a prob lem with the ASR system. See “ASR : m Warning Light” in the Index. Systc n this warning light is on, the system will not limit wheel spin.
Page 129 Your Driving and the Road the tires against the road surface makes it possible for the vehicle to change its path when you turn the front wheels. If there’s no traction, inertia will keep the vehicle going in the same direction. If you’ve ever tried to steer a vehicle on wet ice, you’ll understand this.
Page 130 Off-Road Recovery You may find sometime that your right wheels have dropped off the edge of a road onto the shoulder (A) while you’re driving. If the level of the shoulder is only slight11 below the pavement, recovery should be fairly easy.
Page 131 Your Driving and the Road If other cars are lined up to pass a slow vehicle, wait your turn. But take care that someone isn’t trying to pass you as you pull out to pass the slow vehicle. Remember to glance over your shoulder and check the blind spot.
Page 132 While driving on a surface with reduced traction, try your best to avoid sudden steering, acceleration, or braking (including engine braking by shifting to a lower gear). Any sudden changes could cause the tires to slide. You may not realize the surface is slippery until your vehicle is skidding.
Page 133 Your Driving and the Road vehicle with misaimed headlights), slow down a little. Avoid staring directly into the approaching lights. Keep your windshield and all the glass on your vehicle clean inside and out. Glare at night is made much worse by dirt on the glass.
Page 134 Driving too fast through large water puddles or even going through some car washes can cause problems, too. The water may affect your brakes. Try to avoid puddles. But if you can’t, slow down before you hit them. Hydroplaning Hydroplaning is dangerous. So much water can build up under your tires that they can actually ride on the water.
Page 135 Your Driving and the Road City Driving One of the biggest problems with city streets is the amount of traffic on them. You’ll want to watch out for what the other drivers are doing and pay attention to trafflc signals. Here are ways to increase your safety in city driving: Know the best way to get to where...
Page 136 If it needs service, have it done before starting out. Of course, you’ll find experienced and able service experts in Chevrolet dealerships all across North America. They’ll be ready and willing to help if you need it.
Page 137 Your Driving and the Road What can you do about highway hypnosis? First, be aware that it can happen. Then here are some tips: Make sure your vehicle is well ventilated, with a comfortably cool interior. Keep your eyes moving. Scan the road ahead and to the sides.
Page 138 Stay in your own lane when driving on two-lane roads. in hills or mountains. Don't swing wide or cut across the center of the road. Drive at speeds that let you stay in your own lane. As you go over the top of a hill, be alert.
Page 139 Your Driving and the Road Driving on Snow or Ice Most of the time, those places where you1 tires meet the road probably have good traction. However, if there is snow or ice between your iires and the road, you can have a very slippery situation.
Page 140 Run your engine only as long as you must. This saves fuel. When you run the engine, make it go a little faster than just idle. That is, push the accelerator slightly. This uses less fuel for the heat that you get and it keeps the battery charged.
Page 141 Notes...
Page 142 H e r e you’tl find what to do about some problems that can occur on the road . Problems on the Road Hazard Warning Flashers rumpStarting rowing Your Vehicle Engine Overheating Tire Goes Flat [f You’re Stuck: In Sand. Mud. Ice or Snow Part...
Page 143 Problems on the Road Hazard Warning Flashers Your hazard warning flashers let you warn others. They also let police know you have a problem. Your front and rear turn signal lights will flash on and off. .I42 'ress the button in to make your front an( : a r turn signal lights flash on and off.
Page 144 Jump Starting If your battery has run down, you may want to use another vehicle and some jumper cables to start your Corvette. But please follow the steps below to do it safely. NOTICE: Ignoring these steps could result in costly damage to your vehicle that wouldn’t be covered by your warranty.
Page 145 Problems on the Road .144 5. Check that the jumper cables don’t have loose or missing insulation. If they do, you could get a shock. The vehicles could be damaged, too. 6. Positive goes to positive negative goes to negative or a metal engine part.
Page 146 7. Don’t let the other end touch metal. Connect it to the positive terminal of the good battery. Use a remote positive terminal if the vehicle has one. 8. Now connect the black negative cable to the good battery’s negative terminal.
Page 147 Problems on the Road 12. Remove the cables in reverse order to prevent electrical shorting. Take care that they don’t touch each other or any other metal. A. Heavy Metal Engine P a r t 6. Good Battery C. Dead Battery .I46 Towing Your Vehicle to have a GM dealer or a professional...
Page 148 When your vehicle is being towed, have h e ignition key off. The steering wheel should be clamped in a straight-ahead position, with a clamping device designed For towing service. Do not use the vehicle’s steering column lock for this. The transmission should be in “Neutral”...
Page 149 Problems on the Road Front Towing Hook-Ups Attach T-hook chains on both sides in slotted holes behind and just inboard of front wheels. . I 4 0 Position 4x4 wood beam across sling chains contacting under fascia just ahead of curb protect brackets (A). Position sling crossbar against front of 4x4 beam.
Page 150 Attach a separate safety chain around outboard end of each lower control arm. :ear Towing Hook-Ups ittach T-hook chains in slots forward anc lst inboard of rear wheels on both sides. NOTICE: Do not tow with sling-type equipment or rear bumper valance will be damaged.
Page 151 Problems on the Road NOTICE: Towing a vehicle over rough surfaces could damage a vehicle. Damage can occur from vehicle-to-ground or vehicle-to-wheel-lift-equipment. To help avoid damage, install a towing dolly and raise vehicle until adequate clearance is obtained between the ground and/or wheel-lift equipment.
Page 152 NOTICE: If your engine catches fire because you keep driving with no coolant, your vehicle can be badly damaged. The costly repairs would not be covered by your warranty. If No Steam Is Coming from Your Engine: If you get the overheat warning but see hear no steam, the problem may not be too serious.
Page 153 Problems on the Road Cooling System When you decide it’s safe to lift the hood, here’s what you’ll see on the LT5 engine: 1. Coolant recovery tank 2. Coolant high fill reservoir with pressure cap Electric engine fans -152 If the coolant inside the coolant recovery tank is boiling, don’t do anything else until it cools down.
Page 154 How to Add Coolant to the Coolant Recovery Tank If you haven’t found a problem yet, but the coolant level isn’t at or above the “COLD, mark, add a 50150 mixture of clean water (preferably distilled) and a proper antifreeze at the coolant recovery tank.
Page 155 Problems on the Road .I54 How to Add Coolant to the Coolant High Fill Reservoir LT1 Only NOTICE: The LT1 engine (Code P) has a specific coolant high fill reservoir fill procedure. Failure to follow this procedure could cause your engine to overheat and be severely damaged.
Page 156 Then keep turning the pressure cap, but now push down as you turn it. Remove the pressure cap. After the engine cools, open the air bleed valves on the throttle body. and water pump inlet. i... 155.
Page 157 10. Then fill the coolant recovery tank to the proper level. For a complete drain, flush and refill, see your Chevrolet dealer or a Chevrolet Corvette Service Manual. To purchase a service manual, see “Service Publications’’ in the Index.
Page 158 How to Add Coolant to the Coolant (5.7L LT5 (Code J) High Fill Reservoir Engine) 1. You can remove the coolant high fill reservoir pressure cap when the cooling system, including the coolant high fill reservoir pressure cap and upper radiator hose, is no longer hot. Turn the pressure cap slowly to the left until it first stops.
Page 159 Problems on the Road 4. Then fill the coolant recovery tank to the “HOT” mark on the dipstick. .158 5. Put the cap back on the coolant recovery tank, but leave the coolant high fill reservoir pressure cap off. 6. Start the engine and let it run until you can feel the upper radiator hose getting hot.
Page 160 8. Shut the engine and replace the pressure cap. At any time during this procedure if coolant begins to flow out of the filler neck, reinstall the pressure cap. Be sure the arrows on the cap line up like this. If a Tire Goes Flat It’s unusual for a tire to “blow out”...
Page 161 Problems on the Road .I60 The following steps will tell you how to use the jack and change a tire. Your Corvette wheel lock key has a unique registration number. The registration number is printed on a card included in your locknut package. Also on this card is lost key replacement information.
Page 162 The equipment you’ll need is behind the driver’s seat and in the rear storage compartment behind the passenger’s seat. Move the driver’s seat all the way forward and fold the seatback forward. The wheel wrench is on the floor behind the seat.
Page 163 Problems on the Road Put the hooked end of the wheel wrench into the slot in the tray. Insert the wheel wrench a little from the side so it isn't over the latch bolt. Pull up on the wheel wrench to lift the tray. .I62 While holding the tray up with the wheel wrench, pull the latch bolt to release it...
Page 164 Each wheel will have one locknut. A special wheel lock key (removal tool) and instructions are provided. Attach the wheel lock key to the wheel wrench. Remove the locking wheel nut by turning counterclockwise. Attach the wheel nut socket to the wheel wrench and loosen all the wheel nuts.
Page 165 Problems on the Road ~~~~ When you've turned the wrench almost far as it will go, swing it around to the )ther side. Keep turning to raise the jack ift head a few inches. .I64 'osition the jack under the vehicle. rhere are two locator triangles (A) on the ,anels (B) near each wheel.
Page 166 Remove any rust or dirt from the wheel bolts, mounting surfaces and spare wheel. Place the spare on the wheel mounting surface. Replace the wheel nuts with the rounded end of the nuts toward the wheel. Tighten each nut by hand until the wheel is held against the hub.
Page 167 Problems on the Road Tighten the wheel nuts firmly in a criss-cross sequence as shown. .I66 The “LOWELAT TIRE” or “SERVICE LTPWS” light will stay on as long as you ire using the compact spare tire. It should 50 out when the original tire is replaced.
Page 168 Storing a Flat Tire (Except ZR-1 Rear Tires) The road tire is larger than the spare, so you must adjust the tray to its lower position. Lift and push the tire carrier tray toward the front of the vehicle. The tray will drop to its lower position.
Page 169 Problems on the Road Storing a Flat Tire (ZR-1 Rear Tires) A ZR-1 rear tire will not fit in the tray, so you must put it on the floor of the rear area. Put the flat tire in the storage bag provided.
Page 170 Compact Spare Tire Although the compact spare was fully inflated when your vehicle was new, it can lose air after a time. Check the inflation pressure regularly. It should be 60 psi (420 kPa). After installing the compact spare on your vehicle, you should stop as soon as possible and make sure your spare tire is correctly inflated.
Page 171 Problems on the Road NOTICE: Spinning your wheels can destroy parts of your vehicle as well as the tires. If you spin the wheels too fast while shifting your transmission back and forth, you can destroy your transmission. .I70 Rocking your vehicle to get it out: First, turn your steering wheel left and ight.
Page 172 H e r e you will find information about the care of your Corvette . This part begins with service and fuel information. and then it shows how to check important fluid and lubricant levels . There is also technical information about your vehicle.
Page 173: Part 6 Service & Appearance Care 1 7
Service and Appearance Care Service Your Chevrolet dealer knows your vehicle best and wants you to be happy with it. We hope you’ll go to your dealer for all your service needs. You’ll get genuine GM parts and GM-trained and supported service people.
Page 174 Fuel Use premium unleaded gasoline rated at 91 octane or higher. You may use middle grade or regular unleaded gasolines, but your vehicle may not accelerate as well. The gasoline you use should meet specifications ASTM D4814 in the U.S. and CGSB 3.5-92 in Canada.
Page 175 Service and Appearance Care Fuels in Foreign Countries If you plan on driving in another country outside the U.S. or Canada, unleaded fuel may be hard to find. Do not use leaded gasoline. If you use even one tankful, your emission controls won’t work well or at all.
Page 176 B e careful not to spill gasoline. Clean 5asoline from painted suirfaces as soon 1s possible. See “Cleaning the Outside If Your Corvette’’ in the Index. When you put the cap back on, turn it to :he right until you hear at least three :licks.
Page 177 Service and Appearance Care When you open the hood, you'll see: Hydraulic Clutch Fluid Reservoir equipped) Brake Fluid Reservoir .I76 '*?- 5.7L LTI (Code Battery Electrical Engine Fan Air Cleaner Before closing the hood, be sure all the filler caps are on. 6.
Page 178 When you open the hood, you'll see: 1. Hydraulic Clutch Fluid Reservoir Brake Fluid Reservoir Battery Electric Engine 5.7L (Code Air Cleaner 6. Coolant Recovery Tank 7. Power Steering Fluid Reservoir 8. Engine Oil Fill Cap Before closing the hood, be sureall the filler caps are on.
Page 179 Service and Appearance Care Then release the hood strut by moving it to the centered position and lowering the hood. Lower the hood until it is about 12 inches (300 mm) above the engine, then release it. 5.7L (Code Engine Oil If you have the LTl engine, it’s a good idea to check your engine oil level every time you get fuel.
Page 180 . . f ’ . ’ . * . ‘ . * . I . To Check Engine Oil Pull out the dipstick and clean it with a paper towel or cloth, then push it back in all the way. Remove it again, keeping the tip lower.
Page 181 Service and Appearance Care NOTICE: If you use oils that don’t have the GM4718M Standard designation, you can cause engine damage not covered by your warranty. 5W-30 shown in the viscosity chart, 5W-30 is best for your vehicle. However, you can use 1OW-30 if it’s going to be 0°F (-18°C) or above.
Page 182 Engine Oil Additives Don’t add anything to your oil. Your Chevrolet dealer is ready to advise if you think something should be added. When to Change Engine Oil See if any one of these is true for you:...
Page 183 Service and Appearance Care 5.7L LT1 (Code P) Air Cleaner Refer to the Maintenance Schedule to determine when to replace the air filter. See “Scheduled Maintenance Services” in the Index. .182 NOTICE: If the air cleaner is off, a backfire can cause a damaging engine fire.
Page 184 Air Filter Replacement To remove the air filter: 1. Unscrew the three knobs. 1. Pull the air cleaner straight up. 1. ODen the air cleaner and remove the fiiter. 183..
Page 185 How to Check Because this operation can be a little iifficult, you may choose to have this done at a Chevrolet dealership Service Department. [f you do it yourself, be sure to follow all the instructions here, or you could get a false reading on the dipstick.
Page 186 cold check, you must perform a hot check before adding fluid. This will give you a more accurate reading of the fluid level. To check the fluid hot or cold Park your vehicle on a level place. With the parking brake applied, place the shift lever in “P”...
Page 187 How to Check: Because this operation can be difficult, you may choose to have this done at a Chevrolet dealership Service Department. If you do it yourself, be sure to follow all the instructions here, or you could get a false reading.
Page 188 2. Add fluid at the filler plug hole. Add only enough fluid to bring the fluid level up to the bottom of the filler plug hole. Install the filler plug. Be sure the plug is fully seated. Hydraulic Clutch The clutch linkage in your vehicle is self-adjusting.
Page 189 Service and Appearance Care Remove the nut on the outboard side of the unit. Then loosen the front and inboard nuts. For the LT5 engine, loosen the two inboard nuts. Move the ECM unit to either side. Fluid should be added if the fluid level is at or below the “ADD”...
Page 190 What to Use: Use a mixture of one-half clean water (preferably distilled) and one-half antifreeze that meets “GM Specification 1825-M,” which won’t damage aluminum parts. You can also use a recycled coolant conforming to GM Specification 1825-M with a complete coolant flush and refill. If you use this mixture, you don’t need to add anything else.
Page 191 Don’t spill coolant on a hot engine. For complete drain, flush and refill of the engine, contact your Chevrolet jealer or the procedure may be found in Chevrolet Corvette Service Manual. To purchase a service manual, see “Service Publications”...
Page 192 5.7L (Code Power Steering Fluid How to Check Power Steering Fluid: Unscrew the cap and wipe the dipstick with a clean rag. Replace the cap and completely tighten it. 5.7L Then remove the cap again and look at the fluid level on the dipstick. (Code When the engine compartment is hot, the level should be at the “HOT”...
Page 193 Service and Appearance Care NOTICE: When adding power steering ,fluid or making a complete fluid change, always use the proper fluid. Failure to use the proper fluid can cause leaks and damage hoses and seals. . I 9 2 Windshield Washer Fluid To Add: Open the cap labeled “WASHER FLUID ONLY.”...
Page 194 Brake Master Cylinder Your brake master cylinder is here. It is filled with DOT-3 brake fluid. There are only two reasons why the brake fluid level in your master cylinder might go down. The first is that the brake fluid goes down to an acceptable level during normal brake lining wear.
Page 195 Service and Appearance Care NOTICE: Don’t let someone put in the wrong kind of fluid. For example, just a few drops of mineral-based oil, such as engine oil, in your brake system can damage brake system parts so badly that they’ll have to be replaced.
Page 196 Battery Every new Corvette has a Delco Freedom@ battery. You never have to add water to one of these. When it’s time for a new battery, we recommend a Delco Freedom@ battery. Get one that has the catalog number shown on the original battery’s label.
Page 197 Service and Appearance Care 4. Remove the two screws from both sides of the cover. Before you remove the last screw, put your hand under the cover to hold it. 5. Reach around the hood and pull the cover straight out. Be careful not to scratch the paint.
Page 198 Front Turn Signal 1. Open the hood. 2. Find the socket at the front of the engine compartment. Turn the socket counterclockwise 1/4 turn and pull it out. Push the bulb turn it counterclockwise, then pull it out. Reverse the steps with a new bulb. The socket has three large tabs and one small tab.
Page 199 Service and Appearance Care 2. Pull the lens out. Push the bulb in, turn it counterclockwise, then pull it out. 4. Reverse the steps with a new bulb. To prevent water from getting inside the lens, make sure the lens seal is properly positioned.
Page 200 Sidemarker You can reach the front sidemarker from inside the engine compartment. Reach the rear sidemarker from under the vehcle. 1. Turn the socket counterclockwise 1/4 turn and pull it out. 2. Pull the bulb straight out. Reverse the steps with a new bulb. :ornering Light can reach the front cornering.
Page 201 Service and Appearance Care 2. Push the bulb in, turn it counterclockwise, then pull it out. Reverse the steps with a new bulb. .200 Rear Cargo Compartment Light (Coupe) 1. Pry the cover off with a screwdriver. Be sure to pry from the rear side, or you could break the tab on the cover.
Page 202 2. Push the bulb in, turn counterclockwise, then pull it out. Reverse the steps with a new bulb. Center High-Mounted Stoplight (ZR-1) side of hatch, near the roof. Gently pull the assembly away from the roof. Remove the two screws on the underside of the assembly.
Page 203 Service and Appearance Care 6. Rock the bulb back and forth while pulling up to remove it. 7. Reverse the steps with a new bulb. ,202 Windshield Wiper Blades It's a good idea to rotate the wiper blade assembly 180" every six months. This changes the wear pattern and makes the wiper blade insert last longer.
Page 204 MFD BY GENERAL MOTORS CORP. DATE GVWR GAWRFRT GAWRRR 5713LB 2503LB 01/91 The other label is the Certification label, found on the rear edge of the driver’s door. It tells you the gross weight capacity of your vehicle, called the GVWR (Gross Vehicle Weight Rating).
Page 205 Service and Appearance Care Tires We don't make tires. Your new vehicle comes with high quality tires made by a leading tire manufacturer. These tires are warranted by the tire manufacturers and their warranties are delivered with every new Corvette. If your spare tire is a different brand than your road tires, you will have a tire warranty folder from each of these manufacturers.
Page 206 Extended Mobility Tires (omoiv) If your Corvette has optional Goodyear Extended Mobility Tires (EMT’s), the tires will have “EMT” molded on the sidewalls. These tires perform so well without any air that a Low Tire Pressure Warning System (LTPWS) is used to alert you if a tire has lost pressure.
Page 207 Service and Appearance Care Inflation Tire Pressure The Tire-Loading Information label which is on the driver’s door shows the correct inflation pressures for your tires, when they’re cold. “Cold” means your vehicle has been sitting for at least three hours or driven no more than a mile. For competitive driving or high-speed driving (over 150 mph or 240 sure your tires are inflated to psi (240 kPa).
Page 208 When It’s Time for New Tires One way to tell when it’s time for new tires is to check the treadwear indicators, which will appear when your tires have only 2/32 inch (1.6 mm) or less of tread remaining. You need a new tire if You can see the indicators at three or more places around the tire.
Page 209 If the wheel leaks air, replace it (except some aluminum wheels, which can sometimes be repaired). See your Chevrolet dealer if any of these conditions exist. Your dealer will know the kind of wheel you need.
Page 210 If you need to replace any of your wheels, wheel bolts, or wheel nuts, replace them only with new GM original equipment parts. This way, you will be sure to have the right wheel, wheel bolts, and wheel nuts for your Corvette. NOTICE: The wrong wheel can also cause problems with bearing life, brake...
Page 211 Use a vacuum cleaner often to get rid of dust and loose dirt. Wipe vinyl or leather with a clean, damp cloth. Your Chevrolet dealer has two GM cleaners, a solvent-type spot lifter and a foam-type powdered cleaner. They will clean normal spots and stains very well.
Page 212 Use solvent-type cleaners in a well-ventilated area only. If you use them, don’t saturate the stained area. If a ring forms after spot cleaning, clean the entire area immediately or it will set. Using Foam-Type Cleaner on Fabric Vacuum and brush the area to remove any loose dirt.
Page 213 Service and Appearance Care Non-greasy stains: Such as catsup, coffee (black), egg, fruit, fruit juice, milk, soft drinks, wine, vomit, urine and blood. Carefully scrape off excess stain, then sponge the soiled area with cool water. If a stain remains, follow the foam-type instructions described earlier.
Page 214 Glass Glass should be cleaned often. GM Glass Cleaner (GM Part No. 1050427) or a liquid household glass cleaner will remove normal tobacco smoke and dust films. Don’t use abrasive cleaners on glass, because they may cause scratches. Avoid placing decals on the inside rear window, since they may have to be scraped off later.
Page 215 Service and Appearance Care Cleaning the Outside of Your Corvette The paint finish on your vehicle provides beauty, depth of color, gloss retention and durability. Washing Your Vehicle The best way to preserve your vehicle’s finish is to keep it clean by washing it often with lukewarm or cold water.
Page 216 These brushes can take off the protective coating. rires Your Chevrolet dealer has a GM White Sidewall Tire Cleaner. You can use a stiff )rush with the cleaner. When applying a tire dressing always take ;are to wipe off any overspray or splash...
Page 217 Although no defect in the paint job causes this, Chevrolet will repair, at no charge to the owner, the surfaces of new vehicles damaged by this fallout condition within 12 months or 12,000 miles (20 000...
Page 218 Appearance Care Materials Chart 12 oz.10.340 Powder" Bon-Ami Windshield cleaner 105001 1 'Not recommended for pigskin suede leather. See your General Motors Dealer for these products. See the Index under "Recommended Fluids and Lubricants" for other products.
Page 219 Service and Appearance Care Vehicle Identification Number (VIN) :his is the legal identifier for your lorvette. It appears on a plate in the front orner of the instrument panel, on the .river’s side. You can see it if you look hrough the windshield from outside your .chicle.
Page 220 Fuses and Circuit Breakers The wiring circuits in your vehicle are protected from short circuits by a combination of maxi-fuses, mini-fuses and circuit breakers. This greatly reduces the chance of fires caused by electrical problems. There are three fuse centers on your vehicle.
Page 221 Service and Appearance Care Instrument Panel Fuse Block A/C Module (5 Amp) Blank Windshield WiperNVasher Switch Assembly (30 Amp.) Radio Receiver Box (Ignition) Amp.) Heated Mirrors Amp.) Taillight, Daytime Running Lights Module (15 Amp.) .220 E o A 7 POWER WINDOW Horn Relay (15 Amp.) *Export Horn (20 Amp.) Hazard Flashers;...
Page 222 3, 5, 8 (LTI); Injectors Secondary Injector Relays (#1,2 (LT5); Secondary SF1 Control Modules (LT5) (10 Amp.) Turn Signal Flashers (10 Amp.) Ignition Coil and Ignition Coil Module (10 Amp.) Passive Keyless Entry Module Amp.) Instrument Cluster; Driver Information Center; Air Bag Derm; Acceleration Slip Regulation Switch (15 Amp.) Backup Lights Switch;...
Page 223 Service and Appearance Care INTERIOR LIGHTING RH HDLP 30A SECONDARY COOLING FAN EXTERIOR LIGHTING p i i i F i A A c c s y AIR PUMP .222 Forward Lamp Fuse Block Interior Lighting (20 Amp.) Primary Cooling Fan (30 Amp.) LH Headlight Motor (30 Amp.) RH Headlight Motor (30 Amp.) Secondary Cooling Fan (40 Amp.)
Page 224 Replacement Bulbs ........Air Conditioningmeater Control Automatic Transmission Indicator Backup...
Page 225 Service and Appearance Care Capacities and Specifications Engine Type Fuel Delivery Valve Arrangement VIN Engine Code J VIN Engine Code P Piston Displacement Bore ........VIN Engine Code J VIN Engine Code P Stroke...
Page 226 Replacement Parts ..........AirCleanerFilter Battery .
Page 227 If the air conditioning system in your vehicle needs refrigerant, be sure the proper refrigerant is used. If you’re not sure, ask your Chevrolet dealer. *Recheck fluid level after filling. See Part 6 or the Index.
Page 228 Vehicle Dimensions Wheelbase Tread Front Rear Coupe and Convertible ZR-1 Length Width Coupe and Convertible ZR-1 Height Coupe and ZR- 1 Convertible .96.2" (2 443 mm) 57.7" (1 466 mm) .59.1 (1 501 mm) .60.6" (1 539 mm) 178.5'' (4 534 mm) 70.7"...
Page 229 Service and Appearance Care Power Curves LT1 Engine 140 w ENGINE SPEED-RPM ,228 Power Curves LT5 Engine HORSEPOWER ENGINE SPEED-RPM 300 0 150 2 Belt Routing (Code Belt Routing (Code Engine Engine...
Page 230 IMPORTANT: KEEP THE ENGINE OIL AT THE PROPER LEVEL AND CHANGE AS RECOMMENDED T h i s part covers the maintenance required for your Corvette . Your vehicle needs these services to retain its safety. dependability and emission control performance . Maintenance Schedule Section Introduction: A Word about Maintenance...
Page 231 If you have any questions on how to keep your vehicle in good condition, see your Chevrolet dealer, the place many GM owners choose to have their maintenance work done. Your dealer can be relied upon to use proper parts and practices.
Page 232 This section tells you the maintenance services you should have done and when you should schedule them. Your Chevrolet dealer knows your vehicle best and wants you to be happy with it. If you go to your dealer for your service needs, you’ll know that GM-trained and...
Page 233 Maintenance Schedule Section A: Scheduled Maintenance Services Schedule Follow Schedule I if your vehicle is MAINLY driven under one or more of the following conditions: When most trips are less than 4 miles km). When most trips are less than 10 miles and outside temperatures remain below freezing.
Page 234 The services shown on this chart up to 48,000 miles (80 000 km) should be performed after 48,000 miles (80 000 km) at the same intervals. MILES (000) 233.
Page 235 Maintenance Schedule Section A: Scheduled Maintenance Services Schedule /I Follow Schedule I1 ONLY if none of the driving conditions specified in Schedule I apply. An Emission Control Service. Environmental Protection Agency or the California Air Resources Board has determined that the failure to perform this maintenance item will not nullify the emission warranty or limit recall liability prior to the completion of vehicle useful life.
Page 236 The services shown on this chart up to 45,000 miles (75 000 km) should be performed after 45,000 miles (75 000 at the same intervals. MILES (000) 22.5 KILOMETERS (000) 37.5 235.
Page 237 Maintenance Schedule Section A: Scheduled Maintenance Services Explanation of Scheduled Maintenance Services Following are explanations of the services listed in Schedule I and Schedule 11. The proper fluids and lubricants to use are listed in Section D. Make sure whoever services your vehicle uses these.
Page 238 ITEM NO. SERVICE Index. This provides proper freeze and boil protection, corrosion inhibitor level and maintains proper engine operating temperature. Inspect hoses and replace if they are cracked, swollen or deteriorated. Tighten screw-type hose clamps. Clean the outside of the radiator and air conditioning condenser.
Page 239 Maintenance Schedule Section B: Owner Checks isted below are owner checks and services which should be performed at the intervals specified to help ependability and emission control performance of your vehicle. Be sure any necessary repairs are completed at once. Vhenever any fluids or lubricants are added to your vehicle, make sure they are the proper ones, as shown in Section D.
Page 240 Once Year At Least Lubricate the key lock cylinders with the lubricant specified in Section D. Lubricate all body door hinges. Also lubricate all hinges and latches, including those for the hood, rear compartment, glove box door, console door and any folding seat hardware. Section D tells you what to use.
Page 241 Maintenance Schedule Section B: Owner Checks and Services At Least Once a Year (CONT.) CHECK OR SERVICE Brake-Transmission Shift Interlock BTSI (Automatic Transmis- sion) 1. Before you start, be sure you have enough room around the vehicle. It should be parked on a level surface.
Page 242 At Least Once a Year (CONI) CHECK OR SERVICE Parking Brake and Automatic Transmission “P” (Park) Mechanism Check Park on a fairly steep hill, with the vehicle facing downhill. Keeping your foot brake, set the parking brake. To check the parking brake: With the engine runriing and transmission in “N” (Neutral), slowly remove foot pressure from the regular brake pedal.
Page 243 Maintenance Schedule Section C: Periodic Maintenance Inspections isted below are inspections and services which should be performed at least twice a year (for instance, each spring and fall). You hould let your GM dealer’s service department or other qualified service center do these jobs. Make sure any necessary repairs are ompleted at once.
Page 244 INSPECTION SERVICE Manual Transmission Check the transmission fluid level; add if needed. See “Manual Transmission” in the Index. A fluid loss may indicate a problem. Check the system and repair Rear Axle Service Check the gear lubricant level in the rear axle and add A fluid loss may indicate a problem.
Page 245 Maintenance Schedule Section D: Recommended Fluids & Lubricants NOTE: Fluids and lubricants identified below by name, part number or specification may be obtained from your GM Dealer. USAGE FLUID/LUBRICANT Engine Oil API service SH or SG Energy Conserving I1 oils of the proper viscosity. To determine the preferred viscosity for your vehicle’s engine, see “Engine Oil”...
Page 246 USAGE Key Lock Cylinders Lubricate with Multi-Purpose Lubricant (GM Part No. 12345120) or synthetic SAE 5W-30 engine oil. Manual Transmission Chassis lubricant (GM Part No. 1052497 or equivalent) or lubricant meeting requirements of Shift Linkage NLGI Grade 2, Category LB or GC-LB. Automatic Engine oil.
Page 247 Maintenance Schedule Section D: Recommended Fluids & Lubricants USAGE Hood Latch Assembly a. Pivots and Spring a. Engine oil. Anchor b. Release Pawl b. Chassis lubricant (GM Part No. 1052497 or equivalent) or lubricant meeting requirements of NLGI Grade 2, Category LB or GC-LB. Hood and Door Engine oil or Lubriplate Lubricant (GM Part No.
Page 248 Section E: Maintenance Record After the scheduled services are performed, record the date, odometer reading and who performed the service in the columns indicated. When completing the Maintenance Performed column, insert the numbers from the Schedule I or Schedule I1 maintenance charts which correspond to the maintenance performed.
Page 249 Maintenance Schedule ODOMETER DATE SERVICED BY MAINTENANCE PERFORMED READING .24%...
Page 250 ODOMETER DATE SERVICED BY MAINTENANCE PERFORMED READING...
Page 251 Maintenance Schedule Section E: Maintenance Record (Cont.) DATE ODOMETER SERVICED BY MAINTENANCE PERFORMED READING .250...
Page 252: Part 8 Customer Assistance Information
H e r e you will find out how to contact Chevrolet if you need assistance. This part also tells you how to obtain service publications and how to report any safety defects. Customer Assistance Information ..
Page 253 Nature of concern We encourage you to call the toll-free number listed previously in order to give your inquiry prompt attention. However, if you wish to write Chevrolet, write to: Chevrolet Customer Assistance Center P.O. Box 7047 Troy, MI 48007-7047...
Page 254 GM Participation in BBB AUTO LZNE Alternative Dispute Resolution Program Both Chevrolet and your Chevrolet dealer are committed to making sure you are completely satisfied with your new vehicle. Our experience has shown that, if a situation arises where you feel your...
Page 255 In addition to notifying NHTSA (or Transport Canada) in a situation like this, we certainly hope you’ll notify us. Please call us at 1-800-222- 1020, or write: Chevrolet Customer Assistance Center P.O. Box 7047 Troy, MI 48007-7047 In Canada, please call us at 1-800-263-3777 (English) or 1-800-263-7854 (French).
Page 256 Courtesy Transportation will be offered in conjunction with the coverage provided by the BUMPER TO BUMPER Mew Vehicle Limited Warranty to retail and retail lease purchasers of 1994 Chevrolet passsenger cars and light-duty trucks. Courtesy Transportation includes: One-way SHUTTLE RIDE for any warranty repair completed during the same day.
Page 257: Part 9 Index
Individual PSP’s If you don’t want to buy all the PSP’s issued by Chevrolet for all car or truck models in the model year, you can buy individual PSP’s, such as those which may pertain to a particular model. To do this, you will first need to see our index of PSP’s.
Page 258 How You Can Get an Index: Indexes are published periodically. Most of the PSP’s which could potentially apply to the most recent Chevrolet models will be listed in the most recent publication for that model year. This means you may want to wait until the end...
Page 259 Model Number Form Price year. The indexes list all PSP's published by Chevrolet in the model year. 1894 Chevrolet Corvette Index NOTE: Year Form Number ......
Page 260 CHEVROLET SERVICE PUBLICATIONS ORDER FORM NOTE: Please complete form below (Print Post Office Box 07130, Detroit, Michigan 48207 PUBLICATION FORM NUMBER ST-364-94 Service Manual 10260935 Owner’s Manual In-Portfolio Owner’s Manual In-Portfolio 10260937 Owner’s Manual Without-Portfolio 10260941 Dealers and Companies please provide dealer or company name, and...
Page 261 Notes .260...
Page 262 A B S Acceleration Slip Regulation System ....Accessory Plug ....Acrylic Roof Panel .
Page 263 Chevrolet Roadside ....Assistance Chevrolet Service Publications ..(Ordering Information) ....
Page 264 Coolant Adding Engine ....Heater. Engine How to Add to the Coolant ... . . Recovery Tank How to Add to the Coolant .
Page 265 Index Engine ....58. 59 Running ....Starting Your Environment.
Page 266 ....Instrumeqt Cluster ....Instrument Panel ..Instrument Panel Fuse Block Instrument Panel.
Page 267 Index ..N e w Vehicle “Break-In” ....Night. Driving at ....Night Vision .
Page 268 12 1 ..Roads. Hill and Mountain ..Roadside Assistance. Canadian ..Roadside Assistance. Chevrolet Rocking Your Vehicle to Get It Out Roof Panel Installing Removing Storing .
Page 269 Index Shift Speeds ... . . Shifting into P (Park) ... Shifting out of P (Park) ..Six-Speed Manual Transmission Skidding Smaller Children and Babies...
Page 270 Transmitters. Passive Keyless ....Entry System ..Transportation. Courtesy ....Trip Odometer .
Page 271 Notes .270...
Page 272 Notes...
Page 273 Service Station Information Battery The Delco Freedoms battery needs no water. See Page 195 Cold Tire Pressure See Tire-Loading Information label on inside edge driver’s door. See Page 206 Fuel, Use unleaded gas only, 91 octane or higher. See Page 173 by using the dipstick.
Page 274 WE SUPPORT VOLUNTARY TECHNICIAN CERTIFICATION THROUGH National Institute for AUTOMOTIVE BERVICE EXCELLENCE...

Chevrolet 1994 Corvette Owner's Manual

Quick Links

Related Manuals for Chevrolet 1994 Corvette

Summary of Contents for Chevrolet 1994 Corvette

Page 2: Table Of Contents

Page 8: Part 1 Seats & Restraint Systems

Page 91: Part 3 Comfort Controls & Audio Systems

Page 173: Part 6 Service & Appearance Care 1 7

Page 252: Part 8 Customer Assistance Information

Page 257: Part 9 Index

Table of Contents
