EAW MS165 Specifications

The MS -165 represents an extension of EAW's engineering effort
to produce studio monitors with true flat response over the entire
listening area for quality assurance in audio production applications.
The use of a small, high output, specially dampened , cone driver for
the midband eliminates the problem of polar response in this critical
region. This results in considerably better response linearity off axis
than the popular two-way designs with large woofers.
The MS -165's wide bandwidth, high power handling and flat
response combine with its efficiency to result in powerful output
capabilities for larger mixdown and mastering applications. These
same features make the MS -165 ideal for high level playback
applications.
Specifi -cations:
Frequency Response
Axial+ 2 dB
Axial - 10 dB
Polar Response:
Sensitivity:
Power Handling
Long Term (100 hours)
Sine Wave:
Continuous Program:
Short Term Peak
(> 10 ms):
Maximum Sound Pressure Level
Continuous:
Program:
Nominal Impedance: 8 ohms
Crossover Frequency
Frequency:
Slope:
45 to 18k Hz
30 to 24k Hz
- 6 dB 15k Hz at 60'
97 dB SPL 1w at 1m
200 w RMS
350 w
500 w
120 dB SPL at 1m
123 dB SPL at 1m
450, 5,000 Hz
18 dB per octave
Bass Driver:
Nominal Diameter:
Voice Coil Diameter:
Flux Density:
Mid Driver:
Nominal Diameter:
Voice Coil Diameter:
Flux Density:
HF Driver:
`I~rpe:
Voice Coil Diameter:
Flux Density:
Enclosure T~rpe:
Dimensions:
L15/542
380mm (15in)
75mm Pin)
13,000 gauss
MF -170A
170mm (6.5in)
38mm (1.5in)
14,600 gauss
CD-2070/AL-80
Compression Driver/Lens
26mm (lin)
14,500 gauss
Vented 170 liter box
223/411 x 303/4" x 181/8"
