Intel NUC 11 Performance User Manual page 10

A
20V
A
Thunderbolt™ 4 Port
Connect any USB Type C or Thunderbolt device into this port, such as a USB Flash drive or an
external storage device. This port will also support displays using a Type-C to DisplayPort cable.
Power Connector
Connect the AC adapter into this connector
B
HDMI Port
Supports high-definition digital video connections
C USB 3.2 Gen2 Port
Connect any USB device into this port, such as a USB flash drive, keyboard, or mouse.
D Wireless Antenna
8
B C
Left Side
D
