  • Page 1 W515PU...
  • Page 3 Preface Notebook Computer W515PU Service Manual...
  • Page 4 Version 1.0 September 2016 Trademarks Intel, Pentium and Celeron are trademarks/registered trademarks of Intel Corporation. ® Windows is a registered trademark of Microsoft Corporation. Other brand and product names are trademarks and /or registered trademarks of their respective companies.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the W515PU se- ries notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. FCC Statement This device complies with Part 15 of the FCC Rules.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 LCD ....................A-5 Schematic Diagrams......... B-1 Overview ..................1-1 Specifications ..................1-2 System Block Diagram ..............B-2 External Locator - Top View with LCD Panel Open ......1-4 SOC 1/6 ..................B-3 External Locator - Front & Right Side Views .........1-5 SOC 2/6 ..................B-4 External Locator - Left Side &...
  • Page 12 Preface AC-In Conn .................. B-30 Power SW Board ................B-31 Click Board .................. B-32 Updating the FLASH ROM BIOS..C-1 Download the BIOS ............... C-1 Unzip the downloaded files to a bootable CD/DVD or USB Flash drive ................C-1 Set the computer to boot from the external drive ......C-1 Use the flash tools to update the BIOS ..........

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the W515PU series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri- vers (e.g.

  • Page 14: Specifications

    Security (Kensington® Type) Lock Slot BIOS Password 11.6" (29.46cm), 16:9, HD (1366x768) (Thickness: 3.6mm) Intel PTT for Systems Without TPM Hardware Memory Slots One 204 Pin SO-DIMM Socket Supporting DDR3L 1600/ Slot 1 (M.2) for WLAN and Bluetooth Combo Module 1866 MHz Memory ...
  • Page 15 Built-In Gigabit Ethernet LAN 1.0M HD PC Camera Module (Factory Option) 3G or 4G M.2 Module WLAN/ Bluetooth M.2 Modules: (Factory Option) Intel® Wireless-N 7265 Wireless LAN (802.11b/g/n) + Bluetooth 4.0 (Factory Option) Intel® Wireless-AC 3165 Wireless LAN (802.11ac) + Bluetooth 4.0 (Factory Option) Intel®...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated in red 3. Built-In Microphone 4. LCD 5.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicators FRONT VIEW Figure 3 RIGHT SIDE VIEW Right Side View 1. USB 2.0 Ports 2. Multi-in-1 Card Reader 3. RJ-45 LAN Jack 4. DC-In Jack External Locator - Front &...

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Security Lock Slot 2. External Monitor Port LEFT SIDE VIEW 3. Vent 4. HDMI-Out Port 5. USB 3.0/3.1 Port 6. Microphone-In Jack 7. Headphone-Out Jack Figure 5 Rear View REAR VIEW...

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Speakers 3. Fan Intake/Vent  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC ITE IT8987E 2. ALC269 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. Mini-Card Connector (3G/ mSATA module) 2. HDD Connector 3. M.2 Connector (WLAN Module) 4. Memory Slot DDR3L SO-DIMM 5. CPU Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. External Monitor Port 2. HDMI-Out Port 3. USB 3.0 Port 4. Microphone-In Jack 5. Headphone-Out Jack 6. Keyboard Cable Connector 1 - 10 Mainboard Overview - Top (Connectors)

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. CCD Cable Connector 2. LCD Connector 3. Fan Cable Connector 4. Touchpad Connector 5. Power Switch Connector 6. Speaker Connectors Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the W515PU series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Click Board: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. Figure 1 2. Slide the latch in the direction of the arrow (Figure 1a Battery Removal 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a 4.

  • Page 30: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 2 1. Turn off the computer and remove the battery (page 2 - Keyboard Removal 2. Use only the small tool provided (see picture below) to carefully press the four keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (Figure 2a).

  • Page 31: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 3 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 7mm Removal (h) and a speed of 5400 RPM or lower. Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 32 Disassembly 5. Slightly lift and pull the hard disk in the direction of arrow (Figure 4c Figure 4 6. Lift the hard disk out of the bay (Figure 4d HDD Assembly 7. Reverse the process to install a new hard disk (do not forget to replace all the screws and cover). Removal (cont’d.) c.

  • Page 33: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 5 RAM Module The computer has a memory socket for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L Up to 1600/1866MHz. The main memory can be expanded up to 8GB. The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 34 Disassembly 5. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. Figure 6 6. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot RAM Module as it will go.

  • Page 35: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 7 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5), keyboard (page 2 - 6), and bottom case (page 2 - Module Removal 2. The Wireless LAN module will be visible at point (Figure 7a on the mainboard.

  • Page 36: Wireless Lan, And Combo Module Cables

    Disassembly Wireless LAN, and Combo Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 37: Removing The Click Board Module

    Disassembly Removing the Click Board Module Figure 8 Click Board Module 1. Turn off the computer, remove the battery (page 2 - 5), keyboard (page 2 - 6), bottom case (page 2 - 7), and Removal WLAN (page 2 - 11).

  • Page 38: Removing The Ccd Module

    Disassembly Removing the CCD Module Figure 9 CCD Module 1. Turn off the computer, remove the battery (page 2 - Removal 2. Turn the computer over, run your fingers around the inner frame of the LCD panel at the points indicated by the arrows (Figure 9a a.

  • Page 39: Part Lists

    Part Lists Appendix A:Part Lists This appendix breaks down the W515PU series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 40: Parts List Illustration Location

    Part Lists Parts List Illustration Location The following table indicates where to find the appropriate parts list illustration. Table A - 1 Parts List Illustration Parts Location page A - 3 Bottom page A - 4 page A - 5 A - 2 Parts List Illustration Location...

  • Page 41: Top

    Part Lists Figure A - 1 Top A - 3...

  • Page 42: Bottom

    Part Lists Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 43: Lcd

    Part Lists Figure A - 3 LCD A - 5...
  • Page 44 Part Lists A - 6 LCD...

  • Page 45: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams Table B - 1 This appendix has circuit diagrams of the W515PU notebook’s PCB’s. The following table indicates where to find the SCHEMATIC appropriate schematic diagram. DIAGRAMS Diagram - Page Diagram - Page Diagram - Page...

  • Page 46: System Block Diagram

    Schematic Diagrams System Block Diagram 1.8VS,3.3VA,3.3V,3.3VS 5 IN 1 6-7P-W51P5-003 5V,5VS W510PU Apollo Lake System Block Diagram W510PU MAIN BOARD SHEET 20 SHEET 2~26 6-71-W51P0-D03 1.8VA,1.24VA,1.05VS IO BOARD SHEET 21 USB2.0 x2,SPEAK CONN 85ohm 6.5 inch CARD READER CON,RJ45 CONN 1600/ 1866 MHz VDD5,VDD3 SHEET 27~28...

  • Page 47: Soc 1/6

    Schematic Diagrams SOC 1/6 U24B APL_SOC APL_SOC U24A M_A_A[15:0] DDR1 BG16 M_A_A15 DDR0 BG57 DDR3_M1_MA_15 BG15 DDR3_M0_MA_15 M_A_A14 BG56 M_A_DQ[63:0] DDR3_M1_MA_14 BJ34 M_A_DQ63 DDR3_M0_MA_14 DDR3_M1_DQ_63 M_A_A13 BG46 DDR3_M0_DQ_63 DDR3_M1_MA_13 DDR3_M0_MA_13 BG37 M_A_DQ62 BG13 DDR3_M1_DQ_62 M_A_A12 BG54 DDR3_M0_DQ_62 DDR3_M1_MA_12 BH37 M_A_DQ61 BH13 DDR3_M0_MA_12 DDR3_M1_DQ_61...
  • Page 48 Schematic Diagrams SOC 2/6 1.8VA APL_SOC 2.2K_04 2.2K_04 U24C MCSI_DP_0 MCSI_DN_0 MCSI_DP_1 MCSI_DN_1 HDMI_CTRLCLK HDMI_SCL-C [10] MCSI_DP_2 MTDK3S6R MCSI_DN_2 [10] HDMI_DATA0P DDI0_TXP_0 MCSI_DP_3 HDMI [10] HDMI_DATA0N DDI0_TXN_0 MCSI_DN_3 HDMI_CTRLDATA HDMI_SDA-C [10] MTDK3S6R [10] HDMI_DATA1P DDI0_TXP_1 MCSI_CLKP_0 [10] HDMI_DATA1N DDI0_TXN_1 MCSI_CLKN_0 1.8VA [10] HDMI_DATA2P...

  • Page 49: Soc 3/6

    Schematic Diagrams SOC 3/6 U24D APL_SOC 1.8VA C315 0.1u_10V_X7R_04 PCIE_TXP0_C SATATXP0 [18] [18] PCIE_TXP0_GLAN PCIE_TXP0 SATA_TXP0 C318 0.1u_10V_X7R_04 PCIE_TXN0_C SHORT SATATXN0 [18] [18] PCIE_TXN0_GLAN PCIE_TXN0 SATA_TXN0 [18] PCIE_RXP0_GLAN PCIE_RXP0 SATA_RXP0 SATARXP0 [18] [18] PCIE_RXN0_GLAN SATARXN0 [18] PCIE_RXN0 SATA_RXN0 C322 0.1u_16V_Y5V_04 64Mbit SATA_TXP1/USB3_TXP5 PCIE_TXP1...
  • Page 50 Schematic Diagrams SOC 4/6 U24F APL_SOC USB_OTG_ID USB2.0 AC15 USB3.0 USB_OTG_ID [14] USB3_TX0_P USB_PP0 [14] USB3_TXP0 USB_DP0 [14] USB3_TX0_N USB3_TXN0 USB_DN0 USB_PN0 [14] APL PIN W51xPU STRAP W51XPU Default [14] USB3_RX0_P USB3_RXP0 Note [14] USB3_RX0_N USB3_RXN0 USB_DP1 USB_PP1 [18] USB_PN1 [18] UART1_TXD pull up *4.7K...

  • Page 51: Soc 5/6

    Schematic Diagrams SOC 5/6 VCGI VNN_SVID U24H APL_SOC 4.8A AA36 AJ37 VCC_VCGI_1 VNN_SVID_1 AA37 AJ39 VCC_VCGI_2 VNN_SVID_2 C288 C305 AA39 AJ41 C128 C136 C140 C113 C282 C117 VCC_VCGI_3 VNN_SVID_3 AC36 AJ42 VCC_VCGI_4 VNN_SVID_4 22u_6.3V_X5R_08 22u_6.3V_X5R_08 47uF_6.3V_X5R_08 47uF_6.3V_X5R_08 47uF_6.3V_X5R_08 AC37 AJ46 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04...

  • Page 52: Soc 6/6

    Schematic Diagrams SOC 6/6 APL_SOC APL_SOC U24J U24K APL_SOC U24L APL_SOC U24M POWER-VSS POWER-VSS POWER-VSS POWER-VSS AG42 AK36 BB19 AN54 VSS_70 VSS_1 VSS_1 VSS_69 VSS_1 VSS_71 AG44 AR19 BB25 AN56 AC20 VSS_71 VSS_2 VSS_2 VSS_70 VSS_2 VSS_72 RSVD_1 NCTF_3 AG46 AR32 AN57 AM32...

  • Page 53: Level Shifter

    Schematic Diagrams Level Shifter 3.3VS 1.8VS SB_KBCRST# G-SENSOR 3.3VA 1.8VA PLT_RST# 3.3V R274 R487 R485 R484 *0_04 10K_04 SOC_PWROK 10K_04 10K_04 R285 100K_04 R254 SOC_G_INT1 BUF_PLT_RST#_R [19] 10K_04 SOC_KBCRST# R250 10K_04 2SK3018S3 2SK3018S3 C203 C207 2SK3018S3 C356 *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 2SK3018S3 2SK3018S3 [14]...

  • Page 54: Ddr So-Dimm_0

    Schematic Diagrams DDR SO-DIMM_0 SO-DIMM A JDIMM1A JDIMM1B M_A_A[15:0] M_A_DQ[63:0] M_A_A0 M_A_DQ14 M_A_A1 M_A_DQ13 1.35V M_A_A2 M_A_DQ10 M_A_A3 M_A_DQ9 M_A_A4 M_A_DQ11 VDD1 VSS16 M_A_A5 M_A_DQ12 VDD2 VSS17 M_A_A6 M_A_DQ8 VDD3 VSS18 M_A_A7 M_A_DQ15 Layout Note: VDD4 VSS19 M_A_A8 M_A_DQ5 VDD5 VSS20 M_A_A9 M_A_DQ6...

  • Page 55: [10] Hdmi Port

    Schematic Diagrams HDMI Port HDMI CONNECTOR HDMI_5VS (W/O LEVELSHIFT) HDMI_5VS RB751S-40G C341 *BAV99 RECTIFIER VOUT *10u_6.3V_X5R_06 R177 R187 *BAV99 RECTIFIER C333 C334 J_HDMI1 2.2K_04 2.2K_04 *BAV99 RECTIFIER SY6288DAAC D03 0419 R125 100K_04 HDMI_SCL-C [8,23] SUSB HDMI_HPD-C HDMI_SDA-C uP7549UMA5-20 HOT PLUG DETECT HDMI_HPD-C PCB Footprint = M-SOT23-5A HDMI_HPD-C...

  • Page 56: Ps8625

    Schematic Diagrams PS8625 PS8625 (Odd) VDDIO VDDIO VDDIO VDDIO LVDS-L0N [12] LVDS-L0P [12] LVDS-L1N [12] LVDS LVDS LVDS LVDS LVDS LVDS-L1P [12] C281 VDDIO *HCB1005KF-121T20 *10K_04 *10K_04 *0.1u_10V_X7R_04 *0.1u_10V_X7R_04 3.3VS 6-19-31001-247 VDDIO LVDS-L2N [12] LVDS-L2P [12] PS8625_PD# RST# PIN50 PIN38 LVDS-LCLKN [12] LVDS...

  • Page 57: Panel Con

    Schematic Diagrams Panel Con PANEL CONN LVDS Default eDP +w/o driver ic 40pin(M116XW05-V1FH/N116XW05) LED PANEL (LVDS Dual Channel).CO-LAYOUT eDP-old PANEL eDP +w/o driver ic 40pin(M116XW05-V1FH/N116XW05) LED_VDD *BCIHP0730-100M *SK34SA eDP + w/ driver ic 40pin(N116BGE-EB2) C257 C258 C260 R348 C274 C271 C269 J_LCD1 3.3VS...

  • Page 58: Rtd2168-Cg, Crt

    Schematic Diagrams RTD2168-CG, CRT Embedded LDO POWER Select VCCK_V12 source from external 1.2V or embedded LDO 3.3VS 3.3VS VGA_HPD VGA_HPD AVCC33 AUX_CH_N EP Mode 0.1u_10V_X5R_04 VGA_AUX_CH_N FCM1005MF-600T01 AUX_CH_P 0.1u_10V_X5R_04 4.7K_04 Ra R156 pull up VCCK_V12 from LDO enable VGA_AUX_CH_P Pin2, Pin3 should be connected to EC for EP mode Rb R157 pull down VCCK_V12 from external *1u_6.3V_X5R_04 0.1u_10V_X5R_04...

  • Page 59: Tpm / Usb / G-Sensor

    Schematic Diagrams TPM / USB / G-Sensor G SENSOR SLB9665TT Only NOTE:LPC POWER 3.3VA R471 0_04 3.3VA G_SENSOR 3.3V R466 *0_04 C185 10u_6.3V_X5R_06 3.3V R463 *0_04 G_SENSOR 3.3VS C186 0.1u_10V_X7R_04 3.3V_GSENSOR [5,16] LPC_AD0 LAD0 VDD1 3.3V_GSENSOR [5,16] LPC_AD1 LAD1 VDD2 [5,16] LPC_AD2 LAD2...

  • Page 60: Mini Pcie / M.2 Card (3G/Wlan

    Schematic Diagrams Mini PCIE / M.2 Card (3G/WLAN) MINI 3G CARD / LTE 3G POWER 3G_3.3V C301 220u_6.3V_6.3*6.3*4.2 0.1u_16V_Y5V_04 mSATA function only, mount 0_06_2A J_3G1 R110 *0_06_2A 3.3VS WAKE# 3.3VAUX_0 R100 *0_06_2A COEX1 1.5V_0 3G_3.3V UIM_PWR 0.1u_16V_Y5V_04 COEX2 UIM_PWR UIM_DATA >3A >3A UIM_DATA...

  • Page 61: Kbc Ite It8987

    Schematic Diagrams KBC ITE IT8987 MODEL_ID PROJECT NAME IT8987 KBC_AVDD V1.0 W510PU V1.0 W515PU R473 0_04 [19] AIRPLAN_LED# HCB1005KF-121T20 V1.0 W517PU VDD3 VDD3 VDD3 C347 C151 C159 C162 C179 MODEL_ID R234 10K_04 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 R236 *10K_04 C153...

  • Page 62: Audio Codec Alc269Q-Vc2

    Schematic Diagrams Audio Codec ALC269Q-VC2 AUDIO CODEC ALC269 VC2 For 1.5V HDA Link. DVDD_IO PVDD1_2 HCB1005KF-121T20 R298 0_04 1.8VS C223 C220 C234 C232 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 PIN9 PIN9 PIN39 PIN39 3.3VS 3.3VS_AUD C228 HCB1005KF-121T20 C227 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 5VS_AUD C216 C221 C224 PIN46...

  • Page 63: Conn, Ccd, Fan, Click

    Schematic Diagrams Conn, CCD, Fan, Click CONN TO I/O BOARD CCD + Internal DIGITAL MIC RTC_VBAT VDD3 3.3VS CCD_PWR J_BTB1 3.3VS VOUT USB_PP1 C259 C254 USB_PN1 USB_PP2 1u_6.3V_X5R_04 2.2u_6.3V_X5R_04 USB_PN2 PCIE_WAKE0# UP7553 PCIE_RXP0_GLAN PCIE_RXN0_GLAN [16] CCD_EN PCIE_TXN0_GLAN PCIE_TXP0_GLAN CLK_PCIE_GLAN CLK_PCIE_GLAN# LAN_CLKREQ# SPKOUTRR+ USB_PN6_R...

  • Page 64: Emmc / Led/ Hole/Nut

    Schematic Diagrams eMMC / LED/ Hole/Nut eMMC 3.3VA +V3P3A_EMMC +V1P8A 1.8VA eMMC eMMC eMMC eMMC R214 0_04 R215 0_04 R278 *0_04 R281 *0_04 3.3VA 1.8VA eMMC C208 C149 C160 C156 C158 C155 C157 C154 C161 C206 EM5209 eMMC eMMC eMMC eMMC eMMC eMMC...

  • Page 65: System Power

    Schematic Diagrams System Power P2808 VIN1 VDD3 VDD3 DEBUG USE VDD3 VIN1 47K_04 47K_04 74AHC1G08GW R342 10K_04 DTC114EUA CHANGE 2N3904 VIN1 RSMRST# TJE-532-Q-T/R R343 1_1%_06 DD_ON_P 100K_04 DD_ON 2SK3018S3 [16] EC_RSMRST# DD_ON_LATCH Zener Diode-->5V or 6V M_BTN#_P PWR_SW#_R R344 10K_04 R361 10K_04 [18]...

  • Page 66: 1.05Vs / 1.24Va / 1.8Va

    Schematic Diagrams 1.05VS / 1.24VA / 1.8VA 1.05VS/1.24VA/1.8VA PR22 180K_1%_04 G5383A VIN_PAD 1.05VS_TON PC46 PC65 PC48 1.05VS 1u_25V_X5R_06 4.7u_25V_X5R_08 4.7u_25V_X5R_08 PR93 1.05VS_BST 1.5_04 1.05VS PC13 SYS1.05V 0.1u_10V_X5R_04 PC54 1.05VS_LX 4.7u_6.3V_X5R_06 BCIHP0730-1R0M PC107 PC101 PC105 PC109 *OPEN-5mm PR91 0_04 AGND defaul PR120 PC93 LX_PAD...

  • Page 67: [22] Vdd3,Vdd5

    Schematic Diagrams VDD3, VDD5 VDD3/VDD5 PC149 1000p_50V_X7R_04 Iout=6A Freq OCP=13A I=2.1A Ripple=mV PR73 0_04 LDO5 Freq.385~420khz +V5_LDO PR143 VDD5_TON 220K_1%_04 PC151 +HDW 5HDWLQJ &XUUHQW $ PR142 10u_6.3V_X5R_06 6DWXUDWLRQ &XUUHQW $ 0_04 P 0$; LDO5 VDD5_EN PR140 PC152 VDD5_BST SYS5V VDD5 0_04 0.1u_10V_X5R_04 PJ27...

  • Page 68: [23] Vtt_Mem/1.35V

    Schematic Diagrams VTT_MEM/1.35V 1.35V/0.675VS PC143 PC153 PC154 PC148 VDDQ VTT_MEM G5616BRZ1U PQ13 PC141 QM3004M3 1.35V PC33 10u_6.3V_X5R_06 VDDQ_VBST VLDOIN VBST PR137 Short VDDQ_DRVH_R 0.1u_10V_X5R_04 PJ12 0_04 VTT_MEM_R VDDQ_DRVH Short VTT_MEM DRVH VDDQ PL10 PJ29 *OPEN-2mm BCIHP0730-1R0M VDDQ_L PR69 VTTGND 1.35V PC31 PC30 *20mil_04...

  • Page 69: Vcgi

    Schematic Diagrams VCGI VREF VREF 1.05VS 0.1u_10V_X7R_04 PR28 PR48 PR42 PR45 7.5K_1%_04 80.6K_1%_04 22.6K_1%_04 2.2_04 *75_1%_04 51K_1%_04 VREF H_PROCHOT# PR29 PR49 121_1%_04 0_04 1.05VS AU1_SET1 PR47 84.5_1%_04 AU1_SET2 VDD3 VBOOT SET to 0V AU1_SET3 VREF H_CPU_SVIDCLK [5,25] AU1_PSYS defaul H_CPU_SVIDDAT [5,25] PJ17 PJ18...

  • Page 70: Vnn

    Schematic Diagrams PC79 0.1u_10V_X7R_04 PR108 2.2_04 VNN_VREF 1.05VS VNN_VREF VNN_VREF 1.05VS PR109 PR14 46.4K_1%_04 169_1%_04 PR95 PR98 PR99 PR38 75_1%_04 32.4K_1%_04 620K_1%_04 200K_1%_04 150K_1%_04 H_CPU_SVIDCLK [5,24] 3.3VA VNN_EN [16] VDD3 H_CPU_SVIDDAT [5,24] H_CPU_SVIDALRT# [5,24] EWTF02-104F4F-N R506 PR106 AU2_SET1 *10K_04 0_04 PR37 10K_04 AU2_SET2...

  • Page 71: Ac-In, Charger

    Schematic Diagrams AC-In, Charger SMART CHARGER PR12 *20mil_04 PC55 0.1u_25V_X7R_06 EMB20P03V V_BAT PC86 PC81 PC80 PC62 PC61 PR116 20K_04 PQ12 HCB2012KF-800T80 EMB20P03V PD10 PR97 PR123 *FMS3004-AS-H BCIHP-0730 8R2M 0.01_1%_32 0.01_1%_32 PC78 PR46 0.1u_50V_Y5V_06 470K_04 PC87 PR82 PR56 PR52 PR55 2_1%_04 100K_04 0_04 0_04...

  • Page 72: I/O Board

    Schematic Diagrams I/O Board CONN TO M/B USB2.0 Port0 A_RTC_VBAT A_VDD3 A3.3VS A_19V AUSB_VCC0 A_J_BTB1 AUSB_PP0 100 mil AUSB_PN0 VOUT AUSB_PP1 AUSB_PN1 AC17 A_PCIE_WAKE0# [28] 0.1u_16V_Y5V_04 22u_6.3V_X5R_08 22u_6.3V_X5R_08 A_DD_ON# 10u_6.3V_X5R_06 *220u_6.3V_6.3*6.3*4.2 A_PCIE_RXP0_GLAN [28] A_PCIE_RXN0_GLAN [28] A_PCIE_TXN0_GLAN [28] SY6288D20AAC A_GND A_GND A_PCIE_TXP0_GLAN [28] A_GND...
  • Page 73 Schematic Diagrams RTL8411B SD_CMD/MS_D2 AR24 0_04 SD_CMD/MS_D2_R SD_D0/MS_D1 AR26 0_04 SD_D0/MS_D1_R LAN (RTL8411B) SD_D1 AR27 0_04 SD_D1_R SD_D2/MS_CLK AR30 0_04 SD_D2/MS_CLK_R Switching Regulator close to PIN48 SD_CLK/MS_D0 AR25 0_04 SD_CLK/MS_D0_R RSET AR12 2.49K_1%_04 A_GND SD_D3/MS_D3 AR29 0_04 SD_D3/MS_D3_R AR11 *1K_04 VDD10 A_GND XTAL2...
  • Page 74 Schematic Diagrams AC-In Conn AC IN Connector BJ_DC_JACK1 BJ_BTB1 B_ACIN GND1 GND2 PH115C-006G12P ZI90-06221-11RY Sheet 29 of 31 AC-In Conn BGND BGND *H3_5D1_6 *O3_5x4_0D1_5x2_0 *MTH6_0D2_2 *MTH6_0D2_2 BGND BGND BGND BGND PCBA CHECK H6_0D3_7 1BBR *0_04 4BBR *0_04 2BBR *0_04 5BBR *0_04 3BBR *0_04...

  • Page 75: [30] Power Sw Board

    Schematic Diagrams Power SW Board POWER SW & LED S_3.3VS SVDD3 POWER SWITCH SVDD3 100K_04 S_3.3VS SJ_SW1 470_04 20mil AH9249NTR-G1 20mil SLID_SW# SM_BTN# SMGND SLID_SW# *0.1u_10V_X5R_04 Sheet 30 of 31 50578-0060N-001 *1u_10V_Y5V_06 0.1u_16V_Y5V_04 *100p_50V_NPO_04 Power SW Board SMGND SMGND SMGND SMGND SMGND SMGND...

  • Page 76: [31] Click Board

    Schematic Diagrams Click Board CLICK CONN CTP_VCC CJ_TP4 CTP_CLK CTP_VCC CTP_VCC CTP_DATA CTPBUTTON_L CJ_TP2 CGND CTPBUTTON_R CJ_TP1 0.1u_16V_Y5V_04 CTP_CLK CGND CSMB_CLK CTP_DATA CSMB_DATA CTP_CLK CTPBUTTON_L CTP_DATA CTPBUTTON_R *FP225H-008S11M FP226H-004S10M 50578-0060N-001 CGND CGND CJ_TP3 CSMB_CLK CSMB_DATA Sheet 31 of 31 CGND CTP_CLK W510 &...

  • Page 77: Updating The Flash Rom Bios

    BIOS Update Appendix C:Updating the FLASH ROM BIOS  BIOS Version To update the FLASH ROM BIOS, you must: Make sure you down- • Download the BIOS update from the web site. load the latest correct version of the BIOS ap- •...

  • Page 78: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “EFI Shell”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by EFI Shell.
